Electro-Voice Variplex II User manual

Key Features:
• 3-Way Design for Intelligibility, Clarity
and Extended Dynamic Range
• Asymmetric Directed Coverage tm
Technology for even coverage and
simple installation
• Very Linear Frequency Response
• Digital Dynamic Capable tm, wide
dynamic range
• Compact and Fully assembled
• Triamp or Biamp Operation
VariplexTM II
Tri-Amplified or Bi-Amplified
Variplex 3-Way High-Power
Screen Channel Speaker
General Description:
The Electro-Voice Variplex is designed to provide
perfect coverage, wide bandwidth, and extended
dynamic range in today’s Cinemas. It uses second-
generation asymmetric directed coverage to uniformly
cover every seat in stadium or traditional theaters. This
design greatly reduces energy wasted by focusing it on
the audience, not walls and ceiling where it can be
reflected to degrade clarity. Ring-Mode Decoupling
(RMDtm) incorporated into the transducers improves
system transient detail that further refines system sound
quality at all SPLs. The Variplex’s 3-way design allows
each frequency range’s transducers to be optimized for
low distortion, high power handling, and smooth
frequency response. Two high power 8-inch midrange
transducers clearly and accurately reproduce dialog,
music and effects in detail. A neodymium 3-inch
diameter compression driver with titanium diaphragm
delivers high level response past 16 kHz. Careful
attention to crossover and waveguide design further
enhances coverage and response. Variplex’s
asymmetric coverage directs energy for uniform
coverage from front to rear, simply placing the aiming
axis at the row two thirds from the front provides each
seat exceptional sound. The easily adjustable bracket
provides aiming versatility for difficult installations. The
product line of EV cinema speakers includes
subwoofers and surround speakers that provide
excellent performance to match the screen system.
Technical Specifications:
:)Bd01-(egnaR.qerFzHk81-zH43
:)Bd3-/+(esnopseR.qerFzHk61-zH14
:ytivitisneSmetsySBd901:FH/FM,Bd101:FL
:LPSdetaluclacxaMBd141:FH/FM,Bd631:FL
:).tnoC(sgnitaRrewoP
:)kaeP(sgnitaRrewoP
W57:FH,W004:FM,W008:FL
W003:FH,W0061:FM,W0023:FL
:egarevoClatnoziroH°09
:egarevoClacitreV)°03-,°02+(°05
:tliTtekcarBpU°51,nwoD°5
:)ID(xednIytivitceriD01
dednemmoceR
:revossorC
RLBd42;zH005
:stnenopmoC
TS606LT
:gnitaRrewoP)kaePW0023(W008
)reifilpmAdednemmoceRW0001(
:srotcennoCtupnIpirtsreirrablanimretwercS
:ecnadepmItupnIsmhO4
:srecudsnarT.aiD"51,TS51LDx2
:)DxWxH(snoisnemiD"5.71x"5.52x"5.93
)mm544xmm846xmm3001(
:thgieWteN)gk9.94(sbl011
:thgieWgnippihS)gk4.45(sbl021
IIxelpiraVKPH
:gnitaRrewoPW57/W004FH/FM
)kaePW003/W0061(
)reifilpmAdednemmoceRW006(
:srotcennoCtupnIpirtsreirrablanimretwercS
:ecnadepmItupnIsmhO4
:srecudsnarT8-6DN,.aiD"8,HD-8VEx2
:)DxWxH(snoisnemiD"4.51x"5.52x"3.63
)mm293xmm846xmm129(
:thgieWteN)gk5.92(sbl56
:thgieWgnippihS)gk1.43(sbl57

Block Diagram: Frequency Response:
Dimension Drawings:
Beamwidth:
Directivity:
Performance Match:
• Dx38 Digital Processor
• TL440 Subwoofer
• TL880 Subwoofer
• TL440M Subwoofer
• TL880DM Subwoofer
• CPS Series Amplifiers
• SL10-2V Surround Speaker
• SL12-2V Surround Speaker
• SL6.2M Surround Speaker
12000 Portland Avenue South, Burnsville, MN 55337
Phone:[phone], Fax:[phone]
www.electrovoice.com
© Telex Communications, Inc. 4/2003
Part Number 38110-172 Rev A
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: [phone]
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 736-4212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
