Electro-Voice Active Subwoofer SB2A User manual

The new Electro-Voice SB2A powered 12-inch subwoofer eliminates the need
for external system processing and amplification, addressing the demand for
lightweight high performance portable sound systems.
Featuring dual 350 watt amplifiers, the SB2A’s switch-able powered speaker
output can drive either an external 8 ohm passive subwoofer or full range
loudspeaker. This makes SB2A a supremely versatile and compact “sub system
drive” solution, easily configured with a variety of loudspeakers for a multitude of
sound reinforcement applications.
Typical SB2A-powered Electro-Voice system setups include: with a ZX1-90,
as a standalone PA that fits in the front seat of your car; in clusters with Sx100
or Sx300’s; with a passive SB122, for portable lightweight sub extension to
replace bulky 15-inch two-way systems (two 16kg packages vs. one 40kg
package); with an additional powered top box (such as the SxA100+). The
possibilities are endless!
The SB2A shares the same durable injection-molded enclosure as EV’s popular
passive SB122 subwoofer. Both utilize the EVS12S woofer, designed from the
ground up for optimized performance within this small footprint enclosure.
SB2A: REDEFINING “SUB SYSTEM DRIVE”
your
UNLEASH

Key Features:
• VeryCompactandLightweight-Only35.3lbs/16.0kg
• IntegralHandle
• TwoDigitalPowerAmpliers
• 350WDedicatedLF,350WSwitchable
• NeutrikSpeakonHighCurrentOutputConnector
• CastFrameEVS12SB12-inchHigh-ExcursionSubwooferDriver
• IntegralElectronicCrossover/Processor-NoAdditionalAmplierorProcessorNeeded
Frequency Response:
BoschCommunicationsSystems
TelexCommunications,Inc.
12000 Portland Ave South,
Burnsville,MN55337,USA
USA–Ph:1-800-392-3497
Fax: [phone]
©2008TelexCommunications,Inc.
PA#20691
20
50
100
1000
10000
20000
3.16
10
100
316
70
80
90
100
110
Fre que ncy (Hz)
Sensitivity (dB)
Impedance (Ohms)
Frequency Response, Half
Space, -10 dBu Input
Freq. Response1 (-3 dB): 55Hz-165Hz
Freq. Range1 (-10 dB): 43Hz-275Hz
HipassAmplierRange: 66Hz-16kHz
Coverage: EssentiallyOmnidirectional
Subwoofer Amplifier Power: 350WRMS
Switchable Amplifier Power: 350WRMSLF
Transducer: EVS12SB,12in(305mm)Driver
Connectors:
LineInputs:
BalancedLineOutput:
XLRand1/4”PhoneCombinationXLR
SwitchableAmplierOutput: NeutrikNL4
Power Requirement: 110-130VAC,50-60Hz,or220-240
VAC,50-60Hz,
600Watts
Enclosure Material: Copolymer
Grille: PowderCoatedSteel
Dimensions(HxWxD): 586mm x 429mm x 312mm
(23.1” x 16.9” x 12.3”)
NetWeight: 16.0 kg (35.3 lbs)
ShippingWeight: 17.9kg(39.5lbs)
