Electrolux TanGO SOLO ST User manual

TANGO®
SOLO ST
EN User manual *
*Original instructions TG9920- 2020.05

2
Installation diagram TANGO SOLO ST
629
420
80
90
130
185
140
55
35
97
753
512
50 min
300 min
CW I
D O
EI
391
618
629
370
420
453
255

3
Installation diagram TANGO SOLO ST with fridge
501
629
420
80
130
185
140
55
35 205
310
50 min
300 min
97
512
753
CW I
D O
EI
EI
ES
654
703
255
435
ES
EI
360
629
400

4
DO = Drain outlet
EI = Electricity inlet
CWI = Cold water inlet G 3/8″

5
Foreword
The installation, use and maintenance manual (hereinafter Manual) provides the user with information necessary for correct
and safe use of the machine (or “appliance“).
The following must not be considered a long and exacting list of warnings, but rather a set of instructions suitable for improving
machine performance in every respect and, above all, preventing injury to persons and animals and damage to property due to im-
proper operating procedures.
All persons involved in machine transport, installation, commissioning, use and maintenance, repair and disassembly must con-
sult and carefully read this manual before carrying out the various operations, in order to avoid wrong and improper actions that
could compromise the machine's integrity or endanger people. Make sure to periodically inform the user regarding the safety regu-
lations. It is also important to instruct and update personnel authorised to operate on the machine, regarding its use and
maintenance.
The manual must be available to operators and carefully kept in the place where the machine is used, so that it is always at hand
for consultation in case of doubts or whenever required.
If, after reading this manual, there are still doubts regarding machine use, do not hesitate to contact the Manufacturer or the au-
thorised Service Centre to receive prompt and precise assistance for better operation and maximum efficiency of the machine.
During all stages of machine use, always respect the current regulations on safety, work hygiene and environmental protection. It
is the user's responsibility to make sure the machine is started and operated only in optimum conditions of safety for people, ani-
mals and property.
IMPORTANT
• The manufacturer declines any liability for operations carried out on the appliance without respecting the instructions
given in this manual.
• The manufacturer reserves the right to modify the appliances presented in this publication without notice.
• No part of this manual may be reproduced.
• This manual is available in digital format by:
– contacting the dealer or reference customer care;
– downloading the latest and up to date manual on the web site;
• The manual must always be kept in an easily accessed place near the machine. Machine operators and mainte-
nance personnel must be able to easily find and consult it at any time.

6
Contents
A SAFETY INFORMATION.........................................................................................................................7
A.1 General information ......................................................................................................................7
A.2 General safety .............................................................................................................................7
A.3 Personal protection equipment ........................................................................................................ 8
A.4 Transport, handling and storage ......................................................................................................8
A.5 Installation and assembly ............................................................................................................... 9
A.6 Water connection..........................................................................................................................9
A.7 Electrical connection .....................................................................................................................9
A.8 Use ......................................................................................................................................... 10
A.9 appliance cleaning and maintenance .............................................................................................. 10
A.10 Service..................................................................................................................................... 10
A.11 Disposal of packing..................................................................................................................... 10
A.12 Machine disposal........................................................................................................................ 11
B WARRANTY TERMS AND EXCLUSIONS................................................................................................. 11
C GENERAL SAFETY RULES................................................................................................................... 11
C.1 Introduction............................................................................................................................... 11
C.2 Mechanical safety characteristics, hazards....................................................................................... 11
C.3 Protection devices installed on the machine ..................................................................................... 11
C.4 Main switch ............................................................................................................................... 11
C.4.1 Appliance with 2 positions main switch................................................................................... 12
C.5 Safety signs to be placed on the machine or near its area.................................................................... 12
C.6 Instructions for use and maintenance .............................................................................................. 12
C.7 Reasonably foreseeable improper use ............................................................................................ 12
C.8 End of use ................................................................................................................................ 12
C.9 Residual risks ............................................................................................................................ 12
D GENERAL INFORMATION .................................................................................................................... 13
D.1 Introduction............................................................................................................................... 13
D.2 Definitions................................................................................................................................. 13
D.3 Machine and manufacturer's identification data ................................................................................. 13
D.4 Additional indications................................................................................................................... 14
D.5 Responsibility ............................................................................................................................ 14
D.6 Copyright.................................................................................................................................. 14
D.7 Keeping the manual .................................................................................................................... 14
D.8 Recipients of the manual .............................................................................................................. 14
E NORMAL USE .................................................................................................................................... 14
E.1 Characteristics of personnel enabled to operate on the machine ........................................................... 14
E.2 Characteristics of personnel trained for normal machine use ................................................................ 14
E.3 Operator qualified for normal machine use ....................................................................................... 14
F TECHNICAL CHARACTERISTICS .......................................................................................................... 15
F.1 Data table ................................................................................................................................. 15
G DESCRIPTION PRODUCT .................................................................................................................... 15
G.1 Overview .................................................................................................................................. 15
H OPERATING....................................................................................................................................... 15
H.1 Switching on.............................................................................................................................. 15
H.2 Coffee...................................................................................................................................... 15
H.3 Screen (display) ......................................................................................................................... 16
H.4 Screen during an infusion ............................................................................................................. 16
H.5 Screen : Quick access / code ........................................................................................................ 16
I DAILY CLEANING................................................................................................................................ 16
I.1 Intro......................................................................................................................................... 16
I.2 Rinsing cycle ............................................................................................................................. 17
I.3 Daily cleaning cycles (duration ~10 minutes) .................................................................................... 17
I.4 Cleaning milk (in the case of a milk pump system) ............................................................................. 17
I.5 External cleaning........................................................................................................................ 17
J MAINTENANCE .................................................................................................................................. 17
J.1 Maintenance intervals.................................................................................................................. 17
J.1.1 Preventive Maintenance ..................................................................................................... 17
J.2 Preventive maintenance for coffee products ..................................................................................... 18
J.2.1 Preventive maintenance for milk pump .................................................................................. 19
J.3 Softener ................................................................................................................................... 19
J.4 Machine disposal........................................................................................................................ 19

7
A SAFETY INFORMATION
A.1 General information
To ensure safe use of the appliance and a proper understanding of the manual it is
necessary to be familiar with the terms and typographical conventions used in the
documentation. The following symbols are used in the manual to indicate and identify the
various types of hazards:
WARNING
Danger for the health and safety of operators.
WARNING
Danger of electrocution - dangerous voltage.
CAUTION
Risk of damage to the machine or the product.
IMPORTANT
Important instructions or information on the product
Read the instructions before using the appliance
Clarifications and explanations
A.2 General safety
• The machine must not be used by people (including children) with limited physical,
sensory or mental abilities or without experience and knowledge of it, unless instructed
in its use and supervised by those responsible for their safety.
– Do not let children play with the machine.
– Keep all packaging and detergents away from children.
– Cleaning and user maintenance shall not be made by children without supervision.
• For suitable personal protection equipment, refer to chapter “A.3 Personal protection
equipment“.
• Several illustrations in the manual show the machine, or parts of it, without guards or
with guards removed. This is purely for explanatory purposes. Do not install the machine
without the guards or with the protection devices deactivated.
• Do not remove, tamper with or make illegible the safety, danger and instruction signs
and labels on the machine.
• Do not remove or tamper with the machine’s safety devices.
• Before carrying out any machine installation, always consult the installation manual,
which gives the correct procedures and contains important information on safety.
• Unauthorized personnel must not enter the work area.
• Remove any flammable products or items from the work area.
• Machine positioning, installation and disassembly must be carried out by the specialised
personnel in conformity with the current safety regulations, regarding the equipment
used and the operating procedures.

8
A.3 Personal protection equipment
Summary table of the Personal Protection Equipment (PPE) to be used during the various stages of the machine's
service life.
Stage Protective
garments
Safety
footwear
Gloves Glasses Safety
helmet
Transport —● ○ —○
Handling —● ○ — —
Unpacking —● ○ — —
Installation ○ ● ○1— —
Normal use —○— — —
Adjustments —○ ○ — —
Routine
cleaning
— — ○2— —
Extraordi-
nary
cleaning
○ ● ○ ○ —
Maintenance ○ ● ○ ○ —
Dismantling ○ ● ● ○ —
Scrapping ○ ● ● ○ —
Key:
●PPE REQUIRED
○PPE AVAILABLE OR TO BE USED IF NECESSARY
—PPE NOT REQUIRED
1. During these operations, gloves must be cut-resistant. Failure to use the personal protection equipment by
operators, specialized personnel or users can involve exposure to damage to health (depending on the
model).
2. During these operations, gloves must be suitable for contact with chemical substances used (refer to the
safety data sheet of the substances used for information regarding the required PPE). Failure to use the
personal protection equipment by operators, specialized personnel or users can involve exposure to
chemical risk and cause possible damage to health (depending on the model).
A.4 Transport, handling and storage
• Due to their size, the machines cannot be stacked on top of each other during transport,
handling and storage; this eliminates any risks of loads tipping over due to stacking.
• Do not stand under suspended loads during loading or unloading operations.
Unauthorized personnel must not enter the work area.
• The weight of the appliance alone is not sufficient to keep it steady.
• For machine lifting and anchoring, do not use movable or weak parts such as: casings,
electrical raceways, pneumatic parts, etc.
• Do not push or pull the machine to move it, as it may tip over. Use proper tool to lift the
machine.
• Machine transport, handling and storage personnel must be adequately instructed and
trained regarding the use of lifting systems and personal protection equipment suitable
for the type of operation carried out.

9
A.5 Installation and assembly
• The installation must be carried out by a specialised personnel.
• Follow the installation instruction supplied with the appliance.
• Do not install a damaged appliance. Any missing or faulty parts must be replaced with
original parts.
• Do not make any modifications to the parts supplied with the appliance.
• Disconnect the appliance from the power supply before carrying out any installation
procedure. Connect the appliance to the power supply only at the end of the installation.
• The appliance is not suitable for installation outdoors and/or in places exposed to
atmospheric agents (rain, direct sunlight, freeze, humid and dusty location, etc.).
• Make sure that the floor where you install the appliance is flat, stable, heat resistant and
clean.
• Access to the service area is limited to persons with the necessary knowledge of safety
and hygiene as well as practical experience of the device.
• Leave enough free space around the appliance to facilitate its use and to preform any
maintenance operations.
A.6 Water connection
• The plumbing connections must be carried out by a specialised personnel.
• The machine is to be connected to the water mains using the new supplied hose-sets.
Do not use old hose sets.
• Always use a new set of joints if you remove and re-install the water inlet pipe to the
machine.
• Before connection to new pipes, pipes not used for a long time, where repair work has
been carried out or new devices fitted (water meters, etc.), let the water flow until it is
clean and clear.
• The operating water pressure (minimum and maximum) must be between:
– 1 bar [0.1 MPa] and 8 bar [0.8 MPa];
• Make sure that there are no visible water leaks during and after the first use of the
machine.
• Install an approved dual check valve upstream according to the regulation of the
installation country.
A.7 Electrical connection
• Work on the electrical systems must only be carried out by a specialised personnel.
• Make sure that the electrical information on the rating plate agrees with the power supply.
• Make sure to install the appliance in accordance with the safety regulations and local
laws of the country where used.
• If the power cable is damaged it must be replaced by the Customer Care Service or in
any case by specialised personnel, in order to prevent any risk.
• The appliance must be correctly earthed. The manufacturer is not responsible for the
consequences of an inadequate earthing system.
• To protect the power supply of the appliance against short circuits and/or overloads,
install a thermal fuse or a suitable automatic thermal magnetic circuit breaker, ADS
(Automatic Disconnection of Supply).
• To protect the power supply of the appliance against current leakages, install a high-
sensitivity manual reset RCD (Residual Current Device), suitable for overvoltage
category III.
For protection against indirect contacts, refer to point 6.3.3 of EN 60204-1 (IEC 60204-1)
with the use of protection devices that ensure automatic cut-off of the supply in case of

10
isolation fault in the TN or TT systems or, for IT systems, the use of isolation controllers
or differential current protection devices to activate automatic power disconnection (an
isolation controller must be provided for indicating a possible first earth fault of a live part,
unless a protection device is supplied for switching off the power in case of a such a fault.
This device must activate an acoustic and/or visual signal which must continue for the
entire duration of the fault). For example: in a TT system, a residual current device with
cut-in current (e.g. 30 mA) coordinated with the earthing system of the building where
the appliance is located must be installed ahead of the supply.
A.8 Use
• The appliance must be used in room with an ambient temperature of 5℃to 35℃(41℉-
95℉).
• If it is stored at an ambient temperature below 5℃(41℉) the water circuit (boiler-piping)
must be drained.
• In case of emergency (fire, surge, abnormal noise, etc. the first thing to do is to cut off the
current and close the water tap.
• Make sure not to obstruct the air inlets of the appliance with towels or other objects.
• Beware of hot surfaces such as cup heaters, the unit heads and the hot water and steam
outputs. Never install containers filled with liquid on the top of the appliance.
A.9 appliance cleaning and maintenance
• Refer to “A.3 Personal protection equipment“ for suitable personal protection equipment.
• Put the appliance in safe conditions before starting any maintenance operation.
Disconnect the appliance from the power supply and carefully unplug the power supply
cable, if present.
• Depending on the model and type of electric connection, during maintenance operations,
the cable and plug must be kept in a visible position by the operator carrying out the work.
• Do not touch the appliance with wet hands or feet or when barefoot.
• Do not remove the safety guards.
• Respect the requirements for the various routine and extraordinary maintenance
operations. Non compliance with the instructions can create risks for personnel.
• Extraordinary maintenance, checking and overhaul operations must only be carried out
by a specialised personnel or the Customer Care Service, provided with suitable
personal protection equipment (safety shoes and gloves), tools and ancillary means.
• Do not clean the appliance with jets of water.
Repair and extraordinary maintenance
• Repair and extraordinary maintenance have to be carried out by specialised authorised
personnel. The manufacturer declines any liability for any failure or damage caused by
the intervention of an unauthorized technician by the Manufacturer and the original
manufacturer warranty will be invalidated.
• The appliance should be descaled only by a specialised personnel.
• Do not forget to regenerate your water softener periodically.
A.10 Service
• Only original spare parts can ensure the safety standards of the appliance.
A.11 Disposal of packing
• Dispose of each packaging items respecting the current regulation in the country of
installation.
