Electrolux EHT 60418 User manual

Gas hob
EHT 60418
operating instructions
IL

2electrolux

electrolux 3
Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully will
provide you with lots of pleasure in the future.
The Electrolux ambition is to offer a wide variety of quality products that make
your life more comfortable.
You find some examples on the cover in this manual. Please take a few minutes
to study this manual so that you can take advantage of the benefits of your new
machine.
We promise that it will provide a superior User Experience delivering Ease-of-
Mind.
Good luck!

4electrolux
This appliance is manufactured according to the following EEC directives:
2006/95 EEC - 2004/108 EEC - 90/396 EEC,
current edition.
Guide to Use the instructions
The following symbols will be found in the text to guide you throughout the Instructions:
Safety Instructions
Step by step instructions for an operation
Hints and Tips
Environmental Information
)
Contents
Instructions for the User
Important Safety Information 5
Description of the Hob 7
Operation 8
Maintenance and Cleaning 10
Something Not Working? 12
Service and original spare parts 22
Instructions for the Installer
Engineers Technical Data 13
Gas Connection 16
Electrical Connection 17
Commissioning 18
Building In 19
Possibilities for Insertion 21
MANUFACTURER:
ELECTROLUX ITALIA S.p.A.
C.so Lino Zanussi, 30 – 33080 Porcia - PN (ITALY)

electrolux 5
During Operation
• Thisappliance hasbeendesignedfornonprofessionalpurposeinprivatehousesonly.Itismeant
to cook edible foodstuff only and MUST NOT be used for any other purposes.
• It is dangerous to alter the specification in any way.
• Forhygiene and safety reasons,this appliance should bekept clean at alltimes. A build-up offats
orotherfoodstuff could result inafire.
• Do not use this hob if it is in contact with water. Do not operate the hob with wet hands.
• Never leave the hob unattended when cooking with oil and fats.
• Unstableormisshapenpansshouldnotbeusedonthehobasunstablepanscancauseanaccident
by tipping or spillage.
• Never use plastic or aluminium foil dishes on the hob.
• Perishablefood,plasticitemsandareosolsmaybeaffected byheatandshouldnotbestored above
or below the hob unit.
• Underno circumstancesshouldyouattemptto repairtheapplianceyourself. Repairscarriedoutby
unexperienced persons may cause injury or serious malfunctioning. Refer to your local Service
Centre. Always insist on genuine spare parts.
• Ensure that all control knobs are in the OFF position when not in use.
• Shouldyouconnectanyelectricaltooltoaplugnearthiscookingappliance,ensurethatelectriccables
are not in contact with it and keep them far enough from the heated parts of this appliance.
•Iftheappliance is out of order,disconnectit from the electric supply.
People Safety
• Thisapplianceisnotintendedforusebychildrenorotherpersonswhosephysical,sensoryormental
capabilities or lack of experience and knowledge prevents them from using the appliance safely
withoutsupervision orinstructionbyaresponsible persontoensurethat theycanusetheappliance
safely.
• Thisappliancehas been designedtobeoperatedbyadultsand children undersupervision.Young
children MUST NOT be allowed to tamper with the controls or play near or with the oven.
These warnings are provided in the interest of safety. You must read them carefully before
installing or using the appliance.
It is most important that this instruction book should be retained with the appliance for future
reference. Should the appliance be sold or transferred, always ensure that the book is left
with the appliance in order that the new owner can get to know the functions of the appliance
and the relevant warnings.
These instructions are only valid for countries whose identification symbols are shown on
the cover of this instruction booklet and on the appliance itself.
Important Safety Information
ENGLISH

6electrolux
• Accessible parts of this appliance may become hot when it is in use. Children should be KEPT AWAY
untilithascooled.
• The residual heat indicator comes on when the cooking zone is switched on. Children should be
kept away until it switches off.
• Children can also injure themselves by pulling pans or pots off the hob.
About Installation, Cleaning and Manteinance
• Itismandatorythatalloperationsrequiredfortheinstallationarecarriedoutbyaqualifiedorcompetent
person,in accordance withexistingrulesandregulationsin force inthecountrywheretheappliance
isused.
• Ensure a good ventilation around the appliance. A poor air supply could cause lack of oxygen.
• Ensurethatthegasandelectricalsupplycomplieswiththetypestatedontheidentificationlabel,placed
near the gas supply pipe.
• Thisapplianceisnotconnected toacombustionproductsevacuationdevice.Itmustbeinstalled and
connectedinaccordancewithcurrentinstallationregulations.Particularattentionshallbegiventothe
relevantrequirementsregarding ventilation.
•The use of a gas cooking appliance results in the production of heat and moisture in the
room in which it is installed. Ensure that the kitchen is well ventilated: keep natural
ventilation holes open or install a mechanical ventilation device (mechanical extractor
hood).
•Prolonged intensive use of the appliance may call for additional ventilation, for example
opening of a window, or more effective ventilation, for example increasing the level of
mechanical ventilation where present.
• Onceyouremovedall packaging from the appliance,ensurethat it is not damagedandthe electric
cableis in perfectconditions.Otherwise,contactyour dealerbeforeproceedingwiththe installation.
• Disconnecttheappliancefromtheelectricalsupply, beforecarryingoutanycleaningormanteinance
work.
• This appliance cannot be cleaned with steam or with a steam cleaning machine.
• Never use the hob as a working space. Do not store things on the hob.
• Never use plastic or aluminium foil dishes on the glass hob, as they could melt on the hob, thus
damaging it.Anyway,If anything of this nature accidentally comes into contact with the glass surface
it must be scraped off immediately while stlll hot and wiped away to avoid damage to the surface. In
the same way, remove sugar or food residues with hich sugar content, which may have split from
saucepans by using a scraper for glass hobs.
• Unstable or misshapen pans should not be used on the hob as unstable pans can cause an accident
by tipping or spillage.
• The glass hob is shockproof, but not unbreakable! Hard or pointed objects falling from a height can
damage the hob. If scratches or cracks are noticed, disconnect the appliance from the electrical
supply to avoid the risk of electric shock and call you nearest Service Force Centre.
Never use scratching sponges, abrasive products or chemically powerful detergents. Use only
cleaning agents specific for glass hobs.
• The manufacturer disclaims any responsability should all the safety measures not be
carried out.

electrolux 7
Description of the Hob
Service
• Undernocircumstances should you attempttorepairtheapplianceyourself.Repairs carried out by
unexperienced persons may cause injury or serious malfunctioning. Refer to your local Service
Centre. Always insist on genuine spare parts.
Environmental Information
• Afterinstallation,pleasedisposeofthepackagingwithdueregardtosafetyandtheenvironment.
• Whendisposingofanoldappliance,makeitunusable,bycuttingoffthecable.
• The symbol on the product or on its packaging indicates that this product may not be treated
ashouseholdwaste.Insteaditshallbe handedovertotheapplicablecollectionpointfortherecycling
ofelectrical andelectronicequipment.Byensuring thisproductisdisposedof correctly,youwillhelp
prevent potential negative consequences for the environment and human health, which could
otherwisebe caused byinappropriatewastehandlingofthis product. Formoredetailedinformation
aboutrecyclingofthisproduct,pleasecontactyourlocalcityoffice,yourhouseholdwastedisposal
service or the shop where you purchased the product.
1. Hob Top
2. Rapid Burner
3. Semi-rapid Burner
4. Auxiliary Burner
5. Control knob for back right burner (semi-rapid)
6. Control knob for back left burner (semi-rapid)
7. Control knob for front left burner (rapid)
8. Control knob for front right burner (auxiliary)
1
35678
3
4
2

8electrolux
Hob Burners
To light a burner:
zTurn the relevant knob anticlockwise to maximum
position and push down the knob to ignite.
zAfter lighting the flame, keep the knob pushed down
for about 5 seconds. This will allow the
"thermocouple" (Fig. 1 - lett. D) to be heated and
the safety device to be switched off, otherwise the
gas supply would be interrupted. Then, check the
flame is regular and adjust it as required.
If you cannot light the flame even after several attempts,
check the "cap" (Fig. 1 - lett. A) and “crown” (Fig. 1 -
lett. B) are in the correct position.
To put the flame out, turn the knob to the symbol .
In the absence of electricity, ignition can occur without the electrical device; in
this case approach the burner with a flame, push the relevant knob down and
turn it anti-clockwise until it reaches the"maximum" position.
When switching on the mains, after installation or a power cut, it is quite normal
for the spark generator to be activated automatically.
Operation
INSTALLATION
Any gas installation must be carried out by qualified personnel, and in
accordance with existing rules and regulations.
The relevant instructions are to be found in the second section of this manual.
Please, ensure that, once the hob is installed, it is easily accessible for the
engineer in the event of a breakdown.
The manufacturer will not accept liability, should the above instructions or any
of the other safety instructions incorporated in this book be ignored.
WHEN THE HOB IS FIRST INSTALLED
Once the hob has been installed, it is important to remove any protective materials,
which were put on in the factory.
The symbols mean:
= no gas supply
= maximum gas supply
= minimum gas supply
)
)
Fig. 1
A- Burner cap
B- Burner crown
C- Ignition electrode
D- Thermocouple

electrolux 9
Burner minimum maximum
diameter diameter
Large (rapid) 160 mm 260 mm
Medium (semi-rapid) 120 mm 220 mm
Small (auxiliary) 80 mm 160 mm
As soon as a liquid starts boiling, turn down the flame so that it will barely keep the liquid
simmering.
Use only pans or pots with flat bottom.
If you use a saucepan which is smaller than the recommended size, the flame will
spread beyond the bottom of the vessel, causing the handle to overheat.
Carefully supervise cooking with fat or oil, since these types of foodstuff can result in a fire,
if over-heated.
Prolonged cooking with potstones, earthenware pans or cast-iron plates is
inadvisable. Also, do not use aluminium foil to protect the top during use.
Make sure pots do not protrude over the edges of the cooktop and that
they are centrally positioned on the rings in order to obtain lower gas
consumption.
Do not place unstable or deformed pots on the rings: they could tip
over or spill their contents, causing accidents.
Pots must not enter the control zone.
If the control knobs become difficult to turn, please contact your local Service
Force Centre.
Do not keep the control knob pressed for more than 15 seconds.
If the burner does not light even after 15 seconds, release the control knob, turn it the
"off" position and wait for at least one minute before trying to light the burner again.
If the burner accidentally goes out, turn the control knob to the "off" position and wait
for at least 1 minute before trying to light the burner again.
Using the hob correctly
To ensure maximum burner efficiency, it is strongly recommended that you use only pots
and pans with a flat bottom fitting the size of the burner used, so that flame will not spread
beyond the bottom of the vessel (see the table beside).

10 electrolux
Before any maintenance or cleaning can be carried out, you must DISCONNECT
the hob from the electricity supply.
The hob is best cleaned whilst it is still warm, as spillage can be removed more
easily than if it is left to cool.
This appliance cannot be cleaned with steam or with a steam cleaning machine.
The pan supports
To ensure a better cleaning, pan supports can be removed from the hob (Fig. 2).
Pay attention when placing the
pan supports back on their
position, in order to avoid
scratching the glass hob top.
Thepansupports arenotdishwasher
proof; they must be washed by hand.
Take care when drying them as the
enamellingprocessoccasionallyleaves
rough edges. If necessary, remove
stubbornstainsusingapaste cleaner.
After cleaning, make sure that the pan
supportsarecorrectlypositioned.
The hob top
Regularly wipe over the hob top using a soft clothwell wrung out in warm water to which
a little wasingup liquid has been added.
Avoid the use of thefollowing:
- household detergent and bleaches;
- impregnated pads unsuitable for non-sticksaucepans;
- steel wool pads;
- bath/sink stain removers.
If scratches or cracks are noticed, disconnect the appliance from the
electrical supply to avoid the risk of electric shock and call your nearest
Service Force Centre.
Keep all objects and materials which can melt away from the cooking surface,
e.g. plastics, aluminium foil.
Maintenance and Cleaning
Fig. 2

electrolux 11
The burners
The burner caps and crowns can be removed for cleaning.
Wash the burners taps and crowns using hot soapy water, and remove marks with a mild
paste cleaner. A well moistened soap impregnated steel wool pad can be used with
caution, if the marks are particularly difficult to remove.
After cleaning, be sure to wipe dry with a soft cloth.
Ignition electrode
The electric ignition is obtained through a ceramic "electrode" and a metal electrode
(Fig. 1 - letter C). Keep these components well clean, to avoid difficult lighting, and
check that the burner crown holes are not obstructed.
Periodic maintenance
Periodically ask your local Service Centre to check the conditions of the gas supply pipe
and the pressure adjuster, if fitted.

12 electrolux
Something Not Working?
If the hob is not working correctly, please carry out the following checks before contacting
your local Electrolux Service Force Centre.
SYMPTOM
There is no spark when lighting the
gas.
The gas ring burns unevenly.
SOLUTION
Check that the unit is plugged in and
the electrical supply is switched on.
Check that the general safety switch
has not tripped (if fitted).
Check the burner cap and crown
have been replaced correctly, e.g.
after cleaning.
Check the main jet is not blocked and
the burner crown is clear of food
particles.
Check the burner cap and crown
have been replaced correctly, e.g.
after cleaning.

electrolux 13
OVERALL DIMENSIONS Width: 580 mm
Depth: 510 mm
CUT OUT DIMENSIONS Width: 550 mm
Depth: 470 mm
APPLIANCE CLASS 3
SUPPLY CONNECTIONS Gas:
RC 1/2 inch (1/2 inch male) Rear right hand corner
Electric:
230 V ~50 Hz supply, 3 core flexible cable with non
rewireable plug.
HEAT INPUT
Rapid Burner 2.45 kW
Semi-Rapid Burner 1.6 kW
Auxiliary Burner 0.95 kW
APPLIANCE CATEGORY I3
GAS SUPPLY LPG 30 mbar (1 mbar = 10 mm water coloumn)
Engineer technical data

14 electrolux
Table 2 : Injectors
Table1 : By-pass diameters
NOMINALPOWER LPG (Butane “A”) FEEDING
PRESSURE
BURNER kW kCal/h nozzle g/h
mbar
Auxiliary
burner 0,95 814 50 75
Semi-rapid
burner 1,60 1368 066 126 30
Rapid
burner 2,45 2095 77 193
Burner Ø By-pass in 1/100 mm.
Auxiliary 28
Semi-rapid 35
Rapid 45

electrolux 15
zThefollowing instructions aboutinstallation and maintenancemust be carriedout
by qualified personnel in compliance with the regulation in force.
zThe appliance must be electrically disconnected before all interventions. If any
electric supply to the appliance is required to carry out the work, ensure all the
necessaryprecautionsarefollowed.
zThe side walls of the unit in which the hob is going to be installed, must not exceed
the height of the working top.
zAvoidinstallingtheapplianceintheproximityofinflammablematerials(e.g.curtains,
tea towels etc.).
THE MANUFACTURER WILL NOT ACCEPT LIABILITY, SHOULD ANY OF THE OTHER
SAFETY INSTRUCTIONS INCORPORATED IN THIS BOOKLET OR THE REGULATION IN
FORCE BE IGNORED.
Instruction for the Installer

16 electrolux
Connection using flexible non metal pipes
When the connection can be easily inspected in its full extent, there is the chance to use a flexible pipe
according to the rules in force. The flexible pipe must be tightly fixed using clamps according to the rules
in force.
Use the rubber pipe holder «D». Always insert the gasket «B» (Fig.3). Then proceed with the gas
connection. The flexible pipe should be made ready for use in such a way that:
- nowhere it can reach overtemperature, other than room temperature, higher than 30°C;
- it is no longer than 1500 mm;
- it shows no throttles;
- it is not subject to traction or torsion;
- it doesn't get in touch with cutting edges or corners;
- it can be easily inspected in order to check its condition.
The control of preservation of the flexible pipe consistsin
checking that:
- it doesn't show cracks, cuts, marks of burnings bothon
the end parts and on its full extent;
- the material is not hardened, but shows its normal
elasticity;
- the fastening clamps are not rusted;
- expiry term is not due.
If one or more abnormalities are seen, do not repair the
pipe, but replace it. Fig. 3
A) Ramp with ending nut
B) Seal
C) Adjustable connection
D) Rubber pipe holder for liquid gas
D
Gas Connection
Choose fixed connections or use a flexible pipe instainless steel in compliance with the regulation in
force. If using flexible metallic pipes, be careful they do not come in contact with mobile parts or they are
not squeezed. Use the same attention when the hob is combinated with an oven.
IMPORTANT - To ensure a correct operation, a saving of energy and the long life of the appliance,
the voltage pressure of the appliance must correspond to the recommended values.
The adjustable connection has to be fixed to the comprehensive ramp by means of a threaded nut G
1/2".
Interpose the sealing between the components as shown in Fig. 3.
Screw the parts without forcing, adjust the connection in the required direction and tighten everything.

electrolux 17
Any electrical work required to install this appliance should be carried out by a
qualified electrician or competent person, in accordance with the current regulations.
THIS APPLIANCE MUST BE EARTHED.
Themanufacturerdeclinesanyliabilityshouldthesesafetymeasuresnotbeobserved.
This appliance is designed to be connected to a 230 V ~50Hz AC electrical supply.
Before the appliance is connected:
1) check that the main fuse and the domestic installation can support the load (see the rating label);
2) check that the power supply is properly earthed in compliance with the current rules;
3) check the socket or the double pole switch used for the electrical connection can be easily reached
with the appliance built in the forniture unit. Before switching on, make sure the electricity supply
voltage is the same as that indicated on the appliance rating plate. The rating plate is located on the
bottom of the hob. Acopy is attached on the back cover of this book.
The appliance is supplied with a 3 core flexible supply cord incorporating a plug. Connect the plug to an
adequate socket.
Permanent connection
In the case of a permanent connection, it is necessary that you install a double pole switch between the
appliance and the electricity supply (mains), with a minimum gap of 3 mm between the switch contacts
and of a type suitable for the required load in compliance with the current electric regulations.
The switch must not break the yellow and green earth cable at any point.
Ensure that the hob supply cord does not come into contact with surfaces with
temperatures higher than 50 deg. C.
Electrical Connection
It is important to install the elbow correctly, with the shoulder on the end of the thread, fitted to the
hob connecting pipe.
Failure to ensure the correct assembly will cause leakage of gas.
IMPORTANT
Once installation is complete, check the perfectseal of every pipe fitting, using a soapy solution,
never a flame.

18 electrolux
Commissioning
Fig. 4
By-pass screw
When the hob has been fully installed it will be necessary to check the minimum flame setting.
To do this, follow the procedure below.
- Turn the gas tap to the MAX position and ignite.
- Set the gas tap to the MIN flame position then turn
the control knob from MIN to MAX several times.
If the flame is unstable or is extinguished follow
the procedure below.
Procedure:
Re-ignite the burner and set to MIN.
Remove the control knob, insert a thin
bladed screwdriver down the centre of the gas tap control shaft and turn the adjustment
screw until the flame is steady and does not extinguish, when the knob is turned from MIN
to MAX. Repeat this procedure for all burners.
)

electrolux 19
Building In
A= Auxiliary burner
SR = Semi-rapid burner
R= Rapid burner
Dimensions are given in millimeters
The hob can be inserted in a built-in kitchen unit
whose depth is between 550 mm and 600 mm.
The hobs dimensions are shown in Fig. 5.
The edge of the cut out must have a minimum
distance from the rear wall of 55 mm.
If there are side walls, or sides of the furniture unit
near the hob, the cut out edges must have a
minimum distance of 150 mm.
Hanging forniture units or hoods must be placed
at 650 mm minimum from the hob.
580
510
R
SR
SR
A
Fig. 5
Fig. 6

20 electrolux
Fitting the hob to the worktop
Before fitting the hob into the cut out, an adhesive
seal must be fitted to the underside outside edge
of the hob. It is essential that no gaps are left in this
seal in order to prevent spillage near the hob
seeping into the cabinet below.
1) Remove the pan supports, the burners caps
and crowns and turn the hob upside down,
taking care the ignition candles are not
damaged in this operation.
2) Place the relevant sealing all around the glass
top edge, taking care that the sealings meet
without overlapping (Fig. 7).
3) Place the hob in the cut out, taking care of its
centring.
4) Fix the hob with the supplied fixing clamps
(Fig. 8).
A) Sealing gasket
Fig. 7
Fig. 8
A
