Electrolux OT350 User manual

EN Accessories

1. CABINET ASSEMBLY INSTRUCTIONS
1.1 Product range
1 2 3 4
5 6 78
1. OT350 (height 380 - 650 mm)
2. OT450 (height 450 - 750 mm)
3. OT500 (height 500 - 800 mm)
4. OT700 (height 700 - 1000 mm)
5. O250 (height 250 mm)
6. O300 (height 300 mm)
7. O350 (height 350 mm)
8. O550 (height 550 mm)
Components supplied
A
B
C
D
F
G
E
A) Handle screw, 4 x 15 mm (1x)
B) Steering screws, 4,2 x 13 mm (4x)
C) Locking screw, 4,2 x 14 mm (2x)
D) Assembly brackets (2x)
E) Double-sided tape (2x)
F) Handle (1x)
G) Plastic rivets (10x) (only for OT
models)
www.electrolux.com2

Choose the door opening direction by
turning the cupboard 180°.
1.2 Installation
The assembly procedure depends on the type of your appliance. There are three
types of installation:
1. Cabinets with the plastic top and hinge on the top.
2. Cabinets without the plastic top, with hinge and cover on the top.
3. Cabinets without the plastic top, without hinge and cover on the top.
Type 1
4 mm
470 mm
1
2
3
1. Drill 3,5 mm holes in the rear corners
of the appliance on the pre-marked
positions.
2. Screw the two steering screws in (B).
Do not tight them fully.
3. Attach the double-sided tape (E) to
one of the assembly brackets (D).
Fasten the bracket to the plastic top
of the appliance in the front, on the
side without the hinge. Refer to the
measurements on the picture. For ex‐
tra security you may use the steering
screw (B) to fix the bracket.
Turn the cupboard and place it on the ap‐
pliance, to let the door open in the de‐
sired direction.
Some models have a pre-as‐
sembled bracket in the front,
on the side without the
hinge . Dismantle it, cut the
end carefully and fix the
bracket again. For these
models, additional assembly
bracket (D) is not needed.
ENGLISH 3

Slide two steering screws into the cutouts
on the bottom of the cupboard cabinet.
41 mm
To secure the cabinet, fasten the two
locking screws (C) directly into the plastic
top through the drop-shaped holes.
Type 2
Screw the two steering screws into the
existing holes in the back corners of the
appliance . Do not tight them fully.
Turn the cupboard and place it on the ap‐
pliance, to let the door open in the de‐
sired direction.
Slide two steering screws (B) into the cut‐
outs on the bottom of the cupboard cabi‐
net.
www.electrolux.com4

41 mm
To secure the cabinet, fasten the two
locking screws (C) directly into the plastic
top through the drop-shaped holes.
Type 3
Place the assembly brackets (D) along
the rear edge of the appliance and mark
the positions of the holes.
Remove the brackets and drill two 3,5
mm holes where marked.
4mm
417mm 4mm
Attach the double-sided tapes (E) to the
assembly brackets (D). Fasten the brack‐
ets to the top of the appliance in the front.
Refer to the measurements on the pic‐
ture.
Turn the cupboard and place it on the ap‐
pliance, to let the door open in the de‐
sired direction.
To secure the cabinet, screw the two
locking screws (C) into the drilled holes.
ENGLISH 5

1.3 Handle assembly
Place the handle on the bottom of the
door and fix it with the blunt screw (A).
1.4 Shelf assembly
Only for models: O550, OT450, OT500, OT700.
Hang the shelf on the four attachment
points inside the cupboard. Make sure
the shelf is properly positioned and sta‐
ble.
1.5 Telescope walls assembly
Only for models: OT350, OT450, OT500, OT700.
1
2
1. Slide the telescope walls upwards to
desired height.
2. Fold the lower flap on each side and
fix the plastic rivets (G).
www.electrolux.com6

1.6 Telescope front assembly
Only for models: OT350, OT450, OT500, OT700.
90°
Place the telescope front with the bended
border upwards, towards the back of the
cupboard. Adapt the height by folding the
front 90° backwards.
Assemble the bended border backwards,
below the upper edges of the telescope
walls.
Fix the telescope front by pressing the
plastic rivets into the front holes.
1.7 Care and cleaning
Clean the appliance with a moist soft cloth. Only use neutral detergents.
Do not use abrasive products, abrasive cleaning pads, solvents or metal
objects.
2. ENVIRONMENT CONCERNS
Recycle the materials with the symbol
. Put the packaging in applicable
containers to recycle it. Help protect the
environment and human health and to
recycle waste of electrical and electronic
appliances. Do not dispose appliances
marked with the symbol with the
household waste. Return the product to
your local recycling facility or contact
your municipal office.
*
ENGLISH 7
