EOU5720AOX EN OVEN USER MANUAL

CONTENTS
1. SAFETY INFORMATION...................................................................................... 3
2. SAFETY INSTRUCTIONS.....................................................................................4
3. PRODUCT DESCRIPTION................................................................................... 7
4. CONTROL PANEL............................................................................................... 7
5. BEFORE FIRST USE............................................................................................9
6. DAILY USE.......................................................................................................... 9
7. CLOCK FUNCTIONS......................................................................................... 12
8. USING THE ACCESSORIES.............................................................................. 13
9. ADDITIONAL FUNCTIONS.................................................................................15
10. HINTS AND TIPS............................................................................................. 17
11. CARE AND CLEANING....................................................................................24
12. TROUBLESHOOTING......................................................................................27
13. ENERGY EFFICIENCY..................................................................................... 28
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can be
safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2

1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning the use of the appliance in a safe
way and understand the hazards involved.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts are
hot.
•If the appliance has a child safety device, this should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
•Children aged 3 years and under must be kept away
from this appliance when it is in operation at all times.
1.2 General Safety
•Only a qualified person must install this appliance and
replace the cable.
•The control panel must be connected to specified
heating unit with matching colours of connectors, to
avoid possible hazard.
•WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
ENGLISH 3

touching heating elements. Children less than 8 years of
age shall be kept away unless continuously supervised.
•Always use oven gloves to remove or put in accessories
or ovenware.
•Before maintenance cut the power supply.
•Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service
Centre or similarly qualified persons to avoid an
electrical hazard.
•To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the side
walls. Install the shelf supports in the opposite
sequence.
•The means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• The kitchen cabinet and the recess
must have suitable dimensions.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is
installed below and adjacent safe
structures.
• Parts of the appliance carry current.
Close the appliance with furniture to
prevent touching the dangerous parts.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
www.electrolux.com4

• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by
our Authorised Service Centre.
• Do not let mains cables touch or come
near the appliance door, especially
when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation device
must have a contact opening width of
minimum 3 mm.
• This appliance complies with the E.E.C.
Directives.
2.3 Use
WARNING!
Risk of injury, burns and
electrical shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is in
operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully. The
use of ingredients with alcohol can
cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not use microwave function to
preheat the oven.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other
objects in the appliance directly on
the bottom.
– do not put aluminium foil directly
on the bottom of the appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and food
in the appliance after you finish the
cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel has no
effect on the performance of the
appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
ENGLISH 5

• Always cook with the oven door
closed.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold. There
is the risk that the glass panels can
break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service Centre.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Clean regularly the appliance to
prevent the deterioration of the surface
material.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
2.5 Internal light
• The type of light bulb or halogen lamp
used for this appliance is only for
household appliances. Do not use it for
house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable close
to the appliance and dispose of it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
2.7 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
www.electrolux.com6

3. PRODUCT DESCRIPTION
3.1 General overview
21
6
6
1
2
3
4
7
1
2
3
4
7
3
3
5
5
4
4
1Control panel
2Electronic programmer
3Heating element
4Lamp
5Fan
6Shelf support, removable
7Shelf positions
3.2 Accessories
•Wire shelf
For cookware, cake tins, roasts.
•Grill- / Roasting pan
To bake and roast or as pan to collect
fat.
•Trivet
For roasting and grilling.
Use the trivet only with the
Grill- / roasting pan.
•Telescopic runners
For shelves and trays.
4. CONTROL PANEL
4.1 Electronic programmer
1 112 3 4 65 7 8 9 10
Use the sensor fields to operate the appliance.
Sensor
Field
Function Description
1ON / OFF To activate and deactivate the appliance.
ENGLISH 7

Sensor
Field
Function Description
2OPTIONS To set an oven function, a cleaning function or
an automatic programme.
3OVEN LIGHT To activate or deactivate the oven lamp.
4
TEMPERATURE /
FAST HEAT UP
To set and examine the cavity temperature or
the core temperature sensor temperature (if
present). If you press it and hold for three sec-
onds, it turns the Fast heat up function ON and
OFF.
5OVEN SELECTION To switch between top and main oven.
6- DISPLAY Shows the current settings of the appliance.
7UP To move up in the menu.
8DOWN To move down in the menu.
9CLOCK To set the clock functions.
10 MINUTE MINDER To set the Minute Minder.
11 OK To confirm the selection or setting. To move
down in the menu.
4.2 Display
B C D
EF
A
A. Top / Main oven indicator
B. Oven function symbol
C. Number of the oven function /
programme
D. Indicators for the clock functions (refer
to the table "Clock functions")
E. Clock / residual heat display
F. Temperature / time of day display
Other indicators of the display:
Symbol Name Description
/ h / min A clock function operates.
www.electrolux.com8

Symbol Name Description
Heat-up / residual heat indi-
cator
Shows the temperature level in the appli-
ance.
Temperature / fast heat up The function operates.
Temperature You can examine or change the temper-
ature.
Minute minder The minute minder function operates.
4.3 Heat up indicator
If you activate an oven function, the bars
come on in the display. The bars
show that the temperature in the
appliance increases or decreases.
When the appliance is at the set
temperature, the bars go off the display.
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
5.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the appliance.
Refer to "Care and cleaning"
chapter.
Clean the appliance and the accessories
before first use.
Put the accessories and the removable
shelf supports back to their initial position.
5.2 Setting the time
After the first connection to the mains, all
symbols in the display are on for some
seconds. For the subsequent few seconds
the display shows the software version.
After the software version goes off, the
display shows h and 12:00. "12" flashes.
1. Touch or to set the hours.
2. Touch .
3. Touch or to set the minutes.
4. Touch or .
The Temperature / Time display shows the
new time.
5.3 Changing the time
You can change the time of day only when
the appliance is off.
Touch .
flashes in the display.
To set the new time of day, refer to
"Setting the time".
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 Selecting an oven
1. To switch on the appliance press .
2. Repeatedly press until the top /
main oven indicator appears on the
display.
ENGLISH 9

6.2 Top oven functions
Oven function Application
True Fan Cook-
ing
To bake on 1 shelf positions at the same time and to
dry food.
Pizza Setting To bake food on 1 shelf position for a more intensive
browning and a crispy bottom.
Slow Cooking To prepare tender, succulent roasts.
Bottom Heat To bake cakes with crispy bottom and to preserve
food.
Defrost This function can be used for defrosting frozen foods,
such as vegetables and fruits. The defrosting time de-
pends on the amount and size of the frozen food.
ECO Roasting When you use this function during cooking, it allows
you to optimize the energy consumption. To get more
information about the recommended settings, refer to
the cooking tables with the equivalent function.
Grilling To grill flat food and to toast bread.
Fast Grilling To grill flat food in large quantities and to toast bread.
Turbo Grilling To roast larger meat joints or poultry with bones on 1
shelf position. Also to make gratins and to brown.
6.3 Main oven functions
Oven function Application
True Fan Cook-
ing
To bake on up to 2 shelf positions at the same time
and to dry food. Set the temperature 20 - 40 ºC lower
than for Conventional Cooking.
Pizza Setting To bake food on 1 shelf position for a more intensive
browning and a crispy bottom. Set the temperature
20 - 40 ºC lower than for Conventional Cooking.
Conventional
Cooking
To bake and roast food on 1 shelf position.
www.electrolux.com10

Oven function Application
Slow Cooking To prepare tender, succulent roasts.
Bottom Heat To bake cakes with crispy bottom and to preserve
food.
Defrost This function can be used for defrosting frozen foods,
such as vegetables and fruits. The defrosting time de-
pends on the amount and size of the frozen food.
Keep Warm To keep food warm.
ECO Roasting When you use this function during cooking, it allows
you to optimize the energy consumption. To get more
information about the recommended settings, refer to
the cooking tables with the equivalent function.
Grilling To grill flat food and to toast bread.
Fast Grilling To grill flat food in large quantities and to toast bread.
Turbo Grilling To roast larger meat joints or poultry with bones on 1
shelf position. Also to make gratins and to brown.
6.4 Setting the oven function
1. Activate the appliance with .
The display shows the set temperature,
the symbol and the number of the oven
function.
2. Touch or to set an oven
function.
3. Touch or the appliance starts
automatically after five seconds.
If you activate the appliance
and do not set an oven
function or programme, the
appliance deactivates
automatically after 20
seconds.
6.5 Changing the temperature
Touch or to change the
temperature in steps of 5 °C.
When the appliance is at the set
temperature, an acoustic signal sounds
three times and the Heat up indicator
goes out.
6.6 Checking the temperature
You can see the temperature in the
appliance when the function or
programme operates.
1. Touch .
The Temperature / Time display shows the
temperature in the appliance.
2. Touch to go back to the set
temperature or the display shows it
automatically after five seconds.
ENGLISH 11

6.7 Fast heat up function
Do not put food in the oven
when the Fast heat up
function operates.
The Fast heat up function is not available
with every oven function. An acoustic
signal sounds if the Fast heat up function
is not available for the set function if Faulty
tone is activated in the settings menu.
Refer to "Using the settings menu".
The Fast heat up function decreases the
heat up time.
To activate the Fast heat up function
touch and hold for more than three
seconds.
If you activate the Fast heat up function,
horizontal bars on the display flash to
show that the function operates.
7. CLOCK FUNCTIONS
7.1 Clock functions table
Clock function Application
TIME OF DAY To show the time of day. To change the time of day,
refer to "Setting the time".
DURATION To set how long the appliance operates.
END To set when the appliance deactivates. You can use
Duration and End at the same time (Time delay) if you
want the appliance to activate and deactivate automat-
ically later.
7.2 Count Up Timer
The Count Up Timer is not
activated if Duration and End
are set.
The Count Up Timer starts to count when
the appliance starts to heat.
To reset the Count Up Timer, touch
and at the same time until the display
shows "00:00" and the Count Up Timer
starts to count up again.
7.3 Setting the DURATION
1. Activate the appliance and set an oven
function and temperature.
2. Touch again and again until the
display shows .
flashes in the display.
3. Use or to set the minutes for
DURATION.
4. Touch to confirm.
5. Use or to set the hours for
DURATION.
If you touch while you
set the DURATION, the
appliance switches to the
setting of the END
function.
6. When the set time ends, an acoustic
signal sounds for two minutes.
and time setting flash in the display.
The appliance deactivates.
7. Touch a sensor field to stop the
acoustic signal.
8. Deactivate the appliance.
7.4 Setting the END
1. Activate the appliance and set an oven
function and temperature.
2. Touch again and again until the
display shows .
flashes in the display.
www.electrolux.com12

3. Use or to set the END and
to confirm. First you set the minutes
and then the hours.
When the set time ends, an acoustic
signal sounds for two minutes. symbol
and the time setting flash in the display.
The appliance deactivates.
4. Touch a sensor field to stop the
acoustic signal.
5. Deactivate the appliance.
7.5 Setting the MINUTE MINDER
Use the MINUTE MINDER to set a
countdown (maximum 2 h 30 min). This
function has no effect on the operation of
the oven. You can set the MINUTE
MINDER at any time and also when the
appliance is off.
1. Touch .
and "00" flash in the display.
2. Use to switch between options.
First you set the seconds, then the
minutes and the hours.
3. Use or to set the MINUTE
MINDER and to confirm.
4. Touch both and at once to
reset the set time.
5. Touch or the MINUTE MINDER
starts automatically after five seconds.
When the set time ends, an acoustic
signal sounds for two minutes and 00:00
and flash in the display.
6. Touch a sensor field to stop the
acoustic signal.
7.6 Setting the Time delay
function
The DURATION and END can be
used at the same time, if the appliance is
to be switched on and off automatically
later. In this case, first set the DURATION
and then the END function (refer
to "Setting the DURATION" and "Setting
the END" ).
When the Time delay function
is activated, the display
shows a static symbol of the
oven function, with a dot
and . The dot shows
which clock function is on in
the Clock / residual heat
display.
8. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
8.1 Inserting the accessories
Wire shelf:
Push the shelf between the guide bars of
the shelf support and make sure that the
feet point down.
Deep pan:
Push the deep pan between the guide
bars of the shelf support.
ENGLISH 13

Wire shelf and the deep pan together:
Push the deep pan between the guide
bars of the shelf support and the wire shelf
on the guide bars above.
All accessories have small
indentations at the top of the
right and left side to increase
safety. The indentations are
also anti-tip devices.
The high rim around the shelf
is a device which prevents
cookware from slipping.
8.2 Telescopic runners -
inserting the accessories
With the telescopic runners you can put in
and remove the shelves more easily.
CAUTION!
Do not clean the telescopic
runners in the dishwasher. Do
not lubricate the telescopic
runners.
CAUTION!
Make sure you push back the
telescopic runners fully in the
appliance before you close
the oven door.
Wire shelf:
Put the wire shelf on the telescopic
runners so that the feet point downwards.
The high rim around the wire
shelf is a special device to
prevent the cookware from
slipping.
Baking tray or deep pan:
Put the baking tray or deep pan on the
telescopic runners.
Wire shelf and deep pan together:
Put the wire shelf on the deep pan. Put
the wire shelf and the deep pan on the
telescopic runners.
www.electrolux.com14

8.3 Trivet and Grill- / Roasting
pan
WARNING!
Be careful when you remove
the accessories from a hot
appliance. There is a risk of
burns.
You can use the trivet to roast larger
pieces of meat or poultry on one shelf
position.
1. Put the trivet into the deep pan so that
the supports of the wire shelf point up.
2. Put the deep pan into the oven on the
necessary shelf position.
You can use the trivet to grill flat dishes in
large quantities and to toast.
1. Put the trivet into the deep pan so that
the supports of the wire shelf point
down.
2. Put the deep pan into the oven on the
necessary shelf position.
9. ADDITIONAL FUNCTIONS
9.1 Using the Child Lock
The Child Lock prevents an accidental
operation of the appliance.
1. To activate the function deactivate the
appliance with . Do not set an oven
function.
2. Touch and hold and at the
same time for 2 seconds.
SAFE comes on in the display.
To deactivate the Child Lock function
repeat step 2.
9.2 Using the Function Lock
You can activate the function only when
the appliance operates.
The Function Lock prevents an accidental
change of the oven function.
1. To activate the function activate the
appliance.
2. Activate an oven function or setting.
3. Touch and hold and at the
same time for 2 seconds.
An acoustic signal sounds.
Loc comes on in the display.
To deactivate the Function Lock repeat
step 3.
You can deactivate the
appliance when the Function
Lock is on. When you
deactivate the appliance, the
Function Lock deactivates.
9.3 Using the settings menu
You can set the settings menu only when
the appliance is deactivated.
The settings menu lets you activate or
deactivate functions in the main menu.
The display shows SET and the number of
the setting.
ENGLISH 15

Description Value to set
1 RESIDUAL HEAT INDICATOR ON / OFF
2KEY TONE1) CLICK / BEEP / OFF
3 FAULTY TONE ON / OFF
4 SERVICE MENU -
5 RESTORE SETTINGS YES / NO
1) It is not possible to deactivate the tone of the ON / OFF sensor field.
1. When the appliance is deactivated,
touch and hold for three seconds.
The display shows SET1 and "1" flashes.
2. Touch or to set the setting.
3. Touch .
4. Touch or to change the value
of the setting.
5. Touch .
To exit the Settings menu, touch or
touch and hold .
9.4 Automatic Switch-off
For safety reasons the appliance
deactivates automatically after some time
if an oven function operates and you do
not change any settings.
Temperature (°C) Switch-off time
(h)
30 - 115 12.5
120 - 195 8.5
200 - 245 5.5
250 - maximum 1.5
After the Automatic switch-off, touch a
sensor field to operate the appliance
again.
The Automatic switch-off
does not work with the
functions: Light, Slow
Cooking, Duration, End, Time
delay.
9.5 Brightness of the display
There are two modes of display
brightness:
• Night brightness - when the appliance
is deactivated, the brightness of the
display is lower between 10 PM and 6
AM.
• Day brightness:
– when the appliance is activated.
– if you touch a sensor field during
the night brightness (apart from
ON / OFF), the display goes back
to the day brightness mode for the
next 10 seconds.
– if the appliance is deactivated and
you set the Minute Minder. When
the Minute Minder function ends,
the display goes back to the night
brightness.
9.6 Cooling fan
When the appliance operates, the cooling
fan activates automatically to keep the
surfaces of the appliance cool. If you
deactivate the appliance, the cooling fan
can continue to operate until the appliance
cools down.
www.electrolux.com16

10. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
The temperature and baking
times in the tables are
guidelines only. They depend
on the recipes and the quality
and quantity of the
ingredients used.
10.1 Double oven
Top oven
The top oven is the smaller of the two
ovens. It has 4 shelf positions. Use it to
cook smaller quantities of food. It gives
especially good results when used to cook
fruitcakes, sweets and savoury flans or
quiche.
Main oven
The main oven is the bigger of the two
ovens. It is particularly suitable for cooking
larger quantities of food.
10.2 Baking
• Your oven may bake or roast differently
to the appliance you had before. Adapt
your usual settings (temperature,
cooking times) and shelf positions to
the values in the tables.
• The manufacturer recommends that
you use the lower temperature the first
time.
• If you cannot find the settings for a
special recipe, look for the one that is
almost the same.
• You can extend baking times by 10 –
15 minutes if you bake cakes on more
than one shelf position.
• Cakes and pastries at different heights
do not always brown equally at first. If
this occurs, do not change the
temperature setting. The differences
equalize during the baking procedure.
• With longer baking times, you can
deactivate the oven approximately 10
minutes before the end of the baking
time and then use the residual heat.
When you cook frozen food, the trays in
the oven can twist during baking. When
the trays become cold again, the
distortions are gone.
10.3 Tips on baking
Baking results Possible cause Remedy
The bottom of the cake is
not browned sufficiently.
The shelf position is incor-
rect.
Put the cake on a lower
shelf.
The cake sinks and be-
comes soggy, lumpy or
streaky.
The oven temperature is too
high.
The next time you bake, set
a slightly lower oven tem-
perature.
The cake sinks and be-
comes soggy, lumpy or
streaky.
The baking time is too
short.
Set a longer baking time.
You cannot decrease
baking times by setting
higher temperatures.
The cake sinks and be-
comes soggy, lumpy or
streaky.
There is too much liquid in
the mixture.
Use less liquid. Be careful
with mixing times, especially
if you use a mixing ma-
chine.
The cake is too dry. The oven temperature is too
low.
The next time you bake, set
a higher oven temperature.
ENGLISH 17

Baking results Possible cause Remedy
The cake is too dry. The baking time is too long. The next time you bake, set
a shorter baking time.
The cake browns unevenly. The oven temperature is too
high and the baking time is
too short.
Set a lower oven tempera-
ture and a longer baking
time.
The cake browns unevenly. The mixture is unevenly dis-
tributed.
Spread the mixture evenly
on the baking tray.
The cake is not ready in the
baking time given.
The oven temperature is too
low.
The next time you bake, set
a slightly higher oven tem-
perature.
10.4 Baking
Top oven
Food Temperature (°C) Time (min) Shelf position
Biscuits 170 - 190 10 - 20 2
Bread 200 - 220 30 - 35 1
Bread rolls / buns 170-180 10 - 15 1
Cakes:
- Small & Queen 160 - 170 18 - 25 2
- Sponges 160 - 175 20 - 30 2
- Victoria Sandwich 160 - 170 18 - 25 2
- Madeira 140 - 150 75 - 90 2
- Rich Fruit 140 - 150 120 - 150 2
- Gingerbread 140 - 150 75 - 90 2
- Meringues 90 - 100 150 - 180 2
- Flapjack 160 - 170 25 - 30 2
- Shortbread 130 - 150 45 - 65 2
Casseroles:
- Beef / Lamb 160 - 170 150 - 180 1
- Chicken 160 - 180 75 - 90 1
Convenience Foods Follow manufacturer's instructions.
Fish 170 - 190 20 - 30 2
Fish Pie (Potato Topped) 190 - 200 20 - 30 2
Fruit Pies, Crumbles 190 - 200 30 - 50 2
www.electrolux.com18

Food Temperature (°C) Time (min) Shelf position
Milk Puddings 150 - 170 90 - 120 2
Pasta, Lasagne etc. 170 - 180 40 - 50 2
Pastry:
- Choux 180 - 190 30 - 40 2
- Eclairs, Profiteroles 180 - 190 30 - 40 2
- Flaky / Puff Pies 210 - 220 30 - 40 2
Shortcrust:
- Mince Pies 190 - 210 15 - 20 2
- Meat Pies 190 - 210 25 - 35 2
- Quiche, Tarts, Flans 180 - 200 25 - 50 2
Scones 220 - 230 8 - 12 2
Shepard's Pie 180 - 190 30 - 40 2
Souffles 190 - 200 20 - 30 2
Vegetables:
- Baked Jacket Pota-
toes
180 - 190 60 - 90 2
- Roast Potatoes 180 - 190 60 - 90 2
Yorkshire Pudding:
- Large 200 - 210 25 - 40 1
- Individual 210 - 220 15 - 25 1
Main oven
Food Temperature (°C) Time (min) Shelf posi-
tion
Conventional
Cooking
True Fan Cook-
ing
Biscuits 180 - 190 180 - 190 10 - 20 2
Bread 200 - 220 190 - 210 30 - 35 2
Cakes:
- Small & Queen 170 - 180 160 - 170 18 - 25 2
- Sponges 170 - 180 160 - 170 20 - 25 2
- Madeira 150 - 160 140 - 160 60 - 75 2
- Rich Fruit 140 - 150 130 - 140 120 - 150 2
- Christmas 140 - 150 130 - 140 180 - 270 2
ENGLISH 19

Food Temperature (°C) Time (min) Shelf posi-
tion
Conventional
Cooking
True Fan Cook-
ing
Fish 170 - 180 160 - 180 20 - 30 3
Fruit Pies, Crum-
bles
180 - 200 170 - 180 30 - 50 3
Milk Puddings 150 - 170 140 - 160 60 - 90 3
Pastry:
- Choux 180 - 190 180 - 190 30 - 40 3
- Shortcrust 190 - 200 180 - 190 25 - 35 3
- Flaky 190 - 210 180 - 190 30 - 40 3
- Puff Follow manufacturer's instructions. Reduce the temperature by 20ºC
for True Fan Cooking Function.
Plate Tarts 190 - 200 180 - 190 25 - 45 3
Quiches / Flans 200 - 210 170 - 180 25 - 45 3
Scones 220 - 230 210 - 230 8 - 12 2
10.5 Slow Cooking
Use this function to prepare lean, tender
pieces of meat and fish. This function is
not applicable to such recipes as pot roast
or fatty roast pork.
In the first 10 minutes you can set an oven
temperature between 80 °C and 150 °C.
The default is 90 °C. After the temperature
is set, the oven continues to cook at 80
°C. Do not use this function for poultry.
Always cook without a lid
when you use this function.
1. Sear the meat in a pan on the hob on
a very high setting for 1 - 2 minutes on
each side.
2. Put the meat together with the hot
roasting pan into the oven on the wire
shelf.
3. Select the function Slow Cooking.
Food Quantity Temperature
(°C)
Time (min) Shelf posi-
tion
Roast beef 1000 - 1500 g 150 120 - 150 1
Fillet of beef 1000 - 1500 g 150 90 - 110 1
Roast veal 1000 - 1500 g 150 120 - 150 1
Steak 200 - 300 g 120 20 - 40 1
www.electrolux.com20
