Electrolux EW30GF65G Series Installation guide

PN / 316439224Publication # 5995523312 August 2008
Wave-Touch™
EW30GF65
IQ Touch™
EW30GF55
FREESTANDING GAS RANGE
PRODUCT TRAINING MANUAL
MODELS - EW30GF65G , EI30GF55G ,
EW3LGF65G
CEW30GF6G , CEI30GF5G
*
**
* *

Page 2
SAFE SERVICING PRACTICES ..............................3
SERVICE TIPS - DEVELOP GOOD
WORK HABITS.........................................................4
SERVICE TOOLS AND EQUIPMENT ......................4
RANGE TECHNICAL DATA .....................................5
Maximum Allowable Surface Temperatures .........5
RTD Temperature / Resistance Chart ..................5
Gas Range Component Resistance Chart...........5
Oven Relay Board Circuit Analysis Matrix
(ES 610/615) ........................................................6
EOC Signal Voltage Test Matrix ..........................6
Variable Speed Control Board.............................. 7
Power Supply Board ............................................7
Terms and Abbreviations .....................................7
Electronic Oven Control
Failure/Fault Codes (ES630)................................8
Schematic Diagram - Gas Wave Touch Models
with Lower Oven ..................................................9
Wiring Diagram - Gas Wave Touch Models with
Lower Oven........................................................10
Schematic Diagram - Gas IQ Touch Models with
Warming Drawer ................................................ 11
Wiring Diagram - Gas IQ Touch Models with
Warming Drawer ................................................12
PRODUCT OVERVIEW ..........................................13
LP GAS CONVERSION ..........................................13
TOUCH SENSOR TECHNOLOGY
(TST) CONTROL SYSTEM.....................................14
Troubleshooting The TST Panel.........................14
Diagnostic Service Mode ...................................15
ELECTRONIC OVEN CONTROL (ES630).............16
EOC Troubleshooting and Testing......................17
Power Supply Board...........................................17
Oven Relay Board ..............................................18
VARIABLE SPEED CONTROL...............................19
Variable Fan Speed............................................ 19
LUXURY™ Lighting............................................20
RACK SENSING SWITCH......................................21
MEAT PROBE FEATURE .......................................23
Theory Of Operation ..........................................23
Component Parts ...............................................23
Troubleshooting..................................................23
NOTE:
The information contained in this manual is subject
to change as product development continues after
the date this manual was created.
LP GAS CONVERSION INFORMATION
Models EI30GF55GW, EI30GF55GB, and
EI30GF55GS may be converted for use with LP gas
using the LP kit packaged with these units.
Models EW30GF65GW, EW30GF65GB and
EW30GF65GS are not approved for LP conversion.
LP versions of these ranges are available by the
following model numbers:
EW3LGF65GW, EW3LGF65GB, EW3LGF65GS
COMPONENT ACCESS AND REPLACEMENT
OVEN DOOR ..........................................................24
Door Removal ....................................................24
Door Disassembly ..............................................25
COOKTOP REMOVAL
Cooktop Removal - Wave Touch Models ........... 29
Cooktop Removal - IQ Touch Models................. 31
Orice Holders....................................................32
Removing Manifold Panel...................................33
Replacing Ignitor Switches and Harness............33
Replacing Surface Burner Valves.......................32
UPPER OVEN COMPONENTS .............................. 34
Luxury Glide Oven Rack
Removal & Maintenance ....................................34
Rack Sensor Assembly
Removal & Maintenance ....................................35
Halogen Oven Lights.......................................... 36
Convection Fan Blade and
Element Replacement........................................ 37
Rack Sensing Switch Replacement ...................37
Bake Burner and Ignitor - IQ Touch Models .......38
Bake Burner and Ignitor - Wave Touch Models.. 40
Broil Burner and Ignitor ......................................42
LOWER OVEN COMPONENTS -
Wave Touch models ............................................... 43
Replacing Lower Oven Element......................... 43
Replacing Drawer Glide Rails ............................44
Replacing Drawer Seal ......................................44
Replacing Lower Oven Temperature Probe ....... 45
Lower Oven Chassis ..........................................46
LOWER OVEN COMPONENTS -
IQ Touch models.....................................................47
Warmer Oven Theory of Operation -
IQ Touch models.....................................................47
Removing and Replacing Warmer Drawer ........47
Replacing Warmer Drawer Element
& Thermo Disc....................................................48
TABLE OF CONTENTS
MODEL APPLICATION LIST
The information contained in this manual can be
applied to the models listed below:
EW30GF65GW
EW30GF65GB
EW30GF65GS
EI30GF55GW
EI30GF55GB
EI30GF55GS
EW3LGF65GW
EW3LGF65GB
EW3LGF65GS
CEI30GF5GW
CEI30GF5GB
CEI30GF5GS
CEW30GF6GW
CEW30GF6GB
CEW30GF6GS

Page 3
To avoid personal injury and/or property damage, it is important that Safe Servicing Practices be
observed. The following are some limited examples of safe practices:
1. DO NOT attempt a product repair if you have any doubts as to your ability to
complete it in a safe and satisfactory manner.
2. Before servicing or moving an appliance:
• Remove the power cord from the electrical outlet, trip the circuit breaker to the
OFF position, or remove the fuse.
• Turn off the gas supply.
• Turn off the water supply.
3. Never interfere with the proper operation of any safety device.
4. USE ONLY REPLACEMENT PARTS CATALOGED FOR THIS APPLIANCE.
SUBSTITUTIONS MAY DEFEAT COMPLIANCE WITH SAFETY
STANDARDS SET FOR HOME APPLIANCES.
5. GROUNDING: The standard color coding for safety ground wires is GREEN, or
GREEN with YELLOW STRIPES. Ground leads are not to be used as current
carrying conductors. It is EXTREMELY important that the service technician
reestablish all safety grounds prior to completion of service. Failure to do so will
create a hazard.
6. Prior to returning the product to service, ensure that:
• All electrical connections are correct and secure
• All electrical leads are properly dressed and secured away from sharp edges,
high-temperature components, and moving parts
• All non-insulated electrical terminals, connectors, heaters, etc. are adequately
spaced away from all metal parts and panels
• All safety grounds (both internal and external) are correctly and securely
connected
• All panels are properly and securely reassembled
• All gas connections are secure and have been leak tested
ATTENTION!!!
This service manual is intended for use by persons having electrical and mechanical
training and a level of knowledge of these subjects generally considered acceptable in
the appliance repair trade. The manufacturer cannot be responsible, nor assume any
liability, for injury or damage of any kind arising from the use of this manual.
- ALL APPLIANCES -
SAFE SERVICING PRACTICES

Page 4
Consistently following a standard routine when servicing appliances will insure that you do not
waste time searching for a complex solution to a simple problem. One of the most common mistakes
made by service technicians is failing to verify the incoming power supply to the appliance.
Many times electronic controls and other components are replaced unnecessarily because
the incoming power supply was not veried. When testing the electrical supply the test should be
performed at the terminal block where the power cord or house wiring attaches to the appliance. Verify
that there are 240 volts between L1 & L2 and that there is 120 volts from L1 to Neutral and also from
L2 to Neutral. You should also check the power supply while the appliance is operating or “under load”.
The power supply may check good with the product sitting idle but fail when certain components are
turned on. This can be caused by a weak connection in the customer’s house wiring, or a faulty circuit
breaker or fuse.
Another common mistake is failure to verify all component part wire harness connections. It is
essential that all component connections be checked visually and with the appropriate circuit tester.
Many times components are assumed to be faulty because they do not operate or there is an error
code displayed by the electronic control system. Often the failure is caused by a loose or miswired
connection which can cause the same error code as a defective component part. Newly installed
appliances may have loose connections resulting from shipping and handling conditions or improper
installation. Check the wiring connections before you order replacement parts.
When the repair has been completed the product should be thoroughly tested to verify that the
service performed corrected the problem and that all of the other features and functions of the product
are in proper working order. The extra time taken to do this will create consumer condence in your
efciency and professionalism as well as possibly saving an expensive callback.
SERVICE TIPS - DEVELOP GOOD WORK HABITS
In addition to standard hand tools such as wrenches, screwdrivers, pliers, etc; the following
instruments are considered to be essential equipment for technicians servicing Electrolux cooking
products. Proper testing and diagnostic procedures are not possible without these tools.
•Volt/ohmmeter - Must be capable of voltage measurement from 0 to 500 volts AC and
resistance measurements from 0 to 2 meg-ohms. This usually requires a meter that utilizes
a 9 volt battery. Either digital or analog meters are acceptable however most technicians nd
analog meters easier to use. Appropriate test leads and tips are required to test certain
electronic components and connections.
• Clamp on amp meter - Should be capable of measuring from 0 to 60 amps.
• Temperature Meter - Should be high quality with thermocouple or electronic
“K-type” test probe. Capable of temperature readings up to 1000 degrees Fahrenheit.
Additional instruments that a technician will need to have access to at various times include the
following:
• Combustible gas leak detection meter.
• U tube manometer or equivalent testing device for measuring LP and Natural gas line
pressure on gas ranges. Measurements must be in IWC (inches water column)
• Carbon Monoxide (CO) detection meter capable of measuring from 0-1000 PPM.
• Microwave Leak Detection Meter
NOTE: Electrolux Does Not Supply Tools Or Test Instruments.
SERVICE TOOLS AND EQUIPMENT

Page 5
SURFACE TEMPERATURE LIMITS
1. Product must be undamaged, correctly assembled and have the cor-
rect oven temperature.
2. All skin temperatures are based on a room temperature of 77° F (25° C)

For ELECTRIC ranges built prior to 08/26/2003 - 400° F
For ELECTRIC ranges built after 08/26/2003 - 475° F
For GAS ranges built prior to 01/01/2004 - 400° F
For GAS ranges built after 01/01/2004 - 475° F
3. Oven must be cycling at designated test temperature for one hour
before test is conducted.
4. Pyrometers, (temperature testers), must be of high quality and properly
adjusted.


temperature of the range.
All gas and electric ranges must comply with U.L and A.N.S.I. surface temperature limits outlined in the following chart.
Note that the testing temperature is different for electric ranges produced after 08/26/2003.
MATERIAL TYPE / FINISH
PAINTED PORCELAIN GLASS PLASTIC†METAL
LOCATION
Side Panel 152° F 160° F — — —
Oven Door 152° F 160° F 172° F 182° F —

Front Panel
152° F 160° F — — —
Knobs & Handles — — — *167° F
**182° F
131° F
**152° F
Skirt — — — *182° F *152° F
Cooktop

Oven Vent Area
NO TEMPERATURE LIMITS APPLY TO THIS AREA
†Includes plastic with metal plating not more than 0.005” thick and metal with a plastic covering not
less than 0.005” thick.
* Self-Clean Gas Range at Clean Temperature
** Self-Clean Electric Range at Clean Temperature
RANGE TECHNICAL DATA
The chart seen here can be used to test the resistance of the oven
temperature sensor probe. For accuracy in testing use a high quality
thermometer or temperature meter to determine actual oven temperature
before reading the resistance of the probe.
RTD SCALE
TEMPERATURE °F RESISTANCE Ω
32 ± 1.9 1000 ± 4.0
75 ± 2.5 1091 ± 5.3
250 ± 4.4 1453 ± 8.9
350 ± 5.4 1654 ± 10.8
450 ± 6.9 1852 ± 13.5
550 ± 8.2 2047 ± 15.8
650 ± 13.6 2237 ± 18.5
900 ± 13.6 2697 ± 24.4
RTD TEMPERATURE / RESISTANCE CHART
MAXIMUM ALLOWABLE SURFACE TEMPERATURES
Gas Range Component Resistance Chart
GAS RANGE COMPONENT RESISTANCE CHART
NOTE: RESISTANCE MEASUREMENTS ARE APPROXIMATE. VARIATIONS DUE TO TEMPERATURE CHANGES
AND OTHER FACTORS ARE NORMAL.
COMPONENT VOLTAGE
RATING
WATTAGE 
WARMER DRAWER ELEMENT 108 / 132 700 20.5 
WARMER DRAWER ELEMENT 108 / 132 450 32 
MINI OVEN ELEMENT 108 / 132 1000 14 
CONVECTION ELEMENT 108 / 132 350 40 
CONVECTION ELEMENT 108 / 132 200 72 
CONVECTION FAN MOTOR
WINDINGS
108 / 132 35 
LOCK MOTOR WINDINGS 108 / 132 2000 
GAS SAFETY VALVE ** 1.5 
BAKE IGNITOR 108 / 132 100 
BROIL IGNITOR 108 / 132 80 
OVEN TEMPERATURE SENSOR
PROBE (AT ROOM TEMPERATURE)
-1100 *
*(refer to rtd chart)
** Never apply line voltage to the oven safety valve terminals.

Page 6
Relay Board Circuit Analysis Matrix
ES 610/615 GAS OVEN RELAY BOARD CIRCUIT ANALYSIS MATRIX
Relay Contacts
P6 (BK)
to
P10 (Y)
P6 (BK)
to
P8 (BL)
P6 (BK)
to
P12 (Y/BK)
J4/3 (BK)
to
J4/5 (V)
J4/3 (BK)
to
J4/6 (BR)
Component Bake Ignitor Broil Ignitor Lower Oven
Element
Convection
Element
Door Lock
Motor
O
P
E
R
A
T
I
O
N
Bake / Time Bake X P
Convection Bake/Roast X X
Broil X
Dehydrate X X
Bread Proof X
Slow Cook X
Keep Warm (Upper Oven) X
Keep Warm (Lower Oven) X
Bake (Lower Oven) * X
Door Lock Motor
Locking/Unlocking
X
Clean X
X = Contact Closed P = Contact closed during Pre-Heat only
*Some Models
RANGE TECHNICAL DATA
EOC Signal Voltage Test Matrix
FREESTANDING GAS “A” & “B” MODELS
FUNCTION / RELAY EOC CONNECTOR / PIN# RELAY BOARD CONNECTOR / PIN #
/ K8 P11 / Pin 3 J7 / Pin 3
Broil / K4 P11 / Pin 1 J7 / Pin 1
Bake / K6 P11 / Pin 2 J7 / Pin 2
Convection Element / K10 P11 / Pin 5 J7 / Pin 5
Lock Motor / K12 P11 / Pin 6 J7 / Pin 6
Test for 3.3 VDC (+/- .5 volts) between GND on EOC circuit board and the indicated connector pin when the specied
function is activated.

Page 7
RANGE TECHNICAL DATA
Terms and Abbreviations Used In This Manual
TECHNICAL TERMS
BTU = BRITISH THERMAL UNIT
EOC = ELECTRONIC OVEN CONTROL
GND = GROUND
LED = LIGHT EMITTING DIODE
RTD = RESISTANCE TEMPERATURE DEVICE (Temperature Sensor Probe)
VSC = VARIABLE SPEED CONTROL
IWC = INCHES WATER COLUMN ( Unit of measure for testing gas line pressure )
TST = TOUCH SENSOR TECHNOLOGY (Refers to glass touch control panel)
SALES/MARKETING TERMS
Perfect Pair™ = Lower oven in the drawer below the main oven. Also called a Mini Oven.
IQ Touch™ = Control panel display style found on “B” model ranges.
Wave-Touch™ = Control panel display style found on “A” model ranges.
Power Supply Board (PS1 or PS2) Test Points
Connector P1 pins 1 & 4 - 120 vac
Connector P2 pins 1 & 5 - 8 vdc
NOTE: All voltages are approximate.

RELAY CONTACTS
P2/5 (BK)
to
P2/1 (Tan)
P2/5 (BK)
to
P2/7 (Pink)
OPERATION Oven Lamps X
Convection Fan Mtr. X
X = Contact Closed
VSC Test Points.
Connector P6 pins 1 & 6 - 5 vdc
Connector P2 Pins 3 & 5 - 120 vac
Variable Speed Control Board
NOTE: All voltages are approximate.

Page 8
RANGE TECHNICAL DATA
For each Fault code there is a listing of the likely failure condition or cause, as well as suggested
corrective actions to be taken. Perform the steps one at a time in the order listed below to correct the
specic failure condition.
Note: Fault codes are not a foolproof system. Never assume that a part has failed based on a displayed fault


FAULT
CODE
LIKELY FAILURE
CONDITION/CAUSE
SUGGESTED CORRECTIVE ACTION
F10 Runaway Temperature.
Oven heats when no cook
cycle is programmed.
1. Check RTD Sensor Probe using the RTD scale found in the tech sheet. Replace if defective.
2. If oven is overheating disconnect power from the range and unplug connector P1 from power supply
board 1. Reapply power to the range. If oven continues to heat when the power is reapplied, replace the
oven relay board.
3. Replace the EOC
NOTE: Severe overheating may require the entire oven to be replaced should damage be extensive.
F11 Shorted Keypad 1. Reset power supply to range to see if failure code will clear.
2 Test ribbon harness and connectors between the TST panel and EOC. Replace if defective
3. Replace the TST panel
4. Replace the EOC
F13 Internal software error in
EOC
Disconnect power, wait 30 seconds and reapply power. If fault returns upon power-up, replace EOC.
F14 TST Display tail missing or
not connected
1. Check/reseat ribbon harness and connections between TST panel and EOC.
2. Replace the TST panel
3. Replace the EOC
F15 Signal loss between oven
relay board and EOC
1. Test the harness and connections from EOC connector P16 to oven relay board J2.
2. Replace the oven relay board
3. Replace the EOC
F20 Communication failure
between EOC and ESEC
1. Test wiring harness and connections between EOC connector P2 and ESEC 30 UIB P9
2. Test wiring harness and connections between ESEC 30 UIB and ESEC 20 relay board
3. Test wiring harness and connections between PS board 2 (P2) and ESEC 30 UIB connector P7
4. Test for approximately 8 volts DC output from PS board 2 at ESEC 30 UIB connector P7, pins 1 & 5.
If output voltage is incorrect test incoming power supply to PS board 2 at harness connector P1 pins
1 & 4. If incoming power is correct (120 VAC) replace PS board 2.
If output voltage is correct replace ESEC 30 UIB
5. Replace EOC
F23
F25
Communication failure
between VSC board and
EOC
1. Check harness and connections between VSC board and EOC.
2. Test for approximately 5 volts DC to VSC board at P6 connector pins 1 & 6.
If voltage is correct replace VSC board. If voltage is incorrect replace EOC.
F30
F31
Open probe connection.
Shorted Probe connection
1. (F30 or F31) Check resistance at room temperature & compare to RTD Sensor resistance chart. If
resistance does not match the RTD chart replace RTD Sensor Probe. Check Sensor wiring harness between
EOC & Sensor Probe connector.
2. (F30 or F31) Check resistance at room temperature, if less than 500 ohms, replace RTD Sensor Probe.
Check for shorted Sensor Probe harness between EOC & Probe connector.
F90 Door lock motor latch
failure
If lock motor runs:
1. Test continuity of wiring between EOC and lock switch on lock motor assy. Repair if needed.
2. Advance motor until cam depresses the plunger on lock motor switch. Test continuity of switch contacts.
If switch is open replace lock motor assy.
3. If motor runs and switch contacts and wiring harness test good, replace the EOC
If lock motor does not run:
1. Test continuity of lock motor windings. Replace lock motor assy if windings are open.
2. Test lock motor operation by using a test cord to apply voltage. If motor does not operate replace lock
motor assy.
3. If motor runs with test cord check continuity of wire harness to lock motor terminals. If harness is good
replace the EOC.
Electric
Models
Only
ELECTRONIC OVEN CONTROL
FAILURE/FAULT CODES (ES630)

Page 9


Page 10


Page 11


Page 12


Page 13
PRODUCT OVERVIEW
Electrolux branded freestanding gas ranges are currently available in two distinct model series. The
Wave Touch series and IQ Touch series.
Both designs feature a ve burner cooktop with full width burner grates, a self cleaning main oven
with bake and broil burners, convection and normal bake modes in the main oven, variable speed
convection fan motor, Luxury Glide oven racks, Dual halogen oven lights, and a meat probe.
The Wave Touch models also feature a Perfect Pair™ lower oven capable of baking at temperatures
up to 450 degrees in addition to functioning as a warming drawer.
The IQ Touch models features a lower warming drawer only. The appearance of the Touch Sensor
control panel of the IQ Touch series is also very different from the Wave Touch series as will be seen
later in this manual.
The oven and warmer drawer functions are controlled by the ES630 Electronic Oven Control.
The oven door hinges are designed to allow the door to stand open in virtually any position without
springing closed.
Current nish options available are White , Black and Stainless Steel. Both range models operate on
120 volt 60 hz AC power supply.
Wave-Touch™ IQ Touch™
EW30GF65 EW30GF55
IQ Touch™ models - EI30GF55GW, EI30GF55GB, and EI30GF55GS may be converted for use
with LP gas using the LP kit packaged with these units.
Wave-Touch™ models - EW30GF65GW, EW30GF65GB and EW30GF65GS are not approved for
LP gas conversion.
LP gas ready versions of the Wave-Touch™ models with lower oven are available by the following
model numbers: EW3LGF65GW, EW3LGF65GB, EW3LGF65GS
LP GAS CONVERSION

Page 14
The TST system utilizes a touch sensitive glass panel (photo A) to allow the user to control all oven
and warmer drawer operations. The TST panel is connected to the electronic oven control (EOC)
and the electronic surface element control (ESEC) system UIB (user interface board) via ribbon
connectors. It is similar in function to a membrane switch.
The TST control panel generates an electromagnetic eld around each touch pad. When this eld is
interrupted by touching the glass, the control panel communicates the selection information to the
EOC. The EOC then responds by signaling the oven relay board to close the appropriate relays to
perform the selected operation or function.
NOTE: The TST system touch glass is a non serviceable part and must be replaced as a complete
assembly if found to be defective. The replacement glass panel will come attached to the frame and
will include ribbon connectors. (Photo B)
TOUCH SENSOR TECHNOLOGY (TST) CONTROL SYSTEM
The TST control panel has ribbon connectors that link it to the EOC. (Photo C).
If these connectors fail or become loose the TST control panel will not operate and under some
conditions will generate a fault code in the EOC display window.
If the TST control malfunctions or fails to operate inspect and re-seat the ribbon connectors. If a
failure/fault code is present follow the diagnostic procedure for that code.
Troubleshooting The TST Panel
If no fault code appears but the EOC does not
respond when the TST panel is touched then
the cause is either a defective EOC or TST
panel. Replace the EOC rst. If the problem
remains replace the TST panel assembly.
If only a single key is non responsive then the
TST panel is the most likely cause of failure.
Photo A
Photo B
Photo C
EOC
Ribbon Connectors
Frame Touch Glass

Page 15
When an error or failure occurs in the Electronic Oven Control (EOC) system the control panel will usually
produce an audible beep accompanied by a special display to indicate that there is a failure condition. In order
for a service technician to be able to more easily determine which failure condition has occurred a special
Diagnostic Service Mode has been built in to the control panel software.
To enter the service mode the range must be in the “IDLE” condition meaning that all elements and functions
are turned off. Press and hold the TIMER keypad for the upper oven and the Upper Oven selector keypad for 3
seconds. Always press the TIMER keypad rst immediately followed by the Upper Oven selector keypad.
After three seconds the control panel will enter the service mode and will display the most recent error or
failure codes for the upper and lower ovens as well as the ESEC system.
The control will exit the Diagnostic Service Mode after one minute or it can be ended by pressing the CANCEL
keypad. The service mode can be restarted if necessary by repeating the steps outlined above. While the
control is in the Diagnostic Service Mode the error codes can be cleared from memory by pressing the Upper
Oven Timer keypad. Once they are cleared they can not be recalled.
Error Displayed
for Upper Oven
Control
Error Displayed
for Lower Oven
Control
Error Display
Window
for ESEC System
Press and Hold for three seconds
to start Service Mode
Diagnostic Service Mode
The photo above shows an IQ Touch control panel that has been programmed into the Diagnostic Service
Mode. The upper oven control is displaying an F11 error code (Stuck Keypad), The lower oven control is
displaying no error code.
The display window to the right of the F11 code is used to display error messages related to the ESEC
(Electronic Surface Element Control) system found in electric ranges. In gas ranges this window will display
E - - in the diagnostic service mode.
Once it has been determined which failure condition is present follow the troubleshooting steps outlined in the
tech sheet and this service manual to correct that specic condition.
.
NOTE: The Diagnostic Service Mode works exactly the same for both IQ Touch and Wave Touch models.

Page 16
Gas Oven Control
The Electrolux branded ranges covered in this manual feature the ES630 Electronic Oven Control
(EOC) . This control system is comprised of the Electronic Oven Control Board, Oven Relay Board,
and Power Supply Board. The ES630 control interfaces with the TST (Touch Sensor Technology)
panel to allow the consumer to select the desired function and options.
There are currently two different versions of the TST control panels sometimes referred to as “A” and
“B” versions. Other terms used to refer to the different control styles are: “Wave-Touch™” for the A
model and “ IQ Touch™” for the B model.
The most obvious difference is the appearance of the
control panels when they are in an idle state.
The Wave-Touch™ display panel has a “sleep mode”
that turns off the illuminated control icons on the
touch panel whenever the range is idle for 2 minutes
(Diag A). During this sleep mode only the time of day
will be illuminated in the control panel.
To wake the control simply touch the glass surface.
The touch control keypads will illuminate to allow the
user to program the desired function (Diag B).
Diag.A
Diag. B
The IQ Touch™ display panel has permanent
graphics imprinted in the glass panel and will remain
visible at all times (Diag C).
Diag. C
In current models the Wave-Touch control is always used on ranges that feature the “Perfect Pair™
lower oven”, also referred to as a Mini Oven.
Models that have the IQ Touch control feature a warmer drawer instead of a mini oven.
ELECTRONIC OVEN CONTROL (ES630)

Page 17
EOC Troubleshooting and Testing
The Electronic Oven Control system found in the Electrolux freestanding gas ranges uses a separate
oven relay board to power the individual components such as the bake and broil ignitor, lock motor,
warmer drawer or mini oven element, etc. This is different from some other styles of electronic oven
controls where the EOC and control relays are integrated in to a single component. The servicer must
follow the troubleshooting and diagnostic information found in this manual and in the product tech
sheet to accurately diagnose any failures and avoid unnecessary parts replacement.
Photo A shows the locations of the EOC Board, Oven Relay Board and Power supply board as seen
from the rear of the range with the rear panel removed. The ribbon connectors to the TST panel can
be seen at the bottom of the EOC circuit board.
EOC Board
Oven Relay Board Power Supply Board
Photo A

The EOC is powered by separate power supply board that is mounted on the rear of the range chassis
to the right of the EOC as seen in photo A.
Power Supply Board (PS1 or PS2) Test Points
Connector P1 pins 1 & 4 - 120 vac
Connector P2 pins 1 & 5 - 8 vdc
NOTE: All voltages are approximate.

Photo A
EOC Board Power Supply Board
Incoming voltage to the boards should be approximately 120
VAC at P1. Output voltage should be approximately 8 VDC at
P2.
Always test the incoming and outgoing voltage at the power
supply boards when troubleshooting EOC or ESEC control
failures.

Page 18
FREESTANDING GAS MODELS
FUNCTION EOC Test Points
Connector/Pin#
Relay Board Test Points
Connector/Pin#
Lower Oven or Warmer Drawer P11/Pin 3 → to GND J7 / Pin 3
Broil P11/Pin 1 → to GND J7 / Pin 1
Bake P11/Pin 2 → to GND J7 / Pin 2
Convection Element P11/Pin 5 → to GND J7 / Pin 5
Lock Motor P11/Pin 6 → to GND J7 / Pin 6
EOC SIGNAL VOLTAGE TEST MATRIX
If a component part that is controlled by the EOC fails to operate the cause could be due to a defect in
the EOC, Oven Relay Board, wiring connections , or the non functioning component. Component parts
like elements, fan motors, lock motors, etc. can be tested with a simple continuity check using an ohm
meter. Verify the continuity of the component and the wiring circuit between the component to the relay
board rst. Also verify continuity of the wiring harness and connectors between the EOC and Oven
Relay Board.
If the component and wiring connections are good, test the output signal voltage from the EOC to the
Relay board for the particular relay that turns on that component part. When testing the output signal
set your volt meter to read DC voltage. The output signal will be approximately 3.3 volts DCV.
Using the EOC SIGNAL VOLTAGE TEST MATRIX it is possible to determine if the EOC is properly
signaling the relay board to turn on a particular component. If the proper signal is detected but the
relay does not close then the relay board is defective and must be replaced. If the proper signal is not
detected then the EOC is defective and must be replaced.
GND (-) CIRCUIT ACCESS POINTS
Photo A
When testing the signal voltage from the EOC the negative (-) lead of the test meter must connect the
GND circuit on the EOC circuit board. The easiest access point to the GND circuit is located just above
the left corner of the P11 connector. (Photo A).
Photo B demonstrates testing the Bake Relay signal voltage by measuring the voltage output between
connector J7 pin #2 (red wire) and the GND circuit on the EOC circuit board on a gas range.
Photo B
BAKE RELAY SIGNAL VOLTAGE TEST
Oven Relay Board
Test for 3.3 VDC (+/- .5 volts) between GND on EOC circuit board and the
indicated connector pin when the specied function is activated.
RELAY BOARD CONNECTORS
J5
J7
ELECTRONIC OVEN CONTROL (ES630)

Page 19
To achieve optimum cooking results during convection cooking the fan motor speed can be varied.
The EOC will signal the VSC board to speed up or slow down the fan as needed. This speed change
takes place automatically with no action required by the consumer.
The Variable Speed Control (VSC) board operates the Convection Fan as well as the Oven LUXURY™
lighting. In the event that either of these features do not operate properly the VSC board should be
examined as a possible source of failure. When testing for convection fan operation it should be noted
that on gas ranges there is a six minute delay from the start of the convection cooking cycle until the
fan motor will run.
Variable Fan Speed
The VSC Board is located on the rear of the range
as seen in photo A. The board varies the voltage to
the convection fan motor as directed by the EOC to
alter the motor speed. The speed control signal and
the power supply to operate the VSC board come
from the EOC through a wiring harness connected
between P2 on the EOC and P1 on the VSC board.
This harness must be intact and properly connected
for the VSC board to operate. If the harness is
defective or not properly connected the EOC will
display a fault code F23.
When testing the VSC board the power supply from
the EOC to the board can be veried by measuring
the voltage between pins 1 & 6 (the two outside pins)
on connector P6 of the VSC board. This connector is
not wired in eld applications and the pins are easily
accessed to test voltage while the other harness
connectors are in place and power is applied to the
range. Test for approximately 5 volts DC (+/- .5 volt)
on these two pins. If the EOC appears to operate
normally but the voltage to the VSC board is incorrect
or if there is no voltage present inspect and test the
wire harness and connectors between the EOC and
VSC board. If the harness is good then the EOC is
defective and should be replaced.
VSC Board
Photo A
P6
P2 Photo B
P1
Pin 1
Pin 6
If the convection fan motor fails to run after the oven has been heating for six minutes test for voltage
to the convection fan motor. If no voltage is present then the failure is either in the VSC board, EOC ,
or the wiring in between. If there is proper voltage to the fan motor but it does not run then either the
motor windings are open or the motor is stuck. Test the continuity of the motor windings with an ohm
meter. There should be approximately 15 ohms of resistance in the convection fan motor windings. If
the windings test good inspect the fan blade and motor shaft to see if the motor will turn. Adjust the fan
blade to eliminate binding or replace the motor assembly if the motor shaft is seized.
VARIABLE SPEED CONTROL

Page 20
LUXURY™ Lighting
When the oven door is opened or the LIGHT keypad
on the touch control panel is pressed the interior
oven halogen lights (photo B) come on and brighten
gradually. When turned off they dim gradually
until they are completely off. This feature is also
sometimes referred to as “Ramp Up lighting”.
Photo B
The incremental changing of the oven lights is
controlled by the VSC board. A triac on the board
gradually increases the voltage to the lights over a
2 - 3 second time span until the lights are on at full
power.
If none of the halogen oven lights operate, plug
in the range and open the oven door. Test for
approximately 120 volts AC at pins 1 & 3 of the P2
wire harness connector (brown & white wires) on the
VSC board (photo C).
Always use special care when making live voltage
tests.
If the voltage is correct then the failure is caused by
defective bulbs, sockets or wiring connections.
If the voltage is incorrect the problem could be
caused by a defective door switch, VSC board, or
EOC.
Test the contacts of the oven door switch by
disconnecting the P10 connector on the EOC and
checking for continuity between the grey and pink
wires in the wire harness.
P6
P2 Photo C
Pin 3
Pin 1
P1
