Electrolux thermaline S90
6-burners boiling top on base
The Electrolux thermaline S90 cooking equipment is designed for the very heavy duty requirements of small institutions,
hotels and restaurants. The range consists of a wide choice of modular elements that can be installed as individual
free-standing or wall mounted units, or assembled into a complete cooking suite. Construction based on an internal
stainless steel frame combined with a new plug-connection system ensures that individual modules can be solidly
connected with a virtually seamless working surface.The modules described in detail on this sheet have 6 independently
controlled open burners, mounted on a base unit. These models are available for operation either on one side only or
from both sides to suit a central cooking island. The installation options floor mounted on 200mm high feet or on a plinth
that can be either in stainless steel or of masonry construction.
599523+shelf fixation
EASY TO USE
• Three different sizes of burners to suit
different cooking requirements from rapid
boiling to a gentle simmer process.
• Manual gas valves with fixed high and
low positions allow precise control of the
flame intensity.
• Large sized pan support in cast iron
with long center fins to allow the use of
the largest down to the smallest pans.
• The level of the pan support and the
top of the unit is the same, which means
it is possible to move pans around the
surface without lifting.
EASY TO MAINTAIN
• Removable pan supports, burner rings
and flame ignition components.
• Simply, convenient operation with
highly visible control panels and knobs.
• Gas main valve built in as standard.
EASY ON THE ENVIRONMENT
• 98% of the unit is recyclable by weight.
• Packing free of toxic substances.
MATERIALS
• Body and base compartment are made
of stainless steel AISI 304 and pan
supports are made of cast iron.
• 3 mm work top in AISI 304 stainless
steel.
• “Lasertec connection system” in
304AISI stainless steel creates a nearly
seamless work top .
APPROVALS
• The appliances are IPX5 certified
against water jets.
• All appliances are developed and
assembled according to European safety
and hygiene standards and are H
marked.
MODELS
• All the models are delivered with four
square stainless steel feet.
• Some models are supplied with the
Ecoflam pan detection system, which has
the advantage of saving energy and
reducing unnecessary heat radiation in
the kitchen.
• The models installed against the wall
have a C-board of 43 mm. The C-board
on the rear side of the appliances closes
any kind of gap between the unit and the
wall, for better hygiene.
• The 2 side operating models have a
pass-through base.
• Available as variation models with open
base in hygienic designed execution with
large rounded corners for easier cleaning.

Electrolux thermaline S90
6-burners boiling top on base
Internet: http://www.electrolux.com/foodservice
CFAA0502013-10-03Subject to change without notice
SOLID TOP PLATE F.OPEN BURNER-360X360MM 910718 910718 910718 910718
SIDE PANEL RIGHT-AGAINST WALL+CB,H=700MM 911950
SIDE PANEL RIGHT-AGAINST WALL, H=700MM 911952
SIDE PANEL RIGHT - BACK TO BACK 911954
SIDE PANEL LEFT-AGAINST WALL+CB,H=700MM 911951
SIDE PANEL LEFT-AGAINST WALL, H=700MM 911953
SIDE PANEL LEFT - BACK TO BACK 911955
SIDE PANEL FREESTANDING 911949 911949 911949
SHELF FOR OPEN & HOT BASE,W=700&800,2-S 910779 910779
SHELF FOR OPEN & HOT BASE,W=700&800,1-S 910780 910780
SHELF FIXATION FOR OPEN&HOT BASE,1-S 910771 910771
SHELF FIXATION F.OPEN&HOT BASE 800,2-S 910772 910772
S90 PAN REST CNS 430X430 MM THERMA 911988 911988 911988 911988
S/S SIDE KICKING STRIPS LEFT+RIGHT -WALL 911639 911639
S/S SIDE KICKING STRIPS LEFT+RIGHT - FS 911638 911638 911638
S/S SIDE KICKING STRIPS L+R-BACK-TO-BACK 911640
S/S SIDE KICKING STRIPS BACK TO BACK C-B 911844
S/S FRONT+BACK KICKING STRIPS 1500MM -FS 911601 911601 911601
S/S FRONT KICKING STRIP 1500MM - WALL 911602 911602
PORTIONING SHELF 1500X200 MM 911883 911883 911883 911883
PORTIONING SHELF 1500X130 MM 911861 911861 911861 911861
PAN REST STAINLESS STEEL-430X380 MM 910729 910729 910729 910729
LOWER SIDE PANEL WALL MOUNTING 300 MM RI 911672 911672
LOWER SIDE PANEL WALL MOUNTING 300 MM LE 911671 911671
KIT FOR WALL MOUNTING H = 700MM 911670 911670
KIT FOR BACK TO BACK INSTALLATION,1-PCE 911619
KIT BACK TO BACK INSTALLATION C-BOARD 911845
FLEXIBLE CONNECTION HOSE 3/4'' 910720 910720 910720 910720
ACCESSORIES
PAN REST CAST-IRON-430X399 MM 1 1 1 1
INCLUDED ACCESSORIES
Net weight - kg. 270 270 270 270
gas 36 36 36 36
Power - kW
Front burners power - kW 5, 7, 5 5, 7, 5 5, 7, 5 5, 7, 5
Front burners dimension - mm 420x440, 420x440,
420x440
420x440, 420x440,
420x440
420x440, 420x440,
420x440
420x440, 420x440,
420x440
Back burners power - kW 7, 5, 7 7, 5, 7 7, 5, 7 7, 5, 7
Back burner dimensions - mm 420x440, 420x440,
420x440
420x440, 420x440,
420x440
420x440, 420x440,
420x440
420x440, 420x440,
420x440
height 358 358 358 358
depth 738 860 860 738
width 540 540 540 540
Storage cupboard - mm
height 900 900 900 900
depth 900 900 900 900
width 1500 1500 1500 1500
External dimensions - mm
Configuration One-Side Operated Both-Sides Operated Both-Sides Operated One-Side Operated
Installation Standing as an island;
Standing back to
back
Standing as an island Standing as an island Standing against wall;
Standing back to
back; Wall mounted
Power supply Gas Gas Gas Gas
TECHNICAL DATA
GC1G31A1B
584266
GC1G31A2B
584268
GC1G31A2BF
584269
GC1G31C1B
584270

Electrolux thermaline S90
6-burners boiling top on base
Internet: http://www.electrolux.com/foodservice
CFAA0502013-10-03Subject to change without notice
G - Gas connection 3/4"
LEGEND
GC1G31A1B
584266
584266

Electrolux thermaline S90
6-burners boiling top on base
Internet: http://www.electrolux.com/foodservice
CFAA0502013-10-03Subject to change without notice
G - Gas connection 3/4" 3/4"
LEGEND
GC1G31A2B
584268
GC1G31A2BF
584269
584268, 584269

Electrolux thermaline S90
6-burners boiling top on base
Internet: http://www.electrolux.com/foodservice
CFAA0502013-10-03Subject to change without notice
G - Gas connection 3/4"
LEGEND
GC1G31C1B
584270
584270
