Electrolux AEG DD9996-B User manual

DD9996-B
Cooker Hood
Operating and Installation Instructions

2
For the User
Important Safety Information
Your Appliance
Operating Instructions
Cooker Hood Controls
To Operate
Recirculation
Extraction
Maintenance and Cleaning
External Cleaning
Metal Grease Filter
To Remove the Grease Filter Cassette
Charcoal Filter
To Remove/Replace the Charcoal Filter
Worktop Lighting
Replacing the Light Bulb
Something Not Working
Service and Spare Parts
Guarantee Conditions
For the Installer
Installation Instructions
Technical Information
Electrical Connections
Electrical Requirements
Electrical Connection
Installing the Cooker Hood
Installation Requirements
Unpacking
Clearance Height
Wall drilling and bracket  xing
Hood body mounting
Drilling the Shelves
Chimney assembly
Top Shelf
Electrical Connection and Working Test
Guide to use the instruction book
The following Symbols will be found in the text to guide you through the instruction book
Safety instructions Step by step instructions
Thank you for buying an AEG product.
To enable you to use your appliance effectively and safely, please read this instruction book carefully before using the
appliance and retain for future reference. If you require guidance in the use of the appliance or require further infor-
mation on AEG Products, please contact our Customer Services Department. For general enquiries concerning your
AEG appliance or for further information, visit our website at http:\\www.aeg.co.uk
Customer Services Department
Major Appliances
AEG
Addington Way
Luton
Bedfordshire
LU4 9QQ Tel: [phone](*)
* calls to this number may be recorded for training purposes.

3
Installation
• Any installation work must be undertaken by a quali-
ed electrician or competent person.
• This hood must be installed in accordance with the
installation instructions and all measurements adhered
to.
• If the cooker hood is installed for use above a gas
appliance then the provision for ventilation must be
in accordance with the Gas Safety Code of Practice
BS.6172, BS.5440 and BS.6891 (natural gas) and
BS.5482 (LP gas) 1994, the Gas Safety (Installation &
Use) Regulations, the Building Regulations issued by
the Dept. of the Environment, the Building Standards
(Scotland) (Consolidated) Regulations issued by the
Scottish Development Department.
• The fan motor of the cooker hood incorporates a
cut-out device, which will operate if the cooker hood
is installed below the minimum height recommended
in the Technical Information section, or if the motor
becomes overheated. If the cut-out device is acti-
vated, switch off the motor and allow the hood to
cool. The cut-out device will reset itself when the
fan motor has cooled.
• It is dangerous to alter the specications or modify
this product in any way.
• When installed between adjoining wall cabinets, the
cabinets must not overhang the hob.
• If the room where the hood is to be used contains
a fuel burning appliance such as a central heating
boiler then its ue must be of the room sealed or
balanced ue type.
• If other types of ue or appliances are tted en-
sure that there is an adequate supply of air to the
room.
• When the hood is used in conjunction with appliances
supplied with energy other than electricity, the nega-
tive pressure in the room must not exceed 0.04mbar
to prevent fumes being drawn back into the room by
the hood.
• The ducting system for this appliance must not be
connected to any existing ventilation system which
is being used for any other purpose.
• Do not install above a cooker with a high level
grill.
Child Safety
• The appliance is designed to be operated by adults.
Children should not be allowed to tamper with the
controls or play with the appliance.
IMPORTANT SAFETY INFORMATION
These warnings are provided in the interests of your safety. Ensure that you understand them all before installing
or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings
of these warnings contact the Customer Services Department.
During Use
• This appliance is for domestic use only.
• Never leave frying pans unattended during use as
over-heated fats and oils might catch re.
• Never do ambé cooking under this cooker hood.
• Do not leave naked ames under this hood.
Maintenance and Service
• This appliance can be a re hazard if the grease
and charcoal lters are not cleaned or replaced as
recommended.
• Under no circumstances should you attempt to re-
pair the appliance yourself. Repairs carried out by
inexperienced persons may cause injury or serious
malfunctioning. Refer to your local Service Force
Centre. Always insist on genuine spare parts.

4
YOUR APPLIANCE





5
OPERATING INSTRUCTIONS
Key Function Display
AUpper panel closed: when pressed for about two sec-ond it
opens the upper panel. It switches the motor on at the latest
selected speed.Upper panel open: when shortly pressed it
switches the motor and the lights on/off. It stops all function
and closes the panel
Indicates the selected speed.
BDecreases the suction speed. Number of lit LEDS decreases.
CIncreases the suction speed. Number of lit LEDS increases.
DFunctioning only when the upper panel is open. This speed
has been timed at 10 minutes. After that time the system ac-
tivates automatically the latest selected speed. The function
is suitable for cooking conditions when vapours and smells
are of the at most emission.
I ashes and all the LEDS on the display are lit.By pressing
the key the function is deacti-vated.
EFunctioning only when the upper panel is open. By pressing
this key it is possible to set up the motor to a suction speed
at 100 m3/h .
24–symbol appears and the LEDS on the display go off
cyclically, one by one. By pressing the key the function is
deacti-vated.
FFunctioning only when the motor is on. By pressing this key
it is possible to set the delayed shutdown of the motor and
the lighting to 30 minutes.
A ashing clock symbol appears. By pressing the key the
function is deacti-vated.
GBy pressing this key for about 2 seconds it is possible to reset
the lter saturation alarm.
A drop symbol indicates that the metal grease lters satu-
ration alarm has been activated, and the lters need to be
washed. The alarm is triggered after 100 working hours. C
indicates that the charcoal lter satura-tion alarm has been
activated, and the lter has to be replaced. The alarm s
triggered after 200 working hours.
HBy pressing this key the intensity of the lighting sys-tem can
be modied up to ve levels.
IIt switches the lights on and off (at maximum speed) inspite
of the panel’s position.
LUpper panel closed: when pressed for about two sec-ond it
opens the upper panel .Upper panel open: when pressed for
about two second it switches off motor and lights resetting
every acti-vated function, and closes the panel.
Keyboard lock: it is possible to jam the keyboard when, for example, cleaning the glass. The motor and
lights are switched off, and upper panel can be open or closed.By pressing the D-key for about 5 secon-
ds the keyboard block can be activated or deactivated. This function is conrmed by a Beep and by an
animation on the display.






6
This cooker hood can be used to recirculate or extract
contaminated air.
Recirculation Mode
The cooker hood is supplied specied for use in the recir-
culation mode with the charcoal lter tted.
The contaminated air is cleaned by passing through the
lters and than back into the kitchen.
The activated charcoal lter absorbs odours arising from
cooking. In use it will slowly become saturated in grease
and less effective. The lter normally requires changing
after at least every three months or more frequently if the
hood is used for more than three hours per day.
• Remove the chimney angle bracket.
• Screw the lter cover onto the air outlet, using four
screws 12c (2.9 x 12.5).
• Fix the air outlet grid 8on the recirculation air outlet
using the 2 screws 12d (2,9 x 9,5) provided.
Extraction (Ducted)
The cooker hood is more effective when installed in the
extraction mode (ducted to the outside).
Venting kits may be purchased through your retailer or DIY
store, and must be evacuated through an outside vent of
ø125 (5ins) or ø150mm (6ins).
The ducting used must be manufactured from re retar-
dent material conforming to the relevant British Standard
or DIN 4102-B1.
When the cooker hood is ducted to the outside the
charcoal filter must be removed.
When installing the ducted version, connect the hood to
the chimney using either a exible or rigid pipe ø 150 or
125mm, the choice of which is left to the installer.
To install a ø 150
• Fix the pipe in position using sufcient pipe clamps
(not supplied).
To install a ø 120
• To install a ø 120 mm air exhaust connection, insert
the reducer ange 9 on the hood body outlet.
• Fix the pipe in position using sufcient pipe clamps
(not supplied).
• Remove any activated charcoal lters.
OPERATING INSTRUCTIONS




Fitting the Ducting
• To install the Ducting Version of the hood, the optional
Ducting chimney kit must be purchased.
 Neverdoambécookingunderthiscooker
hood.
 Takeextracarewhenfryingandneverleave
fryingpansunattendedduringuse,asover-
heatedfatsandoilscancatchre.
 Donotleavenakedamesunderthecooker
hood.
 Ensurethehoodisswitchedonbeforeusingthe
hob.
 Ensureheatingareasonyourhobarecovered
withpotsandpanswhenusingthehoband
cookerhoodsimultaneously.
 Ensurenottodamagethecharcoallterwhen
cleaningorreplacingastheactivatedcharcoal
insideissaturatedwithgrease,whichwillstainif
itcomesintocontactwithclothingorfurnishings.




7
MAINTENANCE AND CLEANING
Before carrying out any maintenance or lean-
ing isolate the cooker hood from the mains
supply.
The cooker hood must be kept clean, as a
build up of grease or fat can be a fire hazard.
External Cleaning
The metal casing, grille and chimney should be cleaned at
least once a month to keep it looking like new. Wipe over
the hood with a soft cloth wrung out in mild
soapy water and then dry thoroughly.
Never use scouring pads or abrasive cleaners as they
may scratch or damage the surfaces.
 Alwayswearprotectivegloveswhencleaning
thehood.
 Neverusescouringpadsorabrasivecleaners.
 Neveruseexcessiveamountsofwaterwhen
cleaningparticularlyaroundthecontrolpanel.
Metal Grease Filters
Filters can be washed in the dish machine. They need to
be washed when Drop-sign appears on the display or in
any case every 2 months, or even more frequently in case
of particularly intensive use of the hood.
To Remove the Grease Filter
• Open the upper panel by pressing the A-key for few
second (see Part USE).
• Remove the lters one by one pushing them towards
the back side of the hood unit and simultaneously
pulling downwards.
Alarm reset
• Press the G–key for at least 2 seconds.
Cleaning the lters
• Any kind of bending of the lters has to be avoided
when washing them. Before tting them again into the
hood make sure that they are completely dry. (The
colour of the lter surface may change throughout
the time but this has no inuence to the lter ef-
ciency).
• When tting the lters into the hood pay attention
that they are mounted in correct position the handle
facing outwards.

8
MAINTENANCE AND CLEANING
Alarm signal reset
• Stop the motor and switch off the lights.
• Press the G-key for at least 2 seconds.
Before carrying out any maintenance or
cleaning isolate the cooker hood from the
mains supply.
Charcoal Filters
In the recirculation mode the charcoal lters absorb smells
and unwanted odours.
This lter cannot be washed or regenerated. It must be
replaced when the C appears on the display or at least
once every 4 months. The lter saturation alarm has to
be activated already before.
Enabling/Disabling the alarm signal
• In the recycling version hoods the lter saturation
alarm must be activated during the instal-lation or
later.
• Switch off the hood and the lights.
• Press the E-key for about 5 seconds until the last
two segments of the motor LEDS are lit on the
display.
• By releasing the E-key the clock icon starts to
ash.
• Within 3 seconds press the D-key to activate/
deactivate charcoal lter saturation alarm.
• C-symbol lit - charcoal lter saturation alarm
ACTIVATED.
• C-symbol unlit - charcoal lter saturation alarm
DEACTIVATED.
To Remove the Charcoal Filters
• Open the upper panel by pressing the A-key for few
second (see Part USE).
• Remove the metal lters.
• Remove the saturated charcoal lter as indicated
(A).
• Fit the new lters as indicated (B).
• Put the metal grease lters in their seats.
This appliance can be a possible fire hazard if
the grease and charcoal filters are not cleaned
and replaced as recommended.
A
B

9
Changing the Halogen Spot Lamp
• Extract the lamp from the lamp holder by pulling
gently.
• Replace with another of the same type, making sure
that the two pins are properly inserted in the lamp
holder socket holes.
Replacement filters and light bulbs can be
obtained from your local Service Force Centre.
Replacing the fuser
The hood panel opening and closing mechanism is
controlled by a starter motor which is activated by a
fuser. This fuser works only on the starter motor. In case
the fuser gets damaged when the panel is closed it is be
necessary to manually unblock the panel. In this case
proceed as follows:
• Remove the cover placed up on the left side by the 2
screws.
• Unscrew the 2 hexagonal screws(A) by means of an
appropriate tool to open the panel manually.
• After having completely opened the panel remove the
metal grease lters, as explained in the partconcern-
ing the lter cleaning.
• The fuser is placed up on the right side. Turn the fuser
holder as indicated. Replace the fuser with one having
the same features.
• Open the panel by the control board (see par. USE
button L) so the moving arm comes out, and you can
screw again the 2 hexagonal screws(A) previously
removed.
• Put the fuser holder and grease lters into their place
again. Make sure that the hood functions correctly. In
case the panel doesn’t work correctly it is necessary
to contact an authorized technician.
• Reassemble the cover placed up on the left side by
the 2 screws previously remouved.
If the fuser gets damaged being the panel open, it is
sufcient to simply remove the grease lters and replace
the fuser.
MAINTENANCE AND CLEANING
�

10
SOMETHING NOT WORKING
SERVICE AND SPARE PARTS
If, having followed these instructions carefully, your cooker hood fails to work properly please carry out
the following checks.
Symptom
The cooker hood will not start
The cooker hood is not working effectively
The cooker hood has switched off during operation
I
f after all these checks, the problem persists, contact
your local Service Force Centre, quoting the model and
serial number.
Please note that it will be necessary to provide proof of
purchase for any in-guarantee service calls.
Solution
• Check the hood is connected to the electricity sup-
ply.
• Check that the fan speed control is set to 1, 2 or 3.
• The fan speed is set high enough for the task.
• The grease lter is clean.
• The kitchen is adequately vented to allow the entry
of fresh air.
• If set up for recirculation, check that the charcoal
lter is still effective.
• If set up for extraction, check that the ducting and
outlets are not blocked.
• The safety cut-out device has been tripped.
• Turn off the hob and then wait for the device to re-
set.
In-guarantee customers should ensure
that the above checks have been made as
the engineer will make a charge if the fault
is not a mechanical or electrical
breakdown.
If you require an engineer or wish to purchase spare parts
contact your local Service Force Centre by telephoning:
08705 929929
Your telephone call will be routed to the Service Force
Centre covering your postcode area.
For general enquires concerning your AEG appliance or
for further information on AEG products, please contact
our Customer Services Department at the address below
or visit our website at www.aeg.co.uk
Customer Services Department
Major Appliances
AEG
Addington Way
Luton
Bedfordshire
LU4 9QQ
Tel: [phone] *
* calls to this number may be recorded for training pur-
poses

11
GUARANTEE CONDITIONS
Standard Guarantee Conditions
We, AEG, undertake that if within 12 months of the date of the purchase this AEG built-in appliance or any part thereof
is proved to be defective by reason only of faulty workmanship or materials, the company will, at our option, repair or
replace the same FREE OF ANY CHARGE for labour, materials and carriage on condition that:
• The appliance has been correctly installed and used only on the electrical supply stated on the rating plate.
• The appliance has been used for normal domestic purposes only, and in accordance with the manufacturer’s
operating and maintenance instructions.
• The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any person not
authorised by us.
• All service work under this guarantee must be undertaken by an AEG Service Force Centre.
• Any appliances or defective parts replaced shall become the property of this company.
Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available outside these hours in
which case a premium will be charged.
EXCLUSIONS
This Guarantee does not cover:
• Damage or calls resulting from transportation, improper use or neglect, the replacement of any light bulbs or
removable parts of glass or plastic.
• Costs incurred for calls to put right appliances improperly installed or calls to appliances outside the United
Kingdom.
• Appliances found to be in use within a commercial environment, plus those which are the subject of rental
agreements.
• Products of AEG manufacture which were not marketed by AEG. This guarantee is in addition to your statutory
and legal rights.
EUROPEAN GUARANTEE
If you move to another country within Europe then your guarantee moves with you to your new home subject to the
following qualications:
• The guarantee starts from the date you rst purchased your product.
• The guarantee is for the same period and to the same extent for labour and parts as exists in the new country
of use for this brand or range of products.
• The product is installed and used in accordance with our instructions and is only used domestically, i.e. a normal
household.
• The product is installed taking into account regulations in your new country.
Before you move please contact your nearest Customer Care centre, listed below, to give them details of your
new home. They will ensure that the local Service organisation is aware of your move and able to look after
you and your appliance.
France Senlis [phone]
Germany Nurnberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Luton [phone]

12
INSTALLATION INSTRUCTIONS
 Itisdangeroustoalterthespecicationsorattempttomodifythisproductinanyway.
Technical Information
DIMENSIONS HEIGHT (CANOPY): 760 mm
HEIGHT (CHIMNEY): 300-300 mm
WIDTH (CANOPY): 898 mm
WIDTH (CHIMNEY): 300 mm
GROSS: 47 kg
NET: 37,4 kg
ELECTRICAL SUPPLY: 220-240 V (50 Hz)
POWER CONSUMPTION: 370 W
FAN MOTOR: 330 W
LAMP: (2x20W) HALOGEN Ø 35 mm GUA 40 W
SUITABLE FOR INSTALLATION
ABOVE: ELECTRIC HOB: 7 KW
GAS HOB: 10 KW
SLOT-IN GAS COOKER 13.5 KW
SLOT-IN ELECTRIC COOKER 12.4 KW
Note: CE Marking certies that this appliance complies with the requirements laid
down in EEC directive 89:336. (Electromagnetic compatibility) and subsequent
modications and Low Voltage directive 72/23/E.
ELECTRICAL CONNECTIONS
This appliance must be earthed
Electrical Requirements
Any permanent electrical installation must comply with
the latest I.E.E. Regulations and local Electricity Board
regulations. For your own safety this should be undertaken
by a qualied electrician e.g. your local Electricity Board,
or a contractor who is on the roll of the National Inspection
Council for Electrical Installation Contracting (NICEIC).
Electrical Connection
Before connecting to the mains supply ensure that the
mains voltage corresponds to the voltage on the rating
plate inside the cooker hood.
Remove the grease lters (see paragraph Maintenance)
being sure that the connector of the feeding cable is
correctly inserted in the socket placed on the side of
the fan.
This appliance is tted with a 3 core mains cable and
must be permanently connected to the electricity supply
via a double-pole switch having 3mm minimum contact
gap on each pole. A Switched Fuse Connection Unit to
BS1363 Part 4, tted with a 3 Amp fuse, is a recommended
mains supply connection accessory to ensure compliance
with the Safety Requirements applicable to xed wiring
instructions.
This appliance conforms to BS 800: 1988 and EEC
Directive No. 78 308 regarding suppression of radio and
television interference.

13
INSTALLING THE COOKER HOOD
Please ensure that when the appliance is installed it
is easily accessible to an engineer in the event of a
breakdown.
 Allinstallationsmustcomplywiththelocal
authoritiesrequirementsforthedischargeof
exhaustair.
 Incorrectinstallationmayaffectthesafetyofthis
cookerhood.
Installation Requirements
 Beforeinstallationcheckthewallto
 whichthecookerhoodistobettedfor
 electriccables,waterpipesorgas.
 Thechimneyhoodmustbeinstalledaccording
totheinstructionssuppliersbelowandbyqua-
liedandcompetentpersonneltotherelevant
NationalStandards.
The cooker hood is designed to be xed to a solid block or
block wall over a cooking area. If not, suitable xing must
be used for other types of walls. The hood can be used
in the extraction (ducted to the outside) or recirculation
(internal recycling) mode.
The Installation work must be undertaken by a qualied
and competent person. The manufacturer disclaims any
responsibility to damages due to incorrect installation of
the cooker hood or if the cooker hood is not installed in
compliance with relevant regulations controlling this type
of installation.
Unpacking
Before unpacking the cooker hood position the carton with
the arrows pointing upwards as illustrated on the carton.
The canopy is supplied with the following components
for installation:
Ref Qty Product Components
11 Cooker hood with control unit, lights,
blower unit, filters
2.1 1 Upper chimney
2.2 1 Lower chimney
81 Air outlet grid
91 Reducer flange Ø 150-120
16 1 Cover for recycling version
Ref. Q.ty Installation components
7.2.1 2 Fixing brackets for upper chimney
11 7 Plugs
11a 2 Plugs SB 12/10
12a 7 Screws 4,2 x 44,4
12c 10 Screws 2,9 x 6,5
12e 2 Screws 2,9 x 9,5
Q.ty Documentation
1 Instruction booklet



  











 

14
INSTALLATION INSTRUCTIONS
Wall drilling and bracket xing
As a rst step, proceed with the following drawings:
• a vertical line up to the ceiling or up to the upper
limit, at the centre of the area in which the hood is to
be tted;
• a horizontal line at a minimum 960 mm above the
cooker top.
• Mark a point (1) on the horizontal line, 292 mm to
the right of the vertical reference line.
• Repeat this operation on the other side, checking
that the two marks are levelled.
• Mark a reference point (2) as indicated at 200 mm
from the vertical reference line and 458 mm above
the cooker top.
• Repeat this operation on the other side, checking
that the two marks are levelled.
• Mark a reference point (3) at 743 mm above the
cooker top on the vertical reference line.
• Drill at the marked points (1), using a ø 12 mm drill
bit.
• Drill at the marked points (2) and (3), using a ø 8
mm drill bit.
• Insert the bracket plugs 11a into the holes (1) and
tighten the screws.
• Insert plug 11 into holes (2) and (3).
• Place bracket 7.2.1 on the wall, about 1-2 mm from
the ceiling or from the upper limit, aligning the centre
(notch) with the vertical reference line.
• Mark the wall at the centres of the bracket holes.
• Place the bracket 7.2.1 on the wall at X mm below
the rst bracket (X = height of the upper chimney
section), aligning the centre (notch) with the vertical
line.
• Mark the wall at the centres of the bracket holes.
• Drill ø 8 mm holes at all the marked centre points.
• Insert the wall plugs 11 in the holes.
• Fix the brackets using the 12a screws (4,2 x 44,4)
supplied with the hood.
 







 









15
Hood body mounting
• Firstly, it is necessary to adjust the two Vr-screws of
the 11a-brackets, at minimun (B).
• Hang the hood body on the two brackets 11a.
• Connect the hood to the mains supply by means of
a bipolar switch with at least 3 mm contact gap.
• see Part USE to open the upper panel
• Remove the metal lters by using the handles
• In order to align the hood it is necessary to adjust
the Vr-screws from inside the hood.
• Fasten the safety screw 11.
• Fit again the metal lters into their seats and see
Part USE to close the upper panel.
• Disconnect the hood from the mains supply.
Attention: If any barrier occurs in its way during the
panel opening or closing, the upper panel stops for
1 sec and starts again the other way round. If within
5 sec the panel does not open or close, the motor
stops. Press the key once again.
Chimney assembly
Upper exhaust Chimney
• Slightly widen the two sides of the upper chimney
and hook them behind the brackets 7.2.1, making
sure that they are well seated.
• Secure the sides to the brackets using the 4 screws
12c (2,9 x 9,5) supplied.
Lower exhaust Chimney
• Slightly widen the two sides of the chimney and
hook them between the upper chimney and the wall,
making sure that they are well seated.
• Fix the lower part laterally to the hood body using
the 2 screws 12c (2,9 x 9,5) supplied.






INSTALLATION INSTRUCTIONS





16
Electrical connection and working
test:
• Connect the hood to the mains supply.
• Open the upper panel by pressing the A-key (See
Part “USE” ) for at least 2 seconds.
• Remove the metal lters (See Part “MAINTENANCE”)
and make sure that the connector piece of the supply
cable is correctly inside the hood socket.
INSTALLATION INSTRUCTIONS

436004794_02 - 091217
The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead
it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling
of this product, please contact your local city ofce, your household waste disposal service or the shop where you purchased
the product.
