Electrolux PLHV36W6C User manual

PRODUCT NO. BASE MODEL NO. BRAND/SERIES MARKET COLOR
PLHV36W6CC PLHV36W6C Electrolux North America stainless steel
PRODUCT NO. EXHAUST-CFM VOLTAGE OWNER’S GUIDE INSTL. INSTR.
PLHV36W6CC 405 CFM 120 316137227 316137227
PRODUCT NO. WIRING DIAGRAM PRODUCTION DATE
PLHV36W6CC 5995397790 2004
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
©2003 Electrolux Home Products, Inc. All rights reserved
Publication No.
5995397790
031022
-EN/SERVICE /KC
099
Range Hood

11/13/2003 2
Publication No. PLHV36W6CC
5995397790
Exploded No. $1349
87
461
56
57
97
348
19
514
14
470
508
510
84
6
7511
509
48
8
46
47
42
43
40
41
31
23
85
REPLACEMENT PARTS

# = Fast Moving Part 3 11/13/2003
* = Non-Illustrated Part
PLHV36W6CC Publication No.
5995397790
REPLACEMENT PARTS
POS. NO PART NO DESCRIPTION
6 # 5304425236 Blower Wheel,fan
7 # 5304425237 Motor,blower fan
8 5304425238 Support,motor
14 5304425239 Housing,blower fan
19 # 5304425240 Capacitor,12.5 microfarad
23 # 5304425241 Filter,grease ,aluminum ,washable
31 # 5304425242 Lamp Assy,halogen G4 base,20 W,12 V,
w/holder,cover
40 5304435617 Control Box
41 5304425244 Control Panel
42 5304425245 Actuator,lamp key
43 5304425246 Actuator,motor key
46 # 5304425247 Switch,light ,sliding
47 # 5304425248 Switch,fan motor ,sliding
48 # 5304425249 Control Board,printed circuit ,120 V
56 5304425250 Chimney,duct cover ,lower ,fixed
57 5304425251 Chimney,duct cover ,upper ,sliding
84 # 5304425252 Transformer,60 Hz ,120 V
85 5304425253 Bracket,mounting hook ,hood rear
87 5304425254 Connector,transition duct
97 5304425255 Bracket,chimney support ,ceiling/rear
348 5304425256 Cover,capacitor box
461 5304425257 Anchor Assy,drywall ,with screw
470# 5304425258 Fuse
508 5304425259 Cover,fuse
509 5304425260 Plate,fuse holder
510 5304425261 Housing,transformer box
511 5304425262 Channel,xfmr box canal
514 5304425263 Housing,capacitor box

11/13/2003 4
Publication No. PLHV36W6CC
5995397790
WIRING DIAGRAM
