Electrolux 318202107 User manual

Service Manual
Warmer Drawer
318 202 107 (0311)

THIS IS A
BLANK
PAGE

I
Table of Contents
SAFE SERVICING PRACTICES .......................................... 1
WIRING DIAGRAM............................................................... 2
SECTION A - INSTALLATION INSTRUCTIONS ................. 3
FOR YOUR SAFETY .......................................................................................................... 3
WARM & SERVE DRAWER DIMENSIONS ........................................................................ 3
IMPORTANT NOTES TO THE INSTALLER ........................................................................ 4
IMPORTANT NOTE TO THE CONSUMER ......................................................................... 4
IMPORTANT SAFETY INSTRUCTIONS ............................................................................. 4
TOOLS YOU WILL NEED ................................................................................................... 4
WARM & SERVE DRAWER INSTALLATION ..................................................................... 5
SECTION B - REPLACEMENT OF PARTS ......................... 6
1.0 HOW TO REMOVE THE DRAWER FROM THE DRAWER CAVITY ........................ 6
2.0 HOW TO RE-INSTALL THE DRAWER ..................................................................... 6
3.0 HOW TO REMOVE THE APPLIANCE FROM THE CABINET .................................. 6
4.0 HOW TO REMOVE PANELS TO HAVE ACCESS TO THE PARTS .......................... 7
5.0 HOW TO REPLACE THE ELECTRICAL CORD ....................................................... 8
6.0 HOW TO REPLACE THE WARMER DRAWER ELEMENT ...................................... 8
7.0 HOW TO REPLACE THE THERMOSTAT ................................................................. 9
8.0 HOW TO REPLACE THE WARMER DRAWER CONTROL ..................................... 9
9.0 HOW TO REPLACE THE SLIDING CHANNELS .................................................... 10
SECTION E - EXPLODED VIEW DRAWINGS................... 12
BODY EXPLODED VIEW ................................................................................................. 12
BODY PARTS DESCRIPTION .......................................................................................... 13
DRAWER EXPLODED VIEW ............................................................................................ 14
DRAWER PARTS DESCRIPTION .................................................................................... 15

THIS IS A
BLANK
PAGE

1
SAFE SERVICING PRACTICES
To avoid personal injury and/or property damage, it is important that Safe Servic-
ing Practices be observed. The following are some limited examples of safe
practices:
1. DO NOT attempt a product repair if you doubt your ability to complete it in a
safe and satisfactory manner.
2. Before servicing or moving an appliance:
• Remove power cord from electrical outlet, trip circuit breaker to the OFF
position, or remove fuse.
• Turn off gas supply
• Turn off water supply
3. Never interfere with the proper operation of any safety device.
4. Use The Correct Replacement Parts Cataloged For This Appliance. Sub-
stitutions May Defeat Compliance With Safety Standards Set For Home
Appliances.
5. GROUNDING: The standard color code for safety ground wires is GREEN, or
GREEN with YELLOW STRIPES. DO NOT use ground leads as current
carrying conductors. It is EXTREMELY important that the service technician
reestablish all safety grounds prior to completion of service. Failure to do so
will create a hazard.
6. Prior to returning the product to service, ensure that:
• All electrical connections are correct and secure.
• All electrical leads are properly dressed and secured away from sharp edges,
high-temperature components, and moving parts
• All non-insulated electrical terminals, connectors, heaters, etc. are ad-
equately spaced away from all metal parts and panels
• All safety grounds (both internal and external) are correctly and securely
connected
• All panels are properly and securely reassembled
©2003 Electrolux Home Products, Inc.
!
WARNINGWARNING
WARNINGWARNING
WARNING
This service manual is intended for use by persons having electrical and mechanical
training and a level of knowledge of these subjects generally considered acceptable in the
appliance repair trade. Electrolux Home Products cannot be responsible, nor assume any
liability, for injury or damage of any kind arising from the use of this manual.

2Wiring Diagram

3
Section A - Installation Instructions
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
GENERAL INFORMATION
The Warm & Serve Drawer can be used:
• As a stand alone appliance
• As a combination Warm & Serve Drawer with a 30" (76 cm) built-in oven mounted above
IMPORTANT: The warmer drawer must be installed on a leveled surface from left to right, rear to front and the
surface must be capable of supporting 100 lbs (45 Kg).
Warm & Serve Drawer Dimensions
Stand Alone Installation
Combination Warm & Serve Drawer/
30" (76 cm) Built-in Oven Installation
NOTE: A 60" (152 cm) long cable is supplied with
the Warm & Serve Drawer.
A. HEIGHT B. WIDTH C. DEPTH
9 7/8 " (25 cm) 30" (76,2 cm) 24 5/8" (62,5 cm)
D. CUTOUT E. CUTOUT F. CUTOUT
HEIGHT WIDTH DEPTH
Min. 8 3/8" (21,3 cm) 28 1/2 " (72,4 cm) 24" (61 cm)
Max. 8 5/8" (21,9 cm) 28 3/4 " (73 cm)
D. CUTOUT E. CUTOUT F. CUTOUT G. HEIGHT
HEIGHT WIDTH DEPTH
Min. 8 3/8" (21,3 cm) 28 1/2 " (72,4 cm) 24" (61 cm) 1 1/2" (3,8 cm)
Max. 8 5/8" (21,9 cm) 28 3/4 " (73 cm)
IMPORTANT: The Warm & Serve Drawer runs off a
single phase three-wire 120 volt, 60 hertz, AC only
electrical supply with ground.
H* =10 1/8" (25.7 cm) Min. is a Critical
dimension and has to be respected.
Depends on critical
dimension H
A. HEIGHT B. WIDTH C. DEPTH
40" (101,5 cm) 30" (76,2 cm) 24 5/8" (62,5 cm)
FLOOR
Warm and Serve
Cutout
Warm and Serve
Drawer
60" (152 cm)
Cord
Minimum distance to
floor 41/2" (11,4 cm)
Bottom of oven cutout
Caution: Two 3" wide X 3/4"
(1.9 cm) thick planks have to
be install and they should be
able to support 200 pounds.
(90.7 Kg)

4Section A - Installation Instructions
Important Notes to the Installer
1. Read all instructions contained in these installation
instructions before installing appliance.
2. Remove all packing material from appliance before
connecting the electrical supply.
3. Observe all governing codes and ordinances.
4. Be sure to leave these instructions with the consumer.
Important Note to the Consumer
Keep these instructions for future reference.
IMPORTANT SAFETY
INSTRUCTIONS
•Be sure your appliance is installed and plugged
into a 120 Volt grounded outlet.
•This appliance must be electrically grounded in
accordance with the National Electrical Code
ANSI/NFPA No. 70—latest edition in the United
States, or CSA C22.1, Part 1 in Canada, and local
code requirements.
Tools You Will Need
Phillips® Screwdriver
Pencil
Ruler or Tape Measure and Straight-edge
Hand Saw or Saber Saw
Spirit Level
Figure 1
c/c 25 5/16"
(64.3 cm)
24" (64.3 cm) Max.
23 5/8" (60 cm) Min.
c/c 12 21/32"
(32.15 cm)

5
Section A - Installation Instructions
Warm & Serve Drawer Installation
1. Locate the 2 anti-tip brackets supplied as shown on
figure 1.
2. Slide drawer into cutout opening until front frame of
drawer is flush against cabinet. Be careful not to
pinch electrical cord.
3. Remove the drawer as instructed in the Use & Care
Guide and secure drawer housing to cabinet using
the 2 nickel-plated screws supplied (see Figure 2).
Do not overtighten screws.
4. The 60" (152 cm) appliance power cord can now be
connected into the 120 Volt outlet.
5. Proceed with mounting built-in oven above the
drawer (if applicable). Follow installation instructions
provided with built-in oven. Make sure to use anti-
tip brackets supplied with the built-in oven.
Figure 2
Use screws
supplied to attach
drawer to front
of cabinet.

6Section B - Replacement of parts
1.0 HOW TO REMOVE THE DRAWER FROM THE DRAWER CAVITY
1. Disconnect Warmer Drawer from electrical supply.
2. Make sure the drawer is COOL. Open the drawer to the
fully opened position
3. Locate the latches on both sides of the warmer drawer.
Push at the same time on both latches while pulling the
drawer out. (Figure 1)
Figure 1
2.0 HOW TO REINSTALL THE DRAWER
1. Align the glide latches on both sides of the drawer with slots on the drawer.
2. Push the drawer back in until you heard two clicks which will indicate that
the drawer is well installed.
3.0 HOW TO REMOVE THE APPLIANCE FROM THE CABINET
1. Disconnect Warmer Drawer from electrical supply.
2. Remove the drawer from the drawer cavity. (Section 1.0)
3. Remove the 2 screws securing the warmer drawer to the cabinet.
4. Pull out the appliance from the cabinet.

7
Section B - Replacement of parts
4.0 HOW TO REMOVE PANELS TO HAVE ACCESS TO THE PARTS
1. Disconnect Warmer Drawer from electrical supply.
2. Remove the drawer from the drawer cavity. (Section 1.0)
3. Remove the appliance from the cabinet. (Section 3.0)
4. Remove the 2 screws on both sides. (Figure 2)
5. Remove the 2 screws located at rear of the appliance.
(Figure 3)
6. Remove the 3 screws located at front of the appliance.
(Figure 4)
Cavity Interior view
Figure 2
Figure 3
Figure 4

8Section B - Replacement of parts
5.0 HOW TO REPLACE THE ELECTRICAL CORD
1. Disconnect Warmer Drawer from electrical supply.
2. Remove the drawer from the drawer cavity. (Section 1.0)
3. Remove the appliance from the cabinet. (Section 3.0)
4. The electrical cord is located at rear of the appliance
proceed from steps 4 to 6 under section 3.0 to have
access to the electrical cord.
2. Disconnect the electrical cord. (Figure 5)
3. Replace the electrical cord and reassemble in reverse
order.
6.0 HOW TO REPLACE THE WARMER DRAWER ELEMENT
1. Disconnect Warmer Drawer from electrical supply.
2. Remove the drawer from the drawer cavity. (Section 1.0)
3. Remove the appliance from the cabinet. (Section 3.0)
4. Proceed from steps 4 to 6 under section 3.0 to have
access to the element.
5. Remove the 2 screws at the rear. (Figure 6)
Figure 5
Figure 6
6. Remove the 2 screws at the front of the element. (Figure
7)
7. Disconnect the 2 wires.
8. Replace the element and reassemble in reverse order.
Figure 7

9
Section B - Replacement of parts
7.0 HOW TO REPLACE THE THERMOSTAT
1. Disconnect Warmer Drawer from electrical supply.
2. Remove the drawer from the drawer cavity. (Section 1.0)
3. Remove the appliance from the cabinet. (Section 3.0)
4. Proceed from steps 4 to 6 under section 3.0 to have
access to the thermostat.
5. There is 2 different thermostats.
6. Remove the 2 screws first. (Figure 8)
7. Disconnect the 2 wires. (Figure 9)
8. Replace the defective thermostat and reassemble in
reverse order.
Figure 8
Figure 9
8.0 HOW TO REPLACE THE WARMER DRAWER CONTROL
1. Disconnect Warmer Drawer from electrical supply.
2. Remove the drawer from the drawer cavity. (Section 1.0)
3. Remove the appliance from the cabinet. (Section 3.0)
4. Remove the screw on the right side of the appliance to
have access to the drawer control. (Figure 10)
Figure 10

10 Section B - Replacement of parts
8.0 HOW TO REPLACE THE WARMER DRAWER CONTROL (CONTINUED)
5. Remove the 2 screws. (Figure 11)
6. Replace the drawer control by the side access and
reassemble in reverse order.
Figure 11
9.0 HOW TO REPLACE THE SLIDING CHANNELS
1. Disconnect Warmer Drawer from electrical supply.
2. Remove the drawer from the drawer cavity. (Section 1.0)
3. Remove screws holding the sliding channel you have to
replace. (Figure 12)
4. Replace the sliding channel and reassemble in reverse
order.
Figure 12

11
Section B - Replacement of parts
THIS IS A
BLANK
PAGE

12 Section C - Exploded view drawings
BODY EXPLODED VIEW

13
Section C - Exploded view drawings
BODY PARTS DESCRIPTION
Position No Part No Description
13A# 316095500 Switch, Infinite, Warmer
14# 318250400 Light, Indicator, Blue
19 318246900 Panel, Control, Stainless
32 318228100 Strain Relief
36A 318017600 Knob, Warmer
39 318144001 Cord, Service
46 318250500 Lens, Indicator Light
69 5303323134 Screw, Switch Mtg., 8-32 X 0.188
74 318141920 Bumper, Base
81 318251000 Element, Warmer Drawer
84# 318005106 Thermostat, Safety
84A# 318005104 Thermostat, Safety
86 316095800 Clip, Hold Down, Warmer Drawer
196 318100101 Cover, Access
198 08008009 Bushing, Side Panel, Nylon, RH, Snap
201 318145104 Wrapper, Outer
202 318121601 Wrapper, Lower
203 318025711 Bracket, Side Panel, RH
203A 318025701 Bracket, Side Panel, LH
205 318123711 Panel, Side, RH
205A 318123701 Panel, Side, LH
207 318143601 Panel, Wire Cover
209 318247400 Bracket, Wall
209* 5303302745 Screw, 10-16 X 1-1/8, Square Drive
* 318199730 Wiring Harness
* 08067961 Fastener, Clip Cable
* 5303211311 Screw, 8 X 0.500
* 5303300265 Screw, 8-18 X 0.500, Chrome
* 5303311333 Screw, 8-32 X 3/8, (6)
* 5303323140 Screw, Ground, 10-32 X 0.375
# = Fast Moving Part
* = Non-Illustrated Part

14 Section C - Exploded view drawings
DRAWER EXPLODED VIEW

15
Section C - Exploded view drawings
DRAWER PARTS DESCRIPTION
Position No Part No Description
1 318246400 Drawer, Warmer w/Track
4 318247000 Glass, Drawer Panel, Black
10 5303325168 Screw, 10-32 X 5/8, Handle Mtg
13 318248400 Channel, Drawer Slide, Outer
39 318238900 Handle, Oven Door, Stainless
74 318141920 Bumper, Base
80 318247300 Gasket, Warmer Drawer
85 316093600 Rack, Warmer Drawer
122 318247200 Panel, Drawer, Interior
123 318247100 Panel, Control, Humidity
126 318251100 Handle, Control, Humidity
126* 5304436029 Screw, Handle Mtg
130 318246800 Panel, Drawer Front, Stainless, RH Side
130A 318246801 Panel, Drawer Front, Stainless, LH Side
* 218490900 Cleaner, Stainless Steel
* 5303323175 Adhesive Tape, 1” Long
* 08016432 Screw, Truss Head, 8-18 X 0.375
* 5303311333 Screw, 8-32 X 3/8, (6)
# = Fast Moving Part
* = Non-Illustrated Part

THIS IS A
BLANK
PAGE
