WARM & SERVE DRAWER INSTALLATION INSTRUCTIONS
1
D
G
H*
F
BC
A
E
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
GENERAL INFORMATION
The Warm & Serve Drawer can be used:
• As a stand alone appliance
• As a combination Warm & Serve Drawer with a 30" (76 cm) built-in oven mounted above
IMPORTANT: The warmer drawer must be installed on a leveled surface from left to right, rear to front and the surface
must be capable of supporting 100 lbs (45 Kg).
P/N 318201805 (0411) Rev. A
English – pages 1-2
Español – páginas 3-4
Français – pages 5-6
Notes - pages 7-8
D
A
B
F
E
C
Warm & Serve Drawer Dimensions
Stand Alone Installation
Combination Warm & Serve Drawer/
30" (76 cm) Built-in Oven Installation
NOTE: A 60" (152 cm) long cable is supplied with the
Warm & Serve Drawer.
A. HEIGHT B. WIDTH C. DEPTH
10" (25.4 cm) 30" (76,2 cm) 24 5/8" (62,5 cm)
D. CUTOUT E. CUTOUT F. CUTOUT
HEIGHT WIDTH DEPTH
Min. 8 3/8" (21,3 cm) 28 1/2 " (72,4 cm) 24" (61 cm)
Max. 8 5/8" (21,9 cm) 28 3/4 " (73 cm)
D. CUTOUT E. CUTOUT F. CUTOUT G. HEIGHT
HEIGHT WIDTH DEPTH
Min. 8 3/8" (21,3 cm) 28 1/2 " (72,4 cm) 24" (61 cm) 1 1/2" (3,8 cm)
Max. 8 5/8" (21,9 cm) 28 3/4 " (73 cm)
FLOOR
Warm and Serve
Cutout
Warm and Serve
Drawer
60" (152 cm)
Cord
Minimum distance to floor
41/2" (11,4 cm)
IMPORTANT: The Warm & Serve Drawer runs off a
single phase three-wire 120 volt, 60 hertz, AC only
electrical supply with ground.
H* =10 1/8" (25.7 cm) Min. is a Critical
dimension and has to be respected.
Depends on critical
dimension H
Bottom of oven cutout
Caution: Two 3" (7,6 cm) wide X
3/4" (1,9 cm) thick planks have to
be install and they should be able
to support 200 pounds. (90,7 Kg)
A. HEIGHT B. WIDTH C. DEPTH
10" (25.4 cm) 30" (76,2 cm) 24 5/8" (62,5 cm)
29½"
(74.9 cm)
Printed in the USA
WARM & SERVE DRAWER INSTALLATION INSTRUCTIONS
2
Important Notes to the Installer
1. Read all instructions contained in these installation
instructions before installing appliance.
2. Remove all packing material from appliance before
connecting the electrical supply.
3. Observe all governing codes and ordinances.
4. Be sure to leave these instructions with the consumer.
Important Note to the Consumer
Keep these instructions for future reference.
IMPORTANT SAFETY
INSTRUCTIONS
•Be sure your appliance is installed and plugged
into a 120 Volt grounded outlet.
•This appliance must be electrically grounded in
accordance with the National Electrical Code ANSI/
NFPA No. 70—latest edition in the United States,
or CSA C22.1, Part 1 in Canada, and local code
requirements.
Tools You Will Need
Phillips® Screwdriver
Pencil
Ruler or Tape Measure and Straight-edge
Hand Saw or Saber Saw
Spirit Level
Warm & Serve Drawer Installation
1. Locate the 2 anti-tip brackets supplied as shown on
figure 1.
2. Slide drawer into cutout opening until front frame of
drawer is flush against cabinet. Be careful not to
pinch electrical cord.
3. Remove the drawer as instructed in the Use & Care
Guide and secure drawer housing to cabinet using
the 2 nickel-plated screws supplied (see Figure 2).
Do not overtighten screws.
4. The 60" (152 cm) appliance power cord can now be
connected into the 120 Volt outlet.
5. Proceed with mounting built-in oven above the drawer
(if applicable). Follow installation instructions provided
with built-in oven. Make sure to use anti-tip brackets
supplied with the built-in oven.
Figure 1
c/c 25 5/16"
(64.3 cm)
24" (64.3 cm) Max.
23 5/8" (60 cm) Min.
c/c 12 21/32"
(32.15 cm)
Figure 2
Use screws
supplied to attach
drawer to front
of cabinet.
