1
WINE COOLER
SERVICE MANUAL
5995430781 5/2005

2
ATTENTION!!!
This service manual is intended for use by persons having electrical and mechanical
trainingandalevelofknowledgeofthesesubjectsgenerallyconsideredacceptableinthe
appliance repair trade. Electrolux Major Appliances cannot be responsible, nor assume
any liability, for injury or damage of any kind arising from the use of this manual.
©2005 Electrolux Major Appliances
SAFE SERVICING PRACTICES - ALL APPLIANCES
To avoid personal injury and/or property damage, it is important that Safe
Servicing Practices be observed. The following are some limited examples of
safe practices:
1. DO NOT attempt a product repair if you have any doubts as to your ability to
complete it in a safe and satisfactory manner.
2. Before servicing or moving an appliance:
•Remove the power cord from the electrical outlet, trip the circuit breaker to
the OFF position, or remove the fuse.
•Turn off the gas supply and allow any residual gas to dissipate for 10 to 20
minutes.
3. Never interfere with the proper operation of any safety device.
4. USEONLYREPLACEMENTPARTSCATALOGEDFORTHISAPPLIANCE.
SUBSTITUTIONS MAY DEFEAT COMPLIANCE WITH SAFETY
STANDARDS SET FOR HOME APPLIANCES.
5. GROUNDING: The standard color coding for safety ground wires is GREEN,
or GREENwithYELLOWSTRIPES.Groundleadsarenottobeusedascurrent
carrying conductors. It is EXTREMELY important that the service technician
reestablish all safety grounds prior to completion of service. Failure to do so
will create a hazard.
6. Prior to returning the product to service, ensure that:
•All electrical connections are correct and secure
•All electrical leads are properly dressed and secured away from sharp
edges, high-temperature components, and moving parts
•All non-insulated electrical terminals, connectors, heaters, etc. are
adequately spaced away from all metal parts and panels
•All safety grounds (both internal and external) are correctly and securely
connected
•All panels are properly and securely reassembled

3
Safe Servicing Practices 2
Quick Reference Sheet 4
Owner’s Guide and Parts Information 4
Contact Information 4
General information 5
Safety Precautions 5
Door Adjustment 5
Specifications 7
Sample Wiring Diagram 8
Compressor/Electrical Specifications 9
Compressor Pins 9
Specifications 9
Refrigeration Systems 10
Refrigeration System Diagnosis Guide 11
Troubleshooting 12
Not Refrigerating (compressor and fan are operating) 12
Not Refrigerating (compressor not operating - fan operating) 12
Not Refrigerating (compressor and fan not operating) 12
Compressor Overheating 12
Compressor Will Not Stop Operating 12
Water Leak (inside unit) 12
Excessive Frost Build-up 13
Noisy 13
Fresh Food Temperature too Cold 13

4
QUICKREFERENCESHEET
1.Owner’s guide and parts information may
be viewed or downloaded at:
2. Contact information:
Orders.
Canada Service, Warranty, General
Questions.
U.S.A. Service, Warranty, General
Questions.
Damage Claims.
Parts Orders.
Mailing Address.
www.electroluxusa.com
EHP Direct South: 1-800-845-4555
EHP Direct Northeast 1-800-611-4057
Fax [phone]
EHP Direct North, Central & West 1-800-345-2566
Monday - Friday 8:00 AM - 5:00 EST 1-800-265-8352
Monday - Friday 8:00 AM - 5:00 EST
1-877-4Electrolux (435-3287) Electrolux ICON brands
1-800-456-4669 (option 3, then option 2)
1-800-320-0859
Electrolux Major Appliances
P.O. Box 212378
Martinez, GA. 30917

5
GENERAL INFORMATION
Safety Precautions
Do not attempt to service or repair the unit until you
have read the entire procedure. Safety items through-
out this manual are labeled with Danger, Warning or
Caution.
Risk of child entrapment. Before you throw away an
old refrigerator or freezer: Take off the doors, leave
shelves in place so that children may not easily climb
inside
• Never attempt to repair or perform
maintenance on the unit until the
electricity has been disconnected.
•Altering, cutting of power cord,
removal of power cord, removal of
power plug, or direct wiring can
cause serious injury, fire and/or
loss of property and/or life and will
void the warranty.
•Do not lift unit by door handle.
•Never use an ice pick or other sharp
instrument to help speed up defrosting. These
instruments can puncture the inner lining or
damage the cooling unit.
•Failure to clean the condenser every three months
can cause the unit to malfunction. This could void
the warranty.
•Never install the unit behind closed doors. Be sure
front grille is free of obstruction. Obstructing free
air flow can cause the unit to malfunction, and may
void the warranty.
DoorAdjustment
All model doors are aligned at the factory before ship-
ment. Occasional readjustment may be necessary, es-
pecially if an Overlay Panel is installed. The following
procedure will correct for up to 1/4" alignment.
IMPORTANT
The door should never be flush with the top of the cabi-
net. Even when level, the top edge of the door will be
1/8" below the top of the cabinet
To adjust door:
1. Compare the top edge of the door (opposite the
hinges) to the top edge of the cabinet and note the
type (up or down) of adjustment needed.
2. Remove the top hinge pivot pin with a 7/64" hex
wrench and lift door off bottom hinge
pin.
CAUTION

6
Be careful not to lose door closer inserts.
Note: The hinge plate on some models do not
have the holes slotted for adjustment. New
hinge plates are available from Electrolux Parts.
3. With door upside-down, inspect the bottom hinge
plate mounting holes.
a. If your plate has slotted mounting holes, loosen
but do not remove the two hinge plate screws.
b. If your plate does not have slotted mounting
holes, remove the old plate and install the new
plate with the notch to the inside of the door.
4. If door edge opposite the hinges needs to move up,
move plate toward outside of door. If door edge
needs to move down, move plate toward inside of
door. Repeat until top edge of door is parallel with
top of cabinet and tighten screws securely.
5. After adjustment is complete, remove the door
closers from the bottom hinge, clean thoroughly and
apply petroleum jelly to the mating surfaces of the
closers. Be sure that bosses on closers align with
holes in hinge and hinge plate. Mount door and
install top hinge pivot pin.

7
Brand
Series
Models
Defrost
Cooling Type
Total Capacity (bottles)
Dimensions
Width
Height
Depth
Unit Wt. (lbs)
Voltage
Agency Certs
Legs
Handle
Badge
Controls
Shelves
Temperature Zones
Door Arrangement
Lighting
Electrolux
Designer
E24WC48EBS
Automatic
Compressor
48
23 15/15”
34 1/8”
23 1/4”
128 lbs
115 VAC
UL, cUL
Adjustable
ICON
Electrolux ICON
Manual
5 side, 1 fixed display
3
Reversible, tinted glass
always on option
Electrolux
Professional
E24WC48EPS
Automatic
Compressor
48
23 15/15”
34 1/8”
23 1/4”
128 lbs
115 VAC
UL, cUL
Adjustable
Professional
Electrolux ICON
Manual
5 side, 1 fixed display
3
Reversible, tinted glass
always on option
Specifications

8
Sample Wiring Diagram
Note: Always refer to diagram on wine cooler.

9
Compressor/Electrical Specifications:
Compressor Pins:
To measure start winding resistance, measure across the C-S pins.
To measure run winding resistance, measure across the C-R pins. These pins should never measure any
resistance to ground. This would indicate a shorted compressor.
Specifications:
Start Winding Resistance: 28 OHMS.
Run Winding Resistance: 8 OHMS.
OVERLOAD PROTECTOR
START RELAY
RELAY COVER
C
SR

10
REFRIGERATIONSYSTEMS
Normal Vapor/Compression Cycle Refrigeration
•Refrigerant is pumped from the compressor to the condenser as a high pressure, high
temperature vapor.
•As the refrigerant cools in the high pressure condenser, the vapor condenses to liquid. During
this phase change, a great amount of heat is rejected with the help of the condenser fan.
•The liquid then flows to the dryer where it is strained and filtered.
•From the dryer, the refrigerant flows through the capillary tube which meters the liquid refrigerant
to the evaporator. The pressure of the refrigerant is reduced to the evaporating or low side
pressure.
•The reduction of pressure on the liquid refrigerant causes it to boil or vaporize until it reaches
saturation temperature. As the low temperature refrigerant passes through the evaporator coil, it
continues to absorb a lot of heat, causing the boiling action to continue until the refrigerant is
completely vaporized. It is during this phase change that the most heat is absorbed (the cooling
takes place) in the refrigerator.
•The refrigerant vapor leaving the evaporator travels through the suction line to the compressor
inlet. The compressor takes the low pressure vapor and compresses it, increasing both pressure
and temperature. The hot high pressure gas is pumped out the discharge line and into the
condenser. The cycle continues.
CAPILLARY TUBE
DRYER
CONDENSER
COMPRESSOR
EVAPORATOR

11

12
Troubleshooting
Problem
1. Not refrigerating (compressor
and fan are operating).
Cause
2. Not refrigerating (compressor
not operating - fan operating).
Cause
3. Not refrigerating (compressor
and fan not operating).
4. Compressor overheating.
Cause
5. Compressor will not stop
operating.
Cause
6. Water leak (inside unit).
Cause
DANGER
DO NOT service the unit until the main
electrical power has been disconnected.
Cause
a. Little or no frost pattern on
evaporator.
a. Relay defective.
b. Overload defective (open).
c. Compressor defective.
a. Control defective (open).
b. Broken wire in compressor
circuit.
c. Power cord not plugged in.
d. Control in off position.
a. Condenser air flow restricted.
b. Condenser fan blade
obstructed.
c. Condenser fan motor stalled.
d. Defective compressor.
a. Control set too cold.
b. Control defective (contacts will
not open).
c. Control sensing bulb not
sensing evaporator plate.
a. Defrost drain plugged.
Correction
a. Check for sealed system leak
or restriction.
Remedy
a. Replace relay.
b. Replace overload.
c. Replace compressor.
Remedy
a. Replace control.
b. Repair or replace wiring.
c. Plug in power cord.
d. Rotate control knob clockwise.
Remedy
a. Remove restriction (clean
condenser and grille).
b. Remove blade restriction.
c. Replace fan motor.
d. Replace compressor.
Remedy
a. Adjust control warmer (counter
clockwise).
b. Replace control.
c. Clamp bulb completely against
bottom of plate, routing bulb
away from compressor
discharge tube.
Remedy
a. Remove obstruction.
Remedy

13
Problem Cause Correction
7. Excessive frost build-up.
Cause
8. Noisy.
Cause
9. Fresh food temperature too
cold.
Cause
a. Door gasket not sealing
properly.
b. Door out of alignment.
c. Water soaked cabinet
insulation.
d. Light stays on when door is
closed.
a. Copper refrigeration tube
touching cabinet.
b. Fan blade touching shroud.
c. Fan blade obstruction (wiring,
foam insulation, packaging
material).
a. Temperature control set too
cold.
a. Adjust door hinges or replace
door gasket.
b. Align fill door hinges.
c. Replace foamed cabinet
assembly (factoryrepair only).
d. Repair light bracket.
Remedy
a. Carefully adjust tubing.
b. Adjust fan mounting or shroud.
c. Remove obstruction.
Remedy
a. Adjust control to warmer setting
(counterclockwise).

14
NOTES

15
NOTES

16
