Electrolux E24WC75HSS0 User manual

Product No. E24WC75HSS0
Color stainless
Volts 115
Wiring Diagram 241899001
Owner's Guide 241957000
Market North America
Service Data Sheet 241957100
U05L00004.eps U05DIBAAA0.eps U05BIABBA0.eps U05SWIAAA0.eps
U05CWADAD1.eps W241899001B.eps S241899001B.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
THIS CATALOG SUPERCEDES
PUBLICATON #5995522694.
Publication No.
5995531851
09/01/21
(EN/SERVICE/KHB)
390
WINE COOLER
Model No.
E24WC75H
Copyright ©2009 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995531851 E24WC75HSS0
01/09 2
DOOR
26
26
23 21C
21C
26
26 40
26
26
26
22A
22
22C
22D
20
20A
21D
21D
1
3
10
26
26
21A21A 21A
18
13
15
21
21
6
13A
U05DIBAAA0

E24WC75HSS0 Publication No: 5995531851
# Functional Parts 3 01/09
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 7241867201 Gasket-door, black
3 7241879203 Door Assembly, glass, w/framing
6 # 7241958501 Harness-wiring, door
10 7241953401 Plug button, black
13 7241866601 Door Stop, black, RH
13A 7241866602 Door Stop, black, LH
15 7241954601 Cover-door, stainless
18 7241962801 Handle-door, stainless steel
20 7241866801 Door Closer, cam, black RH, upper
20A 7241866802 Door Closer, cam, black LH, upper
21 7241548004 Screw, handle mtg, 10-32 x 1/4, (2)
21A 7241906101 Screw-#10 x 3/4 TEK
21C 7241918201 Screw, #8-32 x 3/8, flat head
21D 7241904601 Screw, #10-32 x 1/4
21D* 7241947201 Washer-flat, .250 x 1.50 OD, zinc
22 7241866401 Plate-door, upper left
22A 7241866402 Plate-door, upper right
22C 7241866501 Plate-door, lower left
22D 7241866502 Plate-door, lower right
23 7241897403 Board-control, temp control
26 7215503203 Screw, cr pan hd, 10-16 x 0.500
40 7241866101 Cover-access

Publication No: 5995531851 E24WC75HSS0
01/09 4
CABINET
89
30
30A
22
21D
21A
209
21C
21C
22A
23
23
42
42
42
43
43
43
72
92
15
15
15
15 26
26
26
26
92
92
37
37A
40
210
40A
U05BIABBA0

E24WC75HSS0 Publication No: 5995531851
# Functional Parts 5 01/09
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
15 # 7241904201 Light Assembly, LED, (4)
21A 7241906101 Screw-#10 x 3/4 TEK
21C 7241947301 Screw
21D 7241500304 Screw, hex washer head, 8-18AB x 0.625
22 7241882201 Door Closer, cam, black
22A 7241882202 Door Closer, cam, black LH, lower
23 7241904601 Screw, #10-32 x 1/4
26 7241904301 Screw, LED lighting
30 7241882401 Bracket-lower hinge, RH, w/hinge pin
30A 7241882402 Bracket-lower hinge, LH, w/hinge pin
37 7241882301 Hinge-upper, black
37A 7241882302 Hinge-upper, black LH
40 7241881801 Cover-upper hinge, black, RH
40A 7241881802 Cover-upper hinge, black, LH
42 7241710601 Screw, hex washer hd, 1/4 x 7/8, hinge mtg
43 7241911501 Leveling Leg, screw
72 7241908401 Grille/Kickplate, stainless
72* 7241908402 Grille/Kickplate, stainless
89 7241898002 Cover-access
92 7241904501 Screw, upper hinge
209 7241909201 Bracket, harness
210 7241903801 Bracket-anti tip
* # 7241900701 Harness-intermediate, UC, LED lighting

Publication No: 5995531851 E24WC75HSS0
01/09 6
SHELVES
24A
U05SWIAAA0
24
24
24

E24WC75HSS0 Publication No: 5995531851
# Functional Parts 7 01/09
* Non-Illustrated Parts
SHELVES
POS. NO PART NO. DESCRIPTION
24 7241902602 Shelf-Wine Rack, lower
24* 7241904701 Screw, 8-18 X 1-1/4
24A 7241905202 Shelf-Wine Rack, lower

Publication No: 5995531851 E24WC75HSS0
01/09 8
SYSTEM
U05CWADAD1
22
50
96
34
59A
59B
58
58
60
24
30
55 32
29
24
23
23
25
25
25
24
3
10
17
3
7
13
13
7
81
81
81
81
3
94
84
15
95
61
85
59
1
26
4
6
44
41
41
45
45
45
45
93
97
92

E24WC75HSS0 Publication No: 5995531851
# Functional Parts 9 01/09
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 7241931201 Condenser
1* 75304406721 Spacer-cond tube, round, 5/8 OD x .81"lg
3 7241890001 Spacer-evap
3* 7241890002 Spacer-evap
3* 7241931901 Washer, nylon
4 7218944002 Drier-filter, R134a System
6 # 7241516901 Cord-service
6* 7241932501 Harness-wiring, evap fans
6* 7241932601 Bushing-service cord
6* 7241932701 Retainer, wire
6* # 7241900201 Harness-evaporator
6* # 7241900501 Harness-wiring, machine compt
6* # 7241900701 Harness-intermediate, UC, LED lighting
7 7241890201 Cover-fan
10 7241890503 Cover-evap coil
10* 7241933201 Seal-coil cover
13 # 7241781901 Motor-evap fan
13* 7215503203 Screw, cr pan hd, 10-16 x 0.500
15 # 7241891801 Evaporator, w/heat exchangr
17 7241889801 Trough-drain
22 7241888101 Base-compressor
22* 7218252201 Screw, #8 truss hd, 10-32CA x 0.500
23 7218513300 Grommet-compr mtg, (4)
24 7241812301 Washer-compr mtg
25 7216056401 Clip-compressor mtg
26 7241889901 Pan-defrost drain
29 # 75303918368 Compressor Kit
30 # 7241707717 Starter-PTC
32 7216649200 Clip, controller
34 7240405201 Grommet, rubber, black, cond tube/wire
41 7240433204 Screw, hex washer head, 8-18 x 5/16
44 75304456288 Clamp-wiring harness, strain relief, galv steel
45 7241906101 Screw-#10 x 3/4 TEK
50 7241511116 Board-main power
50* 7241532401 Channel
55 7218909913 Capacitor, run, 220 VAC, 15 microfarad
58 7240433203 Screw, hex washer head, 8-18 x 3/8
59 7241889701 Shroud, cond fan motor
59* 7240359403 Screw-fan shroud, (2)
59* 7240396801 Clamp, tube/wiring, nylon, black/natural
59A 7241889601 Bracket-cond motor
59B 7241896401 Support, cond shroud
60 7241584301 Motor-condenser fan
61 7241639501 Blade-condenser fan
81 7240555004 Screw-#8-32 X 3/8 BLACK
84 7241931401 Tube-drain, lower
85 7241898101 Tube-hot loop
92 7241512902 Cover-sensor, black
93 7240597203 Sensor
94 7241904001 Housing-filter, air
95 7241754001 Filter-air
96 # 7241900001 Board-LED power
96*# 7241900401 Harness-LED driver
97 7241519401 Clip, sensor
* 7218515401 Clip
* 7241919901 Clamp, cable

Publication No: 5995531851 E24WC75HSS0
01/09 10
WIRING SCHEMATIC
USER
INTERFACE
DISPLAY
(U.I.)
TDO
RDI COM
+5
J1-2 J1-1 J1-3
J1-4
GRN
RED
BLK
NATURAL
J1-7
J1-8
J1-9
J1-10
J1-11
J1-12
RDI TDO
COM
+5
ALARM
J1
J1-1
J1-2
J1-3
J1-4
J1-5
J1-6
NTC-THERMISTOR
COOLER COMPARTMENT
EVAPORATOR FAN
WINE COOLER (3 USED)
BEVERAGE COOLER (1 USED)
GRY
GRY
J2-9
J2-8
YEL/WHT
BRN/WHT
J2-7
J2-6
J2-10 J2-5
J2-4
J2-3
J2-2
J2-1
J2
J3-1 J3-8 J3-7
J3-3
J3-5
J3-6
J3-4 J3-2
CONDENSER FAN
STANDARD COMPRESSOR
M
RED
GRN/YEL
3A
J3
STANDARD COMPRESSOR ONLY
M
L.E.D. POWER
SUPPLY
COMMON
PWM SIGNAL IN (+5V)
LED -
LED +
J2-4
J2-3
J2-2
J2-1
J1-1
J1-2
NEUTRAL
LINE
BLK/WHT
PINK/YEL
BLK
PINK LED 1-4
LINE IN
NEUTRAL
BLK
LT BLUE
NEUTRAL LT BLUE LINE BLK
5
6
7
8
5
6
7
8
5
4
3
2
1
5
4
3 2
1
6
5
4
3
2
1
6
5
4
3
2
1
CATCH
LATCH
CATCH
LATCH
CATCH
LATCH
12 11
10
9
8
7
10
9
8
7
6
1
2
3
4
PWM SIGNAL OUT (+5V)
GRY
GRY
NTC-THERMISTOR
EVAPORATOR COIL
BLK RED
MM
VS COM
B
B
B

E24WC75HSS0 Publication No: 5995531851
# Functional Parts 11 01/09
* Non-Illustrated Parts
WIRING DIAGRAM
6
7
8
9
10
NOT USED
NOT USED
YEL/WHT
GRY
GRY
BRN/WHT
NOT USED
BLK/WHT
NOT USED
PINK/YEL 1
2
3
4
5
5
4
3
2
1
6
7
8
9
10
J2
5 OR 12 VDC
(2x5)
J1
(2x6)
MOTHER BOARD
AC LINE VOLTAGE
J3
(2x4)
GRY
NOT USED
GRY
NATURAL
NOT USED
BLK
RED NOT USED
GRN
NOT USED NOT USED
1
2
RDI
3
TDO
4
5
6
12 11 10 987
1234
BLK
RED NOT USED
LT. BLU
GRN/YEL
5678
GRY
GRY
SPLICE
SEE
COMPRESSOR
WIRING
TDO
RDI
COM
+5
RED
GRN
BLK
WHITE
SERVICE CORD
RIBBED
NON-RIBBED
4
3
2
1
4
3
2
1
1
2
1
2
GRY
GRY
NTC THERMISTOR
COOLER COMPARTMENT
2 1
2 1
NOT USED
BLK
NOT USED
NOT USED
CONDENSER FAN
USER
INTERFACE
DISPLAY
(U.I.)
4321
432 1
NOT USED
NOT USED
1
2
3
4
5
6
1
2
3
4
5
6
LEDs
2 1 2 1 2 1 2 1
2 1 2 1 2 1 2 1
RED
WHTYEL
BLU 1
2
1
2
4
3
1
2
1
2
PINK
BLK
PINK/YEL
BLK/WHT
J2
J1
COMMON
PWM SIGNAL IN (+5V)
LED +
LED -
NEUTRAL
LINE
L.E.D. POWER
SUPPLY
LT BLUE
BLK
BLK
RED
GRN/YEL
LT BLUE
RED
LT BLUE
GRN/YEL
LT BLUE
GRN/YEL
BLK
GRN/YEL
GRN/YEL
GRN/YEL
1 1
GRN/YEL GRN/YEL GRN/YEL
1
2
3
1 2
1
2
1
2
1
2
RED
BLK
BEVERAGE COOLER
EVAPORATOR FAN
BLK
RED
1 2
1 2
1 2
1 2
1 2
1 2
1
2
BLK
BLK
RED
RED
BLK
RED
RED BLK
RED BLK
BLK
RED
WINE COOLER
EVAPORATOR FANS
B
GRY
GRY
1
2
1
2
NTC THERMISTOR
EVAPORATOR COIL
GRY
GRY 1
2
1
2
B
B
B
B
