Electrolux Wine Cooler / Beverage Center User manual

5995505228 (Revision A) October 2008
Wine Cooler & Beverage Center
Service Manual
with Addendum added for Refrigerator Drawers

2
ATTENTION!!!
This service manual is intended for use by persons having electrical and mechnical
training and a level of knowledge of these subjects generally considered acceptable in the
appliance repair trade. Electrolux Home Products cannot be responsible, nor assume any
liability, for injury or damage of any kind arising from the use of this manual.
©2008Electrolux Home Products, Inc.
SAFE SERVICING PRACTICES - ALL APPLIANCES
To avoid personal injury and/or property damage, it is important that Safe Servicing
Practices be observed. The following are some limited examples of safe practices:
1. DO NOT attempt a product repair if you have any doubts as to your ability to
complete it in a safe and satisfactory manner.
2. Before servicing or moving an appliance:
• Remove the power cord from the electrical outlet, trip the circuit breaker to the
OFF position, or remove the fuse.
• Turn off the gas supply.
• Turn off the water supply.
3. Never interfere with the proper operation of any safety device.
4. USE ONLY REPLACEMENT PARTS CATALOGED FOR THIS APPLIANCE.
SUBSTITUTIONS MAY DEFEAT COMPLIANCE WITH SAFETY
STANDARDS SET FOR HOME APPLIANCES.
5. GROUNDING: The standard color coding for safety ground wires is GREEN, or
GREEN with YELLOW STRIPES. Ground leads are not to be used as current
carrying conductors. It is EXTREMELY important that the service technician
reestablish all safety grounds prior to completion of service. Failure to do so will
create a hazard.
6. Prior to returning the product to service, ensure that:
• All electrical connections are correct and secure
• All electrical leads are properly dressed and secured away from sharp edges,
high-temperature components, and moving parts
• All non-insulated electrical terminals, connectors, heaters, etc. are adequately
spaced away from all metal parts and panels
• All safety grounds (both internal and external) are correctly and securely
connected
• All panels are properly and securely reassembled
Safe Servicing Practices
2008

3
Table of Contents
Safe Servicing Practices - All Appliances........................2
A - Installation
Important safety instructions..................................................4
General Precautions................................................................4
Installing the Wine Cooler/Beverage Center ...........................5
Site Preparation ......................................................................6
Reversing the Doors ...............................................................7
B - Maintenance.................................................... 10
Maintaining your Wine Cooler/Beverage Center....................10
Exterior Cleaning for your Stainless Steel Model ..................10
Interior Cleaning - as Required .............................................10
Wine Rack Removal/Installation ...........................................10
Glass Shelf Removal/Installation (Beverage Center Only) .....11
Method 1............................................................................11
Method 2............................................................................11
C - Electrical Components / Operation.......................... 12
Table of contents
Electrical Grounding .............................................................12
Compressor Electrical Components and Circuits..................12
Solid State Relay ................................................................12
To Check/Replace Relay .....................................................13
Overload Protector .............................................................13
To Check/Replace Overload Protector ................................13
Run Capacitor.....................................................................13
To Check/Replace Run Capacitor........................................13
Compressor Start Circuit....................................................14
Compressor Run Circuit.....................................................14
Compressor Operating Characteristics .................................14
Compressor Electrical Check ................................................15
Adjusting the Temperature....................................................15
Diagnostics / Service Mode ..................................................15
Description of Features.........................................................16
Alarms................................................................................16
Sabbath Mode ....................................................................16
System Error Codes ...........................................................17
Disassembly .........................................................................17
User Interface Board (UI) ...................................................17
Replacing the Main PCB .....................................................17
Evaporator Fan & Motor Assembly.....................................17
Wiring Diagrams ................................................................18
D - Refrigeration System ......................................... 20
Definitions ............................................................................20
Recovery ...........................................................................20
Recycling............................................................................20
Reclaim ..............................................................................20
Safety Warnings....................................................................20
Compressor Testing ...........................................................20
Charging Sealed Systems...................................................20
Soldering ..............................................................................21
Basic Components................................................................21
Refrigerant Cycle ..................................................................21
Low/High Side Leak or Undercharge.....................................21
Testing for Refrigerant Leaks ................................................22
Compressor Replacement.....................................................22
To Flush the System ...........................................................23
To Use Dry Nitrogen to Flush the System...........................23
To Use Refrigerant to Flush the System .............................23
Installing a New Compressor................................................23
Condenser Replacement.......................................................26
Filter-Drier Installation ..........................................................26
Evaporator and Suction Line Replacement ...........................26
Evacuating and Recharging ..................................................27
Equipment Needed for Evacuating & Recharging ...............27
Installing Evacuating & Recharging Equipment..................27
Evacuating System .............................................................27
Charging the System ..........................................................28
Preparing the Charging Cylinder.........................................28
Final Leak Test....................................................................28
Evacuating and Recharging Connections............................29
Verify Refrigerant Type in the System...................................30
Dedicated Equipment..........................................................30
R-134a Refrigeration Systems..............................................30
Miscibility of R-134a and Ester Oil........................................30
Water in the Refrigeration System........................................31
Vacuum Pump Maintenance .................................................31
Refrigerant Leaks..................................................................31
Leak Detection ......................................................................33
R-134a Properties.................................................................33
HFC-134a, CFC-12 Pressure Temperature Chart ...................34
Inhalation Toxicity.................................................................35
Cardiac Sensitization.............................................................35
Spills or Leaks ......................................................................35
Skin and Eye Contact ............................................................35
Combustibility of HFC-134a..................................................36
Leak Testing .......................................................................36
Bulk Delivery and Storage ..................................................36
Filling and Charging Operations..........................................36
Refrigerant Recovery Systems ...........................................36
Thermal Decomposition........................................................36
Exploded View Diagrams ......................................... 37
System Diagram ...................................................................37
Cabinet Diagram ...................................................................38
Door Diagram .......................................................................39
Addendum for Refrigerator Drawers ............................ 40
Disassembly-Evaporator Fan Motors ....................................40
Disassembly-User Interface (UI)...........................................40
LED Lighting.........................................................................41
Main PCB..............................................................................41
Sealed System ......................................................................41
Diagnostic / Service Mode ....................................................41
Diagnostic Tests....................................................................41
Wiring Diagrams...................................................................42

4A - Installation
Important Safety Instructions
Safety Precautions
Do not attempt to install or operate your unit
until you have read the safety precautions in this
manual. Safety items throughout this manual are
labeled with a Danger, Warning or Caution based
on the risk type.
Definitions
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards. Obey
all safety messages that follow this symbol to avoid
possible injury or death.
WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
IMPORTANT
Indicates installation, operation or maintenance
information which is important but not hazard-
related.
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
General Precautions
DANGER
RISK OF CHILD ENTRAPMENT. Before you
throw away your old appliance, take off the
doors and leave shelves in place so that
children may not easily climb inside.
WARNING
• Neverattempttorepairorperform
maintenance on the unit until the electricity
has been disconnected.
• Altering,cuttingofpowercord,removalof
power cord, removal of power plug, or direct
wiring can cause serious injury, fire and/or
loss of property and/or life and will void the
warranty.
• Donotliftunitbydoorhandle.
CAUTION
• Usecarewhenmovingtheunit.Someedges
are sharp and may cause personal injury.
Wear gloves when moving or repositioning
the unit.
• Neverinstalltheunitbehindcloseddoors.
Be sure front grille is free of obstruction.
Obstructing free air flow can cause the unit
to malfunction, and may void the warranty.
• Allowunittemperaturetostabilizefor24
hours before use.
CAUTION
• UseonlygenuineElectroluxreplacement
parts. Imitation parts can damage the unit
and may void the warranty.

5
A - Installation
Installing the Wine Cooler / Beverage Center
Your Electrolux wine cooler / beverage center has been designed for either free-standing or built-in
installation. When built-in, your wine cooler does not require additional air space for top, sides or rear. In
either case, the front grille must NOT be obstructed.
NOTE
To ease unit installation and removal, it is recommended that the cabinet rough opening dimensions be
increased by at least ¼inch over the dimensions given for your unit.
Width Height Depth
2313/16 inch 34-35 inches 263/4inch
Unit Dimensions
NOTE
All units require zero clearance when installed flush with a cabinet or wall. Electrolux stainless steel
models require a minimum 2⁷⁄₈ inch handle clearance when installed against a wall or cabinet that
extends beyond the front edge of the unit.
Product Dimensions

6A - Installation
DANGER
ELECTROCUTION HAZARD!
Electrical Grounding Required.This appliance
is equipped with a three prong (grounding)
polarized plug for your protection against
possible shock hazards.
•NEVERremovetheroundgroundingprong
from the plug.
•NEVERuseatwo-pronggroundingadapter.
•NEVERuseanextensioncordtoconnect
power to the unit.
Where a two-prong wall receptacle is
encountered or a longer power cord is
required, contact a qualified electrician to
have it replaced in accordance with applicable
electrical codes.
5Position the unit to allow free air flow through
the front grille.
6Wipe out inside of unit with a damp cloth.
7Be sure to install the Anti-Tip bracket. Follow
the instructions provided with the Anti-Tip
bracket kit.
Site Preparation
1Position the unit on a flat, level surface
capable of supporting the entire weight of the
unit. Remember the unit will be significantly
heavier once it is fully loaded.
2This unit requires a grounded and polarized
115 VAC, 60Hz, 15A circuit (normal
household current).
3Avoid connecting the unit to a Ground
Fault Interruptor (GFI). GFIs are prone to
nuisance tripping which will cause the unit to
shut down. GFIs are generally not used on
circuits which power equipment that must run
unattended for long periods of time.
4The unit must be installed according to your
local codes and ordinances.

7
A - Installation
Reversing the Door
To reverse the door:
1Disconnect power to the wine cooler /
beverage center.
2Remove toe grille by removing two (2) Philips
screws. Remove plastic cap, reverse it and
place it in the other side of the toe grille.
3Disconnect door harness from connector
bracket behind lower front panel. Pull
harness from behind lower front panel so it is
hanging below the door.
4Remove upper right-hand (RH) hinge bracket
by loosening four (4) Torx screws. Be careful
to support the door while loosening and
removing the upper hinge bracket.
5Lift the door off of the lower RH hinge
bracket. Turn the door upside down and
place on a soft, non-abrasive surface.

8A - Installation
6Remove access cover by removing two (2)
Philips screws.
7Shift door harness from one side to the other.
Replace access cover.
8Remove plastic RH door closer by removing
hex head screw. Remove metal RH door
stop by removing hex head screw.
9Install metal left-hand (LH) door stop by
installing hex head screw.
10 Install plastic LH door stop by installing hex
head screw.
11 Remove lower RH door hinge by removing
two (2) hex head screws.
12 Install lower LH door closer in lower LH door
hinge by installing hex head screw.
13 Install lower LH door hinge by installing two
(2) hex head screws.

9
A - Installation
14 Remove button plugs from left side of cabinet
and place in right side of cabinet. Remove
button plug from upper left side of door and
place in upper right side of door. Place door
on lower LH hinge bracket.
15 Install upper LH hinge bracket by installing
four (4) Torx screws.
16 Route door harness behind lower front panel.
Reconnect door harness to bracket.
17 Reattach toe grille by installing two (2) Philips
screws.
18 Reapply power.

10 B - Maintenance
Maintaining Your Wine Cooler/
Beverage Center
Periodic cleaning and proper maintenance will
ensure efficiency, top performance, and long
life. The maintenance intervals listed are based
on normal conditions. You may want to shorten
the intervals if you have pets or other special
considerations.
ExteriorCleaningforYourStainless
Steel Model
•  Yourstainlesssteelmodelmaydiscolorwhen
exposed to chlorine gas, pool chemicals, salt
water, or cleaners with bleach.
•  Keepyourstainlessunitlookingnewby
cleaning with a high quality, all-in-one
stainless steel cleaner/polish on a monthly
basis. Frequent cleaning will remove surface
contamination that could lead to rust. Some
installations will require cleaning on a weekly
basis.
•  DONOTCLEANWITHSTEELWOOLPADS.
•  DONOTUSECLEANERSTHATARE
NOTSPECIFICALLYINTENDEDFOR
STAINLESSSTEEL(thisincludesglass,tile
and counter cleansers).
•  Ifanysurfacediscolorsorrustingappears,
clean it quickly with Bon-Ami or Barkeepers
Friend Cleanser and a non-abrasive cloth.
Always clean in the direction of the grain.
Always finish this process with a high quality,
all-in-one stainless steel cleaner/polish to
prevent further problems.
•  USEOFABRASIVEPADSSUCHAS
SCOTCHBRITEWILLCAUSETHE
GRAININGINTHESTAINLESSTO
BECOMEBLURRED.
•  Rustthatisallowedtolingercanpenetrate
into the surface of the stainless steel and
become impossible to remove.
CAUTION
• Stainlesssteelmodelsexposedto
chlorine gas and moisture such as areas
with spas or swimming pools, may have
some discoloration of the stainless steel.
Discoloration from chlorine gas is normal.
Followexteriorcleaninginstructions.
• NEVERUSECHLORIDETOCLEAN
STAINLESS STEEL.
Interior Cleaning - as Required
1Disconnect power to the wine cooler /
beverage center.
2Remove racks if desired, see “WINE RACK
REMOVAL/INSTALLATION”below.
3Wipe down the interior with a solution of non-
abrasive mild detergent and warm water.
4Rinse with clear water.
5Reconnect power to the unit.
Wine Rack Removal/Installation
1Open door fully.
2Extend wine rack fully.
3Ball bearing slide features plastic release
latches on each side. Push release latches,
then pull wine rack out.
4To reinstall, push ball bearing slides in fully.
Slide rack into ball bearing slide ensuring
each side engages properly.

11
B - Maintenance
3Method 2 - glass shelf removal:
a. Extend shelf fully.
b. Ball bearing slide features plastic release
latches on each side. Push release
latches then pull shelf out.
c. To reinstall, push ball bearing slides in
fully. Slide shelf rack into ball bearing
slide ensuring each side engages
properly.
Glass Shelf Removal/Installation
(Beverage Center Only)
1Open door fully.
2Method 1 - removal of entire shelf
assembly:
a. Lift up on front edge and rear portion of
shelf. Cantilever brackets will disengage
from ladder.
b. To reinstall, slide shelf into cabinet
ensuring the cantilever brackets engage
fully in the proper holes. It may help to
extend the glass portion.

12
Compressor Base
Grommet
Bracket
Shroud
Support
Condenser Fan Motor
PTC Starter
Run Capacitor
Compressor
Grommet
Clip
Condenser
Fan Blade
Hot Lube Tube
Shroud
Condenser
Drier-Filter
Clip
C - Electrical Components / Operation
Electrical Grounding
All refrigerators are equipped with a power supply
cord incorporating a three-prong grounding
plug and a ground wire which is attached to the
refrigerator cabinet for protection against shock
hazard. Each electrical component is either cabinet
mounted or connected through a ground wire
to the cabinet to complete the ground. Certain
components, such as defrost timers, may be
double insulated and do not require a ground wire.
Ensure the electrical wall receptacle is of the three
prong type and is properly grounded in accordance
withtheNationalElectricalCodeand/orlocal
codes.
Compressor Electrical
Components and Circuits
The new series of very high efficiency compres-
sor is equipped with all new electrical components
consisting of a solid state PTC relay with a thermal-
ly operated overload protector, and a run capacitor.
See Figure C1.
Figure C1
Solid State Relay
The solid state relay has no moving parts. It
consists of a PTC resistor mounted in a plastic
case with appropriate terminals. PTC (Positive
Temperature Coefficient) simply denotes a resistor
which increases in resistance as its temperature is
increased. The self-heating PTC resistor used in
the solid state relay has the unique characteristic
of changing from low to very high resistance very
abruptly, thus serving as an on-off switch. (See
Figure C3.)
The solid state relay plugs directly onto the
compressor start and run terminals. (See Figure 2.)
Relay terminals 1, 2, and 5 are connected within
the relay, as are terminals 3 and 6.
A run capacitor is connected to relay terminals
2 and 3, so it is connected in parallel with the
PTC resistor. One side of the 120 VAC power is
connected to relay terminal 1. The other side of line
is connected to the overload protector. (See figure
C3.)
Figure C2
Figure C3
NOTE
There are 2 exploded views (Cabinet and
System) at the end of this section to assist you in
troubleshooting.

13
C - Electrical Components / Operation
To Check/Replace Relay
1. Disconnect electrical supply to refrigerator.
2. Remove bale wire holding relay to
compressor.
3. Remove relay assembly from compressor.
(See Figure C2.)
4.  Usesmall,at-bladedscrewdriverto
disconnect leads to relay assembly.
5.  Useatheadedscrewdrivertogentlypry
capacitor from relay assembly.
6.  Useohmmetertocheckresistancebetween
terminals 5 and 6. Resistance should be 3
to 12 ohms at normal room temperature.
Shorted relay will read 0 ohms. Open relay
will read very high or infinite resistance.
7. If ohm readings are out of range, replace
relay.
8. Reverse this procedure to re-assemble.
Overload Protector
The overload protector is completely thermally
operated. It will open from excessive heat or
current.Unlikeprioroverloads,theinternalbi-
metal is not self-heating, and is not a part of the
electrical circuit. The overload has a small built-in
coil heater that is in series with the compressor
start and run windings (See Figure C3).
NOTE
When replacing leads to the PTC relay, ensure
locking tabs snap into terminal.
To Check/Replace The Overload
Protector
1. Disconnect electrical supply to refrigerator.
2. Remove bale wire holding relay to
compressor.
3. Remove relay assembly from compressor.
4.  Useatheadedscrewdrivertogentlypry
capacitor from relay assembly.
5.  Usesmall,at-bladedscrewdriverto
disconnectleadstorelayassembly.(Note:
On some models you will have to remove
bale wire and cover, to gain access to relay
and overload protector.)
6.  Useohmmetertocheckresistancebetween
tab terminal and female pin terminal.
Overload protector should have less
than 1 ohm of resistance at normal room
temperature.
7. If ohm readings are out of range, install new
Starter/Overload Assembly. See Figure 2.
8. Reverse this procedure to re-assemble.
NOTE
When replacing leads to the PTC relay, ensure
locking tabs snap into terminal.
Run Capacitor
The run capacitor has permanently attached
terminals which are connected to relay terminals 2
and 3.
NOTE
Some models are not equipped with a run
capacitor.
To Check/Replace The Run Capacitor
1. Disconnect electrical supply to refrigerator.
2. Remove bale wire holding relay to
compressor.
2.  Usesmall,at-bladedscrewdriverto
disconnect leads to relay assembly.
3.  Useat-bladedscrewdrivertogently
pry capacitor from relay assembly.
4. Discharge capacitor by shorting across
terminalswith500K(1watt)resistorforone
minute.
5.  Useohmmetersetonthe“Ohms times
1000” scale (if available), to check resistance
across capacitor wire terminals.
 • Theneedleshouldjumptowardszeroohms
and quickly move back to infinity.
 • Iftheneedledoesnotmove,thecapacitoris
open.
 • Iftheneedlereadsaconstantvalueator
near zero ohms, the capacitor is shorted out.
 • Iftheneedlejumpstowardzeroandthen 
moves back to constant high resistance (not
infinity), the capacitor has a high resistance
leak.
6. If ohm readings are out of range, replace
capacitor.
7. Reverse procedures to re-assemble.

14 C - Electrical Components / Operation
Compressor Start Circuit
When the compressor circuit is first energized, the
solid state relay has low resistance (3-12 ohms),
and both the run and start windings are energized
to start the compressor. The run capacitor is being
bypassed by the relay, and it has a minor function
during compressor starting (See Figure C4).
Figure C4
Compressor Run Circuit
When the self-heating solid state relay has reached
sufficient temperature, it will abruptly change from
low resistance (3-12 ohms) to very high resistance
(10-20Kohms)and,ineffect,switchesoffthestart
windings.
The relay no longer shunts the run capacitor.
The run capacitor is now in series with the start
windings. The only purpose of the run capacitor
is to improve compressor operating efficiency,
which it does by correcting the power factor of the
compressor motor (See Figure C5).
Figure C5
Compressor Operating
Characteristics
•  Whenthecompressorelectricalcircuitis
energized, the start winding current causes
the relay to heat and switch off the start
winding circuit.
NOTE
The relay will switch off the start winding circuit
even though the compressor has not started
(as when attempting to re-start after momentary
power interruption).
•  Withanopenrelay,thecompressorwillnot
start since there is little or no current to the
start windings. The overload protector will
open due to high locked rotor run winding
current.
•  Withashortedrelayorcapacitor,the
compressor will start, and the overload
protector will open.
•  Withanopenorweakcapacitor,the
compressor will start and run. The
compressor, however, will be operating at
reduced efficiency of energy usage.
•  Ifthecompressorcasinggetstoohot,it
will shut down on the overload. After the
compressor has cooled down, the overload
will reset and the compressor will restart.
•  Inrearmountedcompressors,theoverload
will cycle the compressor on and off if the
refrigerator is set in so tight that the air can’t
circulate around the condenser. In air cooled
condensers, the overload will cut the unit off
if the condenser becomes blocked or the fan
motor stops running.
•  Theoverloadprotectorisdesignedand
calibrated to open the compressor electrical
circuit with locked rotor run winding current
on.

15
C - Electrical Components / Operation
Compressor Electrical Check
If the compressor will not run, make a voltage
check across the power lead terminals on the PTC
Relay. (See Figure C5.)
The voltmeter should show line voltage if the
thermostat knob is in normal operating position and
not in the OFF position. If this check does not show
a live circuit, the control thermostat and defrost
timer wiring should be checked for loose and/or
broken connections.
A control thermostat check can be made by using
a piece of wire as a temporary bridge across two
thermostat terminals. If the compressor starts and
runs with the bridge, the control thermostat is at
fault and should be replaced.
If the voltage check shows power supply at the
PTC Relay terminals, use a test cord to check the
compressor.
If the compressor does not start and run with the
test cord, check the line voltage to see if there is
more than 10% variation from the rated voltage. If
voltage is correct and the compressor will not start
and run, replace the compressor.
If the compressor starts and runs with the test cord,
replace the PTC Relay.
Adjusting the temperature
Press the (+) or (-) indicator to adjust the
temperature to the desired setting. The temperature
display will begin to blink with the first touch. Adjust
the temperature by touching the key. After (3)
seconds of inactivity, the display will beep to accept
the new temperature.
Diagnostics / Service Mode
To enter the service mode, press and hold the
vacation mode key, while pressing the on/off key 3
times in 5 seconds. Temperature digit display will
show (1). Each press of the left hand temperature
UP(+)orlefthandtemperatureDOWN(-)keywill
step through the Service Tests, (1) through (6).
Press the “Mute Sounds” button to access the test
selected. Once the test is accessed the display
will show “°” and each press of the temperature
UP(+)keywillcycleforwardthroughthetest
features (A-E) and display the Test information in
theDisplay.EachpressofthetemperatureDOWN
(-) key will cycle back through the test features.
Pressing the “Mute Sounds” key will exit from the
test and display the current service test number.
TEST
#1 Firmware
Version
Displays firmware version
of main PCB and user
interface board.
#2 Evaporator
Fan
Toggles the evaporator
fan(s) on and off.
#3 Primary
Sensor
WillDisplay:“P1”Normal,
“P2” Open and “P3”
Shorted.
#4 Evaporator
Sensor
WillDisplay:“E1”Normal,
“E2” Open and “E3”
Shorted.
#5 Compressor Toggles the compressor on
and off.
#6 LED
Display Test
Illuminates display LED’s.
#7 ExitService
Mode
Hold left temperature (+)
key for 5 seconds to exit
service mode.

16
Alarms
door ajar If the door has been left open for five (5) min-
utes, an audible alarm will sound and the door
ajar indicator will illuminate on the right side of
the display. The mute sounds indicator will
blink. Pressing the mute sounds key will
acknowledge the alarm and disable the audible
portion. The door ajar indicator will continue
to blink until the door is closed.
high temp In the event of a high temperature condition,
an audible alarm will sound, the temperature
display will blink and display “HI” and the
high temp indicator on the right side of
the display will blink. The mute sounds
indicator will blink. Pressing the mute
sounds key will acknowledge the alarm and
disable the audible portion. All other modes
are turned off until the alarm is acknowl-
edged. The high temperature indicator
and “HI” will stay illuminated until a normal
safe range operating temperature has been
reached, at which time the temperature
display will show the actual temperature.
power fail In the event of a power failure or initial
power-up, an audible alarm will sound and the
power fail indicator on the right side of the
display will blink. The mute sounds indica-
tor will blink. Pressing the mute sounds
key will acknowledge the alarm and disable
the audible portion. All other functions are
disabled until the alarm is acknowledged,
at which point the power fail indicator is
turned off and the unit will resume normal
operation. The high temp alarm (beverage
center only) may also be illuminated until a
safe temperature has been reached.
Description of Features
vacation mode Conserves energy by disabling interior
lights and keypad inputs.
mute sounds Tones emitted by each keypress can be
turned off based on user preference. The
sounds are muted when the red indicator is
lit. The mute sounds key also is used to
acknowledge alarm conditions, denoted by
a flashing red indicator. Press and hold the
mute sounds key for three (3) seconds
to enable control lock, which prevents
undesired changes to the unit settings.
Temperature display will show “LOC”.
temperature mode Simultaneously pressing the (+) and (–)
keys causes the temperature display to
toggle from Fahrenheit to Celsius and back
again.
display light Manually activates the lights, regardless of
whether the door is closed. Each succes-
sive keypress will advance the interior lights
from “Off” to “Low Intensity” to “Maximum
Intensity” then to “Off” again. Interior
lighting is automatically disabled after 120
minutes, at which point the lights may be
manually activated again if desired.
on off Press and hold for three (3) seconds. This
allows the user to turn off the cooling sys-
tem. The temperature display will display
“OFF”. THIS DOES NOT REMOVE POWER
FROM THE UNIT.
(Beverage
Center Only)
Sabbath Mode
Sabbath mode disables portions of the unit and its controls in accordance with the weekly Sabbath and
religious holidays observed within the Orthodox Jewish community.
Sabbath mode is enabled and disabled by pressing and holding the vacation mode key for five
(5) seconds. Temperature display shows “Sb” while in Sabbath mode.
The customer may open or close the door at any time without concern of directly turning on or
off any lights, digital readouts, solenoids, fans, valves, compressor, icons, tones or alarms. After
power failure, the unit will immediately return to Sabbath mode.
While in Sabbath mode, alarm indicators may illuminate, but will not be accompanied by audible alarms. The
alarm indicators will continue to blink until the Sabbath mode is exited and the alarm condition is remedied.
For further assistance, guidelines for proper usage and a complete list of models with the Sabbath feature,
pleasevisitthewebathttp:\\www.star-k.org.
C - Electrical Components / Operation

17
C - Electrical Components / Operation
System Error Codes
Primary Sensor Open Display will flash “P2”
@ 1 hz.
Primary Sensor
Shorted
Display will flash “P3”
@ 1 hz.
Evaporator Mounted
Sensor Open
Display will flash “E2”
@ 1 hz.
Evaporator Mounted
Sensor Shorted
Display will flash “E3”
@ 1 hz.
Communication Error Display will flash “CL”
@ 1 hz.
Incorrect User
Interface
Display will flash “UI”
@ 1 hz.
Disassembly
User Interface board (UI)
ToremovetheUserInterfaceboard,itwillbe
necessary to remove the door from it’s hinge.
1. Disconnect power to unit.
2.  DisconnectquickdisconnectortodoorUI
located behind toe plate.
3. Pull out unit in order to gain access to the top
hinge.
4. Loosen screws to hinge and lift up so door
can be removed.
5. Remove screws located on underside of door
that hold front panel.
6. SlideofffrontpaneltogainaccesstoUI.
Replacing the main PCB
The main PCB is located under the unit behind the
toe kick plate. It will be necessary to pull out the
unit (if built in) and lean back to gain access.
The power supply for the interrior lighting led’s is
located in front of the main PCB.
21C
21C
15
Evaporator Fan & Motor
Assembly
The Beverage center uses one 12 vdc air
circulation motor.
The Wine Cooler uses three 12 vdc air circulation
motors.
To Remove Evaporator Fan Motor
1. Disconnect wine cooler or Beverage Center
from electrical supply.
2. Remove shelving from interior.
3. Remove the four screws that hold on the
evaporator cover.
4. Remove Evaporator cover, dissassemble fan
motor, and replace.
Beverage Center
Evaporator fan (1)
Wine Cooler
Evaporator Fans (3)
Main Po wer Board
LED Po wer
Board

18 C - Electrical Components / Operation

19
C - Electrical Components / Operation

20 D - Refrigeration System
NOTICE
Instructions given here are furnished as a guide.
Persons attempting to use these instructions to
make repairs to the sealed refrigeration system
should have a working knowledge of refrigeration
and previous training on sealed system repair,
and an EPA certification for servicing refrigeration
systems.
IMPORTANT NOTICE
EffectiveJuly1,1992,theUnitedStatesclean
air act governs the disposal of refrigerants such
as R-134a. Therefore, when discharging or
purging the sealed system use an epa approved
refrigerant recovery system as outlined in the final
rule on the protection of stratospheric ozone and
refrigerant recycling, which was published in the
Federal Register May 14, 1993.
NOTE
Frigidaire does not permit the use of recovered
refrigerant in the servicing of our products for
in-warranty and out-of-warranty repairs or for
products covered by service contracts. Therefore,
only new refrigerant or refrigerant that has
been reclaimed back to new specifications by a
refrigerant manufacturer is to be used.
Definitions
Recovery:
To remove refrigerant in any condition from a
system and store it in an external container without
necessarily testing or processing it in any way.
Recycling:
To clean refrigerant for reuse by oil separation and
single or multiple passes through devices, such
as replaceable core filter-driers, which reduce
moisture, acidity and particulate matter. This term
usually applies to procedures implemented at the
field job site or at a local service shop.
Reclaim:
To reprocess refrigerant to new product
specifications by means which may include
distillation. Will require chemical analysis of the
refrigerant to determine that appropriate product
specifications are met. This term usually implies the
use of processes or procedures available only at a
reprocessing or manufacturing facility.
Safety Warnings
Compressor Testing
Whenever testing a compressor, extreme caution
should be used to prevent damaging the terminals.
A compressor with a damaged terminal or a
grounded winding can expel a terminal from
its insulated housing when the compressor is
energized. If this happens, a mixture of refrigerant
and oil will be released that could be ignited by
an external heat source (open flame, heater,
etc.). Also, if there is air in the system when this
happens, a spark at the compressor shell could
ignite the refrigerant and oil mixture.
Charging Sealed Systems
Overcharging a refrigeration system with refrigerant
can be dangerous. If the overcharge is sufficient
to immerse the major parts of the motor and
compressor in liquid refrigerant, a situation has
been created which, when followed by a sequence
of circumstances can lead to the compressor shell
seam separating.
A hydraulic block occurs, preventing the
compressor from starting. This condition is known
as locked rotor. Electric current continues to flow
through the compressor motor windings which
become, in effect, electric resistance heaters.
The heat produced begins to vaporize the excess
refrigerant liquid causing a rapid increase in
system pressure. If the compressor protective
devices fail, the pressure within the system may
rise to extremes far in excess of the design limits.
Undertheseconditions,theweldseamaround
the compressor shell can separate with explosive
force, spewing oil and refrigerant vapor which could
ignite.
To eliminate this exceedingly rare but potential
hazard, never add refrigerant to a sealed system. If
refrigerant is required, evacuate the existing charge
and recharge with the correct measured amount of
the refrigerant specified for the system.
