Electrovision A195MA User manual

A195MA
Double Arm Canlever
TV Mounng Bracket with Tilt & Swivel
Screen Size: 32” - 65”
Vesa Size : 600 x 400mm
User Manual
Thank you for purchasing an Electrovision bracket, please read these instructions carefully
and leave with the user of the product for future reference.

IMPORTANT
Installer and Users please note:
These instructions should be read carefully and left with the user of the product for future
reference.
BEFORE USE
Inspect the product for any signs of damage. If the product is damaged, DO NOT use it,
and contact your supplier immediately
PRODUCT SAFETY
• Prior to the installation of this product, the installation instructions should be read
and completely understood. The installation instructions must be read to prevent
personal injury and property damage. Keep these installation instructions in an easily
accessible location for future reference.
• CAUTION: The maximum load capacity is 50Kg. Use with products exceeding the
maximum load capacity may cause serious injury. See appliance instructions.
• Do not install on a structure that is prone to vibration, movement or chance of impact.
Failure to do so could result in damage to the display and/or damage to the stand.
• Do not place near heater, replace, air conditioning, in direct sunlight, or any other
heat producing source. Failure to do so may result in damage to the display and could
increase the risk of re.
• It is recommended that two people perform the installation. Injury and/or damage can
result from dropping or mishandling the display.
• The enclosed instructions are an aid to installation and cannot cover all eventualities,
if you have any concerns regarding the mounting of the arm or brackets you should
consult an expert.
• CAUTION: Before installation the mounting area should be checked that it is suitable
for the weight of the bracket and screen and is free from pipes, electric cables or any
other obstructions.

No Part Qty No Part Qty
AM4 x 20mm 4 FM8 Plug 4
B M6 x 20mm 4 G1 M8 Washer 4
CM8 x 25mm 4 G2 Spirit Level 1
DWasher 4 HSpacer 4
EM8 Screw 4
TV MOUNTING ACCESSORIES
TOOLS REQUIRED
STUD WALL FITTING INSTRUCTIONS
• Select a suitable position to mount the arm.
• It is recommended that the arm is mounted using the supplied bolts to the wooden
supports behind the plasterboard. If you wish to mount directly to the plasterboard a
survey of the plasterboard must be taken by suitably qualied installers and the correct
mounting hardware must be purchased. The bolts and plugs provided are not suitable
for this purpose.
• Use a stud detector to locate the centre points of a suitable wooden support.
• Mark the holes required.
• Drill pilot holes 5mm diameter by 50mm deep in the supports.
• Attach the arm to the wall using the 4 x M8 bolts (E) and M8 washers (G1), the bolts
should be tightened using a 13mm socket wrench or spanner.

BRICK/CONCRETE WALL FITTING INSTRUCTIONS
• Select a suitable position to mount the arm.
• Use a stud detector to check for hidden cables, pipes or steelwork.
• Place the arm against the wall and mark the holes required.
• Drill the holes with a 10mm diameter drill bit to a depth of 50mm.
• Insert the wall plugs (F).
• Attach the arm to the wall using the 4 x M8 bolts (E) and M8 washers (G1), the bolts
should be tightened using a 13mm socket wrench or spanner.
ATTACHING BRACKETS TO TV
The A195M TV bracket comes with a range of TV mounting accessories designed to t
the majority of televisions. Depending upon the required parts it may be necessary to use
screws A, B or C with the washers (D) and spacers (H).

ATTACHING BRACKETS TO CURVED TV
The A195M TV bracket comes with a range of TV mounting accessories designed to t
the majority of televisions. Depending upon the required parts it may be necessary to use
screws A, B or C with the washers (D) and spacers (H).
ATTACHING TV TO ARM
Due to the risk of damage or injury it is recommended that a minimum of two people should
be used to attach the television to the arm. The television should be tilted slightly forwards
and the groove at the top arm should be aligned top crossbar on the support plate. The
television should be lowered till the arms rest against the bottom crossbar. Extend the
threaded bolts to secure the television in place. The telvision can be tilted forwards and
backwards using the adjustments on the arm (between -12º and +10º). Once the required
position and angle are achieved all screws, nuts and bolts should be fully tightened.

SERVICE WARRANTY
Electrovision Ltd. guarantees the product free from defects in materials and workmanship
for a period of twelve months.
Should this bracket be operated under conditions other than those recommended, or any
attempts are made to service or modify the bracket, then the warranty will be rendered
void. The product you buy may sometimes differ slightly from illustrations. This warranty is
in addition to, and does not affect, your statutory rights.
Our guarantee is administered by our retailers.
If your product arrives damaged, you must contact the retailer from whom you bought it.
The retailer’s contact details will be on the invoice that arrived with the product, or on the
e-mail you received when you placed the order. Do not contact Electrovision, only your
retailer can arrange a replacement.
If the product needs to be repaired or replaced, you must contact the retailer from whom
you bought it. The retailer’s contact details will be on the invoice that arrived with the
product, or on the e-mail you received when you placed the order.
If you have just received your product and require technical help in using it, please call our
Help Desk on [phone]
Electrovision Ltd.,
Lancots Lane, Sutton, St. Helens, Merseyside. WA9 3EX
www.electrovision.co.uk
