StarTech.com FPWARTS1 User manual

Manual Revision: 02/28/2023
User Manual
For the latest information and specications visit
www.startech.com/FPWARTS1
TV Wall Mount - Articulating Arm - For TVs up
to 80”
SKU#: FPWARTS1
Actual product may vary from photos

i
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Compliance Statements
Use of Trademarks, Registered Trademarks, and other
Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and
other protected names and/or symbols of third-party companies not related in
any way to StarTech.com. Where they occur these references are for illustrative
purposes only and do not represent an endorsement of a product or service
by StarTech.com, or an endorsement of the product(s) to which this manual
applies by the third-party company in question. Regardless of any direct
acknowledgement elsewhere in the body of this document, StarTech.com
hereby acknowledges that all trademarks, registered trademarks, service marks,
and other protected names and/or symbols contained in this manual and
related documents are the property of their respective holders.
PHILLIPS® is a registered trademark of Phillips Screw Company in the United
States or other countries.

ii
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Safety Statements
Safety Measures
• Product installation and/or mounting should be completed by a certied
professional as per the local safety and building code guidelines.
• Cables (including power and charging cables) should be placed and routed
to avoid creating electric, tripping or safety hazards.
Mesures de sécurité
• L’installation et/ou le montage du produit doit être réalisé par un
professionnel certié et dans le respect des normes locales et du code de
construction local.
• Les câbles (y compris les câbles d’alimentation et de chargement) doivent
être placés et acheminés de façon à éviter tout risque électrique, de chute ou
de sécurité
安全対策
• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に
従い、有資格の専門業者が行うようにしてください。
• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し
を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう
にしてください。
Misure di sicurezza
• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un
tecnico professionale certicato che conosca le linee guida locali sulle norme
edilizie e sulla sicurezza.
• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati
e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o
pericoli per la sicurezza.
Säkerhetsåtgärder
• Installation och/eller montering får endast göras av behöriga yrkespersoner
och enligt gällande lokala förordningar för säkerhet och byggnormer.
• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så
sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

iii
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Warning Statements
• Make sure to assemble this product according to the instructions. Failure to
do so might result in personal injury or property damage.
• Make sure that the weight of the TV doesn’t exceed the weight capacity
of this product. If you exceed the weight capacity, you might experience
personal injury or damage to the equipment. This product can support the
following weight: Up to 110 lb. (50 kg).
• Never use this product if parts are missing or damaged.
• The wall mount is designed to be installed on a wood stud, solid concrete, or
cinder block wall. The wall structure should also be capable of supporting at
least four times the weight of the mounted equipment.
• The mounting hardware included with this product may not be adequate for
installation on certain wall structures. Failure to comply with these warnings
may result in personal injury or damage to the equipment.
• The mounting hardware included with this product might not be adequate
for some wall structures. If you lack the necessary expertise to attach this
product to the wall structure that you’re using, contact a construction
professional to install the wall mount or to provide specic mounting
instructions for your wall structure.
Mensagens de Aviso
• Certique-se de que monta este produto de acordo com as instruções.
O incumprimento pode resultar em ferimentos pessoais ou danos de
propriedade.
• Certique-se de que o peso do monitor não excede a capacidade de peso
deste produto. Se exceder a capacidade de peso, pode sofrer ferimentos
pessoais ou danos no equipamento. Este produto pode suportar o seguinte
peso: 50 kg.
• Nunca opere este produto se faltarem peças ou estas estiverem danicadas.
• As estruturas de parede variam e é importante certicar-se de que o tipo de
estrutura de parede e hardware de montagem que está a usar irá suportar
devidamente o equipamento montado. O incumprimento pode resultar
em ferimentos pessoais e/ou danos no equipamento. A estrutura de parede
deve ser capaz de suportar pelo menos quatro vezes o peso do equipamento
montado.
• O hardware de montagem incluído com este produto pode não ser
adequado para algumas estruturas de parede. Se não tiver o conhecimento
necessário para xar este produto à estrutura de parede que está a usar,
contacte um prossional de construção para fazer a instalação em parede ou

iv
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
para fornecer instruções de montagem especícas para a sua estrutura de
parede.
Varningsmeddelanden
• Se till att du monterar produkten i enlighet med instruktionerna. Om du inte
gör det kan skada på person eller egendom uppstå.
• Se till att skärmens vikt inte överstiger produktens viktkapacitet. Om
viktkapaciteten överstigs kan skada på person eller utrustning uppstå. Denna
produkt har stöd för följande vikter: 50 kg.
• Använd aldrig produkten om delar saknas eller är skadade.
• Eftersom väggstrukturer varierar är det viktigt att kontrollera att
väggstrukturen och monteringsutrustningen som du använder klarar av
den monterade utrustningen. Om du inte gör det kan skada på person och/
eller utrustning uppstå. Väggstrukturen ska kunna klara av minst fyra gånger
vikten av den monterade utrustningen.
• Monteringsutrustningen som medföljer produkten kanske inte är lämplig för
vissa väggstrukturer. Om du saknar nödvändiga kunskaper för att fästa denna
produkt på väggstrukturen som du använder, kontakta en professionell
konstruktör för att installera väggmonteringen eller för att ge specika
monteringsinstruktioner för din väggstruktur.
Advertencias de Uso
• Asegúrese de ensamblar este producto según las instrucciones. De lo
contrario, pueden producirse lesiones personales o daños en la propiedad.
• Asegúrese de que el peso del monitor no exceda la capacidad de carga de
este producto. Si se excede dicha capacidad se podrían producirse lesiones
personales o daños al equipo. Este producto tiene la siguiente capacidad de
carga: 50 kilogramos.
• Nunca opere o ponga en funcionamiento este producto si faltan piezas o hay
daños en las mismas.
• Las estructuras de las paredes pueden variar y, por tanto, es importante
determinar con certeza que el tipo de estructura de la pared y el hardware
de montaje que se va a utilizar puedan soportar debidamente el equipo. De
lo contrario, se pueden producir lesiones personales o daños en el mismo. La
estructura de la pared debe ser capaz de soportar al menos cuatro veces el
peso del componente instalado.
• El hardware de montaje incluido con este producto puede no ser adecuado
para algunas estructuras de pared. Si no tiene la experiencia suciente para
jar este producto a la estructura de la pared correspondiente, póngase en

v
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
contacto con un profesional de la construcción para instalar el soporte de
pared o para que le proporcione las instrucciones especícas de montaje
para su estructura de pared.
Avertissements
• Assemblez ce produit conformément aux instructions. Si vous ne respectez
pas ces instructions, vous risquez de vous blesser ou d’endommager
l’équipement.
• Vériez que le poids du moniteur ne dépasse pas la capacité pondérale du
produit. Si vous dépassez la capacité pondérale, vous risquez des blessures
corporelles ou des dommages matériels. Ce produit peut supporter de 50 kg.
• N’utilisez pas ce produit si des pièces sont endommagées ou manquantes.
• Les structures des murs varient. Vous devez impérativement vérier que
le type de mur et le matériel de xation que vous utilisez permettent de
soutenir correctement l’équipement. Dans le cas contraire, vous risquez des
blessures corporelles ou des dommages matériels. La structure du mur doit
pouvoir supporter au moins quatre fois le poids de l’équipement monté.
• Le matériel de xation inclus avec ce produit n’est pas forcément approprié
pour toutes les structures de murs. Si vous ne disposez pas des compétences
nécessaires pour installer ce produit au mur, contactez un professionnel
an qu’il installe le support mural ou qu’il vous fournisse les instructions de
montage spéciques à votre structure de mur.
Waarschuwingen
• Zorg dat dit product volgens de instructies in elkaar wordt gezet. Indien dit
niet goed gebeurt kan lichamelijk letsel of materiële schade ontstaan.
• Zorg dat het gewicht van het scherm de maximale capaciteit van dit product
niet overschrijdt. Als u de gewichtscapaciteit overschrijdt, kan persoonlijk
letsel of schade aan de apparatuur ontstaan. Dit product ondersteunt het
volgende gewicht: 50 kg.
• Gebruik dit product nooit als er onderdelen ontbreken of beschadigd zijn.
• Omdat wanden verschillen, is het belangrijk dat u ervoor zorgt dat het type
wandstructuur en de montagemiddelen die u gebruikt de gemonteerde
apparatuur goed ondersteunen. Indien u dit niet doet kan lichamelijk
letsel en/of schade aan de apparatuur ontstaan. De wandstructuur moet
voldoende zijn om ten minste vier keer het gewicht van de gemonteerde
apparatuur te ondersteunen.
• De bij dit product geleverde montagemiddelen kunnen niet geschikt zijn
voor sommige wandstructuren. Als u onvoldoende kennis hebt om dit

vi
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
product aan de door u gebruikte wandstructuur te bevestigen, neem dan
contact op met een bouwkundige om de steun aan de muur te installeren of
specieke montage-instructies voor uw wandstructuur te geven.
Warnhinweise
• Montieren Sie dieses Produkt gemäß den Anweisungen. Anderenfalls kann
dies zu Verletzungen von Personen oder Schäden an Eigentum führen.
• Das Gewicht des TVs darf die zulässige Traglast des Produkts nicht
übersteigen. Wenn die Traglast überschritten wird, kann dies zu Verletzungen
von Personen oder Schäden an Geräten führen. Dieses Produkt ist für
folgendes Gewicht geeignet: 50 kg.
• Das Produkt darf nicht bedient werden, wenn Teile fehlen oder beschädigt
sind.
• Wandstrukturen unterscheiden sich, und es muss sichergestellt werden,
dass die Wand und das verwendete Montagematerial das montierte Gerät
halten kann. Anderenfalls kann dies zu Verletzungen von Personen und/oder
Schäden an Geräten führen. Die Wand muss mindestens das Vierfache des
Gewichts des montierten Geräts halten können.
• Das mitgelieferte Montagematerial ist möglicherweise nicht für jede Wand
geeignet. Wenn Ihnen die nötigen Fachkenntnisse zum Anbringen dieses
Produkts an einer Wand fehlen, lassen Sie einen Fachmann den Wandhalter
anbringen, oder lassen Sie sich von einem Fachmann Montageanweisungen
für Ihre Wand erteilen.
注意
• 必ず取扱説明書に従って本製品の組み立てを行って下さい。取り扱いを誤
った場合に、傷害を負う恐れや物的損害が発生する恐れがあります。
• 取り付けるモニターの重量が、本製品で定められた最大積載重量を超えな
いようにして下さい。最大積載重量をオーバーした場合、傷害を負う恐れや
モニターや本製品に損害が発生する恐れがあります。本製品は、最大50kg
までのモニター重量に対応しています。
• 本製品で使用している部品の一部が紛失していたり損傷している状態で使
用するのは絶対に止めて下さい。
• 壁の構造はお客様の環境ごとに異なります。ご使用になる壁の構造タイプ
と取付け金具が、取り付けモニターを確実に支持することを確認して下さ
い。確認を怠った場合、傷害を負う恐れや物的損害が発生する恐れがあり
ます。壁の構造が、取り付けるモニター重量の最低４倍まで支持できるだけ
の強度を持っていなければなりません。
• 本製品に同梱されている取付け金具は、ご使用になる壁の構造に対して十

vii
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
分ではない場合があります。本製品を壁面に取り付ける時、十分な専門知
識が不足していると判断された場合、専門業者に連絡を取って、本製品の取
り付けを行ってもらうか、お客様の壁の構造に適した取り付け方法を教えて
もらってから取り付けを行って下さい。
Dichiarazioni di avvertenza
• Assemblare il prodotto rispettando le istruzioni. Il mancato rispetto delle
istruzioni potrebbe causare danni a persone o proprietà.
• Vericare che il peso del monitor non superi la capacità di supporto del
prodotto. In caso di superamento della capacità di supporto potrebbero
vericarsi danni a persone o apparecchiature. Il prodotto è in grado di
supportare i seguenti pesi: 50 kg.
• Non utilizzare il prodotto in presenza di parti mancanti o danneggiate.
• Le caratteristiche dei muri sono variabili ed è importante vericare che
la struttura muraria e l’hardware di montaggio in uso siano in grado di
supportare adeguatamente le apparecchiature montate. Il mancato rispetto
delle istruzioni potrebbe causare danni a persone o proprietà. La struttura
muraria deve essere in grado di supportare un peso almeno quattro volte
superiore a quello dell’apparecchiatura montata.
• L’hardware di montaggio incluso con il prodotto potrebbe non essere
adeguato ad alcune strutture murarie. Se l’utente non dispone delle
competenze necessarie per agganciare il prodotto alla struttura muraria
in uso, dovrà contattare un professionista edile per installare il supporto a
parete o ottenere istruzioni di montaggio per la struttura muraria in uso.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Table of Contents
Compliance Statements........................................................................i
Safety Statements..................................................................................ii
Warning Statements ..............................................................................iii
Product Diagram ....................................................................................1
Front View.................................................................................................................................................... 1
Side View...................................................................................................................................................... 2
Product Dimensions ..............................................................................3
Product Information ..............................................................................4
Package Contents ..................................................................................................................................... 4
Requirements ............................................................................................................................................. 5
Technical Specications ........................................................................5
Installation ..............................................................................................6
Fasten the Wall Mounting Bracket to a Wall .................................................................................... 6
Insert and Secure the Mounting Plates............................................................................................. 7
Attach the Decorative Covers............................................................................................................... 9
Attach the TV Mounting Brackets ....................................................................................................... 10
Attach the TV to the TV Wall Mount Assembly............................................................................... 12
Operation ................................................................................................14
Adjust the TV............................................................................................................................................... 14
Cable Management.................................................................................................................................. 16
Warranty Information............................................................................17

1
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Diagram
Front View
TV Wall Mount
Assembly
TV Mounting
Brackets

2
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Side View
Decorative
Covers
Tilt Quick-
Release Lever
Wall Mounting
Bracket

3
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Dimensions

4
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Information
Package Contents
• Wall Mounting Bracket x 1
• Decorative Covers x 2
• Mounting Plates x 2
• M6 x 15 mm Screws x 4
• Round Washers, Small x 4
• Wrench x 1
• Hex Key x 1
• M5 x 14 mm Screws x 4
• M6 x 14 mm Screws x 4
• M6 x 30 mm Screws x 4
• M8 x 30 mm Screws x 4
• M8 x 50 mm Screws x 4
• Rectangular Washers x 4
• Small Spacers x 8
• Large Spacers x 8
• Round Washers, Large x 6
• User Manual x 1
Mounting Hardware
• TV Wall Mount Assembly x 1
• TV Mounting Brackets x 2
• Mounting Screws x 6
• Wall Anchors x 6

Requirements
• VESA Mount Compatible Display
• Phillips Head Screwdriver
• Spirit/Bubble Level
• Mounting Surface
Technical Specications
Type of Measurement Measurement
Weight Capacity
Up to 110 lb. (50 kg)
Tilt
+2 to -15
Screen Size
Up to 80’’
(2032 mm)
Swivel
+90 to -90
VESA Mounting Hole Pattern 200x100, 200x200, 200x300
200x400, 300x200, 300x300
400x200, 400x300, 400x400
600x200, 600x300, 600x400
5
kg

6
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Installation
Fasten the Wall Mounting Bracket to a Wall
Warning! The TV Wall Mount is designed to be installed
on a wood stud, solid concrete, or cinder block wall. The
wall structure should be capable of supporting at least four
times the weight of the mounted equipment. The Mounting
Hardware included with this product may not be adequate
for installation on certain wall structures. Contact a construc-
tion professional to install the TV Wall Mount. Failure to do
so may result in personal injury and/or equipment damage.
FPWARTS1 can be mounted using the Mounting Hardware
included. Verify that the Wall Mount Bracket is level with a
Spirit/Bubble Level before fastening it to your Mounting
Surface.
Attach the TV Wall Mount Assembly
1. Lift the TV Wall Mount assembly up and towards the Wall
Mounting Bracket.
2. Hook the top of the TV Wall Mount Assembly onto the top
edge of the Wall Mounting Bracket.
3. Lower the bottom portion of the TV Wall Mount Assembly
until it makes contact with the Wall Mounting Bracket.
(Figure 1)

7
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Insert and Secure the Mounting Plates
1. Determine the nal location of the TV Wall Mounting
Assembly along the Wall Mounting Bracket and slide the
TV Wall Mounting Assembly into that location. (Figure 2)
Note: Ensure the holes in the TV Wall Mounting Assembly
are aligned with the holes in the Wall Mounting Bracket.
2. Insert one Mounting Plate behind the top of the TV Wall
Mount Assembly, where the TV Wall Mount Assembly
makes contact with the Wall Mounting Bracket. Ensure
the Mounting Plate is oriented so that the two bumps are
pointing upwards. Align the holes in the Mounting Plate
with the holes in the TV Wall Mount Assembly and the Wall
Mounting Bracket. (Figure 3)
Figure 1
TV Wall Mount
Assembly
Wall Mounting
Bracket

8
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Figure 3 Mounting Plate
Mounting Plate
Hex Key
Figure 2
Wall Mounting
Bracket

9
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
3. While holding the Mounting Plate in place, insert two M6 x
15 mm Hex Screws through two Small Round Washers and
into the holes in the top of the TV Wall Mount Assembly,
Wall Mounting Bracket, and Mounting Plate.
4. Partially tighten the two M6 x 15 mm Hex Screws with the
Hex Key.
5. Insert one Mounting Plate behind the bottom of the
TV Wall Mount Assembly, where the TV Wall Mount
Assembly makes contact with the Wall Mounting Bracket.
Ensure the Mounting Plate is oriented so that the two
bumps are pointing downwards. Align the holes in the
Mounting Plate with those found in the TV Wall Mount
Assembly and the Wall Mounting Bracket.
6. While holding the Mounting Plate in place, insert two M6
x 15 mm Hex Screws through two Round Washers, Small
and into the holes in the bottom of the TV Wall Mount
Assembly, Wall Mounting Bracket, and Mounting Plate.
7. Tighten all four M6 x 15 mm Hex Screws with the Hex Key.
Attach the Decorative Covers
• Attach the upper and lower Decorative Covers by sliding
each Decorative Cover onto the TV Wall Mount Assembly,
until you hear or feel the Tabs of each Decorative Cover
snap into place. (Figure 4)

10
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Attach the TV Mounting Brackets
1. Place your TV on a padded surface, screen side down, so that
you can access the back of the TV.
2. (Optional) Identify and remove the pre-installed VESA
Hardware from the back of your TV.
Note: Not all TVs will have placeholder VESA Hardware.
Ensure you are only removing the four Screws for the VESA
Mount. Do not remove any of the screws from your TV’s
structural assembly.
3. (Optional) Place the necessary number of Small and/or
Large Spacers over each VESA Mounting Hole. (Figure 5)
Decorative
Cover
Figure 4

11
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
4. Place the TV Mounting Brackets, parallel to one another,
on the back of the TV over the VESA Mounting Holes. The
arrows on the TV Mounting Brackets should be pointing
towards the bottom of the TV. (Figure 3)
5. Place the four Rectangular Washers onto the TV Mounting
Brackets. Align the holes in the Rectangular Washers with
the VESA Mounting Holes.
Note: Each Rectangular Washer features two holes. Select
the hole that ts the M-Type Screws.
6. Thread the appropriately sized M-Type Screws (e.g. M5 x
14 mm Screws) through the Rectangular Washers, TV
Mounting Brackets, (Optional) Spacers,and into your TV.
(Figure 6)
Figure 5
Mounting Brackets
M-Type
Screw
Rectangular
