Electrovision A195DB User manual

FOR WHITE LOGO
A195DB
FIXED TV MOUNTING BRACKET
Vesa Size : 400 x 400mm
User Manual
Noce d’Ulisaon
Thank you for purchasing an Electrovision bracket, please read these instructions carefully
and leave with the user of the product for future reference.

IMPORTANT
Installer and Users please note:
These instructions should be read carefully and left with the user of the product for future
reference.
BEFORE USE
Inspect the product for any signs of damage. If the product is damaged, DO NOT use it,
and contact your supplier immediately
PRODUCT SAFETY
• Prior to the installation of this product, the installation instructions should be read
and completely understood. The installation instructions must be read to prevent
personal injury and property damage. Keep these installation instructions in an easily
accessible location for future reference.
• CAUTION: The maximum load capacity is 45Kg. Use with products exceeding the
maximum load capacity may cause serious injury. See appliance instructions.
• Do not install on a structure that is prone to vibration, movement or chance of impact.
Failure to do so could result in damage to the display and/or damage to the stand.
• Do not place near heater, replace, air conditioning, in direct sunlight, or any other
heat producing source. Failure to do so may result in damage to the display and could
increase the risk of re.
• It is recommended that two people perform the installation. Injury and/or damage can
result from dropping or mishandling the display.
• The enclosed instructions are an aid to installation and cannot cover all eventualities,
if you have any concerns regarding the mounting of the frame or brackets you should
consult an expert.
• CAUTION: Before installation the mounting area should be checked that it is suitable
for the weight of the bracket and screen and is free from pipes, electric cables or any
other obstructions.

No Part Qty No Part Qty
A M4 x 20mm 4 E Plug 8 x 40mm 4
B M6 x 20mm 4 F1 Washer 8
C M8 x 25mm 4 F2 Spirit Level 1
D ST6 x 50mm 4 G Spacer 4
TV MOUNTING ACCESSORIES
TOOLS REQUIRED
STUD WALL FITTING INSTRUCTIONS
• Select a suitable position to mount the frame.
• It is recommended that the frame is mounted using the supplied bolts to the wooden
supports behind the plasterboard. If you wish to mount directly to the plasterboard a
survey of the plasterboard must be taken by suitably qualied installers and the correct
mounting hardware must be purchased. The bolts and plugs provided are not suitable
for this purpose.
• Attach the spirit level (F2) to the frame and place against the wall.
• Use a stud detector to locate the centre points of 2 or more suitable wooden supports.
• Mark the holes required. Use the spirit level (F2) to keep the frame horizontal.
• Drill pilot holes 3mm diameter by 50mm deep in the supports.
• Attach the frame to the wall using the 6x50mm bolts (D) and washers (F1), the bolts
should be tightened using a 12mm / 1/2 inch socket wrench or spanner.

BRICK/CONCRETE WALL FITTING INSTRUCTIONS
• Select a suitable position to mount the frame.
• Attach the spirit level (F2) to the frame.
• Use a stud detector to check for hidden cables, pipes or steelwork.
• Place the frame against the wall and mark the holes required. Use the spirit level (F2)
to keep the frame horizontal.
• Drill the holes with a 8mm diameter drill bit to a depth of 50mm.
• Insert the wall plugs (E).
• Attach the frame to the wall using the 6x50mm bolts (D) and washers (F1), the bolts
should be tightened using a 12mm / 1/2 inch socket wrench or spanner.
ATTACHING BRACKETS TO TV
The A195DB TV bracket comes with a range of TV mounting accessories designed to t
the majority of televisions. Depending upon the required parts it may be necessary to use
screws A, B or C with the washers (F1) and spacers (G). The television should be laid at
on a soft surface so as not to damage or mark the screen.
A or B

ATTACHING TV TO FRAME
Due to the risk of damage or injury it is recommended that a minimum of two people
should be used to attach the television to the frame. The television should be tilted slightly
backwards and the top hook section of the bracket should be placed on the top rail of the
frame (g. 1). The television can now be lowered onto the frame and locked (g. 2).
g. 1
g. 2
If the television has a curved back or includes an obstruction that may prevent the brackets
from tting ush to the back you can place the spacers (G) beneath the brackets to lift
away from the back. The brackets can now be secured with screws A, B or C with the
washers (F1) if necessary.
A or B

SERVICE WARRANTY
Electrovision Ltd.guarantees the product free from defects in materials and workmanship
for a period of twelve months.
Should this bracket be operated under conditions other than those recommended, or any
attempts are made to service or modify the bracket, then the warranty will be rendered
void. The product you buy may sometimes differ slightly from illustrations. This warranty is
in addition to, and does not affect, your statutory rights.
Our guarantee is administered by our retailers.
If your product arrives damaged, you must contact the retailer from whom you bought it.
The retailer’s contact details will be on the invoice that arrived with the product, or on the
e-mail you received when you placed the order. Do not contact Electrovision, only your
retailer can arrange a replacement.
If the product needs to be repaired or replaced, you must contact the retailer from whom
you bought it. The retailer’s contact details will be on the invoice that arrived with the
product, or on the e-mail you received when you placed the order.
If you have just received your product and require technical help in using it, please call our
Help Desk on [phone]
