ELEKTRA CACM25-PROi User manual

Connection kit for cold applied
installation with M25 gland
Zestaw przyłączeniowy do montażu
na zimno z wpustem M25
êîìïëåêò äëÿ ñîåäèíåíèÿ
ñ õîëîäíûì êàáåëåì ñ ïàçîì M25
www.elektra.eu
CACM25-PROi
DE
PL
UK
RU
Anschlussset mit M25 Kabeleinführung

CACM25-PROi
0123456789
10 11 12 13 14 15 16 17 18

CACM25-PROi
Directive ATEX 2014/34/EU
ATEX KBD 19ATEX0003U
II 2G Ex eb IIC Gb
II 2D Ex tb IIIC Db
IECEx KDB 19.0001U
Ex eb IIC Gb
Ex tb IIIC Db
Standards EN 60079-0, EN 60079-7,
EN 60079-30-1
Operating temperature range
-50 C Ta +110 C
Protection IP68 (5 bar 1h)
oo
£££
UK
Each circuit must be protected with
a residual current device.
Disconnect all circuits before undertaking
any installation or maintenance works.
Keep the termination points of the heating
cables, power supply conductors and all
subcomponents of the sets in dry condition
before and during any installation works.
Use only in places of low vulnerability
to mechanical damage.
Connect the heating cable’s shield with
the proper grounding terminal.
Note:
3

The design of electrical heating systems
must be executed according to the design
directives for explosive conditions, basing
on the manufacturer’s recommendations
and supervised by qualified experts.
Heating systems must be executed in full
accordance with the instructions herein,
and the installation must be performed
by an authorised electrician.
Before undertaking any maintenance
works/repairs/ alterations, read the
specification of the heating system.
The specification of the heating system
should be stored for any heating circuit,
as long as the system is in use.
Note:
4
CACM25-PROi
Electrical systems must be checked
before the first start-up.
Anti-frost systems must be checked
before each heating season.
Regularly check systems for maintaining
process temperature, min. twice a year.
Note:

5
Installation must be executed in a clean
and dry place. Protect the termination
points of the heating cable, as well as all
the components of the installation kit,
against moisture, both before and during
installation, and maintain in the dry state.
Detailed agreement with the instructions
and maintaining the recommended
sequence of the installation procedure
must be observed.
Note:
4
3
2
1
1
2
3
Kit contents:
M25 gland and gasket with oval opening
double insulation silicone tubes,
150mm long
auxiliary insulation tubes covering silicone tubes,
180mm long
green-yellow tube, 160mm long
4

6
1
2
List of installation tools
not included in the kit:
snap-off blade utility knife
flat-head screwdriver
adjustable wrench or 28mm open-end wrench
and 32mm open-end wrench
side cutter
3
4
12 34
CACM25-PROi

7
1
2
The construction
of heating cables:
outer sheath
protective screen, copper wire braid
electrical insulation
self-regulating heating element
conductor wire
3
5
4
1
2
3
4
5
The installation kit is recommended
for the following cables:
SelfTec PROi LT / F 10
SelfTec PROi LT / F 20
SelfTec PROi LT / F 33
SelfTec PROi MT / F 30
SelfTec PROi MT / F 40
SelfTec PROi MT / F 50
SelfTec PROi HT F 30
SelfTec PROi HT F 45
SelfTec PROi HT F 60
®
®
®
®
®
®
®
®
®
M1

³300mm
8
A1
Place the gland with the oval opening gasket
on the heating cable, following the sequence
shown in the picture, in the distance of min.
300mm from the beginning of the cable.
Split the cable sheath delicately along the length
of 170mm, not damaging the protective screen.
CACM25-PROi

9
A3
Remove the sheath.
A4
Insert the heating element through the opening
in the protective screen.

10
Twist the screen.
140mm
Split and strip the insulation along the length of
140mm.
A5
A6
CACM25-PROi

11
A7
Split the heating element open revealing the
conductor wires along the length of 140mm.
A8
The splits should be made so that the
conductor wires are not damaged with
the blade of the utility knife or the side
cutter.
Note:

12
Pull on the 180mm-long auxiliary insulation
tubes covering silicone tubes, as well as the
150mm-long double silicone insulation tubes.
Pull the auxiliary tubes on so that the
conductor wires remain twisted.
Note:
A9
CACM25-PROi

13
Pull the common part of the double silicone
tubes onto the earlier uncovered electric
insulation of the heating cable, along the length
of 20mm.
Rotation might cause the short circuit
of the conductor wires.
A10
Note:

14
Put the green-yellow 160mm-long tube onto
the twisted protection screen.
Pull out the auxiliary tubes covering the 180mm-
long tubes and save them in case any
modification of the heating circuit becomes
necessary.
A11
A12
CACM25-PROi

15
Align the conductor wires and twisted
protective screen, leaving the wires isolated
along the length of 12mm.
If necessary, shorten the silicone insulation
tubes by a max. 40 mm.
Enter the prepared heating circuit, together
with the components recreating insulation,
into the electrical box through the counter nut
so that the heating cable’s sheath is inserted
into the box along the length of 10mm.
Tighten the barrel nut and the counter nut
of the M25 gland.
Enter the conductor wires and the braided
screen into the adequate terminals.
12mm
12mm
max. 40mm
A13

16
CACM25-PROi
12mm
12mm
A14
a
b

17
A15
ST terminal blocks positioned on the installation
rail of the power supply electrical box enable
connecting the conductor wires of the heating
cables, as well as the wires of the installation
cables, as above.

18
A16
