Elektro-Automatik PSI 9000 DT Series User manual
Elektro-Automatik
Operating Guide
PSI 9000 DT
DC Laboratory Power Supply
Attention! This document is only
valid for devices with rmware
“KE: 3.07” and “HMI: 2.17” and
“DR: 1.0.6” or higher. For avail-
ability of updates for your device
check our website or contact us.
Doc ID: PSI9DTEN
Revision: 05
Date: 10/2019
Page 3
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
TABLE OF CONTENTS
1GENERAL
1.1 About this document......................................5
1.1.1 Retention and use..........................................5
1.1.2 Copyright........................................................5
1.1.3 Validity ............................................................5
1.1.4 Symbols and warnings ..................................5
1.2 Warranty.........................................................5
1.3 Limitation of liability ........................................5
1.4 Disposal of equipment ...................................6
1.5 Product key ....................................................6
1.6 Intended usage ..............................................6
1.7 Safety .............................................................7
1.7.1 Safety notices.................................................7
1.7.2 Responsibility of the user...............................8
1.7.3 Responsibility of the operator .......................8
1.7.4 User requirements .........................................8
1.7.5 Alarm signals..................................................9
1.8 Technical Data ...............................................9
1.8.1 Approved operating conditions......................9
1.8.2 General technical data...................................9
1.8.3 Specic technical data .................................10
1.8.4 Views............................................................22
1.8.5 Control elements..........................................25
1.9 Construction and function............................26
1.9.1 General description......................................26
1.9.2 Block diagram ..............................................26
1.9.3 Scope of delivery .........................................26
1.9.4 Optional accessories ...................................26
1.9.5 The control panel (HMI)...............................27
1.9.6 USB port (rear side).....................................30
1.9.7 Ethernet port ................................................30
1.9.8 Analog interface ...........................................30
1.9.9 Sense connector (remote sensing) .............30
2INSTALLATION &
COMMISSIONING
2.1 Storage.........................................................31
2.1.1 Packaging ....................................................31
2.1.2 Storage.........................................................31
2.2 Unpacking and visual check........................31
2.3 Installation ....................................................31
2.3.1 Safety procedures before installation and
use................................................................31
2.3.2 Preparation...................................................31
2.3.3 Installing the device .....................................31
2.3.4 Connection to AC supply .............................36
2.3.5 Connection to DC loads...............................36
2.3.6 Grounding of the DC output ........................37
2.3.7 Connection of remote sensing ....................37
2.3.8 Connecting the analog interface .................37
2.3.9 Connecting the USB port (rear side)...........38
2.3.10 Initial commission.........................................38
2.3.11 Commission after a rmware update or a
long period of non-use.................................38
3OPERATION AND APPLICATION
3.1 Personal safety ............................................39
3.2 Operating modes .........................................39
3.2.1 Voltage regulation / Constant voltage .........39
3.2.2 Current regulation / constant current / current
limiting ..........................................................40
3.2.3 Power regulation / constant power / power
limiting ..........................................................40
3.2.4 Internal resistance regulation ......................40
3.3 Alarm conditions ..........................................41
3.3.1 Power Fail ...................................................41
3.3.2 Overtemperature..........................................41
3.3.3 Overvoltage protection.................................41
3.3.4 Overcurrent protection.................................41
3.3.5 Overpower protection ..................................41
3.4 Manual operation .........................................42
3.4.1 Switching the device on...............................42
3.4.2 Switching the device o...............................42
3.4.3 Conguration via MENU..............................42
3.4.4 Adjustment limits (Limits).............................47
3.4.5 Changing the operating mode.....................47
3.4.6 Manual adjustment of set values.................48
3.4.7 Switching the main screen view ..................49
3.4.8 The meter bars.............................................49
3.4.9 Switching the DC output on or o ...............50
3.4.10 Recording to USB stick (logging) ................50
3.5 Remote control.............................................52
3.5.1 General.........................................................52
3.5.2 Control locations ..........................................52
3.5.3 Remote control via a digital interface ..........52
3.5.4 Remote control via the analog interface
(AI)................................................................53
3.6 Alarms and monitoring.................................57
3.6.1 Denition of terms ........................................57
3.6.2 Device alarm and event handling................57
3.7 Control panel (HMI) lock..............................59
3.8 Limits lock.....................................................60
3.9 Loading and saving an user prole .............60
3.10 The function generator.................................61
3.10.1 Introduction...................................................61
3.10.2 General.........................................................61
3.10.3 Method of operation.....................................62
3.10.4 Manual operation .........................................62
3.10.5 Sine wave function.......................................63
3.10.6 Triangular function .......................................64
3.10.7 Rectangular function....................................64
3.10.8 Trapezoidal function.....................................65
3.10.9 DIN 40839 function ......................................65
3.10.10 Arbitrary function..........................................66
3.10.11 Ramp Function.............................................70
3.10.12 Remote control of the function generator....70
3.11 Other applications........................................71
3.11.1 Series connection ........................................71
3.11.2 Parallel operation .........................................71
3.11.3 Operation as battery charger.......................71
Page 4
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
4SERVICE AND MAINTENANCE
4.1 Maintenance / cleaning................................72
4.2 Fault nding / diagnosis / repair...................72
4.2.1 Replacing a defect mains fuse ....................72
4.2.2 Firmware updates ........................................72
4.3 Calibration ....................................................73
4.3.1 Preface .........................................................73
4.3.2 Preparation...................................................73
4.3.3 Calibration procedure ..................................73
5CONTACT AND SUPPORT
5.1 General.........................................................75
5.2 Contact options ............................................75
Page 5
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
1. General
1.1 About this document
1.1.1 Retention and use
This document is to be kept in the vicinity of the equipment for future reference and explanation of the operation of
the device. This document is to be delivered and kept with the equipment in case of change of location and/or user.
1.1.2 Copyright
Reprinting, copying, also partially, usage for other purposes as foreseen of this manual are forbidden and breach
may lead to legal process.
1.1.3 Validity
This manual is valid for the following equipment:
Model Article number Model Article number
PSI 9040-20 DT 06200500 PSI 9500-06 DT 06200509
PSI 9080-10 DT 06200501 PSI 9750-04 DT 06200510
PSI 9200-04 DT 06200502 PSI 9080-60 DT 06200511
PSI 9040-40 DT 06200503 PSI 9200-25 DT 06200512
PSI 9080-20 DT 06200504 PSI 9360-15 DT 06200513
PSI 9200-10 DT 06200505 PSI 9500-10 DT 06200514
PSI 9080-40 DT 06200506 PSI 9750-06 DT 06200515
PSI 9200-15 DT 06200507 PSI 9040-60 DT 06200516
PSI 9360-10 DT 06200508 PSI 9040-40 DT 06200517
1.1.4 Symbols and warnings
Warning and safety notices as well as general notices in this document are shown in a box with a symbol as follows:
Symbol for a life threatening danger
Symbol for general safety notices (instructions and damage protection bans) or important infor-
mation for operation
Symbol for general notices
1.2 Warranty
EA Elektro-Automatik guarantees the functional competence of the applied technology and the stated performance
parameters. The warranty period begins with the delivery of free from defects equipment.
Terms of guarantee are included in the general terms and conditions (TOS) of EA Elektro-Automatik.
1.3 Limitation of liability
All statements and instructions in this manual are based on current norms and regulations, up-to-date technology
and our long term knowledge and experience. The manufacturer accepts no liability for losses due to:
• Usage for purposes other than designed
• Use by untrained personnel
• Rebuilding by the customer
• Technical changes
• Use of not authorized spare parts
The actual delivered device(s) may dier from the explanations and diagrams given here due to latest technical
changes or due to customized models with the inclusion of additionally ordered options.
Page 6
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
1.4 Disposal of equipment
A piece of equipment which is intended for disposal must, according to European laws and regulations (ElektroG,
WEEE) be returned to the manufacturer for scrapping, unless the person operating the piece of equipment or an-
other, delegated person is conducting the disposal. Our equipment falls under these regulations and is accordingly
marked with the following symbol:
1.5 Product key
Decoding of the product description on the label, using an example:
PSI 9 080 - 40 DT
Construction (not printed everywhere)
DT = Desktop model
Maximum current of the device in Ampere
Maximum voltage of the device in Volt
Series : 8= Series 8000 or 800, 9= Series 9000
Type identication:
PSI = Power Supply Intelligent, always programmable
1.6 Intended usage
The equipment is intended to be used, if a power supply or battery charger, only as a variable voltage and current
source, or, if an electronic load, only as a variable current sink.
Typical application for a power supply is DC supply to any relevant user, for a battery charger the charging of vari-
ous battery types and for electronic loads the replacement of an ohmic resistor by an adjustable DC current sink
in order to load relevant voltage and current sources of any type.
• Claims of any sort due to damage caused by non-intended usage will not be accepted.
• All damage caused by non-intended usage is solely the responsibility of the operator.
Page 7
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
1.7 Safety
1.7.1 Safety notices
Mortal danger - Hazardous voltage
• Electrical equipment operation means that some parts can be under dangerous voltage.
Therefore all parts under voltage must be covered! This basically applies to all models,
though 40 V models according to SELV can not generate hazardous DC voltage.
• All work on connections must be carried out under zero voltage (output not connected
to load) and may only be performed by qualied and informed persons. Improper ac-
tions can cause fatal injury as well as serious material damage.
• Never touch cables or connectors directly after unplugging from mains supply as the
danger of electric shock remains.
• Never touch the contacts on DC output terminal directly after switching o the DC
output, because there still can dangerous voltage present, sinking more or less slowly
depending on the load! There also can be dangerous potential between negative DC
output to PE or positive DC output to PE due to charged X capacitors.
• The equipment must only be used as intended
• The equipment is only approved for use within the connection limits stated on the product label.
• Do not insert any object, particularly metallic, through the ventilator slots
• Avoid any use of liquids near the equipment. Protect the device from wet, damp and conden-
sation.
• For power supplies and battery chargers: do not connect users, particularly low resistance, to
devices under power; sparking may occur which can cause burns as well as damage to the
equipment and to the user.
• For electronic loads: do not connect power sources to equipment under power, sparking may
occur which can cause burns as well as damage to the equipment and to the source.
• ESD regulations must be applied when plugging interface cards or modules into the relative slot
• Interface cards or modules may only be attached or removed after the device is switched o.
It isn’t necessary to open the device.
• Do not connect external power sources with reversed polarity to DC input or outputs! The
equipment will be damaged.
• For power supply devices: avoid where possible connecting external power sources to the
DC output, and never those that can generate a higher voltage than the nominal voltage of
the device.
• For electronic loads: do not connect a power source to the DC input which can generate a
voltage more than 120% of the nominal input voltage of the load. The equipment isn’t protected
against over voltage and may be irreparably damaged.
• Never insert a network cable which is connected to Ethernet or its components into the master-
slave socket on the back side of the device!
• Always congure the various protecting features against overvoltage overpower etc. for sensi-
tive loads to what the currently used application requires
Page 8
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
1.7.2 Responsibility of the user
The equipment is in industrial operation. Therefore the operators are governed by the legal safety regulations.
Alongside the warning and safety notices in this manual the relevant safety, accident prevention and environmental
regulations must also be applied. In particular the users of the equipment:
• must be informed of the relevant job safety requirements
• must work to the dened responsibilities for operation, maintenance and cleaning of the equipment
• before starting work must have read and understood the operating manual
• must use the designated and recommended safety equipment.
Furthermore, anyone working with the equipment is responsible for ensuring that the device is at all times techni-
cally t for use.
1.7.3 Responsibility of the operator
Operator is any natural or legal person who uses the equipment or delegates the usage to a third party, and is
responsible during its usage for the safety of the user, other personnel or third parties.
The equipment is in industrial operation. Therefore the operators are governed by the legal safety regulations.
Alongside the warning and safety notices in this manual the relevant safety, accident prevention and environmental
regulations must also be applied. In particular the operator has to
• be acquainted with the relevant job safety requirements
• identify other possible dangers arising from the specic usage conditions at the work station via a risk assessment
• introduce the necessary steps in the operating procedures for the local conditions
• regularly control that the operating procedures are current
• update the operating procedures where necessary to reect changes in regulation, standards or operating con-
ditions.
• dene clearly and unambiguously the responsibilities for operation, maintenance and cleaning of the equipment.
• ensure that all employees who use the equipment have read and understood the manual. Furthermore the users
are to be regularly schooled in working with the equipment and the possible dangers.
• provide all personnel who work with the equipment with the designated and recommended safety equipment
Furthermore, the operator is responsible for ensuring that the device is at all times technically t for use.
1.7.4 User requirements
Any activity with equipment of this type may only be performed by persons who are able to work correctly and
reliably and satisfy the requirements of the job.
• Persons whose reaction capability is negatively inuenced by e. g. drugs, alcohol or medication may not operate
the equipment.
• Age or job related regulations valid at the operating site must always be applied.
Danger for unqualied users
Improper operation can cause person or object damage. Only persons who have the necessary
training, knowledge and experience may use the equipment.
Delegated persons are those who have been properly and demonstrably instructed in their tasks and the atten-
dant dangers.
Qualied persons are those who are able through training, knowledge and experience as well as knowledge of
the specic details to carry out all the required tasks, identify dangers and avoid personal and other risks.
Page 9
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
1.7.5 Alarm signals
The equipment oers various possibilities for signalling alarm conditions, however, not for danger situations. The
signals may be optical (on the display as text), acoustic (piezo buzzer) or electronic (pin/status output of an analog
interface). All alarms will cause the device to switch o the DC output.
The meaning of the signals is as follows:
Signal OT
(OverTemperature)
• Overheating of the device
• DC output will be switched o
• Non-critical
Signal OVP
(OverVoltage)
• Overvoltage shutdown of the DC output due to high voltage entering the device or gener-
ated by the device itself due to a defect
• Critical! The device and/or the load could be damaged
Signal OCP
(OverCurrent)
• Shutdown of the DC output due to excess of the preset limit
• Non-critical, protects the load from excessive current consumption
Signal OPP
(OverPower)
• Shutdown of the DC output due to excess of the preset limit
• Non-critical, protects the load from excessive power consumption
Signal PF
(Power Fail)
• DC output shutdown due to AC undervoltage or defect in the AC input
• Critical on overvoltage! AC input circuit could be damaged
1.8 Technical Data
1.8.1 Approved operating conditions
• Use only inside dry buildings
• Ambient temperature 0-50°C
• Operational altitude: max. 2000 m above sea level
• Max. 80% relative humidity, non-condensing
1.8.2 General technical data
Display: Colour TFT touch screen with gorilla glass, 4.3”, 480pt x 272pt, capacitive
Controls: 2 rotary knobs with pushbutton functions, 2 pushbutton
The nominal values for the device determine the maximum adjustable ranges.
Page 10
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
1.8.3 Specic technical data
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: a 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to dier max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20 MHz
(3 The display error adds to the error of the related actual value on the DC output
320 W Model
PSI 9040-20 DT PSI 9080-10 DT PSI 9200-04 DT
AC Input
Voltage range 90...264 V AC 90...264 V AC 90...264 V AC
Connection 1ph,N,PE 1ph,N,PE 1ph,N,PE
Frequency 45-65 Hz 45-65 Hz 45-65 Hz
Fusing MT 8 A MT 8 A MT 8 A
Leak current < 3.5 mA < 3.5 mA < 3.5 mA
Power factor ≈ 0.99 ≈ 0.99 ≈ 0.99
DC Output
Max. output voltage UMax 40.8 V 81.6 V 204 V
Max. output current IMax 20 A 10 A 4 A
Max. output power PMax 320 W 320 W 320 W
Overvoltage protection range 0...44 V 0...88 V 0...220 V
Overcurrent protection range 0...22 A 0...11 A 0...4.4 A
Overpower protection range 0…352 W 0…352 W 0…352 W
Output capacitance 4760 μF 3400 μF 720 μF
Temperature coecient for set
values Δ/K Voltage / current: 100 ppm
Voltage regulation
Adjustment range 0...40.8 V 0...81.6 V 0...204 V
Accuracy (1 (at 23 ± 5°C) < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax
Load regulation at 0...100% load < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 0...100% (@full load) Max. 30 ms Max. 60 ms Max. 65 ms
Settling time after load step < 1.5 ms < 1.5 ms < 1.5 ms
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Ripple (2 < 8 mVPP
< 0.8 mVRMS
< 8 mVPP
< 0.8 mVRMS
< 20 mVPP
< 2.5 mVRMS
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax
Output voltage fall time (at no load)
after switching DC output o - Down from 100% to <60 V: less than 10 s
Current regulation
Adjustment range 0...20,4 A 0...10,2 A 0...4,08 A
Accuracy (1 (at 23 ± 5°C) < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 1 mARMS < 1 mARMS < 1,5 mARMS
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Power regulation
Adjustment range 0…326.4 W 0…326.4 W 0…326.4 W
Accuracy (1 (at 23 ± 5°C) < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUOUT * ΔIOUT < 0.75% PMax < 0.75% PMax < 0.75% PMax
Page 11
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
(2 The display error adds to the error of the related actual value on the DC output
(3 For technical specications of the analog interface see „3.5.4.4 Analog interface specication“ on page 54
(4 Typical value at 100% output voltage and 100% power
320 W Model
PSI 9040-20 DT PSI 9080-10 DT PSI 9200-04 DT
Power regulation
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (2 ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax
Eciency (4 ≈ 92% ≈ 92% ≈ 93%
Internal resistance regulation
Adjustment range 0...81.6 Ω 0...163.2 Ω 0...979.2 Ω
Accuracy (1 ≤ 1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Analog interface (3
Set value inputs U, I, P, R
Actual value output U, I
Control signals DC on/o, remote control on/o, resistance mode on/o
Status signals CV, OVP, OCP, OPP, OT, PF, DC on/o
Galvanic isolation to the device Max. 400 VDC
Sample rate of inputs 500 Hz
Insulation
Output (DC) to enclosure (PE) DC minus: permanent max. ±400 V
DC plus: permanent max. ±400 V + output voltage
Input (AC) to output (DC) Max. 2500 V, short-term
Miscellaneous
Cooling Temperature controlled fan, side inlet, rear exhaust
Ambient temperature 0..50°C
Storage temperature -20...70°C
Humidity < 80%, not condensing
Standards EN 60950:2006 + A11:2009 + A1:2010 + A12:2011 + AC:2011 + A2:2013
EN 61236-1:2013-07
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication
Galvanic isolation from device Max. 400 VDC
Terminals
Rear side AC input, analog interface, USB-B, Ethernet
Front side DC output, USB-A, remote sensing
Dimensions
Enclosure (WxHxD) 276 x 103 x 355 mm
Total (WxHxD) 308 x max. 195 x min. 391 mm
Weight ≈ 7.5 kg ≈ 7.5 kg ≈ 7.5 kg
Article number 06200500 06200501 06200502
Page 12
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: a 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to dier max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20 MHz
(3 The display error adds to the error of the related actual value on the DC output
640 W Model
PSI 9040-40 DT PSI 9080-20 DT PSI 9200-10 DT
AC Input
Voltage range 90...264 V AC 90...264 V AC 90...264 V AC
Connection 1ph,N,PE 1ph,N,PE 1ph,N,PE
Frequency 45-65 Hz 45-65 Hz 45-65 Hz
Fusing MT 8 A MT 8 A MT 8 A
Leak current < 3.5 mA < 3.5 mA < 3.5 mA
Power factor ≈ 0.99 ≈ 0.99 ≈ 0.99
DC Output
Max. output voltage UMax 40 V 80 V 200 V
Max. output current IMax 40 A 20 A 10 A
Max. output power PMax 640 W 640 W 640 W
Overvoltage protection range 0...44 V 0...88 V 0...220 V
Overcurrent protection range 0...44 A 0...22 A 0...11 A
Overpower protection range 0…704 W 0…704 W 0…704 W
Output capacitance 4760 μF 3400 μF 720 μF
Temperature coecient for set
values Δ/K Voltage / current: 100 ppm
Voltage regulation
Adjustment range 0...40.8 V 0...81.6 V 0...204 V
Accuracy (1 (at 23 ± 5°C) < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax
Load regulation at 0...100% load < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 0...100% (@full load) Max. 30 ms Max. 60 ms Max. 65 ms
Settling time after load step < 1.5 ms < 1.5 ms < 1.5 ms
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Ripple (2 < 8 mVPP
< 0.8 mVRMS
< 8 mVPP
< 0.8 mVRMS
< 20 mVPP
< 2.5 mVRMS
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax
Output voltage fall time (at no load)
after switching DC output o - Down from 100% to <60 V: less than 10 s
Current regulation
Adjustment range 0...40.8 A 0...20.4 A 0...10.2 A
Accuracy (1 (at 23 ± 5°C) < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 1 mARMS < 1 mARMS < 1.5 mARMS
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Power regulation
Adjustment range 0…652.8 W 0…652.8 W 0…652.8 W
Accuracy (1 (at 23 ± 5°C) < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUOUT * ΔIOUT < 0.75% PMax < 0.75% PMax < 0.75% PMax
Page 13
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
640 W Model
PSI 9040-40 DT PSI 9080-20 DT PSI 9200-10 DT
Power regulation
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (2 ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax
Eciency (4 ≈ 92% ≈ 92% ≈ 93%
Internal resistance regulation
Adjustment range 0...40.8 Ω 0...81.6 Ω 0...489.6 Ω
Accuracy (1 ≤ 1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Analog interface (3
Set value inputs U, I, P, R
Actual value output U, I
Control signals DC on/o, remote control on/o, resistance mode on/o
Status signals CV, OVP, OCP, OPP, OT, PF, DC on/o
Galvanic isolation to the device Max. 400 VDC
Sample rate of inputs 500 Hz
Insulation
Output (DC) to enclosure (PE) DC minus: permanent max. ±400 V
DC plus: permanent max. ±400 V + output voltage
Input (AC) to output (DC) Max. 2500 V, short-term
Miscellaneous
Cooling Temperature controlled fan, side inlet, rear exhaust
Ambient temperature 0..50°C
Storage temperature -20...70°C
Humidity < 80%, not condensing
Standards EN 60950:2006 + A11:2009 + A1:2010 + A12:2011 + AC:2011 + A2:2013
EN 61236-1:2013-07
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication
Galvanic isolation from device Max. 400 VDC
Terminals
Rear side AC input, analog interface, USB-B, Ethernet
Front side DC output, USB-A, remote sensing
Dimensions
Enclosure (WxHxD) 276 x 103 x 355 mm
Total (WxHxD) 308 x max. 195 x min. 391 mm
Weight ≈ 7.5 kg ≈ 7.5 kg ≈ 7.5 kg
Article number 06200503 06200504 06200505
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
(2 The display error adds to the error of the related actual value on the DC output
(3 For technical specications of the analog interface see „3.5.4.4 Analog interface specication“ on page 54
(4 Typical value at 100% output voltage and 100% power
Page 14
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: a 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to dier max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20 MHz
(3 The display error adds to the error of the related actual value on the DC output
1000 W Model
PSI 9040-40 DT PSI 9080-40 DT PSI 9200-15 DT
AC Input
Voltage range 90...264 V AC 90...264 V AC 90...264 V AC
Connection 1ph,N,PE 1ph,N,PE 1ph,N,PE
Frequency 45-65 Hz 45-65 Hz 45-65 Hz
Fusing T 16 A T 16 A T 16 A
Leak current < 3.5 mA < 3.5 mA < 3.5 mA
Power factor ≈ 0.99 ≈ 0.99 ≈ 0.99
DC Output
Max. output voltage UMax 40 V 80 V 200 V
Max. output current IMax 40 A 40 A 15 A
Max. output power PMax 1000 W 1000 W 1000 W
Overvoltage protection range 0...44 V 0...88 V 0...220 V
Overcurrent protection range 0...44 A 0...44 A 0...16.5 A
Overpower protection range 0…1100 W 0…1100 W 0…1100 W
Output capacitance 6120 μF 6120 μF 1020 μF
Temperature coecient for set values Δ/K Voltage / current: 100 ppm
Voltage regulation
Adjustment range 0...40.8 V 0...81.6 V 0...204 V
Accuracy (1 (at 23 ± 5°C) < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax
Load regulation at 0...100% load < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 0...100% (@full load) Max. 40 ms Max. 40 ms Max. 40 ms
Settling time after load step < 1.5 ms < 1.5 ms < 1.5 ms
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Ripple (2 < 10 mVPP
< 1.5 mVRMS
< 10 mVPP
< 1.5 mVRMS
< 60 mVPP
< 9 mVRMS
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax
Output voltage fall time (at no load)after
switching DC output o - Down from 100% to <60 V: less than 10 s
Current regulation
Adjustment range 0...40.8 A 0...40.8 A 0...15.3 A
Accuracy (1 (at 23 ± 5°C) < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 6 mARMS < 6 mARMS < 1.8 mARMS
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Power regulation
Adjustment range 0…1020 W 0…1020 W 0…1020 W
Accuracy (1 (at 23 ± 5°C) < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUOUT * ΔIOUT < 0.75% PMax < 0.75% PMax < 0.75% PMax
Page 15
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
1000 W Model
PSI 9040-40 DT PSI 9080-40 DT PSI 9200-15 DT
Power regulation
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (2 ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax
Eciency (4 ≈ 92% ≈ 92% ≈ 92%
Internal resistance regulation
Adjustment range 0...30.6 Ω 0...61.2 Ω 0...367.2 Ω
Accuracy (1 ≤ 1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Analog interface (3
Set value inputs U, I, P, R
Actual value output U, I
Control signals DC on/o, remote control on/o, resistance mode on/o
Status signals CV, OVP, OCP, OPP, OT, PF, DC on/o
Galvanic isolation to the device Max. 400 VDC
Sample rate of inputs 500 Hz
Insulation
Output (DC) to enclosure (PE) DC minus: permanent max. ±400 V
DC plus: permanent max. ±400 V + output voltage
Input (AC) to output (DC) Max. 2500 V, short-term
Miscellaneous
Cooling Temperature controlled fan, side inlet, rear exhaust
Ambient temperature 0..50°C
Storage temperature -20...70°C
Humidity < 80%, not condensing
Standards EN 60950:2006 + A11:2009 + A1:2010 + A12:2011 + AC:2011 + A2:2013
EN 61236-1:2013-07
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication
Galvanic isolation from device Max. 400 VDC
Terminals
Rear side AC input, analog interface, USB-B, Ethernet
Front side DC output, USB-A, remote sensing
Dimensions
Enclosure (WxHxD) 276 x 103 x 415 mm
Total (WxHxD) 308 x max. 195 x min. 451 mm
Weight 8.15 kg 8.15 kg 8.15 kg
Article number 06200517 06200506 06200507
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
(2 The display error adds to the error of the related actual value on the DC output
(3 For technical specications of the analog interface see „3.5.4.4 Analog interface specication“ on page 54
(4 Typical value at 100% output voltage and 100% power
Page 16
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: a 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to dier max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20 MHz
(3 The display error adds to the error of the related actual value on the DC output
1000 W Model
PSI 9360-10 DT PSI 9500-06 DT PSI 9750-04 DT
AC Input
Voltage range 90...264 V AC 90...264 V AC 90...264 V AC
Connection 1ph,N,PE 1ph,N,PE 1ph,N,PE
Frequency 45-65 Hz 45-65 Hz 45-65 Hz
Fusing T 16 A T 16 A T 16 A
Leak current < 3.5 mA < 3.5 mA < 3.5 mA
Power factor ≈ 0.99 ≈ 0.99 ≈ 0.99
DC Output
Max. output voltage UMax 360 V 500 V 750 V
Max. output current IMax 10 A 6 A 4 A
Max. output power PMax 1000 W 1000 W 1000 W
Overvoltage protection range 0...396 V 0...550 V 0...825 V
Overcurrent protection range 0...11 A 0...6.6 A 0...4.4 A
Overpower protection range 0…1100 W 0…1100 W 0…1100 W
Output capacitance 430 μF 130 μF 50 μF
Temperature coecient for set values Δ/K Voltage / current: 100 ppm
Voltage regulation
Adjustment range 0...367.2 V 0...510 V 0...765 V
Accuracy (1 (at 23 ± 5°C) < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax
Load regulation at 0...100% load < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 0...100% (@full load) Max. 75 ms Max. 30 ms Max. 30 ms
Settling time after load step < 1.5 ms < 1.5 ms < 1.5 ms
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Ripple (2 < 58 mVPP
< 11 mVRMS
< 62 mVPP
< 13 mVRMS
< 94 mVPP
< 16 mVRMS
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax
Output voltage fall time (at no load)after
switching DC output o Down from 100% to <60 V: less than 10 s
Current regulation
Adjustment range 0...10.2 A 0...6.12 A 0...4.08 A
Accuracy (1 (at 23 ± 5°C) < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 2 mARMS < 8 mARMS < 10 mARMS
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Power regulation
Adjustment range 0…1020 W 0…1020 W 0…1020 W
Accuracy (1 (at 23 ± 5°C) < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUOUT * ΔIOUT < 0.75% PMax < 0.75% PMax < 0.75% PMax
Page 17
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
1000 W Model
PSI 9360-10 DT PSI 9500-06 DT PSI 9750-04 DT
Power regulation
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (2 ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax
Eciency (4 ≈ 92% ≈ 92% ≈ 92%
Internal resistance regulation
Adjustment range 0...1100.6 Ω 0...2295 Ω 0...5317.5 Ω
Accuracy (1 ≤ 1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Analog interface (3
Set value inputs U, I, P, R
Actual value output U, I
Control signals DC on/o, remote control on/o, resistance mode on/o
Status signals CV, OVP, OCP, OPP, OT, PF, DC on/o
Galvanic isolation to the device Max. 400 VDC
Sample rate of inputs 500 Hz
Insulation
Output (DC) to enclosure (PE) DC minus: permanent max. ±400 V
DC plus: permanent max. ±400 V + output voltage
Input (AC) to output (DC) Max. 2500 V, short-term
Miscellaneous
Cooling Temperature controlled fan, side inlet, rear exhaust
Ambient temperature 0..50°C
Storage temperature -20...70°C
Humidity < 80%, not condensing
Standards EN 60950:2006 + A11:2009 + A1:2010 + A12:2011 + AC:2011 + A2:2013
EN 61236-1:2013-07
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication
Galvanic isolation from device Max. 400 VDC
Terminals
Rear side AC input, analog interface, USB-B, Ethernet
Front side DC output, USB-A, remote sensing
Dimensions
Enclosure (WxHxD) 276 x 103 x 415 mm
Total (WxHxD) 308 x max. 195 x min. 451 mm
Weight 8.15 kg 8.15 kg 8.15 kg
Article number 06200508 06200509 06200510
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
(2 The display error adds to the error of the related actual value on the DC output
(3 For technical specications of the analog interface see „3.5.4.4 Analog interface specication“ on page 54
(4 Typical value at 100% output voltage and 100% power
Page 18
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: a 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to dier max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20 MHz
(3 The display error adds to the error of the related actual value on the DC output
1500 W Model
PSI 9040-60 DT PSI 9080-60 DT PSI 9200-25 DT
AC Input
Voltage range without derating 150...264 V AC 150...264 V AC 150...264 V AC
Voltage range with derating 90...150 V AC 90...150 V AC 90...150 V AC
Connection 1ph,N,PE 1ph,N,PE 1ph,N,PE
Frequency 45-65 Hz 45-65 Hz 45-65 Hz
Fusing T 16 A T 16 A T 16 A
Leak current < 3.5 mA < 3.5 mA < 3.5 mA
Power factor ≈ 0.99 ≈ 0.99 ≈ 0.99
DC Output
Max. output voltage UMax 40 V 80 V 200 V
Max. output current IMax 60 A 60 A 25 A
Max. output power PMax 1500 W 1500 W 1500 W
Max. output power PMax with derating 1000 W 1000 W 1000 W
Overvoltage protection range 0...44 V 0...88 V 0...220 V
Overcurrent protection range 0...66 A 0...66 A 0...27,5 A
Overpower protection range 0…1650 W 0…1650 W 0…1650 W
Output capacitance 6120 μF 6120 μF 1020 μF
Temperature coecient for set values Δ/K Voltage / current: 100 ppm
Voltage regulation
Adjustment range 0...40.8 V 0...81.6 V 0...204 V
Accuracy (1 (at 23 ± 5°C) < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax
Load regulation at 0...100% load < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 0...100% (@full load) Max. 40 ms Max. 40 ms Max. 40 ms
Settling time after load step < 1.5 ms < 1.5 ms < 1.5 ms
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Ripple (2 < 10 mVPP
< 1,5 mVRMS
< 10 mVPP
< 1,5 mVRMS
< 60 mVPP
< 9 mVRMS
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax
Output voltage fall time (at no load)after
switching DC output o - Down from 100% to <60 V: less than 10 s
Current regulation
Adjustment range 0...61.2 A 0...61.2 A 0...25.5 A
Accuracy (1 (at 23 ± 5°C) < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 6 mARMS < 6 mARMS < 1.8 mARMS
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Power regulation
Adjustment range 0…1530 W 0…1530 W 0…1530 W
Accuracy (1 (at 23 ± 5°C) < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUOUT * ΔIOUT < 0.75% PMax < 0.75% PMax < 0.75% PMax
Page 19
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
1500 W Model
PSI 9040-60 DT PSI 9080-60 DT PSI 9200-25 DT
Power regulation
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (2 ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax
Eciency (4 ≈ 92% ≈ 92% ≈ 92%
Internal resistance regulation
Adjustment range 0...20.4 Ω 0...40.8 Ω 0...244,8 Ω
Accuracy (1 ≤ 1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Analog interface (3
Set value inputs U, I, P, R
Actual value output U, I
Control signals DC on/o, remote control on/o, resistance mode on/o
Status signals CV, OVP, OCP, OPP, OT, PF, DC on/o
Galvanic isolation to the device Max. 400 VDC
Sample rate of inputs 500 Hz
Insulation
Output (DC) to enclosure (PE) DC minus: permanent max. ±400 V
DC plus: permanent max. ±400 V + output voltage
Input (AC) to output (DC) Max. 2500 V, short-term
Miscellaneous
Cooling Temperature controlled fan, side inlet, rear exhaust
Ambient temperature 0..50°C
Storage temperature -20...70°C
Humidity < 80%, not condensing
Standards EN 60950:2006 + A11:2009 + A1:2010 + A12:2011 + AC:2011 + A2:2013
EN 61236-1:2013-07
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication
Galvanic isolation from device Max. 400 VDC
Terminals
Rear side AC input, analog interface, USB-B, Ethernet
Front side DC output, USB-A, remote sensing
Dimensions
Enclosure (WxHxD) 276 x 103 x 415 mm
Total (WxHxD) 308 x max. 195 x min. 451 mm
Weight 8.15 kg 8.15 kg 8.15 kg
Article number 06200516 06200511 06200512
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
(2 The display error adds to the error of the related actual value on the DC output
(3 For technical specications of the analog interface see „3.5.4.4 Analog interface specication“ on page 54
(4 Typical value at 100% output voltage and 100% power
Page 20
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
PSI 9000 DT Series
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: a 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to dier max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20 MHz
(3 The display error adds to the error of the related actual value on the DC output
1500 W Model
PSI 9360-15 DT PSI 9500-10 DT PSI 9750-06 DT
AC Input
Voltage range without derating 150...264 V AC 150...264 V AC 150...264 V AC
Voltage range with derating 90...150 V AC 90...150 V AC 90...150 V AC
Connection 1ph,N,PE 1ph,N,PE 1ph,N,PE
Frequency 45-65 Hz 45-65 Hz 45-65 Hz
Fusing T 16 A T 16 A T 16 A
Leak current < 3.5 mA < 3.5 mA < 3.5 mA
Power factor ≈ 0.99 ≈ 0.99 ≈ 0.99
DC Output
Max. output voltage UMax 360 V 500 V 750 V
Max. output current IMax 15 A 10 A 6 A
Max. output power PMax 1500 W 1500 W 1500 W
Max. output power PMax with derating 1000 W 1000 W 1000 W
Overvoltage protection range 0...396 V 0...550 V 0...825 V
Overcurrent protection range 0...16.5 A 0...11 A 0...6.6 A
Overpower protection range 0…1650 W 0…1650 W 0…1650 W
Output capacitance 430 μF 130 μF 50 μF
Temperature coecient for set values Δ/K Voltage / current: 100 ppm
Voltage regulation
Adjustment range 0...367.2 V 0...510 V 0...765 V
Accuracy (1 (at 23 ± 5°C) < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax
Load regulation at 0...100% load < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 0...100% (@full load) Max. 75 ms Max. 30 ms Max. 30 ms
Settling time after load step < 1.5 ms < 1.5 ms < 1.5 ms
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Ripple (2 < 58 mVPP
< 11 mVRMS
< 62 mVPP
< 13 mVRMS
< 94 mVPP
< 16 mVRMS
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax
Output voltage fall time (at no load)after
switching DC output o Down from 100% to <60 V: less than 10 s
Current regulation
Adjustment range 0...15.3 A 0...10.2 A 0...6.12 A
Accuracy (1 (at 23 ± 5°C) < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 2 mARMS < 8 mARMS < 10 mARMS
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Power regulation
Adjustment range 0…1530 W 0…1530 W 0…1530 W
Accuracy (1 (at 23 ± 5°C) < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUOUT * ΔIOUT < 0.75% PMax < 0.75% PMax < 0.75% PMax
