1. General
1.1 About this document
1.1.1 Retention and use
This document is to be kept in the vicinity of the equipment for future reference and explanation of the operation of the de-
vice. This document is to be delivered and kept with the equipment in case of change of location and/or user.
The most recent issue of this document can be found online, on our website.
1.1.2 Copyright
Modication and partial or complete usage of this PDF document for other purposes as intended are forbidden and breach
may lead to legal process.
1.1.3 Validity
This manual is valid for the following equipment and its variants:
Model Model Model Model
EA-PUB 10010-1000 4U EA-PUB 10200-420 4U EA-PUB 10750-120 4U EA-PUB 11500-60 4U
EA-PUB 10060-1000 4U EA-PUB 10360-240 4U EA-PUB 10920-125 4U EA-PUB 12000-40 4U
EA-PUB 10080-1000 4U EA-PUB 10500-180 4U EA-PUB 11000-80 4U
1.1.4 Symbols and warnings in this document
Warning and safety notices as well as general notices in this document are shown in a box with a symbol as follows. The
symbols are also valid, where placed, also to mark specic spots on the device:
Symbol for a life threatening danger (electric shock hazard)
Symbol for risk (of damage to the equipment). If placed on the device it requests the user to read the
operating guide prior to start operation.
Symbol for general safety notices (instructions and damage protection bans) or important information
for operation
Symbol for general notices
1.2 Warranty
EA Elektro-Automatik guarantees the functional competence of the applied technology and the stated performance param-
eters. The warranty period begins with the delivery of free from defects equipment.
Terms of guarantee are included in the general terms and conditions (TOS) of EA Elektro-Automatik.
1.3 Limitation of liability
All statements and instructions in this manual are based on current norms and regulations, up-to-date technology and our
long term knowledge and experience. The manufacturer accepts no liability for losses due to:
• Usage for purposes other than designed
• Use by untrained personnel
• Rebuilding by the customer
• Technical changes
• Use of not authorized spare parts
The actual delivered device(s) may differ from the explanations and diagrams given here due to latest technical changes or
due to customized models with the inclusion of additionally ordered options.

© EA Elektro-Automatik in 2023, this information is subject to change without notice 601123000_manual_pub_10000_4u_30kw_en_01
1.4 Disposal of equipment
A piece of equipment which is intended for disposal must, according to European laws and regulations (ElektroG, WEEE) be
returned to the manufacturer for scrapping, unless the person operating the piece of equipment or another, delegated person
is conducting the disposal. Our equipment falls under these regulations and is accordingly marked with the following symbol:
The device contains a Lithium battery cell. Disposal of that battery follows the above stated rule or spe-
cic local regulations.
1.5 Product key
Decoding of the product description on the label, using an example:
EA-PUB 10080 -1000 4U xxx
Options and special versions:
WC = Water cooling installed
Construction (only stated on type label):
4U = 19" frame with 4 height units
Maximum current of the device in Ampere
Maximum voltage of the device in Volt (“10080” = 80 V)
Series: 10 = Series 10000
Type identication:
PSB = Power Unit Bidirectional

© EA Elektro-Automatik in 2023, this information is subject to change without notice 701123000_manual_pub_10000_4u_30kw_en_01
1.6 Intended usage
The equipment is intended to be used only as a variable voltage and current source or only as a variable current sink. Fur-
thermore it’s only intended to be used installed and operated in suitable equipment (19” rack or similar), together with a rigid,
non-retractable AC supply connection.
Typical application for a voltage source is DC power supply to any relevant user, including when used as battery charger to
test charge various battery types, and for current sinks the replacement of an ohmic resistor by an adjustable electronic DC
load in order to load relevant voltage and current sources of any type.
Additionally to the functionality of the equipment as source or sink of electrical energy on the DC side, all models in this series
are also so-called recuperating devices and thus not just drain energy on the AC side, but also source energy when being
sinks on the DC side. This is where the term “bidirectional” comes from. In sink mode the devices become energy recoverers,
but are not dened or considered as energy generation equipment.
• Claims of any sort due to damage caused by non-intended usage will not be accepted
• All damage caused by non-intended usage is solely the responsibility of the operator
1.6.1 Symbols and warnings on the device
Decal Explanation
DANGER
RISK OF ELECTRIC
SHOCK
Disconnect all sources of
supply prior to servicing.
!This warning is primarily related to the reconguration of the device on the DC termi-
nal which, for safety reasons, requires to also cut the device from AC (external main
switch). The same applies to disconnection and reconnection of the AC terminal.
Capacitors on DC, stor-
ing voltage! Discharge
for 10 sec then ground
before working.
DANGER
!Even after disconnection of the DC terminal from an external source there can still be
dangerous voltage potential present between the DC terminal poles and/or between
DC and the enclosure. For safety reasons the DC terminal must be short-circuited
after the capacitors have been discharged and it must also be grounded, i. e. con-
nected to PE.
WARNING
ELECTRICAL
HAZARDS
Authorized personnel
only.
!There can always be a voltage potential on metallic, openly touchable parts on
electrical devices, though the voltage level may not be hazardous. Caution is still
advisable, as these potential can still cause mild electrical shocks or sparking.
WARNING
Read and understand the operat-
ing guide before using this device.
Non-adherence of the instructions
in the operating guide can result
in serious injury or death.
!This is valid for any use of the device.

© EA Elektro-Automatik in 2023, this information is subject to change without notice 801123000_manual_pub_10000_4u_30kw_en_01
1.7 Safety
1.7.1 Safety notices
Mortal danger - Hazardous voltage
• Electrical equipment operation means that some parts accessible on the outside of the device can be
under high voltage. Therefore all parts under voltage must be covered during operation! This basically
applies to all models, except for the 10 V and 60 V models according to SELV.
• The DC terminal is isolated from the AC input and not connected to ground internally. Hence there can
be dangerous potential between the DC poles and PE, for instance caused by a connected external
source application. Due to charged capacitors this could even be true if the DC output or the device
are already switched off.
• Do not insert any object, particularly metallic, through the ventilator slots!
• For every reconguration on the AC or DC connectors, specically those which can have a dangerous
voltage potential, the device must be cut completely from the AC supply (main switch on the distant
end of the AC cable); it doesn’t suce to only use the power switch on the front
• Always follow 5 safety rules when working with electric devices:
• Disconnect completely
• Secure against reconnection
• Verify that the system is dead
• Carry out earthing and short-circuiting
• Provide protection from adjacent live parts
• Avoid any use of liquids near the equipment. Protect the device from wet, damp and condensation.
• Do not connect external power sources with reversed polarity to the DC terminal! The equipment will be
damaged, even when completely powered off.
• Never connect external power sources to the DC terminal that can generate a higher voltage than the
rated voltage of the device!
• Never insert a network cable which is connected to Ethernet or its components into the master-slave
sockets on the rear side of the device!
• The equipment must only be used as intended
• The equipment is only approved for use within the connection limits stated on the product label.
• ESD regulations must be applied when plugging interface cards or modules into the relative slot
• Interface cards or modules may only be attached or removed after the device is switched off. It’s not
necessary to open the device.
• Always congure the various protecting features against overcurrent, overvoltage etc. for sensitive loads
to what the target application requires!
• When operating the device as electronic load: always make sure that the energy recovery can feed back
the inverted energy and that it does not switch to isolated operation. For situations of isolated operation
a supervision device (grid protection) has to be installed
• It’s not allowed to run the device on AC sources such as generators or UPS equipment. It must only be
connected to a power grid!

© EA Elektro-Automatik in 2023, this information is subject to change without notice 901123000_manual_pub_10000_4u_30kw_en_01
1.7.2 Responsibility of the operator
Operator is any natural or legal person who uses the equipment or delegates the usage to a third party, and is responsible
during its usage for the safety of the user, other personnel or third parties.
The equipment is in industrial operation. Therefore the operators are governed by the legal safety regulations. Alongside the
warning and safety notices in this manual the relevant safety, accident prevention and environmental regulations must also
be applied. In particular the operator has to
• be acquainted with the relevant job safety requirements
• identify other possible dangers arising from the specic usage conditions at the work station via a risk assessment
• introduce the necessary steps in the operating procedures for the local conditions
• regularly control that the operating procedures are current
• update the operating procedures where necessary to reect changes in regulation, standards or operating conditions.
• dene clearly and unambiguously the responsibilities for operation, maintenance and cleaning of the equipment.
• ensure that all employees who use the equipment have read and understood the manual. Furthermore the users are to be
regularly schooled in working with the equipment and the possible dangers.
• provide all personnel who work with the equipment with the designated and recommended safety equipment
Furthermore, the operator is responsible for ensuring that the device is at all times technically t for use.
1.7.3 Requirements to the user
Any activity with equipment of this type may only be performed by persons who are able to work correctly and reliably and
satisfy the requirements of the job.
• Persons whose reaction capability is negatively inuenced by e.g. drugs, alcohol or medication may not operate the equipment.
• Age or job related regulations valid at the operating site must always be applied.
Danger for unqualied users
Improper operation can cause person or object damage. Only persons who have the necessary train-
ing, knowledge and experience may use the equipment.
The group of people allowed to operate the equipment is additionally limited to:
Delegated persons: these are persons who have been properly and demonstrably instructed in their tasks and the attendant
dangers.
Qualied persons: these are persons who are able through training, knowledge and experience as well as knowledge of the
specic details to carry out all the required tasks, identify dangers and avoid personal and other risks.
1.7.4 Responsibility of the user
The equipment is in industrial operation. Therefore the operators are governed by the legal safety regulations. Alongside the
warning and safety notices in this manual the relevant safety, accident prevention and environmental regulations must also
be applied. In particular the users of the equipment:
• must be informed of the relevant job safety requirements
• must work to the dened responsibilities for operation, maintenance and cleaning of the equipment
• before starting work must have read and understood the operating manual

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1001123000_manual_pub_10000_4u_30kw_en_01
1.7.5 Alarm signals
The equipment offers various possibilities for signaling alarm conditions, however, not for danger situations. The signals
are optical (via an LED on the control panel), electronic (status output of the analog interface) and digitally readable status
bits. All alarms will cause the device to switch off the DC terminal. For details about the different alarms refer to section «3.4
Alarm conditions» .
The meaning of the signals is as follows:
Signal OT
(OverTemperature)
• Overheating of the device
• DC terminal will be switched off
• Non-critical
Signal OVP / SOVP
(OverVoltage)
• Overvoltage shutdown of the DC terminal due to high voltage entering the device or generated by
the device itself due to a defect
• Critical! The device and/or the load could be damaged
Signal OCP
(OverCurrent)
• Shutdown of the DC terminal due to excess of the preset limit
• Non-critical, protects the load or source from excessive current consumption
Signal OPP
(OverPower)
• Shutdown of the DC terminal due to excess of the preset limit
• Non-critical, protects the load or source from excessive power consumption
Signal PF
(Power Fail)
• DC terminal shutdown due to AC undervoltage or defect in the AC section
• Critical on overvoltage! AC section could be damaged
Signal MSP
(Master-Slave Pro-
tection)
• DC terminal shutdown due to communication problems on the master-slave bus
• Non-critical
Signal SF
(Share Bus Fail)
• DC terminal shutdown due to signal distortion on the Share bus
• Non-critical
1.7.6 Functionality test
The operator of the device must decide when to check the device for correct functionality, by whom and how often. The
when could either be before every use or after it has been relocated or recongured or perhaps in a dened interval.
Should the set values not be adjustable as instructed below it could simply be due to adjustment limits
interfering. When reaching a limit adjusting value can’t be signaled by the device. In remote control an
invalid value would be rejected, together with an error message.
The test procedure would always be like this:
1. Disconnect all cables (DC, Sense, Share bus, analog interface, USB), except for AC.
2. Connect a suitable voltage meter to the DC terminal.
3. Switch the device on. Adjust a voltage of 10% UNom using remote control via the front or rear USB port while the current
and power set values for source mode should be at maximum and those for sink mode at 0. Then switch the DC output
on and verify with the multimeter that the adjusted voltage is available on the DC terminal. Also compare it to the actual
voltage value read via remote command query.
4. Repeat the same thing at 100% UNom.
5. Switch the DC output off and bridge the DC terminal with a cable or copper rails of suitable current capability of at least
INom. If available, put a current measuring device (transducer, current probe).
6. Adjust the current for source mode to 10% INom, switch the DC output on and measure the current with the external
measuring device, if available, and compare to the actual current measured by the device which can be read via remote
query command or at least compare the read actual current with the set value.
7. Repeat the same thing at 100% INom.
Only if the current and voltage are supplied by the device as adjustable in the range of 0-100% FS, the device can be consid-
ered as correctly operational.

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1101123000_manual_pub_10000_4u_30kw_en_01
1.8 Technical Data
1.8.1 Approved operating conditions
1. 8 .1.1 Ambiance
The allowed ambient temperature range for operation is 0 °C (32 °F) to 50 °C (122 °F). During storage or transport, the al-
lowed range extends to -20 °C (-4 °F) to 70 °C (158 °F). In case water condensation occurred due to transport, the device
must be acclimatized prior to operation for at least 2 hours, ideally in a place with good air circulation.
The device is intended to be operation in dry rooms. It must not be exposed or operated to extreme dust, high air humidity,
danger of explosion and aggressive chemicals polluting the air. The operating position isn’t arbitrary (see «2.3.3 Installing
the device» ),but in any case it requires a sucient air circulation. The device is allowed to be operated in altitude up to 2000
m (approx. 6,560 ft) above sea level. Technical specications (here: ratings), when given with tolerance, are valid for a unit
warmed up for at least 30 minutes and for an ambient temperature of 23 °C (73 °F). Specications without tolerance are
typical values from an average device.
1.8.1.2 Cooling
Power dissipated inside the device heats up air circulating through the device. With the air-cooled versions a fan at the end
of an air ow channel,in which a cooling block is placed, pulls the air through the device. Entry is on the front, exhaust at the
back. Depending on the internal temperature, the fan speed is automatically regulated up or down, whereas a certain mini-
mum speed is maintained because some internal components even heat up when the device is idle.
Dust in the air can obstruct the air ow with time, thus it’s important to keep the air ow unimpeded at least outside of the
device be leaving sucient room behind it. Since it’s usually installed inside cabinets, the cabinet doors are required to be
meshed.
At the same time, the ambient temperature should be kept at low levels, perhaps by external means such as an air condition.
Should the device heat up internally and the cooling block temperature exceed 80 °C (160 °F), the device will protect itself
from overheating by automatically switching off the power stage. It could then only continue to operate and switch the power
stage on again after cooling down for some time.
For the water-cooled versions, water is the main cooling agent, owing through the internal cooling blocks. The air inside the
almost hermetically body circulates, engaged by fans, to cool the remaining components not sitting on the cooling blocks,
but heat up over time.
1.8.2 General technical data
Display: 6 LED with different colors
Controls: 1 pushbutton

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1201123000_manual_pub_10000_4u_30kw_en_01
1.8.3 Specic technical data
General speci cations
AC input
Voltage, Phases 380 V - 480 V ±10%, 3ph AC (208 V - 240 V ±10%, 3ph AC with derating to 18 kW)
Frequency 45 - 65 Hz
Power factor ca. 0.99
Leakage current <10 mA
Phase current ≤56 A @ 400 V AC
Overvoltage category 2
DC output static
Load regulation CV ≤0.05% FS (0 - 100% load, constant AC input voltage and constant temperature)
Line regulation CV
≤0.01% FS
(380 V - 480 V +10% AC input voltage, constant load and constant temperature)
Stability CV ≤0.02% FS (during 8 h of operation, after 30 minutes warm-up, at constant AC input voltage, load and temperature)
Temperature coeffi cient CV ≤30ppm/°C (after 30 minutes of warm-up)
Compensation (remote sense) ≤5% UNominal
Load regulation CC ≤0.1% FS (0 - 100% load, constant AC input voltage and constant temperature)
Line regulation CC ≤0.01% FS (380 V - 480 V +10% AC input voltage, constant load and constant temperature)
Stability CC ≤0.02% FS (during 8 h of operation, after 30 minutes warm-up, at constant AC input voltage, load and temperature)
Temperature coeffi cient CC ≤50ppm/°C (after 30 minutes of warm-up)
Load regulation CP ≤0.3% FS (0 - 100% load, constant AC input voltage and constant temperature)
Load regulation CR ≤0.3% FS + 0.1% FS current (0 - 100% load, constant AC input voltage and constant temperature)
Protective functions
OVP Overvoltage protection, adjustable 0 - 110% UNominal
OCP Overcurrent protection, adjustable 0 - 110% INominal
OPP Overpower protection, adjustable 0 - 110% PNominal
OT Overtemperature protection (DC output shuts down in case of insuffi cient cooling)
DC output dynamic
Rise time 10 - 90% CV ≤10 ms
Fall time 90 - 10% CV ≤10 ms
Rise time 10 - 90% CC ≤2 ms
Fall time 90 - 10% CC ≤2 ms
Insulation
AC input to DC output 3750 Vrms (1 minute, creepage distance >8 mm)
AC input to case (PE) 2500 Vrms
DC output to case (PE) Depending on the model, see model tables
DC output to interfaces 1000 V DC (models up to 360 V output), 1500 V DC (models from 500 V output)
Interfaces digital
Built-in, galvanically isolated USB, Ethernet (100 MBit), USB front panel, all for communication
Optional, galvanically isolated CAN, CANopen, RS232, ModBus TCP, Profi net, Profi bus, EtherCAT, Ethernet
Interfaces analog
Built-in, galvanically isolated 15 pole D-Sub
Signal range 0 - 10 V or 0 - 5 V (switchable)
Inputs U, I, P, R, remote control on/off, DC output on/off, resistance mode on/off
Outputs Monitor U and I, alarms, reference voltage, DC output status, CV/CC regulation mode
Accuracy U / I / P / R 0 - 10 V: ≤0.2%, 0 - 5 V: ≤0.4%
Device con guration
Parallel operation Up to 64 units of any power class in series 10000 start from 5 kW, with Master-Slave-Bus and Share-Bus

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1301123000_manual_pub_10000_4u_30kw_en_01
General speci cations
Safety and EMC
Safety
EN 61010-1
IEC 61010-1
UL 61010-1
CSA C22.2 No 61010-1
BS EN 61010-1
EMC
EN 55011, class A
CISPR 11, class A
FCC 47 CFR part 15B, unintentional radiator, class A
EN 61326-1 include tests according to:
- EN 61000-4-2
- EN 61000-4-3
- EN 61000-4-4
- EN 61000-4-5
- EN 61000-4-6
Safety protection class 1
Ingress Protection IP20
Environmental conditions
Operating temperature 0 - 50 °C (32 - 122 °F)
Storage temperature -20 - 70 °C (-4 - 158 °F)
Humidity ≤80% relative humidity, non-condensing
Altitude ≤2000 m (≤6,600 ft)
Pollution degree 2
Mechanical construction
Cooling Forced air fl ow from front to rear (temperature controlled fans), optional water cooling
Dimensions (W x H x D) Enclosure: 19“ x 4U x 668 mm (26.3 in)
Weight 50 kg (110 lb)
Weight with water cooling 56 kg (126 lb)

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1401123000_manual_pub_10000_4u_30kw_en_01
Technical speci cations PUB 10060-1000 PUB 10080-1000 PUB 10200-420 PUB 10360-240 PUB 10500-180
DC output
Voltage range 0 - 60 V 0 - 80 V 0 - 200 V 0 - 360 V 0 - 500 V
Ripple in CV (rms) ≤25 mV (BW 300 kHz) ≤25 mV (BW 300 kHz) ≤40 mV (BW 300 kHz) ≤55 mV (BW 300 kHz) ≤70 mV (BW 300 kHz)
Ripple in CV (pp) ≤320 mV (BW 20 MHz) ≤320 mV (BW 20 MHz) ≤300 mV (BW 20 MHz) ≤320 mV (BW 20 MHz) ≤350 mV (BW 20 MHz)
UMin for IMax (sink) 0.62 V 0.62 V 1.8 V 2.5 V 1.1 V
Current range 0 - 1000 A 0 - 1000 A 0 - 420 A 0 - 240 A 0 - 180 A
Power range 0 - 30000 W 0 - 30000 W 0 - 30000 W 0 - 30000 W 0 - 30000 W
Resistance range 0.003 Ω - 5 Ω 0.003 Ω - 5 Ω 0.0165 Ω - 25 Ω 0.05 Ω - 90 Ω 0.08 Ω - 170 Ω
Output capacitance 25380 μF 25380 μF 5400 μF 1800 μF 675 μF
Effi ciency sink/source (up to) 95.1% *1 95.5% *1 95.3% *1 95.8% *1 96.5% *1
Insulation
Negative DC pole <-> PE ±600 V DC ±600 V DC ±1000 V DC ±1000 V DC ±1500 V DC
Positive DC pole <-> PE +600 V DC +600 V DC +1000 V DC +1000 V DC +2000 V DC
Article numbers
Standard 01123001 01123002 01123003 01123004 01123005
Standard + Water Cooling 01543001 01543002 01543003 01543004 01543005
Technical speci cations PUB 10750-120 PUB 10920-125 PUB 11000-80 PUB 11500-60 PUB 12000-40
DC output
Voltage range 0 - 750 V 0 - 920 V 0 - 1000 V 0 - 1500 V 0 - 2000 V
Ripple in CV (rms) ≤200 mV (BW 300 kHz) ≤250 mV (BW 300 kHz) ≤300 mV (BW 300 kHz) ≤400 mV (BW 300 kHz) ≤500 mV (BW 300 kHz)
Ripple in CV (pp) ≤800 mV (BW 20 MHz) ≤1200 mV (BW 20 MHz) ≤1600 mV (BW 20 MHz) ≤2400 mV (BW 20 MHz) ≤3000 mV (BW 20 MHz)
UMin for IMax (sink) 1.2 V 2 V 3.4 V 3.2 V 3.7 V
Current range 0 - 120 A 0 - 125 A 0 - 80 A 0 - 60 A 0 - 40 A
Power range 0 - 30000 W 0 - 30000 W 0 - 30000 W 0 - 30000 W 0 - 30000 W
Resistance range 0.2 Ω - 370 Ω 0.25 Ω - 550 Ω 0.4 Ω - 650 Ω 0.8 Ω - 1500 Ω 1.7 Ω - 2700 Ω
Output capacitance 450 μF 100 μF 200 μF 75 μF 50 μF
Effi ciency sink/source (up to) 96.5% *1 96.5% *1 95.8% *1 96.5% *1 96.5% *1
Insulation
Negative DC pole <-> PE ±1500 V DC ±1500 V DC ±1500 V DC ±1500 V DC ±1500 V DC
Positive DC pole <-> PE +2000 V DC +2000 V DC +2000 V DC +2000 V DC +2000 V DC
Article numbers
Standard 01123006 01123007 01123008 01123009 01123010
Standard + Water Cooling 01543006 01543007 01543008 01543009 01543010
*1 At 100% power and 100% output voltage
*1 At 100% power and 100% output voltage

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1501123000_manual_pub_10000_4u_30kw_en_01
1.8.4 Views
1.8.4.1 Technical drawings PUB 10000 4U ≤200 V
Side view of the air-cooled version shown

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1601123000_manual_pub_10000_4u_30kw_en_01
1.8.4.2 Front panel description PUB 10000 4U
1.8.4.3 Rear panel description PUB 10000 4U <200 V
1. DC on/off pushbutton
2. LED status display
3. USB interface
1. Master-Slave bus connectors to set up a system for parallel connection
2. Slot for interfaces
3. Remote sense connectors
4. Share bus connectors to set up a system for parallel connection
5. DC output connector (copper blades)
6. AC input connector
7. Grounding connection screw (PE)
8. Connector (DB15 female) for isolated analog programming, monitoring and other functions
9. USB interface
10. Ethernet interface

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1701123000_manual_pub_10000_4u_30kw_en_01
1.8.4.4 Technical drawings PUB 10000 4U ≥360 V
Side view of the air-cooled version shown

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1801123000_manual_pub_10000_4u_30kw_en_01
1.8.4.5 Front panel description PUB 10000 4U
1.8.4.6 Rear panel description PUB 10000 4U >360 V
1. DC on/off pushbutton
2. LED status display
3. USB interface
1. Master-Slave bus connectors to set up a system for parallel connection
2. Slot for interfaces
3. Remote sense connectors
4. Share bus connectors to set up a system for parallel connection
5. DC output connector (copper blades)
6. AC input connector
7. Grounding connection screw (PE)
8. Connector (DB15 female) for isolated analog programming, monitoring and other functions
9. USB interface
10. Ethernet interface

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1901123000_manual_pub_10000_4u_30kw_en_01
1.8.4.7 Front panel description PUB 10000 4U with Water Cooling option
1.8.4.8 Rear panel description PUB 10000 4U with Water Cooling option
1. DC on/off pushbutton
2. LED status display
3. USB interface
1. Master-Slave bus connectors to set up a system for parallel connection
2. Slot for interfaces
3. Remote sense connectors
4. Share bus connectors to set up a system for parallel connection
5. Inlets and outlets for water-cooling
6. DC output terminal (copper blades)
7. AC input connector
8. Grounding connection screw (PE)
9. Connector (DB15 female) for isolated analog programming, monitoring and other functions
10. USB interface
11. Ethernet interface

© EA Elektro-Automatik in 2023, this information is subject to change without notice 2001123000_manual_pub_10000_4u_30kw_en_01
1.8.5 Control elements
Figure 1- Control Panel
Overview of the elements on the control panel
For a detailed description see section «1.9.6 The control panel (HMI)».
(1)
On/Off button
Can be used to switch the DC output on or off during manual operation, while LED “Remote” is off
Pin REM-SB on the analog interface, when set to a logical level which would request to turn DC off,
can block switching DC on by this pushbutton.
(2)
USB port
For quick and easy access to the most important DC output related values when the device isn’t in master-slave
mode. This port has reduced functionality compared to the rear port.
(3) Status indicators (LED)
These six color LEDs show the device status.
