elero Combio-868 LI Specification sheet

181110703_EN_0319
Combio-868 LI
285630006
Information for use
Keep for future use.

2 | EN Ⓒ elero GmbH
Translation from the original German version.
All other documents in diff erent languages are transla-
tions of the original version.
All rights reserved in the event case of patent, utility
model or design registrations.

Ⓒ elero GmbH EN | 3
Contents
1 Introduction 4
1.1 Manufacturer contact details 4
1.2 Symbols and warnings 5
2 Safety instructions 5
2.1 Target group 5
2.2 Intended use 5
2.3 Warranty 6
3 System description 6
3.1 Application area 6
3.2 Terminal connection diagram 7
4 Technical data 8
5 Preparation 9
5.1 Product contents 9
5.2 Packaging 9
5.3 Settings 9
5.4 Connection and installation 9
5.5 Commissioning 11
5.6 Diagram of programming mode 11
5.7 Asynchronous programming mode (standard) 12
5.8 Synchronous programming mode 14
6 General control options 17
6.1 Adapting an illuminant 18
6.2 Deleting the programmed handheld/
wall-mounted transmitter 20
7 Servicing 21
7.1 Cleaning 21
7.2 Maintenance 21
7.3 General notes on troubleshooting 21
7.4 Repairs 23
8 Decommissioning and disposal 23
8.1 Disassembly 23
8.2 Disposal 24
9 Certifi cation and imprint 24
9.1 EU Declaration of Conformity 24
9.2 Legal Disclosure 24

4 | EN Ⓒ elero GmbH
1 Introduction
This user manual describes the functions and features
of the Combio-868 LI system. Combio-868 LI enables
appropriate illuminants to switched and dimmed. Appro-
priate illuminants are as follows:
• standard light bulbs
• high-voltage halogen light bulbs
• low-voltage light bulbs with electronic transformer
• LED light bulbs with a suitable electronic dimmer
(ECG, electronic control gear)
An elero handheld/wall-mounted transmitter (at least 1)
is also required. The Combio-868 LI can be controlled
by several transmitters.
Follow the instructions in these manuals to ensure
proper and safe use.
Retain for future use.
1.1 Manufacturer contact details
elero GmbH
Maybachstr. 30
73278 Schlierbach - Germany
Telephone: [phone]
Email: [email protected]
Website: www.elero.de

Ⓒ elero GmbH EN | 5
1.2 Symbols and warnings
This user manual uses the following illustrations to
display important warnings:
WARNING
Danger with a medium level of risk, possibly
resulting in death or serious injury.
ATTENTION
Danger, possibly resulting in damage to property.
2 Safety instructions
2.1 Target group
This document is primarily intended for use by electrici-
ans, technicians and engineers with experience in the
design, installation, commissioning and maintenance of
building technology.
2.2 Intended use
This product is for private use only. It is intended only for
the switching and/or dimming of suitable illuminants for
use in dry rooms.
The Combio-868 LI is designed for installation in dry
cavities in buildings. Do not perform any modifi cations to
the device. The manufacturer will not assume liability for
damage caused by the above.
Do not operate a programmed transmitter inadvertently
or carelessly.

6 | EN Ⓒ elero GmbH
2.3 Warranty
• The warranty period for Combio-868 LI is in
accordance with the legal regulations. Damages
caused due to improper use are excluded.
• Never open the device without authorisation. Opening
the housing renders the warranty null and void.
• No warranty claims may be made for damage caused
to the Combio-868 LI due to improper operation resul-
ting from non-observance of the operating instructions
or due to a disregard of these instructions.
• No liability shall be accepted for consequential damages.
3 System description
3.1 Application area
Combio-868 LI enables the switching and dimming of
suitable illuminants in combination with elero hand-held/
wall-mounted transmitters.

Ⓒ elero GmbH EN | 7
3.2 Terminal connection diagram
Connection diagram with/without ballast
Combio-868 LI
antenna
green-
yellow
blue (N)
brown L
PE
N power grid
blue (N)
green-
yellow
brown L
Combio-868 LI
antenna
green-
yellow
blue (N)
brown L
PE
N power grid
blue (N)
green-
yellow
ECG
electronic
control gear
brown L
The Combio-868 LI is supplied with 230V AC via
spring clips.
Designation Assignment
L Exterior conductor (brown)
N Neutral conductor (blue)
PE Protective conductor
(yellow/green)
The illuminants that are connected are powered
and activated via suitable clips by means of
same-coloured connections.
R, C

8 | EN Ⓒ elero GmbH
4 Technical data
Technical data
Power supply 230 V, 50 Hz
Power (load designation R = ohmic
load, C = capacitive load)
max. 100 W
Stand-by power consumption < 0.5 W
Nominal current of lighting clamps max. 0.5 A
Ingress protection IP 56
Protection class II
Software class A
Operating temperature -20 ... 65 °C
Relative air humidity 0 ... 95%
Max. usage altitude 2000 m over NHN
Network cable length 3 m
Number of maximum transmitters 16
Radio frequency 868 MHz
(frequency band)
Resistance to short-circuiting guaranteed
Soft start maximum 1 s
Dimming time maximum 5 s
Dimensions of housing (L x W x H) 98 x 41 x 16 mm
Weight with cable approx. 350 g
Type of mounting Screws / glued
Conformity CE (FCC / IC)
Item number 285630006

Ⓒ elero GmbH EN | 9
5 Preparation
5.1 Product contents
Designation Fig.
Combio-868 LI
Article no. 285630006
User manual
Article no. 181110703
Retain for future use.
5.2 Packaging
Packaging is designed for protection of the Combio-868
LI during transport. After unpacking, please check all
components delivered for completeness or damage.
5.3 Settings
The equipment is set via the elero handheld/wall-moun-
ted transmitter following the electrical connection.
5.4 Connection and installation
WARNING
Risk of injury, damage to the Combio-868 LI
and its surrounding area due to improper
electrical connections.

10 | EN Ⓒ elero GmbH
WARNING
• The electrical connection may only be conducted by
qualifi ed personnel.
• Only perform work on the electrical connection if it
has been disconnected from the power supply.
• Note the technical data for the device.
• Take care to ensure correct, securely affi xed
connections.
• The Combio-868 LI must be installed in a dust-free
and dry environment.
• Screw the Combio-868 LI to the surface by means
of the ring lug using a suitable screw.
• Affi x the Combio-868 LI using a self-adherent
foam strip.
• Do not kink, shorten or extend the external antenna of
the Combio-868 LI, route it as free from obstruction as
possible. Do not lay it against metal. Realign it in case
of poor reception.
ATTENTION
Replacing components of the Combio-868 LI with
third party components may damage these com-
ponents or other connected systems.
• Exchange components between diff erent systems
only after consultation with the manufacturer or
your supplier.
• When replacing a component, check whether the
type description of the new component matches
the one being replaced.

Ⓒ elero GmbH EN | 11
5.5 Commissioning
The elero handheld/wall-mounted transmitter has to be
programmed to the Combio-868 LI radio receiver.
The functions of the Combio-868 LI are controlled using
the buttons [OPEN ▲], [STOP ■], [DOWN/CLOSE ▼],
programming button [P] and the slider of the handheld/
wall-mounted transmitter.
The + sign in the text indicates pressing the buttons
simultaneously.
5.6 Diagram of programming mode
During the programming
phase, press the DOWN/
CLOSE button
Light OFF
(random duration)
Light OFF
(random duration)
Light ON 30%
(3 s)
Light ON 100%
(3 s)
Light ON 30%
2 s = programming
phase
Light ON 100%
2 s = programming
phase
During the programming
phase, press the
OPEN button
Duration
2 min.

12 | EN Ⓒ elero GmbH
5.7 Asynchronous programming mode
(standard)
Asynchronous programming mode is the standard pro-
gramming mode. In asynchronous programming mode,
the switch-on duration of the ON times vary in case of
several receivers. After a few ON/OFF cycles, the illu-
minants of the receivers will no longer light up synchro-
nously. This will enable the hits for a certain receiver to
be set better.
Asynchronous programming mode is suitable for
• programming the fi rst transmitter
• programming an additional transmitter
• programming individual receivers in case of several
receivers ready for programming (e.g. several
receivers using one fuse).
Asynchronous programming mode (standard)
Operating procedure Result
1 Activate asynchronous
programming standby:
Switch the mains voltage
off and on again or press
the buttons [OPEN ▲] +
[DOWN/CLOSE ▼] + [P]
simultaneously and hold
them down for 3 seconds
on a transmitter that has
already been programmed.
The receiver changes to
asynchronous program-
ming standby for 5 minu-
tes. Ready to receive the
programming button [P].

Ⓒ elero GmbH EN | 13
Asynchronous programming mode (standard)
2 Start programming mode:
Press the [P] programming
button for approx. 1 second.
Combio-868 LI changes
to asynchronous program-
ming mode and the light
source begins to change
intensity (between 100%
and 30%) periodically.
3Set fi rst hit:
Immediately after the light
source lights up, push
the [OPEN ▲] button or
[DOWN/CLOSE ▼].
• If luminous intensity is
high (100%) press the
[OPEN ▲] button.
• If luminous intensity is
low (30%) press the
[DOWN/CLOSE ▼]
button.
Hit successful:
The light source goes out
briefl y.
Hit failed:
The light source does not
go out. → repeat action
"Set fi rst hit"!
4 Set second hit:
Prerequisite:
First hit has been set.
Immediately after the light
source with the opposin-
gintensity lights up, push
the [OPEN ▲] button or
[DOWN/CLOSE ▼].
• If luminous intensity is
high (100%) press the
[OPEN ▲] button.
• If luminous intensity is
low (30%) press the
[DOWN/CLOSE ▼]
button.
Hit successful:
The light source goes out
permanently and indica-
tes that the programming
procedure is over.
Hit failed:
The light source does not
go out. → repeat action in
"Set second hit"!

14 | EN Ⓒ elero GmbH
• Programming can only ever be performed in one
selected channel.
• When programming is complete or after 5 minutes has
passed, the receiver will revert to normal operation.
• Programming mode can be stopped by pressing the
[STOP ■] button for at least 6 seconds.
• Up to 16 transmitters can be programmed.
• Several receivers can be programmed to one channel.
• If more than 10 receivers at once are in programming
mode, the transmitter changes to group program-
ming mode. Once programming is complete, group
programming mode has to be terminated manually in
the transmitter by pressing the [STOP ■] button for at
least 6 seconds.
5.8 Synchronous programming mode
Synchronous programming mode is a special program-
ming mode. In synchronous programming mode, the
switch-on duration of the ON times will be constant with
several receivers. Even after a few ON/OFF cycles, the
illuminants of the receivers will light up synchronously.
As a result, the hits for all participating receivers can be
set simultaneously.
Synchronous programming mode is suitable for
• programming an additional transmitter
• programming several receivers simultaneously to one
transmitter or one channel.

Ⓒ elero GmbH EN | 15
Synchronous programming mode
Operating procedure Result
1 Activate synchronous pro-
gramming standby:
Press the buttons [DOWN/
CLOSE ▼] + [P ] simulta-
neously on a transmitter
that has already been pro-
grammed and hold them
down for 3 seconds.
The receiver changes to
synchronous programming
standby for 5 minutes.
Ready to receive the
programming button [P].
2 Start programming mode:
Press the [P] programming
button for approx. 1 second.
Combio-868 LI changes to
synchronous programming
mode and the light source
begins to change intensity
(between 100% and 30%)
periodically.
3Set fi rst hit:
Immediately after the light
source lights up, push
the [OPEN ▲] button or
[DOWN/CLOSE ▼].
• If luminous intensity is
high (100%), press the
button [OPEN ▲].
• If luminous intensity is
low (30%), press the but-
ton [DOWN/CLOSE ▼].
Hit successful:
The light source goes
out briefl y.
Hit failed:
The light source does not
go out. → repeat action
"Set fi rst hit"!

16 | EN Ⓒ elero GmbH
Synchronous programming mode
4 Set second hit:
Prerequisite:
First hit has been set.
Immediately after the light
source with the opposin-
gintensity lights up, push
the [OPEN ▲] button or
[DOWN/CLOSE ▼].
• If luminous intensity is
high (100%) press the
[OPEN ▲] button.
• If luminous intensity is
low (30%) press the
[DOWN/CLOSE ▼]
button.
Hit successful:
The light source goes out
permanently and indica-
tes that the programming
procedure is over.
Hit failed:
The light source does not
go out. → repeat action in
"Set second hit"!
• Programming can only ever be performed in one
selected channel.
• When programming is complete or after 5 minutes has
passed, the receiver will revert to normal operation.
• Programming mode can be stopped by pressing the
[STOP ■] button for at least 6 seconds.
• Up to 16 transmitters can be programmed.
• Several receivers can be programmed to one channel.
• If more than 10 receivers at once are in programming
mode, the transmitter changes to group program-
ming mode. Once programming is complete, group
programming mode has to be terminated manually in
the transmitter by pressing the [STOP ■] button for at
least 6 seconds.

Ⓒ elero GmbH EN | 17
6 General control options
General control options
Key combination Press Action
[OPEN ▲]
Short
Light source is off :
Set the last brightness
value
Light source is on:
Reduce dimming slightly
[OPEN ▲] Long Reduce dimming
[OPEN ▲] 2 x short
Set maximum user-defi ned
brightness value
(Standard: 100%)
[DOWN/CLOSE ▼] Short
Light source is off :
Set the last brightness
value.
Light source is on:
Increase dimming slightly.
[DOWN/CLOSE ▼] Long Increase dimming
[DOWN/CLOSE ▼] 2 x short Set lowest user-defi ned
brightness value
(Standard: 10%)
[STOP ■] Short Switch off light source
[UP ▲] + [STOP ■]
Short
Save current brightness
value as the maximum
user-defi ned brightness
value
[UP ▲] + [STOP ■] Longer
than 6
seconds
Delete maximum user-de-
fi ned brightness value and
restore standard value

18 | EN Ⓒ elero GmbH
General control options
[DOWN/
CLOSE ▼] +
[STOP ■]
Short
Save current brightness
value as the lowest
user-defi ned brightness
value
[DOWN/
CLOSE ▼] +
[STOP ■]
Longer
than 6 se-
conds
Lowest maximum user-
defi ned brightness value
and standard value
Operation with MonoCom Slide / VarioCom Slide
Slider Action
Swipe up and hold Reduce dimming
Swipe down and hold Increase dimming
Let go of slider Dimming stops
6.1 Adapting an illuminant
The factory setting of the Combio-868 LI allows a power
setting between 10% and 100%. The power cannot be
set below 10%. Some illuminants require more than
10% of the power at the lowest operating limit. This
could lead to the illuminant not lighting up yet a low level
of current fl owing regardless. In such cases the absolute
lower dimming limit should be adapted to the illuminant.
When adapting an illuminant, the absolute lower
dimming limit can be set or this can be reset to the
factory setting (10%).
In addition the Combio-868 LI can also be confi gured as
a light switch.

Ⓒ elero GmbH EN | 19
Requirement for adapting an illuminant
Operating procedure Result
Activate adaptation
of illuminant:
Switch the mains voltage off
and on again or press the
buttons [STOP ■] + [OPEN ▲]
+ [P] and hold them down for
6 seconds on a transmitter that
has already been programmed.
Combio-868 LI changes to
illuminant adaptation mode
for 5 minutes. Within this
time, settings can be made
for the absolute lower
dimming limit.
Setting the absolute lower dimming limit
Operating procedure Result
1 Set lowest user-defi ned
brightness value:
Using the [OPEN ▲] +
[DOWN/CLOSE ▼] buttons,
set the desired brightness
value and then briefl y press
the [DOWN/CLOSE ▼]
buttons + [STOP ■] button.
The set brightness value
is saved as the lowest
user-defi ned brightness
value.
2 Set absolute lower
dimming limit:
Press the buttons [OPEN ▲]
+ [DOWN/CLOSE ▼] briefl y.
The illuminant goes out.
The lowest user-defi ned
brightness value is set
as the absolute lower
dimming limit.

20 | EN Ⓒ elero GmbH
Confi guring the Combio-868 LI as a light switch
Operating procedure Result
Press the buttons
[OPEN ▲] + [DOWN/
CLOSE ▼] for 3 seconds.
The illuminant lights up. The
absolute lower dimming limit
is set to 100%. Combio-868 LI
now functions as a light switch.
Dimming will no longer work.
Restoring the absolute lower dimming limit
Operating procedure Result
Press the buttons
[OPEN ▲] + [DOWN/
CLOSE ▼] for 6 seconds.
The illuminant goes out. The
absolute lower dimming limit
of 10% is restored.
6.2 Deleting the programmed handheld/
wall-mounted transmitter
Deleting a transmitter does not eff ect the brightness
values set. Deleting a transmitter will cause the factory
setting to be restored.
Deleting the handheld/wall-mounted transmitter
Operating procedure Result
Press the [STOP ■] + [P]
buttons for at least
6 seconds until the
status LED lights up red.
On the transmitter:
The selected channels are
deleted entirely.
On the receiver:
The individual transmitter
only is deleted from the
Combio-868 LI.
