ELGO Electronic EMIX23 series User manual

Operating Manual
SERIE EMIX23
Magnetic Linear Encoder with 0.001 mm resolution
Status LED available (see type designation)
Periodically index or reference pulse available (see type designation)
Direct and contactless measurement
Allowed distance between sensor and tape: 0.1 … 0.8 mm
Measurement lengths theoretically unlimited
Resolution 0.001 mm
Repeat accuracy +/- 1 increment
Very robust against dust and dirt
Speed proportional square wave outputs
799000127 / Rev. 3 / 2019-02-11
Translation of the original operating manual

- 2 -
Publisher
ELGO Electronic GmbH & Co. KG
Carl-Benz-Str. 1
D-78239 Rielasingen-Worblingen
Technical Support
[phone]
[phone]
[email protected]
Document- No.
799000127
Document- Name
EMIX23-000-MA-E_07-19
Document- Revision
Rev. 3
Issue Date
2019-02-11
Copyright
© 2019, ELGO Electronic GmbH & Co. KG

Contents
- 3 -
1Contents
1Contents................................................................................................................... 3
2Image Directory....................................................................................................... 4
3Table Directory ........................................................................................................ 4
4General, Safety, Transport and Storage ................................................................. 5
4.1 Information Operating Manual ........................................................................................................5
4.2 Explanation of Symbols...................................................................................................................5
4.3Statement of Warranties..................................................................................................................6
4.4 Demounting and Disposal...............................................................................................................6
4.5 General Causes of Risk...................................................................................................................6
4.6 Personal Protective Equipment .........................................................................................................6
4.7 Conventional Use ..........................................................................................................................7
4.8 Safety Instructions for Transport, Unpacking and Loading .....................................................................7
4.9 Handling of Packaging Material .......................................................................................................7
4.10 Inspection of Transport ...................................................................................................................7
4.11 Storage........................................................................................................................................7
5Product Features...................................................................................................... 8
5.1 Functional principle........................................................................................................................8
5.2 Pulse diagram ...............................................................................................................................8
6Technical Data ......................................................................................................... 9
6.1 Identification .................................................................................................................................9
6.2 Dimensions Sensor.........................................................................................................................9
6.3 Dimensions Guiding Profile FBK80 and End / Connection Profile AFBK80...............................................9
6.4 Technical Data Sensor..................................................................................................................10
6.5Technical Data Magnetic Tape.......................................................................................................11
7Installation and First Start-Up .............................................................................. 12
7.1 Operating Area ...........................................................................................................................12
7.2 Installation of the Magnetic Tape....................................................................................................13
7.3 Mounting of the Sensor.................................................................................................................18
8Connections ........................................................................................................... 21
8.1 Pin Assignments...........................................................................................................................21
9Disturbances, Maintenance, Cleaning .................................................................. 22
9.1 Fault Clearance...........................................................................................................................22
9.2 Re-start after Fault Clearance.........................................................................................................22
9.3 Maintenance...............................................................................................................................23
9.4 Cleaning ....................................................................................................................................23
10 Type Designation................................................................................................... 24
10.1 Type Designation EMIX23 .............................................................................................................24
10.2 Type Designation Magnetic Tape....................................................................................................25
10.3 Type Designation Guide Profile ......................................................................................................26
11 Index...................................................................................................................... 27

Contents
- 4 -
2Image Directory
Figure 1: Code of the Magnetic Tape ......................................................................................................... 8
Figure 2: Pulse Diagram............................................................................................................................ 8
Figure 3: Dimensions Sensor ..................................................................................................................... 9
Figure 4: Dimensions FBK80 ..................................................................................................................... 9
Figure 5: Dimensions AFBK80 ................................................................................................................. 10
Figure 6: Magnetic Tape Structure............................................................................................................ 13
Figure 7: Magnetic Tape with Option BK80 .............................................................................................. 14
Figure 8: Handling ................................................................................................................................. 14
Figure 9: Magnetic Tape Variants............................................................................................................. 17
Figure 10: Magnetic Tape Variants with FBK80 ......................................................................................... 17
Figure 11: Sensor Tolerances................................................................................................................... 18
Figure 12: Sensor - Mounting Options ..................................................................................................... 19
Figure 13: Installing Sensor and Tape....................................................................................................... 19
Figure 14: Mounting of FBK80 / AFBK80 ................................................................................................. 20
Figure 15: FBK80 on beams with different heights ..................................................................................... 20
Figure 16: FBK80 Drawing ...................................................................................................................... 26
3Table Directory
Table 1: Resistance against Chemical Influence......................................................................................... 16
Table 2: Tolerances EMIX23 .................................................................................................................... 18
Table 3: Pin assignment with open cable ends........................................................................................... 21
Table 4: Pin assignment of option D1 (ELGO standard assignment) ............................................................ 21
Table 5: Pin assignment of option D3 (round connector suitable for SKA-1) ................................................. 21

Contents
- 5 -
4General, Safety, Transport and Storage
4.1 Information Operating Manual
This manual contains important information regarding the handling of the device. For your own safety and operational safety, please ob-
serve all safety warnings and instructions. Precondition for safe operation is the compliance with the specified safety and handling instruc-
tions. Moreover, the existing local accident prevention regulations and the general safety rules at the site of operation have to be observed.
Please read the operating manual carefully before starting to work with the device! It is part of the product and should be kept close to the
device and accessible for the staff at any time. The illustrations in the manual are for better demonstration of the facts. They are not neces-
sarily to scale and can slightly differ from the actual design.
4.2 Explanation of Symbols
Special notes in this manual are characterized by symbols.
The notes are introduced by signal words which express the magnitude of danger.
Please follow this advice and act carefully in order to avoid accidents, damage, and injuries.
Warning notes:
DANGER!
This symbol in connection with the signal word “Danger” indicates an immediate danger for the life and health of
persons. Failure to heed these instructions can result in serious damage to health and even fatal injury.
WARNING!
This symbol in connection with the word „Warning” means a possibly impending danger for the life and health of
persons. Failure to heed these instructions can result in serious damage to health and even fatal injury.
CAUTION!
This symbol in connection with the signal word “Caution” indicates a possibly dangerous situation. Failure to heed
these instructions can lead to minor injuries or damage of property.
Special safety instructions:
DANGER!
This symbol in connection with the signal word “Danger” indicates an immediate danger for the life and health of
persons due to voltage.
Failure to heed these instructions can result in serious damage to health and even fatal injury. The operations may
only be carried out by a professional electrician.
Tips and recommendations:
NOTE!
…points out useful tips and recommendations as well as information for an efficient and trouble-free operation.
Reference marks:
Marks a reference to another chapter of this manual.
Marks a reference to another chapter of another document.

Contents
- 6 -
4.3 Statement of Warranties
The producer guarantees the functional capability of the process engineering and the selected parameters.
4.4 Demounting and Disposal
Unless acceptance and disposal of returned goods are agreed upon, demount the device considering the safety instructions of this manual
and dispose it with respect to the environment.
Before demounting,disconnect the power supply and secure against re-start. Then disconnect the supply lines physically and discharge
remaining energy. Remove operational supplies and other material.
Disposal: Recycle the decomposed elements: Metal components in scrap metal, Electronic components in electronic scrap, Recycle plastic
components, Dispose the remaining components according to their material consistence
CAUTION!
Wrong disposal causes environmental damages!
Electronic scrap, electronic components, lubricants and other auxiliary materials are subject to special refuse and can
only be disposed by authorized specialists!
Local authorities and waste management facilities provide information about environmentally sound disposal.
Safety
CAUTION!
Please read the operating manual carefully, before using the device! Observe the installation instructions! Only start
up the device if you have understood the operating manual. The operating company is obliged to take appropriate
safety measure.
The initial operation may only be performed by qualified and trained staff. Selection and installation of the devices as
well as their embedding into the controlling system require qualified knowledge of the applicable laws and normative
requirements on the part of the machine manufacturer.
4.5 General Causes of Risk
This chapter gives an overview of all important safety aspects to guarantee an optimal protection of employees and a safe and trouble-free
operation. Non-observance of the instructions mentioned in this operating manual can result in hazardous situations.
4.6 Personal Protective Equipment
Employees have to wear protective clothing during the installation of the device to minimize danger of health.
Therefore: Change into protective clothing before performing the works and wear them throughout the process. Additionally observe the
labels regarding protective clothing in the operating area.
Protective clothing:
PROTECTIVE CLOTHING
… is close-fitting working clothing with light tear strength, tight sleeves and without distant parts. It serves preliminari-
ly for protection against being gripped by flexible machine parts.
Do not wear rings, necklaces or other jewellery.
PROTECTIVE GLOVES
…for protecting the hands against abrasion, wear and other injury of the skin.
PROTECTIVE HELMET
…for protection against injuries of the head.

Contents
- 7 -
4.7 Conventional Use
The ELGO-device is only conceived for the conventional use described in this manual.
The EMIX23 - ELGO- length measuring system only serves to measure lengths.
CAUTION!
Danger through non-conventional use!
Non-intended use and non-observance of this operating manual can lead to dangerous situations.
Therefore:
Only use the device as described
Strictly follow the instructions of this manual
Avoid in particular:
Remodeling, refitting or changing of the construction or single components with the intention to alter the
functionality or scope of the device.
Claims resulting from damages due to non-conventional use are not possible.
Only the operator is liable for damages caused by non-conventional use.
4.8 Safety Instructions for Transport, Unpacking and Loading
CAUTION!
Transport the package (box, palette etc.) professionally.
Do not throw, hit or fold it.
4.9 Handling of Packaging Material
Notes for proper disposal: 4.4
4.10 Inspection of Transport
Check the delivery immediately after the receipt for completeness and transport damage.
In case of externally recognizable transport damages:
Do not accept the delivery or only accept under reserve.
Note the extent of damages on the transportation documents or delivery note.
File complaint immediately.
NOTE!
Claim any damage immediately after recognizing it. The claims for damage must be filed in the lawful reclaim peri-
ods.
4.11 Storage
Store the device only under the following conditions:
Do not store outside
Keep dry and dust-free
Do not expose to aggressive media
Protect from direct sun light
Avoid mechanical shocks
The storage temperature (6 Technical Data) needs to be observed
The relative humidity (6 Technical Data) must not be exceeded
Inspect packages regularly if stored for an extensive period of time (>3 months)

Product Features
- 8 -
5Product Features
The EMIX23 is an incremental magnetic length measuring system. The sensor technology and translator are
placed in the same housing. The magnetic tape is adhered to a flat base with the supplied adhesive tape. The
EMIX23 can be installed up to a maximum distance of 0.8 mm.
The measuring system offers decisive advantages:
Direct and contactless measurement
Distance range between sensor and tape: 0.1... 0.8 mm
Status LED for reading distance available (option only for version 5 VDC / 5 V-TTL)
Theoretically unlimited measurement length
High resolution of 0.001 mm
Repeat accuracy +/- 0.004 mm
Very robust against dust and dirt
Definable reference pulse (option)
Signal output with channels A, A´, B, B´, Z, Z´.
5.1 Functional principle
The basis of the magnetic incremental encoder consists of a scanning technology, which scans the north and
south poles on the coded magnetic tape and produces a single Sine/Cosine wave for each pole.
The complete sine/cosine signal process is interpolated electronically. Depending on the interpolation refine-
ment, together with the pole distance of the magnetic tape, the resolution of the measuring system is deter-
mined. The MB 20.20 magnetic tape has a pole pitch of 2 mm. A special evaluation electronic (translator) pro-
cesses the sine/cosine wave into square output signals from the signal information of the magnetic tape. These
square signals are equivalent to conventional optical rotary- or linear encoder outputs.
Figure 1: Code of the Magnetic Tape
5.2 Pulse diagram
Figure 2: Pulse Diagram
N N N NS S S S N N N NS S S S N NS SN NS SS
B
B‘
Z
Z‘
A
A‘
The channels A and B are phase
shifted by 90°.
The index pulse output occurs
periodically every 2 mm or op-
tionally as a free definable refer-
ence pulse (R / R’).

Technical Data
- 9 -
6Technical Data
6.1 Identification
The type label serves for the identification of the unit. It is located on the housing of the sensor and gives the
exact type designation(=order reference, see type designation) with the corresponding part number. Further-
more, the type label contains a unique, traceable device number.When corresponding with ELGO always indi-
cate this data.
6.2 Dimensions Sensor
Figure 3: Dimensions Sensor
6.3 Dimensions Guiding Profile FBK80 and End / Connection Profile
AFBK80
Dimensions of the FBK80 (guiding profile for magnetic tape BK80)
Figure 4: Dimensions FBK80
30,00
12,50
Magnetic tape
17,00
4,00
21,00
25,00
25,00
Ø3,40
320,00 320,00320,00 20,00
B
Top view
Side view
B
20,00
4,00

Technical Data
- 10 -
Dimensions of the End / Connection Profile AFBK80
Figure 5: Dimensions AFBK80
6.4 Technical Data Sensor
EMIX23 (standard version)
Mechanical Data
Measuring principle:
incremental
Repeat accuracy:
± 0.001 mm
System accuracy in µm at 20° C:
± (20 + 20 x L) L = measuring length in meters
Allowed distance sensor / tape:
max. 0.8 mm
Pole pitch:
2 mm
Sensor housing material:
zinc die cast
Sensor housing dimensions:
L x W x H = 30 x 12.5 x 25 mm
Required magnetic tape
with higher resolutions ≤1 µm:
standard: MB20-20-10-1-R-EPS
option REF: MB20-20-10-2-R-C-REFXXXX-EPS
option BK80: MB20-20-10-1-R-D-BK80-EPS
option BK80 + REF: MB20-20-10-2-R-D-BK80-REFXXXX-EPS
Required magnetic tape
with coarser resolutions >1 µm:
standard: MB20-20-10-1-R
option REF: MB20-20-10-2-R-C-REFXXXX
option BK80: MB20-20-10-1-R-D-BK80
option BK80 + REF: MB20-20-10-2-R-D-BK80-REFXXXX
Maximum measuring length:
theoretically unlimited
Connection type:
open cable end or with plug connector (option D1, D3)
Sensor cable:
1.5 m standard length, others on request (max. 30 m)
Weight:
approx. 40 g without cable (cable approx. 60 g/m)
Electrical Data
Power supply:
5 VDC or 10 …30 VDC
Residual ripple:
5 V: +/-25 mV; 10-30 V: <10 %
Consumption:
max. 200 mA
Output channels:
A, A‘,B, B‘, Z, Z‘ (index pulse) resp. R, R’ (reference pulse)
Output levels:
5 V-TTL / 10…30 V-HTL
Resolution (at 4-edge triggering):
0,001 mm
Index pulse:
2 mm periodically or free definable reference pulse R, R’
Max. output frequency per channel:
1 MHz
Max. movement speed:
2 m/s
Ambient conditions
Storage temperature:
-20 … +85° C
Operation temperature:
-10 … +70° C
(-25 … +85° C on request)
Humidity:
max. 95 %, not condensing
Protection class:
IP67
20,00
10,00
30,00
40,00
Screw M2 x 4

Technical Data
- 11 -
6.5 Technical Data Magnetic Tape
The magnetic tape consists of two components:
The actual magnetic tape which carries the position information
A mechanical stainless steel back iron (interference band)
Magnetic Tape MB20-20-10-1-R
Coding
Absolute, single track system
Pole pitch
8 mm
Operation temperature installed
-20 …+65° C
(-20 …+80° C usage without adhesive tape , options „B“ or „D“)
Storage temperature uninstalled
Short-term: -10 … +60° C
Medium-term: 0°…+40° C
Long-term: +18° C
(-20 …+80° C usage without adhesive tape , options „B“ or „D“)
Gluing temperature:
+18 … +30° C
Relative humidity
max. 95 %, non-condensing
Accurateness 20°C in mm
± (0.025 + 0.02 x L) L = measuring length in meters
Material carrier tape
Precision strip 1.4310 / X10CrNi 18-8 (EN 10088-3)
Double-faced adhesive tape
3M-9088 (observe instructions), others on request
Dimensions
without adhesive tape:
10 mm (± 0.1) x 1.35 mm (± 0.11)
with adhesive tape (excl. carrier):
10 mm (± 0.1) x 1.56 mm (± 0.13)
with adhesive tape (incl. carrier):
10 mm (± 0.1) x 1.63 mm (± 0.14)
Length expansion coefficient
 16 x 10-6 1/K
Thermal length expansion
∆L[m] = L[m] x [1/K] x ∆[K]
(L = tape length in meters, ∆= relative temperature change)
Bending radius
min. 150 mm, min. 50 mm in case of usage without adhesive tape
(options B and D)
Available lengths
up to maximum 32 m
Weight magnetic tape
approx. 62 g/m (incl. magnetic tape and cover tape)
Tape imprint
ELGO standard, printing color black, digit height >= 5 mm
Influence of external magnets
External magnetic fields must not exceed 64 mT (640 Oe; 52 kA/m) on
the surface of the magnetic tape, because this could damage or destroy
the code on the tape.
Protection class
IP65

Installation and First Start-Up
- 12 -
7Installation and First Start-Up
CAUTION
Please read the operating manual carefully before using the device! Strictly observe the Installation instructions!
In case of damage caused by failure to observe this operating manual, the warranty expires.
ELGO is not liable for any secondary damage and for damage to persons, property or assets.
The operator is obliged to take appropriate safety measures.
The first start-up may only be performed by staff that has been trained and authorized by the operator.
7.1 Operating Area
WARNING!
Do not use the device in explosive or corrosive environments!
The device must not be installed close to sources of strong inductive or capacitive interference or strong electrostatic
fields!
CAUTION!
The electrical connections must be made by suitably qualified personnel in accordance with local regulations.
The device may be designed for switchboard mounting. During work on the switchboard, all components must be de-
energized if there is a danger of touching the energized parts!
(protection against contacts)
Wiring works may only be performed in the de-energized state!
Thin cable strands have to be equipped with end sleeves!
Before switching on the device, connections and plug connectors have to be checked!
The device must be mounted in a way that it is protected against harmful environmental influences such as splashing
water, solvents, vibration, shock and severe pollution and the operating temperature must not be exceeded.

Installation and First Start-Up
- 13 -
7.2 Installation of the Magnetic Tape
NOTE: External Magnetic Fields
The magnetic tape must not be influenced by external magnetic fields!
The magnetic tape must not come into direct contact with other magnetic fields (e.g. perma-
nent magnets, magnetic clamps, electromagnets, magnetic stands)! This may cause irrepara-
ble damage, which will compromise the measuring accuracy or even the functioning.
7.2.1 The Magnetic Tape MB20-20-10
In the standard case, the magnetic tape is delivered as described.
It is installed by gluing it to the respective mounting surface.
IMPORTANT NOTE:
EMIX23 with a resolution of ≤1 µm (e.g. 0.001 mm) require single pole magnetized
magnetic tapes with the addition "EPS" (see type designation 10.2). Otherwise the
required accuracy cannot be guaranteed.
For resolutions >1 µm (e.g. 0.005 mm) the conventional magnetic tape can be used
without the addition "EPS".
The magnetic tape consists of 2 pre-assembled components (see Figure 6):
A magnetized, flexible plastic tape (Pos. 3), which is connected with a magnetically conductive steel
tape as inference band (Pos. 4) and is supplied with an adhesive tape (Pos. 5).
A magnetized permeable cover tape (Pos. 1), which serves for the mechanical protection of the plastic
tape (not required for the measurement) and is supplied with an adhesive tape (Pos. 2). The cover tape
is not necessary for the measurement.
Therefore a divergent tape structure and scope of delivery is also possible.
The cover tape is also available separately.
Figure 6: Magnetic Tape Structure
Pos. 1: Stainless steel cover tape
Pos. 2: Double-sided tape
Pos. 3: Magnetized plastic tape
Pos. 4: carrier tape stainless steel
Pos. 5: Double-sided tape
Pos. 6: Mounting surface, for example machine bed

Installation and First Start-Up
- 14 -
7.2.2 Magnetic Tape with Option BK80
Figure 7: Magnetic Tape with Option BK80
The cover tape (C) is not included in the delivery of this version.
7.2.3 Handling
In order to avoid tension in the tape, it must not be stretched, compressed or twisted and should be stored with
the magnetized plastic tape to the outside. The minimum bending radius is 150 mm.
Figure 8: Handling
7.2.4 Processing hint for the gluing of magnetic tapes
Surface-Preparation: In order to guarantee optimal adhesion, all anti-adhesive contamination (e.g. oil, grease,
dust, separating agents) has to be removed using solvents with residue-free evaporation. Suitable agents are
ketones or alcohols. Typical solvents for cleaning the surface are a 50/50 isopropyl alcohol/water mixture or
heptane. Those agents are offered by Loctite and 3M among others as surface cleaners. When using solvents,
always observe the manufacturer instructions! If the surface is copper, brass etc., it should be sealed to avoid
oxidation.
Contact-Pressure: The strength of the adhesion is directly dependent on the contact the adhesive can form with
the surface. Therefore it is important to use as much pressure as possible when gluing the tape, possibly by us-
ing aids such as draw rolls. The optimum contact pressure is 4…5 kg/cm2).
Gluing temperature: The optimal gluing temperature is between + 18° C and 30° C. Avoid colder sticking sur-
faces than + 10°C, because in this case the adhesive becomes too hard and perhaps a sufficient immediate
adhesion is hardly to achieve. After proper sticking, the stability of the connection is ensured also when the tem-
perature is below zero. The final tackiness of a sticking is from experience reached after approximately 72 hours
(at + 21° C). For gluing use only the supplied adhesive tape.
<SN XX/000000001/00000 MB20-20-10-1-R-D-BK80 ELGO
10,00
8,00
1,35
Top view:
Front view:
Scale 5:1
AMagnetized plastic tape
(Magnetic tape)
Magnetically conductive steel band
(Interference band)
B
Magnetized
Plastic tape
Steel tape

Installation and First Start-Up
- 15 -
7.2.5 Cutting and Gluing
Before starting the gluing process, both the magnetic and the cover tape have to be cut to the required length
Length cover tape = measuring length + sensor length + 50mm (end caps)
NOTE!
When sticking the magnetic tape pay attention to the markings on the tape and the Sensor.
Improper installation does not provide the correct values. Already glued magnetic tape is
destroyed after the removal, and cannot be used again. Note also the direction of counting
of the measuring system
Preferably the magnetic tape should be glued close to an edge or into a groove, which
should be deep enough to embed the magnetic tape and the cover tape.
When unprotected, the cover tape may peel off!
Therefore:
Use tape end caps (11) or let the cover tape overlap* the end of the magnetic tape and fix
it with a screw.
The tape must be glued smoothly on the surface. The measuring accuracy decreases if the tape is not even!
Before gluing the magnetic tape and the cover tape onto the surface, they should be left lying on the mounting
surface for approximately 30 minutes so that the temperature matches. This prevents strain in the tape due to
thermal expansion.
Mounting steps:
Thoroughly clean surface (7.2.4)
Let magnetic tape and cover tape adjust their temperature
Remove protection foil of adhesive tape on magnetic tape
Glue magnetic tape using great pressure
Thoroughly clean surface of magnetic tape
Remove protection foil of adhesive tape on cover tape
Glue cover tape using great pressure
Safeguard the ends of the cover tape against peeling off (using end caps see chapter 9.2)

Installation and First Start-Up
- 16 -
7.2.6 Resistance against Chemical Influence
Table 1: Resistance against Chemical Influence
Show no or little effect in constant contact after 2-5 years:
formic acid
glycerol 93°C
linseed oil
soy beans oil
cotton seed oil
N-hexane
lactic acid
formaldehyde 40%
Iso octane
petroleum
Show weak to moderate effects in constant contact after approximately 1 year:
acetone
gasoline
acetic acid 30%
oleic acid
acetylene
steam
acetic acid, pure acetic
acid
sea water
ammonia
acetic acid 20%
isopropyl ether
stearic acid 70°C, anhy-
drous
kerosene
Have strong effects when contacting permanently after 1-5 months:
benzene
nitric acid 70%
turpentine
toluene
lacquer solvent
nitric acid, red, vitriolic
carbon tetrachloride
tetrahydrofuran
trichloroethylene
nitrobenzene
hydrochloric acid 37%,
93°C
xylene

Installation and First Start-Up
- 17 -
7.2.7 Magnetic Tape Variants
Figure 9: Magnetic Tape Variants
Magnetic Tape with guiding profile FBK80
Figure 10: Magnetic Tape Variants with FBK80
Standard ( 1 track)
Magnetic tape: MB20-20-10-1-R
Option REF (reference pulse, 2 tracks)
Magnetic tape: MB20-20-10-2-R-C-REFXXXX
N S N S N S N S N S N S N S N S N S N S N S N S N
N S N S N S N S N S S N S N S N S N S N S N S NN
N S N
Cover tape
Magnetic tape
Interference band
Cover tape
Magnetic tape
Interference band
Standard BK80 - 1 track (compatible with guiding profile FBK80)
Magnetic tape: MB20-20-10-1-R-D-BK80
N S N S N S N S N S N S N S N S N S N S N S N S N
Cover tape
Interference band
Front view
Option BK80 - REF - 2 tracks (compatible with guiding profile FBK80)
Magnetic tape: MB20-20-10-2-R-D-BK80-REFXXXX
Magnetic tape
Interference band
N S N S N S N S N S S N S N S N S N S N S N S NN
N S N
Top view
Standard BK80 - 1 track with guiding profile FBK80
Magnetic tape: MB20-20-10-1-R-D-BK80
N S N S N S N S N S N S N S N S N S N S N S N S N
Magnetic tape
Interference band
FBK80 profile
Option BK80 –REF - 2 tracks with guiding profile FBK80
Magnetic tape: MB20-20-10-2-RD-BK80-REFXXXX
Magnetic tape
Interference band
FBK80 profile
N S N S N S N S N S S N S N S N S N S N S N S NN
N S N

Installation and First Start-Up
- 18 -
7.3 Mounting of the Sensor
Two M3 screws to be used to install the sensor head.
The specified tolerances must be adhered to.
7.3.1 Tolerances EMIX23
Table 2: Tolerances EMIX23
Tolerances
Distance between sensor and tape
max. 0.8 mm
Pitch
The maximum allowed distance of 0.8 mm may not
be exceeded at any position
Roll
The maximum allowed distance of 0.8 mm may not
be exceeded at any position
Yaw
<± 0,5°
Lateral offset with standard magnetic tape
Lateral offset with option REF (magnetic tape)
± 2.5 mm
± 0.5 mm
Figure 11: Sensor Tolerances
Sensor distance
Pitch
Yaw
±0,5°
Roll
Lateral offset
Max 0,8mm Max 0,8mm
±2.5 mm* (standard)
±0.5 mm* (option REF)
*) Related to the system accuracy (see
Technical Data) and 10 mm wide tape

Installation and First Start-Up
- 19 -
7.3.2 LED for Distance Monitoring (Option E)
EMIX23 encoders which are equipped with an LED are able to indicate the correct or incorrect reading distance
between sensor and magnetic tape.
LED lights green: Reading distance is ok
LED lights red: Reading distance is not ok
Please note!
This option is (currently) only available for the version with 5 VDC supply / 5 V-TTL levels.
More information about the reading distance 7.3.1
7.3.3 Mounting Options of the Sensor
Figure 12: Sensor - Mounting Options
7.3.4 How to install the Sensor and the Magnetic Tape
The location of the reference pulse can be detected by using the magnetic magnifying glass which is included in
the delivery. Please ensure that the mounting is centrally aligned with the magnetic tape center, because the
sensor is wider than the magnetic tape. When ordering, the reference pulse position is starting from the right
side of the magnetic tape.
Figure 13: Installing Sensor and Tape
The example image above shows:
Sensor: EMIX23-000-05.0-0001-00-E-R
Magnetic tape: MB20-20-10-2-R-C-REF148
Standard (horizontal) Option L (vertical)
N S N S N S N S N S S N S N S N S N S N S N S NN
N S N
Sensor Reference sensor
Reference mark Fine interpolation track
Error LED
148,00

Installation and First Start-Up
- 20 -
7.3.5 Mounting of the Guiding Profile FBK80 and End / Connection Pro-
file AFBK80
Controlled thermal expansion:
The magnetic tape can be fixed left, right or centrally - depending on the terminal expansion.
Figure 14: Mounting of FBK80 / AFBK80
7.3.6 Mounting of the FBK80 on beams with different heights
The guide rail is able to compensate unevenness up to max. +/- 0.5mm
Figure 15: FBK80 on beams with different heights
Expansion (right) Expansion (left)
Expansion (both directions)
