Eliet Prof 5 User manual

Prof 5
MANUAL

2
English
This booklet provides information about the actual use and maintenance of
the machine.
Read it carefully and keep it in a safe place for future reference.
Please also keep your purchasing invoice or receipt together with this
booklet.
Register your purchase online on www.eliet.eu.

3
English
1. Introduction
1.1 Carefully read this user manual
Elite machines are designed for safe and reliable use if they are operated in accordance with the
instructions given. Carefully read this user manual before using the machine. Failure to observe
this may result in personal injury or damage to the equipment.
1.2 Identification data – Eliet Prof 5
Note the identification data relating to your machine in the boxed areas.
Product code :
Serial Number :
Year of Manufacture :
Date of purchase :
2. Warranty
2.1 Warranty card
To be eligible to obtain warranty you must mail the completed warranty card within one month of
the date of purchase to the address stated below.
European customers : US customers :
ELIET EUROPE NV ELIET USA Inc.
Diesveldstraat 2 3361 Stafford street (office B)
B – 8553 Otegem (Belgium) 15204 Pittsburgh (PA)
T([phone] - F([phone] T412 367 5185 - F412 774 1970
www.eliet.be, e-mail: [e-mail] www.elietmachines.com
Read the warranty conditions on the attached warranty card.

4
English
3. Welcome
Welcome to the family of ELIET customers.
We would like to thank you for the confidence that you have placed in ELIET and we are con-
vinced that you have purchased the very best machine. The operating life of your ELIET machine
depends to a great extent on how you care for your machine. This user manual and the engine
manual provided will assist you in this respect. If you follow the instructions and suggestions in
these manuals, your ELIET machine will operate for a very long time in optimal condition.
Read this instruction manual carefully before operating this machine. This will prevent you from
operating the device incorrectly.
For your own safety, take into account the safety instructions stated in the relevant chapter. Even
if you are thoroughly familiar with operating such equipment, it is still advisable to read these
pages carefully.
At ELIET all our machines and devices are subjected to a policy of continuous change and there-
fore, the specification of your machine may differ slightly in terms of shape, technology and ac-
cessories. The descriptions and technical data in this manual are accurate at the time of printing.
Certain illustrations and descriptions may not be applicable to your specific machine, but instead
relate to a different version of the machine. In turn, we trust that you will understand that the
texts and illustrations in this manual cannot lead to any claims.
If you still have any questions after you have read this manual, we request you to contact your
ELIET dealer.
ELIET AT YOUR SERVICE
European customers : US customers :
ELIET EUROPE NV ELIET USA Inc.
Diesveldstraat 2 3361 Stafford street (office B)
B – 8553 Otegem (Belgium) 15204 Pittsburgh (PA)
T([phone] - F([phone] T412 367 5185 - F412 774 1970
www.eliet.be, e-mail: [e-mail] www.elietmachines.com

5
English
4. Table of Contents
1. Introduction................................................................................................................................ 3
1.1 Carefully read this operating instruction manual............................................................................. 3
1.2 Identification data - ELIET Prof 5 ........................................................................................................ 3
2. Warranty .................................................................................................................................... 3
2.1 Warranty card ........................................................................................................................................... 3
3. Welcome ..................................................................................................................................... 4
4. Table of Contents ...................................................................................................................... 5
5. Safety symbols.......................................................................................................................... 7
5.1 For your information............................................................................................................................... 7
5.2 Caution...................................................................................................................................................... 7
5.3 Warning..................................................................................................................................................... 7
6. Main parts.................................................................................................................................. 8
7. Safety regulations ....................................................................................................................11
7.1 Safety messages.......................................................................................................................................11
7.2 Safety provisions....................................................................................................................................13
7.3 Safety regulations..................................................................................................................................15
7.3.1 General safety precautions...........................................................................................................15
7.3.2 Careful and security-conscious use...........................................................................................15
7.3.3 Responsibilities of the operator .................................................................................................16
7.3.4 Personal protective equipment..................................................................................................16
7.3.5 Zone of danger...............................................................................................................................17
7.3.6 Periodic maintenance...................................................................................................................18
7.3.7 Preserving nature ..........................................................................................................................18
8. Dealer preparation ...................................................................................................................19
9. Operating instructions ............................................................................................................21
9.1 Preliminary checks .................................................................................................................................21
9.2 Filling up with gas..................................................................................................................................21
9.3. Preparing the work area....................................................................................................................22
9.4 Turning and positioning the blowchute and deflector flap ........................................................23
9.5 Starting the gas engine ......................................................................................................................23
9.6 Moving the machine ............................................................................................................................24
9.7 Operating the machine........................................................................................................................25
9.7.1 Before starting work......................................................................................................................25
9.7.2 Shredding proper .........................................................................................................................25
9.8 Troubleshooting....................................................................................................................................27
9.8.1 Rotor stalled ...................................................................................................................................27
9.8.2 Engine cuts out.............................................................................................................................28
9.8.3 Engine stalls while running........................................................................................................28
9.8.4 Starter motor does not operate during starting (optional) ...............................................28
9.8.5 Capacity decreases......................................................................................................................28
9.8.6 Wheel drive does not operate when gas engine is running...............................................28

6
English
9.8.7 Feed roller no longer operates (optional)...............................................................................28
9.8.8 Engine no longer runs and the machine must be moved on ZR model..........................28
9.8 Cleaning the machine..........................................................................................................................29
10. Transporting the machine ....................................................................................................30
11. Maintenance tasks described in detail.................................................................................31
11.1 General......................................................................................................................................................31
11.2 General interventions..........................................................................................................................32
11.2.1 Removing the belt guard .............................................................................................................32
11.2.2 Disconnecting the battery..........................................................................................................33
11.2.3 Opening the shredding chamber..............................................................................................33
11.3 Engine maintenance............................................................................................................................34
11.3.1 Checking the oil level in the engine crankcase + refilling....................................................34
11.3.2 Engine oil change.........................................................................................................................35
11.3.3 Changing or refilling the hydraulic oil .....................................................................................36
11.3.4 Changing the hydraulic oil and oil filter..................................................................................36
11.3.5 Cleaning the air filter ..................................................................................................................36
11.3.6 Changing the air filter.................................................................................................................37
11.3.7 Adding additional battery acid..................................................................................................37
11.4 Machine maintenance.........................................................................................................................38
11.4.1 Checking and sharpening the blades .......................................................................................38
11.4.2 Reversing and renewing the shredding blades.....................................................................39
11.4.3 Checking the V-belt for correct tension.................................................................................42
11.4.4 Tightening the V-belt ..................................................................................................................42
11.4.5 Checking and tightening the drive belt for correct tension ..............................................43
11.4.5 General lubrication ......................................................................................................................43
11.5 Maintenance schedule ....................................................................................................................... 46
11.5.1 Normal maintenance schedule ................................................................................................. 46
11.5.2 Special maintenance .................................................................................................................. 46
11.5.3 Daily maintenance .......................................................................................................................47
11.5.4 Maintenance after 50 hours......................................................................................................47
11.5.5 Maintenance after 100 hours (or six-monthly)......................................................................47
11.5.6 Maintenance after 200 hours (or annually) ......................................................................... 48
12. Winterizing the machine.......................................................................................................49
13. Equipment specifications .....................................................................................................50
14. Prof 5 PTO..............................................................................................................................54
15. EC Declaration of Conformity ..............................................................................................56
16. Warranty-conditions.............................................................................................................. 57
17. Hazard analysis......................................................................................................................60

7
English
5. Safety symbols
Certain symbols in this manual are used to provide additional information and to draw your at-
tention to potential risks.
5.1 For your information
For your information
This symbol is used to draw your attention to specific information and/or
actions, or to denote where you can find additional information relating to the
subject.
5.2 Caution
Caution :
This notice identifies safe usage habits. This is done to prevent incorrect actions
that can result in personal injury or damage to the machine.
5.3 Warning
Warning :
This notice is used to warn you about extreme danger that you must be aware
of in these specific circumstances. Thus remain alert, in order to ensure your
own safety.

8
11
1
10
3
8
1
7
5
2
4
9
6
1
2
2
3
4
3
5
6
7
89
English
8
6. Main parts
To fully understand the content of this operator’s manual, you need to be fully conversant with
the terminology used for the descriptions. In this chapter you can find a set of parts identified by
name. It is a good idea to take time to study the machine beforehand for an improved under-
standing of the descriptions provided in this user manual.
1) Safety handle
2) Wheel drive control / steering wheel (option
ZR)
3) Gas tank
4)Hydraulic oil tank
5)Feed control (option Hydro)
6)Protection guard
7) Loading hopper
8) Controller feed roller
9) Belt cover transmission
10) Blow chute
11) Turbine blower
1) Parking brake
2) Pedal clutch
PROF 5 BLOWER
(drawing with options Hydro-ZR)
PROF 5 STD
(drawing with options Hydro-ZR)
1) Hydraulic wheel motor
(option)
2) Grating (on STD version)
3) Safety screen (on STD version)
4) shredding chamber
5) Hydraulic oil filter
6) Battery
7) Hydraulic oil reservoir
8) hours run counter (option)
9) ABM indicator light (option)

9
20
20
English
9
Engines:
14 HP Subaru EX40
1) Spark plug
2)Exhaust outlet (elongated on machine)
3) Muffler cover
4) Air cleaner
5) Fuel tank
6) Fuel tank cap (fuel filler)
7 ) Speed control
8) Lever Recoil starter
9) Starter handle
10) Choke lever
11) Fuel lever
12) Fuel Cup
13) Carburetor
14) PTO shaft
15) Oil gauge (oil filler)
16) Oil drain plug
17) Engine serial number
18) Engine name label
19) Stop switch
20) Oil sensor unit
13 HP Honda GX390
For your information :
Reference in this manual to right or left hand side, back or front of the unit
is observed from the machine operator facing the branch feed
of the machine.
Your ELIET dealer is at your service, ready to provide you with maintenance or advice so that
your ELIET machine always remains in optimal condition. You can contact him for genuine ELIET
service parts and lubricants. These service parts are manufactured to the same stringent accu-
racy requirements and standard of craftsmanship as the original equipment.
FUEL TANK
ELECTRIC STARTER
(QAE type)
OIL DRAIN PLUG
OIL FILLER CAP
SERIAL NUMBER AND
ENGINE TYPE
FUEL FILLER CAP
STARTER GRIP
FUEL VALVE
THROTTLE LEVER
OIL ALERT LAMP
RECOIL STARTER
CIRCUIT BREAKER
(QAE type)
ENGINE SWITCH
(QAE type)
MUFFLER
SPARK PLUG
CHOKE LEVER
AIR CLEANER
FUEL TANK
ELECTRIC STARTER
(QAE type)
OIL DRAIN PLUG
OIL FILLER CAP
SERIAL NUMBER AND
ENGINE TYPE
FUEL FILLER CAP
STARTER GRIP
FUEL VALVE
THROTTLE LEVER
OIL ALERT LAMP
RECOIL STARTER
CIRCUIT BREAKER
(QAE type)
ENGINE SWITCH
(QAE type)
MUFFLER
SPARK PLUG
CHOKE LEVER
AIR CLEANER

10
English
Caution :
For your safety, use only genuine ELIET parts on ELIET machines.

11
English
7. Safety regulations
7.1 Safety messages
For your information :
Safety stickers have been affixed on to visible areas of the machine. Make a note
of the warning messages specified on these stickers.
This sticker is attached to the safety net and warns
against the danger of injury to hands. The screen on
the shredding chamber should only be opened once the
blades have come to a complete standstill. The motor
should always be switched off before lifting the safety
net.
This sticker is attached to the drive belt guard. The stick-
er points out the danger which can occur if the guard is
removed while the motor is rotating. Never operate the
machine if the guard is not in place.
This sticker is attached to the side of the machine. It
provides a summary of the general safety regulations by
using icons:
1. Before operating the machines the manual should be
read and understood.
2. Suitable safety clothing (gloves, safety glasses, ear de-
fenders) should be worn when operating the machine.
3. Operating or carrying out maintenance on the ma-
chine presents the risk of injury to hands. Be alert and
careful.

12
English
This sticker is attached tot he machine at engine height.
This sticker reminds the operator to switch off the en-
gine and release the spark plug cap before carrying out
maintenance on the machine.
This sticker is attached in the input opening. The sticker
emphatically points out the risk of injury to hands which
is inherent in wood shredding. The sticker reminds the
operator how to operate the shredder in the safest pos-
sible way. It is prohibited to insert your hands beyond
the safety shield!
This decal is located on the side of the loading
hopper. It lists all the identification data relat-
ing to the machine :
Model, model number, serial number, year of
manufacture, engine, power rating, weight,
guaranteed A-weighted sound power level
Lw(A).
This sticker also lists the manufacturer’s details. The CE label means that the machine complies
with the governing European machinery directive.
Caution :
Safety stickers becoming damaged, illegible or removed through use or cleaning,
must be immediately renewed. Stickers are available at your approved ELIET
Dealer.

13
1
2
3
English
7.2 Safety provisions
Safety screen (on STD version)
The safety screen (1) avoids access to the blades. No
tools are required to open the screen, but the motor is
shut off on opening the screen. The motor can be turned
on again once the screen is closed, that is, when the
safety limit switch (2) is actuated.
Belt guards
These guards provide protection from the moving belt.
These guards can only be removed using tools. The
machine must not be started if these guards are not
correctly fitted.
Rugged construction :
The robust construction not only adds to the long operating life of the machine, but also provides
additional user safety whenever there is an unforeseen emergency.
Safety handle (on Hydro version) :
You can operate the feed of the machine with this con-
trol lever.
Operating positions of the safety handle
All versions:
1: out
2: stop
3: in

14
English
Parking brake :
The parking brake will lock the machine in its position
whilst working or transporting material. This ensures
that there cannot be any unforeseen situations where
the machine starts to move unintentionally.
Safety wear :
For your safety, we strongly recommend to use the
safety kit supplied as standard. It contains your Personal
Protective Equipment (PPE). This safety set consists of
safety glasses, ear plugs or hearing protection and a pair
of riggers gloves.
Rotor and turbine brake :
If you have chosen the ZR option a brake is installed on
the machine. This brake makes sure the blades don’t
turn and the blower doesn’t blow when the engine runs.
You can transport your machine without problems.

15
English
7.3 Safety regulations
7.3.1 General safety precautions
• The Owner Manual must stay with the unit during its complete service life. It serves as a refer-
ence for the user, and enables the machine to be used and maintained in accordance with the
correct instructions. Always refer to this instruction manual if you have any doubts about an
action that you are about to perform.
• If the instructions stated in this manual are not clear to you, do not hesitate to contact your
Eliet dealer for further explanation. ELIET’s helpdesk ([phone]) is also at your dis-
posal during office hours to provide answers for your questions.
• Read the chapter that is meant for the dealer (see Chapter 8) and immediately check whether
or not the machine has been delivered in accordance with the instructions.
• Carefully observe all safety instructions when using the ELIET machine ! Carefully read all the
instructions relating to the use of the machine. All these instructions relate to your personal
safety.
• When you purchase the machine, first allow the dealer or a professional to give you some in-
struction.
• Read and observe all safety messages posted on the machine in the form of stickers.
• Read and observe all safety messages posted on the motor.
• Under no conditions whatsoever may the original design of the machine be modified without
written consent of ELIET.
• Under no circumstances must a safety item be shunted, disassembled or switched off.
• As shredding involves ongoing considerable physical effort, take regular breaks for food intake,
rest and drinking.
• It is unsafe for persons suffering heart problems and/or having balance disturbances to oper-
ate the machine.
• Avoid inhaling the exhaust fumes from the machine. Exhaust gases contain toxic particles
which could prove fatal. Never start the engine in an enclosed area.
7.3.2 Careful and security-conscious use
• This machine is designed solely for shredding branchy material, prunings, leaves and all kinds
of organic garden debris. Any use other than the designated operation is at the risk and re-
sponsibility of the operator.
• Never attempt to shred branches that are frozen.
• Think about what you are doing whenever you operate the machine. Do not be tempted to let
routine dull your attention. Never act impulsively or in reflex.
• Despite the extensive safety features, do not seek out dangerous situations.
• Take care to preclude any tools falling into the in-feed funnel.
• Be aware that the machine ejects the shredded material through the blowchute. Make no one
or nothing is in the area where the blowchute is directed.
• Do not feed foreign materials. (string, stones, metal, plastic, textile, etc.)
• According to the manufacturer, this model will take branches up to 80 mm diameter. For your

16
English
own safety on no account should any attempt be made to introduce stems thicker than the
stated capacity.
• The machine is not designed to be subjected to the stated maximum capacity for longer peri-
ods. As a guideline: no more than 10 % of the garden waste that is to be fed into the machine
may have a diameter in excess of 90 mm.
• Never stand on a step when feeding garden waste into the loading hopper.
• Do not use a fork or a shovel to or a fork to feed the machine with garden waste.
• Do not use your feet to feed garden waste in the loading hopper.
• Never work in conditions where light intensity is less than 500 Lux.
• Always remember to set the parking handle, so as to prevent the machine form moving.
• For deontological reasons, ELIET accept no responsibility whatsoever for any accidental injury
to pets or persons caused by its machines.
7.3.3 Responsibilities of the Operator
• All persons using the machine are assumed to be fully conversant with the safety instructions.
• The operator is fully liable for the use of the machine in regard to himself and to third parties.
• Operators are presumed to possess a certain level of maturity that permits them to make deci-
sions based on common sense.
• Underage persons must not operate the machine. However, this does not apply to youths
above the age of 16 years, who are learning to operate the machine under the supervision of
an experienced operator.
• A disabled person may only operate the machine when under the supervision of an experi-
enced operator.
• Children and animals must be kept well away from the machine.
• ELIET recommend that the machine should not be lent to others. However, if this is done, only
lend it to persons who are conversant with the machine.
Always ensure that the user is aware of the potential hazards and ensure that he
reads the manual before he uses the machine.
(an indicative list of potential hazards can be found at Appendix)
• This machine must only be operated by persons who are in good physical condition. If you be-
come tired during the work, take a rest in due time. Persons consuming alcohol or drugs must
not operate this machine.
7.3.4 Personal Protective Equipment (PPE)
• You must wear suitable clothing to operate this machine. That is, clothing covering the whole
body, heavy protective gloves and closed nonslip footwear.
• Do not wear loose fitting clothing (a shawl, for instance, should be avoided by all means). Long
hair should be contained using a cap or a headband, or worn in a ponytail.
• For the protection of the most sensitive senses, ELIET recommends ear hearing protection and safety
goggles.

17
10 m
10 m
3 m
3 m
English
Danger zone throw
out area blower
• Shredding may result in dust production. If this dust irritates your lungs, we recommend that
you wear a dust mask conform to directive 89/686/EC.
7.3.5 Zone of danger
Graphical representation of
the zone of danger
STD:
BLOWER:
The blower can be turned in different positions. The danger zone shifts in the manner the blower
is turned.
• During the work, do not allow bystanders to enter the zone of danger that stretches up to
40ft around the machine. Do not take any risks and immediately stop the machine as soon as
anyone enters the danger area.
• Always let the machine run empty before switching of the engine. Left over chippers in the
chipper chamber can block the blades or turbine so that the machine does not start.
• When leaving the machine, the engine must be switched off. Always wait until the blades come
to a complete standstill before carrying out any operation. Once the engine is running, focus
all your attention on operating the machine.
10 ft
40 ft
10 ft
40 ft

18
English
7.3.6 Periodic maintenance
• Periodic maintenance is essential. For this reason, strictly follow the maintenance schedule in
this user manual (see Chapter 11).
• A maintenance counter will help you keep track of the hours run (optional).
• When replacing parts as a result of wear or failure, always request genuine ELIET service parts
from your ELIET dealer. This is important in the interests of your own safety.
• Always make sure the engine is switched off and the battery cables disconnected before per-
forming repairs or maintenance.
For your information
Also, read the engine manual that comes supplied with the machine. This
contains the information required for the correct use and maintenance of the
engine.
• Also read the engine manual, in order to carry out all maintenance according to the safety
rules given by the engine make.
7.3.7 Preserving Nature
Use the machine in a manner that respects environmental regulations.
• Avoid unnecessary machine running while not at work.
• Avoid spilling gas while refuelling.
• Service the engine regularly in order to achieve optimum combustion.
• Prevent battery acid from overflowing.

19
English
8. Dealer preparation
Warning :
As an ELIET dealer you must familiarize your customers with the function-
ing of the machine and also point out the possible dangers while using it.
You are expected to carefully go over the maintenance points of the machine
together with the new owner. Repeat these instructions until the new owner
has fully understood everything.
Warning :
The manufacturer, ELIET wish to re-emphasise that the Dealer must expressly
point out to the customers that they must examinethe bolts which retain the
chipping blades for security of fixings within the first 5 operating hours.
Ignoring this operation may cause serious injury and may even lead to death. In addition to dam-
aging the machine, the client shall loose all entitlement to make a claim on the warranty. See the
list with tightening torques in the annex.
• Likewise, make sure to check the belt for correct belt tension after a run-in period of 10 hours.
• Each machine that leaves the factory contains a limited amount of oil and fuel. The dealer
must check the levels of the oil and fuel and top them up in accordance with the instructions in
this manual (or in the engine manual).
• The Dealer performs a test run on the machine and confirms that everything is functioning
properly (such as the safety contact at the collection bag).
• He also checks that the bolts securing the blades are fully tight.
• Lastly, the dealer makes sure that the warranty card is filled in completely and signed. This, in
order to avoid any warranty disputes. For more information, please read the warranty condi-
tions on the warranty card.

20
English
• ELIET machines are packaged in accordance with common rules that apply for such transpor-
tation. Deliveries will always be ex factory. ELIET cannot, therefore, be held liable for damages
that occur during transportation.
• Should you notice damage to the packaging when goods are accepted, always check the state
of the machine to ensure it is not damaged. Report any deviation on the delivery order before
signing off for receipt.
• Should the machine be damaged, you should always immediately submit a complaint to the
shipping company.
