Elite HI-979S User manual

MADE IN KOREA


Relevant Model
HI - 979S
HI - 959S
HI - 959
pH Comparison Chart
▣ Measurement : Catching 10-15 ml of test water and drop 2-3drops
reagent. Then, mix well and check color of pH Comparison Chart in
comparison with pH of water.
(Color depends on water quality and reagent.)
4.0 5.0 6.0 7.0 8.0 9.0 10.0
AlkalineAcid Neutral


■ We cannot and do not accept any responsibilities
or liabilities if you replace or repair filters or parts
with those not manufactured by our company.
■This product is subject to slight specification
changes without prior notice with the purpose of
enhancing product performance.
■ Make sure you read "Safety Warnings to ensure proper use.
■ This product is intended for domestic use. To ensure proper use,make sure to read the User Manual.
■ Make sure to carefully read this User Manual before using this product.(Keep the manual handy for easy reference.)

 




Thank you for purchasing one of our products.
Make sure to read this manual carefully to ensure proper use of the product.
We are not responsible for any accidents and malfunctions due to improper use of this machine.
Please keep the manual and the warranty in a safe place, so that it will be easily reachable when you need it.
Please refer to this manual when you have any questions during the use or when this unit doesn't function properly.

This device was intended to create functional alkaline, ionized water. This device changes the properties of normal
tap water through the use of electrolysis. The main changes in the water are as follows.

① Increased or decreased pH ② Oxidation reduction (ORP)
③ Smaller water clusters ④ Increased oxygen
⑤ Cleaning of water
Intended use
Precautions before use
Regarding Power Supply
installation
Usage
Storage
Others
2
3
4
5
6
7
8
To our valued customers Name of parts
LCD Display by Product Feature
Product Features
Product Installation Method
Installation
Instruction
TURBO Function
Filter Configuration
Filter Replacement
Step-by-Step Direction for Using this Produc
Hot water sensing function
Product Specifications
9
11
15
17
19
21
23
25
27
29
34
34
Things to be confirmed
before requesting after-sales service

37
38Product Warranty
Safety Precautions Instruction Service Information




 

The "DANGER" sign indicates an
imminent hazard that could result in
serious injury or death. If you see
this signal, stop use of the unit.
"DANGER"
The "WARNING" sign indicates a potential
hazard that could result in a significant injury
to the body or damage to the unit. Please
acknowledge this notice and stop use of
the unit.
"WARNING"
The "ATTENTION" sign indicates a potential
hazard that could result in minor injury to the
body or damage to the unit.
"ATTENTION "
Please follow all instructions when you drink the water from this device (hereinafter called "functional water" )
formed by electrolysis.
① Do not take medicines with alkaline ionized water.
Use the Clean Water button for taking medication.
② Always consult your doctor before drinking, and only drink a
small amount for the first week at a level that is not too far
above a neutral pH. This gives your body time to adjust to the
water during the detoxification process.
③If you notice any negative effects from drinking the water from
this device, stop drinking it immediately and consult with your
doctor about changes in your bodies pH levels.
④If you are currently under a doctor’s care for an existing condition,
consult with your doctor about how changes in pH and other
characteristics of alkaline ionized water could affect your condition.
⑤ Those who have suffer from anacidity, kidney failure, or excretion
of potassium should not drink alkaline ionized water.
⑥It is a good practice to verify the pH of the water dispersed from
this device on a monthly basis to ensure proper function. This
can be done with the supplied reagent drops or a pH meter.
⑦It is a good practice to let the water run for several seconds
when switching from one ph level to another.
⑧
A good rule of thumb is to drink half of your body weight in ounces.
This rule applies after you have given your body some time to
adjust to the new pH levels.
⑨9.5-9.8 pH is the recommended drinking level for alkaline ionized
water. It is not recommended that you consume water that is
above a 10 pH.
⑩ If you wish to store the functional water, follow the tips below.
- Store in the refrigerator
- Store in glass, stainless steel, or other non-leaching material
- The water will begin to lose strength after 3 days.
⑪Never run hot water through this device.
⑫Never drink acidic water.

Do not use a damaged
power cord or loose connector,
otherwise, electric shock or fire may occur.
Do not forcibly bend the power
cord and make sure the power
cord isn't squeezed, damaged
or crushed by heavy objects.
Otherwise, electric shock or fire may occur.
Otherwise, electric shock or fire may occur.
Safety precautions are provided for the safe and proper use of this product and can prevent danger or possible damage from the misuse.
Make sure that you are familiar with the safety precautions for proper use of the product.
Do not pull the power cord, and
never touch it with wet hands.
otherwise, electric shock or fire may occur.
Unplug the power cord during
the product repair, inspection
and parts replacement.
Use a dedicated connector per
outlet for each electrical product.
Otherwise, electric shock or fire may occur.
Only use the device with
the indicated voltage.
Otherwise, electric shock or fire may occur.
Do not spray water onto the main
unit or do not clean the main unit
with damped cloth.
Otherwise, a short circuit or electric
shock may occur.
Do not disassemble or refurbish
this product at your discretion.
Otherwise, electric shock or damage
to the product may occur and your
warranty will be void.

Replace filters according to
filter replacement cycles to
ensure clean water. When a
filter that has reached the end
of its life cycle is still in use,
purification performance and
product life will be affected
(Replacement cycle: primary filter: 6
months, secondary filter: 6 months).
Please replace filters approximately every 6 months
to optimize the purification performance of this
product even if the filter replacement indicator lamp
isn't turned on.
If any strange noise, burning
odor, or smoke is generated
from the product, unplug the
power connector immediately
and contact our service center.
Otherwise, fire may occur.

In the case where raw water
isn't used over a long period,
lock the raw water valve and
pull the power cord out.
Otherwise, electric shock, electric fires
or leaks can occur.
Do not place any liquids or
other objects on top of this
device.
This may cause electric shock or fire
if it gets into the product.
If water flows out of the product
(other than hoses) or water is
present around the product,
shut off the water supply, pull
the power cord and contact
our service center.
Never poke or scratch the
touch pad with sharp objects.
Otherwise, electric shock or
damage to the product may
occur. (Give a light touch with a
finger to the touch screen.)
 
Safety precautions are provided for the safe and proper use of this product, and prevent danger or possible damage from the misuse.
Make sure that you are familiar with the safety precautions for proper use of the product.

Do not install this product in an
uneven location and do not
apply excessive force or impact
to this product.
This may cause physical injuries and
damage to the product.
Do not connect the water line to
the hot water supply.
Otherwise, a failure or an accident may
occur.
(Be sure to connect water line to
the cold water supply.)
Install this product around
the sink and always to allow
water to be drained into the
sink.
Do not use in a place with high humidity or a high
temperature.
Otherwise, a failure or accident may occur.
Do not use raw water unfit for the standards of
water service act.
Otherwise, a failure may occur.
Install the acidic water outlet hose within the height of the product. Make sure the end of the
hose is installed in such a way that it is less than 20cm from the bottom ofthe product.
Otherwise, product performance can be degraded, and residual water may remain unextracted.

Do not install this product near
heat generating appliances.
Never place a candlelight or
cigarette on this product.
Otherwise, fire may occur.
 
Turn off
Turn off



Condensed water may flow out
of the product during humid
summer months. This is normal
for the product. However, if
condensed water keeps flowing
out of the product even in the
cold weather, please contact our
service center due to possible
leakage.
If alkali water is used over a
long period of time, some
problems may occur in the
product. In such situations,
use acidic water.
The same holds true for the
opposite case.
If the unit is not used for a few
days, let the water run for 1-2
minutes before consuming any
water from it.
That may cause electric shock or fire.
Pull the power cord when cleaning
the unit. Do not spray water directly
onto the power cord and do not
clean it with benzene or chemicals.
This may cause electric shock, fire or
damage to this product.
Do not use alkaline or acidic
water in fish bowls or aquariums.
The sudden change in PH could
be harmful or fatal to fish.
Safety precautions are provided for the safe and proper use of this product, and prevent danger or possible damage from the misuse.
Make sure that you are familiar with the safety precautions for proper use of the product.


Turn off the raw water
supply valve and unplug.
Do not place a vessel filled with
water, pharmaceuticals, food, and
small metals on this product,
which, if introduced into the product,
may cause electric shock and/or
electric fires.
Remove the filters, and turn it
upside down to remove excess
water before storing.
Cover the device in plastic to avoid
scratching the surface. Place the product
on a level surface.
That may cause damage to the product.
That may cause damage to
the product.
Pull the power cord when clean
the unit.
Do not spray water directly onto
the power cord or do not clean it
with benzene or chemicals.
That may cause electric shock, fire or
damage to this product.

 
benzene or thinner........ Dangerbenzene or thinner........ Danger
Turn off

 


 


Make sure to be familiar with designations for different parts, and carefully read operating directions and other information.

 
 


 















Front View HI-979S Front View HI-959S Front View HI-959 Rear View (All Model)
Water Outlet Unit
Front Case
LCD Display
Operation Display
Front Cover
Water Outlet Tube
Front Door Case
Water Outlet Unit
Front Case
LCD Display
Operation Display
Front Cover
Water Outlet Tube
Front Door Case
Water Outlet Unit
Front Case
LCD Display
Operation Display
Front Cover
Water Outlet Tube
Front Door Case
Hanging Groove
Rear Case
Product Sticker
Power Switch
Fuse
Power Cord

 

 
Make sure to be familiar with designations for different product parts, and carefully read about operating guide and other information.

Operation Display







 System Setup
Mode Setting
Voice ON/OFF
Turbo Function(HI-979s)
Water Outflow ON/OFF
Alkali Level Setting
Acidic Level Setting
Purifier Water
Selected mode
Selected Level
System Setup
Turbo(HI-979S)
Power Adjust
Door open
Temperature error
pH Leve


















ORP Level
Selected Language
Working indicator
Time indicator
※RTR
(Cleaning function)




1st/ 2nd filter life
voice on/off






LCD Display
LCD Display






Operation
Display Operation Display

Operation Display







 System Setup
Mode Setting
Voice ON/OFF
Water Outflow ON/OFF
Alkali Level Setting
Acidic Level Setting
Purifier Water
Selected mode
Selected Level
System Setup
Power Adjust
Door open
pH Leve

















ORP Level
Selected Language
Working indicator
Time indicator
※RTR
(Cleaning function)




1st/ 2nd filter life
voice on/off



LCD Display
LCD Display






Operation
Display Operation Display




RTR
(Cleaning function)
Volume
1st/ 2nd filter life



 System Setup
Mode Setting
Volume Adjustment
Alkali Level Setting
Purifier Water
Acidic Level Setting
Water Outflow ON/OFF






Selected Level
Select Display
Selected Mode
System Setup
pH
Time indicator
Voice on/off
Level










LCD Display
LCD
Display
Operation Display




 
 

Operation
Display

▶
Clean Water
Green Back-Light
Alkaline Water 1
Bluish Green Back-Light
Alkaline Water 2
Blue Back-Light
Alkaline Water 3
Violet Back-Light
TURBO Alkaline Water
Violet Back-Light
(HI-979S)
Acidic Water 1
Yellow Back-Light
Acidic Water 2
Orange Back-Light
Acidic Water 3
Red Back-Light
Clean Acidic Water
Red Back-Light
(HI-979S)
When alkaline water(1.2.3.), Clean water and
acidic water(1.2.3.) buttons are selected,
back-light is turned on the same as standard
colorimeter paper.

 

 
Make sure to be familiar with designations for different product parts, and carefully read about operating guide and other information.

▶System setup is a function used when selecting the PH level control/volume control,
and language selection modes.
▶ Whenever you push the "Mode" button, you can change "PH level control→volume
control→language selection (return)" in sequence.
Change the mode to the system setup mode by pressing the "setup" button for 3 seconds.
Voice Message : " system setup mode."
LCD color : " white " ," SETUP " icon(Light).
Select the "PH level control mode" by pressing the "Mode" button.
LCD : HI - 979S & HI - 959S = "LEV" icon(Blinking), HI - 959 = "LEVEL" icon(Blinking)"

Select the desired phase by using the "Alkali" or "Acidic button.
ALKALI : 1→2→3 (RETUNE)
ACIDIC : 1→2→3 (RETUNE) [Model No. : HI-979S, 959S]
ACIDIC : 1→2 (RETUNE) [Model No. : HI-959]
TURBO : “Alkali”or“Acidic” [Model No. : HI-979S]

Control the phase by using the "+" or "-" button.
The supply current value of an electrolytic cell appears on the PHvalue panel display of LCD.(0~6A).

Press the "Setup" icon for 3seconds to complete the setup.
Voice Message : " setup was completed."

Change the mode to the system setup mode by pressing the "setup" button.
LCD : " SETUP " icon (Lighting).
Select the " volume control mode" by pushing the "Mode" button.
LCD : " current setup language(KOR/ENG..) " icon (Blinking)

Control the phase by using the "+" or "-" button.
The voice is presented in the selected language.

① [Model No. :HI-979S, HI-959S] 1.KOR 2.ENG 3.JPN 4.CHN 5.GER 6.ESP
If you want to change from English to Japanese: Push the "+" button once.
② [Model No. :HI-959]
L1 : KOR, L2 : ENG, L3 : JPN, L4 : CHN
If you want to change from English to Korean: Push the "-" button again.
Press the "Setup" icon for 3seconds to complete the setup.
Voice Message : " setup was completed."
▶ 
▶ 
▶ 
Change the mode to the system setup mode by pressing the "setup" button for 3 seconds.
LCD : "SETUP"icon(Light)
Control the phase by using the "+" or "-" button.
The selected volume percentage(%) appears on the PHvalue panel display of LCD.

Press the "Set up" icon for 3seconds to complete the setup.
Voice Message : " setup was completed."


Select the " volume control mode" by pushing the "Mode" button.
LCD : HI - 979S & HI - 959S = "VOL" icon(Blinking), HI - 959 = "VOLUME" icon(Blinking)
The current volume percentage(%) appears on the PHvalue panel display of LCD.


 

  

This product features a combination of highly advanced technology, elegant design,
and advanced electronic control unit, providing ease of operation and excellent performance.

■ Filter replacement cycle.
Replacement cycle display and announcement for filters.
This product is designed to indicate to you when
it is time to change your filters. Remember 6
months is the best rule of thumb for filter
replacement.
■ Voice announcement
Voice announcements for different functions and
safety warning voice announcements ensure safe
and convenient use.
■ Automatic water outflow
Merely pressing the touch button allows you to
extract water or stop the flow of water.
■ Fully automatic system with embedded
Central Processing Unit (CPU)
Every aspects of producing electrolytic water is
controlled by the CPU chip that automatically finds
an optimal operating condition using flow rates
and water quality
■The outflow water stops automatically when inflow water is not supplied.
■This function prevents the electrolyte cell and power supply unit from being damaged due to overflow of current.
■This function causes water outflow to stop automatically to prevent water from being wasted and to prevent accidental
water leaks.
■ Advanced water purifying filter system
The advanced performance primary filter and
functional secondary filter enable optimal purifying
conditions for tap water.
■ Automatic Extraction/Stop Function
15 minutes after a function is selected, water
outflow is stopped to prevent overflow or flooding.
There is no need to wait if the device automatically
shuts off. You can resume use immediately.
■ SMPS Type Power Supply
A CPU monitors the power supplied to different
parts of the unit, thereby ensuring this product is
used in an efficient manner.
■ TURBO Function [HI-979S]
Strong acid water and strong alkaline water with
sterilizing, anti-bacterial cleaning power is generated.
■ RTR(Real Time Refresh) cleaning function
Allows for cleaning the inside of the electrolytic
cell.
■ Door opening sensing function.
When the door of the product opens, the supply
of raw water is automatically shut off.
■ Round mesh electrode
The use of new materials of platinum coated
titanium for the electrodes of the electrolytic cell,
the core part of the water ionizer appliance,
extends its life span and heightens the ratio of
generating hydrogen.
■ Temperature sensing function [HI-979S]
This device is equipped with a temperature
sensor which, prevents the accidental inflow of
hot water.
■ Sensible and Elegant Design
This product uses a compact and an elegant
design to blend with the interior of the kitchen.
■ LCD, RGB Color back light [HI-959S, HI-979S]
The RGB color backlight on the LCD allows you
to distinguish alkali water from acidic water.


 

Prior to installation, make sure to check the following fittings.

※ To make the best functionality, there may be a some
changes without notices.
▶Name: Water Outlet Tube
▶Q'TY: 1
▶Name: Faucet Diverter
▶Q'TY: 1
▶Name: Stem Elbow
▶Q'TY: 2
▶Name: Tube Fixing
▶Q'TY: 2
▶Name: pH Reagent Bottle
▶Q'TY: 1
 ▶User Manual 1EA
▶Name: HOSE
▶Q'TY: 2.5m
Lock the main valve on the water pipe.
Separate the tap from the water pipe.
Turn the adapter to allow it to be fitted
in the water pipe.
Assemble the tap back into the adapter.
Connect the valve to the adapter before
connecting the water inlet hose to the nipple.


Cool Water
Adapter
Hose
Faucet Diverter
Hose
 





Prior to installation, make sure to check for the following parts and fittings.
 




▶ In the case of a power failure during the use, the product will stop functioning.
▶ Unplug the power cord from the wall outlet and shut off the water supply.

▶The product can not be used.
▶Check to make sure your water supply is turned on.
▶If problem persist call for support.
(If air or foreign matter gets into the main unit, filter life may be shortened)
Place the unit on the planned installation location
and screw the flexible tube clockwise tightly to the
water outlet hole positioned on the top of the unit.
Do not over tighten.
Press the stem elbow into the water in
_ flow/out _ flow
hole located on the bottom of the unit until you
hear a click
Plug in the device.
(If power is applied, the melody "ding dong dang" comes in.)
Measure the length between the location where the
device will be located (on counter) and the water
faucet where the diverter (adapter) will be installed.
Cut a sufficient length of hose to allow it to be
connected to the water supply inlet on the rear of
the unit (from faucet to the unit).
※Make sure that you keep the length under 5 meter
between the unit and the water faucet. You may have
to use the pressure pump or larger hose size to
connect water line if water pressure is too low. It is a
good idea to leave a few extra inches of length so
faucet can still be rotated.
Cut a 50-to-70cm length of drain hose and
connect it to the drain on the rear of the product. Make
sure the drain hose is positioned lower than the
product.

“ON”

 
 

 

 
After the installation, make sure to be well familiar with the operating method.
 
*Water flow condition and time appear on the
display window.
*Selection condition appears on the LCD window.
*Selection condition appears on the LCD window.
Select Mode

Select Level

Water Outflow

Water Outflow Stop

 


Select all the desired mode buttons of
alkaline water, acid water, clean water
Step is changed whenever you press
the
selected mode.
Start water flow by pressing
the water flow on/off button.
*Water flow condition and time appear on the
display window.
Stop water flow by pressing
the water flow on/off button.
*Water flow condition appear on the display
window.
*Selection condition appears on the LCD window.
*Selection condition appears on the LCD window.
Select Mode

Select Level

Water Outflow

Water Outflow Stop

 


Select all the desired mode buttons of
alkaline water, acid water, purified water
Step is changed whenever you press
the
selected mode.
Start water flow by pressing
the water flow on/off button.
*Water flow condition appear on the display
window.
Stop water flow by pressing
the water flow on/off button.


 
 

The TURBO fuction allows you to create strong alkaline and strong acidic water.
Thes types of waters are ONLY to be used for cleaning, sanitizing, and disinfecting purposes.
TURBO
strong acidic water
TURBO
strong alkali water
pH 2.5 ~ pH 3.5 pH 10.0 ~ pH 12.0
Don’t
Drink
Never drink
these types of waters!!
Used to disinfect and sterilize Used to remove stains
from clothes and carpet.



① The water produced in the TURBO modes is not intended for drinking. Never drink these types of waters.
② Do not use the TURBO fuction for purposes other than those indicated on this card.


or
“ACIDIC”“ALKALI”
or
“ACIDIC”“ALKALI”

Press“ACIDIC”or “ALKALI”icon. No related to the level of acid water(1.2.) or water(1.2.3)
Press“OUTFLOW/STOP”icon.
OUTFLOW Start water flow by pressing the water flow on/off button.
Press“TURBO”icon. The machine switches to its TURBO function and dispenses water.
TURBO WATER OUTFLOW
Press“OUTFLOW/STOP”icon. Stop water flow by pressing the water flow on/off button






Press“ACIDIC”or “ALKALI”icon. No related to the level of acid water(1.2.) or water(1.2.3)
Press“TURBO”icon. The machine switches to its TURBO function and dispenses water.
Press“OUTFLOW/STOP”icon.
TURBO WATER OUTFLOW
Press“OUTFLOW/STOP”icon. Stop water flow by pressing the water flow on/off button




After the installation, make sure to be well familiar with the operating method.
   
    







TY-2003N
Recommended filter replacement cycle: 3,600ℓRecommended filter replacement cycle: 3,600ℓ
■With the activated absorption method, it absorbs the harmful
organic-chemical materials like chlorine, agrichemicals and
detergents efficiently and eliminates bad smell, and remaining
chlorines dissolved in the water.
■Consisted with various ceramics, it has abundant minerals
and absorbs and eliminates organic-chemical materials that
were not filtrated through the 1 st filer, and changes water into
clean and healthful water.
Reference : Life of filter can vary greatly due to usage, water
pressure, water quality and seasons. Filter has to be replaced
sooner than scheduled time when water quantity reduces greatly
or water taste changes for worse. This filter filters relatively large
suspended matter like rust and sediment residual chlorine in water
and volatile organic compounds.
Reference : Life of filter can vary greatly due to usage, water
pressure, water quality and seasons. Filter has to be replaced
sooner than scheduled time when water quantity reduces greatly
or water taste changes for worse. This filter filters relatively large
suspended matter like rust and sediment residual chlorine in water
and volatile organic compounds.
This product is consisted of a high-performance purifying filter and an advanced control system.
It delivers reliability because of the stringent system control and manufacturing.
TY-2003N

 

 

Please call our branch office to arrange for the filter replacement when filter change icon flashes.
Delay in filter replacement can cause the product to function improperly.

 



Unplug the power cord or turn power off to ensure safety.
Shut off the main valve on the water pipe or be certain that the faucet is off.
To initialize, push ① the Reset switch inside the door two times.
1st - voice message : "1st filter."
LCD : The indication (%) of current filter usage.
2nd - voice message : "Initializing was performed."
LCD : The indication (00%) of the initialization of filter amount.
 -1
 -2

Close the door of the device.
When opening the door, be careful not to get scratched from the sharp portions of the product.
Open the front door of the device.
When opening the door, be careful not to get scratched from the sharp portions of the product.

Plug in the power cord and turn power switch on.

① Unplug the power cord.
② Turn the fuse case cap at the lower back of the product counterclockwise, and remove it.
③ Pull out a blown fuse, and insert a new fuse.
④ Turn the fuse case cap clockwise, and combine it.
⑤ Plug in.
Make sure to request a/s, and have an a/s engineer replace a fuse .
We don't assume no responsibility for any failures or disadvantages caused by the use of unauthorized parts.
 
Separation
Separation
Connection
Connection

Pull the filter towards you and then turn counter clockwise.
Install new filter by turning it clockwise.
Open Close
1ST FILTER RESET

To initialize, push ② the Reset switch inside the door two times.
1st - voice message : "2nd filter."
LCD : The indication (%) of current filter usage.
2nd - voice message : "Initializing was performed."
LCD : The indication (00%) of the initialization of filter amount.
2ND FILTER RESET
FILTER _RESET
Filter_1 Filter_2


 




The method for using this product is divided into several procedures according to pH levels.
Make sure to be well familiar with it since the functions for different stages are quite different.
Light alkaline water
Suitable during the initial stage of
drinking.
Medium alkaline water
Used to make coffee or tea.
Used for watering plants.
Strong alkaline water
Used for cleaning vegetables and fruits.
Used for cooking soup dishes and rice.
Light acidic water
Do not drink!
Use when washing face, hands.
Medium acidic water
Do not drink!
Used for washing the dishes.
Used for cleaning vegetables and fruits.
▶ ▶
▶
Creates purified water
Used for taking medications.
Used for baby formulas
Other icon
Water type selection appears on the LCD
window.
RTR(Real Time Refresh) cleaning function (30 seconds)
Allows for automatic cleaning of the inside of the electrolytic cell.
- Performed during water outflow after more than 12 hours of non-operation.
- Performed after 30 liters or more water outflow.
*Notification of cleaning mode is indicated when the “RTR” icon and back light begin flashing before
each auto cleaning is performed.
▶
Filter F1, Filter F2
Blinking“F1”and“F2”on the filters
means that the filters should be replaced.
1ST alarm : More than 95% of usage.
(blinking)
2nd alarm : More than 100% of usage.
(voice message : Please exchange filters.)














The method for using this product is divided into several procedures according to pH levels.
Make sure to be well familiar with it since the functions for different stages are quite different.
Light alkaline water
Suitable during the initial stage of
drinking.
Medium alkaline water
Used to make coffee or tea.
Used for watering plants.
Strong alkaline water
Used for cleaning vegetables and fruits.
Used for cooking soup dishes and rice.
Light acidic water
Do not drink!
Use when washing face, hands.
Medium acidic water
Do not drink!
Used for washing the dishes.
Used for cleaning vegetables and fruits.
Strong acidic water
Do not drink!
Used for cleaning vegetables and fruits.
Used for cleaning dish towels.
Used for cleaning bathroom.
Creates purified water
Used for taking medications.
Used for baby formulas
▶ ▶ ▶ ▶
Filter F1, Filter F2
The usage of filters appears, notifying you
of when the filter needs to be changed.
Total usage is indicated by percentage.
1ST alarm : More than 95% of usage.
(blinking)
2nd alarm : More than 100% of usage.
(voice message : Please exchange filters.)
Water outflow indicator
It shows the status while water is being
produced.
Time indicator
It shows the remaining time for water
outflow before safety shutoff is activated.
Other icon
Selected functional icon appears on the
LCD window.
RTR(Real Time Refresh)
Allows for automatic cleaning of the
inside of the electrolytic cell.
*Performed during water outflow after
more than 12 hours of non-operation.
*Performed after 30 liters or more water outflow.
*Notification of cleaning mode is
indicated when the “RTR” icon and
back light begin flashing before each
auto cleaning is performed.
Turbo Function
Do not drink!
Strong acid water, strong alkaline water
with sterilizing, anti-bacterial, cleaning
power is generated.
▶
[Model No. :HI-979S, HI-959S]









or







 

Product Name
Model Name
Purifying Mode
Rated Voltage
Power Consumption
Available temperature
Operating pressure range
pH Levels
Adjustable pH
Quanrity of filter
Replacement type
Filter Life Display
Product Size
Product Weight
WATER IONIZER
HI - 979S
Filter percolation
AC100V~AC130V, AC200V~AC240V/50Hz~60Hz
Max. 150W
4~35℃
1~5.0(kgf/㎠)
3 Alkaline, 1 Neutral, 3 Acidic, Turbo Alkalin, Turbo Acidic
User-adjustable pH levels control
2 Filters System
Revolving cartridge type
LCD filter replacement display and announcement
7
Platinum and Titanium
393(W) × 132(D) × 360(H)
7.2㎏
Electrolyte
cell
Filter
Quantity of Poles
Materials
If the temperature of inflow raw water gets out of the scope
of 4~35℃ and gets into the product, raw water supply is
automatically shut off, and the operation stops.
LCD: "TEMP" icon(blinking)
The raw water supplied changes to cold water
Press the"Outflow/Stop" button for 3 seconds, and then the
operationautomatically stops after 10 seconds of water outflow.
[If the standard temperature of inflow water reaches 4~35℃, the water
outflow before 10 seconds stops.]
If the temperature of inflow water doesn't reach standard
temperature(4~35℃) for 10 seconds after water outflow, the
operation stops.
LCD: "TEMP" icon(blinking)
Again, please follow "How to release shut-off" “2”







4~35℃
OPERATION
STOP
※

10 seconds
Outflow
4~35℃4℃ or 35℃
4℃ or 35℃4℃ or 35℃
4℃ or 35℃







Product Name
Model Name
Purifying Mode
Rated Voltage
Power Consumption
Available temperature
Operating pressure range
pH Levels
Adjustable pH
Quanrity of filter
Replacement type
Filter Life Display
Product Size
Product Weight
WATER IONIZER
HI - 959
Filter percolation
AC100V~AC130V, AC200V~AC240V/50Hz~60Hz
Max. 150W
4~35℃
1~5.0(kgf/㎠)
3 Alkaline, 1 Neutral, 2 Acidic
User-adjustable pH levels control
2 Filters System
Revolving cartridge type
LCD filter replacement display and announcement
5
Platinum and Titanium
393(W) × 132(D) × 360(H)
7.2㎏
Electrolyte
cell
Filter
Quantity of Poles
Materials
Product Name
Model Name
Purifying Mode
Rated Voltage
Power Consumption
Available temperature
Operating pressure range
pH Levels
Adjustable pH
Quanrity of filter
Replacement type
Filter Life Display
Product Size
Product Weight
WATER IONIZER
HI - 959S
Filter percolation
AC100V~AC130V, AC200V~AC240V/50Hz~60Hz
Max. 150W
4~35℃
1~5.0(kgf/㎠)
3 Alkaline, 1 Neutral, 3 Acidic
User-adjustable pH levels control
2 Filters System
Revolving cartridge type
LCD filter replacement display and announcement
5
Platinum and Titanium
393(W) × 132(D) × 360(H)
7.2㎏
Electrolyte
cell
Filter
Quantity of Poles
Materials


Product Warranty
1. This product is warranted for one year (12 months). Any manufacturing defects or spontaneous failures that may occur
during the warranty period will be repaired or replaced at no charge.
2. If any failure occurs, please call for service.
3. In the following cases, the customer shall pay repair or replacement costs .
- In the case where a failure occurs resulting from improper use or negligence by the customer.
- In the case where repairs or modifications are performed by non-authorized representatives.
- In the case where a failure due to natural disasters (fires, salt damage, damage from natural gas, earthquakes, floods, lightning, and etc.)
- In the case of absence of the product warranty or no information is provided in the warranty.
- Usage other than domestic use.
4. We shall charge the customer for repairs and replacement costs against failures after the warranty period expires
(one year after the date of purchase).
5. Our customers are asked to show their warranty to us when requesting after-sales service.
6. This warranty will not be reissued. Make sure to keep it in a safe place.
1. This product is warranted for one year (12 months). Any manufacturing defects or spontaneous failures that may occur
during the warranty period will be repaired or replaced at no charge.
2. If any failure occurs, please call for service.
3. In the following cases, the customer shall pay repair or replacement costs .
- In the case where a failure occurs resulting from improper use or negligence by the customer.
- In the case where repairs or modifications are performed by non-authorized representatives.
- In the case where a failure due to natural disasters (fires, salt damage, damage from natural gas, earthquakes, floods, lightning, and etc.)
- In the case of absence of the product warranty or no information is provided in the warranty.
- Usage other than domestic use.
4. We shall charge the customer for repairs and replacement costs against failures after the warranty period expires
(one year after the date of purchase).
5. Our customers are asked to show their warranty to us when requesting after-sales service.
6. This warranty will not be reissued. Make sure to keep it in a safe place.
  
Check the product for the period of use.
Check the filter for replacement time intervals.
Check if the amount of working water exceeds 30ℓ.
Check if the operating time exceeds 12 hours.
Check if the Cleaning Icon is pressed.
The product returns to the normal condition after performing auto cleaning
for 15 seconds.
Check if calcium ions and carbonic acids bond together in
water, forming deposits.
Depending on raw water quality, calcium minerals in raw water are extracted.
There is no problem in drinking the calcium minerals in water.
However, it is recommended that the customer should request for after-sales
service to protect the product units in the case where such calcium minerals
are generated in a continuous manner.
Immediately deplug the power cord and request for after-sales service.
Check if the continuous operating time exceeds 15 minutes.
Water production stops automatically in 15 minutes in order to prevent
accidental flood.
Check if the filter flow rate is initialized. Initialize the filter flow rate in the System Setting Mode.
Request for after-sales service.
 

Before requesting after-sales service, be sure to check the following
We cannot accept any responsibility or liability for errors and/or problems rising from the customer's use of parts that aren't manufactured by our company.
www.tyent.co.kr
15-2, Pyeongsan-Dong, Yangsan-si,
Gyeongsangnam-do, Korea
TEL.[phone] FAX. [phone]
□HI - 959S □HI - 959
□HI - 979S
Warranty Period
One Years from
the Date of Purchase [12months]
Product Name
Water Ionizer
Product Name
Date of Purchase
Customer's
Name / Phone
Customer's
Address
Installation
Engineer Name
Water tastes abnormal
No water outflow
Amount of water generated
different from specified
Incorrect pH levels
(pH samples are provided
on a fee-for-service basis)
The filter replacement icon
remains turned on even after
the filter has been replaced.
The product automatically
stops while it is producing
reduction water.
Leaks from the filter or product
Hazy substance settles down
on the bottom of the bottle filled
with reduction water
The product doesn't operate
in Cleaning Mode
Operate the product so that it should be drained of stagnant water for one minute.
Request that the filter should be replaced.
Be sure water is on..
Check if the hose is bent or folded.
Check if flow rate is below (1 ℓ/min or slower)
Check if water supply is cut off or if the water supply line is frozen.
Check the purifying filter for being clogged.
Open the valve.
Stretch out the hose.
Contact our A/S center to install a water pump.
Wait until water comes out of the water supply pipe.
Replace the filter.
Check water supply line for hardnes.
Check flow rates for higher levels.
Check if the amount of water drained is small.
The pH levels may vary depending on regions and water quality.
Slow down water supply.
Set the system.(Request for after-sales service).
Check the filter for proper mounting.
Check for the inside of the product with the exception of the
filter for any leaks
