eliving FURNITURE COCO Series User manual

*Please Keep For Future Reference Only.
IMPORTANT :-
PLEASE READ THESE INSTRUCTION CAREFULLY BEFORE STARTING ASSEMBLY.
CCO-SB136-WHT / PAGE 1
ASSEMBLY INSTRUCTION
Dimensions
Width : 1200mm
Depth : 400mm
Height : 745mm
COCO SERIES
CCO-SB136-WHT
SIDEBOARD

IMPORTANT TIPS AND MAINTENANCE
i)Keep children and animal away
from working area because smaller
part could choke if swallowed.
ii)Never put the liquid or damp
on the furniture.
iii)To avoid dulling, do not
place directly to the sunlight.
iv)Never use ammonia cleaning
product, because it will damage
to finish.
v)Use a soft or damp cloth (dry
cloth)and then wipe to clean on
the surface.
vi)Two person are required. vii)Put the soft map on the
floor to protect the furniture
before assembly.
COMPONENTS :-
HARDWARE Please check you have all the fittings part or tools are listed in below.
FITTINGS/TOOLSNO. NO. QTYQTY FITTINGS/TOOLS
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
DOWEL 6x30MM
66
Pcs
K.
L.
M.
SCREW M3.5x12MM
36
Pcs
DRAWER RUNNER A - L/R
6
Pcs
DRAWER RUNNER B - L/R
6
Pcs
8
Pcs
M6X50MM
5
Pcs
HANDLE SCREW 19MM
ALLEN KEY
CAM BOLT+CAM NUT
8
Pcs
PVC GLIDE
1
Pc
SCREW M4x38MM
6
Pcs
PLASTIC CORNER BLOCK
8
Sets
SCREW M3.5x16MM
26
Pcs
HANDLE
5
Pcs
34
Sets
TAPPING SCREW 8 X 12MM
HINGES
SHELF SUPPORT PIN
PVC H
NO. QTYFITTINGS/TOOLS
O.
P.
Q.
R.
S.
T.
2
Pcs
8
Pcs
4
Pcs
N. 8
Pcs U.
Anti-Tip Strap
M4 X 16MM
M4 X 25MM
PVC WALL PLUG
2
Pcs
2
Pcs
2
Pcs
2
Pcs
CCO-SB136-WHT / PAGE 2
Serious or fatal injuries can occur from
furniture tipping over. To prevent the furniture
from tipping over we recommend that it is
permanently fixed to the wall.
Wall fixing are not supplied with this product as different
wall material required different types of fixing devices.
Please make sure you use fixing suitable for the walls in
your home.
Wall
Top
WARNING
R
R
S
T
Top
Wall
Top
HARDWARE LIST
(S) M4 X 16MM - 2pcs
(T) M4 X 25MM - 2pcs
(U) PVC Wall Plug - 2pcs
U
(R) Anti-Tip Strap - 2pcs
CCO-SB136-WHT / PAGE 23

Please check you have all the panels are listed below.
COMPONENTS :-
PANELS
PART LIST
1
2
3
4
6
7
8
9
10
11
12
13
14
5
15
TOP PANEL
1pc
SIDE PANEL_RIGHT
FRONT CROSSBAR
BACK LEG BACK PANEL_L&R
SIDE PANEL_LEFT
1pc
1pc
3pcs
SIDE LEG_RIGHT
BOTTOM PANEL 1pc
1pc
FRONT LEG
DRAWER SIDE_R
1pc
2pcs
SIDE LEG_LEFT 1pc
DRAWER FRONT
DRAWER BASE
DRAWER BACK
DRAWER SIDE_L
2pcs
1pc
3pcs
3pcs
3pcs
3pcs
10
15
15
8
6
9
12
13
12
7
7
11
4
4
2
1
3
5
16
17
14
21
19
20
18
22
CENTER LEG 2pcs
16
17
18
19
20
CENTER PANEL_RIGHT 1pc
CENTER PANEL_LEFT 1pc
21
BACK PANEL_C 1pc
DOOR_LEFT 1pc
DOOR_RIGHT 1pc
22
SHELF PANEL 2pcs
