ROOMS TO GO KIDS CREEKSIDE 2.0 3834440P User manual

WARNING DANGER
Failure to follow these warnings and assembly instructions could result in serious
injury or death. To help prevent serious or fatal injuries from entrapment or falls:
-
Read all instructions before assembling bunk bed and keep these instructions for future reference.
-
Before each usage or assembly, inspect bunk bed for damaged hardware, loose joints, missing
parts, or sharp edges. DO NOT Use bunk bed if any parts are missing or broken.
-
DO NOT Use substitute parts. Contact your local Rooms To Go or visit www.ROOMSTOGO.COM
for replacement parts and instructional literature if needed.
-
Follow the information on the warnings appearing on the upper bunk end structure and on the carton,
DO NOT REMOVE WARNING LABEL FROM BED.
-
Always use the recommended size mattress or mattress supports, or both to help prevent the likelihood
of entrapment or falls.
-Ensure thickness of mattress and foundation combine does not exceed
10 inches (255mm
) and
mattress surface is at least
5 inches (127mm)
below upper edge of guardrails.
-
Do not allow children under 6 years of age to use the upper bunk.
-
Periodically check and ensure that the guardrail, ladder, and other components are in their proper
position, free from damage, and that all connectors are tight.
-
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
-
Limit top bunk use to one person.
-
Always use the ladder for entering and leaving the upper bunk.
-
Use of night light may provide added safety precaution for a child using the upper bunk.
-
Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed next to
the wall, the guardrail that runs the full length of the bed should be placed against the wall to
prevent entrapment between the bed and wall.
-
The use of water or sleep flotation mattress is prohibited.
-
This bunk bed meets all the requirements of ASTM 1427-19.
STRANGULATION HAZARD:
Never attach or hang items to any part of the bunk bed that are not designed for
use with the bed; for example, but not limited to, hooks, belts, and jump ropes.
CREEKSIDE 2.0 COLLECTION
THANK YOU FOR YOUR PURCHASE
11/7/2022 Page 1 of 97

35740403 40G-705 TWIN LOFT END
36840406 40G-707 TWIN CASTER BED HD & FT
P A R T S L I S T
3834440P TWIN/TWIN LOFT W/CHEST CHARCOAL
RTG SKU # STYLE # ITEM DESCRIPTION
35540409 40G-706 STEP STORAGE UNIT
38000232 100-645 TW. SLAT PACK (4)
38000232 100-645 TW. SLAT PACK (4)
36640402 40G-730 6 PC RAILS (2 GUARD & 4 SIDE RAILS)
36040400 40G-711 LOFT CHEST
3834441P TWIN/TWIN LOFT W/CHEST CHESTNUT
RTG SKU # STYLE # ITEM DESCRIPTION
35540411 40B-706 STEP STORAGE UNIT
36240404 40G-601 FOLDING DESK (Add on)
36640414 40B-730 6 PC RAILS (2 GUARD & 4 SIDE RAILS)
36040412 40B-711 LOFT CHEST
35740415 40B-705 TWIN LOFT END
36840418 40B-707 TWIN CASTER BED HD & FT
36240416 40B-601 FOLDING DESK (Add on)
38000232 100-645 TW. SLAT PACK (4)
38000232 100-645 TW. SLAT PACK (4)
TOOLS NEEDED
11 Pc
51 Pc
24 Pcs
Phillips screwdriver (not included)
5/16"-18 x 3 3/8" Bolt
PARTS LIST QTY PARTS LIST QTY HARDWARE LIST QTY
32 Pc
Drywall screw
2 Pcs
Twin top bunk bed end
1 Pc
Allen wrench (included)
24 Pc 1 pc bunkbed end twin 5 mm Hex key
FOLDING DESK HARDWARE
2 Pcs
Guardrails Loft chest 3/8" x 3 1/8"
Metal pin 6 x 1 1/4"
61 Pc
16 Pcs
Side rails 6 x 1 1/4"
91 Pc
Casters
Twin slats Caster bed headboard
81 Pc
48 Pc 71 Pc 4 Pcs
Drywall screw
Folding desk (Add on)
11/7/2022 Page 39 of 97
Caster bed footboard
A
B
C
D
C
E

ASSEMBLY INSTRUCTIONS
MAKE SURE ALL BOLTS ARE TIGHTENED COMPLETELY MAKE SURE ALL BOLTS ARE TIGHTENED COMPLETELY
11/7/2022 Page 40 of 97
Assemble loft chest and top bunk bed end.
Install slats, one on each end, two equally spaced in the middle,
Assemble top side rails. then fasten with 1 1/4" screws.
Assemble guardrails and tighten all bolts. Assemble side rails
STEP 5
STEP 4
STEP 1
C
D
B
C
A
C
A
A
A
A
A
B
DD
A
B
STEP 2 STEP 3
A
B
A
A
A
A
A
A
A
A
B

ASSEMBLY INSTRUCTIONS
11/7/2022 Page 41 of 97
Install slats, one on each end and two equally spaced in the middle,
then fasten with 1 1/4" screws Install casters in headboard and footboard.
Install slats, one on each end and two equally spaced in the middle,
then fasten with 1 1/4" screws
STEP 6
STEP 8
C
CSTEP 7 E
E
E

Twin size mattress- 74" - 75" long and 37-1/2" - 38-1/2" wide
Twin size Bunkie board- 74" long and 37-1/2" wide
Full size mattress- 74" - 75" long and 52-1/2" - 53-1/2" wide
Full size Bunkie board- 74" long and 52-1/2" wide
ASSEMBLY INSTRUCTIONS
11/7/2022 Page 42 of 97
Place Bunkie boards (required, sold separately) on top of the slats
Use only correct mattress dimensions and Bunkie board:
PLEASE CONTACT YOUR RETAIL STORE WITH SERVICE OR PARTS REPLACEMENT REQUEST
STEP 9

ASSEMBLY INSTRUCTIONS
Unfold corner supports (from desk box hardware pack) in the pre-bore hole.
Place folding desk by sliding into the opening of loft chest
then push down
Remove center molding by lifting up then pulling out
DO NOT THROW AWAY SAVE IT FOR FUTURE USE Unfold desk leg and look for hardware pack inside desk box.
Secure each corner block with 1 1/4" screw
11/7/2022 Page 43 of 97
STEP 10
STEP 12
STEP 11
STEP 13
STEP 14
C
C

Twin size mattress- 74" - 75" long and 37-1/2" - 38-1/2" wide
Twin size Bunkie board- 74" long and 37-1/2" wide
Full size mattress- 74" - 75" long and 52-1/2" - 53-1/2" wide
Full size Bunkie board- 74" long and 52-1/2" wide
ASSEMBLY INSTRUCTIONS
Place Bunkie boards (required, sold separately) on top of the slats
11/7/2022 Page 44 of 97
Use only correct mattress dimensions and Bunkie board:
PLEASE CONTACT YOUR RETAIL STORE WITH SERVICE OR PARTS REPLACEMENT REQUEST
STEP 15
