Elkay EDF20C Installation manual

96540C (Rev. G - 3/01)
EDF20C
Installation/Care/Use Manual
To assure you install this model easily and correctly, PLEASE READ THESE SIMPLE
INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK YOUR INSTALLA-
TION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL AND OTHER APPLICABLE
CODES. After installation, leave these instructions inside the fountain for future reference.
10
SEE FIG. 3
INSTALLATION INSTRUCTIONS
1. Wall should already be framed for the fountain using the positioning dimensions shown in Figure 1. Shown dimensions pertain to
installation location (framing must support up to 150 lbs. weight).
2. Install rough-in plumbing as shown in Figure 1. Connecting lines to be unplated copper. Run supply water inlet line and connect to
a service stop (not provided). Turn on supply water and flush thoroughly. Close water supply.
3. Secure the fountain to the wall using bolts and washers (not provided). Tighten securely.
4. Make water supply connections from service stop to the fountain. Turn on water supply and check for leaks. Newly installed
water supply line should be insulated after leak check is completed.
5. These products are designed to operate on 20-105 PSIG supply line pressure. If inlet pressure is above 105 PSIG, a pressure
regulator must be installed in the supply line. Any damage caused by reason of connecting these products to supply line pressures
lower than 20 PSIG or higher than 105 PSIG is not covered by warranty.
6. Check stream height from bubbler. Stream height is factory set at 35 PSI. If supply pressure varies greatly from this, remove
items 7 and 8 (See Figure 3) and adjust the screw on the regulator (Item 5). Clockwise adjustment will raise stream height and
counter-clockwise will lower stream height. For best adjustment stream should be approximately 1" (25mm) above the bubbler
guard. (See Figure 2).
TROUBLE SHOOTING AND MAINTENANCE
1. Orifice Assy: Mineral deposits on orifice can cause water flow to spurt or not regulate. Mineral deposits may be removed from
orifice with a small round file not over 1/8" diameter or a small diameter wire. CAUTION: Do not file or cut orifice materials.
IMPORTANT
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
IMPORTANT! INSTALLER PLEASE NOTE.
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO
WATER LINES IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY
OCCUR AWAY FROM THE BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A
FOUNTAIN, CREATING AN ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN
THE METAL CONTENT OF THE WATER. THIS CONDITION IS AVOIDABLE BY USING THE PROPER
MATERIALS AS INDICATED. ANY DRAIN FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE
OF PLASTIC TO ELECTRICALLY ISOLATE THE FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM.
Installer
11, 12
9
All manuals and user guides at all-guides.com
all-guides.com

96540C (Rev. G - 3/01)
EDF20C
PAGE 2
LEGEND
A = RECOMMENDED LOCATION FOR WASTE
OUTLET 1-1/4" O.D. DRAIN
B = RECOMMENDED WATER SUPPLY LOCATION
3/8 O.D. UNPLATED COPPER TUBE CONNECT
C = USE OUTER HOLES TOP AND BOTTOM FOR
CABINET MOUNTING
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
ELKAY MANUFACTURING COMPANY  2222 CAMDEN COURT  OAK BROOK, IL 60523  630.574.8484
PART NO.ITEM NO.
PARTS LIST
1
2
3
4
5
6
7
8
9
10
11
12
13
DESCRIPTION
Bubbler Assy
Screen
Bubbler Body
Orifice Assy
Regulator
Retaining Nut
Button
Cover Nut
Cabinet
Basin and Tailpipe Assy
Bottom Cover
Speed Nut
Lock Nut
45703C
60291C
45675C
40322C
61313C
10031C
40048C
40089C
26758C
21812C
26759C
70059C
75580C
8
FIG. 3
FINISHED FLOOR LINE
FIG. 1
54
1
6
3
2
7
PRINTED IN U.S.A
* SUGGESTED MOUNTING HEIGHTS*
26" (660mm) FOR SMALL CHILDREN
34" (864mm) FOR CHILDREN OR ADULTS
40" (1016mm) FOR ADULTS
**
13
FIG. 2
All manuals and user guides at all-guides.com
