Elkay LK2477CR Operating instructions

WrenchGroove joint pliers Screwdriver Sealant Tape Plumber's Putty
(2) 1/2 in Supply Lines
SAVE FOR CONSUMER
Two Handle Bar Faucet
Model # LK2477CR
INSTALLATION / OWNER'S MANUAL

1
2
Make connectionsto water lines. Use 1/2" IPS
faucet connections (1) Use wrenchestotighten
connections. Do not overtighten.
Important: After installation is completed, remove
aerator. Turn on water supply and allow both hot
and cold water to run for at least one minute each.
While water is running, check for leaks. Replace
aerator.
Place gasket (1) on bottom of newfaucet. Place
faucet through mounting holes in sink. Secure
faucet to sink using mounting nuts (2) provided.
Shut off water supply at angle stop. Remove old
faucet.Clean sink surface in preparation for new
faucet.
1
STEPS:
WARNING: Please carefully read and properly follow the instructions for installation found in this manual.

3
3
Shut off water supply.Remove handle(refer to step
1).Loosen bonnet (1) by turning it counter-clockwise
and lift out the cartridge (2).Inspect the rubber valve
seat (3) inside body (4).Make sure the wings (5) on
the two sides of the cartridge bonnet fit well into the
slots (6) on the body.Tightly bonnet (1).Reinstall the
handle.
Turn off water before proceeding! Remove index(1).
With valves in "closed" position,unscrew fastener (2)
and remove handle (3) from valve stem (4).
5
6
4
4
FOR CARE AND MAINTENANCE:
·The water in certain areas of the world can be very caustic -
standing water around the product can cause damage. Be
sure to remove standing water with a dry, soft cloth as soon
as possible.
·For polished brass finishes, as often as once a week, you
can apply a paste wax or special, non-abrasive, brass
coating (DO NOT APPLY POLISH).
·Before applying a protective coating, gently brush the entire
fixture using a soft tooth brush. This will remove any dirt or
deposit build-up.
·These simple steps will add temporary protective coating to
your faucet and extend the life of the finish.
Failure to follow care and cleaning will void your warranty.
For additional information, please visit elkayusa.com .
Congratulations on your purchase of an Elkay product.
Although your product is extremely durable, attention should
be given to the care, cleaning and maintenance of this
product. Cleaning agents and abrasives may cause damage,
which may result in oxidation and discoloration.
By following these simple guidelines for proper care and
cleaning, it will give you years of enjoyment:
TO CLEAN: Simply wipe gently with a damp cloth and blot dry
with a soft towel. A common rule of thumb is: when you dry off,
dry off your product.
·Avoid build-up of soap, toothpaste or mineral deposits, as
these tend to have an adverse effect on the appearance of
the product.
·NEVER use cleaning products of any kind on this product -
especially those containing ammonia, bleach or alcohol - or
those with any form of abrasive.
CARE AND CLEANING INSTRUCTIONS
2
1
2
1
CARTRIDGE REPLACEMENT

What is not covered:
1. Damage caused by accident, negligence, misuse, abuse, improper
installation or operation or failure to follow care or installation instructions
enclosed with your product.
2. Damage occurring during shipment of the product (claims must be
presented to the carrier).
3. Normal wear and tear.
4. Labor charges, costs of removal and reinstallation, and any damages
to other property.
5. All industrial, commercial and business use whose purchasers are hereby
extended a limited lifetime on mechanical parts and 5 years on finish.
THIS LIMITED WARRANTY IS EXPRESSLY IN LIEU OF ANY OTHER
WARRANTIES, EXPRESSED IMPLIED, ARISING BY LAW OR
OTHERWISE, INCLUDING WITHOUT LIMITATION, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. THIS LIMITED WARRANTY MAY NOT BE
ALTERED, VARIED, OR EXTENDED, EXCEPT BY A WRITTEN
INSTRUMENT EXECUTED BY ELKAY. THE REMEDY OF REPAIR OR
REPLACEMENT AS PROVIDED UNDER THIS LIMITED WARRANTY
IS EXCLUSIVE. IN NO EVENT SHALL THE MANUFACTURER BE
LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES TO
ANY PERSON, WHETHER OR NOT OCCASIONED BY NEGLIGENCE
OF ELKAY, INCLUDING WITHOUT LIMITATION DAMAGES FOR
LOSS OF USE, COSTS PROPERTY DAMAGE OR OTHER
MONETARY LOSS.
Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied warranty
lasts, so the above limitations or exclusions may not apply. This warranty
gives you specific legal rights and you may also have other rights which
vary from state to state.
This warranty covers product installed in the United States and Canada
RP50098 Set Screw
RP10005 Index (B)
RP38205 Aerator
RP64085 Wearable Ring RP64061 Inverter H
RP64062 Inverter C
P36164 Screw
RP10004 Index (R)
RP13146 Handle
RP60008 O-Ring
P35300 Washer
P36160 Mounting Nut
RP22008 Seat & Spring
RP22010 Cartridge
RP70193 Bonnet
RP70106 Ring
What you must do to obtain warranty service:
6245 Shiloh Rd, Suite B, Alpharetta, GA 30005 or call 866-237-3907 .
Please provide date of purchase and installation, description of nature
of the defect, and model number ordescription of model and/or component part.
Elkay
elkay.com
©2018 Elkay
Model # LK2477CR (Rev. date: 09/18)
REPLACEMENT PARTS
Elkay warrants that all parts and finishes of the Elkay Residential brand
faucets are free from defects in materials and workmanship for the life of
the product, if purchased after 1996.This warranty extends to the
original consumer purchaser of the product only.
If the product should leak or drip during normal use, Elkay will provide,
free of charge, a replacement cartridge. For other defects in material or
workmanship, Elkay will, at its option, supply replacement parts (or if no
longer available a comparable product). Elkay reserves the right to
examine product in question and its installation prior to replacement.
WARRANTY
ELKAY LIMITED LIFETIME WARRANTY
