INSTALLATION / OWNER'S MANUAL
Double Handle Kitchen Faucet
Model LKEC2037
INCLUDES:
WrenchGroove joint pliers Screwdriver Sealant Tape Plumber's Putty
RECOMMENDED TOOLS:
SAVE FOR CONSUMER
OPTIONAL 2.2GPM FLOW
REGULATOR
You choose the flow rate!
This faucet ships with an
eco-friendly 1.5GPM flow regulator
installed.
If you desire higher flow rate, a
2.2GPM flow regulator has also
been included in the box.
Switching the flow regulator is
simple! See the "Flow Regulator
Replacement" section for details.
1/2 in Supply Lines
Important!

WARNING: Please carefully read and properly follow the instructions for installation found in this manual.
1
23
4
5
6
5
2
3
4
6
11
24
3
STEPS:
Shut off water supplies. Clean sink or
countertop surface. Place flange
assembly (2) through the center hole
on the sink or contertop(3) . Then lock
it with rubber washer (4) and metal
washer (5) and nut (6). Then place the
rubber washer (1) on the flange.
Place new faucet (5) through the three
holes in top of sink or countertop (6).
From underside, assemble metal
washer (2) and nut (3) onto valve body
(1) and tighten nut (3). and then tighten
the screws (4) . Do the same on the
opposite side. Do not overtighten.
From underneath the sink or
countertop (3), align block (1) and
tabs (2) on Quick connects.Push
Quick connect housing firmly upward
and snap onto receiving block. Pull
down moderately to ensure
connection has been made. If it is
necessary to remove quick connect,
squeeze tabs on hose between index
finger and thumb, then pull down to
disconnect. After connecting the
hose, install the weight (4) at the
lowest point of the hose.
Make connections to water lines with 3/8"
female compression supply hoses(1).
If additional hose length is needed, attach
included 1/2" MIP thread adaptors (2) to
supply hoses (1). Use 1/2" I.P.S. faucet
connections (3) or coupling nuts (5) with
3/8" O.D.ball-nose riser (4) to make
connections to water lines. Use wrenches
to tighten connections. Do not overtighten.
To prevent damage to the internal
parts of your faucet from debris that
may have collected in the water
lines, it will be necessary to flush
the faucet. Remove spray head (1).
Turn on hot and cold water supplies.
Flush water lines for one minute.
Reinstall the spray head tightly.
3
5
4
1
2

1
2
CARTRIDGE RELACEMENT
Shut off water supplies!
Loosen the screws(2) and raise the
faucet(1). turn the tubes(3) clockwise.
Loosen the cartridge nut (1) and
Remove the old cartridge (2) and
replace with the new cartridge. Replace
the cartridge nut (1) .
CARE AND CLEANING INSTRUCTIONS
Congratulations on your purchase of an Elkay product. Although
your product is extremely durable, attention should be given to the
care, cleaning and maintenance of this product. Cleaning agents
and abrasives may cause damage, which may result in oxidation
and discoloration.
By following these simple guidelines for proper care and cleaning, it
will give you years of enjoyment:
TO CLEAN: Simply wipe gently with a damp cloth and blot dry with
a soft towel.
A common rule of thumb is:
when you dry off your hands, dry off your product.
·Avoid build-up of soap, toothpaste or mineral deposits, as these
tend to have an adverse effect on the appearance of the product.
·NEVER use cleaning products of any kind on this product -
especially those containing ammonia, bleach or alcohol - or those
with any form of abrasive.
FOR CARE AND MAINTENANCE:
·The water in certain areas of the world can be very caustic -
standing water around the product can cause damage. Be
sure to remove standing water with a dry, soft cloth as soon
as possible.
·Before applying a protective coating, gently brush the entire
fixture using a soft tooth brush. This will remove any dirt or
deposit build-up.
·These simple steps will add temporary protective coating to
your faucet and extend the life of the finish.
Failure to follow care and cleaning will void your warranty.
For additional information, please visit elkayusa.com.
Turn the tubes (3) counterclockwise and
reinstall the faucet(1). Tighten the
screw (2). Do not overtighten.
Note: Install cartridge correctly for
proper handle rotation.
The faucet ships with a 1.5GPM aerator installed. An
optional 2.2 GPM aerator is also included in the box.
To switch the flow rate of the faucet:
1. Disassemble the quick connect assembly by
separating the connector (1) and quick connect (2).
2. Replace 1.5 GPM connector(green) with the 2.2GPM
connector.
3. Reinstall quick connect assembly.
1
1
2
1
2
FLOW REGULATOR REPLACEMENT
1
2
3
1
2
3
CW to loosen CCW to tighten

P05140* Aerator Assembly
WARRANTY
Elkay
elkayusa.com
2222 Camden Court, Oak Brook,IL 60523
1-630-572-3192 Fax: [phone] © 2011 Elkay
LKEC2037
P99359(Rev. date: 05/2011)
ELKAY LIMITED LIFETIME WARRANTY
LIMITED LIFETIME WARRANTY
Elkay warrants that all parts and finishes of its Elkay Residential brand
faucets are free from defects in materials and workmanship for the life
of the product, if purchased after 1996. This warranty extends to the
original consumer purchaser of the product only.
If the product should leak or drip during normal use, Elkay will provide,
free of charge, a replacement cartridge. For other defects in material or
workmanship, Elkay will, at its option, supply replacement parts (or if no
longer available a comparable product). Elkay reserves the right to
examine product in question and its installation prior to replacement.
What is not covered:
1. Damage caused by accident, negligence, misuse, abuse, improper
installation or operation or failure to follow care or installation instruc-
tions enclosed with your product.
2. Damage occurring during shipment of the product (claims must be
presented to the carrier).
3. Normal wear and tear.
4. Labor charges, costs of removal and reinstallation, and any damages
to other property.
5. All industrial, commercial and business use whose purchasers are
hereby extended a limited lifetime on mechanical parts and 5 years on
finish.
What you must do to obtain warranty service:
Either write to Elkay, attention Customer Care, 2222 Camden Court,
Oak Brook, IL 60523 or call 1-800-223-5529. Please provide date or
purchase and installation, description of nature of the defect, and model
number or description of model and /or component part.
THIS LIMITED WARRANTY IS EXPRESSLY IN LIEU OF ANY OTHER
WARRANTIES, EXPRESSED IMPLIED, ARISING BY LAW OR OTHERWISE,
INCLUDING WITHOUT LIMITATION, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. THIS
LIMITED WARRANTY MAY NOT BE ALTERED, VARIED, OR EXTENDED,
EXCEPT BY A WRITTEN INSTRUMENT EXECUTED BY ELKAY. THE
REMEDY OF REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
LIMITED WARRANTY IS EXCLUSIVE. IN NO EVENT SHALL THE MANUFAC-
TURER BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES
TO ANY PERSON, WHETHER OR NOT OCCASIONED BY NEGLIGENCE OF
ELKAY, INCLUDING WITHOUT LIMITATION DAMAGES FOR LOSS OF USE,,
COSTS PROPERTY DAMAGE OR OTHER MONETARY LOSS.
Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied warranty
lasts, so the above limitations or exclusions may not apply. This
warranty gives you specific legal rights and you may also have other
rights which vary from state to state.
This warranty covers product installed in the United States and Canada.
REPLACEMENT PARTS
P01318* Handle kit
Faucet body kit
P35312 Washer
P35313 Washer
RP70001 Cartridge nut
P29257 Cartridge cold
Valve body assembly
P51006* Hand Spray
RP64166 Plastic Insert
RP64171 Use for LKEC2037AS
Spout
P33010 Hose Tee Assembly
P48064 Hand Spray hose kit
P29258 Cartridge hot
P44278 Hose weight kit
P05135 2.2GPM Flow Regulator
P46468 Quick Connect
P05134 1.5GPM Flow Regulator
P37144 O-Ring
P38111 Screw
P37142 O-Ring
P46466 Block
Flange kit
RP60076 Ring
RP60075
O-RING
P29259 Nut
P29260 Screw
P46471 Adjuster
P35304 Washer
P35305 Washer
P36167 Nut
P80311 Wrench
P46471 Adjuster
P35314 Washer
P35313 Washer
P35312 Washer
RP70001 Cartridge nut
P46472 Thread adapter
