Elkay LK1000 Operating instructions

Screwdriver
SAVE FOR CONSUMER
OPTIONAL 2.2GPM AERATOR
Groove joint pliers (2) 1/2 in Supply Lines Wrench Sealant Tape Plumber's Putty
INSTALLATION / OWNER'S MANUAL
You choose the flow rate!
This faucet ships with an
eco-friendly 1.5GPM flow regulator
installed.
If you desire higher flow rate, a
2.2GPM flow regulator has also
been included in the box.
Switching the flow regulator is
simple! See the "Flow Regulator
Replacement" section for details.
Important!
LK1001
Single Handle Kitchen Faucet
Model # LK1000, LK1001
LK1000

WARNING: Please carefully read and properly follow the instructions for installation found in this manual.
Shut off water supplies. Screw bolt
(1) onto the escutcheon (2). If your
model has a spray, proceed to step
2. If your model does not have a
spray, skip to step 4.
Place faucet in position on sink. From
under sink, screw mounting nuts onto
faucet. Tighten mounting nuts. Hand
tighten only.
STEPS:
1
For models with spray:
Insert spray hose down through the
support and sink. Attach the spray hose to
the connection beneath the faucet by
aligning the tabs on quick connector. Push
quick connector housing firmly upward
and snap onto receiving tube tab. Pull
down moderately to ensure connection
has been made.
If it is necessary to remove the quick
connector, squeeze tabs on hose between
index finger and thumb, then pull down to
disconnect.
Make connections to water lines.
Use 1/2" I.P.S. faucet connections (1)
or use coupling nuts (3) with 3/8"
O.D.ball-nose riser(2).
Use wrenches to tighten connections.
Do not overtighten.
1
Important: After installation is completed,
remove aerator assembly. Turn on hot
and cold water supplies. Turn handle to
full open position for one minute. Check
for leaks. Replace aerator.
3
2
For models with spray ( fits 4 - hole
sinks ): Insert spray support through
far right - hand hole on sink. Screw
hold - down nut onto shank and hand
tighten.
4-Ø1-3/8" (Ø35mm)
1
2

6
FOR CARE AND MAINTENANCE:
·The water in certain areas of the world can be very caustic -
standing water around the product can cause damage. Be
sure to remove standing water with a dry, soft cloth as soon
as possible.
·For polished brass finishes, as often as once a week, you
can apply a paste wax or special, non-abrasive, brass
coating (DO NOT APPLY POLISH).
·Before applying a protective coating, gently brush the entire
fixture using a soft tooth brush. This will remove any dirt or
deposit build-up.
·These simple steps will add temporary protective coating to
your faucet and extend the life of the finish.
Failure to follow care and cleaning will void your warranty.
For additional information, please visit elkayusa.com.
CARE AND CLEANING INSTRUCTIONS
FLOW REGULATOR REPLACEMENT
This faucet ships with a 1.5GPM aerator installed. An
optional 2.2GPM aerator is also included in the box.
To switch the flow rate of the faucet:
1. Disassemble aerator assembly by separating the
aerator shell (1), aerator (2) and washer (3). Remove
existing aerator (2) and install the new aerator.
(2.2GPM=Red, 1.5GPM=Green)
2. Reinstall the aerator assembly.
Congratulations on your purchase of an Elkay product.
Although your product is extremely durable, attention should
be given to the care, cleaning and maintenance of this
product. Cleaning agents and abrasives may cause damage,
which may result in oxidation and discoloration.
By following these simple guidelines for proper care and
cleaning, it will give you years of enjoyment:
TO CLEAN: Simply wipe gently with a damp cloth and blot dry
with a soft towel. A common rule of thumb is: when you dry off,
dry off your product.
·Avoid build-up of soap, toothpaste or mineral deposits, as
these tend to have an adverse effect on the appearance of
the product.
·NEVER use cleaning products of any kind on this product -
especially those containing ammonia, bleach or alcohol - or
those with any form of abrasive.
Shut off water supply. Remove set screw plug (1). With
valves in "closed" position, unscrew set screw (2) and
remove handle (3) from valve stem (4). Loosen the
screw (7) from valve stem (4). Loosen the cap (5) from
the sleeve (6).
3
1
2
Loosen sleeve (1) by turning it counter-clockwise and lift
out the cartridge (2). Remove the old cartridge and
replace with the new cartridge. Replace sleeve and
tighten. Reinstall the handle.
CARTRIDGE REPLACEMENT
3
5
7
4
1
2
2
1

THIS LIMITED WARRANTY IS EXPRESSLY IN LIEU OF ANY
OTHER WARRANTIES, EXPRESSED IMPLIED, ARISING BY LAW
OR OTHERWISE, INCLUDING WITHOUT LIMITATION, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE. THIS LIMITED WARRANTY MAY NOT
BE ALTERED, VARIED, OR EXTENDED, EXCEPT BY A WRITTEN
INSTRUMENT EXECUTED BY ELKAY. THE REMEDY OF REPAIR
OR REPLACEMENT AS PROVIDED UNDER THIS LIMITED
WARRANTY IS EXCLUSIVE. IN NO EVENT SHALL THE
MANUFACTURER BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES TO ANY PERSON, WHETHER OR NOT
OCCASIONED BY NEGLIGENCE OF ELKAY, INCLUDING WITHOUT
LIMITATION DAMAGES FOR LOSS OF USE, COSTS PROPERTY
DAMAGE OR OTHER MONETARY LOSS.
Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied warranty
lasts, so the above limitations or exclusions may not apply. This
warranty gives you specific legal rights and you may also have other
rights which vary from state to state.
This warranty covers product installed in the United States and Canada.
What is not covered:
1. Damage caused by accident, negligence, misuse, abuse, improper
installation or operation or failure to follow care or installation instructions
enclosed with your product.
2. Damage occurring during shipment of the product (claims must be
presented to the carrier).
3. Normal wear and tear.
4. Labor charges, costs of removal and reinstallation, and any damages
to other property.
5. All industrial, commercial and business use whose purchasers are
hereby extended a limited lifetime on mechanical parts and 5 years on
finish.
P05139* 2.2GPM
Aerator (Red)
P36159 Mounting Nut
P05138* 1.5GPM
Aerator (Green)
LK1001 Spout Base
Elkay
elkayusa.com
©2011 Elkay
REPLACEMENT PARTS
Model # LK1000, LK1001
P99344 (Rev. date: 07/2011)
P45746* Spray
P37142 O-ring
P46466 Block
P36158 Bolt
RP70330 Gasket
P37141 O-ring
P35298 Washer
P28137 Diverter
RP33042* Spout
For LK1000
LK1000 Spout Base
P01296* Handle
P38111 Set Screw
P38112 Set Screw Plug
RP80004* Cap
P29247 Cartridge
RP70309* Sleeve
P36163 Screw
P01297* Handle Kit
ELKAY LIMITED LIFETIME WARRANTY
Elkay warrants that all parts and finishes of the Elkay Residential brand
faucets are free from defects in materials and workmanship for the life of
the product, if purchased after 1996. This warranty covers the
original consumer purchaser of the product only.
If the product should leak or drip during normal use, Elkay will provide,
free of charge, a replacement cartridge. For other defects in material or
workmanship, Elkay will, at its option, supply replacement parts (or if no
longer available a comparable product). Elkay reserves the right to
examine product in question and its installation prior to replacement.
WARRANTY
What you must do to obtain warranty service:
Either write to Elkay, attention Customer Care, 2222 Camden Court,
Oak Brook, IL 60523 or call 1-800-223-5529. Please provide date of
purchase and installation, description of nature of the defect, and
model number or description of model and/or component part.
ELKAY LIMITED LIFETIME WARRANTY
