Elkay PSR Series User manual

Cutout in No. of
Inside Countertop 11/2" Dia.
Overall Each Bowl (11/2" Radius Faucet Minimum Ship.
Model L W L W D Corners) Holes Cabinet Wt.
Number A B C D E L W 4" Center Size Lbs.
PSR3319 33 191⁄214 14 71⁄4323⁄8187⁄81, 2, MR2, 3, 4 or 5 36 16
PSR3321 33 211⁄4131⁄216 71⁄2323⁄8205⁄81, 2, MR2, 3, 4 or 5 36 17
PSR4322 43 22 19 16 71⁄4423⁄8213⁄81, 2, MR2, 3, 4 or 5 48 20
GENERAL
Fine quality Pacemaker double bowl hospitality sink seamlessly
drawn of #20 gauge, type 304 (18-8) nickel bearing stainless
steel. Self-rimming.
DESIGN FEATURES
Bowl Depths: 7-1/4" (PSR3319 and PSR4322), 7-1/2" (PSR3321).
Coved Corners: 1-3/4".
Bowl and Faucet Deck Recess: 3/16" drop ledge.
Finish: Exposed surfaces are polished to a lustrous, highlighted
bright satin finish.
Underside: Fully undercoated to prevent condensation and
deaden sound. PSR3321 underside is fully protected by heavy
duty Sound Guard®undercoating.
OTHER
Drain Openings: 3-1/2".
Faucet Holes: Available with 0, 1, 2, MR2, 3, 4 or 5, 1-1/2"
diameter faucet holes 4" centers.
NOTE: Unless otherwise specified, sink is furnished with 4
faucet holes.
Elkay 2222 Camden Court
Oak Brook, IL 60523 Printed in U.S.A. ©2003 Elkay
(Rev. 10/03) 1-75D
www.elkayusa.com
Model PSR33214
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice. This specification describes an Elkay product with design, quality and functional benefits to the user. When making a comparison of other producers’ offerings, be certain these features are not
overlooked.
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
SINK DIMENSIONS (INCHES)*
*Length is left to right. Width is front to back..
Pacemaker®Double Bowl Sink
20 Gauge – Type 304 – Self-Rim
Model PSR Series
®
SPECIFICATIONS
Model PSR33214 Illustrated
4"
C C
DB
E
1-3/4" R
1-3/4" R
1-1/4"
A
4" 4"
HOLE DRILLING
CONFIGURATIONS
4"
4"
4" 4"
4" 4" 4"
4" 4" 4" 4"
1
2
MR2
3
4
5
These sinks comply with ANSI Standard A112.19.3M.
These sinks are listed by the International Association
of Plumbing and Mechanical Officials as meeting the
requirements of the Uniform Plumbing Code.
