Elmes Electronic CBP32 User manual

- 1 -
Alarm Control Panel CBP32
(ver. 1.10, 09.2018)
Installation and operation manual
INTRODUCTION......................................................................................................................2
OPERATING CBP32 CONTROL PANEL 3
1. Arming and disarming the system using a remote 3
2. Arming & disarming using a GSM phone (recommended) 3
3. Emergency arming & disarming alarm from CBP32 panel buttons 4
Arming the system bypassing selected alarm zones. 4
CBP32 SELECTED FUNCTIONS DESCRIPTION...................................................................4
ALARM ZONES MONITOR 4
EMERGENCY POWER BACKUP 5
ANTI-SABOTAGE PROTECTION OF THE PANEL CABINET 5
OPERATION WITH WIRED ALARM DETECTORS 5
OPERATION WITH REMOTE CONTROL TRANSMITTER (REMOTE) 5
OPERATION WITH EXTERNAL WIRELESS SIREN 5
INTERNAL GSM MODULE FUNCTIONS 6
CBP32 PANEL CONFIGURATION AND FIRMWARE UPDATE USING PC 6
MAIN MENU AND PROGRAMMING THE CBP32...................................................................6
ALARM MEMORY 6
FAILURES 6
SERVICE SETTINGS 7
1. Event Memory 7
2. Password Change 7
3. Zone Settings 7
4. Outputs Settings 9
5. System Users - adding, removing and editing user 10
6. Times Setting 12
7. GSM Functions 12
8. Auxiliary functions settings. 14
9. System arming signalling modes. 16
10. System Status 16
SETTINGS RESET ................................................................................................................17
RESETTING PASSWORD OF USER 1. 17
RESTORING CBP32 TO FACTORY SETTINGS (DEFAULT SETTINGS). 17
ALARM SYSTEM INSTALLATION........................................................................................17
POWER SUPPLY:SELECTION OF TRANSFORMER AND BATTERY 18
SEQUENCE OF POWER SUPPLY CONNECTION 19
WIRED DETECTORS INSTALLATION 19
EXAMPLE OF ALARM SYSTEM WITH CBP32 CONTROL PANEL 20
WIRED DEVICES CONNECTION DIAGRAMS WITH CBP32 CONTROL PANEL 21
SPECIFICATION....................................................................................................................22
MANUFACTURER’S LIMITED WARRANTY.........................................................................23
FREQUENTLY ASKED QUESTIONS....................................................................................24

- 2 -
INTRODUCTION
Elmes Electronic CBP32 is a programmable alarm control panel with integrated mobile phone
module, designed for use in anti-theft, intrusion detection, access control and remote control
installations. It operates with Elmes Electronic made wireless detectors, RP501 transmitter-
receiver set, remote control transmitters and any wired detectors. The panel supports up to 16
system users, up to 6 wired detectors and up to 32 wireless detectors. It features eight pro-
grammable all-purpose control outputs out of which two are high current and six are OC type
outputs. The panel can be programmed with the use of buttons and LCD display placed on
board of the panel. In addition, the control panel can be programmed, configured and firm-
ware updated with the use of personal computer (PC). CBP32 control panel is AC mains
transformer powered with 17-18VAC secondary output and 12V battery as backup power.
General features of CBP32 control panel:
-integrated mobile phone GSM module for SMS & CLIP(*) arming, disarming and notification,
- 32 wireless and two wired parametric alarm zones with user defined names,
- six parametric inputs for connecting wired detectors,
- identification of up to 16 users,
- panel programming with buttons and LCD on board or, with personal computer (USB),
- arming and disarming of the panel with hand held remote or GSM mobile phone,
- wide range of alarm zone types,
- functional modes of partial arming of the control panel (day and night modes),
- panic and robbery alarm function (call for help) activated by a remote,
- memory of the last 256 events with event type and the time of its occurrence.
- acoustic signalling (beeps) of “chime” type zone violation,
- monitoring of wireless detectors and external devices presence,
- operation with Elmes Electronic WSS wireless external siren & strobe,
- two parametric outputs S1 and S2 (**), rated up to 700mA at 12VDC, with electronic over-
load current protection and anti-sabotage wires cut or short circuit protection,
- control outputs O1÷ O6 (**) are open collector type (OC) and rated up to 100 mA,
- outputs S2 and O1÷ O6 are programmable and all-purpose type,
- outputs feature programmable set on timing in the range from 1 up to 999 seconds,
- radio jamming sabotage protection signalling in zone 30,
- RF signal and interference level monitor in form of bar graph line displayed on panel’s LCD,
- optional panel configuration and firmware update with personal computer (PC),
- powering of the panel with 17-18VAC alternating current,
- control panel backup power with 12V battery of 1.2 ÷ 17Ah capacity.
(*) CLIP - Calling Line Identification Presentation –a GSM feature meaning that user can
arm/disarm control panel just by making a call to its phone number. Also, the panel can noti-
fy user of alarm by calling the user/operator phone number.
(**) symbols used on the panel board.
CAUTION! This control panel has been designed to be as effective as possible. However,
there are circumstances that alarm system may fail to operate as expected for variety of
reasons. Users and installers are warned that radio signals from wireless detectors and
sensors may not reach the CBP32 panel under all circumstances. Metal objects placed on
radio transmission paths, deliberate jamming or other radio signal interference can seri-
ously reduce operating range.

- 3 -
OPERATING CBP32 CONTROL PANEL
Operating alarm system with CBP32 control panel mean system arming and disarming with
periodical check up of its functioning state. Arming and disarming is made by remotes or
phones registered in the system. The use of GSM phone allows notification of failures and
state of the system, remote blocking of alarm zones and controlling outputs of the panel, in
addition to arming and disarming of the system. State of the system, i.e. its armed mode, dis-
armed or failed to operate properly is SMS notified on SMS request send by the user.
System failure is notified by SMS to the user, beeps by the build in beeper and flashing of the
Failure LED on the panel board. Checking the cause of the failure may be done by SMS or,
on the panel board by long pressing OK button.
Browsing the control panel menu is made by using the following buttons:
▲◄ ►▼ - menu navigation cursors,
OK - menu entry and setting acceptance,
C - CANCEL button for cancelling setting and exit.
Alarm system arming and disarming
Arming and disarming may be made by the use of hand held transmitter (called later “remote”)
or GSM phone registered in the system. It is also possible to it with the use of buttons on
the control panel board. In the case of GSM phone, arming and disarming is made by
sending an appropriate text message (SMS) or call (CLIP) to the phone number of the
panel. Every disarming of the system results in immediate stop of alarming (setting OFF
alarm sirens).
1. Arming and disarming the system using a remote
The CBP32 panel can operate with Elmes Electronic made remotes in two ways (see pt. 5.7):
1.1 Remote arms and disarms the system.
Control panel may be armed/disarmed with the use of one, two or four button remote. With
the use of one button remote alarm system can be armed and disarmed alternately. With
two buttons remote, the second button may also arm the system in night mode. Four but-
tons remote features buttons for all optional modes of system arming (see pt. 5.7).
No matter which remote model, the use of standard system arming button triggers one
signal pulse on one or more outputs: S1, S2, O1 or built-in siren (see pt. 9 on page 16)
and the countdown of exit delay time starts. The system arms on the delay passage. The
use of system disarm button triggers two loud sound signals and the system disarms. If,
while in the armed state, intruder alarm occurred then five loud sound signals will be pro-
duced.
Arming system in night mode is similar to standard arming (exit delay is also used) with
the difference that signal pulse will appear on one of outputs S2, O1 or on buzzer. Arming
in day mode is different, it is instant and no exit delay is used.
1.2 Remote activates entry zone delay only.
In this mode pressed remote button activates entry delay in zone type “remote delayed”
for predefined delay time, signalled by two loud beeps. Now, system should be disarmed
using wireless keypad KB1. Violation of “remote delayed” zone while in entry delay count-
down without system disarming will set up intruder alarm after passage of the delay.
2. Arming & disarming using a GSM phone
The GSP32 control panel may be remotely armed and disarmed by SMS command or CLIP
call from any registered phone number listed in the panel memory. Phone numbers for the
panel control and monitoring are registered for system users in Service Settings pt. 5.5.

- 4 -
3. Emergency arming & disarming alarm from CBP32 panel buttons
This operating method is not recommended as requires opening the control panel cabinet.
Nevertheless, in case of emergency, e.g. no access to system registered phone or lost re-
mote, there are two possible methods of system arming/disarming using the panel buttons:
1. If “day/night” mode is set OFF (see pt. 8.5 menu) - by entering user’s password (by default:
▲▲▲▲) followed by OK will arm the system or, disarm the system if it was armed. Exit delay
time counts down starts prior to system is armed.
2. If “day/night” mode is set ON (see pt. 8.5 menu) - by entering user’s password followed by
OK will allow selection of one of four methods of system arming:
“▲- disarm” - disarming the alarm system –“disarmed” status appears on dis-
play. Anti-sabotage zones “24h” remain armed.
“◄- arm” - arming the system. On the end of the exit delay (signalled acoustically and
optically with displayed time countdown on the LCD panel), all alarm zones ex-
cept blocked are armed. “Armed” status appears on display.
“►- day” - partial arming in day supervision mode. The zones earlier defined as “day
armed” and the “24h” zones are armed (as in pt. 3.1). The “day mode” message
appears on display.
“▼- night” - partial arming in night supervision mode. At the end of exit delay (signalled
acoustically and optically) all alarm zones are armed, except for blocked zones
and zones earlier defined as „night disabled” (as in pt. 3.1.). The “night armed”
message appears on display.
Arming the system bypassing selected alarm zones.
If, in the course of arming the system, one of the zones is violated, the reaction of the system
depends on whether the zone was earlier defined as “bypass” type (see pt. 3.1.g) or not:
-if the zone function is defined as “bypass” (Y) –the system generates 3 beeps on arm-
ing using remote or panel buttons and waits 8 seconds for user’s decision whether to
arm the system bypassing violated zone. Acceptance with the use of remote or panel
OK button arms the system bypassing that zone. If no action is detected (>8s) arming
procedure is cancelled. Arming with the use of mobile phone will arm the system and
SMS notification will be send informing of the bypassed zone.
-if the zone is not defined as “bypass” type (N) – the system generates 3 beeps on arm-
ing using remote and will not arm. When arming using panel buttons displays message
“Violated zones” with zone name and system will not arm. In that case, the cause of the
zone violation should be cleared and a new arming should be made. While arming by
mobile phone, the system will respond by sending SMS with information on violated
zones.
See also S.S. pt. 9 –“System arming signalling modes”
CBP32 SELECTED FUNCTIONS DESCRIPTION
Alarm zones monitor
CBP32 control panel allows checking operation of all detectors by displaying all alarm zones
simultaneously. To activate this function button “◄” must be pressed and hold down until two
16 bar graph lines scale appear on the LCD panel displaying status of all 32 alarm zones of
the CBP32 control panel. Any violated zone produces “*” mark (star) to be momentarily dis-
played on the LCD at dot position corresponding to zone number in which violation was de-
tected. Sabotage activation displays mark “S”. Function deactivation is made by “◄” button.

- 5 -
Emergency power backup
The control panel is designed to operate with typical 12V sealed lead rechargeable battery
used for alarm system application. The battery charging current is user set by jumper “ISET”
on the panel board. For 1.2Ah battery capacity the jumper should be set to 130mA current
and for typical batteries of higher capacity, e.g. 5Ah, 7Ah or 17Ah, the jumper must be set to
450mA charging current. In order to protect battery against destructive discharge, the panel
disconnects the battery automatically, if battery voltage drops below 10,2V level.
In addition, the control panel performs regular battery tests. Detected battery failure, or battery
absence are notified to the user/alarm system operator.
Anti-sabotage protection of the panel cabinet
In order to enable anti-sabotage protection of the control panel cabinet TAMPER switch of the
cabinet should be connected in series with 1kOhm resistor to any of six wired detector input
zones of the panel (see example on diagram 5), then unblock the zone using buttons on the
panel board and close cabinet cover. Since now, any opening of the cabinet cover will gener-
ate sabotage alarm. If the panel cabinet cover/door must be opened for any reason, the only
way to do it without generating sabotage alarm, is to block the sabotage zone by sending ap-
propriate SMS command (pt. 5.6.9).
Operation with wired alarm detectors
CBP32 provides six input zones Z1÷Z6 for connecting wired alarm detectors with NC (normal-
ly closed) outputs. The wired inputs are shared with panel’s wireless inputs 1÷6 and may be
operated together (see pt. 3.3). The wired detectors are connected to the panel according to
diagram 2 (resistors 1k and 3k3 Ohm are supplied with the panel).
NOTICE! Zones Z1÷Z6 are blocked by default.
Operation with remote control transmitter (remote)
The use of Elmes made remotes with Elmes CBP32 control panel allows remote arm-
ing/disarming of alarm system as well as enables personal panic alarm. Detailed description
of using a remote with the panel may be find in pt. 1 of Operating CBP32 Control Panel chap-
ter. Programming (learning) a remote to a user of the control panel is described in pt. 5.3 of
menu “Users”. Activation of the panic alarm is made in pt. 8.6, while pt. 9.4 and pt. 9.5 of the
service settings are used for setting how the control panel will signal the use of a remote.
Operation with external wireless siren
The Elmes CBP32 wireless panel can operate with dedicated external wireless sound and
strobe siren Elmes WSS with periodical siren presence check test. The siren is powered by
external mains power pack (delivered with the siren) that recharges internal sealed battery be-
ing siren’s main source of power supply. The following steps are required to set Elmes WSS
wireless siren to operate with the CBP32 control panel:
1. Learn the siren to alarm zone line 29 of the CBP32 panel by selecting detector learning
mode (see 3.3) and activating the siren to transmit RF signals in one of the three ways, as
below:
a. Connecting siren’s battery while mains power supply is off.
b. Connecting or disconnecting mains power while battery is connected.
c. Activating siren’s housing top cover sabotage switch.
2. Set required alarming time at S1 of the panel that equals to alarming time of the wireless
siren (pt. 4.3).
3. Set in pt. 6.4 required time interval (1 to 99 minutes –20 minutes as standard) for wireless
siren presence checking frequency and enable radio link testing (pt. 8.2).

- 6 -
4. Choose the way alarm system signals failure of radio link between wireless siren and the
control panel. If the system is expected to set on loud alarm along with failure indication,
the function in pt. 8.8 should be set ON. If only failure indication is required then the func-
tion should be OFF.
5. If control panel is armed/disarmed by a remote, its use may be signalled by signal pulses
on external siren (pt. 9.4 and 9.5).
NOTICE! To avoid loud sabotage alarm during external siren’s installation or maintenance
temporarily disable (block) alarm zone 29.
Internal GSM module functions
The following functions are available when using CBP32 panel with active SIM card: remote
arming and disarming of alarm system by SMS or CLIP call; requesting system status notifica-
tion; remote disabling (blocking) of alarm zones, SMS notifications send to up to 8 mobile
phones on alarms, arming/disarming, AC supply failure and return as well as system failures.
The notifications include information of the source of the event. In case of alarm and the con-
trol panel makes also a CLIP call to registered phone numbers. It may also operate with any
GSM mobile monitoring system by responding to its test signals and sending cyclic SMS or
making CLIP calls.
Control panel outputs may be toggled on/off by SMS command and may control variety of de-
vices such as switching on/off lighting, heating, etc. The devices should be controlled via ex-
ternal power relay as shown in diagram 3.
CBP32 panel configuration and firmware update using PC
The CBP32 control panel can be easily configured and firmware updated with the use of Win-
dows® based PC (Personal Computer). To connect the panel to personal computer a USB in-
terface cable with one mini USB plug is needed (ordered separately). Proper cable installation
is red LED signalled on the panel board. For data transmission installation of virtual series
COM port drivers at the PC are necessary. In recent Windows® versions the drivers load au-
tomatically. The COM port drivers as well as dedicated “CB32 Configurator” software for PC
are free for download from the CBP32 panel manufacturer web site: www.elmes.pl .
Before any data is sent to or received from the CBP32 panel, the following steps should be
followed:
1. In the options of “CB32 Configurator” new serial COM port must be selected that appears
on the list of COM ports, after connecting the USB cable to PC.
2. By holding down button ▲ at power on, the panel is forced to set up communication mode
with PC. Flashing “?” sign on the panel’s LCD confirms the mode has been entered.
MAIN MENU AND PROGRAMMING THE CBP32
To access the main menu of the CBP32 panel press and hold down OK button for more than
two seconds. Navigate the menu using vertical and horizontal cursor buttons ▲,◄, ►,▼.
Confirm option selection by OK button while annulations and exit with C button. Exit menu
with C button or, automatically, if no user activity is detected for more than 90 seconds. Main
menu consists of four submenus:
Alarm Memory
In this menu details of the latest alarms are displayed: date, time and zone of the alarm(s)
source. The use of ▲▼ buttons selects earlier or later events respectively, while the use of
◄► buttons selects between alarm type and alarm source, e.g. “Intruder alarm” ↔ “kitchen”.
Failures
This menu is designed to view the causes of the failures signalled on the control panel by
flashing yellow “ALARM” LED. Failures signalled on the control panel include:

- 7 -
▪Mains power supply failure (no mains).
▪Backup rechargeable battery absence or failure.
▪Failure of communication with wireless detectors.
▪Detector’s low battery (replacement need).
▪GSM module network connection failure.
▲▼buttons are used to scroll through failures, if many.
The “ALARM” LED stops flashing when cause of failure is cleared.
System Status
In this menu there are two submenus are available:
1. Displays level of received GSM signal by built-in module in graphic mode. Minimum of four
bar level is required for proper functioning. Lower lever requires change of panel placement.
2. Control panel firmware version is displayed.
Service Settings
Access to Service Settings menu is enabled only if the control panel is disarmed and upon en-
tering a valid password code confirmed by OK button. Factory setting of the password for the
user No.1 is „▲▲▲▲”. Exit from the menu and cancelling entries are made by the C button.
Users Nos. 1-4 (administrators) have access to all functions whereas other users may access
functions 1-2 only. All editable service settings available in this menu are described further.
1. Event Memory
Service settings → Event Memory
This menu allows viewing detailed information on last 256 events that occurred in the system
(alarms, failures, arming, disarming, errors, etc.). Event memory cannot be edited, and allows
only viewing the event details in the sequence of their occurring date and time. Buttons ▲▼
select an earlier or later event while ◄► buttons select between type of event and its source,
e.g. “Arming” ↔ “John”.
2. Password Change
Service settings → Password change
This menu allows changing user’s own password. Password of other users can be changed in
the “Users” menu (see pt. 5). After accessing this menu “Enter password” prompt appears.
Enter new password containing 3 to 6 signs ▲,◄, ►,▼ and then press OK. When the “Re-
peat password” prompt appears, enter the new password again and press OK. The new
password replaces old one. In case of entering an existing or incorrect password “Wrong
password” message appears.
3. Zone Settings
This menu contains number of submenus. Entering any submenu with ▲▼ buttons selects
zones while ◄► buttons select between zone number or zone name, e.g. “Zone no 1” ↔
“Kitchen”. After selecting a zone confirmed by OK following submenus are accessed:
3.1. Alarm zone function.
Service Settings → Zone Settings → Zone function
This menu of CBP32 control panel allows assigning special functions to alarm zones. Buttons
▲▼ select one of the functions described below while ◄► buttons allow setting the function
ON (Y) or OFF (N). OK button accepts the selection while the use of C button cancels chang-
es and exits the menu without saving changes.
a) “24h” - 24 hour zone, e.g. anti-sabotage zone (permanently armed),
b) “day armed” - zone armed in day supervision mode selection,
c) “night disabled” - zone disabled in night supervision mode,
d) “remote delayed” - entry zone with delay set on by a remote;
e) “delayed” - standard entry zone with delay;
f) “chime” - door chime feature generates signal pulses at one of selected outputs,

- 8 -
or beeps on panel’s internal buzzer on zone violation (see pt. 9.6).
g) “bypass” - zone that can be left disarmed if violated on system arming.
h) “silent alarm” - zone violation sets on silent panic alarm (no siren sounds) and panel’s
outputs type “silent alarm” will set on. If the zone is required to be armed
all the time, function “24h” must be on as well.
A standard zone has functions a ÷c set off and supervises when the system is in “armed” or
“night armed” mode and does not supervise when system is “disarmed” or “day armed".
IMPORTANT: Zones can have assigned more than one special function, but some functions
exclude others. In that case, only one selection is valid, e.g.:
-if a zone is “active 24h” then functions such as “day armed”, “night disabled” have no
meaning.
Examples of zones with assigned functions:
“chime”zone generates two beeps sound signal on every violation of the zone (e.g. noti-
fying store personnel of customer entrance).
“remote delayed” zone – when remote’s button is pressed “entry time” countdown is
started and the zone is not active. Its violation will not trigger an instant alarm but only af-
ter “entry time” has passed. It allows the user to disarm alarm system with the use of valid
password input on wireless keypad KB1.
“delayed” zone – its violation (by entering the zone) triggers “entry time” countdown, dur-
ing which the system must be disarmed to prevent from system intruder alarm.
Basement or a garage zone can be “day armed”.
A „bypass” zone allows arming the alarm while intentionally leaving e.g. window opened
protected by CTX detector (see “System Arming”).
3.2. Zone name.
Service settings →Zone Settings → Zone name
This menu allows alarm zones used in the system to have user defined up to 16-character
name, e.g.: kitchen, living room, office, Mark’s Room, etc. Upper and lowercase letters, digits,
space and characters “-,./” are accepted.
Buttons ◄► select the successive letters position of the name while the ▲▼ buttons browse
character table for selection. Accept name with OK button. Use C button to exit the menu.
3.3. Learning wireless detectors to control panel.
Service settings → Zone Settings → Learning detectors
It is recommended to learn wireless detectors starting from zone 7 (*).
After selecting a zone number “OK-remove” prompt appears on display, if detector is already
learned to the zone. Pressing OK button deletes detector in the zone. If zone is vacant, “OK-
learn” will appear on the LCD. Pressing OK button starts learning detector to the zone. In re-
sponse to the “Awaiting trans. 1” and “Awaiting trans. 2” prompts, two successive alarm
transmissions must be triggered in detector (**).Correct learning will be followed by “OK-
correct” message. Errors are signalled by 3 beeps and “Program error” message. The use of
C button exits the menu.
(*) Zones 1÷ 6 are intended for wired and/or wireless detectors installation and are disabled
(blocked) by default. If wireless detector is to be learned to any of these zones, it must be en-
abled (unblocked) and its wire input shorted to ground (COM) with 1kOhm resistor (supplied).
If a wired detector is to be installed in that zone as well, which is possible, then it may create
ambiguity issue when both detectors signal zone violation simultaneously. Therefore, it is not
recommended to install in these zones detectors with permanent set on output, e.g. door open
magnet detector, but detectors with momentary set on, e.g. PIR movement detector.
(**) IMPORTANT! Wireless detectors cannot be learned to the panel by the use of sabotage
TAMPER switch to activate radio transmission. For detailed information on how to learn any
Elmes detector to CBP32 control panel please refer to instruction manual of the detector.

- 9 -
Description of wired detector installation in zones 1÷ 6 can be found on page 19.
3.4. Zone disabling.
Service settings → Zone Settings → Zone disabling
Zone number is selected with ▲▼ buttons while buttons ◄► disable (block) and enable the
zone. Accept selection with OK button. Exit the menu with C button.
3.5. Radio range test.
Service settings → Zone Settings → RF range test
To assess the level of radio reception of signals received from detectors, the most distant de-
tectors in particular, the CBP32 panel is provided with “RF range test” function allowing the
received signal level to be displayed on 16 bar graph scale of panel’s LCD.
After entering this menu all RF signals in the 433.92MHz radio band will be displayed in form
of bar graph. The detectors should be triggered to send alarm transmissions. The longer the
distance of the detector from the control panel, or the greater difficulty in radio waves propa-
gation, the lower the level of received signals and the length of the displayed bar graphs. If the
number of displayed bars is lower than three it should be assumed it does not guarantee reli-
able alarm operation. The location of detectors or the control panel should be changed in
search for better RF reception or, Elmes Electronic made repeater TRX should be installed to
prolong operating range of wireless detectors.
The “RF range test” function allows also assessing levels of all local RF signals in the
433.92MHz band, also those that can interfere and disturb operation of the wireless alarm
system. The test should be carried out prior to permanent installation of alarm devices or, in
tracing causes of short operation range. To find out any interfering signals, the LCD 16 bar
graph scale readouts should be observed without activation of own detectors. Frequent or
continuous unknown RF signals received and signalled on the control panel display indicate
close presence of other RF devices operating in the same RF band. If level of these signals
exceeds three bars displayed in the “RF range test” function and their occurrence is frequent,
acceptable signals from detectors may not be received and the alarm system may fail to oper-
ate properly.
4. Outputs Settings
This menu contains some submenus. Entering any of them select output number with ▲▼
buttons while the use of OK button opens submenu:
4.1. Output types.
Service Settings → Outputs → Output type
This menu allows allocation of wired outputs of the control panel. Outputs S1 and S2 are high
current draw with up to 700 mA rating, short circuit protected and providing 12VDC on output
set on. These outputs may be sabotage protected (see pt. 8.3).
Outputs O1÷O6 are low current draw, OC type with up to 100 mA rating. Overload of these
outputs, such as direct connection to +12V, may cause their damage.
Output S1 is “alarming” type and its function cannot be changed. It is intended for connecting
an external siren. The remaining outputs may have assigned the following functions:
“alarming”
for connection of outdoor/external alarm signalling devices, e.g. external siren
or/and strobe;
“AC power
failure”
signalling 230VAC power supply failure/cut off
“arming”
output active when system armed mode is armed or night armed and inactive
when system is disarmed or in day armed mode;
“failure”
signalling any failure state in system (also 230VAC power failure)
“SMS con-
trolled”
output controlled by SMS. Examples of SMS controlling panel output named
PUMP are shown below:

- 10 -
„PUMP T” - permanently sets output on;
„PUMP N” - sets output off;
„PUMP” - sets output on for time specified in pt. 4.3;
„PUMP 15” - sets output on for 15 seconds;
„PUMP 10:30” - sets output on for 10 minutes and 30 seconds;
„PUMP 1:00:00” - sets output for 1 hour.
Output maximal set on time is 18 hours, 12 minutes and 15 seconds.
„silent
alarm”
output will be set on, if zone type “silent alarm” has been violated (pt. 3.1h), or
silent panic alarm is activated (pt. 8.6).
Example: if output O2 is “arming” type and the output connects LED to detector’s supply out-
put (AUX) in series with 1kOhm resistor then it will stay lighted on for as long as the system is
armed offering additional signalling or warning option.
Outputs S1, S2 and O1 may also pulse signal system arming and disarming, violation of zone
with “chime” function and exit time countdown (see pt. 9).
Output type is defined by accessing the menu, selecting output number with ▲▼ buttons, ac-
cepting with OK, selecting output type with ▲▼ or ◄► buttons, accepting with OK button.
4.2. Output name.
Service Settings → Outputs → Output name
This menu allows every output to have any up to 16-character long name e.g. “OVEN”,
“Lamp”, etc. Upper and lower case letters, digits and “-,./” signs are accepted while “space”
sign is not allowed. Instead of sample name “lamp garden” a name “lamp-garden” should be
used. Output’s names are used only if controlled by SMS.
In the menu ◄► buttons are used selecting character position of the name and ▲▼ buttons
selecting appropriate character. Defined name is accepted with OK and exit menu with C.
4.3. Outputs set on time.
Service Settings → Outputs → Output time
This menu is used to define individual set on time, ranging from 1 to 999 seconds, of outputs
type “alarm”, “silent alarm” and “SMS controlled”. Set on time defined for any other output type
is irrelevant. Set on time defined for output S1 also defines set on time for external wireless si-
ren (Elmes Electronic WSS), if installed.
5. System Users - adding, removing and editing a user
This menu contains submenus. Entering any submenu with ▲▼ buttons selects system user
number while ◄► buttons select between displaying user number or user name, e.g. “User 1”
↔ “John Dutch”. Accept user selection with OK and pass on to submenu:
5.1. Setting and editing user password.
Service Settings → System Users → Password
Please follow detailed instructions in “Password Change” menu (S.S. pt. 2).
To delete user’s password press OK button when “Enter password” prompt appears. On next
prompt “OK-delete password” press OK button again. “Password deleted” message confirms
password is deleted.
5.2. User name change.
Service Settings → System Users → Name
Please follow detailed instructions as in “Zone name” menu (S.S. pt. 3.2)
5.3. Remote transmitter learning and deleting.
Service Settings → System Users → Learning a remote
In this menu a remote is added to user or deleted. Please follow detailed instructions in
“Learning detectors” menu (S.S. pt. 3.3). In order to learn all buttons (2 or 4) of multi channel

- 11 -
remote to the control panel, the last button must be used while learning the remote, i.e. sec-
ond or fourth. Operation mode of the remote can be set on in pt. 5.7 of Service Settings.
5.4. Disabling user.
Service Settings → System Users → Disabling user
Please follow detailed instructions as in “Zone disabling” menu (S.S. pt. 3.4). After disabling a
user, its remote and password are inactive. In order to disable user’s control of CBP32 panel
by SMS or CLIP, the functions should be set off in pt. 5.6.9 and pt. 5.6.10 of S.S.
5.5. Mobile phone number.
Service Settings → System Users → Phone number
This menu allows entering user’s mobile phone number. The number must be preceded by
national dialling code number, without the “+” sign. Example: 33xxxxxxxxx for France.
5.6. Mobile phone functions.
Service Settings → System Users → Phone functions
This menu allows selection (Y/N) of notifications, messages, commends and SMS/CLIP func-
tions required to be active operating CBP32 control panel with user’s GSM phone:
1) SMS on alarm - sending SMS on alarm set on;
2) SMS on arming - sending SMS to control panel phone number: “arm” to arm and
“disarm” to disarm alarm system;
3) SMS on powering - sending SMS on mains power failure and return;
4) SMS on radio link off - sending SMS on radio link failure;
5) SMS on low battery - sending SMS on low battery;
6) SMS on other failures - sending SMS on other failures (e.g. accumulator failure);
7) Alarm CLIP - making alarm CLIP call;
8) Descriptive SMS <-> SMS with ID codes –selection of SMS content: event description
such as “Intruder Alarm” or the use of special codes defined in pt. 7.9, 7.10 and 7.11.7.
9) SMS accept - SMS commands (as below) acceptance received by CBP32.
ARM, DISARM, NIGHT and DAY- sets appropriate arming mode;
DISABLE zone_name - disables zone: zone_name;
ENABLE zone_name - enable zone: zone_name;
STATUS - in response control panel sends SMS on current armed/disarmed
status and failure events;
TIME HH:MM - sets current time in control panel;
TEST - sets up instant test procedure and starts time count to next test
under condition that “Test every time interval” is selected in pt.
7.11.2 and “Execute test” function is selected in pt. 5.6.12.
LAMP - sample control command for output named LAMP. Detailed de-
scription of controlling outputs by SMS commands can be found
in pt. 4.1.
10) CLIP arming - remotely arming and disarming CBP32 pane by CLIP call (by calling the
panel phone number). Panel is disarmed if call is rejected after one ring. If
the call is rejected after three rings, the panel is armed.
11) Call back - calling back function. If the control panel is called by user/operator, it will call
back. This and next function may be used in operation with monitoring centre:
a) if the function is set off, CBP32 panel rejects the call after 3-4 seconds and
does not call back to calling number,
b) if the function is set on, the control panel rejects the call and calls back.
12) Execute test - executing SMS or CLIP time interval test by CBP32 panel. The function
may be used in operation with monitoring centre. See also pt. 7.6, pt. 7.7
and pt. 7.11 of Alarm Notification by GSM section.

- 12 -
5.7. Remote transmitter type and operation mode.
Service Settings → System Users → Remote type
This menu allows selection of remote’s operation modes. Description: 1CH-one channel re-
mote, 2CH-two channels remote, 4CH-four channels remote.
1CH: arm/disarm -any selected button alternatively arms and disarms control panel. Re-
maining buttons of, e.g. 4-channels remote, may be used for other purposes.
2CH: arm/disarm, night/disarm - button 1 (green) of 2-channels remote (*) alternately arms
and disarms control panel while button 2 (red) arms in night mode and disarms the panel.
2CH: disarm, arm - button 1 (green) of 2-channels remote (*) disarms while button 2 (red)
arms the panel.
This mode allows real time clock channel of Elmes STX remote transmitter may be used to
arm/disarm CBP32 control panel automatically, at predefined times.
2CH: disarm, night arm - button 1 (green) of 2-channels remote disarms while button 2 (red)
arms in night mode.
4CH: disarm, arm, night, day arm - button 1 (green) disarms system, button 2 (red) arms, but-
ton 3 (blue) night arms, button 4 (grey) day arms.
Remote sets on delay - remote sets on entry delay in “remote delayed” zones (see pt. 3.1.d).
6. Times Setting
This menu allows setting up different times in alarm system. The ▲▼ and ◄► buttons are
used to select current date and time, OK button accept selection and C cancelling selections.
6.1. System date/time setting.
Service Settings → Times Setting → System date/time
This menu allows setting system current date and time. To be set on power supply cease.
6.2. Entry delay time (0..99s)
Service Settings → Times Setting → Entry delay
This menu allows setting entry time delay needed for entering protected premises and disarm-
ing alarm system before intruder alarm is activated (in seconds: 0-99).
6.3. Exit delay time (0..99s)
Service Settings → Times Setting → Exit delay
This menu allows setting time delay needed to exit premises (in seconds: 0-99) after alarm
system arming from remote, phone or panel buttons.
6.4. Wireless siren check up interval (1..99 minutes).
Service Settings → Times Setting → WSS siren check-up interval
This menu allows setting time interval between checking of Elmes WSS wireless siren pres-
ence (in minutes: 1 to 99) - as standard set to 10 minutes.
6.5. CBP32 panel clock adjustment.
Service Settings → Times Setting → Clock adjustment
This menu allows adjustment of control panel clock fast/slow run within -99 to +99 steps
range. Decreasing steps slow the clock while increasing steps speed up clock. One adjust-
ment step equals 0,0864 second faster/slower clock run per day (24h).
7. GSM Functions
This menu allows definition of settings for notifications, remote control and other functions of
GSM module in the CBP32 panel.

- 13 -
7.1. SMS centre phone number.
Service Settings → GSM Functions → SMS Centre Number
This menu is used to enter the phone number of GSM operator’s SMS centre, preceded by
country code dialling without “+” mark in front. This is important if option in pt. 7.11.6 “Use en-
tered SMS centre no” is selected. If option “Use default SMS centre no” is selected, then this
field can be left empty. Example: the following phone number should be entered for Plus GSM
operator (PL): 48601000310
7.2. Alarm SMS daily limit.
Service Settings → GSM Functions → Alarm SMS daily limit
Feature allowing limitation of daily (24h) SMS notifications send by CBP32 control panel on
system alarm, arming and disarming. Limit is to 99 by default and resets daily at 12:00 hours.
7.3. Failure SMS daily limit.
Service Settings → GSM Functions → Failure SMS daily limit
Feature allowing limitation of daily (24h) SMS notifications on system failures send by CBP32
control panel and registered in event memory. Failures are divided into 4 categories. First cat-
egory includes “Mains power failure”, “Accumulator failure” and “System restart”, second “Ra-
dio link failure”, third “Low battery” and fourth “short circuit at S1, S2 or AUX outputs”.
SMS notification limit for each category is set to 10 by default and resets daily at 12:00 hours.
Change of the limit (10) results in limit change in all categories and CBP32 event memory.
7.4. Calling duration.
Service Settings → GSM Functions → Calling duration
This feature defines duration of CBP32 calling, e.g. CLIP calling notification on alarm. It
should be set to the time duration allowing user to reject call before the time lapses, if function
“Alarm CLIP once” (S.S. pt. 7.11.5) is set off. See also pt. 5 of FAQ section of manual.
7.5. SMS password.
Service Settings → GSM Functions → SMS password
This menu is used to enter a maximum 6-character password that will precede SMS com-
mand text, if option “SMS with password” is selected in pt. 7.11.3.
7.6. Test SMS.
Service Settings → GSM Functions → Test SMS
This menu is used to enter Test SMS content send by GSM module, if test function is set on in
pt. 5.6.12 and “Test as SMS” option is selected in pt. 7.11.1.
7.7. Interval / Test time.
Service Settings → GSM Functions → Interval/Test time
This menu is used to enter time interval (if option “Test interval” is selected in pt. 7.11.2) or,
test time (if option “Test time” is selected in pt. 7.11.2), if the CBP32 control panel is expected
to perform SMS or CLIP test. Maximum value is 24h. This feature is valid only if “Execute test”
option is selected in pt. 5.6.12.
7.8. Phone Module ON/OFF.
Service Settings → GSM Functions → GSM Module ON/OFF
This menu is used to toggle on/off control panel GSM module operation. Enter the menu with
OK and select GSM Module ON or OFF using ◄► buttons.
7.9. SMS ID codes.
Service Settings → GSM Functions → SMS ID codes
This menu is used to enter two character ID codes send in SMS event notifications. Each
code contains any two characters except for lower case letters. To set the CBP32 panel to

- 14 -
send ID codes instead of standard text notification, e.g. “Intruder alarm: kitchen”, option “SMS
with ID codes” must be selected in S.S. pt. 5.6.8.
7.10. Definition of monitoring station subscriber account number .
Service Settings → GSM monitoring → Subscriber account number
This menu is used to define subscriber code (max. 8 characters) used by monitoring station
operating in e.g. “Ademco Contact ID” to identify SMS notification sender (see pt. 7.11.7).
7.11.Auxiliary GSM settings.
Service Settings → GSM Functions → Aux GSM settings
1) Test as CLIP or Test as SMS - interval test as CLIP call (default) or SMS.
2) Execute test at time or Execute test after interval - test executed daily at predefined test
time (default), or test after predefined time interval.
3) SMS with password - if Y SMS send to CBP32 must begin with password (default N).
4) Letter case sensitive - N (no) (default). If selected Y (yes), the control panel is SMS letters
case sensitive.
5) Alarm CLIP once - if this function is set off (default), control panel expects CLIP notification
rejection. If the call (see pt. 7.4) is not rejected, the panel disconnects and repeats CLIP
call twice. If the function is set on (Y), CLIP calling is made once only, even the call is
not rejected. It does not refer to a control CLIP that is made only once as standard.
6) Use default SMS centre no or Use entered SMS centre no –selection of the first option
(default) allows CBP32 panel to use SMS centre number supplied with SIM card, while
selection of the second option causes CBP32 to use centre number entered in pt. 7.1.
7) Ademco Contact ID→ Subscriber + event code → Subscriber + event code + zone no
The settings is valid only, if “SMS with ID codes” is set on in pt. 5.6.8 and allows selection
of one of three SMS notification patterns send to monitoring station:
1) ”Ademco Contact ID” pattern. SMS notification has the following form:
CCCCQEEEGGZZZ
where “CCCC” stands for subscriber code set in pt. 7.10. Other elements are defined by
the user, e.g. three digits event number “EEE”. NOTE: if monitoring station requires digits
“18” to appear before “CCCC” then subscriber’s code should input as “18CCCC” in
pt.7.10.
2) ”Subscriber + event code” pattern. SMS notification has the following form:
CCCCEE
where CCCC stands for subscriber code set in pt. 7.10 and “EE” event code set in pt.7.9.
3) ”Subscriber + event code + zone no” pattern. SMS notification has the following form:
CCCCEEZZ
where CCCC is subscriber, “EE” event code and end “ZZ” is zone or user number.
8. Auxiliary functions settings.
This menu contains auxiliary functions and options for alarm system configuration. Use ▲▼
buttons to browse between functions and ◄► buttons to change setting. OK button saves se-
lection. Exit menu any time with C button without saving selections.
8.1. Jamming protection (default N)
Service Settings → Aux functions → Jamming protection
This function allows radio jamming anti-sabotage protection of wireless alarm system. If se-
lected (Y), it will activate sabotage alarm in zone 30 on all deliberate or incidental jamming in
used radio band.

- 15 -
8.2. Radio link test (default N)
Service Settings → Aux functions → Radio link test
Setting this function to (Y) enables monitoring of the detector presence. Cyclic radio link
transmissions sent from detectors (except CTX3H) are received by CBP32 control panel. If,
for any reason, radio link transmission from a detector is not received during 24 hours, “radio
link failure” sabotage alarm sets on.
8.3. Sabotage protection of S1 output (default N)
Service Settings → Aux functions → Output S1 Test
This function enables sabotage protection of output S1, if installed alarm siren is not provided
with dedicated sabotage connectors. Setting the function on will generate sabotage alarm in
zone 32, if siren wires connected to S1 are cut off or shorted to ground (COM). Before the
function is set on, it is necessary to check that polarizing resistor is installed between output
AUX (+12V) and output S1 so, when the output S1 is off its voltage is at within +05...6V range.
Such resistor can be directly connected to the control panel connectors or, to appropriate
connectors inside the siren. When output S1 testing is on, the control panel monitors voltage
level at S1 connectors and sets sabotage alarm, if wires cut or shorted is detected.
8.4. Sabotage protection of S2 output (default N)
Service Settings → Aux functions → Output S2 Test
As described above, but for output S2 with sabotage alarm in zone 31.
8.5. Activating partial day & night arming modes (default N)
Service Settings → Aux functions → Day/night mode
Activating the function (Y) will display additional menu on LCD allowing selection of supervi-
sion modes confirmed by password and the OK button. There are 4 modes available: 1 - dis-
armed, 2 - armed, 3 –day, 4 –night (see also: “Arming/disarming alarm system”). With the
function set off (N), the menu is not displayed and system can be armed and disarmed from
the control panel buttons without partial arming options. However, night mode arming is still
possible, if arming by remote (see details in pt. 5.7) or by GSM phone.
8.6. Setting on panic alarm or call for help function.
Service Settings → Aux functions → Panic alarm off / Loud panic alarm / Silent panic alarm
This function allows activation of panic alarm for users equipped with remote control by longer
than two seconds pressing the remote’s button. Control panel starts alarming and registers
the event as panic alarm with name of the user that activated the alarm and sends appropriate
SMS notification. Loud panic alarm differs from silent panic alarm by setting on outputs type
“silent alarm” while alarm sirens remain off (see pt. 4.1).
Switching activated panic alarm OFF is done by entering a password from keypad or by the
use of a remote, if this option is set on for the remote (pt. 5.7).
8.7. Control panel buttons beep (default Y)
Service Settings → Aux functions → Buttons beep
This option allows setting on/off beep signals when control panel buttons are used.
8.8. Alarm on radio link withWSS siren failure (default N)
Service Settings → Aux functions → WSS siren link alarm
Setting this function to yes (Y) allows loud alarm along with LED alarm notification on wireless
Elmes WSS siren radio link check-up test failure. As standard the function is set to no (N) and
the failure is signalled by flashing Alarm LED only. Failure check menu will display “Radio link
error” and name of zone 29 (if specified).

- 16 -
8.9. Limitation of alarms from one alarm zone (default Y)
Service Settings → Aux functions → Alarms limit to 3
This function limits number of alarms in one zone to three and is factory set to on (Y). Alarms
count is reset on every arming or disarming of the system. When the limit is selected to off (N)
alarm sets on every time violation is detected in the alarm zone.
8.10.Selection of menu language: Polish/English.
Service Settings → Aux functions → Język polski / English language
This function allows selection of the panel’s menu language using ◄► buttons.
NOTE! Change of menu language can be made also with button ▲ pressed on connecting
power supply to the panel.
8.11. Beep when failure detected (default N)
Service Settings → Aux functions → Beeps when failure
Setting this function to yes (Y) allows control panel internal buzzer beeps on detected failures.
9. System arming signalling modes.
Service Settings → Arming signalling modes
This menu allows selection of alarm system arming and disarming signalling mode. Use ▲▼
buttons to toggle between functions and ◄► to change setting. OK button saves selection.
Exit menu any time with C button without saving selection. The following options are possible:
9.1. Remote: pulses or Remote: pulses + SMS if problem –selecting the first option sets on
sound pulses on sirens only (**). Selecting second option allows sound pulses on sirens and
SMS notification if any problem occurs (*).
9.2. SMS: SMS or SMS: pulses + SMS if problem –selecting first option a return SMS is send
on arming SMS. Selecting second option sets on sound pulses (**), while SMS notification is
received only if problem occurs (*).
9.3. CLIP: SMS or CLIP: pulses + SMS if problem –selecting first option a return SMS is re-
ceived on CLIP arming. Selecting second option sets on sound pulses (**), while SMS notifi-
cation is received only if problem occurs (*).
9.4. Pulses on WSS -setting on/off arming sound pulses on wireless Elmes WSS siren.
9.5. Pulses on S1 , Pulses on S2 , Pulses on O1 , Pulses on internal buzzer –setting on
arming signalling sound pulses on S1, S2, O1 and buzzer. Signalling may be set on for all
outputs independently.
9.6. Chime and countdown on S1 ↔ …on S2 ↔ . …on O1 ↔ …on internal buzzer –setting
on sound pulses on Chime zone violation and arming countdown pulses on one of outputs S1,
S2, O1 or internal buzzer.
9.7. No pulses at night or Pulses on S2 at night or …on O1 at night or …on buzzer –setting
on night arming signalling sound pulses on S2, O1 or internal buzzer.
(*) While system arming violation of supervised zone may occur. Depending on whether the
zone is “bypass” type (see pt. 3.1.g), the system will arm and SMS notification will be received
informing of the bypassed zone/s or, if the zone is not “bypass” type, the system will not arm
and SMS notification will be received with information of violated zone/s.
(**) In order to obtain sound pulses functionality, a sound siren must be connected to one of
S1, S2 or O1 outputs and sound signalling set on at that output (pt. 9.5). Internal buzzer may
also be used for the purpose.
10. System Status
10.1. Service Settings → Status → GSM signal level
Horizontal bar graph of mobile signal strength received by control panel GSM module is dis-
played. Strength level weaker than indicated by four bars only is insufficient for proper GSM
operation and control panel placement should be changed.

- 17 -
10.2. Service Settings → Status → Elmes Elektronik CBP32 ver. X.XX
Displays installed firmware version of CBP32 control panel.
SETTINGS RESET
Resetting password of user 1.
If user is disabled or its password is lost and there is no way to enter Service Settings menu,
user 1 can be enabled and have factory password “▲▲▲▲” restored, in the following way:
1. Open panel’s cabinet (sabotage alarm may occur, see page 5).
2. Disconnect AC power and remove battery.
3. Short circuit two points marked RESET (in the upper right corner of LCD).
4. Connect AC power supply and wait till start of firmware.
5. Disconnect AC power supply, disconnect shorted RESET points.
6. Connect battery, connect AC power supply.
User 1 is now enabled and its password is restored to “▲▲▲▲”. All other settings remain
unchanged.
Restoring CBP32 to factory settings (default settings).
Factory (default) settings are restored according to procedure described below. The proce-
dure restores factory settings deleting all wireless devices in memory. Records in the event
memory are not deleted.
1. Open panel’s cabinet (sabotage alarm may occur, see page 5).
2. Disconnect AC power and remove battery.
3. Short circuit two points marked RESET (in the upper right corner of LCD).
4. Holding down button ► connect AC power supply –display will show “Factory settings”.
5. Release button ► and wait until control panel restores normal operation.
6. Disconnect shorted RESET points.
7. Connect battery, connect AC supply.
ALARM SYSTEM INSTALLATION
The following accessories are needed before CBP32 control panel can be installed:
-Typical alarm system 12V battery with appropriate capacity (see chapter: power supply
and battery recommendations).
-AC/AC transformer with secondary output 17...18VAC (see chapter: power supply and
battery recommendations).
-Dedicated for alarm system control panel plastic or metal cabinet or, any cabinet suitable
for all components of the control panel and power supply. If the cabinet is made of plastic,
GSM and wireless detector radio antennas can be inside the cabinet. Anti-sabotage cabi-
net switch should be connected to the control panel according to diagram 5.
-Active SIM card, if the panel’s GSM module will be used.
SIM card for use in CBP32 control panel should have SMS memory and address book cleared
with voice mail box set off. Used SIM card may have PIN code protection set on or off. If the
PIN code is on then it should have the PIN set to 1234. This can be done using any other mo-
bile phone. The use of SIM card with other than 1234 PIN code in the CB32G control
panel may cause the card to be blocked!
Designing and installation of alarm system with the Elmes Electronic CBP32 control panel
should start with careful planning of detectors, control panel and outdoor siren placement. To
ensure satisfactory protection of secured premises a variety of detectors may be needed.
Elmes Electronic PTX50 wireless motion detector and CTX wireless magnet contact detectors
should be installed in each protected room with window. Additionally, GBX1 wireless glass
break detector could be installed for protection of windows breakage in premises and shops.
Depending on needs, up to six wired detectors of any manufacturer can be connected to par-
ametric inputs of the panel.

- 18 -
Detailed instruction manuals of devices should be observed while installing wireless or wired
detectors to the control panel.
If the control panel is to be installed inside of metal cabinet, detector’s radio antenna as well
as GSM module antenna must be installed outside the cabinet. If the cabinet is made of plas-
tic the antennas can be inside with minimum distance of few centimetres from each other.
Connections of system components to the CBP32 control panel are shown on diagram 1.
After setting up power supply (observe proper sequence) and, if the GSM module is on, the
blue GSM LED should be watched. Fast blinking LED mean the module is logging on to the
network or, the module is out of the network operating range. Slow blinking with 2-3 seconds
intervals mean the module is logged on to the GSM network. Network signal level can be
checked as instructed in pt. 10.1.
Described below steps of configuring alarm system with CBP32 control panel assume the us-
er will use hand transmitter (remote) to arm/disarm the system:
1. Set on current date and time (pt. 6.1).
2. Program a remote to the user (pt. 5.3) and select its functions (pt. 5.6).
3. Set arming signalling mode of the control panel (pt. 9.5).
4. Learn wireless detectors to control panel alarm zones (pt. 3.3) according to proce-
dures described in their manuals.
5. Check operation of wireless detectors. To do so, hold down button ◄ until two 16 bar
lines appear on display representing all alarm zones. With the help of other person
sequentially activate detectors watching for their star “*” signal displayed on the bar
corresponding to alarm zone the detector is programmed to.
6. Check radio signal level of each wireless detector by selecting “Radio range test” (pt.
3.5) submenu in the panel and, with the help of other person, activate detectors while
watching RF signal level displayed on bar scale of LCD. Weak signals (1-2 bars dis-
played) coming from detector require changing the detector’s place of installation so,
as the number of signal level bars displayed are minimum 3-4. In extreme low signal
levels, the use of Elmes Electronic TRX signal repeater may be needed to guarantee
proper signal reception by the control panel.
After the initial steps above, further setting up of the alarm system can be done, as below:
-configure external wireless siren WSS, if installed;
-set on anti-sabotage protection of output S1, if a wired siren is connected (pt. 8.3);
-set on wireless detectors radio link with the panel test (pt. 8.2);
-set on the GSM module (pt. 7.8), input phone numbers of system users and configure
their functions pt. 5.5 and 5.6);
-define users names (pt. 5.2) and learn remotes to other users (pt. 5.3);
-define alarm zone names (pt. 3.2).
Power supply: selection of transformer and battery
For powering of the control panel AC/AC transformer with secondary output of 17VAC should
be used with output power exceeding total system power requirement by at least 20%.
Selecting a backup battery, it should be assumed that the system must be operational for at
least of 12 hours inclusive of alarming time of 15 minutes (0,25h) after AC power cut off. To
perform calculations it should be assumed that:
-control panel current is ca 30mA,
-battery charge current depends on setting of jumper ISET and for battery capacity of 1,2
Ah it is 130mA while 12Ah and higher it is 450mA,
-average current draw at all AUX power outputs should sum up currents of all wired alarm
devices such as wired detectors and sirens.
Calculating required battery capacity for sample alarm system with six wired detectors and si-
ren connected according to diagram 4, assuming 12 hours system autonomy operation and
0,25 hour alarming time, we shall conclude with the following equation:
Q = 700mA * 0,25h + (30mA + 6*15mA) * 12h = 1615mAh = 1,615Ah

- 19 -
As typical alarm 1,2Ah battery capacity is insufficient so, 7Ah battery is needed with ISET
jumper set to 450mAh charging current.
Now, required summarised output current of AC transformer may be calculated:
I = 450mA + 30mA + 6* 15mA = 570mA.
So, with required 20% of surplus power, a transformer of 700mA output will be sufficient.
Sequence of power supply connection
CAUTION! Danger of electric shock. All connections should be made with 230V mains
disconnected.
1. Connect battery to the control power using the black-red wire with connectors. Observe cor-
rect polarity. Red wire connects to battery + and black to battery -.
2. Connect transformer secondary output wires to AC input of the control panel. Lastly, con-
nect fuse protected AC 230V mains supply to the transformer.
Power supply disconnection must be made in reverse sequence.
NOTE! The control panel will not initialize with only battery connection. AC power supply con-
nection will result in start of the operating system.
CAUTION! Batteries contain dangerous and poisonous substances. Do not dispose of waste
batteries with household waste. Dispose waste batteries according to your local recommenda-
tions or, ask for disposal instructions your battery supplier.
Wired detectors installation
Installation of any wired detector is made with three wire line (see diagram 2). To supply de-
tector with +12V power, appropriate detector’s power terminal should be connected to any
AUX terminal on the control panel side. Any COM terminal on the panel should be used as
common ground (-12V) while any Z1÷Z6 terminal as alarm and sabotage terminal. Next, in
submenu Disabling zones - pt.3.4, the zone to which detector is connected should be enabled
and in submenu Alarm zone function –pt.3.1, alarm function/s may be assigned to the zone.
Wired detectors are always connected to CBP32 control panel in configuration with 1k and
3k3 Ohm resistors (supplied), as shown on diagram 2. Such connection configuration allows
intruder alarming as well as detection of anti-sabotage box opening, wires cut or short circuit.
Control panel CBP32 operation with RP501 transmitter
The panel may operate with Elmes Electronic RP501 four inputs channel transmitter offering
up to four wired detectors (switches, magnets) to be monitored remotely. RP501 transmitter
can be learned to four adjacent alarm zones in the CBP32 control panel. Activating input four
of the RP501 while learning the transmitter to zone 20 of the panel will assign four RP501 in-
puts to alarm zones no 17, 18, 19 and 20. When installing RP501 transmitter respective in-
struction manual must be followed.

- 20 -
Example of alarm system with CBP32 control panel
The following illustration shows example of alarm system installation based on control panel
CBP32 with Elmes Electronic made passive infrared detectors PTX50, magnetic detectors
CTX, glass break detector GBX and hand held remote transmitter UMB100HT for system arm-
ing and disarming. The system may have installed wireless siren WSS or, any wired siren.
