Elo TouchSystems E001004 User manual

Revision B
P/N E001010
www.elotouch.com
Quick Installation Guide
NFC Reader
NFC Kit P/N: E001004
© 2017 Elo Touch Solutions, Inc. All rights reserved.
The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Affiliates (collectively “Elo”) makes no
representations or warranties with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness
for a particular purpose. Elo reserves the right to revise this publication and to make changes from time to time in the content hereof without
obligation of Elo to notify any person of such revisions or changes.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise
without prior written permission of Elo Touch Solutions, Inc.
Elo (logo) and Elo Touch Solutions are trademarks of Elo and its Affiliates.
North America
800-ELO-TOUCH
Tel [phone]
Fax [phone]
[email protected]
Europe
Tel [phone]
Fax [phone]
[email protected]
Asia-Pacific
Tel [phone]
Fax [phone]
[email protected]
Latin America
Tel [phone]
Fax [phone]
EloSales.LAT[email protected]
Elo Touch Solutions Technical Support
Online self-help:
www.support.elotouch.com
1x
2x
2x

Please go to www.elotouch.com/support to verify you have the latest drivers before installing this device.
Installation
Select the location to mount the
NFC Reader. Some systems have
more than one mounting option.
Remove the selected peripheral
cover from the display head to
expose the peripheral bay.
Gently press the NFC Reader into
the peripheral bay making sure the
connector is mated.
Install the 2 at head screws included
with the kit.
Do not adjust the NFC Reader angle
without installing the screws or damage
may occur.
Remove the protective lm from the
included mylar covers and place the
covers over the screws.
Adjust the angle as needed.
