ELTEX MA4000-PX User manual

MA4000-PX (v. 3.24.0)
Operation Manual Appendix
MA4000-PX Quick Setup Guide (v.3.24.0)
Subscriber access and aggregation node

____________________________________________________________________________________
2 MA4000-PX. Operation Manual Appendix
MA4000-PX Quick Setup Guide Version 3.24.0
TABLE OF CONTENTS
1 Abstract................................................................................................................................................................ 3
2 Connection methods for Command Line Interface (CLI)...................................................................................... 4
2.1 Telnet/SSH connection................................................................................................................................ 4
2.2 Serial port connection (console) ................................................................................................................. 4
2.3 Changing user password ............................................................................................................................. 5
3 Adjustment of PP4X network settings ................................................................................................................. 5
4 PP4X Board VLAN Configuration .......................................................................................................................... 6
5 Configuration of SNMP and SNTP services .......................................................................................................... 7
6 Automatic configuration upload settings ............................................................................................................ 7
7 IGMP configuration .............................................................................................................................................. 7
8 LACP configuration............................................................................................................................................... 8
9 Adding PLC8 boards ............................................................................................................................................. 8
10 Configuration CROSS-CONNECT and PORTS profiles for ONT ......................................................................... 9
11 Adding and configuring ONT.......................................................................................................................... 10
12 Configuration of OLT profiles—PPPoE Intermedia Agent, DHCP................................................................... 11
Relay Agent................................................................................................................................................................. 11
12.1 PPPoE Intermedia Agent Configuration .................................................................................................... 11
12.2 DHCP Relay Agent Configuration .............................................................................................................. 11
13 MA4000-pX firmware update........................................................................................................................ 12

____________________________________________________________________________________
_____________________________________________________________________________________________
MA4000-PX. Operation Manual Appendix 3
MA4000-PX Quick Setup Guide Version 3.24.0
1ABSTRACT
This operation manual describes:
Connection methods for MA4000-PX Command Line Interface (CLI) (hereinafter the
"device")
Adjustment of the device network settings
VLAN configuration for provision of various services
Configuration of SNMP and SNTP services
Automatic configuration upload settings
IGMP configuration
LACP configuration
Creation and editing of ONT profiles: Ports, Cross-Connect
Adding and editing subscriber-side devices
Configuration of OLT profiles (PPPoE_IA, DHCP_RA)
Updating device firmware
The following diagram will be used for illustrative purposes, Fig. 1:
Fig. 1—Example of the network configuration
Table 1—Service type and VLAN number description
Type of service
VLAN used
Internet
2149
VoIP
3149
IPTV (multicast)
30
STB
2349
MNG
4094

____________________________________________________________________________________
4 MA4000-PX. Operation Manual Appendix
MA4000-PX Quick Setup Guide Version 3.24.0
2CONNECTION METHODS FOR COMMAND LINE INTERFACE (CLI)
2.1 Telnet/SSH connection
Connect the network data cable (patch cord) to the COMBO port 0 located on PP4X board
installed in the PP0 slot.
SSH/Telnet connection requires the following factory settings:
Default IP 192.168.1.2
Default mask 255.255.255.0
Default GW 192.168.1.1
Login: admin
Password: password
********************************************
* Welcome to MA4000 *
********************************************
MA4000 login: admin
Password:
Technical support: http://eltex.nsk.ru/support
Thu Mar 3 16:24:54 LOCAL 2016
MA4000#
2.2 Serial port connection (console)
Null modem cable is required for this type of connection. For null modem cable wiring diagram,
see Appendix B.
To establish connection via serial port, enter the following settings:
Bit rate: 115200bps
Data bits: 8bit
Parity: no
Stop bits: 1
Flow control: no
Login: admin
Password: password
Connect to the PP4X module. If there are two PP4X boards installed, the serial port should be
connected to the master board (identified by the green 'Master' LED indicator)
********************************************
* Welcome to MA4000 *
********************************************
MA4000 login: admin
Password:

____________________________________________________________________________________
_____________________________________________________________________________________________
MA4000-PX. Operation Manual Appendix 5
MA4000-PX Quick Setup Guide Version 3.24.0
Technical support: http://eltex.nsk.ru/support
Thu Mar 3 16:24:54 LOCAL 2016
MA4000#
For security reasons, we recommend to change the default password during the first
connection (see Paragraph 2.3 Changing user password).
2.3 Changing user password
To change user settings, enter the Configure view terminal configuration mode using the
configure terminal command.
To change user password, use the user command. Pass the user name and the password as
parameters.
MA4000# configure terminal Enter the configuration mode
MA4000(config)# user <operator> password <хххххх> where <operator> is the user name,
<хххххх> is the new password
MA4000(config)# do commit Apply the configuration
MA4000(config)# do confirm Save the configuration
3ADJUSTMENT OF PP4X NETWORK SETTINGS
To enable the remote rack configuration, specify equipment network parameters according to the
existing settings for the network, where the equipment is intended to be used. We recommend to
change the network parameters of the device in CLI connection mode via the serial interface.
If there are two PP4X boards installed, enter the Configure view terminal configuration mode
using the configure terminal command and configure their synchronization with stack sync-allow
command.
MA4000# stack sync-allow
Command accepted. Automatic synchronization (if needed) will be performed in the
background shortly.
MA4000#
Use show stack command to check the PP4X synchronization.
MA4000# show stack
Stack Units
~~~~~~~~~~~
Unit Position Role Prio MAC Address Version
---- -------- ------ ---- ----------------- ---------------
*1 Left MASTER 240 a8:f9:4b:81:ae:60 3 24 0 452 44381
2 Right BACKUP 208 a8:f9:4b:81:ae:20 3 24 0 452 44381
Synchronization state in the stack: Enabled
Stack-channel State
~~~~~~~~~~~~~~~~~~~
Interface Status
-------------------- --------------------
stack-port 1/0 up
stack-port 1/1 up

____________________________________________________________________________________
6 MA4000-PX. Operation Manual Appendix
MA4000-PX Quick Setup Guide Version 3.24.0
Set the Synchronization state in the stack parameter to Enabled in the Stack Units table.
To configure PP4X module network parameters, enter the configuration mode using the configure
terminal command.
Define the required network settings. For instance: IP=192.168.205.113, Mask=255.255.255.0,
Gateway=192.168.205.230, and specify VLAN for the management network.
MA4000# configure terminal Enter the configuration mode
MA4000(config)# management ip 192.168.205.113 255.255.255.0
MA4000(config)# management gateway 192.168.205.230
MA4000(config)# management vlan 4000
MA4000(config)# do commit Apply the configuration
MA4000(config)# do confirm Save the configuration
Since VLAN (e.g. 4000) will be used for chassis management, you have to add it into the PP4X
configuration. (See Paragraph 4 PP4X Board VLAN Configuration.)
4PP4X BOARD VLAN CONFIGURATION
MA4000# configure terminal Enter the configuration mode
MA4000(config)# vlan 2149,2349,30,3149 Add all required VLANs
MA4000(vlan-2149,2349,30,3149)# tagged slot-channel 0-15 Transmit tagged
to all slot ports
MA4000(vlan-2149,2349,30,3149)# tagged front-port 1/1 Receive the traffic into
VLAN from 1/1 front-port
For port-channel
MA4000(vlan-2149,2349,30,3149)# tagged port-channel 1 Receive the traffic into
VLAN from
port-channel 1
Configuration of mng VLAN for management
MA4000(config)# vlan 4000
MA4000(vlan-4000)# tagged front-port 1/1 Receive the traffic into
VLAN from 1/1 front-port
MA4000(vlan-4000)# exit
MA4000(config)# do commit Apply the configuration
MA4000(config)# do confirm Save the configuration
Use show running config command to view the running MA4000 configuration:
MA4000# show running-config View the current configuration

____________________________________________________________________________________
_____________________________________________________________________________________________
MA4000-PX. Operation Manual Appendix 7
MA4000-PX Quick Setup Guide Version 3.24.0
5CONFIGURATION OF SNMP AND SNTP SERVICES
5.1 SNMP configuration
MA4000# configure terminal Enter the configuration mode
MA4000(config)# ip snmp agent enable Address of TFTP server for backup
MA4000(config)# ip snmp agent traps trapsv2 192.168.205.101 Configure sending traps
MA4000(config)# ip snmp agent traps trapsv2 192.168.205.101 Configure sending
informs
MA4000(config)# ip snmp agent system name MA4000 Assign the system name
MA4000(config)# do commit Apply the configuration
MA4000(config)# do confirm Confirm the configuration
5.2 SNTP configuration
MA4000# configure terminal Enter the configuration mode
MA4000(config)# ip sntp client Enable NTP service
MA4000(config)# ip sntp server 192.168.205.50 Define NTP server address
MA4000(config)# ip sntp poll-period 1000 Configure the Poll period
MA4000(config)# do commit Apply the configuration
MA4000(config)# do confirm Confirm the configuration
6AUTOMATIC CONFIGURATION UPLOAD SETTINGS
To enable automatic configuration upload to the remote server, you should enter the
configuration mode using configure terminal command. You can configure two automatic configuration
upload methods—on time or on configuration change.
MA4000# configure terminal Enter the configuration mode
MA4000(config)# backup path tftp://192.168.205.100 Address of TFTP server for backup
MA4000(config)# backup ontimer Enable the backup upload
to the remote server on time
MA4000(config)# backup ontimer-period 86400 86400 seconds timer
MA4000(config)# backup onchange Enable the backup upload
to the remote server on
configuration change
MA4000(config)# do commit Apply the configuration
MA4000(config)# do confirm Confirm the configuration
7IGMP CONFIGURATION
MA4000# configure terminal Enter the configuration mode
MA4000(config)# ip igmp snooping enable Enable IGMP SNOOPING globally
MA4000(config)# ip igmp unregistered ip4-mc drop Drop the multicast traffic
for unregistered groups
MA4000(config)# vlan 30 VLAN 30 configuration mode
MA4000(vlan-30)# ip igmp snooping enable Enable IGMP SNOOPING in the
multicast VLAN
MA4000(vlan-30)# ip igmp snooping querier enable Enable IGMP PROXY in the multicast
VLAN
MA4000(vlan-30)# do commit Apply the configuration
MA4000(vlan-30)# do confirm Confirm the configuration

____________________________________________________________________________________
8 MA4000-PX. Operation Manual Appendix
MA4000-PX Quick Setup Guide Version 3.24.0
8LACP CONFIGURATION
MA4000# configure terminal Enter the configuration mode
MA4000(config)# interface port-channel 1 Select the port-channel
MA4000(express-config-port-channel-1)# mode lacp Select the port-channel operation
mode
MA4000(express-config-port-channel-1)# exit
MA4000(config)# interface front-port 1/3-4
MA4000(front-port-1/3-4)# channel-group 1 force Add the required ports into the
group
MA4000(front-port-1/3-4)# exit
MA4000(config)# vlan 2149
MA4000(vlan-2149)# tagged port-channel 1 Select the current Port-Channel for
the specific VLANs
MA4000(vlan-2149)# exit
MA4000(config)# do commit Apply the configuration
MA4000(config)# do confirm Confirm the configuration
9ADDING PLC8 BOARDS
To add the periphery boards into the configuration, you should enter the configuration mode
using configure terminal command.
MA4000# configure terminal Enter the configuration mode
MA4000(config)# slot 3 type plc8 Add PLC8 for slot 3
MA4000(config)# do commit Apply the configuration
MA4000(config)# do confirm Confirm the configuration
MA4000(config)# do show shelf View the board state in the shelf
Shelf status
~~~~~~~~~~~~
Slot Configured Type Detected Type Version Serial # Link State Slot State
---- --------------- ------------- ------- ---------- ---------- ----------
0 none none 0.0.0.0 down Absent
1 none none 0.0.0.0 down Absent
2 plc8 plc8 3 24 0 452 OL04000222 up Operational
3 plc8 plc8 3 24 0 452 OL04000039 up Operational
4 none none 0.0.0.0 down Absent
5 none none 0.0.0.0 down Absent
6 none none 0.0.0.0 down Absent
7 plc8 plc8 3 24 0 452 OL04000901 up Operational
8 none none 0.0.0.0 down Absent
9 none none 0.0.0.0 down Absent
10 none none 0.0.0.0 down Absent
11 none none 0.0.0.0 down Absent
12 none none 0.0.0.0 down Absent
13 none none 0.0.0.0 down Absent
14 none none 0.0.0.0 down Absent
15 none none 0.0.0.0 down Absent
MA4000(config)#

____________________________________________________________________________________
_____________________________________________________________________________________________
MA4000-PX. Operation Manual Appendix 9
MA4000-PX Quick Setup Guide Version 3.24.0
10 CONFIGURATION CROSS-CONNECT AND PORTS PROFILES FOR
ONT
Configuration of cross-connect profiles
MA4000(config)# profile cross-connect INET Create and go to the
Cross-Connect profile for ONT
Internet service
MA4000(config-cross-connect)("INET")# outer vid 2149 Define the service VLAN for
Internet service
MA4000(config-cross-connect)("INET")# user vid 10 Define the internal VLAN for
Internet service in ONT
MA4000(config-cross-connect)("INET")# exit
MA4000(config)# profile cross-connect VOIP Create and go to the Cross-
Connect profile for ONT SIP VoIP
service
MA4000(config-cross-connect)("VOIP")# outer vid 3149 Define the service VLAN for
VoIP service
MA4000(config-cross-connect)("VOIP")# user vid 12 Define the internal VLAN for
VoIP service in ONT
MA4000(config-cross-connect)("VOIP")# exit
MA4000(config)# profile cross-connect MC_IPTV Create and go to the
Cross-Connect profile for
multicast service
MA4000(config-cross-connect)("MC_IPTV")# outer vid 30 Define the service VLAN for
multicast service
MA4000(config-cross-connect)("MC_IPTV")# user vid 30 Define the internal VLAN for
multicast in ONT
MA4000(config-cross-connect)("MC_IPTV")# type multicast Define the multicast service
type
MA4000(config-cross-connect)("MC_IPTV")# exit
MA4000(config)# profile cross-connect UC_IPTV Create and go to the Cross-
Connect profile for ONT UC_IPTV
service
MA4000(config-cross-connect)("UC_IPTV")# outer vid 2349 Define the service VLAN for
STB unicast service
MA4000(config-cross-connect)("UC_IPTV")# user vid 11 Define the internal VLAN for
STB unicast service in ONT
MA4000(config-cross-connect)("UC_IPTV")# exit
MA4000(config)# profile cross-connect ACS Create and go to the Cross-
Connect profile for ONT
management service
MA4000(config-cross-connect)("ACS")# outer vid 4094 Define the service VLAN for
management service
MA4000(config-cross-connect)("ACS")# user vid untagged Define the internal VLAN for
management service in ONT
MA4000(config-cross-connect)("ACS")# type management Define the management service
type
MA4000(config-cross-connect)("ACS")# exit
Configuration of ports profile
MA4000(config)# profile ports NTP-RG Create and go to the multicasting
profile
MA4000(config-ports)("NTP-RG")# veip multicast Enable IGMP Proxy on veip
interface NTP
MA4000(config-ports)("NTP-RG")# veip upstream vid 30 IGMP traffic mapping
configuration in VLAN 30
MA4000(config-ports)("NTP-RG")# veip downstream vid 30 Multicast mapping configuration

____________________________________________________________________________________
10 MA4000-PX. Operation Manual Appendix
MA4000-PX Quick Setup Guide Version 3.24.0
in VLAN 30
MA4000(config-ports)("NTP-RG")# igmp multicast dynamic-entry 0 vid 30 configuration of
the vlan multicast, which
receives the range of the
following groups
MA4000(config-ports)("NTP-RG")# igmp multicast dynamic-entry 0 group 224.0.0.1
239.255.255.255 Multicast groups range
configuration
MA4000(config-ports)("NTP-RG")# do commit Apply the configuration
MA4000(config-ports)("NTP-RG")# do confirm Confirm the configuration
11 ADDING AND CONFIGURING ONT
Consider an example of ONT configuration, which is connected to the PLC8 PON port 2, slot 7. You
have to add ELTX08001E5D ONT to the configuration with ID=10 and assign all the profiles, required for
service provision, to it.
MA4000# configure terminal Enter the configuration mode
MA4000(config)# interface ont 7/2/10
MA4000(slot-11-pon)# serial ELTX08001E5D Add ONT with PON serial
ELTX08001E5D
MA4000(config)(if-ont-2/10)# profile ports NTP-RG Assign ports NTP-RG profile
MA4000(config)(if-ont-2/10)# service 0 profile cross-connect INET Assign
cross-connect INET profile
MA4000(config)(if-ont-2/10)# service 1 profile cross-connect VOIP Assign
cross-connect VOIP profile
MA4000(config)(if-ont-2/10)# service 2 profile cross-connect MC_IPTV Assign
cross-connect MC_IPTV profile
MA4000(config)(if-ont-2/10)# service 3 profile cross-connect UC_IPTV Assign
cross-connect UC_IPTV profile
MA4000(config)(if-ont-2/10)# service 4 profile cross-connect ACS Assign
cross-connect ACS profile
Assign the default dba profile 'dba-00' to all the used services
MA4000(config)(if-ont-2/10)# service 0 profile dba dba-00
MA4000(config)(if-ont-2/10)# service 1 profile dba dba-00
MA4000(config)(if-ont-2/10)# service 2 profile dba dba-00
MA4000(config)(if-ont-2/10)# service 3 profile dba dba-00
MA4000(config)(if-ont-2/10)# service 4 profile dba dba-00
MA4000(config)(if-ont-2/10)# do commit Apply the configuration
MA4000(config)(if-ont-2/10)# do confirm Confirm the configuration
You have to check all services after the configuration procedure has been performed.
