This document provides instructions for the eluminocity GridCharge and should not be used
for any other product. This product should be installed only by a licensed contractor and/or a
licensed electrician and in accordance with all applicable state, local and national electrical
codes and standards.
Table of Contents
nstallation-manual_CH-211
v1.0.4

nstallation-manual_CH-211
v1.0.4
nside this box you will find
1) GridCharge EV Charger
2) Mounting Bracket
3) Torx T30 bolts (x2)
4) 1/4 inch expansion bolts (x3)
5) No. 8 wood screws (x3)
f any parts are damaged or missing, please contact us at [e-mail]

B for Installation
NSTRUCT ONS PERTA N NG TO THE R SK OF ELECTR C SHOCK
Read all the instructions before using this product.
This device should be supervised when used around children.
Do not put fingers into the electric vehicle connector.
Do not use this product if the flexible power cord or EV cable are frayed, have broken
insulation, or any other signs of damage.
Do not use this product if the enclosure or the EV connector is broken, cracked, open, or
shows any other indication of damage.
A device employing pressure terminal connectors for field wiring connections shall be
provided with instructions specifying a range of values or a nominal value of tightening
torque to be applied to the clamping screws of the terminal connectors.
Only for hardwired unit:
CAUT ON – To reduce the risk of fire, connect only to a circuit provided with below amperes
maximum branch circuit overcurrent protection in accordance with the National Electrical
Code, ANS /NFPA 70.
Model Current rating
CH-21140 50 A
CH-21130 40 A
Only for cord connected unit:
CAUT ON – To reduce the risk of fire, connect only to a circuit provided with below amperes
maximum branch circuit overcurrent protection in accordance with the National Electrical
Code, ANS /NFPA 70.
Model Current rating
CH-21140 50 A
CH-21130 40 A
*NEMA 6-50P wall plug required for cord connected models. Receptacle installed with the
ground facing down.
nstallation-manual_CH-211
v1.0.4

Safet Check
CAUTION!
D SCONNECT ELECTR CAL POWER PR OR TO NSTALL NG THE ELUM NOC TY
GR DCHARGE. FA LURE TO DO SO MAY CAUSE PHYS CAL NJURY OR DAMAGE
TO THE ELECTR CAL SYSTEM AND CHARG NG UN T.
MPORTANT SAFETY NSTRUCT ONS
SAVE THESE NSTRUCT ONS.
The eluminocity GridCharge shall be installed only by a licensed contractor, and/or a licensed
electrician in accordance with all applicable state, local and national electrical codes and
standards. Before installing this product, ensure compliance with local building practices,
climate conditions, safety standards, and state and local codes. Use appropriate protection
when connecting to the main power distribution cable.
WARN NG: Danger of electrical shock or injury. Turn OFF power at the panelboard or load
center before working inside the equipment or removing any component. Do not remove
Grounding Instructions
The eluminocity GridCharge must be connected to a grounded, metal, permanent wiring
system; or an equipment grounding conductor must be run with the circuit conductors and
connected to the equipment grounding terminal or lead on the product.
Recommended Tools
The following tools are recommended for eluminocity GridCharge installation:
– Vendor-supplied accessories and components:
■ Mounting bracket
■ Cable hanger bracket (optional)
■ Torx T30 bolts (x2) for securing the AC Charger to the mounting bracket
■ 1/4 inch expansion bolts (x3)
■ No. 8 wood screws (x3)
– nstaller-supplied components:
■ Conduit of appropriate trade size for power wire
■ NEMA 6-50P receptacle
■ Electrical box and wallplate
– Recommended tools:
■ Torx T30 screw driver
■ Torx T20 screw driver
■ Phillips #2 screw driver
■ Flathead slotted #5 screw driver
■ Terminal crimper
■ Stud finder
■ Level
nstallation-manual_CH-211
v1.0.4

INSTALLING THE eluminocit GridCharge
1. Use the supplied template to drill bolt holes
in the wall for the mounting bracket and the
optional cable hanger.
Note: Follow applicable accessibility
requirements for the mounting position. The
unit shall be mounted at a sufficient height
from grade such that the height of the storage
means is located between 600 mm (24
inches) and 1.2 m (4 feet) from grade per
NEC Article 625.
2. Secure the mounting bracket and the
optional cable hanger bracket to the wall
with appropriate bolts as follows:
■ For masonry walls use 1/4” expansion
bolts and torque to 78 lb•in (8.8 N•m).
■ For finished walls supported by wood
studs use #8 wood screws of 2” or above
screw length and torque to 26 lb•in
(3 N•m).
3. Align the screw holes of the mounting
bracket with the eluminosity GridCharge.
nstall and secure the eluminosity
GridCharge on the mounting bracket with
the two (2) Torx T30 screws supplied.
Torque to 13 lb·in (1.5 N·m).
4. Secure the mounting bracket and the
optional cable hanger bracket to the wall
with appropriate bolts as follows:
■ For masonry walls use 1/4” expansion
bolts and torque to 78 lb•in (8.8 N•m).
■ For finished walls supported by wood
studs use #8 wood screws of 2” or above
screw length and torque to 26 lb•in
(3 N•m).
5. Remove the screw located at the bottom of
the front cover.
6. Hold the front cover. Flip upward and then
shift leftward to separate the front cover
from the charger.
7. Remove the compartment cover.
nstallation-manual_CH-211
v1.0.4

8. Use appropriate copper wire with listed
pressure terminal connectors, such as
conductor before attachment to the terminal
blocks. Keep enough length of wire to
facilitate installation. Connect each terminal
to the correct terminal input block
connector in the compartment and torque
to 19 lb•in (2.2 N•m) .
Note:
Model Copper wire type
CH-21140 No. 6 AWG, 90 ºC
CH-21130 No. 8 AWG, 75 ºC
or 90 ºC
Note: Choose appropriate conduit in
accordance with all applicable state, local and
national electrical codes and standards.
9. Replace the compartment cover and torque
to 8.7 lb·in (1.0 N·m).
10. Replace the front cover by aligning the
hinge on the top. Secure the front cover
by the bottom screw, torque to 10.4 lb·in
(1.2 N·m).
11. Place the charger cable properly.
To view an introduction installation video, visit www.gridcharge.io
nstallation-manual_CH-211
v1.0.4

EVMU30
EVMU40
Charging interface
SAE J1772 compliant charging plug
Input rating
208-240 Vac, single
208-240 Vac, single
phase, 30 A max., 60 Hz
208-240 Vac, single
phase, 40 A max., 60 Hz
Wiring for
hardwired models
L1, L2, and Ground, hardwired with terminal block; bottom-fed
Wall plug for cord
connected models
NEMA 6-50P
NEMA 6-50P
Output rating
208-240 Vac, single
phase, 30 A max., 60 Hz
208-240 Vac, single
phase, 40 A max., 60 Hz
Standby power
< 5 W
Metering
Embedded non-revenue grade meter with 1% accuracy
Output rating
208-240 Vac, single
phase, 30 A max., 60
Hz, 7.2 kW
208-240 Vac, single
phase, 40 A max., 60
Hz, 9.6 kW
Internal residual
current detection
20 mA CCID per UL 2231
Upstream breaker
2-pole 40 A breaker on
dedicated circuit,
non-GFCI type
2-pole 50 A breaker on
dedicated circuit,
non-GFCI type
Electrical protection
Over current, short circuit, over voltage under voltage, ground fault, surge
protection, over temperature
Status indicators
AC present, charging, fault
Buttons/Switches
Charger on/off, stop charging
Option: Network
interface
WLAN
Operating temp.
-22 °F to +122 °F (-30 °C to +50 °C)
Humidity
95% related humidity, non-condensing
Charging cable
length
18 ft (5.5 m) straight cable
Ingress protection
Type 3R
Cooling
Natural cooling
Dimension
(W x H x D)
12.6 x 10.3 x 4.5 in (320 x 260 x 115 mm), excluding charging cable, mounting
plate and cable holder
Net weight
5 lbs (2 kg) excluding charging connector and cable
Certificate
UL, cUL
Specifications
nstallation-manual_CH-211
v1.0.4
CH-21130 CH-21140

nstallation-manual_CH-211
v1.0.4
EVSE Product Warranty (2016)
For products sold by eluminocity US, nc. 80 Pine Street, 24th Floor, New York, NY 10005, hereinafter
referred to as “eluminocity”, Factory Warranty is as follows:
• 3 years on Level EVSE
• 1 year on Level EVSE
• 1 year on accessories
Scop : United States/Canada/Mexico
Warranty P riod:
The warranty period will be for 36 months for Level EVSE and 12 months for DCFC and for accessories
such as brackets and pedestals from the date of the invoice or the date of the shipment, whichever is
later.
Cov rag
Eluminocity warrants the products against defects in workmanship and materials during the warranty
period. Eluminocity will replace or repair the defective Product at eluminocity’s discretion free of charge,
provided that the customer notifies eluminocity or the Product defect within the Warranty Period, and
provided that eluminocity, through inspection, establishes the existence of such a defect. Customer must
report the Product defect to an eluminocity service contact by contacting eluminocity US, nc. at:
80 Pin Str t, 24th Floor, N w York, NY 10005 T. 1.212.752.3706
Customer should provide a brief description of the defect in order to obtain a Return Merchandise
Authorization (RMA) number before returning the Product. Eluminocity accepts no responsibility or liability
for Products returned without a prior authorized RMA. Product must be returned with a copy of the original
dealer invoice or written proof of installation. n the event Customer transfers ownership of Product to a
third-party, the warranty will only transfer to the third party if the Product remains installed at the original
site. Product must also include a legible data label showing the serial number. Product must be returned
to eluminocity US, nc. in the original packaging materials or packaging providing equal protection during
shipment. Eluminocity is not responsible for damage occurring during shipment.
Eluminocity reserves the right, and at its option, to use new and/or refurbished Product for the warranty
replacement. Eluminocity further reserves the right to use Products of original or improved design in the
warranty replacement. f eluminocity replaces a Product, the Product’s Warranty period continues for the
remaining portion of the Warranty Period, without any extension thereof. All replaced Products are the
property of eluminocity.
Exclusion of Liability
Eluminocity disclaims any liability, and is not responsible for providing warranty service or support under
this Warranty for any direct or indirect damages due to:
• Transportation damage.
• mproper installation or commissioning.
• The removal, installation, or troubleshooting of the Customer’s electrical systems.
• Modifications, alterations or repair attempts by persons other than eluminocity’s authorized personnel.
• Relocation of the Product from its original installation location.
• Normal wear and tear of the Product.

eluminocity US, Inc.
80 Pine Street, 24th Floor
New York, NY 10005
TEL: [phone]
For more product information and sales inquiries,
Please contact [e-mail]
www.eluminocity.com
www.gridcharge.io
• Neglect, misuse, inappropriate operation, generators operating outside of the limits of the Product
specifications, or use in an unsuitable environment, including but not limited to damage due to
lightning strike.
• nsufficient ventilation or storage which does not meet requirements set out in the product manual.
• Force Majeure (e.g., water, ice, over-voltage, generalized corrosion, biological infestations, and other
acts of God or nature, including but not limited to earthquakes, floods, fires, lightning or storms).
• The Product’s original identification (trademark, serial number) markings have been defaced, altered,
or removed.
• Non-compliance with relevant safety standards or regulations.
• Cosmetic shortcomings where damage to the exterior or casing of the Product does not influence or
affect the operation of the Product, or the supply of energy from the Product.
• Missing items (ex: screws, brackets).
• nstallation by a non-licensed contractor.
Limitation of Liability
TO THE EXTENT PERMITTED BY APPLICABLE LAW, OTHER THAN THE EXPRESS WARRANTY
SET FORTH IN THIS WARRANTY, ELUMINOCITY MAKES NO ADDITIONAL WARRANTIES,
EXPRESS OR IMPLIED, AND DISCLAIMS ALL IMPLIED WARRANTIES, WHETHER IN FACT OR BY
OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OR CONDITIONS
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. ANY WARRANTIES THAT
MAY NOT BE DISCLAIMED UNDER APPLICABLE LAW IS LIMITED IN INCIDENTAL OR
CONSEQUENTIAL DAMAGES, LOSSES, COSTS OR EXPENSES, HOWEVER ARISING , WHETHER
IN CONTRACT OR IN TORT, INCLUDING WITHOUT RESTRICTION, ANY ECONOMIC LOSSES OF
ANY KIND, ANY LOSS OR DAMAGE TO PROPERTY, OR ANY PERSONAL INJURY. IN NO EVENT
WILL ELUMINOCITY’S LIBILITY UNDER THIS AGREEMENT EXCEED THE PURCHASE PRICE PAID
FOR THE PRODUCT AT ISSUE.
Gov rning Law
This Agreement shall be governed by, and construed in accordance with the laws of the State of New York
without reference to conflicts of law principles. Any dispute arising out of this Agreement shall be
submitted to the exclusive jurisdiction of the state and federal courts of New York.
