ELUSIVE WILDLIFE Blind Sider-X2 User manual
Blind Sider-X2™ Feeder/Bait Light
Thank you for purchasing the Blind Sider-X2™ Feeder/Bait Light from Elusive Wildlife
Technologies, LP. Hunting or viewing wildlife after sunset is extremely exciting, yet very
challenging. The Blind Sider-X2™ provides just the right amount of illumination for you to
make your shot without spooking game. Motion activation watches for you and alerts you
when game is near. Designed to attach in a myriad of ways, the Blind Sider-X2™ is ultra
portable and versatile. Lighting up the night for your shot has never been easier.
If you have not already done so, please check your local game laws to ensure it is legal
to use an articial light source while hunting or observing animals at night. Elusive Wildlife
Technologies, LP and its afliates do not condone or promote the use of any of our
products as a means to illegally harvest any animal. Please take a moment to read these
instructions thoroughly before initial use. Also, reading the included helpful tips will ensure
you get the most out of your Blind Sider-X2™ and ensure your warranty remains in effect
for the full 12 month period.
FRONT INSIDE BACK
LED Light Emitters
Battery Compartment
( 4 D Cells )
Hinged Closure
Power Input Selector
1/4” Threaded Brass
Mounting Insert
Slotted Strap
Attachment
Cable Lock Channel
Battery Tray
For Solar Charging
External Power/Solar Input Plug
Day/Night Sensor
Motion Sensor
Time Duration Switch
Brightness Control
On-Off-Motion
Selector Switch
Open the hinged closures to access inside
of unit.
Select your desired mode of operation:
Brightness, Duration, On/Off/Motion, then
close the unit.
Insert (4) D Cell batteries with negative (-)
terminal facing upward on all batteries.
To remove batteries, push down with index
nger on bottom battery in window while
pulling up and out with thumb.
Position camera on tree with strap and
cam buckle or use 1/4” threaded inserts to
secure to a mounting device.
Operating the Blind Sider-X2™
The Blind Sider-X2™ is very simple to operate. Open the light
housing by lifting the two (2) cam locking hasps up and forward
towards the front of the unit. Fold open the light housing and
install four (4) D cell batteries into the battery compartments
located on the right hand side. Two batteries go in each tube
and will t snugly. All batteries should be installed with the
negative (-) terminal of the battery pointing toward the top of
the Blind Sider-X2™. Once batteries are installed, you are now
ready to power the unit on. WARNING: LED is extremely bright,
avoid looking directly into LED at all times.
Anti-Spook Technology™
When the Blind Sider-X2™ is activated, the LEDs will turn on
in a very low power and gradually increase to full power over
one minute time-frame. This gradual increase in brightness is
especially effective in preventing the animal from spooking when
the light is activated.
Brightness Control
The Blind Sider-X2™ was built to operate on a single LED
for low power consumption, or two (2) LEDs for maximum
brightness. You may use the Brightness Control Switch to select
between using one or two LEDs.
Using Blind Sider-X2™ Motion Detection
Your Blind Sider-X2™ comes with a built in motion detector.
To utilize the motion function, nd the mode selector switch
located on the panel opposite the batteries (left side). The Blind
Sider-X2™ has a 3 position switch, OFF-ON-AUTO. To operate
the device utilizing the motion sensor, simply slide the switch to
the AUTO position. This will activate the motion sensor and the
light will turn on when motion is detected, effectively illuminating
your hunting area. If you would rather have your Blind
Sider-X2™ remain ON for the duration of your hunt, switch the
light to the ON position. This deactivates the motion sensor and
provides constant power to the light until batteries are depleted.
Time Duration
When using The Blind Sider-X2™ in Motion Detection mode,
the light will turn on when motion is detected. It will continue to
operate as long as an animal(s) is actively moving in your area
within range of the motion detector. Once game activity ceases,
the light will remain on for a period of time, then power off. The
Time Duration switch will allow you to adjust the amount of time
(20 seconds, 90 seconds, 3 minutes, 5 minutes, 10 minutes, or
15 minutes) the light stays on after game activity ceases before
it powers off.
Multiple Power Options / Solar Charging
The Blind Sider-X2™ has three different options to power the
light; using four (4) D size batteries, using an external 6 volt
battery, and using an 18650 battery with a solar charger for
maintenance free operation.
• To use D size batteries, move the Power Input Switch to the
middle position labeled “4D”. Place four (4) D size batteries
in the battery compartment with all of the positive sides
pointing down.
• To power with an external battery, move the Power Input
Switch to the top position labeled “DC 6V”. Remove the
rubber Plug in the bottom of the light, and then plug the
optional power cord to the bottom of the light. Attach the
other end of the power cord to a 6 volt battery.
• To use the optional solar charger and 18650 battery, move
the Power Input Switch to the bottom position labeled “Solar
Charge”. Place the 18650 rechargeable battery in the “For
Solar Charging Only” battery tray with the positive end
facing up. Then remove the rubber plug on the bottom of
the light, and plug the solar charger into the light. For more
information about the optional Solar Charger, please contact
Mounting your Blind Sider-X2™
The Blind Sider-X2™ was built to mount like a trail camera.
Included is a standard nylon web strap with cam buckle as
well as two (2) 1/4” threaded brass inserts for use with
various mounts.
• To mount with included strap, simply thread the end opposite
the cam buckle through the two vertical slotted brackets on
the back of the light housing. Position the light on a tree,
post or other stationary object with the front of the unit facing
your feeder, bait pile, game trail, or other area you expect
animals to approach. Your Blind Sider-X2™ will illuminate
a rather large area so it is not necessary to precisely aim
it as you would a trail camera. Once you have your light
positioned correctly, wrap the bare end of the strap around
the stationary object you are securing the light to. Thread the
end of the strap through the cam buckle, tighten and secure
the cam buckle by closing the latch. To remove the light,
simply open the latch, pull the strap free from the buckle and
remove your Blind Side–R™.
• You can also mount your Blind Sider-X2™ to virtually any
1/4” threaded trail camera mount. The Blind Sider-X2™
has brass mounting inserts on both the back and bottom
of the housing. Carefully thread the unit clockwise onto
your preferred camera mount and position the light facing
the direction or location you expect game to approach.
To remove, simply unscrew the mount by turning counter-
clockwise until the Blind Sider-X2™ is no longer connected
to the camera mounting device.
Helpful Tip
Although much more forgiving than a trail camera, when
mounting your Blind Sider-X2™ look for a tree or post that is
somewhat straight. This will make aiming your light to the proper
location much easier. The Blind Sider-X2™ comes with molded
stabilizing spikes and naturally mounts at a downward angle.
Keep this in mind when selecting your mounting location.
Warranty
Elusive Wildlife Technologies, LP warranties this product for a
period of 1 year from original date of purchase. This warranty
covers manufacturer defects as well as malfunction during normal
operation. Please complete the warranty registration and mail in
along with proof of purchase to register your light. You may also
e-mail your registration and proof of purchase to
Your Blind Sider-X2™ is not waterproof. It is water resistant ONLY
when used as intended. Do not submerse your light, this will void
your warranty. Take care to insure the light is mounted properly
and securely. Unthreading of 1/4” brass inserts from unit is not
covered under warranty. Take care to not over-tighten mounting
devices or allow to rust while attached to the Blind Sider-X2™.
Elusive Wildlife Technologies, LP will not warranty any light
damaged by user neglect or failure to adhere to these instructions
and guidelines. No lights will be warrantied due to water
penetration, animal damage or theft. It is strongly advised that you
lock your Blind Sider-X2™ with a padlock and cable by utilizing the
cable channel located on the back of the unit.
Blind Sider-X2™
_________________________________________________________________
Date of Purchase
__________________________________________________________
Name
__________________________________________________________
Address
__________________________________________________________
City, State, Zip
__________________________________________________________
Phone
__________________________________________________________
E-mail
__________________________________________________________
Name of store where purchased
Received as a gift ror Purchased for yourself r
Please rate your level of satisfaction with this product from 1-10 with 10
being most satised. If you have yet to use this product, please circle N/A.
Please circle one.
1 2 3 4 5 6 7 8 9 10 N/A
Elusive Wildlife Technologies, LP respects your privacy and we will not
sell or provide your personal information to any other party. However,
we would like to occasionally send you information about your Elusive
Wildlife product or special offers. If you do not wish to receive this
information please check here r.
Please mail or e-mail warranty info to:
Elusive Wildlife Technologies, LP
1107 West Dallas Street, Suite A
Conroe, TX 77301
