EMAC PCM-5864 User manual

PCM-5864/L
All-in-onemultimediaPentium®
processor-basedsingleboard
computerwith audio, SVGA,
Ethernet and PCI expansion slot.
User's Manual

Copyright Notice
This document is copyrighted, 1999. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties that may result
from such use.
For more information on this and other products,
please visit our website
For technical support and service, please visit our support website
This manual is for the PCM-5864 and PCM-5864L.
PartNo.2006586400
1st Edition Printed in Taiwan October 1999

Acknowledgments
AMD is a trademark of Advanced Micro Devices, Inc.
Award is a trademark of Award Software International, Inc.
C&T is a trademark of Chips and Technologies, Inc.
Cyrixis atrademark ofCyrixCorporation.
IBM, PC/AT, PS/2 and VGA are trademarks of International
Business Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
SiS is a trademark of Silicon Integration Systems Corporation
UMC is a trademark of United Microelectronics Corporation.
IDT is a trademark of Intergrated Device Technology , Inc.
Creative is a trademark of Creative Technology LTD.
All other product names or trademarks are properties of their
respective owners.
Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 PCM-5864/L all-in-one single board computer
• 1 CD disk for utility and drivers
• 1 startup manual
• 1 CPU cooling fan
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Please refer to Appendix E, Section E.1 for the optional interface
wiringkit.

Contents
Chapter 1 General Information.................. 1
1.1 Introduction.................................................................................... 2
Highly integrated multimedia SBC .................................................. 2
1.2 Features .......................................................................................... 3
1.3 Specifications................................................................................. 4
1.3.1 Standard SBC functions ......................................................... 4
1.3.2 PCI SVGA/flat panel interface ............................................... 5
1.3.3 LVDS interface (PCM-5864 only) ......................................... 5
1.3.4 Audio function (PCM-5864 only) ......................................... 6
1.3.5 Video function (PCM-5864 only) .......................................... 6
1.3.6 PCI bus Ethernet interface ..................................................... 6
1.3.7 Mechanical and environmental ............................................... 6
1.4 Board layout and dimensions....................................................... 7
Chapter 2 Installation.................................. 9
2.1 Jumpers ........................................................................................ 10
2.2 Connectors ....................................................................................11
2.3 Locating jumpers ......................................................................... 12
2.4 Locating connectors..................................................................... 13
2.4.1 Component side ................................................................... 13
2.4.2 Solder side ............................................................................ 14
2.5 Setting jumpers ........................................................................... 15
2.6 CPU installation and upgrading ................................................ 16
2.6.1 Installing a CPU in the PGA type socket ............................ 16
2.6.2 System clock setting (J5, J9, and J10) ................................. 17
2.6.3 CPU voltage setting (J3) ...................................................... 19
2.6.4 CMOS clear (J7) .................................................................. 20
2.6.5 Buzzer enable/disable (J18).................................................. 20
2.7 Installing system memory (DIMMs) ......................................... 21
2.7.1 Installing DIMMs ................................................................ 21
2.8 IDE hard drive connector (CN12) .............................................. 21
2.8.1 Connecting the hard drive..................................................... 22
2.8.2 CompactFlash (CN501) ....................................................... 22
2.9 Floppy drive connector (CN10) .................................................. 23
2.9.1 Connecting the floppy drive ................................................ 23

2.10 Parallel port connector (CN14).................................................. 24
2.11 Keyboard and PS/2 mouse connector (CN9) ............................ 24
2.12 Front panel connector (CN15) ................................................... 25
2.12.1 Speaker ............................................................................... 25
2.12.2 LED interface ..................................................................... 25
2.12.3 Watchdog output ................................................................ 25
2.12.4 Reset switch ....................................................................... 25
2.13 Power connectors (CN1, CN2, CN8, CN22) ............................. 26
2.13.1 Peripheral power connector, -5 V, -12 V (CN22)............... 26
2.13.2 Main power connector, +5 V, +12 V (CN8) ...................... 26
2.13.3 CPU Fan power supply connector (CN1)......................... 26
2.13.4 Motherboard fan power supply connector (CN2) ............ 26
2.14 ATX power control connector (JP1, J1) ..................................... 27
2.14.1 ATX feature connector (J1) and soft power switch
connector (JP1) .................................................................. 27
2.15 IR connector (CN17).................................................................... 28
2.16 Audio interfaces (CN4, CN6, CN7, CN502) (PCM-5864 only)28
2.16.1 Audio connector (CN4)...................................................... 28
2.16.2 CD audio input connector (CN6)....................................... 28
2.16.3 Aux line-in connector (CN7) .............................................. 28
2.16.4 Speaker-out connector (CN502) ........................................ 28
2.16.5 Audio power source setting (J23) ...................................... 29
2.17 COM port connector (CN23)...................................................... 29
2.17.1 COM2 RS-232/422/485 setting (J19, J20, J21)................. 29
2.17.2 COM3/COM4 RI pin setting (J11, J12) ........................... 30
2.17.3 COM1/COM2 RI pin setting (J14, J15) ........................... 31
2.18 VGA interface connections......................................................... 32
2.18.1 CRT display connector (CN18) ......................................... 32
2.18.2 Flat panel display connector (CN20)................................. 32
2.18.3 Extension flat panel connector (CN21) .............................. 32
2.18.4 LCD power setting (J16) ................................................... 33
2.19 Ethernet configuration ............................................................... 34
2.19.1 100Base-T connector (CN3) .............................................. 34
2.19.2 Network boot ..................................................................... 35
2.20 Watchdog timer configuration ................................................... 35
2.20.1 Watchdog timer action (JP2) .............................................. 35
2.21 USB connectors (CN16) .............................................................. 36
2.22 Video interfaces (CN19, CN30) (PCM-5864 only)................... 37

Chapter 3 Software Configuration.......... 39
3.1 Introduction.................................................................................. 40
3.2 Connections for five standard LCDs ......................................... 40
3.2.1 Connections to Sharp LM64183P, LM64P89
(640 x 480 DSTN MONO LCD)......................................... 40
3.2.2 Connections to PLANAR EL (640 x 480 AD4 EL) ............ 41
3.2.3 Connections to Toshiba LTM10C042
(640 x 480 TFT color LCD)................................................. 42
3.2.4 Connections to Sharp LM64C142
(640 x 480 DSTN color LCD).............................................. 43
3.2.5 Connections to Toshiba LTM12C275A
(800 x 600 TFT color LCD)................................................. 44
3.3 Ethernet software configuration................................................ 45
Chapter 4 Award BIOS Setup .................. 47
4.1 System test and initialization ................................................... 48
4.1.1 System configuration verification......................................... 48
4.2 AWARD BIOS setup .................................................................... 49
4.2.1 Entering setup ...................................................................... 49
4.2.2 Standard CMOS setup ......................................................... 50
4.2.3 BIOS features setup ............................................................. 51
4.2.4 Chipset features setup ......................................................... 52
4.2.5 Power management setup..................................................... 53
4.2.6 PnP/PCI configuration.......................................................... 54
4.2.7 Integrated peripherals........................................................... 55
4.2.8 Load BIOS defaults .............................................................. 56
4.2.9 Change password ................................................................. 57
4.2.10 Auto detect hard disk ......................................................... 58
4.2.11 Save & exit setup................................................................ 58
4.2.12 Exit without saving............................................................. 58
Chapter 5 PCI SVGA Setup ...................... 59
5.1 Before you begin.......................................................................... 60
5.2 Introduction.................................................................................. 60
5.2.1 Chipset ................................................................................. 60
5.2.2 Display memory .................................................................. 61
5.2.3 Display types ...................................................................... 61
5.3 Installation of SVGA driver ....................................................... 61
5.3.1 Installation for Windows 95/98............................................ 62
5.3.2 Installation for Windows 3.1................................................ 65
5.3.3 Installation for Windows NT ............................................... 67
5.4 Further information.................................................................... 70

Chapter 6 Video......................................... 71
6.1 Introduction .................................................................................. 72
6.2 Installation of video driver ......................................................... 72
6.2.1 Installation for Windows 95/98............................................ 73
6.3 Installation of Chips-TV utility................................................. 75
Chapter 7 Audio......................................... 77
7.1 Introduction .................................................................................. 78
7.2 Installation of audio driver......................................................... 78
7.2.1 Installation for Windows 95/98/NT ..................................... 79
Chapter 8 PCI Bus Ethernet Interface .... 81
8.1 Introduction .................................................................................. 82
8.2 Installation of Ethernet driver ................................................... 82
8.2.1 Installation for MS-DOS and Windows 3.1......................... 82
8.2.2 Installation for Windows 95................................................. 83
8.2.3 Installation for Windows NT ............................................... 85
8.3 Further information.................................................................... 87
Appendix A Programming the Watchdog
Timer ....................................................... 89
A.1 Programming the watchdog timer ............................................. 90
Appendix B Installing PC/104 Modules.. 93
B.1 Installing PC/104 modules ......................................................... 94
Appendix C Pin Assignments.................. 97
CPU fan power connector (CN1) .......................................................... 98
Motherboard fan connector (CN2)....................................................... 98
Ethernet 10/100Base-T connector (CN3) ............................................ 99
Audio connector (CN4)........................................................................ 100
Speaker out connector (CN502)......................................................... 100
CD audio input connector (CN6) ....................................................... 101
Aux line-in connector (CN7) .............................................................. 101
Main power connector (CN8) ............................................................. 102
Keyboard and PS/2 mouse connector (CN9)..................................... 103
Floppy disk drive connector (CN10) .................................................. 104
PC/104 connectors (CN11) .................................................................. 105
IDE HDD connector (CN12) ............................................................... 106

Parallel port connector (CN14) .......................................................... 108
Front panel connector (CN15)............................................................ 109
USB connector (CN16) ........................................................................ 109
IR connector (CN17) .............................................................................110
CRT display connector (CN18) ...........................................................110
Video-out connector (CN19) ................................................................ 111
Flat panel connector (CN20) ...............................................................112
Ext. flat panel connector (CN21).........................................................113
Peripheral power connector (CN22) ...................................................113
COM port connector (CN23) ...............................................................114
Video-in (capture) connector (CN30) .................................................115
CompactFlash card connector (CN501)..............................................116
ATX power feature connector (J1) ......................................................117
ATX soft power switch connector (JP1) ..............................................117
LVDS connector (JP3) ..........................................................................118
Appendix D System Assignments ........ 119
D.1 System I/O ports ........................................................................ 120
D.2 1st MB memory map ................................................................. 121
D.3 DMA channel assignments ...................................................... 121
D.4 Interrupt assignments............................................................... 122
Appendix E Optional Extras .................. 123
E.1 PCM-10586-3 cable kit for PCM-5864/L ................................. 124
E.2 Optional LCD cables for 9.4" MONO, 10.4" TFT LCD
panel (CN20) .............................................................................. 125
E.3 Optional USB cable (CN16) ..................................................... 125
E.4 Optional IrdA adapter (CN17) ................................................. 125
E.5 Optional LVDS cables (JP3)..................................................... 125
E.6 Optional PCI riser cards........................................................... 126
Appendix F Mechanical Drawings........ 127
F.1 Component side ......................................................................... 128
F.2 Solder side.................................................................................. 129

Tables
Table 2-1: Jumpers ............................................................................................... 10
Table 2-2: Connectors ........................................................................................... 11
Table 2-3: CPU speed references .......................................................................... 17
Table 2-4: System/PCI clock setting (J9) ............................................................. 17
Table 2-5: CPU frequency ratio (J5) .................................................................... 18
Table 2-6: PCI/clock setting (J10) ........................................................................ 18
Table 2-7: CPU voltage setting (J3) ...................................................................... 19
Table 2-8: CMOS clear (J7) .................................................................................. 20
Table 2-9: Buzzer enable/disable (J18) ................................................................. 20
Table 2-10: CompactFlash enable/disable (J13) ................................................... 22
Table 2-11: Audio power source setting............................................................... 29
Table 2-12: COM2 RS-232/422/485 settings (J19, J20, J21) .............................. 30
Table 2-13: Serial port default settings ................................................................. 30
Table 2-14: COM3 RI pin settings (J12) ............................................................. 31
Table 2-15: COM4 RI pin settings (J11) ............................................................. 31
Table 2-16: COM1 RI pin settings (J14) ............................................................. 31
Table 2-17: COM2 RI pin settings (J15) ............................................................. 31
Table 2-18: LCD power setting ............................................................................ 33
Table 2-19: LCD shift clock setting ...................................................................... 33
Table 2-20: LCD backlight signal setting (J8) ....................................................... 34
Table 2-21: Watchdog timer action (JP2) .............................................................. 35
Table 2-22: TV-out format select (J25) ................................................................ 37
Table 3-1: Connections to Sharp LM64183P & LM64P89 ................................. 40
Table 3-2: Connections to PLANAR EL .............................................................. 41
Table 3-3: Connections to Toshiba LTM10DC042 .............................................. 42
Table 3-4: Connections to Sharp LM64C142 ...................................................... 43
Table 3-5: Connections to Toshiba LTM12C2775A ............................................ 44
Table C-1: CPU fan power connector (CN1) ....................................................... 98
Table C-2: Motherboard fan connector (CN2) ..................................................... 98
Table C-3: Ethernet 10/100Base-T connector (CN3) ........................................... 99
Table C-4: Audio connector (CN4) .................................................................... 100
Table C-5: Speaker out connector (CN502) ....................................................... 100
Table C-6: CD audio input connector (CN6) ..................................................... 101
Table C-7: Aux line-in connector (CN7) ............................................................. 101
Table C-8: Main power connector (CN8) .......................................................... 102
Table C-9: Keyboard and mouse connector (CN9) ............................................ 103
Table C-10: Floppy disk drive connector (CN10) ............................................. 104

Table C-11: PC/104 connectors (CN11)............................................................. 105
Table C-12: IDE HDD connector (CN12) .......................................................... 107
Table C-13: Parallel port connector (CN14) ....................................................... 108
Table C-14: Front panel connector (CN15) ........................................................ 109
Table C-15: USB connector (CN16) ................................................................... 109
Table C-16: IR connector (CN17) ...................................................................... 110
Table C-17: CRT display connector (CN18)...................................................... 110
Table C-18: Video-out connector (CN19)........................................................... 111
Table C-19: Flat panel connector (CN20) .......................................................... 112
Table C-20: Ext. flat panel connector (CN21) .................................................... 113
Table C-21: Peripheral power connector (CN22) ............................................... 113
Table C-22: COM port connector (CN23) ......................................................... 114
Table C-23: DSUB-9 connector pin assignments ............................................... 115
Table C-24: Video-in (capture) connector (CN30) ............................................. 115
Table C-25: CompactFlash card connector (CN501) ......................................... 116
Table C-26: ATX power feature connector (J1)................................................. 117
Table C-27: ATX soft power switch connector (JP1) ....................................... 117
Table C-28: LVDS connector (JP3) .................................................................... 118
Table D-1: System I/O ports .............................................................................. 120
Table D-2: 1st MB memory map ....................................................................... 121
Table D-3: DMA channel assignments ............................................................... 121
Table D-4: Interrupt assignments ....................................................................... 122

Figures
Figure 1-1: PCM-5864/L dimensions ..................................................................... 7
Figure 2-1: Locating jumpers ................................................................................ 12
Figure 2-2: Locating connectors (component side) ............................................... 13
Figure 2-3: Locating connectors (solder side) ....................................................... 14
Figure 2-4: Wiring for ATX soft power switch function ..................................... 27
Figure 4-1: Setup program initial screen ............................................................... 49
Figure 4-2: CMOS setup screen ........................................................................... 50
Figure 4-3: BIOS features setup ........................................................................... 51
Figure 4-4: Chipset features setup ....................................................................... 52
Figure 4-5: Power management setup................................................................... 53
Figure 4-6: PnP/PCI configuration ........................................................................ 54
Figure 4-7: Integrated peripherals......................................................................... 55
Figure 4-8: Load BIOS defaults screen ................................................................. 56
Figure 4-9: IDE HDD auto detection screen ........................................................ 58
Figure B-1: PC/104 module mounting diagram ..................................................... 95
Figure B-2: PC/104 module dimensions (mm) (±0.1)........................................... 95

General Information
This chapter gives background information
on the PCM-5864/L.
Sections include:
•Introduction
•Features
•Specifications
•Board layout and dimensions
CHAPTER
1

2PCM-5864/L User's Manual
1.1 Introduction
The PCM-5864/L is an all-in-one multi-media Pentium®
processor-based single board computer (SBC) with a 16-bit audio
controller, a video in/out controller, a PCI SVGA controller, a PCI
100/10 base-T Ethernet interface, and one PCI expansion slot.
When using an Intel®Pentium®MMX processor, the PCM-5864/L
achieves outstanding performance that surpasses any other SBC in
its class. This compact (only 5.75“x 8”) unit offers all the
functions of a single board industrial computer, but still fits in the
space of a 5.25“floppy drive.
On-board features include 512 KB 2nd level cache, four serial
ports (three RS-232, one RS-232/422/485), one multi-mode
parallel (ECP/EPP/SPP) port, two USB (Universal Serial Bus)
ports, a floppy drive controller, and a keyboard/PS/2 mouse
interface. The built-in high-speed PCI IDE controller supports
both PIO and bus master modes. Up to two IDE devices can be
connected, including large hard disks, CD-ROM drives, and tape
backup drives.
The PCM-5864/L features power management to minimize power
consumption. It complies with the “Green Function”standard and
supports Doze, Standby and Suspend modes. In addition, the
board‘s watchdog timer can automatically reset the system or
generate an interrupt if the system stops due to a program bug or
EMI.
Highly integrated multimedia SBC
The PCM-5864/L is a highly integrated multimedia SBC that
combines audio, video, and network functions on a single
computer board the size of a 5.25" floppy drive. It provides 16-bit
half-duplex, 8-bit full-duplex, integrated 3D audio, and up to
1024 x 768 resolution @ 64 K colors with 2 MB display memory.
Major on-board devices adopt PCI technology, to achieve
outstanding computing performance when used with Intel®
Pentium®processors. This makes the PCM-5864/L the world‘s
smallest and most powerful all-in-one multimedia board.

Chapter 1 General Information 3
1.2 Features
•Accepts Intel®Pentium®,Pentium®MMX; AMD K5, K6, K6-2;
and IDT WinChip C6
•32-bit PCI-bus SVGA/LCD controller supports 36-bit XGA
TFT LCD panels, with up to 1024 x 768 resolution
•18-bit LVDS interface (PCM-5864)
•100/10Base-T Ethernet interface, IEEE 802.3U compatible
•AC97/PCI audio interface, Sound Blaster Pro compatible
•Video capture supports NTSC and PAL formats (PCM-5864)
•4 serial ports (three RS-232 and one RS-232/422/485)
•USB interface complies with USB Rev. 1.10
•Supports fast infrared
•Supports PC/104
•Watchdog timer with jumperless selection (62 levels)
•Switching power for full range of Pentium®MMX level
processors
•Features system overheat temperature control

4PCM-5864/L User's Manual
1.3 Specifications
1.3.1 Standard SBC functions
•CPU: Intel®Pentium®MMX up to 233 MHz
AMD K5, K6, K6-2 up to 333 MHz
IDT WinChip C6 up to 200 MHz
•BIOS: AWARD 256KB Flash BIOS, supports Plug & Play,
APM, Ethernet boot ROM, boot from CD-ROM, LS-120
•Chipset: SiS 5582
•Green function: APM 1.1 compliant
•2nd level cache: On-board 512 KB Pipeline Burst SRAM
•RAM: One 168-pin DIMM socket accepts 8 ~ 128 MB
EDO/synchronous DRAM
•Enhanced IDE interface: Supports 2 enhanced IDE devices
•FDD interface: Supports up to two FDDs (360 KB / 720 KB /
1.2 MB / 1.44 MB / 2.88 MB)
•On-board security: Alarms for CPU, overheating and fan
failure. Detection of system power voltage, with pop-up
monitoring
•Infrared: One 4 Mbps fast infrared (FIR) port, IrDA compliant
•PCI expansion bus: 1 PCI slot for an optional PCI riser card
•LVDS: 20-pin header supports18-bit LVDS LCD panel (5 meter
data transmission) (PCM-5864)
•SSD: Supports CompactFlash cards
•Parallel port: One parallel port, supports SPP/EPP/ECP parallel
mode
•Serial port: Four serial ports with three RS-232 (COM1, 3, 4)
and one RS-232/422/485 (COM2). All ports with 16C550
compatible UARTs

Chapter 1 General Information 5
•Watchdog timer: 62-level interval from 1 to 62 seconds.
Generates system reset or IRQ11. Jumperless selection and
software enabled/disabled
•Keyboard/mouse connector: 8-pin header connector for
keyboard and PS/2 mouse
•USB interface: Two USB connectors with fuse protection.
Compliant with USB Spec. Rev. 1.10
•PC/104 expansion: 104-pin 16-bit PC/104 module connector
•Switch voltage regulator: Supports a full range of processor
voltage requirements. A good solution for processor
overheating.
1.3.2 PCI SVGA/flat panel interface
•Chipset: C&T 69000/69030
•Display memory: 2 MB on-board SDRAM memory, supports
up to 4 MB (optional)
•Display type: Simultaneously supports CRT and flat panel
displays. Also supports 36-bit TFT LCD panels, 64-bit graphics
acceleration
•Display resolution: Flat panel display up to 800 x 600 @ 24
bpp, 1024 x 768 @ 16 bpp. CRT monitors up to 800 x 600 @ 24
bpp, with 2 MB VGA memory. Also supports CRT monitors up
to 1024 x 768 @ 24 bpp, with 4 MB VGA memory
1.3.3 LVDS interface (PCM-5864 only)
•Chipset: NS DS90CF363A
•Interface: 18 low-voltage TTL data channel meets ANSI
EIA/TIA-644

6PCM-5864/L User's Manual
1.3.4 Audio function (PCM-5864 only)
•Chipset: Creative ES 1371
•Audio controller: 16-bit codec, Sound Blaster Pro compatible
•Stereo sound: 8-bit full-duplex, 16-bit half-duplex integrated
ISA bus AC97/PCI 3D surround stereo sound
•Audio interface: Microphone in, Line in, CD audio in; Line
out, Speaker L, Speaker R
•Power: Accepts +12 V source for improved audio quality
1.3.5 Video function (PCM-5864 only)
•Chipset: Philips SDA 7111A for Video in; analog device
AD725AR for TV (Video) out
•Connectors: Pin header via optional cable connects to RCA
(AV) connector or S-video connector
•Format: NTSC or PAL, YUV 422 quality with RGB 16 format.
Supports live video capture up to 10 ~ 15 fps at 320 x 240
resolution
1.3.6 PCI bus Ethernet interface
•Chipset: REALTEK RTL8139A PCI local bus Ethernet
controller
•Ethernet interface: IEEE 802.3U compatible 100/10Base-T
interface. Includes software drivers and boot ROM
1.3.7 Mechanical and environmental
•Max. power requirements: 7 A @ 5 V (4.75 V ~ 5.25 V)
Standard consumption 433 A @ 5 V with Intel Pentium®
MMX-233 processor, 64 MB DIMM
•Operating temperature: 0 ~ 60°C (32 ~ 140°F)
•Size (L x W): 203 mm x 146 mm (8" x 5.75")
•Weight: 0.32 kg (0.7 lb) (w/o package)

Chapter 1 General Information 7
1.4 Board layout and dimensions
Figure 1-1: PCM-5864/L dimensions

8PCM-5864/L User's Manual

Installation
This chapter tells how to set up the
PCM-5864/L hardware. It includes
instructions on setting jumpers, and
connecting peripherals, switches and
indicators. Be sure to read all the safety
precautions before you begin the
installation procedure.
CHAPTER
2
