Emdamed Non-Contact Forehead InfraRed Thermometer User manual

Non-Contact Forehead
InfraRed Thermometer
User Manual
Please read this manual carefully or purchase and use it under
the guidance of the medical sta For prohibited content or
precautions, please refer to this manual. Please keep the
manual in safety place for good reference.

Non-Contact Forehead IR ermometer User Manual Non-Contact Forehead IR ermometer User Manual
32
Contents
1.General Description 4
2.Safety Information 4
3.Features 5
4.Intended Use 6
5.Conguration 7
6.Indicator 7
7.Description of Symbols 8
8.Technical Specications 9
9.Calibration Instructions 10
10.Use 11
11.Measuring Operation 12
12.Advice 14
13.Maintenance and Cleaning 14
14.Troubleshooting 15
15.This Appliance Conforms to the following Standards 17

Non-Contact Forehead IR ermometer User Manual Non-Contact Forehead IR ermometer User Manual
54
2. Safety Information
• This device must only be used for the purposes described
in th instruction manual •This device must only be used in
an ambient temperature range between 10 and 40°C • Do
not expose this thermometer to electic shocks.
• Do not expose this thermometer to extreme temperature
conditions of >50°C or <0°C Do not use the device in rela-
tive humidity higher than 85%.
• Do not use the device near large electromagnetic elds
such as found with cordless or cell phones.
• Keep the device away from water and heat, including direct
sunlight
• Do not drop or knock the device, and do not use if dam-
aged.
• It may aect the accuracy of measurements when the
forehead is covered by hair, perspiration, cap or scarf.(See
Part 10-4) Keep the Measuring distance as 5cm-15cm (2
in-5.9in). (See Part 10-4) •When the body infrared thermom-
eter should be left in that room during 15 to 20 minutes
before using.
• It may aect the accuracy of measurements when the
forehead is covered by perspiration or other factors, please
take the temperature behind the ear lobe.(See Part 10-5)
•Clean the glass with a cotton bud lightly moistened with
70% alcohol.
Importance:
• Before taking of the temperature make sure to remove hair
and perspiration from the forehead.
• Selecting "Body" mode to measure the body temperature;
Selecting
• Surface" mode to measure the surface temperature.
• Use of this thermometer is not intended as a substitute for
consultation with your physician.
• Should a problem occur with your device, please contact
your retailer.
• Do not attempt to repair the device yourself.
• According to EMC standard, the medical electronic products
should be maintained specially.
• Application:This prole is suitable for any peoples body
temperature in any age.
3. Features
• Precise non-contact measurements
• User selectable °C or °F
• Selectable Body and Surface temp Set Alarm value
• Memorization of the last 32 measurements
• Automatic Data Hold & Auto power o
• Automatic selection range and Display Resolution
0.1°C(0.1°F)
• Backlight LCD display
1. General Description
Non-Contact Forehead IR Thermometer is specially designed to
take the body temperature of a person regardless of room tem-
perature. Depending on various skin types and thickness, there
may be temperature dierence.

Non-Contact Forehead IR ermometer User Manual Non-Contact Forehead IR ermometer User Manual
76
4. Intended Use
Non-Contact Forehead IR Thermometer is designed for body
surface and forehead temperature measurement for infants and
adults without contact to human body.
Non-Contact Forehead IR Thermometer can also be used to
measure the temperature of a baby-bottle or bath, or room
temperature (by using the Surface Temp function).
The temperature of the human body varies throughout the day.
It can also be inuenced by numerous external factors: age, sex,
type and thickness of skin...
Normal Temperatures According To Measurement Method
Measurement Method Normal Temp °C Normal Temp °F
Rectal 36.6 to 38 97.8 to 100.4
Oral 35.5 to 37.5 95.9 to 99.5
Axillary 34.7 to 37.3 94.4 to 99.1
Ear 35.8 to 38 96.4 to 100.4
Age Temp °C Temp °F
0-2 years 36.4 to 38.0 97.5 to 100.4
3-10 years 36.1 to 37.8 97.0 to 100.0
11-65 years 35.9 to 37.6 96.6 to 99.7
>65 years 35.8 to 37.5 96.4 to 99.5
Normal Temperatures According To Age
5. Conguration
1. IR Sensor
2. LCD Display
3. Mode Selection
4. Down Button
5. Up Button
6. Mode Button
7. Measurement Trigger
8. Battery Cover
6. Indicator
1. Surface mode Symbol
2. Body mode Symbol
3. Digital readout
4. Battery Symbol
5. Stock Place
6. Save data readout
7. Temperature °C
°F Scale
8. Buzzer symbol

Non-Contact Forehead IR ermometer User Manual Non-Contact Forehead IR ermometer User Manual
98
The device is in accordance with Medical Device Direc-
tive 93/42/EEC
The device is in accordance with FCC Part 15 Subpart
B:2007/Radio Frequency Devices IC Regulation ICEC-
003. 2004 Interference-causing Equipment Stand-
ard-Digitial Apparatus
DC 3V power supply, 2 x 1.5V AA batteries
Type BF equipment
Indication of mode
Attention, consult accompanying consult accompany-
ing documents
In order to protect the environment, please recycle the
battery according to the local regulations
This manual is made of paper, which can be used
circularly
European Representative symbol
Follow the instruction for use
Keep dry
Manufacturer symbol
7. Description of Symbols 8. Technical Specications
Normal Conditions of Use
Display Resolution 0.1°C (0.1°F)
Operating Temperature 10 to 40°C (50 to 104°F)
Storage Temperature 0 to 50°C (32 to 122°F)
Humidity Rate 85%
Power DC 3V (2 x "AA" batteries)
Size 149 x 77x 43 mm/5.9 x 3 x 1.7 in (L x W x H)
Weight Gross 400g/Net 172g
Measuring Range
In Body Temp Mode 32.0 to 42.5°C (89.6 to 108.5°F)
In Surface Temp Mode 0 to 60°C (32 to 140°F)
Accuracy 0.3°C (0.54°F)
Measuring Distance 5 cm - 15 cm (2 in - 5.9 in)
Automatic Stop 7 sec.
Non-contact Body Infrared Thermometer Precision
Body mode
According to ASTM
0.2°C/ 0.4°F Standard
E1965-98
32 to 35.9°C/89.6°F to 96.6°F ± 0.3°C/0.5°F
36 to 39°C/96.8 to 102.2°F ± 0.2°C/0.4°F
39 to 42.5°C/102.2 to 108.5°F ± 0.3°C/0.5°F
Surface mode
0 to 60°C/30 to 140°F ± 0.8°C/1.5°F

Non-Contact Forehead IR ermometer User Manual Non-Contact Forehead IR ermometer User Manual
1110
9. Calibration Instructions
For stable and reliable results, The thermometer provides a
user-correction function, the operation of the method is as
follows:
1” step: take the temperature of a person using a conventional
thermometer; you will get 37.5°C (99.5°F) for instance,
2 step: take the temperature of the same person using the Non
contact Body Infrared Thermometer keeping the 5 to 15 cm (2 in
to 5.9 in) distance between the thermometer and the forehead
(Take care to remove any obstacle which could alter the
measurement (hair, perspiration...). If you get 37.5°C (99.5°F),
the Non-contact Body Infrared Thermometer is properly set and
ready for use.
If you get a lower temperature, 36.4°C (97.4°F) for example, your
dierence is 1.1°C (2.2°F). You should adjust the temperature
on the Non-contact Body Infrared Thermometer and add the
dierence, i.e.
1.1°C (2.2°F).
To do it, press the “MODE” button for 2 seconds, the screen
displays F1, press “MODE” button again until you get F3. Press
“UP” button in order to add the dierence in our example, 1.1°C
-2.2°F).
3d step: To check, take the temperature again using the Non-
contact Body Infrared Thermometer. 10. Use 10-1.Install battery
10. Use
10-1.Install battery
10-2.For the rst use or when inserting new batteries wait
between 10 minutes for the warm-up of the apparatus and
when inserting the new batteries.
10-3.If the device is not used for a long time, once you turn it on
again, the device will test the room temperature rst and will
delay turning on for one or two seconds.
10-4.Aim towards the forehead (see the diagram below for the
positioning), from a distance of 5cm(2in), press the measuring
key, the temperature is displayed immediately. Making sure
there is no hair, perspiration, cosmetic or cap covered on the
forehead.
10-5. When the room temperature is signicant dierence,
or there is perspiration on the forehead, You can take the
temperature behind the ear lobe. Making sure there is no hair,
perspiration, cosmetic or cap covered.

Non-Contact Forehead IR ermometer User Manual Non-Contact Forehead IR ermometer User Manual
1312
11. Measuring Operation
11-1.Choosing The Temperature Unit - F1 Function
for 2 seconds, the screen displays: F1. Select Press "MODE"
button
"DOWN" for degrees Celsius, "UP" for degrees Fahrenheit
11-2.Alarme Setup - F2 Menu
Press "MODE" touch for 2 seconds, the screen displays: F1.Press
twice se threshold by
"MODE" touch to get F2. Select "UP" to increase the
0.1°C (0.1°F), "DOWN" to reduce it by 0.1°C (0.1°F).
Note: The alarm threshold default value is 38°C (100.4°F)
11-3. Total Dierence - F3 Menu
To adjust the total variation of your the Non-contact Body
Infrared Thermometer. Press "MODE" button for 2 seconds, the
screen displays: F1. Press
"MODE" button two times to get F3. Select "UP" to increase the
dierence by 0.1°C (0.1°F), "DOWN" to reduce itby 0.1°C (0.1°F).
In the cases of seasonal or environmental changes a verication
and adjustment should be carried out.
Note: This function is only eective Body
11-4.Buzzer ON/OFF - F4(F3) Menu
Press "MODE" button for 2 seconds, the screen displays: F1.
Press three(two) times "MODE" button to get F4(F3).
Select "UP" to open the buzzer (a sound icon " " is displayed on
the LCD screen), press "DOWN" to stop it (the icon disappear).
11-5.Exiting The Setting Mode
Press "MODE" button until the screen turns o.
11-6.The Non-contact Body Infrared Thermometer is specially
designed to take the body temperature of a human being. For
this, use the Body mode. Measurement range for Body mode: 32
to 42.5°C (86 to 108°F)
You can also use the Non-contact Body Infrared Thermometer
to measure the temperature of an area object, a food, a liquid or
a room temperature. For this, use the Surface mode. Measure-
ment range for Surface mode: 0 to 60°C (32 to 140°F)
Important: The area temperature diers from the internal body
temperature. To obtain the internal temperature always use the
Body mode.
Please make sure to select the Body mode for an internal
temperature reading and the Surface mode for an external area
reading (bottle, bath, room...).
11-7.Data Memory
Data memory automatically after temperature measurements,
which will display at the right corner of LCD. Press "UP" or
"DOWN" button to display the last temperature measurement.
Under the condition of power o, press "UP" and "DOWN"
button together for two seconds, to display the last temperature
measurement.
At this mode if change the order number to 0 and press "MODE"
button, then delete all memory data.
11-8.Changing The Batteries
Display: when the LCD screen displays " ", the battery is used.
Operation: Open the lid and change the batteries, taking great
care with the correct positioning. A mistake with this could cause
damage to the apparatus and compromise the guarantee of your
Non-contact Body Infrared Thermometer. Never use rechargeable
batteries. Use only batteries for single usage.
Remove the battery from the instrument if it is not required for
extended periods of time in order to avoid damage to the ther-
mometer resulting from a leaking battery.

Non-Contact Forehead IR ermometer User Manual Non-Contact Forehead IR ermometer User Manual
1514
11-9. Longevity Use
The Non-contact Body Infrared Thermometer was conceived for
an intense and professional use, its longevity is a quarantine for
40000 takings.
12.Advice
• The protective glass over the lens is the most important and
fragile part of the thermometer, please take great care of it.
• Do not recharge non rechargeable batteries, do not throw .
• Do not expose the thermometer to sunlight or water.
13. Maintenance and Cleaning
• The Infrared Sensor is the most precise part, must be pro-
tected carefully
• Clean the device with a cotton bud lightly moistened with
70% alcohol.
• Do not clean the device with corrosive detergent.
• Keep the device away from water or other liquid. • Store the
device in a dry environment, and keep it away from dust
and direct sunlight.
14. Troubleshooting
If you happen to have one of the following problems while using
your the non-contact forehead IR thermometer please refer to
this bres service guide to help resolve the problem. If the prob-
lem persists please contact our customer service,
The screen displays the body temperature inferior to 32°C
(89.6°F) If you’re on Surface mode the 32°C(89.6°F) temperature
displayed is showing the external temperature that your body
releases.
The screen displays the message “HI”
When using the Non-contact Body Infrared Thermometer the
message HI can show on the screen.
The analysis is above the measurement range selected, either
superior to 42.5°C (108°F) in Body mode or superior to 60°C
(140°F) in Surface mode.
The screen displays the message “LO”
When using the Non-contact Body Infrared Thermometer the
message Lo can show on the screen.
The temperature analyzed is under the measuring range select-
ed, either less than 32°C (90°F) in Body mode or less than 0°C
(32°F) in Surface mode.

Non-Contact Forehead IR ermometer User Manual Non-Contact Forehead IR ermometer User Manual
1716
This message displays in various cases - please nd
belo of the main cases.
15. This appliance conforms to the following standards:
• ASTM E 19651998
• EN 980: Graphical symbols for use in the labeling of medical
devices
• EN 1041:Information supplied by the manufacturer with
medical devices
• EN 60601-1: Medical electrical equipment Part 1: General
requirements for safety (IEC:60601-1:1998)
• EN 60601-1-2: Medical electrical equipment Part 1-2: Gener-
al requirements for safety Collateral standard Electromag-
netic compatibility Requirements and test (IEC 60601-1-
2:2001)
EMC Statement
This device has been tested and homologated in accordance
with EN 60601-1-2:2007 for EMC. This does not guarantee in
any way that the device will not be aected by electromagnetic
interference. Avoid using the device in high electromagnetic
environment.
The MEDICAL ELECTRICAL EQUIPMENT needs special precau-
tions regarding EMC and needs to be installed and put into ser-
vice according to the EMC information provided in the ACCOM-
PANYING DOCUMENTS.
Reasons for “LO” or “HI”
message display
Advice
Temperature reading ham-
pered by hair, perspiration...
Make sure that there is no
obstruction prior to taking a
temperature.
Temperature hampered by
an air ux
Make sure there is no air ux
as this could interfere with
the infrared system.
The measuring distance is
too far.
Please respect the measur-
ing distance (between 5 to
15cm - 2 to 5.9 in).
From high/low temperature
condition to room temper-
ature
Waiting for 10 minutes
before taking the body tem-
perature
