Grundig MDI907 User manual

Infrared
Thermometer
AInstruction Manual
Customer Model:MDI907 Factory Model:MDI903
Tip: A wrong operation can cause a inaccurate
measurement result, the correct measured distance
is 1-5 cm to forehead (between the eyebrows).
July 2020 VER.1.0
©copyright Edco Deutschland GmbH
Siemensstr. 31 47533 Kleve
Deutschland. Made in P.R.C.
www.grundigaccessories.com
®The Grundig trademark is used
under license
0123

2
Table of Contents
Introduction 2
Safety Information 3
Product structure 6
Battery installation 7
Setting 8
Use of the unit 9
Trouble shoot 12
Care and maintenance 13
Specication 14
Warranty information 15

3
Introduction
▲Yournewnon-contactforeheadthermometerusesadvanced
infrared (IR) technology to measure temperature instantly and
accurately on the forehead or object.
▲Easytouseandlessmeasurementtime.Thisthermometerdoes
not need to contact body or object to ensure the safety and hygiene.
Itsergonomicdesignmakesthisthermometerbesimpleandvery
easy to check the temperature. It only takes 1 second to take
measurement and reading.
▲Bodyandobjectmodes
This thermometer supports to measure temperature of body and
object. Measuring range of object mode is 0.0 to 100.0 °C(32.0
°F~212.0 °F).That mean s except to take body temperature, it also
supports to take the surface temperature of object as below,
.Surface temperature of milk in the bottle
.Surface temperature of baby bath
.Environmenttemperature
▲Alarmsoundswhenbodytemperatureisover38.5°C,analarm
sounds for 3 times.
▲Memoryfunction
It stores up to 1 sets recent measurement data.
▲Autopoweroff
Automatically power off if left idle for 30 seconds .
▲Measurement
Measurementtimeintervalin15sandthemeasurementdistanceis
within 1-5 cm.
Please read the manual carefully before you use the unit, and keep
for future reference.

4
Safety Information
This thermometer is not intended to
substitute for a consultation with your
physician.The forehead scan temperature
servesasareferenceonly.Itcannotbea
judgmentonfever.
Basic safety precautions should always
be
observed,especiallywhenthethermometer
is used on or near children and disabled
persons.
Pleaseplacethedeviceunreachableby
young.
Avoiddirectsunlight.
Do not touch the lens.
Nomodicationofthisdeviceisallowed.
The swallowing of small parks like
packingbag,battery,batterycoverandso
on may cause the suffocation.
Please do not use a dilution agent,
alcohol or petrol to clean the unit. Please
treatisgentlyandpreventthefallingfroma
high place.
Please do not immersed it in liquid.
Neverleavebatteryinthebattery
compartment fora long time without use,
as they may leak and cause damage to the
unit.

5
Please take off the battery if you do not
intend to use within 3 months. Replace
with new batteries if the unit display a low
battery symbol.
Do not mix the old and new batteries
together.
This article is not for professional usage.

6
Safety Information
▲Toensurethecorrectuseoftheproduct,basicsafetymeasures
should always be followed including the warning and the caution
symbols listed in the instruction manual :
Symbol descriptions
The following symbols may appear in this manual, on the label,
onthedevice,oronitsaccessories.Someofthesymbols
representstandardsandcomplianceassociatedwiththedevice
and its use.
WARNING:Thisalertidentieshazardsthatmaycause
serious personal injury or death .
CAUTION:Thisalertidentieshazardsthatmaycause
minor personal injury, product damage, or property
damage .
Type BF applied part
Manufacturer
Speciesserialnumbe
DISPOSAL : Do not dispose this product as unsorted
municipal waste. Collection of such wast e separately for
special treatment is necessary.
Direct current
Operating instructions
Consult accompanying documents

7
Safety Information
WARNING :
Do not dispose of electrical appliances as unsorted municipal waste,
useseparatecollectionfacilities.Contactyoulocalgovernmentfor
informationregardingthecollectionsystemsavailable.Ifelectrical
appliancesaredisposedofinlandllsordumps,hazardous
substances can leak into the groundwater and get into the food chain,
damaging your health and well-being.
Classication
1.Internally powered equipment;
2.Type BF applied part;
3.Protection against ingress of water: IPX0;
4.NotcategoryAP/APGequipment;
5.Mode of operation : Continuous operation ;
Note : the user must check that the equipment functions safely and
ensure that it is in proper working condition before it being used.

8
Product structure
Body
1. Display screen
2. Mode switch
3. Sensor probe
4. Down (-) button
5. Up (+) button
6. Setting button
7. START/STOPbutton
8. Batterycover
Display
1. Object temperature indicator
2. Body temperature indicator
3. Temperature unit
4. Memory mode
5. Low battery indicator
6. Sound indicator
7. Temperature reading
1
2
3
4
5
6
7
8
7

9
Battery Installation
1. Removethebatterycoverfromthe
battery compartment as the arrow
direction accordingly.
2. Insert2pcs1.5VAAAsizealkaline
batteries, and ensure each battery is in
the proper direction.Close the battery
cover.
Low battery and replacement
During power on, the low battery symbol will display
once the unit starts to work, and you should replace with new
batteries, otherwise the unit can not work.
Battery type and replacement
Please use 2 pcs of AAA identical 1.5V alkaline batteries. Do not use
the batteries beyond their expiry date .
Pleaseremovethebatteriesifyoudonotneedtouseforlongtime.
WARNING
Dispose the battery in accordance with all federal, state and
locallaws.Toavoidreandexplosionhazard,donotburnor
incinerate the battery.

10
Setting
How to set
Display Function Description
F-1 Unit selection Toggle between Unit
°C and °F
F-2 TurnOn/Offthe
alarm sound
With“OPEN” on the
screen means the
sound is on With
“CLOS” on the
screen means the
sound is off

11
Use of the unit
Pre-measurement
Aboutnormalbodytemperature&feverthetemperatureinthe
forehead and temple area differs from the internal temperature, which
is taken orally or rectally. Vasoconstriction, an effect which constricts
thebloodvesselsandcoolstheskin,canoccurduringtheearly
stagesofafever.Inthiscase,thetemperaturemeasuredbythe
non-contact thermometer may be unusually low. If the measurement
therefore does not match the patients own perception or is unusually
low,repeatthemeasurementevery15minutes.Asareference,you
canalsomeasuretheinternalbodytemperatureusingaconventional
oral or rectal thermometer.
Bodytemperaturecanvaryfromoneindividual/persontonext.It
alsovariesbylocationonthebodyandtimeofday.Belowshowsthe
statistical normal ranges from different sites.
Please keep in mind that temperatures measured from different
sites,evenatthesametime,shouldnotbedirectlycompared.Fever
indicates that the body temperature is higher than normal. This
symptommaybecausedbyinfection,overdressingorimmunization.
Somepeoplemaynotexperiencefeverevenwhentheyareill.
These include, but are not limited to, infants younger than 3
months old, persons with compromised immune systems, persons
taking antibiotics, steroids or antipyretics (aspirin, ibuprofen,
acetaminophen), or persons with certain chronic illnesses. Please
consultyourphysicianwhenyoufeelillevenifyoudonothavefever.
Table* 1 Body Site Normal Temperature Range
Body site Normal temperature range
Oral 0.6°C (1°F) or more
Rectal/ear 0.3°C to 0.6 °C (0.5 °F to 1°F) higher than
oral temperature
Axillary (armpit) 0.3°C to 0.6°C(0.5°F to 1°F) lower than oral
temperature

12
Use of the unit
Measuring procedure
As a body thermometer
1) Select body mode , the temperature unit will
appear. (Picture at right)
2)Movetheprobeclosetotheforehead,make
suretheprobeisatandtakemeasurementwitha
distancewithin1-5cm.PressStart/Stopbutton.
3)Themeasurementwillbenishedin1seconds,
when it has been completed, you can hear 3 short
beeps, at the same time, the reading will appear on
the display.
Note :
• If the reading is <37.5°C(99.5°F) and ≥32°C(89.6°F) the display
will show with green backlight.
• Ifthereadingisbetweenvalue37.5-38.5°C(99.5-101.3°F),
the display will show together with 1 short beeps, the orange
backlight lasts for alarm.
• If the reading is ≥ abovevalue38.5°C(109.4°F),thedisplay
will show together with 3 short beeps, the red backlight lasts
for alarm.
• As the forehead measurement temperature is likely to be
affected by sweat, oil and the surroundings, the reading shall
be taken as a reference only.
• If the probe is placed at an angle close to the forehead
measurement, the reading will be affected by surrounding
temperature.
• Babies’skinreactsveryquicklyintheambienttemperature.
Therefore, do not take their temperature with the non-contact
thermometerduring/afterbreastfeeding,becausetheskin
temperature maybe lower than the internal body temperature.
• The thermometer will automatically turn off if left idle for 30
seconds.

13
Use of the unit
Measuring procedure
As a object thermometer
1. Select Object Mode, the temperature unit will
appear. (Picture at right)
2. Movetheprobeclosetotheobject,makesure
theprobeisatandtakemeasurementwith
adistancewithin1-5cm.PresstheStart/Stop
button to take measurement
3. Themeasurementwillbenishedin1seconds,
when it has been completed, you can hear 3
short beeps, at the same time, the reading will
appear on the display
Note :
• As the object scan temperature is likely to be
affected by the surroundings, the reading shall
be taken as a reference only.
• If the probe is placed at an angle close the object scan, the
reading will be affected by surrounding temperature.
• The thermometer will automatically turn off if left idle for 30
seconds.

14
Trouble shoot
Error indicators
The following symbols will appear on the display when measurement
is abnormal
Symbol Correction
Inbodymode.Measuredtemperatureisabove
measuringrangeof>43.0°C(109.4°F)
It is shown on the LCD with red LED.
In body mode. Measured temperature is bellow
MeasuringRangeof<32°C/89,6°F
It is shown on the LCD with red LED.
Inobjectmode.Measuredtemperatureisabove
measuringrangeof>100°C/212°F
orenvironmentaltemperatureisabovesystem
operatingrange>40°C/104°F
It is shown on the LCD with red LED.
In object mode. Measured temperature is below
measuringrangeof<0.0°C/32,0°F
Orenvironmentaltemperatureisbelowsystem
operatingrange<5°C/41°F
It is shown on the LCD with red LED.
If low battery indicator appears, replace all batteries
with new ones.
ERR Thermomter sytem fails or affected by electric
magneticeld.

15
Care and maintenance
Care for the main unit
• Keep the unit in the storage case when not in use.
• Cleantheunitwithasoftdrycloth.Donotuseanyabrasiveor
volatilecleaners.
• Neverimmersetheunitoranyofitscomponentinwater.
Maintenance
Do not clean the unit with
naphtha, thinner or gasoline
etc.
Store the unit in a clean and
dry location. Do not subject
the unit to extreme hot or cold
temperature, humidity and
direct sunlight.
Removethebatteriesiftheunit
will not be used in 3 months or
longer.
Do not use the unit under the
inuenceofelectromagnetic
interference (nearby cellphones,
microwaveetc.)
Note : We will not be responsible for any quality problem if you do not
care and maintain the product as instructed.

16
Specication
Description Non-contact Infrared Thermometer
Display LCD digital display
Measuring
localization
Forehead and object surface
Measurement
range
Bodymode32.0C~43.0°C(89.6oF~109.4°F);
Object mode 0.0~100.0°C(32.0°F-212.0°F);
Temperature unit °C/°F
Display-resolution 0.1°C/0.1°F
Accuracy ±0.2°C/±0.4°F
(within35.0°C~42.0°C/95.0°F~107.6°F)
Memory function Lastmemoryofmeasurementvalues
Power source 2 pcs AAA alkaline battery
Automatic power-
off
In 30 seconds
Main unit weight Approx. 93 gr (batteries not included)
Mainunitsize 95mm*45mm*155mm
Battery life Could be used for 500 times for normal
condition
Accessories Instruction manual + storage pouch
Operating
environment
Bodymode10.0°C~40.0°C/50.0°F-104.0°F
Objectmode5°C~40.0°C/41.0°F~104.0°F
Storage
environment
Temperature>-20°C~+55°C/-4.0°F
~+131.0°F Humidity: RH≤85% does not
condenseavoidcrash,sunburnorrainduring
transportation

17
Warranty information
▲Theunitisguaranteedtobefreeofdefectsinworkmanshipand
materials under normal use for a period of 1 year from the date of
purchase.
▲Forrepairunderthiswarranty.Ourauthorizedserviceagentmust
beadvisedofthefaultwithintheperiodofthewarranty.Thiswarranty
onlycoverspartsandlaborserviceundernormaloperations.Any
defectresultingfromnaturalcauses,eg.ood,hurricaneetc,is
notcoveredinthisguarantee.Thisguaranteealsodoesnotcover
damage incurred by use of the unit not in accordance with the
instructions,accidentaldamage,orbeingtamperedorservicedby
unauthorizedserviceagents.
▲Thefollowingwillbeexcludedfromthiswarranty-ifthe
thermometer has been misused, abused, or neglect in following
themanual’sinstructionsonpurposeandunauthorizedrepairor
modications.
Thedevicerequiresnocalibration.
Thedeviceisnotrepairableandcontainsnouser
serviceableparts
ShenZhen Medek Bio-Medical Co.,Ltd.
ADD:No.101WenhaoIndustrialParkNo.13YuanxinRoad
Tongle Community, Baolong Street, Longgang District. 518116
ShenzhenP.R.China
Name:Shanghai International Holding Corp.GmbH(Europe)
Add: Eiffestrasse 80,20537 Hamburg,Germany
REPEC

Infrarood
thermometer
c Gebruiksaanwijzing
Customer Model:MDI907 Factory Model:MDI903
Tip: een verkeerd gebruik kan een onnauwkeurig
meetresultaat tot gevolg hebben, de juiste meetafstand
is 1-5 cm tot het voorhoofd (tussen de wenkbrauwen).
July 2020 VER.1.0
©copyright Edco Deutschland GmbH
Siemensstr. 31 47533 Kleve
Deutschland. Made in P.R.C.
www.grundigaccessories.com
®The Grundig trademark is used
under license
0123

2
Inhoudsopgave
Inleiding 2
Veiligheidsinformatie 3
Productstructuur 6
Plaatsing van de batterij 7
Instelling 8
Gebruik van de eenheid 9
Probleemoplossing 12
Zorg en onderhoud 13
Specicaties 14
Garantie-informatie 15

3
Inleiding
▲Uwnieuwecontactlozevoorhoofdthermometermaaktgebruikvan
geavanceerde infrarood (IR) technologie om de temperatuur op het
voorhoofd of van een voorwerp direct en nauwkeurig te meten.
▲GemakkelijktegebruikenenmindermeettijdDezethermometer
hoeft niet in contact te komen met het lichaam of een voorwerp,
omzodeveiligheidendehygiënetewaarborgen.Doorhet
ergonomischeontwerpkuntumetdezethermometerdetemperatuur
heel eenvoudig meten. Het duurt slechts 1 seconde om te meten en
aftelezen.
▲Lichaam-envoorwerpmodi
Metdezethermometerkuntudetemperatuurmetenvaneen
lichaam of een voorwerp. Het meetbereik in de Voorwerpmodus
is 0,0 tot 100.0 °C (32,0 °F~212,0 °F). Dit betekent dat u behalve
de lichaamstemperatuur ook de oppervlaktetemperatuur van een
voorwerpkuntmeten,zoalshieronder,
.Oppervlaktetemperatuurvanmelkindees
. Oppervlaktetemperatuur van een babybadje
. Omgevingstemperatuur
▲Hetalarmgaatafalsdelichaamstemperatuurhogerisdan38,5
°C, er klinkt 3 keer een alarm.
▲Geheugenfunctie
Het slaat tot 1 set recente meetgegevens op.
▲Automatischestroomuitschakeling
Automatischuitschakelenalshetapparaat30secondennietwordt
gebruikt.
▲Meting
Meettijdinterval in 15s en de meetafstand is binnen 1-5 cm.
Leesdehandleidingzorgvuldigdoorvóórdatuhetapparaatgebruikt
enbewaardezevoortoekomstiggebruik.
This manual suits for next models
1
Table of contents
Languages:
Other Grundig Thermometer manuals
