Emerald EE-HWS-RCHP-200 User manual

REFRIGERANT CYCLING HEAT PUMP WATER HEATER
USER MANUAL
SAFETY INFORMATION
Read these instructions carefully before installation.
Keep this manual in a handy for future reference.
Improper installation of equipment or accessories may
result in electric shock, short-circuit, leakage, fire or
other damage to the equipment. Be sure to only use
accessories made by the supplier, which are specifically
designed for the equipment and make sure to get
installation done by a professional.
All the activities described in this manual must be carried
out by a licensed technician. Be sure to wear adequate
personal protection equipment while installing the unit
or carrying out maintenance activities.
Contact your dealer for any further assistance.
MODEL NUMBERS:
EE-HWS-RCHP-200 EE-HWS-RCHP-200E
EE-HWS-RCHP-300 EE-HWS-RCHP-300E
Thank you for choosing Emerald Energy.
This leaflet contains important information on the correct
installation and operation of your heat pump water heater.
CONTENTS
SAFETY PRECAUTIONS 2-3
GENERAL INTRODUCTION 4
- Outdoor unit 4
- Water tank 4
BEFORE INSTALLATION 5
- Accessories 5
- Space for maintenance 5
INSTALLATION PROCEDURE 6-9
- Dimension sketch 6
- Drain hole position 7
- Pipe connection 7
- Vacuum drying 8
- Refrigerant charge 9
ELECTRICAL CONNECTION 10-12
- Power supply cords 10
- Electrical wiring diagram 11
- Water tank temperature sensor installation 11
- ODX & AUX power connection 12
CHECK 13
OPERATION AND PERFORMANCES 14
MAINTENANCE 15
- Confirmation before running 15
- Troubleshooting 15
- After sales service 15
- Important refrigerant information 15
ERROR CODE TABLE 16
POWER SUPPLY: 220V-240V/1N~50Hz
ENVIRONMENT TEMPERATURE: -15°C  46°C
Working water temperature: Min inlet water temperature 5°C,
Max outlet Water Temperature 60°C.

Electric connection work should obey the instructions of local power
company, local electric utility and this manual.
Never use the wiring and fuse with wrong rated current, otherwise
the unit maybe break down and cause fire further more.
Do not insert fingers, rods or other objects into the air inlet or outlet.
When the fan is rotating at high speed, it will cause injury.
Never use a flammable spray such as hair spray, lacquer paint near
the unit. It may cause a fire.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities or lack of expe-
rience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they do
not play with the appliance.
Tear apart and throw away plastic packaging bags so that children
will not play with them. Children playing with plastic bags face dan-
ger of death by suocation.
Safely dispose of packing materials such as nails and other metal or
wood parts that could cause injuries.
Ask your dealer or qualified personnel to perform installation work in
accordance with this manual. Do not install the unit yourself. Improp-
er installation could result in water leakage, electric shocks or fire.
Be sure to use only specified accessories and parts for installation
work. Failure to use specified parts may result in water leakage,
electric shocks, fire, or the unit falling from its mount.
Install the unit on a foundation that can withstand its weight.
Insucient physical strength may cause the equipment to fall and
possible injury.
Perform specified installation work with full consideration of strong
wind, hurricanes, or earthquakes. Improper installation work may
result in accidents due to equipment falling.
Make certain that all electrical work is carried out by qualified
personnel according to the local laws and regulations and this
manual using a separate circuit. Insucient capacity of the power
supply circuit or improper electrical construction may lead to electric
shocks or fire.
Be sure to install a ground fault circuit interrupter according to
local laws and regulations. Failure to install a ground fault circuit
interrupter may cause electric shocks and fire.
Make sure all wiring is secure. Use the specified wires and ensure
that terminal connections or wires are protected from water and
other adverse external forces. Incomplete connection or axing
may cause a fire.
When wiring the power supply, form the wires so that the front panel
can be securely fastened. If the front panel is not in place there
could be overheating of the terminals, electric shocks or fire.
After completing the installation work, check to make sure that there
is no refrigerant leakage.
Never directly touch any leaking refrigerant as it could cause severe
frostbite. Do not touch the refrigerant pipes during and immediately
after operation as the refrigerant pipes may be hot or cold, depend-
ing on the condition of the refrigerant flowing through the refrigerant
piping, compressor and other refrigerant cycle parts. Burns or frost-
bite are possible if you touch the refrigerant pipes. To avoid injury,
give the pipes time to return to normal temperature or, if you must
touch them,be sure to wear protective gloves.
Do not touch the internal parts (pump, backup heater, etc.) during
and immediately after operation. Touching the internal parts can
cause burns. To avoid injury, give the internal parts time to return
to normal temperature or, if you must touch them, be sure to wear
protective gloves.
Servicing shall only be performed as recommended by the equip-
ment manufacturer. Maintenance and repair requiring the assistance
of other skilled personnel shall be carried out under the supervision
of the person competent in the use of flammable refrigerants.
1. SAFETY PRECAUTIONS
⚠ DANGER
If the hot water system is not used for two weeks or more, a quantity
of highly flammable hydrogen gas may accumulate in the water
heater. To dissipate this gas safely, it is recommended that a hot tap
be turned on for several minutes. Before touching electric terminal
parts, turn o power switch.
Do not touch the inner parts of the controller. Do not remove the
front panel. Some parts inside are dangerous to touch, otherwise a
machine malfunction may be caused.
When front panels are removed, live parts can be easily touched by
accident.
Never leave the unit unattended during installation or servicing when
the front panel is removed.
Do not touch water pipes during and immediately after operation
as the pipes may be hot and could burn your hands. To avoid injury,
give the piping time to return to normal temperature or be sure to
wear protective gloves.
Do not touch any switch with wet fingers. Touching a switch with wet
fingers can cause electrical shock.
Before touching electrical parts, turn o all applicable power to the
unit.
⚠ WARNING
A creepage breaker must be installed adjacent to the power supply.
Do not remove, cover or deface any permanent instructions, labels,
or the data labels from either the outside of the unit or inside of unit
panels.
Required qualified person for relocating, repairing and maintaining
the unit instead of doing by yourself.
2
⚠DANGER Indicates an imminently hazardous situation
which if not avoided, will result in death or serious injury.
⚠WARNING Indicates a potentially hazardous situation
which if not avoided, could result in death or serious injury.
⚠CAUTION Indicates a potentially hazardous situation
which if not avoided, may result in minor or moderate injury.
It is also used to alert against unsafe practices.
NOTE Indicates situations that could only result in
accidental equipment or property damage.
WARNING
Indicates this appliance uses a flam-
mable refrigerant. If the refrigerant is
leaked and exposed to an external
ignition source, there is a risk of fire.
CAUTION Indicates the operation manual should
be read carefully.
CAUTION
Indicates a service personnel should
be handling this equipment with
reference to the installation manual
CAUTION
Indicates information is available such
as the operating manual or installation
manual.
Explanation of symbols displayed on the unit
The precautions listed here are divided into the following types.
They are important, please follow them carefully.

1. SAFETY PRECAUTIONS
⚠ CAUTION
The earthing pole of socket must be grounded well, make sure that
power supply socket and plug are dry enough and connected tightly.
Before cleaning, be sure to stop the unit and turn the breaker o or
pull out the power plug.
After a long term use, check the unit base and fittings. If damaged,
the unit may sink and result in injury.
Arrange the drain pipe to ensure smooth draining. Improper drainage
work may cause wetting of the building, furniture etc.
Do not turn o the power supply. System will stop or restart heating
automatically. A continuous power supply for water heating is
necessary, except service and maintenance.
Ground the unit.
Grounding resistance should be according to local laws and
regulations.
Do not connect the ground wire to gas or water pipes, lightning
conductors or telephone ground wires.
Incomplete grounding may cause electric shocks.
- Gas pipes: Fire or an explosion might occur if the gas leaks.
- Water pipes: Hard vinyl tubes are not eective grounds.
- Lightning conductors or telephone ground wires: Electrical
threshold may rise abnormally if struck by a lightning bolt.
The installation height of power supply should be over 1.8m, if there
is any water spattered, separate the power supply from water.
Do not wash the unit. This may cause electric shocks or fire.
The appliance must be installed in accordance with national wiring
regulations. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
Do not install the unit in the following places:
- Where there is mist of mineral oil, oil spray (eg: kitchen) or
vapors. Plastic parts may deteriorate, and cause them to come
loose or water to leak.
- Where corrosive gases (such as sulfurous acid gas) are
produced. Where corrosion of copper pipes or soldered parts
may cause refrigerant to leak.
- Where there is machinery which emits electromagnetic waves.
Electromagnetic waves can disturb the control system and cause
equipment malfunction.
- Where flammable gases may leak, where carbon fiber or
ignitable dust is suspended in the air or where volatile flammables
such as paint thinner or gasoline are handled. These types of
gases might cause a fire.
- Where the air contains high levels of salt such as near the
ocean.
- Where voltage fluctuates a lot, such as in factories.
- In vehicles or vessels.
- Where acidic or alkaline vapors are present.
- Other special environments.
This appliance can be used by children 8 years old and above and
persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they are supervised or given
instruction on using the unit in a safe manner and understand the
hazards involved. Children should not play with the unit. Cleaning
and user maintenance should not be done by children without
supervision.
Children should be supervised to ensure that they do not play with
the appliance.
If the supply cord is damaged, it must be replaced by the manufactur-
er or its service agent or a similarly qualified person.
DISPOSAL: Do not dispose this product as unsorted municipal
waste. Collection of such waste separately for special treatment
is necessary. Do not dispose of electrical appliances as municipal
waste, use separate collection facilities. Contact your local govern-
ment for information regarding the collection systems available. If
electrical appliances are disposed of in landfills or dumps, hazardous
substance can leak into the groundwater and get into the food chain,
damaging your health and well-being.
The wiring must be performed by professional technicians in accor-
dance with national wiring regulation and this circuit diagram. An
all-pole disconnection device which has at least 3mm separation
distance in all pole and a residual current device (RCD) with the
rating not exceeding 30mA shall be incorporated in the fixed wiring
according to the national rule.
Confirm the safety of the installation area (walls, floors, etc.) without
hidden dangers such as water, electricity, and gas. Before wiring/
pipes.
Before installation, check whether the user's power supply meets
the electrical installation requirements of unit (including reliable
grounding, leakage, and wire diameter electrical load, etc.). If the
electrical installation requirements of the product are not met, the
installation of the product is prohibited until the product is rectified.
When installing multiple air conditioners in a centralized manner,
please confirm the load balance of the three-phase power supply,
and multiple units are prevented from being assembled into the
same phase of the three-phase power supply.
Product installation should be fixed firmly.
Take reinforcement measures, when necessary.
NOTE
About Fluorinated Gasses
- This air-conditioning unit contains fluorinated gasses.
For specific information on the type of gas and the amount,
please refer to the relevant label on the unit itself.
Compliance with national gas regulations shall be observed.
- Installation, service, maintenance and repair of this unit must
be performed by a certified technician.
- Product uninstallation and recycling must be performed by a
certified technician.
- If the system has a leak-detection system installed, it must be
checked for leaks at least every 12 months. When the unit is
checked for leaks, proper record-keeping of all checks is
strongly recommended.
3

2. GENERAL INTRODUCTION
4
1
2
3
4
5
5 No. NAME
1 Power cord enter
2 High pressure valve
3 Low pressure valve
4 Air outlet
5 Air inlet
6
7
10
8
9
5
4
5
6
7
8
9
10
11
11
12
12
1
2 1
2
3
4
No. NAME
1 Magnesium rod insertion port
2 Foam filling port
3 Reserved port
4 Water outlet
5 Temperature pressure safety valve
6 Water tank temperature sensor
7 Handle
8 Refrigerant gas pipe
9 Refrigerant liquid pipe
10 Water inlet
11 Drain outlet
12 Electric auxiliary heat
2.1 OUTDOOR UNIT
2.2 WATER TANK
200L WITHOUT HEATER 300L WITH HEATER
⚠ CAUTION
Install safety valve to water inlet, the largest torque of safety valve shouldn’t be more than 80N.m.
Ensure the water tank is placed upright. Install in a location to prevent unit toppling and falling e.g. balcony or corner. If installing the unit in
an open space, avoid areas of strong wind. Please fix water tank according to operation manual.
All the diagrams in this manual is for reference only, its appearance and function may dierent from water heater that you bought, actual
model shall prevail.
Fig. 2-1
Fig. 2-2

3. BEFORE INSTALLATION
5
≥300mm
≥1500mm
Air outlet
≥200mm
≥600mm
≥600mm
Use bolt to fix
≥200mm
≥500mm
3.1 ACCESSORIES
3.2 SPACE FOR MAINTENANCE
Mater unit and water tank installation and maintenance space, see Fig 3-1 . (Unit: mm)
ACCESSORY NAME QTY SHAPE PURPOSE
Installation manual 1 Need by master unit
Wired controller components 1 Control unit and display unit status
Water drainage connection 1 For condensate water draining
Water temperature sensor 1 Measure water temperature inside water tank
Water drainage pipe 1 Condensate water drainage of unit bottom plate
Plastic expansion tube 4 To fix mounting box
Screw 4 To fix mounting box
Fixing box of HMI 1 Install the wired controller
Wiring for HMI 1 Connect the unit and HMI
Table 3-1
Fig. 3-1

4. INSTALLATION PROCEDURE
6
4.1 DIMENSION SKETCH
Dimension of outdoor unit, see Fig. 4-2 and Table 4-1
Strong
wind
CORRECT INCORRECT
B
A
DE
C
DIMENSION AND MOUNTING DIMENSION
A B C D E
803.6 554.9 311.6 452.4 137.5
Table 4-1
NOTE
Ask your dealer or specialized person for moving, repair, and maintenance.
Install it in the place without direct sunlight and other direct heat radiations. If it can’t be avoided, please add a cover to prevent unit from
direct sunlight.
The ceiling is horizontal, and its structure can endure the weight of the indoor unit.
Please firmly install the unit, otherwise it may cause abnormal noise and vibration.
Remove obstacles nearby. A narrow circulation space may influent performance of the unit.
Install in the place that closes to water tank as far as possible, under the condition that the installation requirements could be satisfied.
When installing in the place that near to the sea and high place where strong wind blows, install the unit against a wall or use a bae when
necessary to ensure the unit could run normally. Especially in the place with strong wind, pay attention not to let strong wind blow back to
the unit.
If install the unit in a basement, inside the room or other confined space, please pay attention to air discharge and air supply circulation
around the unit and outside. Circulation air volume should not less than 1000m3/h.
Fig. 4-1
Fig. 4-2

4. INSTALLATION PROCEDURE
7
4.2 DRAIN HOLE POSITION
4.3 PIPE CONNECTION
4.3.1 UNIT CONNECTION SKETCH
Unit connection sketch, please refer to Fig.4-4.
NAME Water end user Stop valve
(bought by customers themselves)
Water mixing valve
(bought by customers themselves)
ICON
NAME Safety valve
(must be installed)
Expansion tank
(suggest to install)
Y-shape filter
(bought by customers themselves)
ICON
Table 4-2
Water outlet
connection
pipe/gasket
Fig. 4-3
==
6.35
9.52
OUTDOOR UNIT WATER TANK
Hot water outlet
Cold water inlet
1
2
2
2
3
4
5
Fig. 4-4

4. INSTALLATION PROCEDURE
8
4.3 PIPE CONNECTION CONTINUED
4.3.2 STOP VALVE INSTRUCTION
In general, the shape of stop valve and names of each part are
shown in Fig.4-5.
Eect of stop valve:
- Stop the system when the unit is working.
- When water tank connects with the master unit, vacuumize and
add refrigerant through it.
- Stop the system and then recycle refrigerant to master unit when
maintaining.
Open and close the stop valve:
- Open: dismantle the bonnet by wrench and insert an allen key
to spool, open the stop block anticlockwise and then tighten the
bonnet.
- Close: use a wrench to dismantle the bonnet and insert an allen
key to spool, close the stop block clockwise and then tighten the
bonnet.
4.4 VACUUM DRYING
4.4.1 PURPOSE
Vacuum drying should be performed in order to remove moisture
and non-condensible gases from the system. Removing moisture
prevents ice formation and oxidization of copper piping or other
internal components. The presence of ice particles in the system
would cause abnormal operation, whilst particles of oxidized copper
can cause compressor damage. The presence of non-condensible
gases in the system would lead to pressure fluctuations and poor
heat exchange performance.
4.4.2 PROCEDURE
4.3.3 CONNECTION LENGTH OF OUTDOOR UNIT AND WATER
TANK PIPE AND HEIGHT DIFFERENCE REQUIREMENTS:
MAX.
LENGTH
m
MAX. HEIGHT
DIFFERENCE
m
STANDARD
LENGTH
m
STANDARD
HEIGHT
DIFFERENCE
m
20 10 2 0
Table 4-4
1
2
Pressure
gauge
Outdoor unit
R134a
refrigerant tank
Stop valve
1. Gas pipe stop valve
2. Liquid pipe stop valve
Service
port
Pressure gauge
⚠ CAUTION
Before water heater runs, please make sure every stop valve
has been opened.
Spool
(you can see the bonnet
after dismantling)
Valve spool
(you can see the bonnet
after dismantling)
Bonnet
Connection nut
Ball-shape cushion
Connection pipe
NOTE
Do not let air, dust, or other impurities fall in the pipe system
during installation.
The connecting pipe should not be installed until the indoor
and outdoor units have been fixed already.
Keep the connecting pipe dry, and do not let moisture in
during installation.
When connecting copper pipe, please wrap it with thermal
insulation material.
Fig. 4-5 Fig. 4-6
Fig. 4-7

ITEM DESCRIPTION IMAGE NOTE
1
Connect the blue (low pressure side)
hose of a pressure gauge to the outdoor
unit gas pipe stop valve.
Before performing vacuum drying, make sure that all
the outdoor unit stop valves are firmly closed.
2Connect the yellow hose to the vacuum
pump.
1. Mixing of pump lubricant with compressor oil could
cause compressor malfunction and a one-way valve
should therefore be used to prevent vacuum pump
lubricant seeping into the piping system.
2. Using a vacuum pump with a discharge in excess of
4L/s and a precision level of 0.02mmHg is
recommended
3Connect the outdoor unit gas pipe stop
valve to water tank gas pipe
4Connect the outdoor unit liquid pipe
stop valve to water tank liquid pipe
5
Start the vacuum pump and then open
the pressure gauge valves to start
vacuum the system.
6After 15-20 minutes, close the pressure
gauge valves.
7
After a further 5 to 10 minutes check
the pressure gauge. If the gauge has
returned to zero, check for leakages in
the refrigerant piping. If the gauge is no
change, then vacuum drying is OK.
8
Re-open the pressure gauge valves and
continue vacuum drying for at least 20
minutes and until a pressure dier-
ence of 756mmHg or more has been
achieved. Once the pressure dierence
of at least 756mmHg has been achieved,
continue vacuum drying for 20 minutes.
9Close the pressure gauge valves and
then stop the vacuum pump.
10
After 1 hour, check the pressure gauge.
If the pressure in the piping has not
increased, the procedure is finished. If
the pressure has increased, check for
leakages.
After vacuum drying, keep the blue and red hoses con-
nected to the pressure gauge and to the outdoor unit
stop valves, in preparation for refrigerant charging
Table 4-5
4.5 REFRIGERANT CHARGE
Pipe length is 2~20m.
If the pipe length is less than 10m, there is no need to add additional refrigerant charge.
If the pipe length is more than 10m, adding additional refrigerant charge is necessary, and the rule is 20g/m for the additional pipe.
4. INSTALLATION PROCEDURE
9

5. ELECTRICAL CONNECTION
10
⚠ CAUTION
The heat pump should use separate power supply with rated voltage. If voltage is not stable, please use stabilized voltage supply.
The external power supply to the heat pump should have ground wiring, which is linked to the ground wiring of the indoor and outdoor unit.
The wiring work should be done by qualified persons according to circuit drawing.
A leakage protector should be installed according to the National Standard concerning electrical appliance.
An all-pole disconnection device which has at least 3mm separation distance in contact points should be installed.
Power supply cords and signal wires should be arranged properly. Separate strong current wire and weak current wire, meanwhile they
can’t contain with connection pipe and valve.
Power supply with a leakage protector should be installed in a water-proof place inside the room.
Don’t do cross connection between 2 wires and signal wires must be shielded.
When power supply cord parallels with controlling wire, please put the wires to corresponding wire pipe and leave proper space between
wires.
When selecting power supply cords, please refer to the National Standard and this manual, power supply used outdoor should not
lighter than NO.57 wire in IEC 60245.
If power supply cord is damaged, to avoid danger, it must be replaced by professional person.
Do not turn on the power until you have checked carefully after wiring.
5.1 POWER SUPPLY CORDS
5.1.1 SPECIFICATION OF POWER SUPPLY
POWER
MINIMUM WIRE DIAMETER
MM 2MENTAL PIPE
SYNTHETIC RESIN PIPE WIRE
Manual switch
(A)
LEAKAGE
PROTECTOR
MAX
EHEATER
POWER W
LENGTH
SUCCESSIVE
LENGTH ≤30M
GROUND
WIRE CAPACITY FUSE
230V~
50Hz 2.5 2.5 20 15
30mA
below
0.1 sec
2200
Table 5-1
NOTE
Specifications of power wires above (master unit power wire
and power wire that connects with water tank) H07RN-F
Power supply provided individually (not use power supply
device).
⚠ CAUTION
Wire diameter shown in the table above and successive length
is the situation than voltage drop is in the range of 2%, when
successive length is longer than the value shown in the table,
please select wire diameter according to relative standards.

5. ELECTRICAL CONNECTION
11
5.2 ELECTRICAL WIRING DIAGRAM SEE FIG 52
5.3 WATER TANK TEMPERATURE SENSOR INSTALLATION
Connect the water tank temperature sensor wire connector to the outdoor unit T5L connector.
Fig. 5-1
Fig. 5-2

12
5. ELECTRICAL CONNECTION
5.4 ODU & AUX. POWER CONNECTION
⚠ CAUTION
A leakage protector must be installed on power supply box outside the unit according to the figure above.
Power supply with leakage protector must be installed inside or installed in the place that can satisfy water-proof requirements.
This unit can be started only if it is grounded reliably.
NOTE
If the water tank has the electric auxiliary heating( AUX.) function, please follow the steps below to connect the electric auxiliary heating
power cord.
GND
L
N
4
3
1
0
1 2
16A
o
oo o o o
o o
Power supply E-heater
1. Remove the protective cover of the electric
control box on the right side of the outdoor unit.
2. Connect the electric auxiliary heating power
line on the water tank to the corresponding port
on the ???PCB???.
3. Outdoor unit power supply.
C: E-heater power cord
1 : Electric counter
2 : Global over current and leakage
circuit breaker
3 : Electric leakage circuit breaker
4 : over current circuit breaker
OUTDOOR UNIT PCB
OUTDOOR UNIT PCB
Fig. 5-3
Fig. 5-4
Fig. 5-5

13
6. CHECK
NOTE
Before switching on the unit, read following recommendations:
When the installation and parameter setting are completed, cover all the sheet metal of the unit well.
The unit should be maintained by professionals.
If the whole unit failed or in protection, the panel will display the corresponding code; when more than one failure or protection
occurs, the order of failure protection will display. When checking, the number is displayed first, then the content. Press check button,
you can go over parameters of the whole unit, the following table shows sequence of check:
ITEM DESCRIPTION IMAGE
0 Normal display
“dF”——Defrosting
“dC”——Refrigerant recovering
“0”——When being shut down
“Tx”——When booting or standby
1 Running mode "3"——Water heating
2 Running air speed
"F0" ——Shut down fan
"F1" ——Low speed
"F3"—— High speed
3 T3 temp. value
4 T4 temp. value
5T5L temp. value
6 Th temp. value
7 Tp temp. value
8 Current
9 EEV opening degree Actual opening=display value×8
10 T5s setting temperature
11 Td setting auto start temp of auxiliary E-heat
12 Trdh setting booting return dierence temp.
13 Penultimate error
14 The third to last error
15 The last error
16 Software version Actual version
17 Check finished “- -”
Table 4-5

14
7. OPERATIONS AND PERFORMANCES
⚠ CAUTION
Please cut o the manual switch power when unit fails. Do not restart until problems are solved.
1. Characteristics of water heating - 3 minute protection.
Restart or open manual switch after the unit has been shut down. Unit will not start immediately until 3 minutes later, because of the self-protect
function of the compressor.
2. During operation, if outdoor temperature is higher than normal, the air supply motor will runs at low air volume or stop running.
3. About defrosting function perform at heating operation.
a. In case of frosting during heating operation, to prevent the heating eciency from decreasing, defrosting operation will turn on
automatically (approx. 2~7 minutes).
b. In the process of defrosting operation, the unit air supply motor will stop running.
4. About protection device.
a. When protection device operate, though the unit stops, the operating indicator of wire control still will be blinking.
b. When protection device operates, nixie indicator will display malfunction code (unit).
c. Protection device will act when the following circumstances occur:
i) Air inlet or outlet are blocked.
ii) Voltage is a little higher or lower compare to the voltage range (Exceeding the range of -15%~105 of 230V )
5. Start the unit after a long period out of service
Start-up the unit after out of service for a long period (includes drive up a unit at the first time), you would see rust mix up water in red,flow out
from tap. Such that is a normal phenomenon, please be calmly and keep draining, after for a while rust will disappear.
6. About power failure
a. In case power failure during the unit working, please stop all operating actions.
b. At the next startup after power failure, the RUN indicator of wire controller will blink slowly for several seconds for noting user.
c. Mis-operation occur during unit working.
7. About RCCB
a. Outdoor unit must use RCCB, pleases install an RCCB between in user power supply and the outdoor unit. In case the unit cannot act but
not attribute to power failure, please check these RCCB switches at first. Before operate the RCCB, please ensure that the user installing
switch is break o.

15
8. MAINTENANCE
8.1 CONFIRMATION BEFORE RUNNING
1) Make sure whether ground wire is broken or fall o.
2) Turn on power supply switch for 12 hours before running.
8.2 TROUBLESHOOTING WHEN ABNORMAL
SITUATION HAPPENS
Before asking for serving or repairing, check the following
points:
Non-mechanical malfunction
1. Water oozes from safety valve pressure relief opening
When water heating, cold water will expand when heated, water
oozing is normal. Do not block it for safety consideration.
If a large amount of water flows, it means safety valve is invalid. Stop
using and replace safety valve.
2. Long period for heating a tank of water
In winter, water heating eciency will decrease because of low ambi-
ent temperature (about 0º). It will take a longer time for water heating.
If customer needs to use hot water, please start the unit in advance.
Need to check
1. Automatically start or stop
- Whether we set timer wrongly.
2. When not working
- Check whether powering on.
- Whether manual switch is on.
- Whether fuse blows.
- Whether start the protection device (indicator lights).
- Whether it is not the time of timer on (operation lamp lights).
3. If heating eect is not good
- Whether air outlet and inlet has been blocked.
⚠ CAUTION
If the following situation happens, please stop running and
cut o power supply manually and contact with the dealer or
service center.
 ON/OFF operation is ineective.
 Fuse or RCCB trips frequently
After left unused for a long time, please check the following
items:
 Check air inlet and outlet of the unit to see whether they are
blocked. Clean immediately when they are blocked.
 Check whether water pipes, valves have been damages or
blocked. Whether there’s water leakage in joints, replace them
when water leaks.
 It's recommended to inspect anode protection material every
half year. If it's been exhausted, please replace with a new one.
8.3 AFTERSALE SERVICE
In case of following malfunctions, please cut o the power switch and
contact after-sale service centre or technical service department, for
detailed information please refer to User Service Guide..
8.4 IMPORTANT INFORMATION FOR THE
USED REFRIGERANT
This product has the fluorinated gas, it is forbidden to release
to air.
Refrigerant type: R134a; Volume of GWP: 1430;
GWP=Global Warming Potential
FACTORY CHARGE
Refrigerant/kg tonnes CO2 equivalent
0.9 1.29
Table 8-1
ATTENTION:
Frequency of Refrigerant Leak Checks
1. For equipment that contains fluorinated greenhouse gases in
quantities of 5 tonnes of CO2 equivalent or more, but of less than
50 tonnes of CO2 equipment,at least every 12 months, or where a
leakage detection system is installed, at least every 24 months.
2. For equipment that contains fluorinated greenhouse gases in
quantities of 50 tonnes of CO2 equivalent or more, but of less than
500 tonnes of CO2 equipment,at least every six months, or where a
leakage detection system is installed, at least every 12 months.
3. For equipment that contains fluorinated greenhouse gases in
quantities of 500 tonnes of CO2 equivalent or more, at least every
three months, or where a leakage detection system is installed, at
least every six months.
4. Non-hermetically sealed equipment charged with fluorinated
greenhouse gases shall only be sold to the end user where evidence
is provide that the installation is to be carried out by an undertaking
certified person.
5. Only certificated person is allowed to do installation, operation and
maintenance.

WARRANTY INFORMATION
Emerald Energy Pty Ltd warrants this heat pump to the original purchaser.
Emerald Energy Pty Ltd warrants each new heat pump is free from defects in material and workmanship under normal use and service from the date of
purchase. 2 year labour warranty. 7 years warranty on the tank, and 5 years on the rest of the system. *Subject to terms and conditions.
This warranty does not cover damage resulting from accident, misuse or abuse or lack of reasonable care of the product.
In no case shall Emerald Energy Pty Ltd be liable for any incidental or consequential damages for breach of this or any other
warranty express or implied whatsoever.
For full warranty details visit our website emerald-energy.com.au
Emerald Energy Pty Ltd
ABN 86 632 172 368
2/29 Mitchell Rd Brookvale NSW 2100 2022.10
TROUBLE SHOOTING
ERROR
CODE CAUSE
E2 Communication fault
E4 T5L sensor fault
E5 T3 sensor fault
E6 T4 sensor fault
E9 Th sensor fault
EA Tp sensor fault
EE EEPROM failure
EF Clock chip fault
EP Leakage protection fault
P1 High pressure protection
P2 Compressor over current protection
P4 Exhaust temperature overheating protection
PA Low water temperature protection
bA Ambient temperature out of operating range protection
HC The electric auxiliary heat no-current protection
HP Smart Grid signal failure
Pb Anti-freezing protection runs
Table 9-1
