emerio TFN-2144743.11 User manual

- 1 -
Content –Inhalt –Teneur –Contenuto
Instruction manual –English......................................................................................- 2 -
Bedienungsanleitung –Deutsch...............................................................................- 13 -
Mode d'emploi –Français........................................................................................- 25 -
Manuale d'istruzioni –Italiano.................................................................................- 37 -

- 2 -
Instruction manual English

Before use make sure to read all of the below instructions in
order to avoid injury or damage, and to get the best results
from the appliance. Make sure to keep this manual in a safe
place. If you give or transfer this appliance to someone else
make sure to also include this manual.
In case of damage caused by user failing to follow the
instructions in this manual the warranty will be void. The
manufacturer/importer accepts no liability for damages
caused by failure to follow the manual, a negligent use or use
not in accordance with the requirements of this manual.
1. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
2. Children shall not play with the appliance.
3. Cleaning and user maintenance shall not be made by
children without supervision.
4. The appliance is only to be used with the power supply unit
provided with the appliance.
5. Before inserting the plug into the mains socket, please
check that the voltage and frequency comply with the
specifications on the rating label.
6. Please use a separate outlet according to the current /
voltage of the fan. Do not use a multi-purpose socket for
simultaneous use with other electrical devices.
7. Disconnect the mains plug from the socket when the
appliance is not in use and before cleaning.
8. Ensure that the mains cable is not hung over sharp edges
and keep it away from hot objects and open flames.
9. Do not immerse the appliance or the mains plug in water or
other liquids. There is danger to life due to electric shock!
10. To remove the plug from the plug socket, pull the plug. Do
not pull the power cord.

- 3 -
11. Do not plug or unplug the appliance from the electrical
outlet with a wet hand.
12. Never attempt to open the housing of the appliance, or to
repair the appliance yourself. This could cause electric
shock.
13. Never leave the appliance unattended during use.
14. This appliance is not designed for commercial use.
15. Do not use the appliance for other than intended use.
16. Do not wind the cord around the appliance and do not bend
it.
17. Do not place any objects on the air inlet or outlet. Make
sure that the ventilation openings are free of dust, lint, hair
and other obstacles that could impair the air flow.
18. The fan should be set up dry on a horizontal platform and
should not be near heat sources, corrosive air and moisture.
The fan should be kept a distance of 150 mm around to
ensure good air circulation.
19. Do not use the fan outdoors or on a wet surface.
20. Do not immerse the fan, power cord, or plug in water or
other liquids to avoid danger. The use of an extension cord
is not recommended unless it has been tested by a qualified
person.
21. Please do not use an air cleaner or similar product right next
to the fan.
22. Do not use any cleaning agents or lubricants for this fan and
pull out the power plug before cleaning, transporting and
servicing the device.
23. WARNING — This appliance contains a UV-C emitter. Do not
stare at the light source.
24. Unintended use of the appliance or damage to the housing
may result in the escape of dangerous UV-C radiation. UV-C
radiation may, even in little doses, cause harm to the eyes
and skin.
25. WARNING: the UV-C emitter installed inside product is not
allowed to replacement by the user. If the UV-C emitter is
damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid
a hazard.

- 4 -
 

1. Air outlet
2. Air duct
3. Top cover of the air purifier filter
4. Air inlet
5. Touch screen button / digital display
6. Base
7. Air duct
8. Top cover of the air purifier filter
9. Air inlet
10. Main body
11. Power connection
12. Adapter

1. Wi-Fi connection
2. UV indicator
3. Negative ions function
4. Filter indicator
5. Speed / timer display

- 5 -

This unit has a remote control. One piece of CR2025 battery is to be installed (not included). If you want to
change the battery, please refer to below pictures. If it is not in use for a long time, please take the battery out
of the remote control. Keep button cell batteries out of reach of small children.


The remote control should be pointed at the signal receiver on the digital display to maximize the remote control
signal.

1. This fan may respond to the remote control of other devices.
2. If you use the remote control of this fan, other devices may respond.
This is due to the overlapping frequencies of the remote control. There is no quality problem in the product itself.
To avoid misuse, keep the remote control away from other electrical devices during operation.

Power button:
Turn the fan on and off
Mode button for wind
speed:
sleep / fresh /boost
Swing:
Start and stop swing
Increase airflow
Decrease airflow
(9 speed levels)
Sleep timer:
1 to 8 hours of timed
shutdown
Buckle
UV sterilization:
Sterilization function

- 6 -
1. Before use, hold the fan body with one hand and the other hand to set the wind outlet 15° before and after.
2. Connect the adapter into the power connection of the fan first and then insert the adpater into a suitable
power outlet. The digital display lights up and the fan goes into standby mode.
3. To switch on and off:
Press the touch screen button (the digital display) the buzzer will beep once and the fan will start. Press and
hold the touch screen button for 2 seconds the buzzer will beep twice and the fan will stop running after you
release your hand.
4. To set the air volume:
When the fan is operating press the touch screen button to adjust the air volume from 1 to 9.
5. To set the oscillation function:
When the fan is operating press and hold the touch screen button for 1 second. The buzzer will beep once
and the fan will start oscillating. Press and hold the touch screen button for 1 second again. The buzzer will
beep once and the fan will stop oscillating.


 


1. The digital display will extinguish in approx. 20 seconds with no operations. If you want to do further
operations, firstly press any button (except for the power button) on the remote control or press the touch
screen button on the fan body to turn on the digital display and then press your desired buttons to choose
your desired functions.
2. After the timer is set, the digital display will turn back to show the speed level and extinguish later. If you
want to check the remaining time, turn on the digital display first and then press the timer button once on
the remote control, the remaining time (by hour) will be shown on the digital display.
Press the power button to turn on/off the appliance.
Press the mode button to choose your desired wind speed:
sleep mode / fresh mode / boost mode: the digital display will
show “L” / “-” / “H” and the wind speed will become minimum
/ adjust among speed 3-4-5 / become maximum. You can exit
the mode by pressing the button “+/-”.
Press the oscillation button to turn on the oscillation function.
Press this button again to stop oscillating.
Press the “+” button to increase the air volume. Press the “-”
button to decrease the air volume. There are 9-speed settings.
Press the timer button to set the working time from 1 to 8
hours. A small “” will flash on the digital display to indicate the
timer is under setting/operation.
Press the UV sterilization button to turn on the UV sterilization
function. The UV indicator will be on. The UV lamp inside the
appliance will effectively kill bacteria/virus in the air. Press the
button again to turn the function off. This function will
automatically shut down after 1 hour.

- 7 -


This appliance is equipped with an air cleaning filter. Before using the appliance, the filter should be installed in
it so that the air can be cleaned. Installation and replacement method of the air cleaning filter are as follows.
◼Please use the fan on a flat platform. Do not place
the fan in an unstable place, such as an inclined or
soft surface, to avoid damage or malfunctions
caused by the fan tipping over.
◼Avoid blocking the air inlet when using. Stay away
from the curtains to avoid objects blocking the air
inlet and the fan not working.
◼Do not place any objects within 30 cm of the air
outlet, otherwise the blower effect will be
impaired.
Away from curtains
Turn the top cover of the filter
counter clockwise to unlock and
remove the filter.
Disconnect the old filter from the
top cover. Pull it out directly.
Attach the new filter to the top
cover. Make sure they are
connected firmly.
After assembling, put it back into
the main body and turn it
clockwise to secure it.

- 8 -
The fan has a memory function. After a total of 720 hours of operation, the filter indicator will be on. After
replacing the filter, long press the power button on the remote control for 5 seconds. When a beep sound is
heard, the indicator will be off and the operating time is converted again.



1. Search “Smart Life – Smart Living” in App Store (for iOS) or Google play (for Android), or directly scan the QR
code below, to download the application “Smart Life”.
2. Sign up or log in to your account on the APP. Tap the “+” at right top or button “Add Device” to add your
device.
3. Find “Small Home Appliances” and tap the icon “FAN (Wi-Fi)”.
You will get the prompt that asks you to use the 2.4 GHz Wi-Fi network. Note that the 5 GHz Wi-Fi is not
supported by this application. Enter your Wi-Fi password and connect to the Wi-Fi. You will get Fig.1.
There are two ways to do the net pairing. Press and hold the power button for 5 seconds, the digital display
will show “F” blinking quickly (way 1). Continue to press and hold the power button for another 5 seconds,
the digital display will show “F” blinking slowly (way 2). Continue to press and hold the power button for the
last 5 seconds, the digital display turns to show “0” and the pairing is cancelled.


- 9 -

1) Press and hold the power button for 5 seconds until the digital display shows “F” and “F” flashes quickly.
2) Tap “Next” on Fig.1. You will get Fig.2 that asks you to check the status of the indicator light. Tap “Blink
Quickly”.
3) Wait until you get Fig.4 and then tap “Done” at the top right corner.
4) Now you can operate your device in the control interface. Tap buttons to set your appliance.

1) Press and hold the power button for 5 seconds until the digital display shows “F” and “F” flashes quickly.
Continue to press and hold the power button for another 5 seconds until the “F” flashes slowly.
2) Tap “Next” in Fig.1. You will get Fig.2 that asks you to check the status of the indicator light. Tap “Blink
Slowly”. Continue to tap “Go to Connect” in Fig.3 to connect your mobile phone to the device’s hotspot
“SmartLife-XXXX”. After the hotspot has been connected, go back to the App.
3) Wait until you get Fig.4 and then tap “Done” at the top right corner.
4) Now you can operate your device in the control interface. Tap buttons to set your appliance.
Fig. 1 Fig.2 Fig.3
Fig.4
