CORESENSE™ DIAGNOSTICS FOR COPELAND™ STREAM COMPRESSORS
MODBUS® SPECIFICATION
CoreSense™Diagnostics for Copeland™Stream Compressors Modbus® Specification..........................................1
1Introduction......................................................................................................................................................3
1.1 Abbreviations...........................................................................................................................................3
1.1 Intent........................................................................................................................................................3
1.2 Scope.......................................................................................................................................................3
1.3 References ..............................................................................................................................................3
2General description..........................................................................................................................................3
3Modbus type identification ...............................................................................................................................4
3.1 Modbus with 10 DIP-switch .....................................................................................................................4
3.2 Modbus with 12 DIP-switch –New version .............................................................................................5
3.3 DIP-Switch functions ...............................................................................................................................5
4Physical layer...................................................................................................................................................6
4.1 Topology..................................................................................................................................................6
4.1.1 Wire used..................................................................................................................................................6
4.1.2 Bus bias ....................................................................................................................................................6
4.1.3 Termination...............................................................................................................................................6
4.2 Data signalling rates................................................................................................................................6
4.2.1 Baud rate selection ...................................................................................................................................6
4.2.2 Parity selection..........................................................................................................................................6
4.3 Labelling ..................................................................................................................................................7
4.4 Connectors ..............................................................................................................................................7
4.5 Wiring and connections ...........................................................................................................................7
5Data Link layer.................................................................................................................................................8
5.1 Node address ..........................................................................................................................................8
5.2 DIP-Switch settings .................................................................................................................................9
5.3 RTU Transmission mode.......................................................................................................................10
5.4 Response message timeout..................................................................................................................10
6Application layer.............................................................................................................................................10
6.1 Available functions.................................................................................................................................10
6.2 Data types..............................................................................................................................................10
6.3 Functions supported..............................................................................................................................10
6.3.1 Coil input status ......................................................................................................................................10

C7.4.3/1107-1111/E
D7.8.6/1112-0815/E 2/18
Technical Information
6.3.2 Input register (command 0x04), version 1.13 .........................................................................................11
6.3.3 Holding register (command 0x03, 0x06, 0x10).......................................................................................16
6.3.4 Status table.............................................................................................................................................17
7Troubleshooting.............................................................................................................................................18

D7.8.6/1112-0815/E 3/18
1 Introduction
Stream with CoreSense™Diagnostics provides advanced motor protection, diagnostics as well as Modbus®
communication. Modbus communication enables reading compressor operating and alarm information from
CoreSense both locally and remotely. By monitoring and analyzing data from the Copeland™compressor, the
module can accurately detect the cause of electrical and system related issues. If an unsafe condition is detected,
the module trips the compressor. A flashing LED indicator communicates an alert code and guides the service
technician more quickly and accurately to the root cause of a problem.
The module also has a RS-485 isolated communication port, by which the modules can communicate with the
system controller or the network master. The details of the communication are provided in this document.
1.1 Abbreviations
RTU Remote Terminal Unit
DLT Discharge Line Temperature
OAC Overall Alarm Count (Total number of alarms since the module has been installed)
CRC Cyclic Redundancy Check
CMD Command
VFD Variable Frequency Drive
1.1 Intent
This document defines the CoreSense Diagnostics module standard usage of the Modbus protocol specification.
This will allow 3rd party controllers to easily communicate to the CoreSense Diagnostics device using a standard
Modbus interface.
1.2 Scope
This document only defines the Modbus options that are used in Stream with CoreSense Diagnostics. It is not
intended to replace the Modbus protocol specification. This specification defines the common usage of the Physical
layer, Data Link layer and some parts of the Application layer interface.
1.3 References
For the details of the Modbus specification, refer to
Modicon Modbus Protocol Reference Guide PI–MBUS–300 Rev. J
www.modbus.org
2 General description
Modbus uses a three-layer protocol:
Physical layer: the hardware interface;
Data Link layer: defines the reliable exchange of messages;
Application layer: defines message structures for the exchange of application specific information.
Modbus has some required features, some recommended features, and some optional features. This specification
starts with the physical layer and then works up to the application layer. The application layer defined in this
specification defines the standard Modbus memory map and data interchange.
Modbus is a protocol with a single master and multiple slave devices. The master device initiates all messages.

D7.8.6/1112-0815/E 4/18
3 Modbus type identification
Two types of Modbus are used with Stream compressors. The only possibility to identify which one is fitted in a
CoreSense module is to open the module lid, and to look at the circuit board and label.
Most of the features are the same; the main differences are explained in this chapter.
3.1 Modbus with 10 DIP-switch
Figure 1: View of the circuit board and label for 10 DIP-switch Modbus
The information given in the following chapters is based on the operation of the Modbus new version (12 DIP-
switch).
The input and holding register tables (Chapters 6.3.2 and 6.3.3) are valid for the 12 DIP-switch version but most of
the listed commands are also valid for the 10 DIP-switch model. The following input register data are specific to the
10 DIP-switch and therefore are not listed in Chapter 6.3.2.
Address
(Hex)
Contents
Qty
Min
Max
Unit
Data description
00E3
OAC of DLT fault
5
0
65535
1 time
One counter means one time
00E4
OAC of current sensor fault warning
6
0
65535
1 time
One counter means one time
00F9
OAC of motor overheat alarm
27
0
65535
1 time
One counter means one time
Table 1: Input register command specific to 10 DIP-switch module

D7.8.6/1112-0815/E 5/18
3.2 Modbus with 12 DIP-switch –New version
Figure 2: View of the circuit board and label for 10 DIP-switch Modbus
3.3 DIP-Switch functions
DIP-switch function
Factory
setting
DIP-switch position
10 DIP-
switch
12 DIP-
switch
Node address for communication
On
1
1
Node address for communication
Off
2 to 5
2 to 6
Communications Baud rate
Off: 19200 Baud
On: 9600 Baud
Off
7
7
Off: No parity
On: Even parity
Off
8
8
Off: Stand-alone mode
On: Network mode
Off
9
9
On: DLT enabled
Off: DLT disabled
On
10
10
Self-test function for oil functionality
TBD
---
11
On: VFD application
Off: Non VFD application
Off
6
12
Table 2: CoreSense Diagnostics DIP-switch setting
NOTE: The following chapters are based on the operation of the present Modbus (12 DIP-switch). For the
other Modbus type, please refer to Chapters 3.1 and 3.3 about the 10 DIP-switch model.

D7.8.6/1112-0815/E 6/18
4 Physical layer
This layer defines the hardware interface to the network.
4.1 Topology
Stream with CoreSense Diagnostics uses the “two-wire” configuration (two signal wires plus a ground). The
standard configuration will be to directly wire to the cable forming a daisy-chain.
4.1.1 Wire used
The recommended wire is shielded twisted pair (22 AWG or 0.33 mm2). The shield is also used as the circuit
ground.
Figure 3: Recommended communication wire (shielded twisted pair 22AWG or 0.33 mm2)
4.1.2 Bus bias
All master devices must provide a means to bias the network. The recommended pull-down on the
RS485 “+” output is a 511Ω resistor, but up to a 1KΩresistor is acceptable. The recommended pull-up resistor on
the RS485 “–“ output is a 511Ω resistor, but up to 1KΩis acceptable. These bias resistors can either be always
enabled or they can be enabled through jumpers. The bias is applied at one point in the network.
4.1.3 Termination
All master devices must provide a 150Ωtermination resistor. The last slave in the network must have a
150Ω resistor for termination. In this module, there is a jumper provision to enable this termination. The jumper is
located between positions 1-2 at “JP3” (see Figure 4). The last CoreSense module in the network shall be
populated with a header on this jumper. For the other CoreSense modules in the network, this jumper needs not be
populated.
4.2 Data signalling rates
4.2.1 Baud rate selection
The default communication port default settings are 19200, no parity, 8 data, 2 stop bits. The baud rate (19200 OR
9600) and parity (Even or No parity) is user-configurable through DIP-switch. The data length and stop bits are not
configurable.
4.2.2 Parity selection
Emerson Climate Technologies Modbus communication parity is user-configurable (Even or No parity).
DIP-switch Nr. 8 On Even.
DIP-switch Nr. 8 Off No parity (default setting).
Figure 4: Baud rate and parity selection through 12 DIP-switches
ON
1 2 3 4 5 6 7 8 9 10 11 12
Baud Rate selection
On: 9600
Off: 19200 (default)
Parity selection
On: Even
Off: no Parity (default)
Inverter mode
On: with VFD
Off: without VFD

D7.8.6/1112-0815/E 7/18
4.3 Labelling
The module has a “COMM PORT” with the connector pins, labelled from left to right as:
“ + GND – ”
+ = RS485 “A” circuit connection
GND = Common
–= RS485 “B” circuit connection
4.4 Connectors
A three-position screw cable connector is used for Modbus communication.
4.5 Wiring and connections
The Modbus wiring should be connected to module connector “+”, “GND”, “–“.
Figure 5: Modbus "Comm Port"
NOTE: RS485 is polarity sensitive. "+" wires must connect to other "+" terminals and "–" wires must
connect to other "–" terminals. The shield wire is connected to the centre terminal.

D7.8.6/1112-0815/E 8/18
5 Data Link layer
Modbus uses master/slave protocol where there is a single master device that initiates all messages. The Data Link
layer defines the reliable transfer of a message transferred from the master to one or more slave devices and the
reliable transfer of the response message (when the command message is sent to a single device). The
CoreSense Diagnostics module is a slave in the network and the rack controller is the master.
5.1 Node address
The DIP-switch setting combination gives the node address. Combination positions 1 to 6 will be used to define a
node address from 1 to 62. Positions 7 to 12 will be used for Baud rate, parity, network mode, discharge
temperature protection, self-test mode, and VFD enable (Variable Frequency Drive).
Figure 6: Switches 1 to 6 are used to set the module Modbus address
See Table 1 and Tables 3 to 9 for more information about setting the DIP-switches.
Figure 7: Default jumper settings on the CoreSense module
ON
1 2 3 4 5 6 7 8 9 10 11 12

D7.8.6/1112-0815/E 9/18
5.2 DIP-Switch settings
Node
address
1
2
3
4
5
6
Node
address
1
2
3
4
5
6
#1
On
Off
Off
Off
Off
Off
#32
Off
Off
Off
Off
Off
On
#2
Off
On
Off
Off
Off
Off
#33
On
Off
Off
Off
Off
On
#3
On
On
Off
Off
Off
Off
#34
Off
On
Off
Off
Off
On
#4
Off
Off
On
Off
Off
Off
#35
On
On
Off
Off
Off
On
#5
On
Off
On
Off
Off
Off
#36
Off
Off
On
Off
Off
On
#6
Off
On
On
Off
Off
Off
#37
On
Off
On
Off
Off
On
#7
On
On
On
Off
Off
Off
#38
Off
On
On
Off
Off
On
#8
Off
Off
Off
On
Off
Off
#39
On
On
On
Off
Off
On
#9
On
Off
Off
On
Off
Off
#40
Off
Off
Off
On
Off
On
#10
Off
On
Off
On
Off
Off
#41
On
Off
Off
On
Off
On
#11
On
On
Off
On
Off
Off
#42
Off
On
Off
On
Off
On
#12
Off
Off
On
On
Off
Off
#43
On
On
Off
On
Off
On
#13
On
Off
On
On
Off
Off
#44
Off
Off
On
On
Off
On
#14
Off
On
On
On
Off
Off
#45
On
Off
On
On
Off
On
#15
On
On
On
On
Off
Off
#46
Off
On
On
On
Off
On
#16
Off
Off
Off
Off
On
Off
#47
On
On
On
On
Off
On
#17
On
Off
Off
Off
On
Off
#48
Off
Off
Off
Off
On
On
#18
On
Off
Off
On
Off
#49
On
Off
Off
Off
On
On
#19
On
On
Off
Off
On
Off
#50
Off
On
Off
Off
On
On
#20
Off
Off
On
Off
On
Off
#51
On
On
Off
Off
On
On
#21
On
Off
On
Off
On
Off
#52
Off
Off
On
Off
On
On
#22
Off
On
On
Off
On
Off
#53
On
Off
On
Off
On
On
#23
On
On
On
Off
On
Off
#54
Off
On
On
Off
On
On
#24
Off
Off
Off
On
On
Off
#55
On
On
On
Off
On
On
#25
On
Off
Off
On
On
Off
#56
Off
Off
Off
On
On
On
#26
Off
On
Off
On
On
Off
#57
On
Off
Off
On
On
On
#27
On
On
Off
On
On
Off
#58
Off
On
Off
On
On
On
#28
Off
Off
On
On
On
Off
#59
On
On
Off
On
On
On
#29
On
Off
On
On
On
Off
#60
Off
Off
On
On
On
On
#30
Off
On
On
On
On
Off
#61
On
Off
On
On
On
On
#31
Off
Off
Off
Off
On
Off
#62
Off
On
On
On
On
On
#32
Off
Off
Off
Off
Off
On
#63
On
On
On
On
On
On
Table 3: Node address settings
Baud rate
7
Parity
8
19200
Off
None
Off
9600
On
Even
On
Table 3: Baud rate DIP-switch settings Table 4: Parity DIP-switch settings

D7.8.6/1112-0815/E 10/18
Mode
9
Discharge temperature
lockout
10
Stand-alone
Off
Disable
Off
Network
On
Enable
On
Table 5: Network mode DIP-switch settings Table 6: High discharge temp. protection DIP-switch
settings
Oil functionality
Self-test mode
11
VFD DIP-switch
12
Disable
Off
Non VFD
Off
Enable
On
VFD
On
Table 7: Oil functionality test DIP Switch settings Table 8: VFD DIP-switch settings
5.3 RTU Transmission mode
The Modbus communication in the CoreSense Diagnostics module uses RTU mode. The default character framing
is an 11-bit character as follows:
1 start bit
8 data bits
2 stop bits (or if “Even parity” is selected 1 stop bit and 1 parity bit)
A standard 2-byte CRC 16 is used for frame verification.
5.4 Response message timeout
As per the Modbus specification, each device can define its own maximum timeout for the response to be sent to a
request. The maximum timeout for the module is one second.
6 Application layer
The Application layer defines the type and format of the messages that will be sent.
6.1 Available functions
Standard Modbus function codes supported by CoreSense Diagnostics module
Switch no.
Function
code
Function name
Registers
Access
1
0x04
Read input registers
Input registers
Read only
2
0x03
Read holding registers
Holding registers
Read / Write
3
0x06
Write single register
Holding registers
Read / Write
4
0x10
Write multiple register
Holding registers
Read / Write
Table 9: Standard Modbus function codes
6.2 Data types
Modbus requires that all multiple byte data be sent in Big Endian format (most significant byte to least significant
byte).
6.3 Functions supported
6.3.1 Coil input status
The module does not support function call 0x2.

D7.8.6/1112-0815/E 11/18
6.3.2 Input register (command 0x04), version 1.13
Address (Hex)
Contents
Qty
Min
Max
Unit
Scale
Data Description
Start
End
0000
0009
Division Name
28
“x”
000A
000F
0010
0019
001A
001B
001C
001F
Product Name
6
'x'
0020
0021
0022
0029
Product code
8
'x'
002A
0030
Control Module Version Number
7
'x'
0031
0037
Sensor Module Version Number
7
'x'
0077
0079
Seven Days of compressor run time
7
0
240
6 min.
7 days, compressor run time
007A
007D
007E
007F
Seven Days of compressor start times
7
0
1 time
7 days, compressor start times
0080
0084
0085
0086
Total Compressor Run Time
2
0
4294967
295
h
One count means 1 hours
0087
0088
Total Compressor Starts
2
0
4294967
295
start
One count means 1 start
0089
008A
Total Insufficient Oil Pressure Run
Time
2
0
4294967
295
h
One count means 1 hour
0097
009A
Bit Alarm Code Correspondence
4
Each bit represents a digital alarm. (64
bits).
The bits are numbered from Bit 0 to Bit 63
Refer to Table 11 in Section 5.3.4.
009B
009F
Ten Most Recent Alarms
10
Alarm Id of ten most recent alarms
00A0
00A4
00A5
Eight Days Alarm History of EEPROM
Failure Warning
0
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 - Present
00AA
Eight Days Alarm History of High
Discharge Temp Fault
5
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00AB
Eight Days Alarm History of Current
Sensor Fault Warning
6
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00AC
Eight Days Alarm History of Loss of
Communication From Rack Controller
To Control Module Warning
7
0
1
BIT0 - Today:
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00AD
Eight Days Alarm History of Loss of
Communication From Sensor Module
to Control Module Warning
8
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00AE
Eight Days Alarm History of Insufficient
Oil Pressure Warning
9
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present

D7.8.6/1112-0815/E 12/18
00B2
Eight Days Alarm History of Sensor
Module Failure Warning
13
0
1
BIT0 - Today
BIT1 - Today-1
……………
BIT7 - Today-7:
0 - Not present 1 Present
00B4
Eight Days Alarm History of High
Discharge Temperature Alarm
15
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00B6
Eight Days Alarm History of Locked
Rotor Alert
17
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00B7
Eight Days Alarm History of Missing
Phase Alert
18
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00B9
Eight Days Alarm History of
Compressor Low Voltage Alert
20
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00BC
Eight Days Alarm History of Voltage
Imbalance Alarm
23
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00C0
Eight Days Alarm History of Motor
Overheat Alarm
27
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
) 0 - Not present 1 Present
00C1
Eight Days Alarm History of Protection
Trip Alarm
28
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00C6
Eight Days Alarm History of High
Discharge Temperature Lockout
33
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00C7
Eight Days Alarm History of Locked
Rotor Lockout
35
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00C9
Eight Days Alarm History of Missing
Phase Lockout
36
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 Present
00CD
Eight Days Alarm History of Insufficient
Oil Pressure Lockout
40
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 to 42 - Present
00D1
Eight Days Alarm History of Control
Module Failure Lockout
44
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 to 46 - Present

D7.8.6/1112-0815/E 13/18
00D3
Eight Days Alarm History of
Compressor Low Voltage Lockout
46
0
1
BIT0 - Today
BIT1 - Today-1
……………………………..
BIT7 - Today-7
0 - Not present 1 to 48 - Present
00DE
OAC of EEPROM Failure Warning
0
0
65535
1 time
One counter means one times
00E5
OAC of Loss of Communication From
Rack Controller to Control Module
Warning
7
0
65535
1 time
One counter means one times
00E6
OAC of Loss of Communication From
Sensor Module to Control Module
Warning
8
0
65535
1 time
One counter means one times
00E7
OAC of Insufficient Oil Pressure
Warning
9
0
65535
1 time
One counter means one times
00EB
OAC of Sensor Module Failure
Warning
13
0
65535
1 time
One counter means one times
00ED
OAC of High Discharge Temperature
Alarm
15
0
65535
1 time
One counter means one times
00EF
OAC of Locked Rotor Alert
17
0
65535
1 time
One counter means one times
00F0
OAC of Missing Phase Alert
18
0
65535
1 time
One counter means one times
00F2
OAC of Compressor Low Voltage Alert
20
0
65535
1 time
One counter means one times
00F5
OAC of Voltage Imbalance Alarm
23
0
65535
1 time
One counter means one times
00FA
OAC of Protection Trip Alarm
28
0
65535
1 time
One counter means one times
00FF
OAC of High Discharge Temperature
Lockout
33
0
65535
1 time
One counter means one times
0101
OAC of Locked Rotor Lockout
35
0
65535
1 time
One counter means one times
0102
OAC of Missing Phase Lockout
36
0
65535
1 time
One counter means one times
0106
OAC of Insufficient Oil Pressure
Lockout
40
0
65535
1 time
One counter means one times
010A
OAC of Control Module Failure
44
0
65535
1 time
One counter means one times
010C
OAC of Compressor Low Voltage
Lockout
46
0
65535
1 time
One counter means one times
0117
Current Status
1
0
1
0 = No Alarm 1= Alarm
Alert (/Warning) (1XX)
101: Discharge Temperature Probe
Failure
106: Discharge Temp Probe open
107: Discharge Temp Probe short
108: Current Sensor Fault
109: Loss of Communication From Rack
Controller To Control Module
110: Loss of Communication From Sensor
Module to Control Module
111: Insufficient Oil Pressure
115: Sensor Module Failure
117: Control Module Failure

D7.8.6/1112-0815/E 14/18
0117
Current Status
1
0
1
Trip with Auto Reset (2XX)
200: High Discharge Line Temperature
202: Locked Rotor
203: Missing Phase
205: Compressor Low Voltage
208: Voltage Imbalance
212: Motor Overheat
Lockout with Manual Reset (3XX)
300:High Discharge Temperature
302:Locked Rotor
303:Missing Phase
304:Phase Loss
307:Insufficient Oil Pressure
311:Control Module Failure
312:Compressor Low Voltage
011C
DIP-Switch_1
1
0
1
Communication Board DIP Switch:
BIT15 - DS15
BIT14 - DS14
……………
BIT1 - DS1
BIT0 - DS0 1 = ON 0 = OFF
0123
Input Status
1
0
1
BIT0 - Demand Status
1 = Present
0
1
BIT1 - Compressor Running
BIT2 - Injection Present
BIT3 - Top Cap Thermistor installed
BIT4 - 250 DTC valve thermistor installed
BIT5 - TRUE if solenoid is open
1=TRUE 0=FALSE
0
1
BIT6 - Operating Voltage
1 = 230V, 0 = 110V
1
2
BIT7 - Line Frequency
1 = 50Hz 2 = 60Hz
0126
Output Status1
1
0
1
BIT3 - CrankCase Heater Status
0 = Open 1 = Closed
0127
Output Status2
0
1
BIT14 –Previous Reset Status
0 = Hard reset 1 = Soft reset
0
1
BIT13 -Oil Pressure Status
BIT12 -HPCO Status
BIT11 -LPCO /Suction pressure Status
1 = Normal 0 = Trip
0
1
BIT10 –PTC3 Status
BIT9 -PTC2 Status
BIT8 -PTC1 Status
0 = Normal 1= Trip
0
1
BIT7 - Spare Input -1 Status
BIT6 - Spare Input -2 Status
BIT4 -StandAlone_Unloader_2 Command
Status
BIT3 -StandAlone_Unloader_1 Command
Status
BIT2 –Standalone Demand Status
0 = Not active 1 = Active
0
1
BIT5- Wake up pushbutton status
0 = Not pressed 1 = Pressed
0
1
BIT1 –Unloader2 Triac Short Circuit
Protection Input Status
BIT0 - Unloader1 Triac Short Circuit
Protection Input Status
0 = Normal
1 = short circuit condition has happened
0129
Discharge Temperature Value
1
-70.0
585.35
°F
(Discharge temp sensor value/100)-70
012B
Compressor R Phase Voltage
1
0
655,35
V
1/100
(R Phase Compressor Voltage/100)
012C
Compressor Y Phase Voltage
1
0
655,35
V
1/100
(Y Phase Compressor Voltage/100)
012D
Compressor B Phase Voltage
1
0
655,35
V
1/100
(B Phase Compressor Voltage/100)

D7.8.6/1112-0815/E 15/18
0130
Compressor Current Y Phase
1
0
655,35
A
1/100
Current = Value / 100
0133
LRA Peak Current
1
0
655,35
A
1/00
LRA Peak Current = Value / 100
0136
0137
Power Consumption
2
0
4294967
,295
kW
1/1000
Power Consumption = Value / 1000
0143
Module Stack Overflow Reset
Counters
1
0
65535
0144
Module Stack Underflow Reset
Counters
1
0
65535
0145
Module MCLK Reset Counters
1
0
65535
0146
Module BOR Reset Counters
1
0
65535
0147
Module WDT Reset Counters
1
0
65535
0148
Module RI Reset Counters
1
0
65535
0149
Module Unknown Reset Counters
1
0
65535
015A
T1 Stack Overflow Reset Counters
1
0
65535
015B
T1 Stack Underflow Reset Counters
1
0
65535
015C
T1 MCLK Reset Counters
1
0
65535
015D
T1 BOR Reset Counters
1
0
65535
015E
T1 WDT Reset Counters
1
0
65535
015F
T1 RI Reset Counters
1
0
65535
0160
T1 Unknown Reset Counters
1
0
65535
0161
0162
T1 valid response counters
2
0
4294967
295
0163
0164
T1 CRC error counters
2
0
4294967
295
0165
0166
T1 frame error counters
2
0
4294967
295
0167
0168
T1 total frame counters
2
0
4294967
295
0173
0174
Total No. of Short Cycles
2
0
4294967
295
Cycle
One count means 1 cycle
0179
017A
Total CCH Run Hours
2
0
4294967
295
h
One counter means 1 hours
017B
017C
Total Alarm Run Hours
2
0
4294967
295
h
One count means 1 hours
Table 10: Module information

D7.8.6/1112-0815/E 16/18
6.3.3 Holding register (command 0x03, 0x06, 0x10)
Address
(Hex)
Contents
Qty
Min
Max
Unit
Default
Scale
Data Description
Start
Start
0000
0010
Customer Name
17
'x'
000A
000F
0011
0014
Customer ID
4
'x'
0015
0024
Customer Location
16
'x'
001A
001F
0025
0036
Compressor Model Number
18
'x'
002A
002F
0037
0042
Compressor Serial Number
12
'x'
003A
003F
0051
0059
Module Part Number
12
'x'
005A
005C
005D
005F
Module Serial Number
12
'x'
0060
0069
0085
Alert Trigger Parameters
Configuration
20
-70
585.35
°F
309
1/100
DLT temp trip set point value, Unit : 0.01°F
Set point = (Word - 7000)/100(°F)
0086
-70
585.35
°F
266
1/100
DLT temp trip reset point value,
Unit : 0.01°F
Reset point =( Word -7000)/100(°F)
008C
0
65535
V
230
Compressor Nominal Voltage
008D
0
65535
Hz
60
Compressor Nominal Frequency
008E
2
8
%
5
Voltage Imbalance Setting
0x02 - 2% 0x03 - 3%
0x04 - 4% 0x05 - 5%
0x06 - 6% 0x07 - 7%
0x08 - 8% Others - NA
00B4
Lockout Status Configuration1
1
0
1
BIT0 - High Discharge Temperature Lockout
Status
BIT3 - Miss Phase Lockout Status
BIT5 - Rack Controller Lockout Status
BIT6 - Part Winding Delay Lockout Status
1 - Enable 0 - Disable
00D2
Sensor Module Required
0x01 –No Sensor Module is equipped
0x02 –Sensor Module is equipped
Table 11: Holding register

D7.8.6/1112-0815/E 17/18
6.3.4 Status table
The current status of the CoreSense module can be read by using either register 0x117 (analog signal) or
0x97:0x9A (digital alarm). Please use only one of the 2 registers to read the current status of the module.
Status Table is used to decode the “module status” in Modbus address register 0x97:0x9A shown in Table 11 in
Chapter 6.3.2. The code sent by the module for status is a number that can be indexed into the table to decode the
state of the module.
Register 0097:009A is showing less than 64 bits in the table below, because only the alarm IDs that belong to
Stream CoreSense are shown. This register supports not only Stream CoreSense but also other Emerson
CoreSense products (for example CoreSense in Scroll).
Bit
number
Register 1
Register 2
Register 3
Register 4
BIT0
Normal running and fault
temperature probe
Voltage imbalance trip
Control module failure
lockout
BIT1
Communication lost between
current sensor and sensor
module
Missing phase trip
Normal Off
BIT2
Oil pressure warning
Locked rotor trip
Normal running
BIT3
No communication to sensor
module
Motor overhead trip
Anti-short cycle time
delay
BIT4
Hardware configuration
mismatch
Low oil pressure lockout
Compressor low voltage
trip lockout
BIT5
No communication to E2
High discharge pressure
lockout
BIT6
High discharge temp trip
Locked rotor lockout
BIT7
Compressor low voltage trip
Missing phase lockout
BIT8
System trip
BIT9
Short cycle warning
BIT10
Open circuit warning
BIT11
Reserve phase lockout
BIT12
Welded contactor warning
BIT13
Module low voltage trip
BIT14
DLT fault warning
BIT15
Current sensor fault warning
Table 12: BIT alarm status table
Alarm
ID
Module Status
Alarm
ID
Module Status
7
Normal running & fault discharge
temperature probe
24
Voltage imbalance trip
28
Missing phase trip
12
Connection lost between current sensor and
sensor module
31
Locked rotor trip
32
Motor overheat trip
13
Insufficient oil pressure warning
37
Insufficient oil pressure lockout
16
No communication to sensor module
39
High discharge temperature lockout
17
Hardware configuration mismatch (module
programmed to have a sensor module and it
is not detected or module programmed not to
have a sensor module and it is detected.)
41
Locked rotor lockout
42
Missing phase lockout
43
CoreSense diagnostics control module failure
lockout
44
Normal Off
18
No communication to rack controller
45
Normal running
19
High discharge temperature trip
46
Anti short cycle delay - time remaining
21
Compressor low voltage trip
54
Low voltage lockout
Table 13: Status table

D7.8.6/1112-0815/E 18/18
7 Troubleshooting
If the communication module does not respond, here is a list of general troubleshooting tips:
1. Check the wiring connection. Ensure the wiring is correctly connected and the connector is not loose.
2. Check the power to the CoreSense module. Check the power supply line and ensure the power is on and
the green LED is on.
3. Check the module network address. The address should match the address that the master has requested.
The valid addresses are 1 to 31. “0” is not a valid address.
4. Check your master data format setting. Ensure the master node data format setting to: RTU mode, 1 start
bit, 8 data bits, no parity bit, and 2 stop bits.
5. Check the master node baud rate setting. Set your master node baud rate as 19200 and then try to
communicate with the module. If the module does not respond, then set to 9600 baud rate and try it again.
Any third party PC debugging tool can also be used by sending a query for getting the firmware version number.
The response indicates the version number as 1.01R00 (this number is only an example and may change
according to models).
Address
CMD
Start
Length
CRC
The request and response is hex value.
Request for version number
08
04
00
00
00
07
50
95
Address
CMD
Bytes
2
0
3
D
1
1
CRC
Response
08
04
0E
00
32
00
2E
00
30
00
33
00
44
00
31
00
31
87
14
The information in this document is subject to change without notification.
