1592023130 XM670K_XM679K GB r4.2 26.06.2017.docx XM670K - XM679K 1/10

CONTROLLERS FOR MULTIPLEXED CABINETS

XM670K- XM679K

-MANUAL FOR THE SW REL. 4.2-

1. GENERAL WARNING

1.1 PLEASE READ BEFORE USING THIS MANUAL

This manual is part of the product and should be kept near the instrument for easy and quick

reference.

The instrument shall not be used for purposes different from those described hereunder. It cannot

be used as a safety device.

Check the application limits before proceeding.

Dixell Srl reserves the right to change the composition of its products, even without notice, ensuring

the same and unchanged functionality.

1.2 SAFETY PRECAUTIONS

Check the supply voltage is correct before connecting the instrument.

Do not expose to water or moisture: use the controller only within the operating limits avoiding

sudden temperature changes with high atmospheric humidity to prevent formation of condensation

Warning: disconnect all electrical connections before any kind of maintenance.

Fit the probe where it is not accessible by the End User. The instrument must not be opened.

In case of failure or faulty operation send the instrument back to the distributor or to “Dixell S.r.l.”

(see address) with a detailed description of the fault.

Consider the maximum current which can be applied to each relay (see Technical Data).

Ensure that the wires for probes, loads and the power supply are separated and far enough from

each other, without crossing or intertwining.

In case of applications in industrial environments, the use of mains filters (our mod. FT1) in parallel

with inductive loads could be useful.

2. BEFORE PROCEEDING

2.1 CHECK THE SW REL. OF THE XM679K

1. Look at the SW rel. of XM679K printed on the label of the controller.

2. If the SW release is 4.2 proceed with this manual otherwise contact Dixell to get the right manual.

3. GENERAL DESCRIPTION

The XM670K/XM679K are high level microprocessor based controllers for multiplexed cabinets suitable

for applications on medium or low temperature. It can be inserted in a LAN of up to 8 different sections

which can operate, depending on the programming, as stand alone controllers or following the commands

coming from the other sections. The XM670K/XM679K are provided with 6 relay outputs to control the

solenoid valve, defrost - which can be either electrical or hot gas - the evaporator fans, the lights, an

auxiliary output and an alarm output and with one output to drive pulsed electronic expansion valves

(only XM679K). The devices are also provided with four probe inputs, one for temperature control, one

to control the defrost end temperature of the evaporator, the third for the display and the fourth can be

used for application with virtual probe or for inlet/outlet air temperature measurement. The model XM679K

is provided by other two probes that have to be used for superheat measurement and regulation. Finally,

the XM670K/XM679K are equipped with the three digital inputs (free contact) fully configurable by

parameters.

The instruments are equipped with the HOTKEY connector that permits to be programmed in a simple

way. Direct serial output RS485 ModBUS-RTU compatible permits a simple XWEB interfacing. RTC are

available as options. The HOTKEY connector can be used to connect X-REP display (Depending on the

model).

4. INSTALLATION AND MOUNTING

This device can operate without any user interface, but normal application is with Dixell CX660 keyboard.

Figure 1a

Figure 1b

The CX660 keyboard shall be

mounted on vertical panel, in a 29x71

mm hole, and fixed using the special

bracket supplied as shown in fig. 1a/1b.

The temperature range allowed for

correct operation is 0 to 60°C. Avoid

places subject to strong vibrations,

corrosive gases, excessive dirt or

humidity.

The same recommendations apply to

probes. Let air circulate by the cooling

holes.

Figure 1c

5. WIRING DIAGRAM AND CONNECTIONS

5.1 IMPORTANT NOTE

XM device is provided with disconnectable terminal block to connect cables with a cross section up to 1.6 mm2 for

all the low voltage connection: the RS485, the LAN, the probes, the digital inputs and the keyboard. Other inputs,

power supply and relay connections are provided with screw terminal block or fast-on connection (5.0 mm). Heat-

resistant cables have to be used.

Before connecting cables make sure the power supply complies with the instrument’s requirements. Separate the

probe cables from the power supply cables, from the outputs and the power connections. Do not exceed the

maximum current allowed on each relay, in case of heavier loads use a suitable external relay. N.B. Maximum

current allowed for all the loads is 16A. The probes shall be mounted with the bulb upwards to prevent damages

due to casual liquid infiltration. It is recommended to place the thermostat probe away from air streams to correctly

measure the average room temperature. Place the defrost termination probe among the evaporator fins in the

coldest place, where most ice is formed, far from heaters or from the warmest place during defrost, to prevent

premature defrost termination.

5.2 XM670K –ALL POWER SUPPLY

5.3 XM679K –230VAC VALVES

5.4 XM679K –24VAC VALVES

NOTE: the jumper indicated as JMP is inside the case of the controller. This jumper

has to be closed only in case of driving 24Vac valve.

5.5 KEYBOARD DISPLAY CX660

The XM670/679K board can operate also without keyboard.

Polarity:

Terminal [34] [-]

Terminal [35] [+]

Use twisted shielded cable

AWG 18 or less in case of long

distance.

Max distance: 30m

5.6 SYNCHRONIZED DEFROST –MAXIMUM 8 SECTIONS

Follow next steps to create a LAN connection, which is a necessary condition to perform synchronized defrost

(also called master-slave functioning):

1) connect a shielded cable between terminals [38] [-] and [39] [+] for a maximum of 8 sections;

2) the Adr parameter is the number to identify each electronic board. Address duplication is not permitted,

in this case the synchronized defrost and the communication with monitoring system is not guaranteed (the

Adr is also the ModBUS address). For example, a correct configuration is the following:

If the LAN is well connected, the green LED will be ON. If the green LED blinks then the connection is

wrongly configured.

The max distance allowed is 30m

1592023130 XM670K_XM679K GB r4.2 26.06.2017.docx XM670K - XM679K 2/10

5.7 SENSORS FOR SUPERHEAT CONTROL –ONLY FOR XM679K

Temperature probe: Pb6 terminals [19] - [20] without any polarity.

Select the kind of sensor with P6C parameter.

Pressure transducer: Pb5 terminals:

[21] = input of the signal; [22] = Power Supply for 4to20mA transducer;

[20] = GND; [23] = +5Vdc power supply for ratiometric pressure

transducer.

Select the configuration of the transducer with parameter P5C.

5.8 HOW TO USE ONLY ONE PRESSURE TRANSDUCER ON MULTIPLEXED APPLICATIONS

A working LAN connection is required (green LED lit on all XM670-XM679K boards of the same LAN). Connect

and configure a pressure transducer only on one XM670-XM679K of the network. Afterwards, the value of

pressure read by the unique transducer connected will be available to each device connected to the same LAN.

By pressing UP ARROW button, the user will be able to enter a fast selection menu and to read the value of the

following parameters:

dPP = measured pressure (only on master device);

dP5 = value of temperature obtained from pressuretemperature conversion;

rPP = pressure value read from remote location (only for slave devices).

Examples of error messages:

dPP = Err the local transducer read a wrong value, the pressure is out of the bounds of the pressure

transducer or the P5C parameter is wrong. Check all these options and eventually change the transducer;

rPF the remote pressure transducer is on error situation. Check the status of the onboard GREEN LED: if

this LED is OFF the LAN is not working, otherwise check the remote transducer.

LAST CHECKS ABOUT SUPERHEAT

On the fast access menu:

dPP is the value read by the pressure gauge;

dP6 is the value read by the temperature probe, temperature of the gas on the outlet section of the evaporator;

SH is the value of the superheat. The nA or Err messages mean that the superheat has no sense in that

moment and its value is not available.

5.9 HOW TO CONNECT MONITORING SYSTEM

1) Terminals [36] [-] and [37] [+].

2) Use shielded twisted cable. For example Belden®

8762 o 8772 or cat 5 cables.

3) Maximum distance 1Km.

4) Don’t connect the shield to the earth or to GND

terminals of the device, avoid accidental contacts by

using insulating tape.

Only one device for each LAN has to be connected to the RS485 connection.

The Adr parameter is the number to identify each electronic board. Address duplication is not permitted, in

this case the synchronized defrost and the communication with monitoring system is not guaranteed (the Adr is

also the ModBUS address).

5.10 DIGITAL INPUTS

1) The terminals from [30] to [33] are all free of voltage;

2) Use shielded cable for distance higher than one

meter;

For each input, has to be configured: the polarity of

activation, the function of the input and the delay of

signaling.

The parameters to perform this configuration are i1P, i1F, i1d respectively for polarity, functioning and delay. The

i1P can be: cL = active when closed; oP = active when opened. The i1F parameter can be: EAL = external alarm,

bAL = serious lock alarm, PAL = pressure switch alarm, dor = door switch, dEF = external defrost, AUS = auxiliary

activation command, LiG = light activation, OnF = board On/OFF, FHU = don’t use this configuration, ES =

day/night, HdY = don’t use this configuration. Then there is i1d parameter for delay of activation. For the others

digital inputs there are a set of the same parameters: i2P, i2F, i2d, i3P, i3F, i3d.

5.11 ANALOG OUTPUT

Selectable between 4 to 20mA and

0 to 10Vdc.

Use CABCJ15 to perform the connections

It’s located near the terminal [39] on a 2-pin connector. It’s possible to use the output to control anti-sweat heaters

through a chopped phase controller XRPW500 (500watt) or family XV...D or XV...K.

6. QUICK REFERENCE GUIDE: HOW TO RUN THE SELF ADAPTIVE

REGULATION IN 4 STEPS.

1. After wiring the XM679K, set the proper gas via Fty parameter. Pre-set gas is R404A.

2. Configure the probes:

- Regulation and evaporator probe are preset as NTC. If another kind of sensors is used, set it via

P1c and P2c parameters.

- Superheat evaporator outlet probe is pre-set as Pt1000, if another kind of sensor is used, set it

via P6c parameter.

- The PP11 (-0.5÷11bar) is pre-set as pressure probe. It operates at relative pressure (Pru = rE).

If you’re using a ratiometric transducer, set P5c = 0-5, then use parameters PA4 and P20 to set

the range

NOTE: check the pressure gauge reading with the value of dPP, press the UP arrow once to enter

the Fast Access Menu. If ok, proceed; otherwise solve the situation before proceeding acting on

par. Pru, PA4 and P20.

3. Set the parameters for self adaptive regulation of superheat

NOTE: the parameters Pb (regulation band) and Int (integral time) are automatically calculated by the

controller

- Set CrE = no, this disable the continuos regulation of the temperature. Default is CrE = no.

- Set SSH, superheating setpoint: a value between 4 and 8 is acceptable. Default is SSH=8

- Set AMS = y to start the self adaptive regulation. Default is AMS = y

- Set ATU = y to start the search of the lowest stable superheat. Default is ATU = y. This function

reduces automatically the setpoint in order to optimize the use of the evaporator, keeping, at the

same time, the superheating regulation stable. The minimum allowed SH set point is LSH+2°C.

- Set LSH, low superheating limit: a value between 2-4 is acceptable. Default is LSH = 3

- Set SUb, pressure filter: Default is SUb = 10. The value can be increased up to 20 in case of too

fast response of the pressure variations.

4. Set the parameters for the temperature regulation

- Set the temperature setpoint. Default is -5°C

- Set the differential HY: Default is 2°C.

- If the capacity of the valve is higher than requested, it can be reduced by the par. MNF (Default

is 100). A proper setting of MnF will reduce the time that the algorithm takes to reach the stability.

MNF value doesn’t affect the band witdh

7. USER INTERFACE

7.1 ICONS

Cooling output

↓

With icon ON the output is

active, while with blinking icon

there is a delay.

MEASUREMENT UNIT

°C, Bar and (time) are

ON depending on the

selection.

Light →

←Fan

Defrost →

AUX

←Auxiliary relay

Energy saving →

←Multimaster Enabled

Generic alarm →

←Clock / time

DURING PROGRAMMING: blink the measurement units of temperature and pressure

7.2 KEYBOARD COMMANDS

Single commands:

LIGHT relay

Press light button.

AUX relay

Press down arrow.

Manual defrost

Press and hold for 3 sec the defrost button

ON/OFF

Press for 3 sec the ON/OFF button (if the function is enabled).

Energy Saving

Press for 3 sec the ON/OFF button (if the function is enabled).

Double commands:

Press and hold for about 3 sec to lock (Pon) or unlock (PoF) the keyboard.

Pressed together to exit from programming mode or from menu; on submenus rtC and EEV

this combination allow to come back to previous level.

Pressed together for 3 sec allow to access to first level of programming mode.

7.3 HOW TO MODIFY THE SET POINT FOR AIR TEMPERATURE REGULATION

The thermostat set point is the value that will be used to regulate the air temperature. The regulation output is

controlled by the electronic valve or by the relay.

BEGIN

Press SET button for 3 sec, the measurement units will blink together.

1592023130 XM670K_XM679K GB r4.2 26.06.2017.docx XM670K - XM679K 3/10

Value

modification

With the arrows it’s possible to change the value within the LS and US

parameters value.

EXIT

By pressing SET it is possible to confirm the value that will blink for

about 2 sec.

In any case, it is possible to wait for about 10 sec to exit. In order to show the air temperature set is sufficient to

press and release the SET button, the value is displayed for about 60 sec.KEY COMBINATIONS

8. HOW TO PROGRAM THE PARAMETERS (PR1 AND PR2)

The device provide 2 programming levels: Pr1 with direct access and Pr2 protected with a password (intended

for experts).

ACCESS to

Pr1

Press and hold for about 3 sec to have access to the first

programming level (Pr1).

Select item

Select the parameter or submenu using the arrows.

Show value

Press SET button.

Modify

Use the arrows to modify the value.

Confirm and

store

Press SET key: the value will blink for 3 sec, and then the display

will show the next parameter.

EXIT

Instantaneous exit from the programming mode, otherwise wait for

about 10 sec (without press any button).

8.1 HOW TO HAVE ACCESS TO “PR2”

To enter Pr2 programming menu:

1. Access to a Pr1 menu by pressing both SET+DOWN keys for 3 sec, the first parameter label will be

showed;

2. Press DOWN key till the Pr2 label will be showed, then press SET;

3. The blinking PAS label will be showed, wait some seconds;

4. Will be showed “0 - -” with blinking 0: insert the password [321] using the keys UP and DOWN and

confirming with SET key.

GENERAL STRUCTURE: The first two item rtC and EEV are related to submenus with others parameters.

SET+UP keys on rtC or EEV submenus allow coming back to parameter list,

SET+UP keys on parameter list allow immediate exit.

8.2 HOW TO MOVE PARAMETER FROM PR1 TO PR2 AND VICE VERSA

Enter on Pr2; select the parameter; press together [SET + DOWN]; a left side LED ON gives to the parameter the

presence on Pr1 level, a left side LED OFF means that the parameter is not present on Pr1 (only Pr2).

9. FAST ACCESS MENU

This menu contains the list of probes and some values that are automatically evacuate by the board such as the

superheat and the percentage of valve opening. The values: nP or noP stands for probe not present or value not

evacuate, Err value out of range, probe damaged not connected or incorrectly configured.

Entering fast

access menu

By press and release the UP arrow. The duration of the menu in

case of inactivity is about 3 min.

The values that will be showed depend on the configuration of the

board.

Use

arrows to

select an

entry,

then press

to see the

value or to

go on with

other value.

HM Access to clock menu or reset of the RTC alarm;

An Value of analog output;

SH Value of superheat. nA = not Available;

oPP Percentage of valve opening.

dP1 (Pb1) Value read by probe 1.

dP2 (Pb2) Value read by probe 2.

dP3 (Pb3) Value read by probe 3.

dp4 (Pb4) Value read by probe 4.

dP5 (Pb5) Temperature read by probe 5 or value obtained from pressure transducer.

dP6 (Pb6) Value read by probe 6.

dPP Pressure value read by (Pb5) transducer.

rPP Virtual pressure probe, only on slave.

L°t Minimum room temperature;

H°t Maximum room temperature;

dPr Virtual probe for room temperature regulation [rPA and rPb];

dPd Virtual probe for defrost management [dPA];

dPF Virtual probe for fan management [FPA];

rSE Real thermoregulation set point: the value includes the sum of SET, HES and/or the

dynamic set point if the functions are enabled.

Exit

Pressed together or wait the timeout of about 60 sec

10. MENU FOR MULTIMASTER FUNCTION: SEC

The function “section” SEC is enabled when icon is lit. It allows entering in the remote programming mode,

from a keyboard not physically connected to the board, through the LAN functionality.

Action

Button or display

Notes

Enter menu

Press UP arrow for about 3 sec, the icon will be ON.

Waiting for action

SEC

The menu to change the section will be entered. SEC label

will be displayed.

Enter section list

Press SET to confirm. The following list will be available to

select the proper network function.

Select proper

function

LOC

ALL

SE1

SEn

SE8

To gain access only to the local device.

To gain access to all the devices connected to the LAN.

To gain access to the device with 1st Adr (*)

…

To gain access to the device with 8th Adr (*)

Confirm

Select and confirm an entry by pressing SET button.

Exit menu

Press SET and UP together or wait about 10 seconds.

(*) The devices on the LAN are indexed by using the Adr parameter (in ascending order).

EXAMPLES:

1. To modify the same parameter values in all the devices connected to the LAN: enter multimaster menu.

Select and confirm ALL. Exit from multimaster menu. Enter the programming menu and change the

required parameter values.

The new values will be changed on all devices connected to the LAN.

2. To modify a parameter value in the device with [Adr = 35]: find the relevant indexed section (the one

linked to [Adr = 35]). Enter multimaster menu. Select and confirm this section from the multimaster menu.

Exit from multimaster menu. Enter the programming menu and change the required parameter value.

3. If the alarm nod is present: enter the multimaster menu. Select and confirm the LOC section. Exit from

multimaster menu.

AT THE END OF THE PROGRAMMING PROCEDURE, SELECT THE SECTION “LOC”. IN THIS WAY

THE ICON WILL BE SWITCHED OFF!!

10.1 SYNCHRONIZED DEFROST

The synchronized defrost allow to manage multiple defrost from different boards connected through the LAN

connection. In this way, the boards can perform simultaneous defrosts with the possibility to end them in a

synchronized way.

The Adr parameter cannot be duplicated because in this case the defrost cannot be correctly managed.

BEGIN

Press for 3 seconds, the rtC or other will be showed. The

measurement unit blinks.

Find Adr

Press more than once the DOWN arrow to find the Adr parameter,

the press SET.

Modify Adr

Set the value of Adr parameter, then press SET to confirm the

parameter.

EXIT

Press the two keys together to exit from menu or wait for about 10

seconds.

The LSn and LAn parameter are only to show the actual settings (read only). Se the following example of

configuration:

DAILY DEFROST FROM RTC: : [cPb = y] & [EdF = rtC]

IdF Parameter: for safety reason force the value of Idf at +1 respect to the interval between two Ld parameters.

The IdF timer is reinitialized after defrost and at every power-on.

DEFROST START: at the time selected by the parameters Ld1 to Ld6 or Sd1 to Sd6.

DEFROST END: if the probes reach the dtE temperature or for maximum MdF time.

SAFETY and RtC or RtF ALARM: with clock alarm the device will use the parameter IdF, dtE and MdF.

WARNING: don’t set [EdF = rtC] and [CPb = n].

MULTIMASTER DEFROST: all the probes with clock

Table for example

Par.

Unit A (RTC)

Unit B (RTC)

Unit C (RTC)

Adr

N + 1

N + 2

EdF

rtC (clock)

IdF

9 hours safety

MdF

45 min safety

dtE

12°C safety

Ld1

06:00 1°

Ld2

14:00 2°

Ld3

22:00 3°

1592023130 XM670K_XM679K GB r4.2 26.06.2017.docx XM670K - XM679K 4/10

11. COMMISSIONING

11.1 CLOCK SETTING AND RTC ALARM RESET

If the clock is present: [EdF = rtC] enable the defrost from rtc [Ld1 to Ld6].

BEGIN

UP arrow (press once) to access the fast access menu

Display

HM identify the clock RTC submenu; press

Display

HUr = hour press to confirm/modify

Min = minutes press to confirm/modify

…… don’t use others parameters if present.

EXIT

Press for about 10 sec. The operation resets the RTC alarm.

Note: the rtC clock menu is present also on the second level of parameters. Warning: if the board shows the

rtF alarm, the device has to be changed.

11.2 ELECTRONIC VALVE SETTINGS –ONLY FOR XM679K

Some parameters have to be checked:

[1] Superheat temperature probe: Ntc, Ptc, Pt1000 with parameter P6C. The sensor has to be fixed at the end

of the evaporator.

[2] Pressure transducer: [4 to 20mA] or ratiometric P5C = 420 or 5Vr with parameter P5C.

[3] Range of measurement: check the parameter of conversion PA4 and P20 that are related to the transducer.

TRANSDUCER: [-0.5/7Bar] or [0.5/8Bar abs] the correct setup is relative pressure with PA4 = -0.5 and P20 = 7.0.

The [0.5/12Bar abs] the correct setup is relative pressure with PA4 = -0.5 and P20 = 11.00.

Example of virtual pressure with unique [4 to 20mA] or [0 to 5V] transducer:

Param.

XM6x9K_1

without transducer

XM6x9K_2 + with

transducer

XM6x9K_3+ without

transducer

Adr

n + 1

n + 2

LPP

LPP = n

LPP = Y

LPP = n

P5C

LAN or not connect the

probe

P5C= 420 or 0-5V

LAN or not connect the

probe

PA4

Not used

-0.5 bar

Not used

P20

Not used

7.0 bar

Not used

[4] From EEV submenu: select the correct kind of gas with FTY parameter.

[5] Use the following parameters to setup the right valve driving, according to the valve datasheet from the

manufacturer.

12. KIND OF REGULATION FOR SUPERHEAT: SELF ADAPTIVE OR

MANUAL OPERATING MODE

12.1 GENERAL CONSIDERATIONS: SELF ADAPTIVE OR MANUAL SH CONTROL

The controller is able to regulate the superheat in manual or self adaptive mode, according to the value of the

parameter AMS, autotuing enabling.

With AMS = n: the normal SH regulation is performed

With AMS = y: the self adaptive SH regulation is performed

12.2 MANUAL OPERATING MODE - AMS = NO

The temperature and SH regulation can be performed in 2 ways according to the value of the parameter CrE:

on/off or continuous. See below in details.Standard temperature regulation

12.2.1 ON/OFF TEMPERATURE REGULATION [CrE = n]

1. Temperature regulation is ON/OFF and it depends on the SET point and HY parameter (dfferential) Valve

is closed when the temperature reaches the set point and open when the temperature is higher than set

point + differential.

2. The superheat is regulated to be closer to its set point.

3. With more pauses normally also the humidity is bigger.

4. Regulation pauses can be realized using Sti and Std parameters (during these pauses the valve is closed).

12.2.2 COUNTINUOUS REGULATION OF THE TEMPERATURE [CrE = Y] (with

superheat regulation):

1. The HY parameter becomes temperature band for PI control. A default good value is 6°C.

2. The regulation of injection is continuous and the cooling output is always on. The icon is always ON

excluding the defrost phase.

3. The superheat is regulated following the SSH parameter.

4. Regulation pauses can be realized using Sti and Std parameters (during these pauses the valve is closed).

5. Increasing the Int integral time it is possible to decrease the speed of reaction of the regulator on the HY

band.

12.3 SELF ADAPTIVE OPERATING MODE –AMS = YES

Auto-adaptive means to find and maintain the condition of the lowest super heating according to the load and

environmental conditions present in a given time on the evaporator.

The parameter AMS enables the self adaptive mode for the superheat regulation.

In this functioning the values of Pb and inC parameter are automatically set by the controller according to the kind

of applications and the response of the system.

With the AMS = YES, CrE must be set at NO.

The self adaptive algorithm does not affect, the functions related to the forced opening of the valve in special

situation such as:

Forced opening of the valve at start of regulation, parameter SFd (percentage) and SFd (time).

Forced opening of the valve after defrost, parameter oPd (percentage) and Pdd (time).

12.4 MINIMUM STABLE SUPERHEAT SEARCH - AMS = YES, ATU = YES

With the parameter ATU, the minimum stable superheat search function is enabled.

With ATU = yES controllers start searching the mimimum stable value for the SH, the minimum admitted value in

any case is LSH + 2°C (4°F).

Please take it in consideration, before setting LSH value.

12.5 VALVE CAPACITY REDUCING –MNF PARAMETER

Thanks to the parameter MnF it’s possible to reduce the capacity of the valve, to fine tune the valve to the

evaporator.

The regulation band is not affected from the modification of the MnF parameter.

See below the behaviour of the capcity of the valve, when the MnF parameter is adjusted.

NOTE: during the soft start phase (oPE, SFd), MnF parameter is not taken in consideration and the

capacity of the valve is set by the parameters oPE and oPd, respectively.

12.6 PRESSURE FILTERING –SUB PARAMETER

For a good SH regulation, it’s important to use a filtered value of the pressure.

This can be done by the parameter Sub.

Suggested values:

From 1-5 evaporators for each racks: Sub = 20

From 6-30 evaporators for each racks: Sub = 15

More than 30 evaporators for each racks: Sub =10

13. DISPLAY MESSAGES

Display

Causes

Notes

KEYBOARD

nod

No display: the keyboard is trying to work with

another board that is not working or not

present

Press for 3 sec UP arrow, enter the SEC

menu and select LOC entry.

Pon

Keyboard is unlocked

PoF

Keyboard is locked

rSt

Alarm reset

Alarm output deactivated

noP, nP

Not present (configuration)

Not available (evaluation)

noL

The keyboard is not able to communicate with

the XM670-XM679K

Verify the connection. Call the Service

ALARM FROM PROBE INPUT

PPF

CPF

Sensor brake down, value out of range or

sensor incorrectly configured P1C, P2C to

P6C.

PPF can be showed by slaves of pressure

that don’t receive the value of pressure.

CPF is showed when the remote probe 4 is

not working.

P1: the cooling output works with Con

and COF,

With defrost probe on error the defrost is

performed only at interval.

For P5, P6 and PPF: the percentage of

the valve opening is fixed at PEO value.

TEMPERATURE ALARM

Temperature alarm from parameter ALU on

probe rAL.

Outputs unchanged.

Temperature alarm from parameter ALL on

probe rAL.

Outputs unchanged.

"HAd

Defrost high temperature

Outputs unchanged.

"LAd”

Defrost low temperature

Outputs unchanged.

"FAd”

Fan low temperature

Outputs unchanged.

"HAF”

Fan high temperature

Outputs unchanged.

DIGITAL INPUT ALARM

Door open alarm from input i1F, i2F or i3F =

after delay d1d, d2d or d3d.

Cooling relay and fan follow the odc

parameter. Cooling restart as specified

on rrd parameter.

Generic alarm from digital input i1F, i2F, i3F =

EAL.

Severe alarm of regulation lock from digital

input i1F, i2F, i3F = bAL.

Regulation output OFF.

PAL

Pressure switch lock i1F, i2F o i3F = PAL.

All the outputs are OFF.

ELECTRONIC VALVE ALARM

LOP

Minimum operating pressure threshold from

LOP parameter.

The valve output increases its opening of

dML quantity every second.

MOP

Maximum operating pressure threshold from

MOP parameter.

The valve output decreases its opening

of dML quantity every second.

LSH

Low superheating from LSH parameter and

SHd delay.

The valve will be closed; the alarm will

be showed after SHd delay.

HSH

High superheating from HSH parameter and

SHd delay.

Only display.

CLOCK ALARM

rtC

Clock settings lost.

Defrost will be performed with IdF till

restoring the settings of RTC.

rtF

Clock damaged.

Defrost will be performed with IdF.

OTHERS

EEPROM serious problem.

Output OFF.

Err

Error with upload/download parameters.

Repeat the operation.

End

Parameters have been correctly transferred.

13.1 ALLARM RECOVERY

Probe alarms P1, P2, P3 and P4 start some seconds after the fault in the related probe; they automatically stop

some seconds after the probe restarts normal operation. Check connections before replacing the probe.

Temperature alarms HA, LA, HA2 and LA2 automatically stop as soon as the temperature returns to normal

values.

Alarms EA and CA (with i1F = bAL)recover as soon as the digital input is disabled. Alarm CA (with i1F = PAL)

recovers only by switching off and on the instrument.

1592023130 XM670K_XM679K GB r4.2 26.06.2017.docx XM670K - XM679K 5/10

14. ELECTRONIC EXPANSION VALVE MENU (ONLY FOR XM679K)

+SET

1. Enter the Programming mode by pressing the SET and DOWN key for few

seconds (measurement unit starts blinking).

2. Press arrows until the instrument shows EEU label;

3. Press SET. You are now in EEV function menu;

15. CONTROLLING LOADS

15.1 THE SOLENOID VALVE

The regulation is performed according to the temperature measured by the thermostat probe that can be

physical probe or virtual probe obtained by a weighted average between two probes (see parameters

table description) with a positive differential from the set point. If the temperature increases and reaches

set point plus differential the solenoid valve is opened and then it is closed when the temperature reaches

the set point value again.

In case of fault in the thermostat probe the opening and closing time of solenoid valve is configured by

“Con” and “CoF”parameters.

15.2 STANDARD REGULATION AND CONTINUOUS REGULATION

The regulation can be performed in two ways: the goal of the first way (standard regulation) is reaching

the best superheat via a classic temperature regulation obtained using hysteresis. The second way,

permits to use the valve to realise an high performance temperature regulation with a good factor of

superheat precision. This second possibility, it can be used only in centralized plants and it is

available only with electronic expansion valve by selecting CrE=Y parameter.

In any case, the regulation is performed via PI regulator that gives the opening percentage to the valve

via PWM modulation explained as follow. Opening percentage is obtained from average of Opening Time

respect to CyP time period like following diagram:

With opening percentage we mean percentage of cycle period where valve is open. For example, if

CyP=6s (standard value) by saying: “The valve is opened at 50%”; this means that the valve is opened

for 3s during cycle period.

First kind of regulation:

In this case, the Hy parameter is the differential for standard ON/OFF regulation. In this case the int

parameter is neglected. The regulation follow this diagram:

Second kind of regulation –Continuous regulation (only XM679K):

In this case, the Hy parameter is the proportional band of PI in charge of room temperature regulation and

we advise to used at least Hy=5.0°C/10°F. The int parameter is the integral time of the same PI regulator.

Increasing int parameter the PI regulator become slow in reaction and of course is true vice versa. To

disable the integral part of regulation you should set int=0.

15.3 DEFROST

Defrost starting

In any case, the device check the temperature read by configured defrost probe before starting

defrost procedure, after that:

-(If RTC is present)Two defrost modes are available through the “tdF” parameter: defrost with electrical

heater and hot gas defrost. The defrost interval is controlled by parameter “EdF”: (EdF = rtc) defrost is

made in real time depending on the hours set in the parameters Ld1..Ld6 in workdays and in Sd1…Sd6

on holidays; (EdF = in) the defrost is made every “IdF” time;

-defrost cycle starting can be operated locally (manual activation by means of the keyboard or digital

input or end of interval time) or the command can come from the Master defrost unit of the LAN. In this

case the controller will operate the defrost cycle following the parameters it has programmed but, at

the end of the drip time, will wait that all the other controllers of the LAN finish their defrost cycle before

to re-start the normal regulation of the temperature according to dEM parameter;

-Every time any of the controller of the LAN begin a defrost cycle it issue the command into the network

making all the other controllers start their own cycle. This allows a perfect synchronisation of the defrost

in the whole multiplexed cabinet according to LMd parameter;

-Selecting dPA and dPb probes and by changing the dtP and ddP parameters the defrost can be started

when the difference between dPA and dPb probes is lower than dtP for all ddP time. This is useful to

start defrost when a low thermal exchange is detected. If ddP=0 this function is disabled;

Defrost ending

-When defrost is started via rtc, the maximum duration of defrost is obtained from Md parameter and

the defrost end temperature is obtained from dtE parameter (and dtS if two defrost probes are

selected).

-If dPA and dPb are present and d2P=y the instrument stops the defrost procedure when dPA is higher

than dtE temperature and dPb is higher than dtS temperature;

At the end of defrost the drip time is controlled through the “Fdt” parameter.

15.4 FANS

CONTROL WITH RELAY

The fan control mode is selected by means of the “FnC” parameter:

C-n = running with the solenoid valve, OFF during the defrost;

C-y = running with th1e solenoid valve, ON during the defrost;

O-n = continuous mode, OFF during the defrost;

O-y = continuous mode, ON during the defrost;

An additional parameter “FSt” provides the setting of temperature, detected by the evaporator probe,

above which the fans are always OFF. This can be used to make sure circulation of air only if his

temperature is lower than set in “FSt”.

CONTROL WITH ANALOG OUTPUT (if present)

The modulating output (trA=rEG) works in

proportional way (excluding the first AMt

seconds where the fans speed is the

maximum). The regulation set point is relative

to regulation set point and is indicated by ASr,

the proportional band is always located above

SET+ASr value and its value is PbA. The fan

are at minimum speed (AMi) when the

temperature read by fan probe is SET+ASr

and the fan is at maximum speed (AMA) when

the temperature is SET+ASr+PbA.

15.5 ANTI SWEAT HEATERS

The anti-sweat heater regulation can be performed with on board relay (if OA6 = AC) or with the analog output (if

present by setting trA = AC). However the regulation can be performed in two ways:

Without real dew-point information: in this case the default value for dew-point is used (SdP

parameter).

Receiving dew-point from XWEB5000 system: the SdP parameter is overwritten when valid value

for dew-point is received from XWEB. In case of XWEB link is lost, SdP is the value that will be

used for safety.

The best performance can be obtained using probe 4. In this case, the regulation follows the chart:

Probe 4 should be placed on the showcase glass. For each cabinet can be used only one probe 4 (P4) sending

its value to the others section that are connected to the LAN.

HOW TO WORK WITH PROBE 4 THROUGH THE LAN:

Param.

XM6x9K_1

Without probe 4

XM6x9K_2 + with probe 4

XM6x9K_3+ Without

probe 4

Adr

n + 1

n + 2

LCP

LCP = n

LCP = Y

LCP = n

P4C

LAN or not connect the

probe

P4C = NTC, PtC or PtM

LAN or not connect the

probe

trA

trA = AC if the device has the analog output

OA6

OA6 = AC if the device will use the AUX relay for regulation

HOW TO WORK WITHOUT PROBE 4:

Param.

XM6x9K

Without probe 4

P4C

AMt

% of ON

In this case, the regulation is performed by switching on

and off the auxiliary relay on a 60 minutes time base. The

ON time will be the AMt value, so that the relay will be ON

for AMt minutes and OFF for [60-AMt] minutes.

In case of P4 error or if P4 is absent the output is at AMA value for the AMt time then the output is at 0 value for

the time [255 –AMt] time performing a simple PWM modulation.

15.6 AUXILIARY OUTPUT

The auxiliary output is switch ON and OFF by means of the corresponding digital input or by pressing and releasing

the down arrow key.

16. PARAMETER LIST

REGULATION

Set Temperature set point (LS÷US)

rtC Access to CLOCK submenu (if present);

EEU Access to EEV submenu (only XM679K);

Hy Differential: (0,1÷25,5°C; 1÷45°F): Intervention differential for set point, always positive.

Solenoid valve Cut IN is Set Point Plus Differential (Hy). Solenoid valve Cut OUT is when the

temperature reaches the set point.

Int Integral time for room temperature regulation (Only XM679K): (0 ÷ 255 s) integral time for

room temperature PI regulator. 0= no integral action;

1592023130 XM670K_XM679K GB r4.2 26.06.2017.docx XM670K - XM679K 6/10

CrE Continuous regulation activation (Only XM679K): (n÷Y) n= standard regulation; Y=

continuous regulation. Use it only in centralized plants;

LS Minimum set point limit: (-55.0°C



SET; -67°F÷SET) Sets the minimum acceptable value for

the set point.

US Maximum set point limit: (SET



150°C; SET÷302°F) Set the maximum acceptable value for set

point.

OdS Outputs activation delay at start up: (0÷255 min) This function is enabled at the initial start up

of the instrument and inhibits any output activation for the period of time set in the parameter.

(AUX and Light can work)

AC Anti-short cycle delay: (0÷60 min) interval between the solenoid valve stop and the following

restart.

CCt Compressor ON time during continuous cycle: (0.0÷24.0h; resolution 10min) Allows to set

the length of the continuous cycle: compressor stays on without interruption for the CCt time. Can

be used, for instance, when the room is filled with new products.

CCS Set point for continuous cycle: (-55÷150°C / -67÷302°F) it sets the set point used during the

continuous cycle.

Con solenoid valve ON time with faulty probe: (0÷255 min) time during which the solenoid valve is

active in case of faulty thermostat probe. With COn=0 solenoid valve is always OFF.

CoF solenoid valve OFF time with faulty probe: (0÷255 min) time during which the solenoid valve

is off in case of faulty thermostat probe. With COF=0 solenoid valve is always active.

DISPLAY

CF Temperature measurement unit: °C=Celsius; °F=Fahrenheit. !!! WARNING !!! When the

measurement unit is changed the parameters with temperature values have to be checked.

PrU Pressure mode: (rEL or AbS) it defines the mode to use the pressure. !!! WARNING !!! the setting

of PrU is used for all the pressure parameters. If PrU=rEL all pressure parameters are in relative

pressure unit, if PrU=AbS all pressure parameters are in absolute pressure unit. (Only XM679K)

PMU Pressure measurement unit: (bAr –PSI - MPA) it selects the pressure measurement units.

MPA= the value of pressure measured by kPA*10. (Only XM679K)

PMd Way of displaying pressure : (tEM - PrE) it permits showing the value measured by pressure

probe with tEM= temperature or by PrE= pressure; (Only XM679K)

rES Resolution (for °C): (in = 1°C; dE = 0.1 °C) allows decimal point display;

Lod Instrument display: (nP; P1; P2, P3, P4, P5, P6, tEr, dEF) it selects which probe is displayed by

the instrument. P1, P2, P3, P4, P5, P6,tEr= virtual probe for thermostat, dEF= virtual probe for

defrost.

red Remote display: (nP; P1; P2, P3, P4, P5, P6, tEr, dEF) it selects which probe is displayed by

the X-REP. P1, P2, P3, P4, P5, P6,tEr= virtual probe for thermostat, dEF= virtual probe for

defrost.

dLy Display delay: (0 ÷24.0 m; resolution 10s) when the temperature increases, the display is

updated of 1 °C/1°F after this time.

rPA Regulation probe A: (nP; P1; P2, P3, P4, P5) first probe used to regulate room temperature. If

rPA=nP the regulation is performed with real value of rPb.

rPb Regulation probe B: (nP; P1; P2, P3, P4, P5) second probe used to regulate room temperature.

If rPb=nP the regulation is performed with real value of rPA

rPE Regulation virtual probe percentage: (0 ÷ 100%) it defines the percentage of the rPA respect

to rPb. The value used to regulate room temperature is obtained by:

value_for_room = (rPA*rPE + rPb*(100-rPE))/100

ELECTRONIC EXPANSION VALVE SUBMENU (Only XM679K)

FtY Kind of gas:

LABEL

REFRIGERANT

OPERATING RANGE

R22

r22

-50-60°C/-58÷120°F

134

r134A

-50-60°C/-58÷120°F

290

r290 –Propane

-50-60°C/-58÷120°F

404

r404A

-70-60°C/-94÷120°F

47A

r407A

-50-60°C/-58÷120°F

47C

r407C

-50-60°C/-58÷120°F

47F

r407F

-50-60°C/-58÷120°F

410

r410A

-50-60°C/-58÷120°F

448

r448A

-45-60°C/-69÷120°F

449

r449A

-45-60°C/-69÷120°F

450

r450A

-45-60°C/-69÷120°F

507

r507

-70-60°C/-94÷120°F

513

r513A

-45-60°C/-69÷120°F

CO2

r744 - Co2

-50-60°C/-58÷120°F

Atu Minimum STABLE superheat search (No; yES) This parameter enables the search of the minimum

stable superheat. The lowest admitted value is LSH+2°C

AMS Self self adaptive SH regulation enabling (No; yES) This parameter enables the self adaptive

regulation of the superheat. CrE = no must to be set, when this function is enabled.

SSH Superheat set point: [0.1°C ÷ 25.5°C] [1°F ÷ 45°F] it’s the value used to regulate superheat

CyP Cycle Period: (1 ÷ 15s) it permits to set cycle time;

Pb Proportional band: (0.1 ÷ 60.0 / 1÷108°F) PI proportional band;

rS Band Offset: (-12.0 ÷ 12.0°C / -21÷21°F) PI band offset;

inC Integration time: (0 ÷ 255s) PI integration time;

PEO Probe Error opening percentage: (0÷100%) if a temporary probe error occurs, valve opening

percentage is PEo until PEd time is elapsed;

PEd Probe Error delay before stopping regulation: (0÷239 sec. –On=unlimited) if probe error

duration is bigger than PEd then valve totally closes. Pf message is showed. If PEd=On valve

opening is PEo until probe error finishes;

OPE Start opening Percentage: (0÷100%) Opening valve percentage when start function is active.

This phase duration is SFd time;

SFd Start Function duration: (0.0 ÷ 42.0 min: resolution 10s) It sets start function duration and post-

defrost duration. During this phase the alarms are neglected;

OPd Opening Percentage after defrost phase: (0÷100%) Opening valve percentage when after

defrost function is active. This phase duration is Pdd time;

Pdd Post Defrost Function duration: (0.0 ÷ 42.0 min: resolution 10s) It sets start function duration

and post-defrost duration. During this phase the alarms are neglected;

MnF Maximum opening percentage at normal Functioning: (0÷100%) during regulation it sets the

maximum valve opening percentage;

dCL Delay before stopping valve regulation: (0 ÷ 255s) When the cooling request goes off, the

electronic valve regulation can go on for the dCL time in order to prevent uncontrolled superheat

variation;

Fot Forced opening percentage: (0÷100% - nu) it permits to force the valve opening to the specified

value. This value overwrite the value calculated by PID algorithm. !!!! WARNING !!!! to obtain

the correct superheat regulation you have to set Fot=nu;

PA4 Probe value At 4mA or At 0V: (-1.0 ÷ P20 bar / -14 ÷ PSI / -10 ÷ P20 kPA*10) pressure value

measured by probe at 4mA or at 0V (related to PrM parameter) Referred to Pb5

P20 Probe value 20mA or At 5V: (PA4 ÷ 50.0 bar / 725 psi / 500 kPA*10) pressure value measured

by probe at 20mA or at 5V (related to PrM parameter) Referred to Pb5

LPL Lower Pressure Limit for superheat regulation: (PA4 ÷ P20 bar / psi / kPA*10) when suction

pressure comes down to LPL the regulation is performed with a LPL fixed value for pressure,

when pressure comes back to LPL the normal pressure value is used. (related to PrM parameter)

MOP Maximum Operating Pressure threshold: (PA4 ÷ P20 bar / psi / kPA*10)if suction pressure

exceeds maximum operating pressure value, instrument signals situation with MOP alarm.

(related to PrM parameter)

LOP Lowest Operating Pressure threshold: (PA4 ÷ P20 bar / psi / kPA*10) if the suction pressure

comes down to this value a low pressure alarm is signalled with LOP alarm. (related to PrM

parameter)

dML delta MOP-LOP: (0 ÷ 100%) when a MOP alarm occurs valve will close of the dML percentage

every cycle period until MOP alarm is active. When LOP occurs valve will open of the dML

percentage every cycle period until LOP alarm is active.

MSH Maximum Superheat alarm: (LSH ÷ 80.0°C / LSH ÷ 144°F) when superheat exceeds this value

an high superheat alarm is signalled after interval SHd

LSH Lowest Superheat alarm: (0.0 ÷ MSH °C / 0÷MSH °F) when superheat goes down to this value

a low superheat alarm is signalled after interval SHd

SHy Superheat alarm Hysteresis: (0.1÷25.5°C/1÷45°F) hysteresis for superheat alarm deactivation

SHd Superheat alarm activation delay: (0.0 ÷ 42.0 min: resolution 10s) when a superheat alarm

occurs, the time SHd have to pass before signalling alarm;

FrC Fast-recovery Constant: (0÷100 s) permits to increase integral time when SH is below the set-

point. If FrC=0 fast recovery function is disabled.

Sub Pressure filter (0÷100) It uses the last average values of the pressure to calculate the superheat.

SLb Reaction time (0÷255s): time to update the valve open percentage.

EI. With SLb = 24: the valve open percentage is updated every 24s.

DEFROST

dPA defrost Probe A: (nP; P1; P2, P3, P4, P5) first probe used for defrost. If rPA=nP the regulation

is performed with real value of dPb.

dPb defrost Probe B: (nP; P1; P2, P3, P4, P5) second probe used for defrost. If rPB=nP the

regulation is performed with real value of dPA.

dPE defrost virtual probe percentage: (0÷100%) it defines the percentage of the dPA respect to

dPb. The value used to regulate room temperature is obtained by:

value_for_defrost= (dPA*dPE + dPb*(100-dPE))/100

tdF Defrost type: (EL –in) EL = electrical heater; in = hot gas;

EdF Defrost mode: (rtc –in) (only if RTC is present) rtc= defrost activation via RTC; in= defrost

activation with idf.

Srt Heater set point during defrost: (-55.0 ÷ 150.0°C; -67 ÷ 302°F) if tdF=EL during the defrost

the defrost relay perform an ON/OFF regulation with Srt as set point.

Hyr Differential for heater: (0.1°C ÷ 25.5°C , 1°F ÷ 45°F) the differential for heater;

tod Time out for heater: 0 ÷ 255 (min.) if the defrost probe temperature is bigger than Srt for all tod

time the defrost ends altough the defrost probe temperature is lower than dtE or dtS. It permits to

reduce defrost duration;

dtP Minimum temperature difference to start defrost: [0.1°C ÷ 50.0°C] [1°F ÷ 90°F] if the

difference between the two defrost probes stays lower than dtP for all ddP time the defrost is

activated;

ddP Delay before starting defrost (related to dtP): (0 ÷ 60 min) delay related to dtP.

d2P Defrost with two probes: (n –Y) n= only the dPA probe is used to defrost management; Y=

defrost is managed with dPA probe and dPb probe. Defrost can performed only if both probe

value are lower than dtE for dPA probe and dtS for dPb probe;

dtE Defrost termination temperature (Probe A): (-55,0÷50,0°C; -67÷122°F) (Enabled only when

the evaporator probe is present) sets the temperature measured by the evaporator probe dPA

which causes the end of defrost;

dtS Defrost termination temperature (Probe B): (-55,0÷50,0°C; -67÷122°F) (Enabled only when

the evaporator probe is present) sets the temperature measured by the evaporator probe dPb

which causes the end of defrost;

IdF Interval between defrosts: (0÷120h) Determines the time interval between the beginning of two

defrost cycles;

MdF Maximum duration of defrost: (0÷255 min) When dPA and dPb aren’t present, it sets the

defrost duration, otherwise it sets the maximum duration for defrost;

dSd Start defrost delay: (0 ÷ 255 min) This is useful when different defrost start times are necessary

to avoid overloading the plant.

dFd Display during defrost: rt = real temperature; it = temperature reading at the defrost start; Set

= set point; dEF = “dEF” label;

dAd Defrost display time out: (0



255 min) Sets the maximum time between the end of defrost and

the restarting of the real room temperature display.

Fdt Drain down time: (0÷255 min.) time interval between reaching defrost termination temperature

and the restoring of the control’s normal operation. This time allows the evaporator to eliminate

water drops that might have formed due to defrost.

dPo First defrost after start-up: y = Immediately; n= after the IdF time

dAF Defrost delay after continuous cycle: (0÷23.5h) time interval between the end of the fast

freezing cycle and the following defrost related to it.

FAN

FPA Fan probe A: (nP; P1; P2, P3, P4, P5) first probe used for fan. If FPA=nP the regulation is

performed with real value of FPB;

FPB Fan probe B: (nP; P1; P2, P3, P4, P5) second probe used for defrost. If FPB=nP the regulation

is performed with real value of FPB;

FPE Fan virtual probe percentage: (0÷100%) it defines the percentage of the FPA respect to FPb.

The value used to regulate room temperature is obtained by:

value_for_defrost= (FPA*FPE + FPb*(100-FPE))/100

FnC Fan operating mode: C-n = running with the solenoid valve, OFF during the defrost; C-y =

running with the solenoid valve, ON during the defrost; O-n = continuous mode, OFF during the

defrost; O-y = continuous mode, ON during the defrost;

Fnd Fan delay after defrost: (0÷255 min) The time interval between the defrost end and evaporator

fans start.

FCt Temperature differential avoiding short cycles of fans (0.0°C ÷ 50.0°C; 0°F ÷ 90°F) If the

difference of temperature between the evaporator and the room probes is more than the value of

the Fct parameter, the fans are switched on;

FSt Fan stop temperature: (-50÷110°C; -58÷230°F) setting of temperature, detected by evaporator

probe, above which the fan is always OFF.

FHy Differential to restart fan: (0.1°C ÷ 25.5°C) (1°F ÷ 45°F) when stopped, fan restarts when fan

probe reaches FSt-FHy temperature;

Fod Fan activation time after defrost: (0 ÷ 255 min.) it forces fan activation for indicated time;

Fon Fan ON time: (0÷15 min) with Fnc = C_n or C_y, (fan activated in parallel with compressor). it

sets the evaporator fan ON cycling time when the compressor is off. With Fon =0 and FoF ≠ 0

the fan are always off, with Fon=0 and FoF =0 the fan are always off.

FoF Fan OFF time: (0÷15 min) with Fnc = C_n or C_y, (fan activated in parallel with compressor). it

sets the evaporator fan off cycling time when the compressor is off. With Fon =0 and FoF ≠ 0 the

fan are always off, with Fon=0 and FoF =0 the fan are always off.

MODULATING OUTPUT (AnOUT) if present

trA Kind of regulation with PWM output: (UAL –rEG –AC) it selects the functioning for the PWM

output. UAL= the output is at FSA value; rEG= the output is regulated with fan algorithm

described in fan section; AC= anti-sweat heaters control (require the XWEB5000 system);

1592023130 XM670K_XM679K GB r4.2 26.06.2017.docx XM670K - XM679K 7/10

SOA Fixed value for analog output: (0 ÷ 100%) value for the output if trA=UAL;

SdP Default value for Dew point: (-55,0÷50,0°C; -67÷122°F) default value of dew point used when

there is no supervising system (XWEB5000). Used only when trA=AC;

ASr Dew-point offset (trA=AC) / Differential for modulating fan regulation (trA=rEG): (-25.5°C ÷

25.5°C) (-45°F ÷ 45°F);

PbA Differential for anti-sweat heaters: (0.1°C ÷ 25.5°C) (1°F ÷ 45°F)

AMi Minimum value for analog output: (0÷AMA)

AMA Maximum value for analog output: (Ami ÷ 100)

AMt Anti-sweat heaters cycle period (trA=AC)/ Time with fan at maximum speed (trA=rEG):

(0÷255 s) when the fan starts, during this time the fan is at maximum speed;

ALARMS

rAL Probe for temperature alarm: (nP - P1 - P2 - P3 - P4 - P5 –tEr) it selects the probe used to

signal alarm temperature

ALC Temperature alarm configuration: rE = High and Low alarms related to Set Point; Ab = High

and low alarms related to the absolute temperature.

ALU High temperature alarm setting: (ALC= rE, 0



50°C or 90°F / ALC= Ab, ALL



150°C or 302°F)

when this temperature is reached and after the ALd delay time the HA alarm is enabled.

ALL Low temperature alarm setting: (ALC = rE , 0



50 °C or 90°F / ALC = Ab , - 55°C or - 67°F



ALU) when this temperature is reached and after the ALd delay time, the LA alarm is enabled.

AHy Differential for temperature alarm: (0.1°C ÷ 25.5°C / 1°F ÷ 45°F) Intervention differential for

recovery of temperature alarm;

ALd Temperature alarm delay: (0÷255 min) time interval between the detection of an alarm condition

and the corresponding alarm signalling.

dLU High temperature alarm (defrost probe): (ALC= rE, 0



50°C or 90°F / ALC= Ab, ALL



150°C

or 302°F) when this temperature is reached and after the ddA delay time the HAdalarm is

enabled.

dLL Low temperature alarm (defrost probe): (ALC = rE , 0



50 °C or 90°F / ALC = Ab , - 55°C or

- 67°F



ALU) when this temperature is reached and after the ALd delay time, the LAd alarm is

enabled.

dAH Differential for temperature alarm (defrost probe): (0.1°C ÷ 25.5°C / 1°F ÷ 45°F) Intervention

differential for recovery of temperature alarm;

ddA Temperature alarm delay (defrost probe): (0÷255 min) time interval between the detection of

an alarm condition and the corresponding alarm signalling.

FLU High temperature alarm (defrost probe): (ALC= rE, 0



50°C or 90°F / ALC= Ab, ALL



150°C

or 302°F) when this temperature is reached and after the FAd delay time the HAFalarm is

enabled.

FLL Low temperature alarm (defrost probe): (ALC = rE , 0



50 °C or 90°F / ALC = Ab , - 55°C or

- 67°F



ALU) when this temperature is reached and after the FAddelay time, the LAFalarm is

enabled.

FAH Differential for temperature alarm (defrost probe): (0.1°C ÷ 25.5°C / 1°F ÷ 45°F) Intervention

differential for recovery of temperature alarm;

FAd Temperature alarm delay (defrost probe): (0÷255 min) time interval between the detection of

an alarm condition and the corresponding alarm signalling.

dAO Delay of temperature alarm at start-up: (0min÷23h 50min) time interval between the detection

of the temperature alarm condition after the instrument power on and the alarm signalling.

EdA Alarm delay at the end of defrost: (0



255 min) Time interval between the detection of the

temperature alarm condition at the end of defrost and the alarm signalling.

dot Temperature alarm exclusion after door open:

Sti Stop regulation interval (Only XM679K): (0.0÷24.0 hours: tens of minutes) after regulating

continuously for Sti time, the valve closes for Std time in order to prevent ice creation.

Std Stop duration (Only XM679K): (0÷60 min.) it defines stop regulation time after Sti.

nMS Maximum number of regulation pauses (nu, 1÷255)

OPTIONAL OUTPUT (AnOUT) if present

OA6 Sixth relay configuration (CPr-dEF-Fan-ALr-LiG-AUS-db-OnF): CPr= relay works as a

compressor or solenoid valve relay; dEF= relay works as defrost relay; Fan= relay works as a

Fan relay; ALr= activation with alarm conditions; LiG= light activation; AUS= auxiliary relay, it

can be switched ON/OFF also by key; db= dead band regulation (not compatible with CrE=y);

OnF= ON/OFF functioning;

CoM Type of functioning modulating output:

For models with PWM / O.C. output PM5= PWM 50Hz; PM6= PWM 60Hz;

OA7= not set it;

For models with 4÷20mA / 0÷10V output Cur= 4÷20mA current output; tEn=

0÷10V voltage output;

AOP Alarm relay polarity: cL= normally closed; oP= normally opened;

iAU Auxiliary output is unrelated to ON/OFF device status: n= if the instrument is switched off

also the auxiliary output is switched off; Y= the auxiliary output state is unrelated to the ON/OFF

device status

DIGITAL INPUTS

i1P Digital input 1 polarity: (cL –oP) CL: the digital input is activated by closing the contact; OP:

the digital input is activated by opening the contact.

i1F Digital input 1 function: (EAL –bAL –PAL –dor –dEF –AUS –LiG –OnF –Htr –FHU –ES

–Hdy) EAL= external alarm; bAL= serious external alarm; PAL= pressure switch activation; dor=

door open; dEF= defrost activation; AUS= auxiliary activation; LiG= light activation; OnF= switch

on/off the instrument; Htr= change type of action ; FHU= not used; ES= activate energy saving;

Hdy= activate holiday function;

d1d Time interval/delay for digital input alarm: (0



255 min.) Time interval to calculate the number

of the pressure switch activation when i1F=PAL. If I1F=EAL or bAL (external alarms), “d1d”

parameter defines the time delay between the detection and the successive signalling of the

alarm. If i1F=dor this is the delay to activate door open alarm

i2P Digital input 2 polarity: (cL –oP) CL : the digital input is activated by closing the contact; OP:

the digital input is activated by opening the contact.

i2F Digital input 2 function: (EAL –bAL –PAL –dor –dEF –AUS –LiG –OnF –Htr –FHU –ES

–Hdy) EAL= external alarm; bAL= serious external alarm; PAL= pressure switch activation; dor=

door open; dEF= defrost activation; AUS= auxiliary activation; LiG= light activation; OnF= switch

on/off the instrument; Htr= change type of action ; FHU= not used; ES= activate energy saving;

Hdy= activate holiday function;

d2d Time interval/delay for digital input alarm: (0



255 min.) Time interval to calculate the number

of the pressure switch activation when i2F=PAL. If I2F=EAL or bAL (external alarms), “d2d”

parameter defines the time delay between the detection and the successive signalling of the

alarm. If i2F=dor this is the delay to activate door open alarm

i3P Digital input 3 polarity: (cL –oP) CL : the digital input is activated by closing the contact; OP:

the digital input is activated by opening the contact.

i3F Digital input 3 function: (EAL –bAL –PAL –dor –dEF –AUS –LiG –OnF –Htr –FHU –ES

–Hdy) EAL= external alarm; bAL= serious external alarm; PAL= pressure switch activation; dor=

door open; dEF= defrost activation; AUS= auxiliary activation; LiG= light activation; OnF= switch

on/off the instrument; Htr= change type of action ; FHU= not used; ES= activate energy saving;

Hdy= activate holiday function;

d3d Time interval/delay for digital input alarm: (0



255 min.) Time interval to calculate the number

of the pressure switch activation when i3F=PAL. If i3F=EAL or bAL (external alarms), “d3d”

parameter defines the time delay between the detection and the successive signalling of the

alarm. If i3F=dor this is the delay to activate door open alarm

nPS Pressure switch number: (0



15) Number of activation of the pressure switch, during the “d#d”

interval, before signalling the alarm event (I2F= PAL). If the nPS activation in the did time is

reached, switch off and on the instrument to restart normal regulation.

odc Compressor and fan status when open door: no = normal; Fan = Fan OFF; CPr =

Compressor OFF; F_C = Compressor and fan OFF.

rrd Outputs restart after doA alarm: no = outputs not affected by the doA alarm; yES = outputs

restart with the doA alarm;

RTC SUBMENU (if present)

CbP Clock Presence (n÷y): it permits to disable or enable the clock;

Hur Current hour (0 ÷ 23 h)

Min Current minute (0 ÷ 59min)

dAY Current day (Sun ÷ SAt)

Hd1 First weekly holiday (Sun ÷ nu) Set the first day of the week which follows the holiday times.

Hd2 Second weekly holiday (Sun ÷ nu) Set the second day of the week which follows the holiday

times.

Hd3 Third weekly holiday (Sun ÷ nu) Set the third day of the week which follows the holiday times.

ILE Energy Saving cycle start during workdays: (0 ÷ 23h 50 min.) During the Energy Saving cycle

the set point is increased by the value in HES so that the operation set point is SET + HES.

dLE Energy Saving cycle length during workdays: (0 ÷ 24h 00 min.) Sets the duration of the

Energy Saving cycle on workdays.

ISE Energy Saving cycle start on holidays. (0 ÷ 23h 50 min.)

dSE Energy Saving cycle length on holidays (0 ÷ 24h 00 min.)

HES Temperature increase during the Energy Saving cycle (-30÷30°C / -54÷54°F) sets the

increasing value of the set point during the Energy Saving cycle.

Ld1÷Ld6 Workday defrost start (0 ÷ 23h 50 min.) These parameters set the beginning of the 6

programmable defrost cycles during workdays. Ex. When Ld2 = 12.4 the second defrost starts at

12.40 during workdays.

Sd1÷Sd6 Holiday defrost start (0 ÷ 23h 50 min.) These parameters set the beginning of the 6

programmable defrost cycles on holidays. Ex. When Sd2 = 3.4 the second defrost starts at 3.40

on holidays.

ENERGY SAVING

ESP Energy saving probe selection: (nP - P1 - P2 - P3 - P4 - P5 –tEr).

HES Temperature increase during the Energy Saving cycle : (-30÷30°C / -54÷54°F) sets the

increasing value of the set point during the Energy Saving cycle.

PEL Energy saving activation when light is switched off: (n÷Y) n= function disabled; Y= energy

saving is actived when the light is switched off and vice versa;

LAN MANAGEMENT

LMd Desfrost synchronisation: y= the section send a command to start defrost to oher controllers,

n= the section don’t send a global defrost command

dEM Type of end defrost: n= the of the LAN defrost are indipendent; y= the end of the defrost are

synchronisated;

LSP L.A.N. set-point synchronisation: y= the section set-point, when modified, is updated to the

same value on all the other sections; n= the set-point value is modified only in the local section

LdS L.A.N. display synchronisation: y= the value displayed by the section is sent to all the other

sections; n= the set-point value is modified only in the local section

LOF L.A.N. On/Off synchronisation this parameter states if the On/Off command of the section will

act on all the other ones too: y= the On/Off command is sent to all the other sections; n= the

On/Off command acts only in the local section

LLi L.A.N. light synchronisation this parameter states if the light command of the section will act

on all the other ones too: y= the light command is sent to all the other sections; n= the light

command acts only in the local section

LAU L.A.N. AUX output synchronisation this parameter states if the AUX command of the section

will act on all the other ones too: y= the light command is sent to all the other sections; n= the

light command acts only in the local section

LES L.A.N. energy saving synchronisation this parameter states if the energy saving command of

the section will act on all the other ones too: y= the Energy Saving command is sent to all the

other sections; n= the Energy Saving command acts only in the local section

LSd Remote probe display: this parameter states if the section has to display the local probe value

or the value coming from another section: y= the displayed value is the one coming from another

section (which has parameter LdS = y); n= the displayed value is the local probe one.

LPP Remote pressure probe: n= the value of pressure probe is read from local probe; Y= the value

of pressure probe is sent via LAN;

StM Solenoid activation via LAN: n= not used; Y= a generic cooling requests from LAN activate the

solenoid valve connected to compressor relay;

PROBE CONFIGURATION

P1C Probe 1 configuration: (nP –Ptc –ntc –PtM) nP= not present; PtC= Ptc; ntc= NTC; PtM=

Pt1000;

Ot Probe 1 calibration: (-12.0



12.0°C/ -21



21°F) allows to adjust possible offset of the thermostat

probe.

P2C Probe 2 configuration: (nP –Ptc –ntc –PtM) nP= not present; PtC= Ptc; ntc = NTC; PtM=

Pt1000;

OE Probe 2 calibration: (-12.0



12.0°C/ -21



21°F) allows to adjust possible offsets of the evaporator

probe.

P3C Probe 3 configuration: (nP –Ptc –ntc –PtM) nP= not present; PtC= Ptc; ntc = NTC; PtM=

Pt1000;

o3 Probe 3 calibration: (-12.0



12.0°C/ -21



21°F) allows to adjust possible offset of the probe 3.

P4C Probe 4 configuration: (nP –Ptc –ntc –PtM) nP= not present; PtC= Ptc; ntc = NTC; PtM=

Pt1000;

o4 Probe 4 calibration: (-12.0



12.0°C/ -21



21°F) allows to adjust possible offset of the probe 4.

P5C Probe 5 configuration: (nP –Ptc –ntc –PtM –420 –5Vr) nP= not present; PtM= Pt1000; 420=

4÷ 20mA; 5Vr= 0÷5V ratiometric; (Only XM679K)

o5 Probe 5 calibration: (-12.0



12.0°C/ -21



21°F) allows to adjust possible offset of the probe 5.

(Only XM679K)

P6C Probe 6 configuration: (nP –Ptc –ntc –PtM) nP= not present; PtC= Ptc; ntc = NTC; PtM=

Pt1000; (Only XM679K)

o6 Probe 6 calibration: (-12.0



12.0°C/ -21



21°F) allows to adjust possible offset of the probe 6.

(Only XM679K)

SERVICE –READ ONLY

CLt Coling time percentage: it shows the effective cooling time calculated by XM600 during

regulation;

tMd Time to next defrost: it shows time before the next defrost if interval defrost is selected;

LSn L.A.N. section number (1 ÷ 8) Shows the number of sections available in the L.A.N.

Lan L.A.N. serial address (1 ÷ LSn) Identifies the instrument address inside local network of

multiplexed cabinet controller.

Adr RS485 serial address (1÷247): Identifies the instrument address when connected to a ModBUS

compatible monitoring system.

1592023130 XM670K_XM679K GB r4.2 26.06.2017.docx XM670K - XM679K 8/10

Rel Release software: (read only) Software version of the microprocessor.

Ptb Parameter table: (read only) it shows the original code of the Dixell parameter map.

Pr2 Access to the protected parameter list (read only).

17. DIGITAL INPUTS

The XM600 series can support up to 3 free of voltage contact configurable digital inputs (depending on

the models). They are configurable via i#F parameter

17.1 GENERIC ALARM (EAL)

As soon as the digital input 1, 2, or 3 is activated the unit will wait for “d1d” or “d2d”or “d3d”time delay

before signalling the “EAL” alarm message. The outputs status don’t change. The alarm stops just after

the digital input is de-activated.

17.2 SERIOUS ALARM MODE (BAL)

When the digital input is activated, the unit will wait for “d1d” or “d2d”or “d3d” delay before signalling the

“BAL” alarm message. The relay outputs are switched OFF. The alarm will stop as soon as the digital

input is de-activated.

17.3 PRESSURE SWITCH (PAL)

If during the interval time set by “d1d” or “d2d”or “d3d” parameter, the pressure switch has reached the number

of activation of the “nPS” parameter, the “CA” pressure alarm message will be displayed. The compressor and

the regulation are stopped. When the digital input is ON the compressor is always OFF. If the nPS activation in

the d#d time is reached, switch off and on the instrument to restart normal regulation.

17.4 DOOR SWITCH INPUT (dor)

It signals the door status and the corresponding relay output status through the “odc” parameter: no = normal

(any change); Fan = Fan OFF; CPr = Compressor OFF; F_C = Compressor and fan OFF. Since the door is

opened, after the delay time set through parameter “d#d”, the door alarm is enabled, the display shows the

message “dA” and the regulation restarts after rrd time. The alarm stops as soon as the external digital input

is disabled again. With the door open, the high and low temperature alarms are disabled.

17.5 START DEFROST (DEF)

It executes a defrost if there are the right conditions. After the defrost is finished, the normal regulation

will restart only if the digital input is disabled otherwise the instrument will wait until the “Mdf” safety time

is expired.

17.6 RELAY AUX ACTUATION (AUS)

This function allows to turn ON and OFF the auxiliary relay by using the digital input as external switch.

17.7 RELAY LIGHT ACTUATION (LIG)

This function allows to turn ON and OFF the light relay by using the digital input as external switch.

17.8 REMOTE ON/OFF (ONF)

This function allows to switch ON and OFF the instrument.

17.9 KIND OF ACTION (HTR)

This function allows to change the kind of regulation from cooling to heating and vice versa.

17.10 FHU –NOT USED

This function allows to change the kind of regulation from cooling to heating and viceversa.

17.11 ENERGY SAVING INPUT (ES)

The Energy Saving function allows to change the set point value as the result of the SET+ HES

(parameter) sum. This function is enabled until the digital input is activated.

17.12 CONFIGURABLE INPUT - HOLIDAY FUNCTION (HDY)

In Holiday function Energy saving and defrost cycles follow holiday times. (Sd1…Sd6)

17.13 DIGITAL INPUTS POLARITY

The digital inputs polarity depends on “I#P”parameters: CL : the digital input is activated by closing the

contact; OP : the digital input is activated by opening the contact.

18. USE OF THE PROGRAMMING “HOT KEY“

The XM units can UPLOAD or DOWNLOAD the parameter list from its own E2 internal memory to the

“Hot Key” and vice-versa through a TTL connector.

18.1 DOWNLOAD (FROM THE “HOT KEY” TO THE INSTRUMENT)

1. Turn OFF the instrument by means of the ON/OFF key ,insert the “Hot Key” and then turn the unit

ON.

2. Automatically the parameter list of the “Hot Key” is downloaded into the controller memory, the

“doL” message is blinking. After 10 seconds the instrument will restart working with the new

parameters. At the end of the data transfer phase the instrument displays the following messages:

“end“ for right programming. The instrument starts regularly with the new programming. “err” for

failed programming. In this case turn the unit off and then on if you want to restart the download

again or remove the “Hot key” to abort the operation.

18.2 UPLOAD (FROM THE INSTRUMENT TO THE “HOT KEY”)

1. When the XM unit is ON, insert the “Hot key” and push “UP” key.

2. The UPLOAD begins; the “uPL” message is blinking.

3. Remove the “Hot Key”.

At the end of the data transfer phase the instrument displays the following messages:

“end “ for right programming.

“err” for failed programming. In this case push “SET” key if you want to restart the programming

again or remove the not programmed “Hot key”.

19. TECHNICAL DATA

CX660 keyboard

Housing: self extinguishing ABS.

Case: CX660 facia 35x77 mm; depth 18mm

Mounting: panel mounting in a 29x71 mm panel cut-out

Protection: IP20; Frontal protection: IP65

Power supply: from XM600K power module

Display: 3 digits, red LED, 14,2 mm high;

Optional output: buzzer

Power modules

Case: 8 DIN

Connections: Screw terminal block



1,6 mm2heat-resistant wiring and 5.0mm Faston

Power supply: depending on the model 12Vac –24Vac - 110Vac



10% - 230Vac



10% or 90÷230Vac

with switching power supply.

Power absorption: 9VA max.

Inputs: up to 6 NTC/PTC/Pt1000 probes

Digital inputs: 3 free of voltage

Relay outputs: Total current on loads MAX. 16A

Solenoid Valve: relay SPST 5(3) A, 250Vac

defrost: relay SPST 16 A, 250Vac

fan: relay SPST 8 A, 250Vac

light: relay SPST 16 A, 250Vac

alarm: SPDT relay 8 A, 250Vac

Aux: SPST relay 8 A, 250Vac

Valve output: a.c. output up to 30W (Only XM679K)

Optional output (AnOUT) DEPENDING ON THE MODELS:

PWM / Open Collector outputs: PWM or 12Vdc max 40mA

Analog output: 4÷20mA or 0÷10V

Serial output: RS485 with ModBUS - RTU and LAN

Data storing: on the non-volatile memory (EEPROM).

Kind of action: 1B. Pollution degree: 2 Software class: A. Operating temperature: 0÷60 °C.

Storage temperature: -25÷60 °C. Relative humidity: 20



85% (no condensing).

Measuring and regulation range:

NTC probe: -40÷110°C (-58÷230°F).

PTC probe: -50÷150°C (-67 ÷ 302°F)

Pt1000 probe: -100 ÷ 100°C (-148 ÷ 212°F)

Resolution: 0,1 °C or 1°C or 1 °F (selectable). Accuracy (ambient temp. 25°C): ±0,5 °C ±1 digit

20. DEFAULT SETTING VALUES

Lab

Val

Menù

Description

Range

SEt

2.0

- - -

Set point

LS - US

rtC

Pr1

CLOCK AND DEFROST menu

access

EEU

Pr1

Electro valve menu access

Regulation

2.0

Pr1

Differential

[0.1°C ÷ 25.5°C] [1°F ÷ 45°F]

Int

150

Pr1

Integral time for room temperature

regulation

0 ÷ 255 s

CrE

Pr1

Continuous regulation activation

n(0) –Y(1)

-30

Pr2

Minimum set point

[-55.0°C ÷ SET] [-67°F ÷ SET]

Pr2

Maximum set point

[SET ÷ 150.0°C] [SET ÷ 302°F]

odS

Pr1

Outputs activation delay at start

0 ÷ 255 (min.)

Pr1

Anti-short cycle delay

0 ÷ 60 (min.)

CCt

0.0

Pr2

Continous cycle duration

0 ÷ 24.0(144) (hour.10min)

CCS

2.0

Pr2

Continuous cycle set point

[-55.0°C ÷ 150,0°C] [-67°F ÷

302°F]

Con

Pr2

Compressor ON time with faulty

probe

0 ÷ 255 (min.)

CoF

Pr2

Compressor OFF time with faulty

probe

0 ÷ 255 (min.)

°C

Pr2

Measurement unit: Celsius ,

Fahrenheit

°C(0) - °F(1)

PrU

Pr2

Pressure Mode

rE(0) - Ab(1)

PMU

bAr

Pr2

Pressure measurement unit

bAr(0) –PSI(1) - MPA(2)

PMd

PrE

Pr2

Pressure displaying mode:

temperature or pressure

tEM(0) - PrE(1)

rES

Pr2

Resolution (only °C) : decimal,

integer

dE(0) - in(1)

Lod

Pr2

Local display: default display

nP(0) - P1(1) - P2(2) - P3(3) -

P4(4) - P5(5) - P6(6) –tEr(7) -

dEF(8)

rEd

Pr2

Remote display: default display

nP(0) - P1(1) - P2(2) - P3(3) -

P4(4) - P5(5) - P6(6) –tEr(7) -

dEF(8)

dLy

Pr1

Display delay

0 ÷ 24.0(144) (Min.10s)

rPA

Pr1

Regulation probe A

nP(0) - P1(1) - P2(2) - P3(3) -

P4(4) - P5(5)

rPb

Pr1

Regulation probe B

nP(0) - P1(1) - P2(2) - P3(3) -

P4(4) - P5(5)

rPE

100

Pr1

Virtual probe percentage (room

temperature)

0 ÷ 100 (100=rPA, 0=rPb)

Electronic Expansion Valve

Fty

404

Pr1

Kind of gas

R22-134-290 - 404- 47A-47C- 47F

410-448-449-450- 507 -513-CO2

Atu

YES

Pr2

Minimum STABLE superheat

No; yES

AMS

YES

Pr2

Self self adaptive SH regulation

enabling

No; yES

SSH

8.0

Pr1

Superheat set point

[0.1°C ÷ 25.5°C] [1°F ÷ 45°F]

CyP

Pr1

Cycle Period

1 ÷ 15 s

5.0

Pr1

Proportional band for superheat

regulator

[0.1°C ÷ 60.0 °C] [1°F ÷ 108 °F]

0.0

Pr1

Band Offset for superheat

regulator

[-12.0°C ÷ 12.0°C] [-12°C ÷

12°C] [-21°F ÷ 21°F]

inC

120

Pr1

Integration time for superheat

regulator

0 ÷ 255 s

PEO

Pr1

Probe error opening percentage

0 ÷ 100

PEd

Pr1

Probe error delay before stopping

regulation

0 ÷ 239 s - On(240)

OPE

Pr1

Start opening percentage

0 ÷ 100

1592023130 XM670K_XM679K GB r4.2 26.06.2017.docx XM670K - XM679K 9/10

SFd

0.3

Pr1

Start function duration

0 ÷ 42.0(252) (min.10sec)

OPd

Pr1

Opening percentage after defrost

phase

0 ÷ 100

Pdd

0.3

Pr1

Post defrost function duration

0 ÷ 42.0(252) (min.10sec)

MnF

100

Pr1

Maximum opening percentage at

normale functioning

0 ÷ 100

dCL

Pr1

Delay before stopping valve

regulation

0 ÷ 255 s

Fot

Pr1

Forced opening percentage

0 ÷ 100 - "nu"(101)

PA4

-0.5

Pr2

Probe value at 4 mA or at 0V

BAR : [PrM=rEL] -1.0 ÷ P20

[PRM=Abs] 0.0 ÷ P20

PSI : [PrM=rEL] -14 ÷ P20

[PRM=Abs] 0 ÷ P20

dKP : [PrM=rEL] -10 ÷ P20

[PRM=Abs] 0 ÷ P20

P20

11.0

Pr2

Probe value at 20 mA or at 5V

BAR : [PrM=rEL] PA4 ÷ 50.0

[PrM=AbS] PA4 ÷ 50.0

PSI : [PrM=rEL] PA4 ÷ 725

[PrM=AbS] PA4 ÷ 725

dKP : [PrM=rEL] PA4 ÷ 500

[PrM=AbS] PA4 ÷ 500

LPL

-0.5

Pr1

Lower pressure limit for superheat

regulation

PA4 ÷ P20

MOP

11.0

Pr1

Maximum operating pressure

threshold

LOP ÷ P20

LOP

-0.5

Pr1

Lowest operating pressure

threshold

PA4 ÷ MOP

dML

Pr1

Delta MOP-LOP opening variation

0 ÷ 100

MSH

80.0

Pr1

Maximum superheat alarm

threshold

[LSH ÷ 80,0°C] [LSH ÷ 144°F]

LSH

2.0

Pr1

Minimum superheat alarm

threshold

[0.0 ÷ MSH °C] [0 ÷ MSH °F]

SHy

2.0

Pr2

Superheat alarm hysteresis

[0.1°C ÷ 25.5°C] [1°F ÷ 45°F]

SHd

3.0

Pr1

Superheat alarm activation delay

0 ÷ 42.0(252) (min.10sec)

FrC

100

Pr1

Fast-recovery costant

0 ÷ 100

SUb

Pr2

Pressure filter

0÷100

SLb

Pr2

Reaction time

0÷255s

Defrost

dPA

Pr1

Defrost probe A

nP(0) - P1(1) - P2(2) - P3(3) -

P4(4) - P5(5)

dPb

Pr1

Defrost probe B

nP(0) - P1(1) - P2(2) - P3(3) -

P4(4) - P5(5)

dPE

100

Pr1

Virtual probe percentage (defrost

temperature)

0 ÷ 100 (100=dPA, 0=dPb)

tdF

Pr1

Defrost type

EL(0) - in(0)

EdF

Pr1

Defrost mode: Clock or interval

rtc(0) - in(1)

Srt

150

Pr1

Heater set point during defrost

[-55.0°C ÷ 150°C] [-67°F ÷

302°F]

Hyr

2.0

Pr1

Differential for heater

[0.1°C ÷ 25.5°C] [1°F ÷ 45°F]

tod

255

Pr1

Time out for heater

0 ÷ 255 (min.)

dtP

0.1

Pr1

Minimum temperature difference

to start defrost

[0.1°C ÷ 50.0°C] [1°F ÷ 90°F]

ddP

Pr1

Delay before starting defrost

0 ÷ 60 (min.)

d2P

Pr1

Defrost with two probes

n(0) –Y(1)

dtE

8.0

Pr1

Defrost termination temperature

(Probe A)

[-55.0°C ÷ 50.0°C] [-67°F ÷

122°F]

dtS

8.0

Pr1

Defrost termination temperature

(Probe B)

[-55.0°C ÷ 50.0°C] [-67°F ÷

122°F]

idF

Pr1

Interval between defrosts

0 ÷ 120 (hours)

MdF

Pr1

Defrost Maximum duration

0 ÷ 255 (min.)

dSd

Pr1

Start defrost delay

0 ÷ 255 (min.)

dFd

Pr1

Display during defrost

rt(0) - it(1) - SEt(2) - dEF(3)

dAd

Pr1

Defrost display time out

0 ÷ 255 (min.)

Fdt

Pr1

Drain down time

0 ÷ 255 (min.)

dPo

Pr1

Defrost at start-up

n(0) –Y(1)

dAF

0.0

Pr1

Defrost delay after continuous

cycle

0 ÷ 24.0(144) (hours.10min)

Fan

FPA

Pr1

Fan probe A

nP(0) - P1(1) - P2(2) - P3(3) -

P4(4) - P5(5)

FPb

Pr1

Fan probe B

nP(0) - P1(1) - P2(2) - P3(3) -

P4(4) - P5(5)

FPE

100

Pr1

Virtual probe percentage (fan

management)

0 ÷ 100 (100=FPA, 0=FPb)

FnC

O-n

Pr1

Fan operating mode

C-n(0) - O-n(1) - C-y(2) - O-y(3)

Fnd

Pr1

Fan delay after defrost

0 ÷ 255 (min.)

FCt

Pr1

Temperature differential to avoid

short cycles of fans

[0.0°C ÷ 50.0°C] [0°F ÷ 90°F]

FSt

2.0

Pr1

Fan stop temperature

[-55.0°C ÷ 50.0°C] [-67°F ÷

122°F]

FHy

1.0

Pr1

Fan stop differential

[0.1°C ÷ 25.5°C] [1°F ÷ 45°F]

Fod

Pr1

Fan activation time after defrost

(without compressor)

0 ÷ 255 (min.)

Fon

Pr1

Fan ON time

0÷15 (min.)

FoF

Pr1

Fan OFF time

0÷15 (min.)

trA

UAL

Pr2

Kind of regulation for modulating

output

UAL(0) - rEG(1) - AC(2)

SOA

Pr2

Fixed speed for fan

AMi ÷ AMA

SdP

30.0

Pr2

Default Dew Point value

[-55.0°C ÷ 50.0°C] [-67°F ÷

122°F]

ASr

1.0

Pr2

Differential for fan / offset for anti

sweat heater

[-25.5°C ÷ 25.5°C] [-45°F ÷ 45°F]

PbA

5.0

Pr2

Proportional band for modulating

output

[0.1°C ÷ 25.5°C] [1°F ÷ 45°F]

AMi

Pr2

Minimum output for modulating

output

0 ÷ AMA

AMA

100

Pr2

Maximum output for modulating

output

AMi ÷ 100

AMt

Pr2

Time with fan at maximum speed

0 ÷ 255 s

Alarm

rAL

Pr1

Probe for temperature alarm

nP(0) - P1(1) - P2(2) - P3(3) -

P4(4) - P5(5) - tEr(6)

ALC

Pr1

Temperature alarm configuration

rE(0) - Ab(1)

ALU

Pr1

High temperature alarm setting

[0.0°C ÷ 50.0°C o ALL ÷ 150.0°]

[0°F ÷ 90°F o ALL ÷ 302°F]

ALL

-30

Pr1

Low temperature alarm setting

[0.0°C ÷ 50.0°C o -55,0°C ÷

ALU] [0°F ÷ 90°F o -67°F ÷

ALU°F]

AHy

1.0

Pr1

Differential for temperature alarm

[0.1°C ÷ 25.5°C] [1°F ÷ 45°F]

ALd

Pr1

Temperature alarm delay

0 ÷ 255 (min.)

dLU

150

Pr2

High temperature alarm setting

(defrost probe)

[0.0°C ÷ 50.0°C o dLL ÷ 150.0°]

[0°F ÷ 90°F o dLL ÷ 302°F]

dLL

-55

Pr2

Low temperature alarm setting

(defrost probe)

[0.0°C ÷ 50.0°C o -55,0°C ÷

dLU] [0°F ÷ 90°F o -67°F ÷

dLU°F]

dAH

1.0

Pr2

Differential for temperature alarm

(defrost probe)

[0.1°C ÷ 25.5°C] [1°F ÷ 45°F]

ddA

Pr2

Temperature alarm delay (defrost

probe)

0 ÷ 255 (min.)

FLU

150

Pr2

High temperature alarm setting

(fan probe)

[0.0°C ÷ 50.0°C o FLL ÷ 150.0°]

[0°F ÷ 90°F o FLL ÷ 302°F]

FLL

-55

Pr2

Low temperature alarm setting

(fan probe)

[0.0°C ÷ 50.0°C o -55,0°C ÷

FLU] [0°F ÷ 90°F o -67°F ÷

FLU°F]

FAH

1.0

Pr2

Differential for temperature alarm

(fan probe)

[0.1°C ÷ 25.5°C] [1°F ÷ 45°F]

FAd

Pr2

Temperature alarm delay (fan

probe)

0 ÷ 255 (min.)

dAo

1.3

Pr1

Delay of temperature alarm at

start-up

0 ÷ 24.0(144) (hours.10min)

EdA

Pr1

Alarm delay at the end of defrost

0 ÷ 255 min

dot

Pr1

Temperature alarm exclusion after

door open

0 ÷ 255 min

Sti

Pr2

Stop regulation interval

"nu"(0) ÷ 24.0(144)

(hour.10min)

Std

Pr2

Stop duration

1 ÷ 255 min

oA6

AUS

Pr2

Sixth relay output configuration

CPr(0) - dEF(1) - FAn(2) - ALr(3)

- LiG(4) - AUS(5) - db(6) -

OnF(7)

CoM

Cur

Pr2

Modulating output configuration

CUr(0) - tEn(1) - PM5(2) -

PM6(3) - oA7(4)

AOP

Pr1

Alarm relay polarity

OP(0) - CL(1)

iAU

Pr1

Auxiliary output indipendent from

ON/OFF state

n(0) –Y(1)

Digital Inputs

i1P

Pr1

Digital input 1 polarity

OP(0) - CL(1)

i1F

dor

Pr1

Digital input 1 configuration

EAL(0) - bAL(1) - PAL(2) - dor(3)

- dEF(4) - AUS(5) -LiG(6) -

OnF(7) - Htr(8) - FHU(9) -

ES(10) - Hdy(11)

d1d

Pr1

Digital input 1 activation delay

0 ÷ 255 (min.)

i2P

Pr1

Digital input 2 polarity

OP(0) - CL(1)

i2F

LiG

Pr1

Digital input 2 configuration

EAL(0) - bAL(1) - PAL(2) - dor(3)

- dEF(4) - AUS(5) -LiG(6) -

OnF(7) - Htr(8) - FHU(9) -

ES(10) - Hdy(11)

d2d

Pr1

Digital input 2 activation delay

0 ÷ 255 (min.)

i3P

Pr1

Digital input 3 polarity

OP(0) - CL(1)

i3F

Pr1

Digital input 3 configuration

EAL(0) - bAL(1) - PAL(2) - dor(3)

- dEF(4) - AUS(5) -LiG(6) -

OnF(7) - Htr(8) - FHU(9) -

ES(10) - Hdy(11)

d3d

Pr1

Digital input 3 activation delay

0 ÷ 255 (min.)

nPS

Pr1

Number of pressure switch

activation before lock

0 ÷ 15

OdC

F-C

Pr1

Compressor and fan status when

open door

no(0) - FAn(1) - CPr(2) - F-C(3)

rrd

Pr1

Outputs restart after door open

alarm

0 ÷ 255 (min.)

1592023130 XM670K_XM679K GB r4.2 26.06.2017.docx XM670K - XM679K 10/10

Clock

CbP

Pr1

Clock presence

n(0) –Y(1)

Hur

- - -

Pr1

Current hour

- - -

Min

- - -

Pr1

Current minutes

- - -

dAY

- - -

Pr1

Current day

Sun(0) - SAt(6)

Hd1

Pr1

First weekly day

Sun(0) - SAt(6) - nu(7)

Hd2

Pr1

Second weekly day

Sun(0) - SAt(6) - nu(7)

Hd3

Pr1

Third weekly day

Sun(0) - SAt(6) - nu(7)

ILE

0.0

Pr1

Energy saving cycle start during

workdays

0 - 23.5(143) (hours.10min)

dLE

0.0

Pr1

Energy saving cycle length during

workdays

0 ÷ 24.0(144) (hours.10min)

ISE

0.0

Pr1

Energy saving cycle start during

holidays

0 - 23.5(143) (hours.10min)

dSE

0.0

Pr1

Energy saving cycle length during

holidays

0 ÷ 24.0(144) (hours.10min)

HES

0.0

Pr1

Temperature increasing during

Energy Saving cycle

[-30.0°C ÷ 30.0°C] [-54°F ÷ 54°F]

Ld1

Pr1

Workdays First defrost start

0.0 ÷ 23.5(143) - nu(144)

(hours.10min)

Ld2

Pr1

Workdays Second defrost start

Ld1 ÷ 23.5(143) - nu(144)

(hours.10min)

Ld3

Pr1

Workdays Third defrost start

Ld2 ÷ 23.5(143) - nu(144)

(hours.10min)

Ld4

Pr1

Workdays Fourth defrost start

Ld3 ÷ 23.5(143) - nu(144)

(hours.10min)

Ld5

Pr1

Workdays Fifth defrost start

Ld4 ÷ 23.5(143) - nu(144)

(hours.10min)

Ld6

Pr1

Workdays Sixth defrost start

Ld5 ÷ 23.5(143) - nu(144)

(hours.10min)

Sd1

Pr1

Holidays First defrost start

0.0 ÷ 23.5(143) - nu(144)

(hours.10min)

Sd2

Pr1

Holidays Second defrost start

Sd1 ÷ 23.5(143) - nu(144)

(hours.10min)

Sd3

Pr1

Holidays Third defrost start

Sd2 ÷ 23.5(143) - nu(144)

(hours.10min)

Sd4

Pr1

Holidays Fourth defrost start

Sd3 ÷ 23.5(143) - nu(144)

(hours.10min)

Sd5

Pr1

Holidays Fifth defrost start

Sd4 ÷ 23.5(143) - nu(144)

(hours.10min)

Sd6

Pr1

Holidays Sixth defrost start

Sd5 ÷ 23.5(143) - nu(144)

(hours.10min)

Energy Saving

ESP

Pr1

Energy saving probe selection

nP(0) - P1(1) - P2(2) - P3(3) -

P4(4) - P5(5) - tEr(6)

HES

0.0

Pr1

Temperature increasing during

Energy Saving

[-30.0°C ÷ 30.0°C] [-54°F ÷ 54°F]

PEL

Pr1

Energy saving activation when

Light switched off

n(0) –Y(1)

L.A.N. Management

LMd

Pr2

Defrost Synchronisation

n(0) –Y(1)

dEM

Pr2

Defrost end Synchronisation

n(0) –Y(1)

LSP

Pr2

SET-POINT Synchronisation

n(0) –Y(1)

LdS

Pr2

Display Synchronisation

(temperature sent via LAN)

n(0) –Y(1)

LOF

Pr2

ON/OFF Synchronisation

n(0) –Y(1)

LLi

Pr2

Light Synchronisation

n(0) –Y(1)

LAU

Pr2

AUX Synchronisation

n(0) –Y(1)

LES

Pr2

Energy Saving Synchronisation

n(0) –Y(1)

LSd

Pr2

Remote probe displaying

n(0) –Y(1)

LPP

Pr2

Pressure value sent in LAN

n(0) –Y(1)

StM

Pr2

Cooling request from LAN enable

compressor relay

n(0) –Y(1)

Probe Configurations

P1C

NtC

Pr2

P1 configuration

nP(0) - Ptc(1) - ntc(2) - PtM(3)

0.0

Pr2

P1 calibration

[-12,0°C ÷ 12,0°C] [-21°F ÷

21°F]

P2C

NtC

Pr2

P2 configuration

nP(0) - Ptc(1) - ntc(2) - PtM(3)

0.0

Pr2

P2 calibration

[-12,0°C ÷ 12,0°C] [-21°F ÷

21°F]

P3C

NtC

Pr2

P3 configuration

nP(0) - Ptc(1) - ntc(2) - PtM(3)

0.0

Pr2

P3 calibration

[-12,0°C ÷ 12,0°C] [-21°F ÷

21°F]

P4C

NtC

Pr2

P4 configuration

nP(0) - Ptc(1) - ntc(2) - PtM(3)

0.0

Pr2

P4 calibration

[-12,0°C ÷ 12,0°C] [-21°F ÷

21°F]

P5C

420

Pr2

P5 configuration

nP(0) - Ptc(1) - ntc(2) - PtM(3) -

420(4) - 5Vr(5)

0.0

Pr2

P5 calibration

[-12,0°C ÷ 12,0°C] [-21°F ÷

21°F]

P6C

PtM

Pr2

P6 configuration

nP(0) - Ptc(1) - ntc(2) - PtM(3)

0.0

Pr2

P6 calibration

[-12,0°C ÷ 12,0°C] [-21°F ÷

21°F]

Service

CLt

- - -

Pr1

ON/OFF percentage (C.R.O.)

(read only)

tMd

- - -

Pr1

Time remaining before next

defrost activation (only for interval

defrost)

(read only)

LSn

- - -

Pr1

Number of devices in LAN

1 ÷ 8 (read only)

LAn

- - -

Pr1

List of address of LAN devices

1 ÷ 247 (read only)

Other

Adr

Pr1

Modbus address

1 ÷ 247

rEL

4.2

Pr1

Firmware release

(read only)

Ptb

Pr1

Parameter table

(read only)

Pr2

- - -

Pr1

PR2 menu access

(read only)

Other manuals for Dixell XM670K

This manual suits for next models

Table of contents

Other Emerson Controllers manuals

Emerson

Emerson Tescom 26-1000 Series User manual

Emerson

Emerson KEYSTONE FIGURE 79U Manual

Emerson

Emerson Fisher HSRL Series User manual

Emerson

Emerson Dixell XR44CX Wiring diagram

Emerson

Emerson Fisher 1051 User manual

Emerson

Emerson Fisher 133H User manual

Emerson

Emerson 6351F User manual

Emerson

Emerson fisher 1008 User manual

Emerson

Emerson Yarway Manual

Emerson

Emerson NELSON CM-GP User manual

Emerson

Emerson Yarway User manual

Emerson

Emerson EC3-D72 User manual

Emerson

Emerson CASH VALVE B Series Manual

Emerson

Emerson AVENTICS Sentronic TWIN 615 User manual

Emerson

Emerson Dixell XR70CHC Wiring diagram

Emerson

Emerson P159A Series Installation and operating instructions

Emerson

Emerson Dixell XT141C Wiring diagram

Emerson

Emerson Bettis SCE300 User manual

Emerson

Emerson EC3 Series User manual

Emerson

Emerson Bettis TEC2 User manual

Emerson

Emerson dixell WING XW260L Wiring diagram

Emerson

Emerson Advantage 2.1 User manual

Emerson

Emerson Fisher easy-Drive 200R User manual

Emerson

Emerson Fisherr 4660 User manual

Popular Controllers manuals by other brands

SOMFY

SOMFY animeo Compact installation guide

Zoo Med

Zoo Med RT-1000E quick start guide

Phason

Phason PLUS Series user manual

Reer

Reer MOSAIC MI8 Installation and use

Omron

Omron E5*N Series manual

Digilent

Digilent chipKIT wf32 Reference manual

Honeywell

Honeywell S9201A1010 quick start guide

IFM Electronic

IFM Electronic AC1331 installation instructions

Frigicoll

Frigicoll Kaysun KCCHT-07 owner's manual

LEGRAND

LEGRAND Wattstopper LMPL-101 installation instructions

Vaillant

Vaillant multiMATIC VRC 700f/4 operating instructions

HIGOAL

HIGOAL iR quick start guide

Omron

Omron C200H-OD212 installation guide

ENSIM SENSORS

ENSIM SENSORS SK-R operating manual

ECD

ECD 100-194 EN81 manual

Leslie

Leslie PMC-1 INSTALLATION, OPERATING, AND MAINTENANCE INSTRUCTIONS DIAGRAMS & PARTS LIST

Carlisle

Carlisle Ransburg DR-1 Service manual

Bose

Bose FREESPACE 4400 installation guide

Emerson Dixell XM670K Wiring diagram

Popular Controllers manuals by other brands
