REFCON Portable Modem
User Manual

REFCON Portable Modem User Manual_1.1 Transportation Solutions
Updated: 2019-03-12 Author: Jens Sarup
Page 2 of 6
1 DECLARATION OF CONFORMITY
Environmental Specifications, markings and certifications
CE EMC Directive 2014/30/EC
Low Voltage Directive 2014/35/EC
RED Directive 2014/53/EC
RoHS Directive 2011/65/EC
WEE Directive 2002/96/EC
FCC ID 2ARHAC00001
1.1 FCC Rules
This device complies with Part 15 of the FCC Rule. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received, including interference that may
cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
•Consult the dealer or an experienced radio/TV technician for help.

REFCON Portable Modem User Manual_1.1 Transportation Solutions
Updated: 2019-03-12 Author: Jens Sarup
Page 3 of 6
WARNING!
FCC Radiation Exposure Statement:
This device complies with FCC’s and IC’s RF radiation exposure limits set forth for an
uncontrolled environment under the following conditions:
1. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user´s authority to operate the equipment.
1.2 Safety Warnings
Caution contains Static Sensitive Device

REFCON Portable Modem User Manual_1.1 Transportation Solutions
Updated: 2019-03-12 Author: Jens Sarup
Page 4 of 6
2 REFCON PORTABLE MODEM
Description:
The REFCON Portable Modem is a simple solution to solve a complex problem in the refrigerated
container industry. Visibility is key to ensuring the wellbeing of the refrigerated containers and its
cargo but on vessels or terminals today this visibility at best limited, leading to undiscovered
alarms, incorrect setpoints etc. which is driving the need for a nonoptimal time-consuming manual
process for monitoring the refrigerated containers to ensure the safety of the cargo.
The REFCON Portable Modem connects easily to any refrigerated container in the market today
directly to the log retrieval plug or with an extension cable depending on the application from here
all data is wirelessly sent to REFCON where the data and alarms can be processed by the crew.
The REFCON Portable Modem can also be used in an application where infrastructure is
unavailable which could be on short-term charter vessels or on peak season storage areas on
terminals in these cases the REFCON Mobile app can be used together with an Android device by
the crew to fast and automatically collect data and alarms for a flexible monitoring solution.
At Emerson data security is always a top priority and the REFCON Portable Modem solution is no
exception, which is one of the reasons why we chose the newest Bluetooth Low Energy 5.0 as the
wireless interface given its high-security standards and to ensure the highest data security the
Portable Modem is also equipped with unique burned in X509 keys for additional protection against
external threats.

REFCON Portable Modem User Manual_1.1 Transportation Solutions
Updated: 2019-03-12 Author: Jens Sarup
Page 5 of 6
3 VERIFICATION OF REFCON PORTABLE
MODEM
Installation and verification REFCON portable modem
3.1 Connect the REFCON Portable modem to the reefers in retriever plug and turn the knob
clock wise.
3.2 Follow the chart for verification (Figure 1)
3.3 Final verification is done by the REFCON Application where the actual Container is
showing with the collected data for the specific reefer .
Installation of the REFCON Application
3.4 Install the Application on your Android device by following the REFCON Application
installation guide.
Figure 1.
Install RMM
-
P and
wait 5 seconds for
the LED multi
status indicator to
show status
Red flash after 6 minutes
Indicating: Controller not
supported or the RS232
connection is faulty
No flash
Green flash after 6
minutes – Unit OK
Yellow blink
Indicating: OK and Ready to
communicate with
controller
Verify that the controller type
is supported and verify the
controller ID
Verify the functionality of the
RS232 line and repair if
required
Indicating RS232
connection is
interrupted for the
REFCON Portable
Modem.
Verify the Reefers RS232 plug
and wiring. Repair if required
Verify the modem on another
unit. Return the modem if
found faulty
Verify that the Container
shows in the REFCON
Application

REFCON Portable Modem User Manual_1.1 Transportation Solutions
Updated: 2019-03-12 Author: Jens Sarup
Page 6 of 6
Document Revision Record
Rev.
Date
Author
Brief description of change
Pages affected
1.0 060616 JES Original issue All
1.1. 120319 JES Updated legislation text All
