AC Power
For Business-Critical Continuity™
Liebert®Power Solutions
IT System Protection That Grows With Your Needs

2
It All Starts With Rack Systems
Liebert and Knurr brand computer rack systems offer all the
advanced features and innovative flexibility required to
accommodate today’s dense and complex IT systems and
network gear.
Knurr racks simplify equipment installation, improve cable
management and increase visibility and control of
equipment inside the rack.
Liebert enclosures integrate power and cooling to provide a
complete rack-based support system. Liebert pioneered this
approach with the Little Glass House and today provides
enclosures, such as the Liebert MCR and Liebert XDF, that
protect sensitive electronics in almost any environment.
UPS Systems
Liebert offers all three major uninterruptible power supply
(UPS) system configurations:
n Off-Line UPS—Passes utility power straight through to the
protected load with a 2-6 ms break in power when
transferring to battery back-up.
n Line Interactive UPS—Provides power conditioning with
a 2-6 ms break in power when transferring to battery
back-up.
n On-Line (Double Conversion) UPS—Delivers continuous,
high-quality AC power to equipment with no break when
transferring to battery. Protects equipment from virtually
all power disturbances due to blackouts, brownouts, sags,
surges or noise interference.
Liebert offers UPS systems in the industry’s widest range of
sizes including desktop, rack-mount and enterprise systems
for full facility power.
Critical Electrical Distribution
Liebert offers a range of power distribution systems designed to
efficiently deliver conditioned power to your critical equipment.
These products include high-reliability distribution systems,
starting with rack power distribution systems, specially designed
for computer and communications applications, as well as
transfer switches offering ultra-fast transfer between two
independent AC power sources to provide virtually uninterrupted
power to sensitive electronic equipment.
Power Quality Protection
For applications requiring protection from electrical line
disturbances without the need for back-up capability, Liebert
manufactures a full line of power conditioning equipment. It
includes a wide variety of transient voltage surge suppression
(TVSS) solutions ranging from high-quality surge suppressors
for use with PCs, workstations and other peripherals to
facility-wide systems with sophisticated active tracking
capability. Other products include power conditioning systems
featuring high-efficiency magnetic synthesizer technology
and isolation transformers to reduce line noise and other
power line problems.
DC Power Systems For Communications Applications
From major switching centers to remote shelters, Emerson DC
power systems offer performance and features to match virtually
every telecommunications equipment application. The line
includes a variety of system capacities ranging from small
systems at less than 3 kW up to large systems rated at over
60 kW. The product offering also includes distribution bays,
enclosures and network management products such as
controllers, monitors and supervisory software to control and
maintain energy equipment in a telecommunications network.
Power System Monitoring
Liebert’s family of power communications software and
hardware provides multiple levels of monitoring and control.
Capabilities range from automated shutdown software to
facility-wide centralized systems that provide a full range of
monitoring, control and analysis.
The Widest Range Of Products Gives You An Infinite Range Of Solutions
A Comprehensive Power Solution—We’re The Only One Who Has It

There Is A Liebert Power Solution To Meet Every Need
CONTENTS
Computer Rooms
Data Centers Network Closets Production
Labs & Testing
Telecom / CATV
Emergency Shelters
Desktops / Peripherals Point Of Sale
Mission-Critical Application Zones
3
1 Racks, Integrated Cabinets, Rack Power Distribution
10-11 Knurr rack enclosure system nnnnnnn n
12 Liebert MCR Mini Computer Room Enclosure nnn nnn n n
13 Liebert MP Advanced power strips & Knurr DI-STRIPs nnn nnn n n
2 Desktop UPS For One-On-One Applications
14 Liebert PSS surge protection strip n n
15 Liebert PSA line-interactive UPS n n
3 Rack-Mount UPS For Distributed Network Applications
16-17 Liebert PSI and PSI-XR line-interactive UPS n n nn
18 Liebert GXT2, 500-3000VA on-line UPS n n n n nn n
19 Liebert GXT2, 6 and 10 kVA on-line UPS n n n n n n
4 Enterprise UPS For Computer Room And Data Center Applications
20 Liebert Nfinity on-line UPS n n nnn n n
21 Liebert NX, 10-30 kVA on-line UPS n nnn n n
22-23 Liebert NX with Softscale, 40-200 kVA on-line UPS n n n n n n n
24 Liebert Npower on-line UPS nn nnn n n
25 Liebert Series 610 on-line UPS nn nnn n n
26-27 Liebert NXL on-line UPS nn nnn
28-29 Liebert FS flywheel DC energy storage nnnnn
5Power Distribution Systems For Critical Protection Applications
30 Liebert FDC power distribution cabinet nn n n
31 Liebert RDC remote distribution cabinet nn n n
32 Liebert FPC power conditioning & distribution cabinet nn n
33 Liebert Precision Power Center power conditioning and distribution cabinet nn n
34 Liebert STS2 static transfer switch nn nn
35 Liebert STS2/PDU static transfer switch/power distribution unit nn n
6 Surge Protection And Power Conditioning Systems
Surge Suppression
36 Liebert AccuVar transient voltage surge protection nnn nnn nn n
36 Liebert Hybrid Advantage surge protection nnn nnn nn n
36 Liebert Interceptor transient voltage surge protection nnn nnn nn n
36 Liebert LM Series surge protective device nnn nnn nn n
37 Liebert Type SS surge protection nnn nnn nn n
37 Liebert Panelguard Extension panelboard surge protection nnnnnnnn n
37 Liebert Specialty Surge Protection Devices nn nnn nn n
7 DC Power Systems For Telecommunications Applications
38-39 Small Power, Medium Power, Large Power, Inverter Systems, Batteries & Accessories nnn nnn n n
8 Monitoring And Control
40 Liebert Intellislot, Liebert Nform & Liebert SiteScan Web nnnnnnn

Every operation in your business depends upon the instant, around-the-
clock availability of computers, servers and other electronic systems. If they
aren’t working, neither is your company.
Unfortunately, every piece of this equipment your company possesses is
subject to the whims of the electricity that powers it.
The first step in taking control of this situation is to understand the threats
to your system reliability—and exactly what you can do about them.
You Face Many Challenges In The
Pursuit Of Productivity
Is There Really A Problem?
“My computer can ride right through a short blip in the
power—why do I need anything else?”
There Are No Simple Solutions
“I have people telling me all I need to do is plug each
workstation into a small UPS from the computer store .
That’s good enough, isn’t it?”
Different Needs Require Different Power
Protection Configurations
“Should I have a small UPS for each workstation or
have everything on one large system . Which is best
for my facility?”
A Lot Can Happen Between Your UPS And
The Equipment It Is Protecting
“We have dozens of pieces of networking equipment. How
can I make sure that each one is getting exactly the power
it needs?”
Every Wire Carries The Potential
For Trouble
“An electrical surge came in through an outside phone line
and knocked out our entire communications system. Is this
going to happen again?”
A Single Source Of Power Simply May
Not Be Enough
“Adding a second power feed would certainly enhance our
availability picture—but who can we talk to about getting
it done right?”
4
Trouble Is Coming Down The Power Line And You Must Be Prepared

But There Are Real Solutions
You Need Protection From All Power Problems
An outage is just the problem you can see. There are many other more frequent power fluctuations—surges, spikes, sags—
that you don’t see. These are the conditions that cause the “unexplained” lock-ups and other potentially damaging results.
“Out-Of-The-Box” Can Put You Out Of Business
Buying a simple off-line UPS down at the computer store may be a good solution for your home PC, but it just doesn’t make
sense when your business and productivity are on the line. Protecting critical network and computing systems requires the
expertise of someone who understands all the risks you face from poor power quality.
Centralized Vs. Distributed UPS Protection
Liebert has the breadth of products that allows you to implement either a centralized or a one-on-one distributed power
protection strategy depending on your requirements. Whatever configuration you choose, you can count on Liebert to
make it the best it can be. Benefits, such as increased system security, more efficient maintenance and improved reliability,
may make a centralized strategy a better choice for larger operations.
Proper Power Depends On Proper Distribution
In network applications, there may be hundreds of different loads with various voltage requirements, a mix of AC and DC
power, plus any number of other electrical specifications. This calls for a distribution system that is designed to maintain the
highest levels of reliability and quality between the source of conditioned power and the protected equipment.
Power Conditioning And Surge Protection Throughout The Facility
Power conditioning and surge suppression systems are key to maintaining power quality in critical facilities. Raw utility
power is often far too “dirty” for sensitive systems, resulting in lost or garbled data, unexpected software glitches or
shutdowns, even hardware damage. The IEEE recommended practice is to install transient voltage surge suppression (TVSS)
protection on every electrical conductor that penetrates a facility shell, including power lines, telephone and other
communications links.
Maximum Reliability Demands Dual Power Sources
If your needs require the highest level of system availability, Liebert has the knowledge and products to implement a dual-
power strategy throughout your enterprise. UPS, transfer switching, power distribution and other equipment are all
brought together to create the ultimate in reliability.
5

6
Where Do You Need Mission-Critical
Power Protection Technology?
We have power solutions for any of
the applications that are part of your
mission-critical business operations.
Liebert has identified ten distinct zones or areas of application, found
within many business operations, which have a requirement for mission-
critical power technology. While these zones have similarities in the
importance of their essential functions, they also have different needs for
infrastructure protection—all of which can be met by Liebert solutions.
Large Data Centers—High
availability data and network
applications are the heart of your
enterprise with blade servers and
high-density racks that demand
increased power protection.
Small To Mid-Size Data Centers—
Smaller sized network and
computer facilities, but equally
essential to your operations.
Network Closets—Housing
routers, switches, modems, cabling
devices and numerous other
communications components.
Network Operations Centers—
As networks expand and grow
more complex, you need reliable
and timely access to mission-
critical infrastructure monitoring
information long before
problems arise.
Production—Smart factories
backed by a complex electronic
network, from computer-controlled
machinery and processes to
electronic sensors, business
systems and utility equipment.
Laboratories and Testing—
Sensitive computers and
equipment used for diagnosing
patients, analyzing data,
performing critical tests, and
operating electronic tools and
lab instruments.
Telecom/CATV—Anything from
indoor and outdoor spaces hosting
cable, DSL and fiber optics to
remote cell sites and enclosures.
Emergency Shelters—Emergency
operations centers, 911 response
emergency dispatch, police and fire
facilities, medical facilities, public
works operations and more.
Desktop/Peripherals—Home and
small office computers, modems,
network components and other
electronic equipment that is vital
to business operations.
Point-of-Sale—Today’s cash
registers and store-level computer
networks not only handle sales
transactions, they also collect
and transmit vital customer and
inventory data required to make
informed supply chain decisions.
Biotechnology
Industry
Retail
Distribution
Industrial
Computer
Systems
Health Care
Government

7
Network Operations
Centers
With many mission-critical
computing systems located
right in the office space,
there is a need for UPS
protection that can be
placed nearby. Liebert offers
a number of power systems
that are especially designed
for use in business and office
environments.
Small to mid-size
Data Center
Liebert offers the full range
of UPS, distribution systems
and other power protection
equipment that can adapt
to data center growth
requirements.
Production
Liebert UPS, surge protection and power
distribution are all key to maintaining the
proper operation of process control and
other manufacturing systems that utilize
microprocessor and computer control.
Mechanical Rooms
Liebert power protection and conditioning
systems can greatly improve the operation
of electrical switchgear and motor control
centers vital to numerous functions
throughout an industrial facility.
Telecom Wireline/Wireless Sites
Liebert can provide a reliable flow
of both AC and DC power for
telephone switching systems and
other communications equipment.
Emergency Shelters
High-reliability Liebert UPS systems and DC
power equipment are critical to maintaining
operations in telecommunications shelters
and other unmanned structures.
Data Center
Liebert offers the full
range of UPS, distribution
systems and other power
protection equipment to
meet the needs of the
largest data centers and
networking facilities.
Network Closets
These densely-packed equipment
bays, housing servers or other
essential communications devices
require UPS back-up plus distribution
to get uninterrupted, conditioned
power to each and every component
in the rack.

The Liebert Adaptive Architecture combines the
advantages of modularity and scalability to create a
power infrastructure that delivers unparalleled benefits.
Advancing technology, new applications and more
demanding users are driving changes across the
network. Changes that are shaping your ability to
manage availability and costs—today and in the future.
Liebert’s Adaptive Architecture for IT infrastructure
uses components and system configurations that are
designed to accommodate changing technology and
application requirements, enabling higher levels of
equipment protection, lower cost of ownership and
simpler IT management.
The Adaptive Architecture is enabled by the
combination of Liebert technology, application
expertise and organizational commitment. Liebert
offers the industry’s broadest range of mission-critical
power, cooling and monitoring solutions, which serve
as the building blocks of an adaptive architecture.
No One Has More Real-World Experience
Than Liebert
The Liebert Adaptive Architecture is the result of more
than 40 years experience in the development and
application of mission-critical power and cooling
systems. Our resources include knowledgeable
leadership, as well as an outstanding staff of research,
design, application and service engineers using the latest
technological tools.
These corporate capabilities are backed by the
unmatched expertise of your local Liebert
Representative, Distributor or Solutions Partner. We are
the only company in this business that maintains such a
strong local presence on a national and international
basis. Specifying and maintaining a high availability
power system requires someone who is knowledgeable
in all phases of critical systems protection.
This resource, coupled with our broad adaptive product
line, gives Liebert the ability to create a solution that will
meet your protection needs precisely and efficiently. We
don’t have to take the one or two items we happen to
have and stretch them to come up with the answer. We
give you the best answer every time.
The Liebert Adaptive Architecture:
The Power Needed Today. The Flexibility Demanded Tomorrow.
8

Only Liebert can bring together all of the critical
power protection solutions you need to create
system availability that is as close to 100% reliability
as possible.
We use the industry’s widest range of product
solutions and apply them in a way that delivers
flexibility and availability. This philosophy is further
demonstrated by a research and development
strategy that extends the life of current
technologies and ensures new technologies work
with existing systems.
The Liebert Adaptive Architecture Offers
Three Primary Advantages:
Flexibility—The building blocks that comprise an
Adaptive Architecture can be reconfigured to meet the
demands of new technologies or achieve higher tiers of
protection, giving the power to adapt to change from
growth, new technologies or changing business
requirements.
Higher Availability—Proven mission-critical
technologies and system designs that minimize single-
points-of-failure produce the highest possible availability
of your IT systems.
Lowest Total Cost of Ownership—The higher
availability alone gives the Liebert Adaptive Architecture
a big edge in TCO. Factor in expansion, support,
operating and replacement costs and the advantage is
overwhelmingly in Liebert’s favor.
9

Knurr’s broad platform of rack
systems will integrate with cooling
and power management
technologies from Liebert, helping
you solve problems in new and
existing installations and giving you
more design flexibility. Knurr and
Liebert are taking proven
technologies from room-level
applications and integrating them
with the rack.
Knurr Racks Are Ideally
Suited For:
n Data centers
nNetwork closets
nTelecommunication equipment
Emerson Network Power’s Knurr, a
world leader for standardized rack
systems, has joined with Liebert to
build comprehensive capabilities in
rack solutions, mission-critical
cooling, and systems integration for
data center and telecom sites.
410
Knurr Racks And Cabinets
Knurr racks provide the
convenience of robust 19” racks
with high end features and
standardized options to provide
fast customization for individual
site needs. The racks are designed
for optimized air flow and
maximized useful mounting space.
Ready-to-deploy rack and
enclosure solutions.
Roof Pre-Drilled
For XDV
Accepts XDV With
No Need For
Drilling
83% Open Area
For Improved
Airflow, Highest In
The Industry
Lightweight
Aluminum
Frame
Makes The
Cabinet Easier
For A Single
Person To Move
Tool-Less Shelf
Mounts In
Square Holes
On 19” Rails In
Seconds
Z Shaped Rail
19” Rail With
Additional
Functionality
Including Cable
Management
and Power Strip
Doors Open to
180˚
Allows Easy
Access To
Cabinet,
Without
Removing The
Door
Spring Nut In
T-Slot
Allows Component
Mounting
Anywhere In
Cabinet Frame
Powerstrip On
Frame
Offers Another
Zero U
Powerstrip
Mounting
Option
The Right Place To
Protect Network
Equipment

5
RACK ENCLOSURE SYSTEMS
1
Knurr Miracel®Open Frame And Server Racks
Knurr Miracel racks are tailored to your requirements.
The platform technology provides the basis for a
versatile range of racks, which has been setting
standards in the world of IT, telecommunications and
network technology as the solution for a diverse
range of requirements.
The design of the Knurr Miracel product line enables
all requested dimensions and standards to be tailored
to specific customer requirements. Adjustments can
be easily made thanks to the broad range of Knurr
accessories, including active and passive
components, need-oriented power supply and
distribution, cable management and scalable thermal
management options.
The range of products runs from open racks to closed
cabinets, EMC-shielded to heavy-duty racks with a
static load of up to 2000 lbs. All are equipped to
meet the most diverse customer needs. The racks are
lightweight yet stable, easy-to-assemble and offer
numerous configuration possibilities.
Key features include:
nAluminum construction — Patented extruded
aluminum frame allows for easy mounting of
components, and offers high flexibility and stability
without excessive weight.
nT-slot system — Simple installation of many
components—anywhere in the frame.
nLockable doors — Offers physical protection for
components against unauthorized access.
nCable management — A complete cable
management system assures optimum cable routing
and includes an extensive range of accessory
components to help manage cabling effectively.
nVented roof — A vented roof also offers
generous cable entrance.
11

412
Liebert GXT2
on-line UPS
ECM
(Environmental
Control Module)
BCM
(Back-up Cooling
Module)
Secure Door
lockable door
provides an extra
measure of
security by limiting
access to critical
equipment.
Sealed Door
specially designed
rubber gasket
provides NEMA12
sealing protection.
Where a minimal
amount of equipment
is needed, the
Foundation 44” tall
enclosure provides
compact protection.
Dual-Split Rear
Door available
Bundled UPS
systems available Wall Mount Systems
12 U Hinge Body
“swing out” and 12”
depth Low Profile
available.
Internal Power
Distribution
A wide range of
installed power strips
is available to better
accommodate power
distribution needs
within the enclosure.
EX Cable
Management
Channel
This versatile option
helps to enhance
cabling organization
and internal airflow.
True On-Line Power Protection
Protecting The Edge
Of The Network
Liebert has brought together several of our
product solutions to create the IP Telephony
Availability System. Especially designed to
protect switches, routers and other critical
components, this solution is ideal for use in
remote locations such as branch offices,
retail stores and other edge of the network
applications. Housed in a Liebert
Foundation™wall mount enclosure or
freestanding enclosure.
The Liebert UpStation®GXT 2U, a true
double conversion UPS, delivers the high
level power quality required to fully protect
critical network switching components from
all power problems. Available in sizes from
700 up to 3000 VA.
Continuous Power Availability
In most cases, your critical routers and other
network components cannot be without
power even for scheduled UPS maintenance.
To meet this need, the Liebert 2U Power
Output Distribution (POD) system ensures
continuous uptime by providing
maintenance bypass capability as well as
power output distribution.
Power System Monitoring,
Communications &
Remote Control
The Liebert Webcard,
housed within the UPS,
will deliver SNMP and
web-management communications
capabilities to your power system, including
the ability to remotely reboot the switch by
cycling the UPS power off and on.
The Liebert IP Telephony Availability System, version 1.0, has
met the Cisco Technology Developer Partner Program test
criteria for interoperability with Cisco CallManager Express 3.1,
Cisco Unity Express, release 1.1.2, Cisco Unity 4.0 (3), and Unity
Bridge 3.0 (2).
Liebert MCR
Mini Computer
Room Enclosure Liebert IP Telephony
Availability System

513
RACK ENCLOSURE SYSTEMS
1
Rack Power Strips
Liebert MP Advanced
Power Strips
Liebert MP advanced power strips
are designed to distribute and
manage power within network
cabinets and server racks. Models
are available with remote
monitoring and/or control
capabilities for power distribution
at the load/equipment level.
Liebert MP Advanced Power Strips
are offered in multiple
configurations that provide a
choice of capacities and number of
receptacles, as well as monitoring
and control capabilities to meet
the power management
requirements of any rack-mounted
equipment. Liebert MP Advanced
Power Strips monitor electrical
attributes of an individual power
strip, including real-time remote
and local display of total strip true
RMS volts, amps and watts.
Knurr DI-STRIP®Power Strips
Knurr DI-STRIP®Power Strips meet a broad range of
power distribution requirements for IT and other
applications. Designed especially to handle the growing
number of electronic components that can be housed
within network cabinets and server racks, the space
saving product line is available with a range of
accessories including circuit breakers, overvoltage
protection—and more.
The Knurr DI-STRIP®Classic power strip offers cost-
efficient power distribution for a wide variety of rack
applications utilizing NEMA5-15R receptacles.
Flexible power distribution for IT
racks and cabinets.

14
Liebert PSS Surge Protection Strip
Protection For
Desktop And
Small Network
Applications
One-On-One Protection
The Liebert family of products
includes surge protection strips
and line-interactive UPS to give
you a real choice in desktop and
network component protection.
Liebert Products Offer
One-On-One Power
Protection Solutions For:
n Home And Small Office
Desktop PCs
nNetwork Workstations
nNetwork Routers, Bridges
And Hubs
nPoint-of-Sale Terminals
nOther Sensitive Electronics
Liebert desktop power solutions are
designed for applications where one
or a few pieces of equipment require
surge suppression or basic power
protection with battery back-up.
Liebert PSS Surge Protection Strips
provide computer grade power,
protecting connected equipment from
the damaging effects of lightning,
spikes, surges, and other power quality
problems. Two models are available:
PRF 1080 Professional Series provides
protection for 8 standard 3-line
receptacles; the Liebert NET 1080T
Network Series includes phone line
protection.
Liebert PSS Offers A Variety Of
Standard Features:
nEight surge protected outlets
nSpacing provided for wall mounted
transformers without covering other outlets
nLightning and surge protection
nIncludes EMI/RFI attenuation for improved
power to connected equipment
nWider input voltage window
nAudible alarm sounds if surge protector is no
longer protecting the connected equipment
nTwo-year warranty
Surge Protection For Professional Equipment And Network Phone Lines
Net 1080T
Includes complete phone and
network surge protection

DESKTOP UPS
2
15
Liebert PSA Line-Interactive UPS
Liebert PSA is an economical line-
interactive UPS that offers full-
featured power protection for small
office computers and electronic
equipment. It is available in the
following sizes: 500, 650, 1000 and
1500 VA at 120 VAC or 230 VAC.
Designed with simple controls for
easy operation, the Liebert PSA
provides up to five minutes of back-
up time at full load...more than
enough time to save work in
process and shut down your
connected equipment. USB
shutdown software and a USB
cable are also included, to allow
remote alerts and automated
graceful shutdown of the
connected systems. Liebert PSA
offers unique features and
extraordinary performance not
normally found in similar products
in this price range.
Other Standard Features Included On
All Liebert PSA Models:
nThree to six battery-backed UPS outlets,
depending on model size.
nOne to two surge-only outlets, differentiated by
color.
nUp to five minutes of battery backup time at full load
nUser replaceable batteries
nFull-sequenced battery testing
nLightning and surge protection
nAdvance early warning of UPS shutdown
nRJ-45 port for data line surge protection
nSite wiring fault indicator
nTwo-year warranty
High-Performance Power Protection For PC’s And Office Equipment
Liebert Power Monitoring
Capabilities
The operation of the Liebert PSA
can be monitored using:
nLiebert MultiLink®Automated
System Shutdown Software
nThird Party Monitoring System
For more information,
see pages 40 and 41.
1000/1500 VA back view
500/650 VA back view

416
Liebert PSI And Liebert PSI-XR Line-Interactive UPS
Rack-mounted servers are at the
heart of today’s network computing
systems. These critical components
need reliable, compact power
protection that will keep pace with
their growing needs.
Protection That Fits
In Anywhere
From line-interactive units to true
on-line models, Liebert rack-
mount UPS systems are designed
for reliability and space-saving
flexibility. No one packs more
power capacity and features into a
smaller package.
Liebert Has Rack-Mount
UPS Solutions For:
nPCs
nNetwork Workstations
nServers and Critical Nodes
nNetwork Routers, Bridges and
Hubs
nLarge Network Peripherals
nNetwork Closets
nVoIP
nStorage Systems
nPoint-of-Sale Terminals
nTest Equipment
nOther Sensitive Electronics
Other Standard Features Of Liebert PSI
and Liebert PSI-XR:
nSeven to eight battery-backed outlets
n0.9 Output Power Factor
nRotatable display panel
nAutomatic frequency sensing
nWider input voltage window
nData line surge protection for telephone/fax/
DSL/modem
nAdvance early warning of UPS system status
nUser-replaceable hot swappable batteries
nGreater than five minutes of battery backup time at full
load when utility fails
nExternal battery cabinet available
nFull sequenced battery testing
nLightning and surge protection
nUSB communications
n Serial and contact closure communication option
nRemote emergency power off
nRack rail kit
nTwo-year warranty
Designed for the IT environment,
Liebert PSI UPS and the Liebert
PSI-XR extended battery model
are slim 2U sized rack/tower style,
line-interactive UPS systems. They
offer configurable input voltage
windows allowing the customer
to precisely match their input
voltage. A choice of
communications options includes
serial, contact closure and USB.
Available in 750, 1000, 1500,
2200, and 3000 VA in 120 and
230VAC models.
Proven high-level performance and reliability for server and network power protection.
Rack-Mounted
Power Solutions
For Growing IT
Networks

517
RACK-MOUNT UPS
3
Liebert PSI-XR
Line-Interactive UPS
With Extended Battery
Option
Liebert Power Monitoring Capabilities
The operation of Liebert PSI can be monitored using:
nLiebert MultiLink®Automated System Shutdown Software
nLiebert Nform Monitoring System
nThird-Party Monitoring Systems
For more information, see pages 40 and 41.
RS232
(DB-9)
Port
Voltage
Configuration
DIP Switch
EPO USB
Port
RJ-45
Data Line
Connectors
External
Battery
Connector
Power
Cord
Liebert
Intellislot
Port
Input
Circuit
Breakers
Output
Circuit
Breakers Receptacles
Liebert PSI-XR is a compact, line-interactive
UPS system designed especially for IT
applications such as network closets and
small data centers. It provides reliable
power protection for servers, critical nodes,
network workstations, large network
peripherals, network routers, bridges, hubs
and other electronic equipment. Matching
battery cabinets are available to extend the
on-battery operating time. Optional External Battery Cabinet
Add up to six cabinets for additional runtime
UPS With Internal Battery
Optional Liebert MicroPOD 2U POD output
distribution and maintenance bypass module ensures
continuous uptime, even during UPS maintenance.

418
Optional Liebert MicroPOD 2U POD
output distribution and maintenance
bypass module ensures continuous
uptime, even during UPS maintenance.
Liebert GXT2 leads the industry in combining small
size, high capacity and multiple features. Designed to
be either rack-mounted or installed in a tower
configuration, the UPS is available in 500, 700, 1000,
1500, 2000 and 3000 VA ratings, in both 120 V and
230 V models.
A true on-line UPS, Liebert GXT2 includes features
such as power factor correction, internal batteries,
frequency conversion, unlimited external battery
connectability and internal bypass capability. And all
this is housed in a smaller 2U size cabinet that cuts
space requirements in half while providing up to 3 kVA
of true on-line power… batteries included. The UPS
can also be used with external batteries for extended
run times.
A Windows™configuration program, included with
each unit allows the user to program a variety of
operating parameters. This capability allows you to
customize Liebert GXT2 performance to your specific
requirements, providing a new level of power
protection control and adaptability.
Other Features Of Liebert
GXT2 2U Models:
nMicroprocessor-based control and
monitoring package
nInput power factor correction
nPWM inverter
nIntegral dynamic bypass
nIntegral sealed, flame retardant,
non-spillable, user replaceable battery
nAutomatic and manual battery test feature
with push button and indicator
nInput and output noise suppression
nRS232 communication port
nLiebert IntelliSlot®communications port
nTwo-year limited warranty
Liebert GXT2 500-3000VA On-Line UPS
Compact UPS combines on-line
reliability, configurability and
internal batteries.
Liebert Power Monitoring Capabilities
The operation of the Liebert GXT2 can be monitored using:
nLiebert MultiLink®Automated System Shutdown Software
nLiebert Nform Monitoring System
nLiebert Universal Monitor and Remote Power Monitor Panels
nThird-Party Monitoring Systems
For more information, see pages 40 and 41.

519
The Parallel POD
enables paralleling of two Liebert GXT2 10 kVA UPS
modules to double capacity to 20kVA. A third unit
may be added to configure the system for N+1
redundancy, raising system reliability.
High capacity, compact on-line UPS with flexible output voltage and power distribution.
RACK-MOUNT UPS
3
Other Product Features Of Liebert GXT2 6 & 10 kVA
UPS Models Include:
nWider input voltage window enables the UPS to support the critical
load without having to transfer to battery
nPatented output neutral bonding feature meets UL 1778 standard
by providing a method for maintaining the UPS output neutral to
ground bond in all modes of operation
nInternal bypass assures continuity of power to critical loads during
system problems or maintenance
nAutomatic frequency detection matches line input frequencies of
either 60 or 50 Hz
nUser-replaceable hot swappable internal batteries provide five
minutes of runtime at full load
nAdditional battery cabinets available for extended backup time
nLiebert IntelliSlot® communications port utilizes Liebert IntelliSlot®
Web Card to provide SNMP and web-based management
Liebert Power Monitoring Capabilities
The operation of the UPS can be monitored using:
nLiebert MultiLink®Automated System Shutdown Software
nLiebert Nform Monitoring System
nLiebert Universal Monitor and Remote Power Monitor Panels
nThird-Party Monitoring Systems
For more information, see pages 40 and 41.
User replaceable
hot swappable
internal batteries
Liebert GXT2 6 & 10 kVA UPS systems provide true
on-line protection in the smallest cabinets in their
capacity range. The UPS systems offer internal
batteries, unlimited extended external batteries, and
internal bypass capability, resulting in continuous
uptime for the connected equipment. This makes
the UPS an ideal fit in applications where the
power requirements are demanding—but rack
space is limited.
Application versatility is achieved through the use of
a dual inverter design capable of providing
simultaneous output voltages of 240/120, 208/120,
230/115, 220/110, or 200/100 VAC. The input is
power factor corrected to approximately .98,
enabling the UPS to power a wide variety of
equipment with different voltages.
For installation flexibility, you may choose from
several different wiring configurations made possible
by the use of removable power distribution boxes
that simply plug into the rear of the UPS. Options
include hardwired or receptacle connections, as well
as maintenance bypass capabilities.
Liebert GXT2 6 & 10 KVA On-Line UPS

420
The need to safeguard critical
operations from power problems can
be solved through the use of large-
scale UPS systems.
A Powerful Defense
Against Uptime Threats
Liebert offers a full range of
enterprise power protection
solutions for any size facility from a
small computer room to the largest
data and communications centers.
Liebert Enterprise UPS
Solutions Are Ideal For
nLarge-Scale Data Centers
nFacility-Wide Networks
nLarge-Scale Telecommunications
Centers
nColocation Facilities
nInternet Data Centers
nServer Farms
nData Warehouses
nNetwork Management Centers
nMedical Imaging Equipment
nTest and Laboratory Facilities
nIndustrial Process Control
Operations
Liebert Nfinity® UPS
The Liebert Nfinity power system is a scalable 4
to 16 kVA or 12 to 20 kVA UPS designed with N+x
parallel redundancy to provide a fault-tolerant
network of power protection.
The modular design of the Liebert Nfinity power
system was devised to provide easy scalability to
users as their power demands grow. Configurations
can be cost-effectively upgraded without re-
investing in a new system or installation.
The Liebert Nfinity is a true on-line, double-
conversion UPS that provides 100% power
conditioning, zero transfer time to battery, no
change in output voltage and better transient
suppression than line-interactive units.
Its unique frame design houses all of the modular
system components, including 4 kVA power
modules, battery modules and system control
modules. By simply installing additional power or
battery modules, you can expand your current
system, extend backup runtime or add redundancy.
nIntelligent power modules provide protection
from all power aberrations, and a patent pending
electrical current-sharing technology provides
equal distribution of power among all modules.
nThe IntelliBattery™modules utilize multiple
sensors to continuously monitor battery voltage,
current and temperature to determine and
predict performance.
nThe IntelliControl™module works with the user
interface to provide vital information about the
condition of the power and battery modules.
A True On-Line System That Delivers
Continuous, Regenerated Sinewave
Output Power
Protecting The
Enterprise: High
Availability UPS
Protection For
Mission-Critical
Applications
Additional Features Of The
Liebert Nfinity Power
System:
nHot-swappable modules allow the
user to replace modules or
upgrade the system without
disturbing connected equipment
nContinuous self-diagnostics detect
and isolate faults to prevent
cascading system failures, as well
as to simplify maintenance and
troubleshooting
nPatent pending intelligent bypass
technology provides seamless
transfers to and from the bypass
source
nWide input voltage window
minimizes battery operation to
maximize battery life
nFully assembled and factory-
tested, simple to install and ready
for use for a plug-and-play solution
that is functional right out of the
box
nAdditional battery cabinets can be
added for backup times up to 72
hours
nTwo-year limited warranty for
repair or replacement with
warranty extensions also available
