EMIX EMRM-811 User manual

EMRM-811
Universal Mixer
OWNER’S MANUAL
Before operating, please read this manual completely.
FEATURES
5 microphone inputs, 3 auxiliary inputs, 2 priority inputs, 2 outputs.
Muting function.
Individual volume control.
Bass and Treble tone control.
Built in chime generator 。
。。
。
Professional Public Address System

2
Left blank for memo

3
FRONT PANEL
Power switch(1 is power on and the
“power LED” is on ).
Led Power Indicator.
Bass control.
Treble control.
AUX3, 2, 1 volume control.
MIC5, 4, 3, 2, 1 volume control.
⑦ MIC1 input.
⑧ CHIME button.
REAR PANEL
MIC2, 3, 4, 5 inputs.
EMC1, 2 inputs.
AUX1, 2, 3 inputs.
Output jacks.
DC24V Power input
AC fuse
⑦ AC power input
MUTING FUNCTION
The MIC input 2, 3, 4, 5 and AUX input 1, 2, 3 automatically muted by EMC input 1, 2. (EMC
1or 2input overrides the MIC2, 3, 4, 5 and AUX 1, 2, 3 signals).
The MIC input 2, 3, 4, 5, AUX input 1, 2, 3 and EMC1, 2 are automatically muted by MIC1
input (MIC1 input overrides the other input signals).
① ② ③ ④ ⑤ ⑥ ⑦ ⑧
①
②
③
④
⑤
⑥
⑦

4
CONNECTIONS
SPECIFICATIONS
Inputs Mic1, 2, 3, 4, 5: 600Ω, 2.5mV, balanced
Aux1, 2, 3 : 10kΩ, 250mV, balanced
Audio output 0dBV
Frequency response Mic: 100Hz-10kHz; Line: 20Hz-18kHz (±3dB)
Signal/ noise ratio Mic input : 72dB
Aux input : 80dB
Tone Bass : ±10dB at 100Hz
Treble : ±10dB at 10kHz
Protection AC fuse
Power Requirement AC240V/50Hz, DC24V
Dimensions 485×88×365mm
Gross weight 6.5kg
Net weight 5.2kg
Specifications are subject to be changed without notice.
CAUTION
● When the “Power switcher” is off, please pull out the power cord from the socket.
Please keep the equipment out of water.
● To reduce the risk of electric shock, do not remove the cover.
● No user parts inside. Refer servicing to qualified service personnel.
POWER AMP
MP-series
TUNER EMC DECK CD
PRIORITY
MIC
OUTPUT AUX3 AUX2 AUX1 EMC2 EMC1 MIC
CHIME
