EMMO CAOFEN-F80 User manual

www.emmo.ca
Toll Free: [phone]
Email: ser[email protected]
Find Emmo dealer near you:
https://emmo.ca/pages/locations
EMMO CAOFEN-F80

Congratulations on your choice to acquire the
EMMO CAOFEN-F80 series electric motorcycle,
which incorporates years of technological
advancements in alloy material research, core
component manufacturing, and integrated
electric drive. As the proud owner of this cutting-
edge electric motorcycle, you can expect long-
lasting enjoyment with proper maintenance. This
manual aims to provide you with a comprehensive
understanding of the model's fundamental
features and operational skills. Should you
encounter any operation or maintenance
concerns not addressed in this manual, please
feel free to reach out to EMMO Manufacturing
Company or your local distributor for assistance.
This instruction manual contains important information,
precautions, warnings and hazard notes for the use of the
vehicle. The illustrations in the manual may differ slightly
from the vehicle in detail, but the principles described are
the same.
EMMO CAOFEN-F80 electric motorcycle has always
maintained high-quality standards, due to the unremitting
pur- suit of product quality and the continuous indepth
research and improvement of product design. The in-
formation provided may not be the same as your ve. hicle
information without further notice.
For more detailed information about EMMO CAOFEN-F80
and the use and maintenance manual, please enter the
EMMO official website: WWW.EMMO.CA ; or scan the
EMMO ofcial QR code on the last page.
Important safety information:
WARNING
Introduction

Open steps and Assemble
Important
Information
Failure to observe the contents of the manual may lead to ser-
ious injury or death!
This manual and its important information are marked as fol-
lows:

Parts Ready: Front axle, front axle lock nut, 2 pieces front wheel
bush 1.First install a bush on the left (From the drivers' view) of the
front wheel, place the big head on the front wheel and small head
toward the shock absorber, and then take the front axle little head
from shock on the left to right across the suspension, front wheel
bushing, the front wheel, wheel bushing, shock absorb, and then put
the former wheel lock, nut lock and then in turn lock before cutting
on the front wheel lock screw tied.
2. Front brake installation: remove the yellow fixed stop plat
hydraulic brake pump, clamp the brake disc on the front hub into the
brake clamp of the lower brake pump, pinch the right brake handle,
tighten the installation bolt of the lower pump, and then release the
handle.
Assemble front
wheel:
Warning
Assemble of Handlebar

Assemble Speedometer and
front Turn signal
Speedometer and front turn signal
1. Handlebar
2. Speedometer
3. Speedometer rubber pad
4. Front turn signal
5. Turn signal lock nut and sleeve
6. Headlight bracket
7. Speedometer wire harness and rubber sleeve
8. Headlight
9. Speedometer lock nut M6
10. Speedometer rubber pad
Tip: The F80 electric motor-
cycle you buy may be differ-
ent from the description in
this manual
3. Speedometer and indicator light

EMMO authorized dealer as soon as possible.
Warning
Warning
5. D Current motion mode: Press the N/D button on the right brake handle to control the
entering sports D gear. The light is either always on or off. If it is always on, it means
that it has entered the current gear and the vehicle can be driven. If it is off, it means
the vehicle is in the neutral position.
6. Energy recovery indicator light:
Steady on: The energy recovery is in the auxiliary braking mode. After the braking sig-
nal is detected, energy recovery is added after a delay of 20 milliseconds or when the
vehicle speed drops by 10%.
Flashing: Energy recovery occurs during the throttle release phase. Off: Energy recov-
ery is turned off.
7 .Driving READY light: The one-key start button controls the light to turn on or off. The
vehicle can be driven when it is always on, and the vehicle cannot be driven when it is
turned off.
8.Off: Sucient power. Steady on: Insucient power. Flashing: Low power, the battery
needs to be charged as soon as possible.

Directional combination switch
Right handlebar switch combination
Front and rear shock adjustment
(Right and left shock)

Front and rear shock adjustment. Front and rear shock adjustment
(adjusted shock assembly)
Special tools are required for preload of shock absorber springs after
adjustment. If adjustment is required, please use your local EMMO authorized
distributor to provide such services for you.
Warning
Note:

Front Part

13. Front tire 22. Chain
14. Front Rim Assy. 23. Rear damping
15. Front brake disc 24. Rear wheel
16. Front brake caliper 25. Rear Rim
17. Front mud guard 26. Rear sprocket
18. Front shock absorber 27. Rear fender rear section
19. Horn
20. Battery pack
21. Battery bottom protective cover
Left Side
Right Side
Frame Inside
28. Rear guard bracket
29. Rear brake disc
30. Chain Adjuster
31. Rear brake caliper
32. Rear fork
33. Rear guard front part
34. Taillight
35. Seat bracket
36. Seat
37. Frame
38. Steering
39. Chain caliper
40. Motor
41. Controller
42. Alarm
43. DCDC converter
Operation and driving of EMMO CAOFEN-F80 electric motorcycle
Step to start the vehicle:
Steps to turn off the vehicle:
When the outdoor temperature is below 0°C, the low temperature protection
of the battery system may be triggered. Please charge the battery before using
it; otherwise, the vehicle may not run normally. When the meter displays a fault
code, please check the fault code displayed on the meter according to the
description in this manual, and consult the local EMMO dealer for treatment as
soon as possible.
Warning
Dangerous

When the speedometer lights up, it may be impossible to directly
power off the alarm key, so we can directly turn off the battery
switch. In this case, please check the fault code displayed on
the instrument according to the description in this manual, and
consult the local EMMO dealer for treatment as soon as possible.
The temperature of the motor may be very high after the vehicle is
stopped, please cool it before touching it.
The failure of the speed control knob will make the switch difficult
to operate. If you want to speed up or slow down, but it is difficult
to use, it may cause serious injury or death. Please check the
switch handle operation before starting. If the operation is not
smooth or stuck, check the reason before riding. If you are unable
to solve the problem, please consult your local EMMO distributor.
Side Stand
Warning
Dangerous
Dangerous
Driving Precautions

Charger Instructions
1. Overview
2. Product appearance diagram
Product Features
Enviroment and power requirements

It is strictly forobidden to use AC220V power supply for AC110V (100V)
special charger! Othervise, there may be serous security risks.
Charging method
Frequently Asked Questions and Instructions
Indicator status description

For more information and maintenance
manual of EMMO CAOFEN-F80
please visit EMMO's official website:
www.emmo.ca or scan the below QR code
to learn more!
8. Safety precautions Notice:
