ROOT INDUSTRIES Type-R User manual

ROOT INDUSTRIES COMPLETE SCOOTERS 1
OWNERS MANUAL
Before using this product, please make
sure you read and understand the entire
manual.
For any further assistance, contact Root
Industries by visiting our website:
www.rootindustries.com
CONTENTS
ROOT INDUSTRIES
2/ Safety Warnings
2/ Getting started
3/ Safety information
4/ Assembly Instructions
5/ General Maintenance
5/ Warranty
COMPLETE SCOOTER

ROOT INDUSTRIES COMPLETE SCOOTERS
2
This manual contains information for the
safety of the user. It is in your best interests
to review this information. Children should
also be accompanied by an adult who can
explain and help with fully understanding
all the warnings, cautions, instructions and
safety topics following.
Riding scooters can be a hazardous activity
Scooters are a moving vehicle and therefore it
is possible for the user to get into dangerous
situations and/ or lose control and/ or fall.
If such things occur, the user and/ or other
persons can be seriously injured or killed.
• Always obey all local traffic laws and
regulations.
• Respect pedestrians when riding on
footpaths.
Replace worn or broken parts
immediately.
• Do not exceed 220 pounds (IOOkg).
• Children under the age of eight years
old should not use this scooter. Adult
guidance is advised for all children using
this product.
• It’s the parent’s decision to allow his or
her child to ride this product. It’s also
their responsibility to judge if the child’s
maturity, skill and ability is suitable and
safe to use this product.
• This scooter was manufactured for
performance and durability, however it is
not impervious to damage. Stunt riding
can over stress or damage any product,
including this scooter and the rider
assumes all risks associated with high-
stress activities.
• Safety equipment to be worn always such
as knee pads and elbow pads.
• Do not operate this scooter without a
helmet.
• Always ride on smooth and paved
surfaces away from motor vehicles.
• Scooter could stop if it comes into contact
with sharp bumps, rocks/sticks or sudden
surface changes.
• Do not ride on surfaces where there is
water, sand, gravel, dirt or other debris.
Use while raining will impact traction and
will affect braking.
• Do not ride at night.
• Brakes do get hot from continuous use.
Do not touch the brake after braking.
• Avoid excessive speeds associated with
downhill rides.
• Adults must assist children in assembling
this scooter.
SAFETY WARNING
GETTING STARTED
LIKE ANY OTHER VEHICLE, USING A
SCOOTER CAN BE A DANGEROUS
ACTIVITY AND MAY RESULT IN INIURY
OR DEATH EVEN WHEN USED WITH
PROPER SAFETY PRECAUTIONS.
USE AT YOUR OWN RISK AND USE
COMMON SENSE.

ROOT INDUSTRIES COMPLETE SCOOTERS 3
SAFETY INFORMATION
ALWAYS USE SAFETY EQUIPMENT
GENERAL MAINTENANCE
Parental supervision is required. Only use the
scooter in a controlled environment that is
free of potential traffic hazards and not on
public streets. Avoid use in any areas where
there are other vehicles operating. Have
two hands on the handlebars always. Never
allow more than one child at a time to ride
the scooter. Never use near steps, slopes,
driveways, hills, roadways, alleyways, or
swimming pool areas.
Do not ride a scooter in wet weather.
Scooters are intended and made to be used
Ensure your child is wearing proper protective
equipment such as a certified safety helmet.
A helmet may be legally required by local
law, we advise you to check with your local
law enforcement. User should always wear
shoes that are fully enclosed with flat soles.
Proper inspection and maintenance of your
scooter can reduce the risk of injury. Always
inspect your scooter before riding and
regularly maintain it.
on concreted or smooth paved areas that are
flat, clean and dry, free from any loose debris
such as rocks, sticks or gravel. Wet, slick
or uneven and rough surfaces may impair
traction and contribute to possible accidents.
Avoid riding this scooter in mud, ice, puddles
or water. Avoid excessive speeds that can be
associated with downhill rides. Do not ride at
night or when visibility is impaired.
FAILURE TO USE COMMON SENSE
AND HEED THE ABOVE WARNINGS
FURTHER INCREASES THE RISK OF
SERIOUS INJURY. USE AT YOUR
OWN RISK AND WITH APPROPRIATE
AND SERIOUS ATTENTION TO SAFE
OPERATION. USE CAUTION.
WARNING! ALWAYS INSPECT YOUR
SCOOTER BEFORE RIDING!
Tightening your compression
If your bars start to shake or move side to side, this
means your compression needs to be tightened.
Do so by removing your handlebars and with your
6mm Allen Key and insert it into the top of your
fork as demonstrated. Turning it in a clockwise
direction, tighten until some pressure is felt in the
Allen Key. You want to be able to still spin your forks
freely, however, if over tightened you can restrict
the movement and damage your compression
or headset. This should be done by an adult or a
professional mechanic.
Tightening HIC/IHC
compression

ROOT INDUSTRIES COMPLETE SCOOTERS
4
SCOOTER ASSEMBLY INSTRUCTIONS
GENERAL MAINTENANCE (CONT.)
(Ensure all wrapping and packing materials are
taken off your scooter before you start)
With the 6mm allen key (provided), ensure the bolt
at the top of the forks is tightly fitted by turning
it clockwise. Although this is pre-tightened at
factory level, it is important to check it has not
come loose during transit. Be sure not to over-
tighten this bolt.
Slide the Handlebars onto the fork tube, ensuring
the fork and bars are lined up correctly.
Avoid twisting/turning the bars as you slide it
down. Doing so may loosen the compression.
Ensure both bars and the clamp are touching the
top of the headset.
When you are satisfied that your front wheel and
your handle bars are inline using your 6mm Allen
Key, start tightening the bolts from the bottom
up. Do this by turning the Allen Key in a clockwise
rotation.
Repeat this action until all 2 bolts are tightened
securely.
FAILURE TO TIGHTEN OR INSTALL PROPERLY
MAY RESULT IN LOSS OF CONTROL
AND INJURY. IF YOU HAVE TROUBLE
UNDERSTANDING THESE INSTRUCTIONS
SEEK ASSISTANCE OF A QUALIFIED
MECHANIC.
Tightening your SCS Compression
Slide the clamp onto the fork, tighten the
compression bolt into the fork and the top cap
compresses your front end together. Once your
front end is tightened, you install your bars into
the top of the clamp and align your bars. Your bars
are now sitting on top of the compression top cap
inside the SCS Clamp. You then tighten all four
bolts to lock both your compression and bars in
place.
Lubricating your bearings
You will need to take off your wheels to lubricate
your wheel bearings. This is done by taking 6m
Allen Key, and turning them anti clock-wise. The
wheels may need some encouragement to slide
out. Using a damp cloth wipe off any dirt or grime
on your wheels and bearings. Using bicycle bearing
oil, place 3 to 4 drops directly on the bearing
covers and allow the oil to sink in. If the wheels do
not spin freely after this you may need to replace
the bearings.

ROOT INDUSTRIES COMPLETE SCOOTERS 5
LIMITED WARRANTY
This product is covered under a limited 3 month
warranty. To activate your warranty you must
complete the warranty form which is found here:
rootindustries.com/warranty
Warranty claims are limited to the following:
DECKS
Covered
Cracks or breakages caused by manufacturing fault
or defect for a period of up to 3 months from date
of purchase.
Exclusions
Damage caused by external forces (e.g. damage
caused to the deck through impact on concrete,
excessive grinding, or other damage caused to the
deck).
Brake, inserts, axles, spacers and finishes (e.g.
paint, anodizing, decals etc) are NOT COVERED
under warranty.
BARS
Covered
Bending or breaking of the bar for a period of up
to 3 months from date of purchase. (1 month for
aluminum bars).
Exclusions
Damage caused by external forces (e.g. damage
caused to the bars through impact on concrete, or
other damage caused to the bars).
Finishes (e.g. paint, anodizing, decals, etc) are
NOT COVERED under warranty.
FORKS
Covered
Bending or breaking of the forks for a period of up
to 3 months from date of purchase.
Exclusions
Damage caused by external forces (e.g. damage
caused to the forks through impact on concrete, or
other damage caused to the bars).
Axles, shims, internal threads, spacers, finishes (e.g.
paint, anodizing, decals, etc) are NOT COVERED
under warranty.
WHEELS:
Covered
Cracks or breakages to the core caused by
manufacturing fault or defect for a period of up to 3
months from date of purchase.
Dehubbing of the wheel (must be a clean dehub
where the PU has come completely away from the
hub) for a period of up to 3 months from date of
purchase.
Core ovalising for a period of up to 3 months from
date of purchase.
Exclusions
Damage caused by external forces (e.g. damage
caused to the wheels through impact on concrete,
or any other damage caused to the wheels).
Factory-fitted bearings, spacers, and finishes (e.g.
paint, anodizing, decals etc) are NOT COVERED
under warranty.
CLAMPS
Covered
Cracking or breaking of the clamps for a period of
up to 30 days from date of purchase.
Exclusions
Damage caused by external forces (e.g. damage
caused to the forks through impact on concrete, or
other damage caused to the bars) Shims, internal
threads, finishes (e.g. paint, anodizing, decals, etc)
are NOT COVERED under warranty.
The following parts are not covered
under any warranty:
All the above parts are not covered under a
warranty, but have a standard statutory life
expectancy of a minimum 14 days. If any of
the above products “fail” within 14 days,
the manufacturer will agree to replace the
product.
GRIPS
GRIPTAPE
BEARINGS
HEADSETS
BRAKES
