Empire LTH1118-1 User manual

35719-0-0515 Page 1
EMPIRE
EMPIRE
Comfort Systems
INSTALLATION
INSTRUCTIONS
IMPORTANT! Read these instructions carefully
before installing or operating this gas appli-
ance. These instructions should be left with the
homeowner for future reference.
WARNING: If the information in this manual
LVQRWIROORZHGH[DFWO\D¿UHRUH[SORVLRQ
may result causing property damage, per-
sonal injury or loss of life.
WARNING: This log set is to be installed only
LQDVROLGIXHOEXUQLQJ¿UHSODFHZLWKDZRUNLQJ
ÀXHFRQVWUXFWHGRIQRQFRPEXVWLEOHPDWHULDO
The vent damper must also have a damper
FODPSDWWDFKHGWRLWWRNHHSWKHGDPSHUIURP
accidentally closing during operation.
TREEHOUSE
VENTED DECORATIVE GAS LOG SET
MODELS
LTH1118-1
LTH1124-1
LTH1130-1
For use on burner models:
BX(L,M,R)(18,24,30)MTN-1
LTH1124-1 Logs Shown
CONGRATULATIONS on the purchase
of your new DECORATIVE VENTED GAS
LOG SET! Your Decorative Gas Log Set is
designed and intended for installation in an
approved, existing, fully vented, wood-burn-
LQJ¿UHSODFHZLWKDJDVKRRNXS
2QFH\RXSODFHWKH¿UVWWKUHHORJV\RXDUH
free to arrange the remaining logs to suit
your taste and even re-arrange them from
time to time to suit your whimsy. The log
placement shown in this manual replicates
the set-up shown in the brochure and pro-
YLGHVDJUHDWÀDPHSDWWHUQ

35719-0-0515Page 2
LOG PLACEMENT - LTH1118
1. Attention: The placement of these 3 logs is MANDATORY.
Place logs A, B and C as shown.
2. Place logs D and E as shown.
LOG IDENTIFICATION - LTH1118
LOG A
Part No. FG10282
LOG B
Part No. FG10228
LOG C
Part No. FG10200
LOG D
Part No. FG10281
LOG E
Part No. FG10280
LOG F
Part No. FG10279
LOG G
Part No. FG10201
LOG H
Part No. FG10167
LOG I
Part No. FG10204
LOG J
Part No. FG10193
Note: Logs may differ from those shown.

35719-0-0515 Page 3
LOG PLACEMENT - LTH1118
3. Place logs F and G as shown.
4. Place logs H, I and J as shown.
5. Log placement for LTH1118-1 is complete.

35719-0-0515Page 4
LOG PLACEMENT - LTH1124
LOG IDENTIFICATION - LTH1124
LOG A
Part No. FG10282
LOG B
Part No. FG10231
LOG C
Part No. FG10232
LOG D
Part No. FG10232
LOG E
Part No. FG10229
LOG F
Part No. FG10201
LOG G
Part No. FG10279
LOG H
Part No. FG10167
LOG I
Part No. FG10281
LOG J
Part No. FG10204
LOG K
Part No. FG10193
Note: Logs may differ from those shown.
Installation
1. Attention: The placement of these 3 logs is MANDATORY.
Place Logs A, B and C as shown.
2. Place Logs D, E, and F as shown.
3. Place Logs G, H, I, J and K as shown.

35719-0-0515 Page 5
LOG PLACEMENT - LTH1130
LOG IDENTIFICATION - LTH1130
LOG A
Part No. FG10237
LOG B
Part No. FG10235
LOG C
Part No. FG10236
LOG D
Part No. FG10204
LOG E
Part No. FG10229
LOG F
Part No. FG10201
LOG G
Part No. FG10234
LOG H
Part No. FG10281
LOG I
Part No. FG10156
LOG J
Part No. FG10167
LOG K
Part No. FG10193
LOG L
Part No. FG10279
Note: Logs may differ from those shown.
Installation
1. Attention: The placement of these 3 logs is MANDATORY.
Place Logs A, B and C as shown.
2. Place Logs D, E, F, G, and H as shown.
3. Place Logs I, J and K as shown.
4. Place Log L as shown.

35719-0-0515Page 6
APPLIANCE SERVICE HISTORY
Date Dealer Name Service Technician Name Service Performed/Notes

35719-0-0515 Page 7
To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort.com. To provide
warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the
unit.
To Order PartsAfter the Warranty Period, please contact your dealer or one of the Master Parts Distributors listed below. This list changes
from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com.
Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair
parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc.
MASTER PARTS DISTRIBUTOR LIST
Parts Not Under Warranty
Parts can be ordered through your Service Person, Dealer, or a Master Parts Distributor. See this page for the Master Parts Distribu-
tors list. For best results, the service person or dealer should order parts through the distributor. Parts can be shipped directly to the
service person/dealer.
Warranty Parts
Warranty parts will need a proof of purchase and can be ordered by your Service Person or Dealer. Proof of purchase is required for
warranty parts.
$OOSDUWVOLVWHGLQWKH3DUWV/LVWKDYHD3DUW1XPEHU:KHQRUGHULQJSDUWV¿UVWREWDLQWKH0RGHO1XPEHUDQG6HULDO1XPEHUIURPWKH
name plate on your equipment. Then determine the Part Number (not the Index Number) and the Description of each part from the fol-
lowing illustration and part list. Be sure to give all this information . . .
Appliance Model Number Part Description
Appliance Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
6KLSPHQWVFRQWLQJHQWXSRQVWULNHV¿UHVDQGDOOFDXVHVEH\RQGRXUFRQWURO
HOW TO ORDER REPAIR PARTS
Dey Distributing
1401 Willow Lake Boulevard
Vadnais Heights, MN 55101
Phone: [phone]
Toll Free: 800-397-1339
Website: www.deydistributing.com
Parts: Heater, Hearth and Grills
Victor Division of F. W. Webb Company
200 Locust Street
Hartford, CT 06114
Phone: [phone]
Toll Free: 800-243-9360
Fax: [phone]
Toll Free Fax: [phone]
Websites: www.fwwebb.com & www.victormfg.com
Parts: Heater, Hearth and Grills
East Coast Energy Products
10 East Route 36
West Long Branch, NJ 07764
Phone: [phone]
Toll Free: 800-755-8809
Fax: [phone]
Website: www.eastcoastenergy.com
Parts: Heater, Hearth and Grills

35719-0-0515Page 8
EMPIRE
EMPIRE
Comfort Systems
Empire Comfort Systems Inc.
918 Freeburg Ave. Belleville, IL 62220
If you have a general question about our products, please e-mail us at
[email protected].
If you have a service or repair question, please contact your dealer.
www.empirecomfort.com
